Search Results (142)

Due to the long operation period of Beijing Metro Line 2 and the complex surrounding building environment, this paper comprehensively studied the mechanical properties of new tunnels using close-fitting undercrossing based on pre-support technology. To control structural deformation caused by the expansion project, methods such as laboratory tests, numerical simulation, and field tests were adopted to systematically analyze the tunnel mechanics during the undercrossing of existing metro lines. First, field tests were carried out on the existing Line 2 and Line 3 tunnels during the construction period. It was found that the close-fitting construction based on pre-support technology caused small deformation displacement in the subway tunnels, with little impact on the smoothness of the existing subway rail surface. The fluctuation range was −1 to 1 mm, ensuring the safety of existing subway operations. Then, a refined finite difference model for the close-fitting undercrossing construction process based on pre-support technology was established, and a series of field and laboratory tests were conducted to obtain calculation parameters. The reliability of the numerical model was verified by comparing the monitored deformation of existing structures with the simulated structural forces and deformations. The influence of construction methods on the settlement changes of existing line tracks, structures, and deformation joints was discussed. The research results show that this construction method effectively controls the settlement deformation of existing lines. The settlement deformation of existing lines is controlled within 1~3 cm. The deformation stress of the existing lines is within the concrete strength range of the existing structure, and the tensile stress is less than 3 MPa. The maximum settlement and maximum tensile stress of the station in the pre-support jacking scheme are −5.27 mm and 2.29 MPa. The construction scheme with pre-support can more significantly control structural deformation, reduce stress variations in existing line structures, and minimize damage to concrete structures. Based on the monitoring data and simulation results, some optimization measures were proposed. Full article

With the rapid advancement of urban underground space development, shield tunnel construction has seen a significant increase. However, at the initial launching stage of shield tunnels in shallow-buried weak strata, engineering risks such as face instability and sudden surface settlement frequently occur. At present, there are relatively few studies on the reinforcement technology of the initial section of shield tunnel in shallow soft ground and the evolution law of ground disturbance. This study takes the launching section of the Guanggang New City depot access tunnel on Guangzhou Metro Line 10 as the engineering background. By applying MIDAS/GTS numerical simulation, settlement monitoring, and theoretical analysis, the reinforcement technology at the tunnel face, the spatiotemporal evolution of ground settlement, and the mechanism of soil disturbance transmission during the launching process in muddy soil layer are revealed. The results show that: (1) the reinforcement scheme combining replacement filling, high-pressure jet grouting piles, and soil overburden counterpressure significantly improves surface settlement control. The primary influence zone is concentrated directly above the shield machine and in the forward excavation area. (2) When the shield machine reaches the junction between the reinforced and unreinforced zones, a large settlement area forms, with the maximum ground settlement reaching −26.94 mm. During excavation in the unreinforced zone, ground deformation mainly occurs beneath the rear reinforced section, with subsidence at the crown and uplift at the invert. (3) The transverse settlement trough exhibits a typical Gaussian distribution and the discrepancy between the measured maximum settlement and the numerical and theoretical values is only 3.33% and 1.76%, respectively. (4) The longitudinal settlement follows a trend of initial increase, subsequent decrease, and gradual stabilization, reaching a maximum when the excavation passes directly beneath the monitoring point. The findings can provide theoretical reference and engineering guidance for similar projects. Full article

The prediction of ground deformation during ultra-shallow-buried pilot tunnel construction is critical for urban rail transit projects in complex geological settings, yet existing cross-section models often lack accuracy. This study proposes an enhanced non-uniform convergence model based on stochastic medium theory, which decomposes surface settlement into uniform soil shrinkage and non-uniform initial support deformation. A computational formula for horseshoe-shaped sections is derived and validated through field data from Kunming Rail Transit Phase I, demonstrating a 59% improvement in maximum settlement prediction accuracy (reducing error from 7.5 mm to 3.1 mm) compared to traditional methods. Its application to Beijing Metro Line 13 reveals two distinct deformation patterns: significant ground heave occurs at 2.5 times the tunnel width from the centerline, while maximum settlement concentrates above the excavation center and diminishes radially. To mitigate heave, early strengthening of the secondary lining is recommended to control initial horizontal deformation. These findings enhance prediction reliability and provide actionable insights for deformation control in similar urban tunneling projects, particularly under ultra-shallow burial conditions. Full article

