In this paper, we propose and demonstrate a liquid crystal on silicon (LCoS) device that achieves high-efficiency, broadband, polarization-independent phase modulation by integrating a metasurface between the liquid crystal layer and the backplane of a commercial LCoS device. The metasurface is composed of rectangular silicon pillars encapsulated in silicon dioxide. By precisely adjusting the orientation and dimensions of these silicon pillars, the metasurface effectively controls the polarization state of the incident light, enabling polarization-independent phase modulation across the C+L band. Experimental results show that the polarization conversion ratio remains approximately 95% throughout the entire C+L band under varying driving voltages. Due to the low absorption characteristics of silicon and silicon dioxide, the metasurface integration introduces minimal loss. Additionally, the experimental results indicate that the reflectance of the metasurface-integrated LCoS exceeds 96% of the original LCoS reflectance. Notably, the metasurface does not affect the phase modulation characteristics of the device or exacerbate the fringing field effect, which could otherwise degrade modulation efficiency. The fabrication process for incorporating the silicon metasurface into the LCoS is fully compatible with standard semiconductor manufacturing techniques, thus facilitating the potential for large-scale production. Theoretical analysis further confirms that the design is tolerant to fabrication errors. Full article

Shaping or splitting of a Gaussian beam is often desired to optimise laser–material interactions, improving throughput and quality. This can be achieved holographically using liquid crystal-on-silicon spatial light modulators (LC-SLMs). Until recently, maximum exposure has been limited to circa 120 W average power with a Gaussian profile, restricting potential applications due to the non-linear (NL) phase response of the liquid crystal above this threshold. In this study, we present experimental tests of a new SLM device, demonstrating high first-order diffraction efficiency of η = 0.98 ± 0.01 at 300 W average power and a phase range Δφ > 2π at P = 383 W, an exceptional performance. The numerically calculated device temperature response with power closely matches that measured, supporting the higher power-handling capability. Surface modification of mild steel and molybdenum up to P = 350 W exposure is demonstrated when employing a single-mode (SM) fibre laser source. Exposure on mild steel with a vortex beam (m = +6) displays numerous ringed regions with varying micro-structures and clear elemental separation created by the radial heat flow. On molybdenum, with multi-spot Gaussian exposure, both MoO₃ films and recrystallisation rings were observed, exposure-dependent. The step change in device capability will accelerate new applications for this LC-SLM in both subtractive and additive manufacturing. Full article

In this study, the potential of employing SiN_x (silicon nitride) waveguide platforms to enable the use of liquid-crystal-based phase shifters for on-chip optical modulators was thoroughly investigated using 3D-FDTD (3D finite-difference time-domain) simulations. The entire structure of liquid-crystal-based Mach–Zehnder interferometer (MZI) optical modulators, consisting of multi-mode interferometer splitters, different tapering sections, and liquid-crystal-based phase shifters, was systematically and holistically investigated with a view to developing a compact, wideband, and CMOS-compatible (complementary metal-oxide semiconductor) bias voltage optical modulator with competitive modulation efficiency, good fabrication tolerance, and single-mode operation using the same SiN_x waveguide layer for the entire device. The trade-off between several important parameters is critically discussed in order to reach a conclusion on the possible optimized parameter sets. Contrary to previous demonstrations, this investigation focused on the potential of achieving such an optical device using the same SiN_x waveguide layer for the entire device, including both the passive and active regions. Significantly, we show that it is necessary to carefully select the phase shifter length of the LC-based (liquid crystal) MZI optical modulator, as the phase shifter length required to obtain a π phase shift could be as low as a few tens of microns; therefore, a phase shifter length that is too long can contradictorily worsen the optical modulation. Full article

