Understanding how electromagnetic (EM) waves travel through different tissues is important for EM medical imaging, sensing, and in-body communication. It is known that EM waves in lossy bio-tissues are nonuniform and do not strictly follow the least time or least loss paths. Instead, they exhibit two distinct wavefronts: the phase wavefront and the amplitude wavefront, which are generally oriented at different angles. The impact of that on imaging and in-body communications is investigated and validated through comprehensive analysis and full-wave EM simulations. Additionally, the impact of a matching medium, commonly used to reduce antenna–skin interface reflections in medical EM applications, on the direction of EM wavefronts, travel time, phase changes, and attenuation is analyzed and quantified. The results show that the Fermat principle of least travel time, often used to estimate EM wave travel time for localization in medical imaging and wireless endoscopy, is only accurate when the loss tangent or dissipation factor of both the matching medium and tissues is very low. Otherwise, the results will be inaccurate, and the dual wavefronts should be considered. The presented analysis and results provide guidance on EM wave travel time and the direction of phase and amplitude wavefronts. This information is valuable for developing reliable processing algorithms for sensing, imaging, and in-body communication. Full article

Recent research in solid-state physics and materials engineering focuses on the development of new dielectric materials, with bismuth-based pyrochlores being already extensively applied in communications technology for their excellent dielectric properties and relatively low sintering temperatures. Herein, the structural, morphological, electrical, and magnetic properties of Bi_1.34Fe_0.66Nb_1.34O_6.35 ceramic, prepared by the sol–gel method and sintered at 500 °C, are investigated. The Rietveld refinement of the XRD pattern showed a cubic phase belonging to the space group Fd-3m and a crystallite size of 42 nm. Transmission electron microscopy further confirmed the crystallite size and the homogeneous distribution of Bi, Fe, Nb, and O elements, as evidenced by high-angle annular dark field imaging and STEM-EDX mapping. The morphology of the sample, assessed by scanning electron microscopy, is characterized by submicron-sized spherical particles. Dielectric spectroscopic studies revealed that the dielectric properties, strongly influenced by frequency and temperature, indicate the material’s potential for energy storage due to lower dielectric loss compared to the dielectric constant. The observed relaxation phenomena, confirmed through variations in dielectric loss and loss tangent, highlight the influence of grain boundaries and temperature on electron hopping and charge carrier dynamics. Using SQUID magnetometry, we identified two distinct magnetic phases. The primary phase, corresponding to the Bi_1.34Fe_0.66Nb_1.34O_6.35 ceramic, exhibits an antiferromagnetic behavior below its Néel temperature at around 8.8 K. A secondary high-Curie temperature ferrimagnetic phase, likely vestigial maghemite and/or magnetite, was also detected, indicating an estimated fraction below 0.02 wt.%. Full article

This article explores the processing of structural, thermal, and dielectric properties of polypropylene (PP) polymer nanocomposites modified with Ni_0.9Zn_0.1Fe₂O₄. The PP/Ni_0.9Zn_0.1Fe₂O₄ nanocomposites are manufactured by the melt-processing method using a Brabender Polyspeed B. The XRD and FTIR structural investigations assure good incorporation of Ni_0.9Zn_0.1Fe₂O₄ into the PP matrix. It should be noted that adding Ni_0.9Zn_0.1Fe₂O₄ NPs to the PP polymer matrix enhances the polymer’s thermal stability. Utilizing the Coats–Redfern model, kinetic thermodynamic parameters such as activation energy (Ea), enthalpy (ΔH), entropy (ΔS), and Gibbs free energy (ΔG*) are deduced from TGA data. The dielectric results showed an increase in ε′ with the introduction of nanoparticles into the PP matrix. As the content of Ni_0.9Zn_0.1Fe₂O₄ NPs in these nanocomposite films increases, the loss tangent values decrease at higher frequencies while increasing at lower frequencies. The estimated ε_s and ε_∞ of PP nanocomposites using Cole–Cole plots reveal an improvement when NPs are added to PP. We believe that the proposed work suggests a relevant step towards the practical application of PP/Ni_0.9Zn_0.1Fe₂O₄ nanocomposites. Full article

