Permanent magnetic couplings provide critical advantages for deep-sea systems through static-sealed, contactless power transmission. However, conventional metallic isolation sleeves incur significant eddy current losses, limiting efficiency and high-speed operation. Limited torque capacities fail to meet the operational demands of harsh marine environments. This study presents a novel permanent magnet coupling featuring a ceramic isolation sleeve engineered for deep-sea cryogenic ammonia submersible pumps. The ceramic sleeve eliminates eddy current losses and provides exceptional corrosion resistance in acidic/alkaline environments. To withstand 3.5 MPa hydrostatic pressure, a 6-mm-thick sleeve necessitates a 10 mm operational air gap, challenging magnetic circuit efficiency. To address this limitation, an improved 3D magnetic equivalent circuit (MEC) model was developed that explicitly accounts for flux leakage and axial end-effects, enabling the accurate characterization of large air gap fields. Leveraging this model, a Taguchi method-based optimization framework was implemented by balancing key parameters to maximize the torque density. This co-design strategy achieved a 21% increase in torque density, enabling higher torque transfer per unit volume. Experimental validation demonstrated a maximum torque of 920 Nm, with stable performance under simulated deep-sea conditions. This design establishes a new paradigm for high-power leak-free transmission in corrosive, high-pressure marine environments, advancing applications from deep-sea propulsion to offshore energy systems. Full article

Torque modeling is an important research aspect of multi-degree of freedom (multi-DOF) spherical motors, and it is the key to realizing the accurate control of multi-DOF spherical motors. In this paper, a torque modeling method of the reluctance spherical motor (RSPM) based on the magnetic equivalent circuit (MEC) method is proposed. Firstly, the structure of the RSPM is introduced, and the MEC topology of the RSPM is obtained. The calculation formulas of the reluctances in this topology are given. Then the magnetic flux of the RSPM is solved by the mesh analysis method, and the torque is calculated based on the magnetic field energy storage. Finally, the calculated torque is verified by the finite element method (FEM). The verification results show that the torque modeling of the RSPM based on the MEC method is correct, which consumes less memory and time than the three-dimensional finite element method. Full article

This paper introduces a hybrid analytical model (HAM) for the evaluation of permanent-magnet (PM) eddy-current loss in dual-stator single-rotor axial flux permanent-magnet machine (AFPMM), accounting for stator saturation. The proposed model integrates the magnetic equivalent circuit (MEC) with an analytical model based on scalar magnetic potential, enabling simultaneous consideration of different rotor positions and stator slotting effects. The three-dimensional finite element method (3D-FEM) validates the no-load and armature reaction magnetic field calculated by HAM, as well as the PM eddy-current loss under both no-load and load conditions. Compared to 3D-FEM, the proposed model reduces the calculation time by more than 98% with an error of no more than 18%, demonstrating a significant advantage in terms of computational time. Based on the proposed model, the effects of air-gap length and slot opening width on PM eddy-current loss are analyzed; the results indicate that reducing the slot opening width can effectively mitigate PM eddy-current loss for AFPMM. Full article

The instability in rare-earth material supply and rising costs have driven research into rare-earth-free electric motors. Among various alternatives, wound rotor synchronous motors (WRSMs) stand out due to their adjustable excitation, enabling high torque at low speeds, and efficient field weakening at high speeds. Unlike permanent magnet synchronous motors (PMSMs), WRSMs offer greater operational flexibility and eliminate the risk of demagnetization. However, accurately modeling WRSMs remains challenging, especially when considering axial fringing flux and leakage components, which significantly affect motor performance. To address this challenge, this paper proposes a 3D nonlinear magnetic equivalent circuit (MEC) model that explicitly incorporates axial flux components and leakage paths in WRSMs with overhang rotor structures. Unlike conventional 2D MEC models, which fail to capture axial flux interactions, the proposed approach improves prediction accuracy while significantly reducing computational costs compared to full 3D finite element analysis (FEA). The model was validated through comparisons with 3D FEA simulations and experimental back-EMF measurements, demonstrating its accuracy and computational efficiency. The results confirm that the 3D nonlinear MEC model effectively captures axial flux paths and leakage components, making it a valuable tool for WRSM design and analysis. Future research will focus on further refining the model, incorporating hysteresis loss modeling, and developing hybrid MEC–FEA simulation techniques to enhance its applicability. Full article

This study presents an optimized design for a Segmented Sinusoidal Parameter Winding with Magnetic Wedge Variable Reluctance Resolver (SSPWMW-VRR), addressing challenges like winding asymmetry and harmonic distortion in conventional designs. By integrating particle swarm optimization (PSO) for winding design, magnetic equivalent circuit (MEC) analysis for leakage flux, and machine learning techniques (XGBoost and Multi-Layer Perceptron), the stator slot shape was fine-tuned for improved accuracy. XGBoost outperformed MLP in prediction accuracy with a mean absolute error (MAE) of 0.1172. Finite element analysis (FEA) simulations and experimental validation demonstrated a reduction in position errors from ±30′ in conventional VRRs to ±5′ in the optimized design, along with significant harmonic reduction. Full article