This work introduces a novel computational approach based on Principal Component Analysis (PCA) for dimensionality reduction of the solution space in optimisation problems with known linear interdependencies among solution variables. By creating synthetic datasets with deliberately engineered properties and applying PCA, the solution space’s remapping significantly reduces its dimensionality, leading to faster computation and more robust convergence in optimisation processes. We demonstrate this method by integrating it with a Genetic Algorithm (GA) for solving the optimal director distribution in liquid crystal (LC) devices, specifically addressing 2D and complex 3D spatial light modulator (SLM) structures such as twisted nematic liquid crystals (TN-LC) and parallel-aligned liquid crystal on silicon (PA-LCoS), respectively. The phase profiles obtained from the director vector distributions for horizontal and vertical high-frequency binary phase gratings closely match the theoretical values derived from minimising the traditional elastic Frank–Oseen functional via Euler–Lagrange equations. Beyond this specific application, our method offers a general framework for reducing computational complexity in optimisation problems by directly reducing the dimensionality of the solution space. This approach is applicable across various optimisation scenarios with well-known linear interdependencies among solution variables, enabling significant reductions in computational costs and improvements in robustness and convergence. Full article

Low cost, low power consumption and high performance are urgent needs for the application of terahertz modulation devices in the 6G field. Rhenium disulfide (ReS₂) is one of the ideal candidate materials due to its unique direct band gap, but it lacks in-depth research. In this work, a highly stable ReS₂ nanodispersion was prepared by liquid-phase exfoliation, and a uniform, dense and well-crystallized ReS₂ film was prepared on high-resistivity silicon by drop casting. The morphological, optical and structural properties of the ReS₂/Si heterojunction film were characterized by OM, SEM, AFM, XRD, RS and PL. The terahertz performance was tested by using a homemade THz-TDS instrument, and the influence of different laser wavelengths and powers on the terahertz modulation performance of the sample was analyzed. The modulation depth of the sample was calculated based on the transmission curve, and the changes in the refractive index and conductivity of the sample with frequency at the corresponding laser power were calculated. The results show that the fabricated ReS₂/Si heterojunction terahertz modulator can stably achieve 30% broadband modulation in the range of 0.3~1.5 THz under the low-power pumping of 1555 mW/cm², and the maximum conductivity is 3.8 Ω⁻¹m⁻¹. Full article

Silicon carbide (SiC) single crystals have great prospects for high-temperature energy storage due to their robust structural stability, ultrahigh power output, and superior temperature stability. However, energy density is an essential challenge for SiC-based devices. Herein, a facile two-step strategy is proposed for the large-scale synthesis of a unique architecture of SiC nanowires incorporating MnO₂ for enhanced supercapacitors (SCs), arising from the synergy effect between the SiC nanowires as a highly conductive skeleton and the MnO₂ with numerous active sites. The SiC@MnO₂ integrated electrode-based SCs with ionic liquid (IL) electrolytes were assembled and delivered outstanding energy and power density, as well as a great lifespan at 150 °C. This impressive work offers a novel avenue for the practical application of SiC-based electrochemical energy storage devices with high energy density under high temperatures. Full article

Combined with vortex light and airglow, some different physical phenomena are presented in this paper. Based on the ground-based airglow imaging interferometer (GBAII) made by our group, a liquid crystal on silicon (LCoS) device on one arm of a wide-angle Michelson interferometer (MI) of the GBAII is replaced by the reflector mirror to become the GBAII-LCoS system. LCoS generates a vortex phase to convert a Gaussian profile airglow into a vortex light pattern. After the Gaussian profile vortex light equation is obtained by combining the Gaussian profile airglow with the Laguerre–Gauss light, three different physical phenomena are obtained: the simulated Gaussian vortex airglow beam exhibits a hollow phenomenon with the introduction of the vortex phase, and as the topological charge (TC) l increases, the hollow range also increases; after adding the vortex factor, the interference fringe intensity can be ‘broadened’ with the optical path difference (OPD) and TC l increases, which match the field broadening technology for solid wide-angle MI; the ‘Four-point algorithm’ wind measurement for the upper atmosphere based on the vortex airglow is derived, which is different from the usual expressions. Some experimental results are presented: We obtained the influence modes of vortex light interference and a polarization angle from 335° to 245°. We also obtained a series of interference images that verifies the rotation of the vortex light, onto which is loaded a set of superimposed vortex phase images with TC l = 3 into LCoS in turn, and the interference image is rotated under the condition of the polarization angle of 245°. The controlled vortex interference image for different TC and grayscale values are completed. Full article

