Maintaining the required relative humidity values in the vehicle cabin is an important HVAC task, along with considerations related to the temperature, velocity, air pressure and noise. Deviation from the optimal values worsens the psycho-physiological state of the driver and affects the energy efficiency of the train. In this study, a model of liquid film formation on and removal from various cabin surfaces was constructed using the fundamental Navier–Stokes hydrodynamic equations. A special transport model based on the liquid vapor diffusion equation was used to simulate the air environment inside the cabin. The evaporation and condensation of surface films were simulated using the Euler film model, which directly considers liquid–gas and gas–liquid transitions. Numerical results were obtained using the RANS equations and a turbulence model by means of the finite volume method in Ansys CFD. Conjugate fields of temperature, velocity and moisture concentration were constructed for various time intervals, and the dependence values for the film thicknesses on various surfaces relative to time were determined. The verification was conducted in comparison with the experimental data, based on the protocol for measuring the microclimate indicators in workplaces, as applied to the train cabin: the average ranges encompassed temperature changes from 11% to 18%, and relative humidity ranges from 16% to 26%. Comparison with the results of other studies, without considering the phase transition and condensation, shows that, for the warm mode, the average air temperature in the cabin with condensation is 12.5% lower than without condensation, which is related to the process of liquid evaporation from the heated walls. The difference in temperature values for the model with and without condensation ranged from −12.5% to +4.9%. We demonstrate that, with an effective mode of removing condensate film from the window surface, including recirculation modes, the energy consumption of the climate control system improves significantly, but this requires a more accurate consideration of thermodynamic parameters and relative humidity. Thus, considering the moisture condensation model reveals that this variable can significantly affect other parameters of the microclimate in cabins: in particular, the temperature. This means that it should be considered in the numerical modeling, along with the basic heat transfer equations. Full article

In this study, in order to overcome the limitations of existing electric vehicle (EV) thermal management systems (TMS), a highly integrated and coordinated operation strategy for EV thermal management was proposed. Specifically, an integrated architecture with a 10-way valve was established to replace traditional 3-way and 4-way valves to enhance the coupling between coolant circuits. Six operating modes were realized via the switching function of the 10-way valve, including the mode of waste heat recovery. A highly integrated TMS model was developed on the AMEsim2304 platform, followed by parameter matching. The accuracy of the model was validated through comparative analysis with laboratory and environmental chamber test results. Based on the designed highly integrated TMS, a classical fuzzy Proportional-Integral-Derivative Control (PID) control strategy was introduced to regulate the coolant circulation pump. Simulation analyses and experimental results demonstrated that the optimized system could reduce the battery pack heating time by approximately 300 s compared to the pre-optimized configuration. Moreover, the waste heat recovery could improve the cabin heating rate from 1.9 °C/min to 3.4 °C/min, representing a 43.7% enhancement. Furthermore, the output power of the high-pressure liquid heater remained low, resulting in a 10% reduction in overall heating energy consumption. Based on simulation and experimental analyses, this research can promote the progress of thermal management system technology for electric vehicles to a certain extent. Full article

With the rapid expansion of methanol-powered shipping, the emphasis within the industry has increasingly been placed on ensuring the operational safety of these alternative fuel vessels. In this study, the mixture and realizable k-ε models are adopted to simulate the liquid methanol leakage model, and the predictive accuracy of the model is verified through a comparative analysis with experimental results. Given the complexity of ship cabins, a comprehensive exploration of the leakage and diffusion behaviors of methanol under different ambient temperatures, main engine surface temperatures, and leakage port sizes is conducted. The research findings show that an increase in ambient temperature significantly accelerates vapor diffusion by enhancing evaporation and strengthening the wall-accumulation effect. In contrast, an increase in the main engine surface temperature mainly causes local vapor stagnation and has a relatively limited impact on the overall diffusion pattern. An increase in the leakage orifice diameter directly increases the leakage volume, shortens the diffusion period, and promotes nonlinear growth of the vapor height. The research results can not only provide a theoretical basis for the design of cabin structures and ventilation systems of methanol fuel ships but also be applied to the risk prevention and control of methanol leakage scenarios on ships. Full article

