Pile–raft foundations are widely used in soft soil engineering due to their good integrity and high stiffness. However, traditional design methods independently design pile–raft foundations and superstructures, ignoring their interaction. This leads to significant deviations from actual conditions when the superstructure height increases, resulting in excessive costs and adverse effects on building stability. This study experimentally investigates the interaction characteristics of pile–raft foundations and superstructures in soft soil under different working conditions using a 1:10 geometric similarity model. The superstructure is a cast-in-place frame structure (beams, columns, and slabs) with bamboo skeletons with the same cross-sectional area as the piles and rafts, cast with concrete. The piles in the foundation use rectangular bamboo strips (side length ~0.2 cm) instead of steel bars, with M1.5 mortar replacing C30 concrete. The raft is also made of similar materials. The results show that the soil settlement significantly increases under the combined action of the pile–raft and superstructure with increasing load. The superstructure stiffness constrains foundation deformation, enhances bearing capacity, and controls differential settlement. The pile top reaction force exhibits a logarithmic relationship with the number of floors, coordinating the pile bearing performance. Designers should consider the superstructure’s constraint of the foundation deformation and strengthen the flexural capacity of inner pile tops and bottom columns for safety and economy. Full article

This study systematically investigates the plastic deformation behavior and load-bearing mechanisms of micropiles through integrated scaled physical modeling and nonlinear finite element analysis, with particular emphasis on quantifying plastic hinge characteristics. The development of plastic deformation in laterally loaded micropiles was analytically described using plastic hinge theory, complemented by experimental-numerical validation. The key findings demonstrate the following points. (1) Existing empirical formulas for plastic hinge length, based on sectional parameters, show significant discrepancies, with experimental calibration establishing an optimized length of 2D. (2) Parametric FEM studies of three diameter groups (3–7% longitudinal reinforcement ratio) reveal that cross-sectional geometry and reinforcement configuration collectively govern nonlinear ultimate capacity, where ≤0.1% reinforcement ratio variation induces <5% bearing capacity deviation. (3) Square sections exhibit 12–18% higher capacity than circular equivalents of the equivalent dimensions, with this advantage amplifying with increasing pile size. (4) While excessive reinforcement ratios (>6%) impair structural performance, emergent scale effects effectively mitigate associated capacity reduction. These findings provide critical insights for optimizing micropile design in geotechnical applications through coordinated consideration of geometric, material, and scale parameters. Full article

The cement–soil pipe pile is a novel blend of cement and soil, designed to enhance load-bearing capabilities while cutting down on the need for cement. Its tubular construction is key to its strength. To delve into how the pile’s cross-sectional size affects its load-bearing properties, we took into account the soil–cement’s strain-softening behavior. Laboratory tests examined the load-bearing properties of piles. We created an exponential decay Mohr–Coulomb model in ABAQUS for further development, performed field tests, and built a numerical model incorporating wall thickness, pile diameter, and length. The unit volume ultimate bearing capacity was used to evaluate pile performance, with a focus on a 600 mm diameter pile. The results show that wall thickness minimally affects load-bearing capacity, needing to be at least a quarter of the diameter. Larger diameters increase the ultimate bearing capacity, but the capacity per unit volume declines. The 600 mm diameter pile boasts the highest unit volume ultimate bearing capacity. The pile’s effective length is roughly 10 m. Beyond this, extending the pile length increases the single pile’s ultimate bearing capacity by less than 5%, but the unit volume capacity starts to dwindle. Full article

To ensure the connection performance of precast concrete square piles, a screw clamping and welding joint connection is applied to the solid square piles. By conducting full-scale bending performance tests on six solid square pile specimens with cross-sectional side lengths of 300, 450, and 600 mm, including pile bodies, screw clamping joints, screw clamping, and welding joints, the bending load-bearing capacity, deformation capacity, and failure characteristics of the screw clamping–welding joint connection are compared and studied. The results show that the bending failure mode of the pile body specimens is shear failure in the flexural shear section and concrete crushing in the compression zone of the pure bending section; the bending failure mode of the screw clamping joint specimens are the pull-out of steel bar heads at the joint end plate; the bending failure mode of the screw clamping and welding joint specimens are concrete crushing in the compression zone of the pure bending section, steel bar breakage in the tension zone of the flexural shear section, and pull-out of steel bar heads at the end plate. It is worth noting that no significant damage occurred at the joints. The cracks in the pure bending section of the bending specimens mainly develop vertically and are evenly distributed, while some cracks in the flexural shear section develop obliquely towards the loading point, with branching. Compared to the pile body specimens, the cracking moment of the joint specimens is up to 16% higher, the ultimate moment is within 15% lower, and the maximum mid-span deflection is within 25% lower, indicating that the provision of anchorage reinforcement can increase the stiffness and cracking moment of the specimens. Full article