Wavelength selective switches (WSSs) are essential elements for wavelength division multiplexing (WDM) optical networks, as they offer cost-effective, high port-count and flexible spectral channel switching. This work proposes a new hybrid WSS architecture that leverages the beam shaping and steering features of uniform silicon nitride-based end-fire optical phased arrays (OPAs). By introducing beamforming to a WSS system, the spectral channels on the liquid crystal on silicon (LCoS) panel can be tailored and arranged properly, depending on the optical configuration, using the beam control capabilities of OPAs. Combining 3D-FDTD and ray tracing simulations, the study shows that, by reducing the input beam dimensions with proper sizing of the OPAs, the WSS design with a null-steering OPA layout and 4 × N_o switch size features increased spectral resolution. This extensive beamforming study on the steering-enabled layout reveals the acquirement of an even higher input channel number, matching the 8 × N_o WSS scheme, with flexible channel routing on the LCoS panel. Such implementation of beamsteerers can unlock an extra degree of freedom for the switching capabilities of hybrid WSS devices. The results show great promise for the introduction of OPAs in WSS systems and provide valuable insight for the design of future wireless communication links and WDM systems. Full article

The broad and fascinating properties of nanowires and their synthesis have attracted great attention as building blocks for functional devices at the nanoscale. Silicon and germanium are highly interesting materials due to their compatibility with standard CMOS technology. Their combination provides optimal templates for quantum applications, for which nanowires need to be of high quality, with carefully designed dimensions, crystal phase, and orientation. In this work, we present a detailed study on the growth kinetics of silicon (length 0.1–1 $\mathsf{\mu }$m, diameter 10–60 nm) and germanium (length 0.06–1 $\mathsf{\mu }$m, diameter 10–500 nm) nanowires grown by chemical vapor deposition applying the vapour–liquid–solid growth method catalysed by gold. The effects of temperature, partial pressure of the precursor gas, and different carrier gases are analysed via scanning electron microscopy. Argon as carrier gas enhances the growth rate at higher temperatures (120 nm/min for Ar and 48 nm/min H${}_2$), while hydrogen enhances it at lower temperatures (35 nm/min for H${}_2$ and 22 nm/min for Ar) due to lower heat capacity. Both materials exhibit two growth regimes as a function of the temperature. The tapering rate is about ten times lower for silicon nanowires than for germanium ones. Finally, we identify the optimal conditions for nucleation in the nanowire growth process. Full article

Developing fast-response liquid crystals (LCs) is an essential way to achieve low cost, high resolution, and good visual experience for augmented reality (AR) displays. In this paper, we optimized one new nematic LC mixture SNUP01 to meet the requirements of fast-response phase-only liquid crystal on silicon (LCoS) devices in AR displays. The photoelectric performance of this new LC mixture and three commercial LC mixtures were further comparatively evaluated, and the 2π phase-change response speed of this new LC mixture was extrapolated. The research results indicate that SNUP01 possesses high birefringence, moderate dielectric anisotropy, low viscoelastic coefficient, low activation energy, and high figure of merit values. When using this LC mixture at 25 °C @ λ = 633 nm, a 2π phase change can be achieved at 5 V with a total response time of up to millisecond response. Widespread applications of this LC mixture for AR displays are foreseeable. Full article