In the paper, a novel design of a wideband power splitter for a four-element antenna array using two RF antiphase segments is proposed. Based on a detailed analysis of the power splitter circuit, an analytical model was set up in the MATLAB environment. The derived analytical model allows the development of a design of the described structure for any operating frequency and estimates the properties of the designed structure. In addition to the RF electrical part, the copper cover is also considered in this study. The copper cover serves as both a support and shielding part of the proposed structure. The electrical part consists of two sections of transmission lines. The first transmission line is symmetrical, while the second transmission line is asymmetrical. The given transmission lines can be realized using any technology (microstrip, coaxial, etc.). A prototype of the proposed wideband splitter operating at 650 MHz with a fractional bandwidth of 84.3% was designed and tested in real-world conditions to prove the concept. The board of the manufactured prototype has dimensions of 25 × 152 mm. A double-sided FR4 material with a substrate height of 1.48 mm, copper thickness of $50\mathsf{\mu }$m, and ${ϵ}_r$ ≅ 4.3, with a dielectric loss tangent of 0.021 was used to manufacture the prototype. The prototype was tested and its parameters were verified in practical conditions as a part of the current radio communication system for the 5G band. Under these conditions, verification measurements of the proposed splitter with a four-element antenna array were carried out. Full article

The split-cylinder resonator method was adapted to measure the microwave properties (dielectric permittivity and loss tangent) of thin ferroelectric films on a dielectric substrate. The mathematical model for calculating the resonance frequency of the split-cylinder resonator was adjusted for the “ferroelectric film—substrate” structure. An approach for correcting the gap effect based on calibrating with a single-layer dielectric was introduced and used to study two-layer dielectrics. The prototype of a split-cylinder resonator designed to measure single-layer dielectric plates at a frequency of 10 GHz was presented. The resonator calibration was performed using dielectric PTFE samples and fused silica, and an example of the correction function was suggested. The measurement error was estimated, and recommendations on the acceptable parameter range for the material under investigation were provided. The method was demonstrated to measure the microwave properties of a ferroelectric film on a fused silica substrate. Full article

In this work, the high-quality factor (Q-factor) and high sensitivity of a circular substrate-integrated waveguide (CSIW) are proposed for the characterization of semisolid materials. The modeled sensor was designed based on the CSIW structure with a mill-shaped defective ground structure (MDGS) to improve measurement sensitivity. The designed sensor oscillates at a single frequency of 2.45 GHz, which was simulated using an Ansys HFSS simulator. Electromagnetic simulation explains the basis of the mode resonance of all two-port resonators. Six variations of the materials under test (SUTs) were simulated and measured, including air (without an SUT), Javanese turmeric, mango ginger, black turmeric, turmeric, and distilled water (DI). A detailed sensitivity calculation was performed for the resonance band at 2.45 GHz. The SUT test mechanism was performed using a polypropylene tube (PP). The samples of dielectric material were filled into the channels of the PP tube and loaded into the center hole of the MDGS. The E-fields around the sensor affect the relationship with the SUTs, resulting in a high Q-factor value. The final sensor had a Q-factor of 700 and a sensitivity of 2.864 at 2.45 GHz. Due to the high sensitivity of the presented sensor for characterization of various semisolid penetrations, the sensor is also of interest for accurate estimation of solute concentration in liquid media. Finally, the relationship between the loss tangent, permittivity, and Q-factor at the resonant frequency were derived and investigated. These results make the presented resonator ideal for the characterization of semisolid materials. Full article