This study established a numerical model for a foundation pit at the Zhongyilu Station of the Wuhan Metro Line 12, using Plaxis3D version 2021 finite element software to examine the horizontal displacement of the diaphragm wall, ground surface settlement, and differential settlement between the diaphragm wall and the lattice columns across various construction stages. A comparison with the cut-and-cover method prompted the adoption of a strategy that integrates segmental pouring of the main structure and the installation of internal supports to optimize the original scheme. The results indicated that as the foundation pit was excavated, both the horizontal displacement of diaphragm wall and the ground surface settlement gradually increased, while the differential settlement between the diaphragm wall and the lattice columns shows exhibited an initial decrease followed by an increase. In comparison to the cut-and-cover method, the cover-and-cut method demonstrated greater efficacy in controlling foundation pit deformation and minimizing disturbances to surrounding environment. As the number of segmental pouring layers and support levels increased, the overall deformation of the foundation pit showed a gradual decreasing trend, and the differential settlement between the diaphragm wall and the lattice columns continued to fluctuate. When each floor slab was poured in three layers with two supports placed in the middle, the maximum horizontal displacement of the diaphragm wall could be reduced by 22.47%, and the maximum ground surface settlement could be decreased by 19.01%. The findings in this research can provide valuable basis and reference for the design and construction of similar projects. Full article

Using the shield project of the Cai Cang Section tunnel of the Guangzhou Metro Line 13 to solve the problem that shield construction is difficult to start in a narrow space and it is easy to disturb the surrounding buildings and pipelines, the corresponding shield tunneling parameters, construction and transportation plans, residual soil management plans, and grouting reinforcement plans are designed. These are tailored according to different working conditions. Meanwhile, the MIDAS GTS 2022 numerical simulation software is applied to simulate and analyze the impact of shield tunneling construction on soil deformation, and to compare the effects before and after reinforcement of the soil layer during shield tunneling. The results show the amount of disturbance of building pipelines along the tunnel are effectively controlled by designing the corresponding shield tunneling parameters for three working conditions: contact reinforcement zone, entering reinforcement zone, and exiting reinforcement zone. In narrow spaces, three kinds of construction transportation modes (namely, horizontal transportation in the tunnel, translation transportation in the cross passage, and vertical transportation) ensure the smooth transportation of pipe segments and the smooth discharge of shield dregs. After the reinforced area is constructed, secondary grouting with cement mortar effectively reduces the erosion concrete segments by underground water. By comparing the deformation of the tunnel soil layer before and after reinforcement, it is found that the maximum surface deformation of the soil layer is significantly reduced after reinforcement. Specifically, the maximum settlement and maximum uplift are 0.782 mm and 1.87 mm respectively, which represent a reduction of 1.548 mm in the maximum surface settlement, and 0.16 mm in the maximum uplift compared with the unreinforced soil layer. This indicates that setting up a soil reinforcement zone during the initial launching stage can effectively reduce soil deformation. The Cai Cang Section tunnel shield project successfully completed the shield construction in a narrow space, which can be a reference and guide for similar projects. Full article

Surface settlement prediction is crucial to assess the safety of subway station construction. To overcome challenges such as missing on-site settlement data and a limited number of monitoring points, this study proposes a composite prediction model that integrates finite element analysis, a time-series interval GA-BP neural network, and variational mode decomposition (VMD) techniques. Using the Dongba-zhongjie Station in Beijing Subway Line 3 as a case study, surface settlement predictions were made for both typical monitoring points and randomly selected feature points throughout the construction period, followed by validation. The experimental results show that the root mean square error (RMSE) of the finite element model is 15.77%, confirming the model’s effectiveness. As excavation progressed through the second underground floor and bottom plate, the settlement at the maximum settlement point began to rebound, and the structure tended to stabilize. At this stage, construction of the comprehensive utility tunnel above the station can proceed concurrently. Full article