To ensure efficient inspection using the magnetic flux leakage (MFL) method, generating a flux density near the saturation level within the tested material is essential. This requirement brings high flux density conditions in the system’s pole regions. Hence, leakage flux within the slot is excessively triggered, leading to distortion of the defect signal. In this context, the system dimensions stand out as one of the most significant factors affecting the mentioned flux distributions. Therefore, various alternative solutions with different system dimensions arise in the design process of the MFL system. This study proposes a magnetic equivalent circuit (MEC) model to achieve optimal system design. The proposed MEC model is designed considering the nonlinear behavior of the material, leakage flux, and fringing effects. Verification results demonstrate that the MEC model consistently tracks the finite element analysis (FEA) results in calculating the flux densities. Furthermore, the relative errors in the flux density calculations of the tested material are at a maximum level of 10.2% and an average of 5.2% compared to the FEA. These findings indicate that the proposed MEC model can be effectively utilized in rapid prototyping and optimization procedures of MFL system design by providing fast solutions with reasonable accuracy. Full article

The shaft eddy currents cause a significant saturation in two-pole induction machines (IMs) as they generate an opposing field and repulse the main flux, thus tightening the flux path. This results in inaccurate performance estimations with the magnetizing inductance measured in no-load conditions when the machine is loaded. This article presents a modified IM equivalent circuit considering the rotor back iron saturation effects caused by the solid shaft eddy currents using experimental measurements and recursive parameter estimation techniques. The classical equivalent circuit (CEC) parameters are determined with the standard test techniques followed by the parameter estimation of the newly introduced modified equivalent circuit (MEC) parameters. The proposed modified equivalent circuit is benchmarked with CEC and finite element analysis (FEA) simulations with and without considering eddy effects. The proposed MEC model and the FEA that consider eddy effects performed better than the other models and yielded a negligibly small error over a wide range of loading conditions. Compared to the FEA, the proposed MEC estimates the IM performance much faster, which makes it more appealing for IM performance estimations. Full article

Post-assembly magnetization can significantly simplify the manufacturing of the rotor of permanent magnet (PM) electrical machines. The optimization of the post-assembly magnetizing device using finite element analysis (FEA) is time-consuming; therefore, a globally optimal solution aiming at achieving an adequate magnetizing level and minimal energy consumption is difficult to achieve. In this paper, a field–circuit coupling analysis (FCCA) model is proposed to optimize the auxiliary stator-type magnetizing device for interior permanent magnet synchronous machines (IPMSMs). A reasonable simplification of the highly saturated magnetic circuit is made based on FEA results so that the magnetic equivalent circuit (MEC) model can be established. On the other hand, the eddy currents in the PMs are equivalent to an eddy current short-circuit; thus, by converting the field calculation into a circuit calculation, the time cost can be reduced significantly, which greatly improves the speed of multi-objective optimization of the magnetizing device with multiple degrees of freedom. A V-type IPMSM is taken as a study case, and its post-assembly magnetizing device is optimized with the proposed method. FEA and experimental results show that the PMs are fully magnetized, while the required energy consumption is greatly reduced when compared with an existing magnetizing device. Full article

This paper proposes a model for the electromagnetic performance of the dual air-gap liquid-cooled eddy current retarder (DAL-ECR) considering the transient permeability. First, the structure and working principle of the DAL-ECR are introduced. Next, the analysis model of the static air-gap flux density considering the flux leakage and end effect is established based on the piecewise function method and the magnetic equivalent circuit (MEC). Then, based on the skin effect of the electromagnetic field in the retarder, an iterative method for solving the transient permeability of the stator is proposed. According to Faraday’s and Ampere’s laws, the analysis model of the static air-gap flux density, and the transient permeability, the analysis model of the transient air-gap flux density is established. The braking torque of the DAL-ECR is then calculated while taking the actual path of the eddy current and the skin effect on the permeability of the stator into consideration. Finally, the calculation accuracy of the model was verified by the finite element method (FEM) and the bench test. Full article

Permanent magnet eddy current couplers (PMECCs) have the characteristics of contactless torque transmission, removal of torque ripple, smooth dynamic process, and adjustable speed, and can be used as couplings, dampers, brakes, and speed governors. Their applications in industry, vehicles, and energy fields are gradually expanding. At the same time, the requirements for the torque density and dynamic performance of PMECCs are increasing. Therefore, a large amount of research work has focused on the fast and accurate modeling, design, and optimization of PMECCs. This paper provides a survey on the development of PMECCs technology. The main topics include the structure and classification of PMECCs, modeling methods, loss and heat transfer analysis modeling, and optimization design. In addition, this paper shows the future trends of PMECCs research. All the highlighted insights and suggestions of this review will hopefully lead to increasing efforts toward the model’s construction and the optimal design of PMECCs for future applications. Full article