This paper provides a detailed description of the development and experimental results of the supercritical flow experiment payload carried on the TZ-6 cargo spacecraft, as well as a systematic verification of the out-of-cabin deployment experiment. The technical and engineering indicators of the payload deployment experiment are analyzed, and the functional modules of the payload are shown. The paper provides a detailed description of the design, installation location, size, weight, temperature, illumination, pressure, radiation, control, command reception, telemetry data, downlink data, and experimental procedures for the out-of-cabin payload in the extreme conditions of space. The paper presents the annular liquid surface state and temperature oscillation signals obtained from the space experiment and conducts ground matching experiments to verify the results, providing scientific references for the design and condition setting of space experiments and comparisons for the experimental results to obtain the flow field structure under supercritical conditions. The paper provides a specific summary and discussion of the space fluid science experiment project, providing useful references for future long-term in-orbit scientific research using cargo spacecraft. Full article

Effective heat dissipation challenges transient high-power electronic devices in hypersonic vehicle cabins. This study introduces a Phase Change Heat Exchange Unit with Layered Porous Media (PCHEU–LPM) employing pulsed heat flow at the top and forced convection at the bottom. The primary aim was a comparative parametric study analyzing the thermal response of the heating surface under pulsed heat flow conditions. The geometric model was generated using electron microscopy images of manufactured objects and the numerical model was established based on the enthalpy–porosity method. Numerical simulations explored amplitude and frequency effects on pulsed thermal excitation, evaluating temperature and phase fields. A comprehensive time-frequency transformation assessed the temperature response. The results indicated an initial decrease and subsequent increase in interface temperature fluctuation with pulse heat flux amplitude growth. Temperature field uniformity correlated with natural convection strength in two-phase and liquid-phase regions. At mid and low frequencies, the phase change process increasingly suppressed interface temperature fluctuations. Optimal pulse thermal excitation selection was crucial for minimizing temperature fluctuations while maintaining the interface temperature within the expected phase transition range. In conclusion, a novel design concept is posited herein, aiming to enhance surface temperature uniformity and broaden the applicability of electronic devices through the manipulation of porosity rates. Full article

Liquid composite molding techniques are largely used to produce pieces such as truck cabins or wind turbine blades. The liquid resin infusion processes use a network of injection channels to improve the resin flow through a porous-reinforced medium. The present numerical study predicts the positioning of empty channels by applying constructal theory to an idealized problem. The channels’ position and size were not predefined but instead constructed (made to grow) from an elemental channel. Two strategies were tested for channel growth: each new elemental channel was placed next to the region with the lowest or highest resistance to resin flow. The geometric configuration of the channels was constructed using a control function instead of using pre-defined shapes. The conservation of mass and momentum and an additional transport equation for the resin volume fraction were solved using the finite volume method. The volume of the fluid model was used for the treatment of the multiphase flow (air + resin). The growth of an empty channel with the lowest resistance strategy led to a decrease in the injection time and waste of resin. The size (resolution) of the elemental channel also affected the performance indicators and geometric configuration of the injection channels. Full article

This paper introduces the concept of a thermal management system (TMS) with integrated on-board power generation capabilities for a Mach 8 hypersonic aircraft powered by liquid hydrogen (LH2). This work, developed within the EU-funded STRATOFLY Project, aims to demonstrate an opportunity for facing the challenges of hypersonic flight for civil applications, mainly dealing with thermal and environmental control, as well as propellant distribution and on-board power generation, adopting a highly integrated plant characterized by a multi-functional architecture. The TMS concept described in this paper makes benefit of the connection between the propellant storage and distribution subsystems of the aircraft to exploit hydrogen vapors and liquid flow as the means to drive a thermodynamic cycle able, on one hand, to ensure engine feed and thermal control of the cabin environment, while providing, on the other hand, the necessary power for other on-board systems and utilities, especially during the operation of high-speed propulsion plants, which cannot host traditional generators. The system layout, inspired by concepts studied within precursor EU-funded projects, is detailed and modified in order to suggest an operable solution that can be installed on-board the reference aircraft, with focus on those interfaces impacting its performance requirements and integration features as part of the overall systems architecture of the plane. Analysis and modeling of the system is performed, and the main results in terms of performance along the reference mission profile are discussed. Full article