Pipeline leakage can induce ground surface settlements and structural responses in existing tunnels. A thorough understanding of pipeline–tunnel interactions is crucial for optimizing urban underground design and establishing construction guidelines. As urban underground spaces undergo rapid, large-scale development, their layouts have grown increasingly complex. Previous studies have mainly focused on the leakage propagation range and the resulting strata instability during tunnel excavation, while paying limited attention to the effects of pipeline leakage on existing tunnels. This study systematically investigated the mechanical response of existing tunnel structures to pipeline leakage under different layout configuration conditions using numerical modeling. A two-dimensional numerical model was developed to simulate the pipeline leakage process and its impact on adjacent tunnels. The research established a correlation between surrounding rock strength parameters and the saturation degree while examining the evolution patterns of leakage effects in various tunnel–pipeline arrangements. The analysis specifically focused on the mechanical influence of horizontal pipeline–tunnel distance, quantitatively determining the relationships among pipeline–tunnel spacing, leakage duration, and structural internal force. The horizontal pipeline–tunnel distance did not influence the development of the leakage zone above the tunnel vault but significantly altered the seepage path length and interface contact area. The complete encapsulation of the tunnel periphery by the leakage zone required progressively longer durations with increasing horizontal offsets: 16 days (0 m), 20 days (3 m), and 33 days (6 m). Corresponding circumferential contact ratios at 10 days were measured at 68.9%, 56.4%, and 30.6%, respectively. Furthermore, prolonged seepage duration led to increased ground subsidence with expanded affected areas, while the maximum settlement decreased proportionally with greater horizontal separation from the tunnel. These findings provide valuable insights for planning, designing, and maintaining “old tunnel-new pipeline” systems in urban underground development. Full article

Due to the intersection of three mining rights in a mining area, the stability of the rock mass is mutually affected after mining operations. To study the optimal backfill ratio and the surface stability after backfilling in the adjacent goaf areas of the three mines in this mining area, a mineral deposit model is established using Rhino software. The model spans 2500 m in the east–west direction, 3000 m in the north–south direction, and ranges from an underground elevation of −610 m below. FLAC3D software was then used to analyze the surface stability under two different backfill ratios after the complete excavation of the ore body. Additionally, 52 monitoring points were set up at critical buildings and structures. The results revealed that after the complete excavation of the ore body, large-scale surface subsidence occurred in the mining area, with the main subsidence center located in the Yinzhushan mining area. Under backfill condition 1, six monitoring points experienced settlements exceeding 30.00 mm, with a maximum settlement of 53.98 mm. Under backfill condition 2, three monitoring points exceeded 30.00 mm, with a maximum settlement of 51.93 mm. The level displacement deformation at the monitoring points under both conditions met the stability requirements specified by national standards. By comparing the settlements at the monitoring points, it was determined that backfill condition 2 represents the optimal backfill ratio. This study provides a theoretical basis for practical backfilling operations in the mine. Full article

This paper investigates the frost heave and thaw settlement characteristics of the pipe–soil system during the freeze–thaw cycle, along with the underlying mechanisms. A numerical simulation platform for the complex pipe–soil system was developed using the heat conduction equation, moisture migration equation, and stress–strain equation, all of which account for the ice–water phase change process. The simulations were performed with the coefficient-type partial differential equation (PDE) module in COMSOL Multiphysics. By employing coupled thermal–hydraulic–mechanical (THM) simulation methods, the study analyzed the changes in volumetric water content, volumetric ice content, moisture migration patterns, and temperature field distribution of a water pipeline after three years of service under real engineering conditions in the cold region of northern Xinjiang, China. The study also examined the effects of parameters such as pipeline burial depth, specific heat capacity, thermal conductivity, permeability of saturated soil, and initial saturation on the displacement field. The results show that selecting soil layers with high specific heat capacity (e.g., 1.68 kJ/kg·°C) and materials with high thermal conductivity (e.g., 2.25 W/m·°C) can reduce surface frost heave displacement by up to 40.8% compared to low-conductivity conditions. The maximum freezing depth near the pipeline is limited to 0.87 m due to the thermal buffering effect of water flow. This research provides a scientific reference and theoretical foundation for the design of frost heave resistance in water pipelines in seasonally frozen regions. Full article

