Search Results (68)

Magnetoelectric composites enable strain-mediated coupling between magnetic and electric fields, supporting applications in sensors, actuators, and tunable devices. This study presents a finite element modeling framework for simulating the direct magnetoelectric effect in core–shell and layered nanocomposites fabricated by material jetting (inkjet printing). The model incorporates nonlinear magnetostrictive behavior of cobalt ferrite nanoparticles and size-dependent piezoelectric properties of barium titanate, allowing efficient simulation of complex interfacial strain transfer. Results show a strong dependence of coupling on field orientation, particle arrangement, and interfacial geometry. Simulations of printed droplet geometries, including coffee ring droplet morphologies, reveal enhanced performance through increased surface area and directional alignment. These findings highlight the potential of material jetting for customizable, high-performance magnetoelectric devices and provide a foundation for simulation-guided design. Full article

Fiber-optic sensing has shown promising development for use in detecting magnetic fields for downhole and biomedical applications. Coupling existing fiber-based strain sensors with highly magnetostrictive materials allows for a new method of magnetic characterization capable of distributed and high-sensitivity field measurements. This study investigates the strain response of the highly magnetostrictive alloys Metglas^® 2605SC and Vitrovac^® 7600 T70 using Fiber Bragg Grating (FBG) acoustic sensors and an applied AC magnetic field. Sentek Instrument’s picoDAS interrogated the distributed FBG sensors set atop a ribbon of magnetostrictive material, and the corresponding strain response transferred to the fiber was analyzed. Using the Vitrovac^® ribbon, a minimal detectable field amplitude of 60 nT was achieved. Using Metglas^®, an even better sensitivity was demonstrated, where detected field amplitudes as low as 3 nT were measured via the strain response imparted to the FBG sensor. Distributed FBG sensors are readily available commercially, easily integrated into existing interrogation systems, and require no bonding to the magnetostrictive material for field detection. The simple sensor configuration with nanotesla-level sensitivity lends itself as a promising means of magnetic characterization and demonstrates the potential of fiber-optic acoustic sensors for distributed measurements. Full article

FeGa alloys with small additions of rare-earth elements surpass binary alloys in magnetostriction and plasticity. For this reason, they are considered promising magnetostrictive materials for various electrical engineering applications. The alloy (Fe₈₁Ga₁₉)_99.8Ce_0.2 was prepared and investigated in this work. It was found that in the cast state, it has a magnetostriction of 3/2 λ about 100 ppm, saturation magnetization of 150 emu/g, tensile strength of about 300 MPa, and fracture strain of 3%. The microstructure, crystallographic texture, and behavior when heated of the alloy were investigated. Then the ingot was subjected to forging and hot rolling with a deformation degree of 90% at 1000 °C. The structure and mechanical properties of samples cut from a hot rolling sheet were studied. Their tensile strength and fracture strain increase compared to cast state up to 600 MPa and 4% correspondingly. Full article

Soft magnetoactive elastomers (MAEs) are currently considered to be promising materials for actuators in soft robotics. Magnetically controlled actuators often operate in the vicinity of a bias point. Their dynamic properties can be characterized by the piezomagnetic strain coefficient, which is a ratio of the time-harmonic strain amplitude to the corresponding magnetic field strength. Herein, the dynamic strain response of a family of MAE cylinders to the time-harmonic (frequency of 0.1–2.5 Hz) magnetic fields of varying amplitude (12.5 kA/m–62.5 kA/m), superimposed on different bias magnetic fields (25–127 kA/m), is systematically investigated for the first time. Strain measurements are based on optical imaging with sub-pixel resolution. It is found that the dynamic strain response of MAEs is considerably different from that in conventional magnetostrictive polymer composites (MPCs), and it cannot be described by the effective piezomagnetic constant from the quasi-static measurements. The obtained maximum values of the piezomagnetic strain coefficient (∼${10}^2$ nm/A) are one to two orders of magnitude higher than in conventional MPCs, but there is a significant phase lag (35–60°) in the magnetostrictive response with respect to an alternating magnetic field. The experimental dependencies of the characteristics of the alternating strain on the amplitude of the alternating field, bias field, oscillation frequency, and aspect ratio of cylinders are given for several representative examples. It is hypothesized that the main cause of observed peculiarities is the non-linear viscoelasticity of these composite materials. Full article