The pre-stressed high-strength concrete (PHC) nodular pile is a type of PHC pile with a variable cross-section of the pile shaft, and it has normally been applied in ground treatment projects in recent years. The PHC nodular pile shaft consists of nodules, which introduce differences for the load transfer mechanism of the PHC nodular pile compared to the conventional PHC pipe pile. In this paper, the load transfer mechanism and influencing factors of the bearing capacity of the PHC nodular pile were investigated based on a group of field tests and numerical simulations. The following conclusions were obtained based on the analysis of the field test and simulation results: the nodules along the pile could effectively increase the ultimate capacity of the PHC nodular pile, and the field test results showed that the ultimate capacity of 450 (500) mm PHC nodular piles was about 1.23–1.38 times of the 450 mm PHC pipe pile after being cured for 40 days, which can be used for the design of PHC nodular pile. The simulation results showed that the bearing capacity of the PHC nodular pile would decrease with the increase in nodular spacing and nodular length along the pile shaft, while increasing with the increase in nodular diameter, and the diameter of the nodule can be increased moderately to improve the ultimate capacity of the PHC nodular pile. Full article

Considering the practical conditions, it has been observed that the support structures of wind turbines inevitably experience bending and axial compression, both during the installation phase and throughout their operational lifespan. The monopile is the most commonly utilized support structure for offshore applications and a reliable method for creating a detachable section within these structures is using a Pile-in-Pile (PIP) slip joint. Consequently, the behavior of PIP slip joints, under combined axial compression and bending, has been meticulously investigated. To facilitate a thorough analysis, overlapping lengths proportional to the pile diameters have been used, encompassing three distinct variations. This approach allows for a comprehensive understanding of structural integrity and performance under varying stress conditions, which are comprehensively understood and accounted for in design considerations. The current study builds upon assessing the pure bending characteristics of slip joints in cylindrical hollow section (CHS) structures. Additionally, two ring stoppers have been strategically employed inside the piles to withstand the axial load. Furthermore, the complexity of the pressure acting in the overlapping length, attributed to the frictional coefficient in that region, has been carefully addressed. The current research also encompasses a comprehensive overview of the P-M envelopes for the existing arrangements, with a particular focus on non-linear buckling, which is known to significantly influence the performance of tubular structures. Finally, a design equation was introduced to concisely describe the behavior of the components and compare it with other design equations provided by an established code. Full article

Stiffened deep cement mixing (SDCM) piles are composite piles that combine the advantages of single large-diameter deep cement mixing (DCM) and precast concrete piles. They comprise precast concrete piles as the core and cast-in-place DCM piles as the outer layer. This study evaluates the bearing characteristics of SDCM piles under vertical loading. The composite modulus of elasticity of SDCM piles is first introduced and determined using the area-weighted average method. Then, the reliability of the proposed method is described by comparing the calculated results with the findings of the existing literature. Furthermore, a nonlinear simplified analysis method based on the load transfer method is proposed for vertical bearing characteristics of equal- and short-core SDCM piles under vertical loading. This method is developed by the finite difference method. The accuracy of the simplified method is validated by comparing its results with those from existing tests, theoretical analysis, and finite element simulations. The results of their study indicated that the area-weighted average method calculates the composite modulus of elasticity of the composite pile section of the SDCM piles with an error below 0.5% compared to the analytical method. This finding represents sufficient accuracy. The simplified calculation method established in this study is computationally stable. When the iteration factor is set to 10⁻⁶, as the number of discrete nodes n on the pile increases, the calculation results are stable with a good convergence when n > 30. The vertical bearing capacity and pile top stiffness of SDCM piles increased with the length of the core piles. There was a reasonable core-to-length ratio for SDCM piles in specific scenarios. An excessively long DCM pile section made its lower part force-free for a given length of core piles. The appropriate length of core piles should be determined in actual projects to avoid unnecessary material waste. An optimum ratio of core piles for SDCM piles was determined. Beyond this optimal value, an increase in the ratio of core piles controlled the pile settlement in a limited manner. Full article

This study proposes a new form of underground diaphragm wall foundation with hexagonal sections, called the grid pile foundation (GPF), which is used for long-span bridges. To investigate the lateral bearing capacity characteristics of the integrated pile foundation, the quasi-static test as well as numerical simulations were conducted. Firstly, the quasi-static test was conducted to obtain the lateral load–displacement curve, the soil pressure distribution, and the deformation and stress distribution of the pile foundation and the surrounding soil. Then, the finite element model of the proposed GPF foundation was built, which was verified and calibrated based on the test data. Finally, the parametric analysis was performed to investigate the effects of soil friction angle, pile foundation Young’s modulus, and pile length on the lateral bearing capacity characteristics of the proposed GPF. It is concluded that the GPF would transition from the stiffness stage to the plastic strain stage under lateral load, and deformation occurred simultaneously. The stress in the soil around the pile foundation is high in the upper portion and low in the lower portion, and the active and passive failure zones of the soil are formed under the action of the GPF. Both experimental and numerical simulations indicate that the GPF has a good lateral load capacity, and the lateral load capacity is most affected by the length of the piles. The GPF is expected to provide a new solution to the construction of large-span bridges with diaphragm wall foundations. Full article

