Search Results (69)

Attempting to make machines mimic human walking, grasping, balancing, and other behaviors is a deep exploration of cognitive science and biological principles. Due to the existing prediction lag problem, an error compensation mechanism that integrates historical motion data is proposed. By constructing a humanoid autonomous walking control system, this paper aims to use a three-dimensional linear inverted pendulum model to plan the general framework of motion. Firstly, the landing point coordinates of the single foot support period are preset through gait cycle parameters. In addition, it is substituted into dynamic equation to solve the centroid (COM) trajectory curve that conforms to physical constraints. A hierarchical whole-body control architecture is designed, with a task priority based on quadratic programming solver used at the bottom to decompose high-level motion instructions into joint space control variables and fuse sensor data. Furthermore, the numerical iterative algorithm is used to solve the sequence of driving angles for each joint, forming the control input parameters for driving the robot’s motion. This algorithm solves the limitations of traditional inverted pendulum models on vertical motion constraints by optimizing the centroid motion trajectory online. At the same time, it introduces a contact phase sequence prediction mechanism to ensure a smooth transition of the foot trajectory during the switching process. Simulation results demonstrate that the proposed framework improves disturbance rejection capability by over 30% compared to traditional ZMP tracking and achieves a real-time control loop frequency of 1 kHz, confirming its enhanced robustness and computational efficiency. Full article

Accurate trajectory tracking of quadrotor UAVs remains challenging due to highly nonlinear dynamics, model uncertainties, and time-varying external disturbances, which make it difficult to achieve both precise position tracking and stable attitude regulation under control constraints. To tackle these coupled problems, this paper develops a hierarchical control framework in which the outer-loop particle swarm optimization (PSO)-compensated model predictive controller (PSMC) adaptively mitigates prediction errors and enhances robustness, while the inner-loop enhanced linear quadratic regulator (LQR), augmented with gain scheduling and control-rate relaxation, accelerates attitude convergence and ensures smooth control actions under varying flight conditions. A Lyapunov-based stability analysis is conducted to ensure closed-loop convergence. Simulation results on a helical reference trajectory show that, compared with the conventional MPC–LQR baseline, the proposed framework reduces the mean tracking errors by more than 13.2%, 17.1%, and 28% in the x-, y-, and z-directions under calm conditions, and by more than 34%, 26.2%, and 46.8% under wind disturbances. These results prove that the proposed hierarchical PSMC–LQR framework achieves superior trajectory tracking accuracy, strong robustness, and high practical implement ability for quadrotor control applications. Full article

This paper investigates the problem of data-driven optimal preview repetitive control of linear discrete-time systems. Firstly, by integrating prior information into the preview time domain, an augmented state-space system is established. Secondly, the original output tracking problem is mathematically reconstructed and transformed into the optimization problem form of a linear quadratic tracking (LQR). Furthermore, a Q-function-based iterative algorithm is designed to dynamically calculate the optimal tracking control gain based solely on online measurable data. This method has a dual-breakthrough feature: it neither requires prior knowledge of system dynamics nor provides an initial stable controller. Finally, the superiority of the proposed scheme is verified through numerical simulation experiments. Full article

Differential tracked robots play a crucial role in various modernized work scenarios such as smart industry, agriculture, and transportation. However, these robots frequently encounter substantial challenges in trajectory tracking, attributable to substantial initial errors and dynamic environments, which result in slow convergence rates, cumulative errors, and diminished tracking precision. To address these challenges, this paper proposes a fuzzy adaptive virtual steering coefficient model predictive control (FVSMPC) algorithm. The FVSMPC algorithm introduces a virtual steering coefficient into the robot’s kinematic model, which is adaptively adjusted using fuzzy logic based on real-time positional error and velocity. This approach not only enhances the robot’s ability to quickly correct large errors but also maintains stability during tracking.The nonlinear kinematic model undergoes linearization via a Taylor expansion and is subsequently formulated as a quadratic programming problem to facilitate efficient iterative solutions. To validate the proposed control algorithm, a simulation environment was constructed and deployed on a real prototype for testing. Results demonstrate that compared to the baseline algorithm, the proposed algorithm performs excellently in trajectory tracking tasks, avoids complex parameter tuning, and exhibits high accuracy, fast convergence, and good stability. This work provides a practical and effective solution for improving the trajectory tracking performance of differential tracked robots in complex environments. Full article