This study investigates the impact of flower tube grouting reinforcement on surface settlement in shield tunnels under complex geological conditions, using the Wuhan Metro Line 12 project as a case example. A simulation model was constructed using PLAXIS 3D software to analyze surface settlement under unreinforced conditions and compare it with reinforced conditions. The effects of grouting pressure, soil pressure, and tunnel depth on surface settlement were also examined. Results indicate that surface settlement decreases with increasing tunnel depth, decreasing by approximately 0.15 mm per 1 m increase in depth. Soil silo pressure positively correlates with surface settlement, increasing by about 0.08 mm for every 10 kPa rise in pressure. A critical grouting pressure of approximately 400 kPa was identified, beyond which surface settlement increases with higher grouting pressure. Flower tube grouting significantly reduced surface settlement, by 92% on average, limiting maximum settlement to 3 mm. Numerical simulation results closely matched field monitoring data, with errors within ±0.5 mm, validating the model’s reliability. The study demonstrates that flower tube grouting reinforcement effectively mitigates the effects of tunnel depth, grouting pressure, and soil bin pressure on surface settlement, ensuring project safety when shield tunnels pass through sensitive areas such as long-distance railroads. Full article

This study utilized unmanned aerial systems (UAS) and terrestrial laser scanners (TLS) to develop a 3D numerical model of slope anchors and conduct a comprehensive analysis. Initial data were collected using a UAS with 4 K resolution, followed by a second dataset captured 6 months later with 8 K resolution after artificially damaging the anchor. The model analyzed damage factors such as cracks, destruction, movement, and settlement. Cracks smaller than 0.3 mm were detected with an error margin of ±0.05 mm. The maximum damaged area on the anchor head was within 3% of the designed value, and the volume of damaged regions was quantified. A combination analysis examined elevation differences on the anchor’s irregular bottom surface, resulting in an average difference at 20 points, reflecting ground adhesion. The rotation angle (<1°) and displacement of the anchor head were also measured. The study successfully extracted quantitative damage data, demonstrating the potential for an accurate assessment of anchor performance. The findings highlight the value of integrating UAS and TLS technologies for slope maintenance. By organizing these quantitative metrics into a database, this approach offers a robust alternative to traditional visual inspections, especially for inaccessible facilities, providing a foundation for enhanced safety evaluations. Full article

Ground subsidence is a critical factor affecting the structural integrity and operational safety of high-speed railways, especially in areas with widespread soft ground. This study applies Persistent Scatterer Interferometric Synthetic Aperture Radar (PS-InSAR) techniques to monitor ground deformation along the Honam High-Speed Railway in South Korea. By processing a time series of 29 high-resolution SAR images from 2016 to 2019, the analysis yielded continuous, millimeter-level measurements of surface displacement. Maximum subsidence rates exceeding −12 mm/year were detected in embankment zones with soft subsoil conditions Validation using leveling data and corner reflectors showed strong agreement (R² > 0.93), confirming the accuracy and reliability of PS-InSAR-derived results. The study also revealed seasonal variation in settlement patterns, highlighting the influence of rainfall and pore water pressure. The findings underscore the utility of PS-InSAR as a sustainable and cost-effective tool for long-term infrastructure monitoring. This study further contributes to the development of predictive maintenance strategies and highlights the need for future research integrating PS-InSAR with geotechnical, hydrological, and construction-related variables to enhance monitoring precision and expand its practical applicability in infrastructure management. Full article