Terahertz (THz) communication has a large available bandwidth, which is expected to be deployed in future communication networks. As THz wave suffers from severe propagation loss in wireless transmission, we consider a THz near-field scenario where a base station (BS) is equipped with a large-scale antenna array with a low-cost hybrid beamforming architecture to serve mobile users nearby. However, the large-scale array and the user mobility incur difficulty in channel estimation. To tackle this issue, we propose a near-field beam training scheme that can align a beam to the user in a fast way by searching the codebook. Specifically, the BS employs a uniform circular array (UCA), and the radiation pattern of the beams in our proposed codebook appears as ellipsoids. To cover the serving zone with the minimum codebook size, we develop a near-field codebook by tangent arrangement approach (TAA). To reduce the time overhead, we leverage the hybrid beamforming architecture to realize multi-beam training concurrently since each RF chain can enable a codeword whose element has a constant magnitude. Numerical results validate that our proposed UCA near-field codebook achieves less time cost while achieving a comparable coverage performance compared to the conventional near-field codebook. Full article

In this article, an aperture antenna excited by a waveguide with a circular cross-section and covered with a dielectric plate was analyzed via simulation calculation and verified via measurements. The influence of the geometrical and electromagnetic parameters of the dielectric plate on the reflection coefficient S₁₁ of the antenna opening was systematically analyzed. The geometrical parameters taken in this analysis are the thickness d and the width/length h₁/h₂ of the dielectric plate. The electromagnetic parameters used in this analysis are the real and the imaginary part of permittivity (ε_r, tan δ) and the electrical conductivity of the dielectric plate (σ). The simulation calculation and analysis included other structural and electromagnetic parameters of the dielectric plate (density of the radome material, relative permeability, and magnetic loss tangent (ρ, µ_r, and tan δ_µ, respectively)), but the results show that in the range of real values of these parameters for the materials used for the dielectric plate, they had no significant influence on the reflection coefficient. The results show that impedance-matched antennas with very low values of the reflection coefficients S₁₁ at the resonant frequency can be realized by changing the geometrical and electromagnetic parameters of the dielectric plate material. The results are presented for a circular aperture antenna on a planar grounded plane with a dielectric plate on the opening, and the achieved lowest values of the S₁₁ parameter were −45.17 dB (simulated) and −43.93 dB (measured) at the frequencies of 1.7820 GHz and 1.7550 GHz, respectively. The estimated values of the dielectric plate parameters in this case are thickness d = 11.08 mm (0.67 λ); width × length of grounded plane and dielectric plate h₁ × h₂ = 423 × 450 mm² (2.51 × 2.67 λ); relative permittivity 2.5, tan δ = 0.09, μ_r = 1, tan δ_μ = 0.00, ρ = 1200 kg·m⁻³; and electrical conductivity σ = 0 S/m. The simulation calculation results were verified by measuring the reflection coefficient S₁₁ on the created laboratory model of the aperture antenna with the dielectric plate and showed a very good match. Full article

Calcium titanate (CaTiO₃) powder was compacted by spark plasma sintering (SPS). The resulting products were subjected to the phase stability study and dielectric characterization. The change in temperature of SPS between 1100 °C and 1250 °C had a clear and straightforward effect on density, porosity, relative permittivity, loss tangent, and DC resistivity. Since the SPS itself introduces certain oxygen deficiency into Ti-perovskites, all samples were annealed after SPS. However, this post-processing did not mask the effects of the SPS regime. Optical reflectance measurements were completed to compare and quantify the sample coloration and support the dielectric results with corresponding optical band gap estimations. Subtle changes in the CaTiO₃ crystal lattice arrangement, completed between 1150 °C and 1250 °C and documented in the literature for conventionally sintered samples, could not be confirmed for SPS-prepared calcium titanate. The novelty of this research work is in producing very stable dielectric ceramics and an indication of the SPS processing parameters suitable for this. The best sample showed at 1 MHz frequency the combination of relative permittivity 370, loss tangent 0.008, and DC resistivity 3 × 10¹² Ωm. Full article