A liquid crystal (LC) mixture in liquid crystal on silicon (LCoS) is the core material for augmented reality (AR) displays. However, a LC mixture with high birefringence (Δn) and large dielectric anisotropy (Δε) possesses high viscosity (γ₁), which results in a slow response time of LCoS devices for AR displays. This work proposes to apply difluorovinyl-based LC diluters to fine balance the low viscosity, high ∆n, and large ∆ε of the LC mixture for a fast response time. Through studying their effects on the key electro-optical properties of a high-∆n LC mixture, it is found that doping these diluter molecules to a high-∆n LC mixture can decrease the viscoelastic coefficient (γ₁/K₁₁), increase ∆ε and the figure of merit, maintain a wide nematic phase temperature range, a high clearing point, and ∆n. It also means that these diluters could effectively regulate the relationship between ∆n, ∆ε, and γ₁ in the LC mixtures to achieve a fine balance of various excellent properties and further improve the LC device’s response time. The widespread applications of these liquid crystal diluters in emerging liquid crystal optical devices are foreseeable. Full article

Polysiloxanes and materials based on them (silicone materials) are of great interest in optoelectronics due to their high flexibility, good film-forming ability, and optical transparency. According to the literature, polysiloxanes are suggested to be very promising in the field of optoelectronics and could be employed in the composition of liquid crystal devices, computer memory drives organic light emitting diodes (OLED), and organic photovoltaic devices, including dye synthesized solar cells (DSSC). Polysiloxanes are also a promising material for novel optoectronic devices, such as LEDs based on arrays of III–V nanowires (NWs). In this review, we analyze the currently existing types of silicone materials and their main properties, which are used in optoelectronic device development. Full article

Holographic generation of beam spot array with high uniformity have been extensively investigated while existing methods cannot combine high quality and tunability. This paper demonstrated a method to generate beam spot array by using phase-only liquid crystal on silicon (LCOS) device. The proposed method is highly flexible and tolerant to the defects within the LCOS device. The uniformity deviation of the speckle array can be limited to within ±5% in the numerical simulation and the experimental results agreed well with the simulation results. Full article

The silicon carbide (SiC) that can achieve better electron concentration and motion control is more suitable for the production of high temperature, high frequency, radiation resistance, and high-power electronic devices. However, the fabrication of the high purity single crystal is challenging, and it is hard to observe the structural details during crystallization. Here, we demonstrate a study of the crystallization of single-crystal SiC by the molecular dynamic simulations. Based on several structure analysis methods, the transition of the solid–liquid SiC interface from a liquid to a zinc-blende structure is theoretically investigated. The results indicate that most of the atoms in the solid–liquid interface begin to crystallize with rapid solidification at low cooling rates, while crystallization does not occur in the system at high cooling rates. As the quenching progresses, the number of system defects decreases, and the distribution is more concentrated in the solid–liquid interface. A maximum crystallization rate is observed for a cooling rate of 10¹⁰ K/s. Moreover, when a stronger crystallization effect is observed, the energy is lower, and the system is more stable. Full article

Photodetectors are widely applied in modern industrial fields because they convert light energy into electrical signals. We propose a printable silver (Ag) paste electrode for a highly flexible metal–semiconductor–metal (MSM) broadband visible light photodetector as a wearable and portable device. Single-crystal and surface-textured silicon substrates with thicknesses of 37.21 μm were fabricated using a wet etching process. Surface texturization on flexible Si substrates enhances the light-trapping effect and minimizes reflectance from the incident light, and the average reflectance is reduced by 16.3% with pyramid-like structures. In this study, semitransparent, conductive Ag paste electrodes were manufactured using a screen-printing with liquid-phase process to form a flexible MSM broadband visible light photodetector. The transmittance of the homemade Ag paste solution fell between 34.83% and 36.98% in the wavelength range of visible light, from 400 nm to 800 nm. The highest visible light photosensitivity was 1.75 × 10⁴ at 19.5 W/m². The photocurrents of the flexible MSM broadband visible light photodetector were slightly changed under concave and convex conditions, displaying stable and durable bending properties. Full article