To investigate the influence of the number of inlet pipes on the characteristics of flow field and the discharge of solid particles such as bait residue and fish feces, STAR-CCM + was used to analyze the flow of field distribution in a ship-based aquaculture cabin under the conditions of two and four inlet pipes, thus optimizing the inlet pipes of the ship-based aquaculture cabin. Furthermore, a three-phase flow model (solid–liquid–gas) was established to determine the movement characteristics of similar solid particles of residual bait and fish manure in the cabin, while the emission performance of solid particles was analyzed. Finally, the formation of solid particles in the center of the aquaculture cabin was simulated. The simulation results show that the effect of flow field is better with two inlet pipes, and the discharge volume of the bottom outlet has little impact on the emission of solid particles. Findings from this study can serve as a reference and basis for the design and optimization of the aquaculture cabin of an aquaculture vessel. Full article

The penetration of a projectile into a warship broadside liquid cabin is usually a non-ideal penetration process. To explore the protective effects of the broadside liquid cabin of a large warship against the non-ideal penetration of rod projectiles and to provide reference for the design of new liquid cabin structures, ballistic impact tests of rod projectiles penetrating the liquid cabin at different attack angles were carried out. Combined with numerical calculation, the impact of the attack angle on the water entry and penetration characteristics of the projectile into the liquid cabin as well as their failure modes were studied. The overturning and yawing of the projectile in water were analyzed. The pressure load characteristics in the liquid cabin and the deformation/failure modes of the projectile and the liquid cabin were identified. The results showed that: multiple overturning and yawing occur in the projectile with an initial attack angle during penetration into liquid; the yaw direction is mainly affected by the initial attack angle and projectile attitude; the projectile mainly undergoes four basic failure modes, namely, asymmetric mushrooming at the projectile nose, side erosion, overall plastic bending and fracture; the actual failure of the projectile is a combination of the basic failure modes; the overall plastic bending and fracture are mainly related to the length to diameter ratio, initial attack angle and initial projectile velocity; the front plate of the liquid cabin may undergo tearing along the central plastic hinge line of the plate: at a small attack angle, the tear is “I” shaped, and at a large attack angle, it is “X”-shaped. Full article

This paper discloses the architecture and related performance of an environment control system designed to be integrated within a complex multi-functional thermal and energy management system that manages the heat loads and generation of electric power in a hypersonic vehicle by benefitting from the presence of cryogenic liquid hydrogen onboard. A bleed-less architecture implementing an open-loop cycle with a boot-strap sub-freezing air cycle machine is suggested. Hydrogen boil-off reveals to be a viable cold source for the heat exchangers of the system as well as for the convective insulation layer designed around the cabin walls. Including a 2 mm boil-off convective layer into the cabin cross-section proves to be far more effective than a more traditional air convective layer of approximately 60 mm. The application to STRATOFLY MR3, a Mach 8 waverider cruiser using liquid hydrogen as propellant, confirmed that presence of cryogenic tanks provides up to a 70% reduction in heat fluxes entering the cabin generated outside of it but inside the vehicle, by the propulsive system and other onboard systems. The effectiveness of the architecture was confirmed for all Mach numbers (from 0.3 to 8) and all flight altitudes (from sea level to 35 km). Full article

The integrated thermal management system of aircraft is essential to maintain a suitable environment for the cabin crew and devices. The system is composed of the air-cycle refrigeration subsystem, the vapor-compression refrigeration subsystem, the liquid-cooling subsystem and the fuel-cycle subsystem, which are coupled with each other through heat exchangers. Due to the complex structure and large number of components in the system, it is necessary to design a corresponding parameter-matching algorithm for its special structure and to select the appropriate optimization design method. In this paper, the structure of an integrated thermal management system is analyzed in depth. A hierarchical matching algorithm of system parameters was designed and realized. Meanwhile, a sensitivity analysis of the system was performed, where key parameters were selected. Besides, a variety of optimization algorithms was used to optimize the design calculations. The results show that the particle swarm optimization and genetic algorithm could effectively find the global optimal solution when taking the fuel penalty as the objective function. Furthermore, the particle swarm optimization method took less time. Full article