The need for new solutions for electrical insulation is growing due to the increased electrification in numerous industrial sectors, opening the door for innovation. Plasma spraying is a fast and efficient way to deposit various ceramics as electrical insulators, which are used in conditions where polymers are not suitable. Alumina (Al${}_2$O${}_3$) is among the most employed ceramics in the coating industry since it exhibits good dielectric properties, high hardness, and high melting point, while still being cost-effective. Various parameters (e.g., feedstock type, spray distance, plasma power) significantly influence the resulting coating in terms of microstructure, porosity, and metastable phase formation. Consequently, these parameters need to be investigated to estimate the impact on the dielectric properties of plasma-sprayed alumina coatings. In this work, alumina coatings with different spray distances have been prepared via atmospheric plasma spray (APS) on copper substrates. The microstructure, porosity, and corresponding phase formation have been analyzed with optical microscopy, X-ray diffraction (XRD), and scanning electron microscopy (SEM). Moreover, we present an in-depth analysis of the fundamental dielectric properties e.g., direct current (DC) resistance, breakdown strength, dielectric loss tangent, and permittivity. Our results show that decreasing spray distance reduces the resistivity from 6.31 × ${10}^9$$\mathsf{\Omega }$m (130 mm) to 6.33 × ${10}^8$$\mathsf{\Omega }$m (70 mm), while at the same time enhances the formation of the metastable $\mathsf{\delta }$-Al${}_2$O${}_3$ phase. Furthermore, space charge polarization is determined as the main polarization mechanism at low frequencies. Full article

An inset fed-microstrip patch antenna (MPA) with a partial ground structure is constructed and evaluated in this paper. This article covers how to evaluate the performance of the designed antenna by using a combination of simulation, measurement, creation of the RLC equivalent circuit model, and the implementation of machine learning approaches. The MPA’s measured frequency range is 7.9–14.6 GHz, while its simulated frequency range is 8.35–14.25 GHz in CST microwave studio (CST MWS) 2018. The measured and simulated bandwidths are 6.7 GHz and 5.9 GHz, respectively. The antenna substrate is composed of FR-4 Epoxy, which has a dielectric constant of 4.4 and a loss tangent of 0.02. The equivalent model of the proposed MPA is developed by using an advanced design system (ADS) to compare the resonance frequencies obtained by using CST. In addition, the measured return loss of the prototype is compared with the simulated return loss observed by using CST and ADS. At the end, 86 data samples are gathered through the simulation by using CST MWS, and seven machine learning (ML) approaches, such as convolutional neural network (CNN), linear regression (LR), random forest regression (RFR), decision tree regression (DTR), lasso regression, ridge regression, and extreme gradient boosting (XGB) regression, are applied to estimate the resonant frequency of the patch antenna. The performance of the seven ML models is evaluated based on mean square error (MSE), mean absolute error (MAE), root mean square error (RMSE), and variance score. Among the seven ML models, the prediction result of DTR (MSE = 0.71%, MAE = 5.63%, RMSE = 8.42%, and var score = 99.68%) is superior to other ML models. In conclusion, the proposed antenna is a strong contender for operating at the entire X-band and lower portion of the Ku-band frequencies, as evidenced by the simulation results through CST and ADS, it measured and predicted results using machine learning approaches. Full article

The Chinese Chang’E-5 probe landed in the Mons Rümker of Oceanus Procellarum on the near side of the Moon. The lunar regolith penetrating radar (LRPR) carried by the Chang’E-5 probe allows for the determination of in situ lunar regolith dielectric properties, which are probably related to the age and chemical composition of the regolith. In this paper, we analyze the Chang’E-5 LRPR data with the frequency shift method to estimate the loss tangent of the lunar regolith within a depth of ∼2.8 m. The loss tangent of the Chang’E-5 landing site is constrained to be 0.0148 ± 0.0016, which is substantially higher than that of the typical lunar regolith. The high loss tangent is found to be characteristic of the young basalt age (∼2.0 Ga) and high TiO${}_2$+FeO content (28.21 ± 1.57%) of the Chang’E-5 landing site. Integrated analysis of results from Chang’E-3, Chang’E-4, and Chang’E-5 show that the younger is the geologic age of the mare unit, the greater is the loss tangent of the lunar regolith, and the weaker is the radar electromagnetic signal penetrating ability. Full article