The use of a suitable modeling technique for the optimized design of a magnetic gear is essential to simulate its electromagnetic behavior and to predict its satisfactory performance. This paper presents the design optimization of an axial flux magnetic gear (AFMG) using a two-dimensional (2D) magnetic equivalent circuit model (MEC) and a Multi-objective Genetic Algorithm (MOGA). The proposed MEC model is configured as a meshed reluctance network (RN) with permanent magnet magnetomotive force sources. The non-linearity in the ferromagnetic materials is accounted for by the MEC. The MEC model based on reluctance networks (RN) is considered to be a good compromise between accuracy and computational effort. This new model will allow a faster analysis and design for the AFMG. A multi-objective optimization is carried out to achieve an optimal volume-focused design of the AFMG for future practical applications. The performance of the optimized model is then verified by establishing flux density comparisons with finite element simulations. This study shows that with the combination of an MEC-RN model and a GA for its optimization, a satisfactory accuracy can be achieved compared to that of the finite element analysis (FEA), but with only a fraction of the computational time. Full article

The switched reluctance motor (SRM) is a promising candidate for electric propulsion systems. In the design process of an SRM, the motor geometry needs to be determined. Using the finite element method (FEM) might be time-consuming for the sizing of the motor geometry. As an alternative, electromagnetic models based on a magnetic equivalent circuit (MEC) can be utilized for the sizing of an SRM. MEC models require fewer computational resources and can help determine the electromagnetic performance with reasonable accuracy. Using the conventional MEC method for SRM sizing might be challenging since the flux pattern inside the motor should be changed for different motor dimensions. In order to address this challenge, this paper applies a reluctance mesh-based MEC technique to determine the geometry of a three-phase 12/16 SRM for a high-lift motor in the NASA Maxwell X-57 electric aircraft. A comprehensive reluctance mesh-based MEC model is developed for this purpose. Both the static and dynamic characteristics of the SRM geometry are evaluated using the reluctance mesh-based MEC method. The determined geometry is verified using the results computed from FEM. Full article

Welding has a severe impact on the efficiency of electrical machines. The heat added during the welding process affects the microstructure of the material and causes residual stress. This results in local degradation of the magnetic permeability and facilitates additional iron losses in the machine core. With the purpose of modeling and simulating welding effects in electric machines, this paper proposes a stress-dependent magnetic equivalent circuit (MEC) model for welded non-grain-oriented electrical steel laminations. A modified iron loss model is proposed to accommodate these welding effects. Furthermore, the proposed MEC model is applied to a M270-35A stator core as a case study. It was demonstrated that the core losses increase by 25% when four welding joints are applied. With a limited number of magnetic measurements on a welded and unwelded core, the model can be fully parametrized. Finally, the model was successfully validated on a core with eight welding seams at 100 Hz. The proposed model can be integrated into the design of electric machines to consider the welding effects. Full article

Permanent magnet synchronous machines (PMSMs) with an overhang structure can increase power density by compensating for the increased magnetic energy of permanent magnets. To analyze the overhang structure, a three-dimensional (3D) analysis of PMSMs is essential. However, 3D analysis takes a long time and the modeling process is complicated in the initial design stage. To overcome these problems, a magnetic equivalent circuit technique is applied to the 2D model. In this paper, an optimal design method for PMSMs with an overhang structure is proposed based on the semi 3D magnetic equivalent circuit (MEC) and random walk method. By using semi 3D MEC, it is possible to quickly analyze PMSM and obtain accurate electromagnetic analysis results considering the overhang effect. Moreover, the volume and weight of PMSM can be minimized by optimizing the rotor’s four design parameters using a random walk algorithm. To obtain high efficiency, the objective function is selected so that copper loss is minimized under the same constraints. The validity of the proposed design technique is verified by comparing the analysis results of semi 3D MEC and 3D finite element method for the derived optimal model. Full article

This paper proposes a modelling technique for Synchronous Reluctance Motors (SynRMs) based on a generalized Magnetic Equivalent Circuit (MEC). The proposed model can be used in the design of any number of stator teeth, rotor poles, and rotor barrier combinations. This technique allows elimination of infeasible machine solutions during the initial machine sizing stage, resulting in a lower cohort of feasible machine solutions that can be further optimized using finite element methods. Therefore, saturation effects, however, are not considered in the modelling. This paper focuses on modelling a generic structure of the SynRM in modular form and is then extended to a full SynRM model. The proposed model can be iteratively used for any symmetrical rotor pole and stator teeth combination. The developed technique is applied to model a 4-pole, 36 slot SynRM as an example, and the implemented model is executed following a time stepping strategy. The motor characteristics such as flux distribution and torque of the developed SynRM model is compared with finite elemental analysis (FEA) simulation results. Full article