An anti-slide pile is a common landslide control measure. Compared with the full-length pile whose top extends to the ground, the buried pile is more optimal in internal force distribution, saves material and has remarkable economic benefits. At present, there is a lack of in-depth theoretical analysis on the pile length of the load section of double-row buried piles. In order to establish the design calculation method of pile length in the load section of double row buried piles, this paper is based on the failure mode of overtopping. The design equation of load section pile length is obtained by using the transfer coefficient and limit equilibrium method. Taking a landslide in Yan’an City, Shaanxi Province, China, as an example, the reliability and economics of double-row buried piles are verified by comparing the treatment effects of single-row, double-row and double-row buried piles, and the engineering design is completed. The results show that the landslide control project using the design calculation method can meet the requirements of slope stability and at the same time save a quarter of the material compared with the double row of full-length piles. The engineering example proves the rationality and practicability of the design method and provides engineering reference value for the use of the double-row buried anti-slide pile structure in large-scale landslide treatment. Full article

Anti-sliding short piles, a novel technique for slope stabilization, have been applied in engineering practices. Nonetheless, a mature structural calculation theory for these piles is still lacking. In this paper, the study presents an internal force solution model for anti-sliding short piles using the finite difference method. By extending the Euler–Bernoulli beam theory and defining boundary conditions, this study develops a set of finite difference equations for computing the structural forces of anti-sliding short piles. Furthermore, this study conducted laboratory model tests on soil landslide cases reinforced with anti-sliding short piles. By comparing the internal forces and deformations of these piles, the test validates the proposed calculation model for anti-sliding short piles. The results suggest that treating the load-bearing and embedded sections as a unified entity during the calculation process, instead of applying continuity conditions separately at the sliding surface as performed in traditional methods, simplifies the complex solving procedure. Moreover, under identical loading conditions, the displacement, bending moment, and shear force data obtained through the finite difference method closely coincide with the measurements from the model tests, confirming the reliability of the anti-sliding short pile calculation model. Additionally, this study demonstrates that reducing the spacing between nodes along the entire anti-sliding short pile, i.e., decreasing the value of the differential segment length ‘h’, results in more precise computational outcomes. This research offers valuable insights and references for sustainable solutions in the realm of geological disaster prevention and control. Full article

Pre-stressed high-strength concrete pipe piles (PHC pipe piles) have been widely used in actual soft foundation treatment projects due to their reliable quality, fast construction, assembly line production, and environmental friendliness. However, large-scale slip damage still occurs in construction projects. In order to reduce and avoid such accidents, a highway in Guangdong (section K31+100~K31+388) was taken as an example for this study. Plaxis 2D software (V22.01.00) was used to establish a PHC pipe pile composite roadbed model and investigate the effects of tie beam form, pile lengths, pile spacings, pile verticality, and embankment filling loading modes on the settlement and stability of the composite roadbed. The results show that the original treatment plan, which had the form of a PHC pipe pile with caps, had a low horizontal bearing capacity and a poor anti-disturbance ability, leading to the occurrence of a landslide accident. A comparison of different structural forms revealed that the longitudinal and transverse tie beam form was the most stable, followed by the transverse tie beam form, longitudinal tie beam form, PHC pipe pile form with caps, and PHC pipe pile form without caps. Compared to the structural form of PHC pipe piles with pile caps, the stabilities of the transverse tie beam form and the longitudinal tie beam form were improved by 42.47% and 38.61%, respectively, while that of the longitudinal and transverse tie beam form was improved by 50.87%. The application of longitudinal and transverse tie beams effectively reduced the settlement of the composite roadbed, as confirmed by both measured data and finite element analysis. This structure achieved the desired vertical settlement control and lateral anti-slip effects. Full article