On 1 December 2020, China’s Chang’E-5 (CE-5) probe successfully landed in the northeastern Oceanus Procellarum. This work mainly presents the results of Lunar Regolith Penetrating Radar (LRPR) equipped on the CE-5 Lander. The lunar regolith structure of the landing site from the surface to 3-m depth is unveiled by LRPR, which found that abundant rock fragments are distributed in uniform lunar regolith. The imaging result proved that the drilling and sampling process was prevented by big rocks at about 100 cm depth. On the basis of the response of lunar soil to electromagnetic (EM) wave, the EM properties of the landing site estimate that the relative dielectric constant and the loss tangent are 2.520 ± 0.186 and 0.0133 ± 0.0020, respectively. Full article

The aim of this study was to perform precision measurements of the frequency-temperature dependences of the loss angle tangent of the liquid-solid composite with the FDS Dirana meter. The composite consisted of heavily moistered oil-impregnated pressboard. The moisturization of the pressboard occurred in a manner as close as possible to the process of wetting the insulation in power transformers to a moisture content of (5.0 ± 0.2) wt. %. This value of moisture content was chosen because exceeding this value can lead to transformer failure. The measuring temperature range was from 293.15 K (20 °C) to 333.15 K (60 °C), with a step of 8 K. The measuring frequency range was 0.0001 Hz to 5000 Hz. It was observed that the shape of the frequency dependence of the loss angle tangent for a moisture content of 5.0 wt. % does not depend on the value of the measuring temperature. An increase in temperature leads to a shift of the waveforms into the higher frequency region. This is associated with a decrease in the relaxation time, and its value depends on the activation energy. It was found that a good fit of the waveforms, simulated by Dirana, to the actual tgδ waveforms obtained at temperatures between 293.15 K (20 °C) and 333.15 K (60 °C) requires the introduction of temperatures, higher than the actual insulation temperatures, into the program. It was found that estimating the moisture content for different temperatures using Dirana soft-ware for insulating an oil-impregnated pressboard produced large discrepancies from the actual content. Better results were obtained after an adjustment requiring manual temperature correction towards higher, compared to measured, temperatures. The moisture content estimated after correction by the Dirana meter ranges from of 4.5 wt. % to 5.7 wt. % and increases almost linearly with increasing measuring temperature. The average moisture content estimated by the Dirana meter for all measuring temperatures is 5.1 wt. % and is close to the actual content (5.0 ± 0.2) wt. %. The uncertainty of the estimate is ±0.43 wt. % and is more than twice as high as the true value. Full article

The aim of the work was to prepare and test a paper-oil insulation system according to the recommendations of CIGRE (Conseil International des Grands Réseaux Électriques) with the parameters X = 50% and Y = 30%. Pressboard was moistened to a water content of (5.0 ± 0.2) wt.% The loss tangent was measured using a DIRANA meter (FDS-PDC dielectric response analyzer) in the frequency range 10⁻⁴ Hz–5000 Hz for 6 temperatures from 293.15 K to 333.15 K with a step of 8 K. The waveforms simulated by the DIRANA software were fitted to the experimental dependence of the loss tangent. The fitting process was performed using two methods. In the first method, the measuring temperature value as well as X and Y values were entered into the software. The estimated moisture content of the insulation varied from about 1.4 to about 5.2 wt.%. The average value of moisture content was (3.73 ± 1.11) wt.%. In the second method, only the measuring temperature value was entered into the software. This improved the quality of matching. The estimated average moisture content was (5.83 ± 0.25) wt.%. It was found that the dimensions of the oil channel clearly affected the quality of the fitting process. By not taking into consideration real values of oil channel, the quality of the moisture content estimation was significantly improved. Full article