This paper addresses the spatial path tracking problem of the X-rudder autonomous underwater vehicle (AUV) under random sea current disturbances. An adaptive line-of-sight guidance-linear quadratic regulator (ALOS-LQR) control strategy with roll constraints is proposed to enhance the tracking control accuracy and stability of the X-rudder AUV in such environments. First, to mitigate the roll-instability-induced depth and heading coupling deviations caused by unknown environmental disturbances, a roll-constrained linear quadratic regulator (LQR) heading-pitch control strategy is designed. Second, to handle random disturbances and model uncertainties, a nonlinear extended state observer (ESO) is employed to estimate dynamic disturbances. At the kinematic level, an adaptive line-of-sight guidance method (ALOS) is utilized to transform the path tracking problem into a heading and pitch tracking problem, while compensating in real time for kinematic deviations caused by time-varying sea currents. Finally, the effectiveness of the proposed control scheme is validated through simulation experiments and lake trials. The results confirm the effectiveness of the proposed method. Specifically, the roll-constrained ESO-LQR reduces lateral and longitudinal errors by 77.73% and 80.61%, respectively, compared to the roll-constrained LQR. ALOS navigation reduced lateral and longitudinal errors by 85.89% and 94.87%, respectively, compared to LOS control, while exhibiting faster convergence than ILOS. In physical experiences, roll control reduced roll angle by 50.52% and depth error by 33.3%. Results demonstrate that the proposed control strategy significantly improves the control accuracy and interference resistance of the X-rudder AUV, exhibiting excellent accuracy and stability. Full article

The increasing penetration of distributed energy resources (DERs) and power electronic loads challenges the modeling and control of modern distribution networks (DNs). The traditional models often fail to capture the complex aggregate dynamics required for advanced control strategies. This paper proposes a novel framework for DN power regulation based on Neural Ordinary Differential Equations (NODEs) and Model Predictive Control (MPC). NODEs are employed to develop a data-driven, continuous-time dynamic model capturing the aggregate relationship between the voltage at the point of common coupling (PCC) and the network’s power consumption, using only PCC measurements. Building upon this NODE model, an MPC strategy is designed to regulate the DN’s active power by manipulating the PCC voltage. To ensure computational tractability for real-time applications, a local linearization technique is applied to the NODE dynamics within the MPC, transforming the optimization problem into a standard Quadratic Programming (QP) problem that can be solved efficiently. The framework’s efficacy is comprehensively validated through simulations. The NODE model demonstrates high accuracy in predicting the dynamic behavior in a DN against a detailed simulator, with maximum relative errors below 0.35% for active power. The linearized NODE-MPC controller shows effective tracking performance, constraint handling, and computational efficiency, with typical QP solve times below 0.1 s within a 0.1 s control interval. The validation includes offline tests using the NODE model and online co-simulation studies using CloudPSS and Python via Redis. Application scenarios, including Conservation Voltage Reduction (CVR) and supply–demand balancing, further illustrate the practical potential of the proposed approach for enhancing the operation and efficiency of modern distribution networks. Full article

Path tracking control is a key technology in the research of intelligent vehicles. In the path tracking process of intelligent vehicles, there are multiple constraints and time-varying nonlinear system states. To address the problems of low tracking accuracy and poor robustness, a method based on Radau pseudospectral method(RPM) is designed. Firstly, a 4-DOF vehicle model was established. Secondly, the multiple phase Radau pseudospectral method(MPRPM) was used to discretize the control and state variables. Then, the path tracking problem was transformed into a nonlinear programming problem. Finally, the method was compared with other control methods such as Gaussian pseudospectral method(GPM) and linear quadratic regulator (LQR). The simulation results show that the tracking error of the proposed method is 0.075 m while those of the GPM and LQR are 0.029 m and 0.05 m, respectively. The simulation and virtual as well as the real vehicle test results indicate that the method can control the vehicle track the given path while meeting various constraint requirements achieving ideal results and good tracking accuracy. Full article