The tandem compound piles are a combination of a granular column in the deep section and a concrete pile in the shallow section. This method effectively utilizes the consolidation and densification effects of the granular column, as well as the cementation strength of the concrete material. The granular column acts as a consolidation path, aiding in the densification of the surrounding soil. On the other hand, the concrete pile prevents the bulging deformation that commonly happens in granular columns during field construction. To study the bearing capacity and deformation of the improved foundation with tandem compound piles, a coupled continuum-discrete numerical model was developed in this study. The accuracy of the model was confirmed by comparing its results with experimental measurements. Additionally, a parametric study was conducted, considering three influential factors: (1) cushion thickness and modulus, (2) length, modulus, diameter, and spacing of the tandem compound pile, and (3) soil modulus. The results indicated that reducing the cushion thickness and increasing the cushion modulus allowed the pile to bear more loads. Moreover, increasing the length and modulus of the deep section of the pile reduced deformation and improved the bearing capacity. The pile modulus, however, had a limited effect on enhancing the bearing capacity. It is important to maintain a critical pile spacing of at least twice the pile diameter. Finally, a high modulus of the underlying stratum led to higher vertical and radial stresses in the pile. Full article

The collapsible loess is widely distributed in western China. The special structure and water sensitivity of loess lead to the complex negative skin friction mechanism in pile foundations. Previous studies mainly focused on the negative skin friction of pile foundations and treatment measures, such as casing and coating methods. However, few studies have focused on the influence of the negative skin friction on the settlement and bearing capacity of piles in collapsible loess, especially environmentally friendly methods that can reduce the negative skin friction. In this study, a series of non-immersion and immersion experiments was conducted to investigate the settlement, axial force, and side friction resistance of piles in loess soil under controlled conditions. The results showed that under the non-immersion condition, the settlement of model piles increased with the increasing pile top load. The axial force gradually decreased along the pile length for piles without casing. The axial force attenuation of the casing section of casing piles was almost negligible due to the isolating frictional resistance effect of casing. The settlement of each soil layer increased with the increase in immersion time, and the process was divided into an initial gradual stage, rapid drop stage, and later gradual stage. Both negative and positive skin friction increased with the increasing immersion time and pile top load, and there was a neutral point. The maximum axial force of piles without casing exceeded the peak load at the pile top. The presence of steel casing reduced the failure of pile foundation in collapsible loess. The research results of this paper provide theoretical support for the application of piles in loess areas. Full article

The settlement behavior of composite foundations plays an important role in the serviceability and stability of the subgrade or other infrastructures supporting the foundation. However, in water-rich flood plains, due to the complexity of the soft soil properties, the settlement behavior has not been well understood. The objective of this study is to investigate the effects of various key factors on the settlement behavior of composite foundations with deep mixed piles supporting highway subgrade in water-rich flood plains. The investigated subgrade is in operation, and the vehicle load is taken into account. The G347AH Project is considered in this study. Several typical models for predicting composite foundation settlements are discussed. By performing three-dimensional finite difference analysis, a comparison is made between the settlement behavior of the natural foundation and the composite foundation with deep mixed piles. Based on the single factor sensitivity analysis and the multi-factor orthogonal experimental design, the effects of pile length, pile diameter, pile spacing, pile elasticity modulus, cushion elasticity modulus, and cushion thickness on the composite foundation settlement are captured. It is found that among these factors, the degree of influence of pile length is superior. The composite foundation settlements predicted by the models agree well with the field-monitoring data, with the error being about 8.42% and 6.38%, respectively, at two monitoring sections. The research conducted in this paper can effectively reduce the probability of various settlement-related disasters occurring on highway subgrades in water-rich flood plains. Moreover, the research has important theoretical guidance for design optimization in terms of settlement control of highway subgrades in soft soil areas. Full article

The steel–concrete composite truss adopts a new type of steel-concrete composite joint with high rigidity and load-carrying capacity. In order to more conveniently and clearly grasp the working mechanism of Perfobond Leiste (PBL) shear keys in the core area of new composite structures such as steel–concrete composite trusses, the lack of strong theoretical support for the theoretical formula of load–slip relationships in the entire loading process of single PBL shear keys is solved. By proposing a straight–curved–straight three-stage simplified load–slip curve with respect to the PBL shear key, the stress process of the PBL shear key is divided into three stages—the elastic stage, plastic stage, and strengthening stage—based on the compressive yield and failure critical point of tenon concrete in the shear key. With reference to the calculation method of the bearing capacity of the order pile under horizontal loads and by calculating the shear stiffness of the shear key, a theoretical formula suitable for separating the load–slip relationship of a single PBL shear key in the entire loading process of the ear plate composite joint is proposed. The results show that, in the elastic section, the slope of the curve is related to the concrete reaction coefficient and the material parameters of the penetrating steel bar; moreover, in the strengthened section, the coefficient is related to the shear modulus of the penetrating steel bar, and a more uniform length distribution of the penetrating steel bar between the two joint plates will improve the initial stiffness of the PBL shear key to a certain extent. The results of the proposed method are in good agreement with the finite element results and experimental values. This research study’s results can provide a convenient design method for the design of the internal PBL shear keys of new composite structure joints, promoting the promotion and application of new composite structures and advancing the development of the engineering field. Full article