This report is on magneto-electric (ME) interactions in bulk composites with coaxial fibers of nickel–zinc ferrite and PZT. The core–shell fibers of PZT and Ni_1−xZn_xFe₂O₄ (NZFO) with x = 0–0.5 were made by electrospinning. Both kinds of fibers, either with ferrite or PZT core and with diameters in the range of 1–3 μm were made. Electron and scanning probe microscopy images indicated well-formed fibers with uniform core and shell structures and defect-free interface. X-ray diffraction data for the fibers annealed at 700–900 °C did not show any impurity phases. Magnetization, magnetostriction, ferromagnetic resonance, and polarization P versus electric field E measurements confirmed the ferroic nature of the fibers. For ME measurements, the fibers were pressed into disks and rectangular platelets and then annealed at 900–1000 °C for densification. The strengths of strain-mediated ME coupling were measured by the H-induced changes in remnant polarization P_r and by low-frequency ME voltage coefficient (MEVC). The fractional change in P_r under H increased in magnitude, from +3% for disks of NFO–PZT to −82% for NZFO (x = 0.3)-PZT, and a further increase in x resulted in a decrease to a value of −3% for x = 0.5. The low-frequency MEVC measured in disks of the core–shell fibers ranged from 6 mV/cm Oe to 37 mV/cm Oe. The fractional changes in P_r and the MEVC values were an order of magnitude higher than for bulk samples containing mixed fibers with a random distribution of NZFO and PZT. The bulk composites with coaxial fibers have the potential for use as magnetic field sensors and in energy-harvesting applications. Full article

Inkjet printing of magnetic materials has increased in recent years, as it has the potential to improve research in smart, functional materials. Magnetostriction is an inherent property of magnetic materials which allows strain or magnetic fields to be detected. This makes it very attractive for sensors in the area of structural health monitoring by detecting internal strains in carbon fibre-reinforced polymer (CFRP) composite. Inkjet printing offers design flexibility for these sensors to influence the magnetic response to the strain. This allows the sensor to be tailored to suit the location of defects in the CFRP. This research has looked into the viability of printable soft magnetic materials for structural health monitoring (SHM) of CFRP. Magnetite and nickel ink dispersions were selected to print using the JetLab 4 drop-on-demand technique. The printability of both inks was tested by selecting substrate, viscosity and solvent evaporation. Clogging was found to be an issue for both ink dispersions. Sonicating and adjusting the jetting parameters helped in distributing the nanoparticles. We found that magnetite nanoparticles were ideal as a sensor as there is more than double increase in saturation magnetisation by 49 Am²/kg and more than quadruple reduction of coercive field of 5.34 kA/m than nickel. The coil design was found to be the most sensitive to the field as a function of strain, where the gradient was around 80% higher than other sensor designs. Additive layering of 10, 20 and 30 layers of a magnetite square patch was investigated, and it was found that the 20-layered magnetite print had an improved field response to strain while maintaining excellent print resolution. SHM of CFRP was performed by inducing a strain via bending and it was found that the magnetite coil detected a change in field as the strain was applied. Full article

We present a macroscale constitutive model that couples magnetism with thermal, elastic, plastic, and damage effects in an Internal State Variable (ISV) theory. Previous constitutive models did not include an interdependence between the internal magnetic (magnetostriction and magnetic flux) and mechanical fields. Although constitutive models explaining the mechanisms behind mechanical deformations caused by magnetization changes have been presented in the literature, they mainly focus on nanoscale structure–property relations. A fully coupled multiphysics macroscale ISV model presented herein admits lower length scale information from the nanoscale and microscale descriptions of the multiphysics behavior, thus capturing the effects of magnetic field forces with isotropic and anisotropic magnetization terms and moments under thermomechanical deformations. For the first time, this ISV modeling framework internally coheres to the kinematic, thermodynamic, and kinetic relationships of deformation using the evolving ISV histories. For the kinematics, a multiplicative decomposition of deformation gradient is employed including a magnetization term; hence, the Jacobian represents the conservation of mass and conservation of momentum including magnetism. The first and second laws of thermodynamics are used to constrain the appropriate constitutive relations through the Clausius–Duhem inequality. The kinetic framework employs a stress–strain relationship with a flow rule that couples the thermal, mechanical, and magnetic terms. Experimental data from the literature for three different materials (iron, nickel, and cobalt) are used to compare with the model’s results showing good correlations. Full article

Significant deformations of bodies made from compliant magnetoactive elastomers (MAE) in magnetic fields make these materials promising for applications in magnetically controlled actuators for soft robotics. Reported experimental research in this context was devoted to the behaviour in the quasi-static magnetic field, but the transient dynamics are of great practical importance. This paper presents an experimental study of the transient response of apparent longitudinal and transverse strains of a family of isotropic and anisotropic MAE cylinders with six different aspect ratios in time-varying uniform magnetic fields. The time dependence of the magnetic field has a trapezoidal form, where the rate of both legs is varied between 52 and 757 kA/(s·m) and the maximum magnetic field takes three values between 153 and 505 kA/m. It is proposed to introduce four characteristic times: two for the delay of the transient response during increasing and decreasing magnetic field, as well as two for rise and fall times. To facilitate the comparison between different magnetic field rates, these characteristic times are further normalized on the rise time of the magnetic field ramp. The dependence of the normalized characteristic times on the aspect ratio, the magnetic field slew rate, maximum magnetic field values, initial internal structure (isotropic versus anisotropic specimens) and weight fraction of the soft-magnetic filler are obtained and discussed in detail. The normalized magnetostrictive hysteresis loop is introduced, and used to explain why the normalized delay times vary with changing experimental parameters. Full article