This paper addresses the real-time trajectory generation problem for hypersonic glide vehicles (HGVs) during atmospheric entry, subject to complex constraints including aerothermal limits, actuator bounds, and no-fly zones (NFZs). To achieve efficient and reliable trajectory planning, a two-phase hp-adaptive sequential convex programming (SCP) framework is proposed. NFZ avoidance is reformulated as a soft objective to enhance feasibility under tight geometric constraints. In Phase I, a shrinking-trust-region strategy progressively tightens the soft trust-region radius by increasing the penalty weight, effectively suppressing linearization errors. A sensitivity-driven mesh refinement method then allocates collocation points based on their contribution to the objective function. Phase II applies residual-based refinement to reduce discretization errors. The resulting reference trajectory is tracked using a linear quadratic regulator (LQR) within a reference-trajectory-tracking guidance (RTTG) architecture. Simulation results demonstrate that the proposed method achieves convergence in only a few iterations, generating high-fidelity trajectories within 2–3 s. Compared to pseudospectral solvers, the method achieves over 12× computational speed-up while maintaining kilometer-level accuracy. Monte Carlo tests under uncertainties confirm a 100% success rate, with all constraints satisfied. These results validate the proposed method’s robustness, efficiency, and suitability for onboard real-time entry guidance in dynamic mission environments. Full article

Stabilization and tracking problems for cart inverted pendulums under disturbances and uncertainties have posed significant challenges for control engineers. While various controllers have been designed for an inverted pendulum, they often overlook the calibration error of the pendulum angle in practical implementations, which degrades the control performance. Incorrect calibration of the pendulum angle in upright equilibrium position generates an offset of cart position errors. To solve this problem, an augmented model comprising integral cart position errors was first constructed. Afterwards, a sliding mode control was designed for this system based on a linear quadratic controller, to facilitate implementation. Additionally, a stepper motor was employed in the inverted pendulum to enhance the control performance and widen applicability in industrial settings. The effectiveness and performance of the proposed controller were validated by means of experimental studies, focusing on stabilization control and tracking control of a cart inverted pendulum actuated by a stepper motor. Full article

The construction industry faces a growing need for automation to reduce costs, improve accuracy and productivity, and address labor shortages. One area that stands to benefit significantly from automation is panelized prefabricated building envelope retrofits, which can improve a building’s energy efficiency in heating and cooling interior spaces. In this paper, we propose using cable-driven parallel robots (CDPRs), which can effectively lift and handle large objects, to install these panels. However, implementing CDPRs presents significant challenges because of their nonlinear dynamics, complex trajectory planning, and precise control requirements. To tackle these challenges, this work focuses on a new application of established control and trajectory optimization theories in a CDPR simulation of a building envelope retrofit under real-world conditions. We first model the dynamics of CDPRs, highlighting the critical role of damping in system behavior. Building on this dynamic model, we formulate a trajectory optimization problem to generate feasible and efficient motion plans for the robot under operational and environmental constraints. Given the high precision required in the construction industry, accurately tracking the optimized trajectory is essential. However, challenges such as partial observability and external vibrations complicate this task. To address these issues, a Linear Quadratic Gaussian control framework is applied, enabling the robot to track the optimized trajectories with precision. Simulation results show that the proposed controller enables precise end effector positioning with errors under 4 mm, even in the presence of external wind disturbances. Through comprehensive simulations, our approach allows for an in-depth exploration of the system’s nonlinear dynamics, trajectory optimization, and control strategies under controlled yet highly realistic conditions. The results demonstrate the feasibility of CDPRs for automating panel installation and provide insights into their practical deployment. Full article

This paper presents a method for designing a static output feedback integrated path tracking controller for autonomous vehicles. For path tracking, state–space model-based control methods, such as linear quadratic regulator, H_∞ control, sliding mode control, and model predictive control, have been selected as controller design methodologies. However, these methods adopt full-state feedback. Among the state variables, the lateral velocity, or the side-slip angle, is hard to measure in real vehicles. To cope with this problem, it is desirable to use a state estimator or static output feedback (SOF) control. In this paper, an SOF control is selected as the controller structure. To design the SOF controller, a linear quadratic optimal control and sliding mode control are adopted as controller design methodologies. Front wheel steering (FWS), rear wheel steering (RWS), four-wheel steering (4WS), four-wheel independent braking (4WIB), and driving (4WID) are adopted as actuators for path tracking and integrated as several actuator configurations. For better performance, a lookahead or preview function is introduced into the state–space model built for path tracking. To verify the performance of the SOF path tracking controller, simulations are conducted on vehicle simulation software. From the simulation results, it is shown that the SOF path tracking controller presented in this paper is effective for path tracking with limited sensor outputs. Full article