The development of underground spaces is crucial for modern urban environments, particularly in coastal cities with prevalent soft soil conditions. Deep foundation excavation works in such areas present technical challenges due to complex deformation phenomena including soil settlement and the lateral displacement of supporting structures. This study analyzes deformation patterns associated with deep foundation pit excavations in Ningbo’s soft soil areas by examining 10 cases of subway station projects. This study evaluated the relationship between the maximum surface settlement and various engineering parameters using statistical and comparative analyses and also compared the results of each relationship with those of other regional studies. The results indicate that multiple coupled parameters—the excavation depth, diaphragm-wall-embedded depth ratio, support system stiffness, and pit aspect ratio—significantly shape the deformation patterns. The average ratio of the maximum surface settlement to the excavation depth is 0.64%, notably higher than in regions such as Hangzhou and Shanghai. The maximum lateral displacement in this study averaged 0.37% of the excavation depth. The maximum lateral displacement of the diaphragm walls in this study averaged 0.37% of the depth of excavation and, in addition, the average positive correlation between the depth at which the maximum lateral displacement occurred and the depth of pit excavation was $h_{\delta \mathrm{h}\mathrm{m}\mathrm{a}\mathrm{x}}=H_e$ + 1.46. A positive correlation also emerged between the maximum ground settlement and lateral displacement of the diaphragm walls. But the influence of the shape of the pit on the deformation will show different types of relationships depending on the area and geotechnical conditions, which need to be further investigated. Full article

The construction of urban subway tunnels typically induces soil settlement within a specific radius of the surrounding area. However, the accuracy of current methods for predicting ground deformation curves corresponding to the excavation of double-track tunnels with small spacing remains insufficient. Most studies simplify this problem by modeling it as a two-dimensional plane problem; however, the actual ground deformation exhibits pronounced three-dimensional characteristics. Consequently, studying the ground settlement patterns caused by the construction of small-spacing double-track tunnels is crucial. This study is based on the Peck formula, used to calculate surface settlement caused by the excavation of single-track tunnels. By incorporating the maximum settlement offset e and the soil loss rate η(y), the soil displacement calculation formula is derived for small-spacing double-track tunnel excavation. The accuracy of the derived formula is then validated through a case study. The findings provide a theoretical reference for predicting surface settlement induced by the excavation of small-spacing double-track tunnels. Furthermore, the influence of different parameters on ground settlement patterns is explored. The results indicate that appropriately increasing the tunnel spacing, increasing burial depth, and adopting a sequential excavation method for the two tunnels help reduce ground settlement. Full article

In the current excavation of water diversion tunnels, significant challenges such as water inrush, rockburst, and large deformations continue to persist. Consequently, research on the stability of the surrounding rock after tunnel excavation is of great scientific importance. To address the impact of groundwater on tunnel-surrounding rock deformation under complex geological conditions, this study utilizes a combination of field monitoring and numerical simulation. Specifically, the research simulates the excavation process under both groundwater and non-groundwater conditions. Systematically, it analyzes the deformation patterns of tunnel-surrounding rock under groundwater conditions. The findings reveal the following: (1) Settlement and excavation mileage exhibit a clear trend of “steep decline, gradual decline, stable,” both stabilizing around 35 m after the excavation reaches the monitoring cross-section. Changes in groundwater levels, whether rising or falling, can either accelerate or delay the point at which settlement stability is achieved. (2) The numerical simulation settlement curves closely align with the field monitoring curves, with simulated settlement values slightly exceeding the monitored results. However, the error rate between the two remains below 20%, indicating the reliability of the method. (3) Groundwater significantly impacts water-sensitive strata such as loess and sandstone, with maximum settlement values at the tunnel vault and ground surface under groundwater conditions being 2 to 3 times those observed in the absence of groundwater. This study provides a scientific basis for optimizing tunnel design and construction processes. Future research should focus on refining the numerical simulation model, by incorporating additional monitoring data for validation and enhancing the safety of tunnel construction. Full article