The magnetoelectric effect (ME) is an important strain mediated-phenomenon in a ferromagnetic-piezoelectric composite for a variety of sensors and signal processing devices. A bias magnetic field, in general, is essential to realize a strong ME coupling in most composites. Magnetic phases with (i) high magnetostriction for strong piezomagnetic coupling and (ii) large anisotropy field that acts as a built-in bias field are preferred so that miniature, ME composite-based devices can operate without the need for an external magnetic field. We are able to realize such a magnetic phase with a composite of (i) barium hexaferrite (BaM) with high magnetocrystalline anisotropy field and (ii) nickel ferrite (NFO) with high magnetostriction. The BNx composites, with (100 − x) wt.% of BaM and x wt.% NFO, for x = 0–100, were prepared. X-ray diffraction analysis shows that the composites did not contain any impurity phases. Scanning electron microscopy images revealed that, with an increase in NFO content, hexagonal BaM grains become prominent, leading to a large anisotropy field. The room temperature saturation magnetization showed a general increase with increasing BaM content in the composites. NFO rich composites with x ≥ 60 were found to have a large magnetostriction value of around −23 ppm, comparable to pure NFO. The anisotropy field H_A of the composites, determined from magnetization and ferromagnetic resonance (FMR) measurements, increased with increasing NFO content and reached a maximum of 7.77 kOe for x = 75. The BNx composite was cut into rectangular platelets and bonded with PZT to form the bilayers. ME voltage coefficient (MEVC) measurements at low frequencies and at mechanical resonance showed strong coupling at zero bias for samples with x ≥ 33. This large in-plane H_A acted as a built-in field for strong ME effects under zero external bias in the bilayers. The highest zero-bias MEVC of ~22 mV/cm Oe was obtained for BN75-PZT bilayers wherein BN75 also has the highest H_A. The Bilayer of BN95-PZT showed a maximum MEVC ~992 mV/cm Oe at electromechanical resonance at 59 kHz. The use of hexaferrite–spinel ferrite composite to achieve strong zero-bias ME coupling in bilayers with PZT is significant for applications related to energy harvesting, sensors, and high frequency devices. Full article

In Tb-Dy-Fe alloy systems, Tb_0.29Dy_0.71Fe_1.95 alloy shows giant magnetostrictive properties under low magnetic fields, thus having great potential for transducers, microsensors, and other applications. The C15 cubic crystal structure of Tb-Dy-Fe has long been thought to be the source of giant magnetostriction. It is surprising that such a highly symmetrical crystal structure exhibits such a large magnetostrictive strain. In this work, the lattice parameters of Tb_0.29Dy_0.71Fe_1.95 magnetostrictive materials were studied by processing atomic-resolution images. The selected area diffraction patterns show a face-centered cubic structure, but the fast Fourier transform diagram shows that the cubic structure has obvious distortion. The lattice parameters obtained by geometric phase analysis (GPA) and Gaussian model-based fitting and calculation show that the lattice constants a, b, and c are not strictly equal, and small disturbance of the lattice constants occurs based on the cubic structure. The actual crystal structure of the Tb-Dy-Fe material is a slightly disturbed cubic structure. This variation in the crystal lattice is mainly caused by the inhomogeneous composition and may be related to the giant magnetostrictive properties of Tb-Dy-Fe alloy. Full article

Defects are an inevitable occurrence during the manufacturing and use of ferromagnetic materials, making it crucial to study the microscopic mechanism of magnetostrictive properties of ferromagnetic materials with defects. This paper conducts molecular dynamics simulations on low-dimensional iron thin films containing hole or crack defects, analyzes and compares the impact of defect size on magnetostrictive properties, and investigates the microscopic mechanism of their effects. The results indicate that the saturation magnetostrictive strains of the defect models do not increase monotonically as the defect size increases. Additionally, it is discovered that the arrangement of atomic magnetic moments in the initial magnetic moment configuration also affects the magnetostrictive properties. When controlling the size of the hole or crack within a certain defect area, it is found that the hole size has less influence on the initial magnetic moment configuration, resulting in a smaller corresponding change in the saturation strain and thus having a lesser impact on the magnetostrictive properties. Conversely, when the crack size changes, the arrangement of the atomic magnetic moments in the initial magnetic moment configuration changes more significantly, resulting in a greater corresponding change in saturation strain, and thus having a greater impact on the magnetostriction performance. Full article