Partial body cryotherapy cabins most often use liquid nitrogen as their cryogenic fluid, which raises safety concerns during operation. In this study, an innovative cryotherapy cabin design is presented, featuring an electric cooling system suitable for producing cold air at −30 °C. The geometry of the designed cryotherapy cabin is evaluated by a thermodynamic modeling which aims at optimizing the circulation of cold air flows inside the cabin. The numerical study is carried out in two successive phases, the first one being necessary to model the pre-cooling phase and to estimate the time required to reach an average temperature close to the set temperature of −30 °C. The second one aims at modeling a 3-min cryotherapy session by taking into account the thermal transfers between the human body and its environment. Results demonstrate the potential benefits of the cold air injection device which has been designed to optimize the thermal transfers and homogenize the temperatures within the therapeutic enclosure. The main innovation of this study is the ability to customize cryotherapy protocols by injecting cold air at different levels through targeting of specific body areas. Further calculations would be required to determine the precise impact of zone-targeted injection on skin cooling. Full article

The life and efficiency of electric vehicle batteries are susceptible to temperature. The impact of cold climate dramatically decreases battery life, while at the same time increasing internal impedance. Thus, a battery thermal management system (BTMS) is vital to heat and maintain temperature range if the electric vehicle’s batteries are operating in a cold climate. This paper presents an induction heater-based battery thermal management system that aims to ensure thermal safety and prolong the life cycle of Lithium-ion batteries (Li-Bs). This study used a standard simulation tool known as GT-Suite to simulate the behavior of the proposed BTMS. For the heat transfer, an indirect liquid heating method with variations in flow rate was considered between Lithium-ion batteries. The battery and cabin heating rate was analyzed using the induction heater powers of 2, 4, and 6 kW at ambient temperatures of −20, −10, and 0 °C. A water and ethylene glycol mixture with a ratio of 50:50 was considered as an operating fluid. The findings reveal that the thermal performance of the proposed system is generally increased by increasing the flow rate and affected by the induction heater capacity. It is evident that at −20 °C with 27 LPM and 6 kW heater capacity, the maximum heat transfer rate is 0.0661 °C/s, whereas the lowest is 0.0295 °C/s with 2 kW heater capacity. Furthermore, the proposed BTMS could be a practical approach and help to design the thermal system for electric vehicles in the future. Full article

Tricresyl phosphate (TCP) is an organophosphorous neurotoxin that has been detected in water, soil and air. Exposure to TCP in cockpit and cabin air poses a severe threat to flight safety and the health of the aircraft cabin occupants. Conventional methods for the detection of TCP in various samples are gas or liquid chromatography coupled to mass spectrometry, which are complex and expensive. To develop a simple low-cost methodology for the real-time monitoring of TCP in the environment, an effective catalyst is demanded for the hydrolysis of TCP under neutral condition. In this study, Ruthenium (III) hydroxide and Iron (III) hydroxide are found to facilitate the production of the alcoholysis and hydrolysis products of TCP, suggesting their role as a catalyst. With this finding, these metal hydroxides provide new potential to realize not only simple colorimetric or electrochemical detection of TCP, but also a simple detoxication strategy for TCP in environment. In addition, the catalytic capability of Ru (III) or Fe (III) hydroxide for TCP gives a hint that they can potentially serve as catalysts for the hydrolysis of alcolyolysis of many other organophosphate compounds. Full article

The aim of this study is to analyze the operating energy savings of a liquid desiccant and an indirect and direct evaporative cooling-assisted 100% outdoor air system (LD-IDECOAS) for marine applications. The LD-IDECOAS comprises a liquid desiccant (LD) unit and indirect and direct evaporative coolers (IEC and DEC) to meet the target supply air (SA) conditions. In this study, seawater was used as the cooling source and the waste heat reclaimed from the engine was used as the heating source in the proposed system. The operating energy of the LD-IDECOAS was determined based on detailed energy simulations conducted on two cabins with an area of 16.5 m², which was compared to a conventional system. The thermal loads on the cabins were estimated using design weather data under various oceanic climate conditions (normal, extremely hot, and extremely cold climates), by adhering to the ISO-7547 standard. The operating energy consumption of the LD-IDECOAS was calculated by modeling the proposed system with a commercial equation solver program (i.e., EES). The results were then compared to those of a conventional constant air volume (CAV) system. The operating energy consumption of the proposed system was reduced by 57–70% in cooling operations and 39% in heating operations under normal climate conditions. In the extremely hot climate regions, the energy consumed by the proposed system was reduced by 56–63% for cooling applications and 39% for heating applications. Full article