A skid-to-turn (STT) missile is an axisymmetric structure missile, and its control system consists of a pitch channel and a yaw channel with an axisymmetric structure. To achieve the fast response of the STT missile system, a compound control method of aerodynamic force and lateral thrust based on regional pole assignment (RPA) is proposed. In the aerodynamic control system, the linear quadratic regulator (LQR) is used to design the controller, and the sliding mode control method is used to design the controller of the lateral thrust system. The regional pole assignment is introduced into the aerodynamic system to improve the compound control system response speed. The problems of regional pole assignment and system stability are solved by a linear matrix inequality (LMI). Considering that the missile flies at different altitudes, the missile system is controlled by gain scheduling. Compared to previous designs of time-varying compound control systems for STT missiles or hypersonic vehicles, in order to meet the practical requirement of a fast response for the vehicle, this time-varying compound control strategy can achieve faster tracking response and attitude control for the STT missile. Finally, through simulations of the pitch channel and yaw channel control systems of the STT missile, the effectiveness of the designed compound control system in achieving a fast response is verified. Full article

The drive torque of each wheel hub motor of a four-wheel independent wire-controlled steering electric vehicle is independently controllable, representing a typical over-actuated system. Through optimizing the distribution of the drive torque of each wheel, fault-tolerant control can be realized. In this paper, the four-wheel independent wire-controlled steering electric vehicle is taken as the research object, aiming at the collaborative control problem of trajectory tracking and yaw stability when the actuator of the by-wire steering system fails, a fault-tolerant control method based on the synergy of differential steering and direct yaw moment is proposed. This approach adopts a hierarchical control system. The front wheel controller predicts the necessary steering angle in accordance with a linear model and addresses the requirements of the front wheels and additional torque. Subsequently, considering the uncertainties in the drive control system and the complexities of the road obstacle model, the differential steering torque is computed via the sliding mode control method; the lower-level controller implements the torque optimization distribution strategy based on the quadratic programming algorithm. Finally, the validity of this approach under multiple working conditions was verified via CarSim 2019 and MATLAB R2023b/Simulink simulation experiments. Full article

The rotary double inverted pendulum system is characterized by one stable equilibrium point and three unstable equilibrium points due to its kinematic properties. This paper defines the transition control problem between these equilibrium points to extend the conventional swing-up control problem and proposes an implementation method using a laboratory-developed rotary double inverted pendulum. To minimize energy consumption during the transition process while satisfying the boundary conditions of different equilibrium points, a two-point boundary value optimal control problem is formulated. The feedforward trajectory required for feedforward control is computed offline by solving this problem. The direct collocation method is employed to convert the constrained continuous optimal control problem into a nonlinear optimization problem. Furthermore, a time-varying linear–quadratic (LQ) controller is utilized as a feedback controller to accurately track the generated feedforward trajectory during real-time control, compensating for uncertainties in the feedforward control process. The proposed transition control strategy is experimentally implemented, and its effectiveness and practicality are validated through the successful tracking of 12 transition trajectories. Full article

This paper presents a method to design a path-tracking controller with an adaptive preview distance scheme for autonomous vehicles. Generally, the performance of a path-tracking controller depends on tire–road friction and is severely deteriorated on low-friction roads. To cope with the problem, it is necessary to design a path-tracking controller that is robust against variations in tire–road friction. In this paper, a preview function is introduced into the state-space model built for better path-tracking performance. With the preview function, an adaptive preview distance scheme is proposed to adaptively adjust the preview distance according to the variations in tire–road friction. Front-wheel steering (FWS) and four-wheel steering (4WS) are adopted as actuators for path tracking. With the state-space model, a linear quadratic regulator (LQR) is adopted as a controller design methodology. In the adaptive preview distance scheme, the best preview distance is obtained from simulation for several tire–road friction conditions. Curve fitting with an exponential function is applied to those preview distances with respect to the tire–road friction. To verify the performance of the adaptive preview distance scheme under variations in tire–road friction, a simulation is conducted on vehicle simulation software. From the simulation results, it was shown that the path-tracking controller with an adaptive preview distance scheme presented in this paper was effective for path tracking against variations in tire–road friction in the peak’s center offset, and the settling delays were reduced by 60% and 23%, respectively. Full article