Chromium (Cr)-doped cobalt ferrite nanoparticles were synthesized using a sol–gel autocombustion method, with the chemical formula CoCr_xFe_2xO₄. The value of x ranged from 0.00 to 0.5 in 0.1 increments. X-ray diffraction analysis confirmed the development of highly crystalline cubic spinel structures for all samples, with an average crystallite size of approximately 40 to 45 nm determined using the Scherrer equation. Pellets were prepared using a traditional ceramic method. The magnetic and magnetostrictive properties of the samples were tested using strain gauge and VSM (vibrating sample magnetometer) techniques. The results of the magnetic and magnetostrictive tests showed that the chromium-substituted cobalt ferrites exhibited higher strain derivative magnitudes than pure cobalt ferrite. These findings indicated that the introduction of chromium into the cobalt ferrite structure led to changes in the material’s magnetic properties. These changes were attributed to anisotropic contributions, resulting from an increased presence of Co²⁺ ions at B-sites due to the chromium substitutions. In summary, this study concluded that introducing chromium into the cobalt ferrite structure caused alterations in the material’s magnetic properties, which were explained by changes in the cationic arrangement within the crystal lattice. This study successfully explained these alterations using magnetization and coercivity data and the probable cationic dispersion. Full article

A composite current sensor is designed with soft ferrite as the magnetizer in combination with giant magnetostrictive material (GMM) and fiber Bragg grating (FBG). The temperature drift characteristics of the GMM, detecting performances under thermal strain caused by temperature variation in the GMM rod, are investigated by simulating the coupled fields of magnetostriction and thermal expansion with the finite-element multi-physics method to explore the temperature-drift mechanism of the ferrite–GMM current detector. The sensing characteristics of the GMM-FBG current sensor under quasi-static current excitation at various work temperatures are evaluated by simulating thermal stress between the GMM and FBG to analyze the temperature drift mechanism of the Bragg wavelength signal modulated by FBG. Even though temperature elevation suppresses GMM magnetization and thereby reduces the slopes of stress–strain curves, the steering magnetization of magnetic domains in the GMM rod tends to saturation without appreciable thermal inhibition in the high-stress region of large current excitation, while the magnetostrictive strain is still abated by the reduction in magnetic flux density caused by the thermal expansion of GMM rods. The temperature elevation can also produce thermal stress between the GMM and FBG, which will decrease the detection sensitivity and testing range of the GMM-FBG current sensor. The temperature drift characteristics of the GMM-FBG are generalized into a formula by fitting the wavelength shifting as a function of thermal strain, which will significantly facilitate designing the scale calibration for various ambient temperatures. The present researchers provide a theoretical basis and experimental guidance for developing GMM-FBG current sensors with high sensitivity and stability. Full article

This paper proposes a multilevel three-dimensional constitutive model based on a microscopically phenomenological approach from the domain rotation mechanism, which is a fully coupled self-consistent homogenization scheme considering the interactions between elastic–inelastic strain and hysteresis. Considering the interactions among magnetic domains, grains, polycrystalline complexes, and macroscopic phenomenology, we predict the nonlinear magnetostrictive response of Terfenol-D under different types of external force loads and magnetic excitations in various thermal environments involving multi-fields of coupled magnetic, elastic, thermal, and mechanical phenomena. The average values of the mechanical bulk strains for different magnetization states are obtained at the grain scale utilizing Boltzmann functions and a self-consistent homogenization scheme. A Taylor series expansion of the Gibbs function concerning the field variables and an adapted Jiles–Atherton model are used to construct the hysteresis coupled constitutive relations at the macroscopic scale. The results associated with the experiments show that the established model can reasonably predict the magnetostrictive response under different external mixed stimuli. It can provide theoretical guidance for the precise control of nonlinear vibrations and the optimal design of the rotating giant magnetostrictive transducers at both microscopic and macroscopic multiple scales. Full article

As is well known, the magnetostrictive phenomenon of electrical steel sheet is the main source of electricity in equipment such as transformers. The magnetostrictive characteristic of the actual transformer core is more complicated than that of single-sheet steel. The magnetostriction phenomenon of the transformer core cannot be fully understood by studying only a single piece of electrical steel, so it is necessary to study the local magnetic characteristics of the transformer directly. In this paper, two-limb, one-phase transformer core with a multi-step-lap construction was assembled, a laminated magnetostrictive testing system based on triaxial strain gauges was built, and the local magnetic characteristics were studied using a self-developed B-H vector sensor. The magnetostrictive and magnetic properties in different local regions were measured and analyzed under several magnetization patterns, and the influence of DC bias on the magnetostrictive property of the corner, yoke, and limb of the core was investigated. The influence of the position of the clamp on the magnetostriction of the transformer core was also studied. The magnetostrictive strain of the single sheet and laminated core was compared and discussed. The results showed that the strain caused by the interaction between laminations in this area can be effectively reduced when clamping in the middle of the yoke. Full article
