Search Results (16)

A shape-controllable laser-engraving treatment (LET) and aramid pulp (AP)-reinforced resin pre-coating (RPC) were used on a titanium (Ti) alloy surface to construct micro-/nano-aramid pulp and epoxy (MAPE) coatings for greater bonding strength with carbon fiber-reinforced polymers (CFRPs). The array pits of regular hexagon on the Ti alloy surface were engraved and vertical spaces between the array pits were created to place the AP-reinforced epoxy for stronger mechanical interlocking. The specimen treated with laser engraving (side length of 0.3 mm) and AP-reinforced RPC yielded the greatest bonding strength of 27.1 MPa, 67.4% higher than the base strength. The failure modes of the Ti-CFRPs composites changed from debonding failure at the Ti/epoxy surface to fiber-damaged failure of the laminated CFRPs panels. The shape-controllable LET and simple AP-reinforced RPC were confirmed as the most feasible and effective combined methods for use on titanium alloy surfaces for manufacturing stronger Ti-CFRPs composites, which exhibited the potential for application in other metal–matrix-bonding composite systems. Full article

This study designed laser engraving and resin pre-coating (RPC) treatments on an aluminum alloy (AA) surface to construct through-the-thickness “epoxy pins” for improving the bonding strength with carbon fiber reinforced polymer (CFRP). A laser engraving treatment was used to create a pitted structure on the AA surface; higher wettability was acquired and greater vertical spaces were formed to impregnate epoxy resin, resulting in stronger mechanical interlocking. The RPC technique was further used to guide high-viscosity epoxy resin into pits to form the epoxy coatings and to minimize defects between the resin and the substrate. The bonding strength of the specimen treated with both laser engraving with a unit dimension of 0.3 mm and RPC increased up to 227.1% in comparison with that of the base. The failure modes of the hybrid composites changed from the debonding failure of the AA surface to the delamination-dominated failure of the laminated CFRP composites. It was confirmed that laser engraving is a feasible and effective method when combined with RPC for treating AAs to improve the bonding strength of AA-CFRP composites, which provides a reference for preparing high-performance hybrid composites with metals. Full article

This study focused on effective methods of laser engraving treatment (LET), plasma spraying, and resin pre-coating (RPC) to manufacture the reinforced adhesive joints of titanium alloy and carbon fiber-reinforced polymer (TA-CFRP) composites. The combined treatments contributed to the creation of a better adhesive bonding condition and offer a vertical gap between circular protrusions to form epoxy pins and carbon nanotube (CNT)-reinforced epoxy pins. The bonding strength of the TA-CFRP composite was reinforced by 130.6% via treatments with a twice-engraving unit of 0.8 mm, plasma spraying, and RPC. The original debonding failure on the TA surface was changed into the cohesive failure of the epoxy adhesive and delamination-dominated failure of the CFRP panel. Overall, laser engraving has been confirmed as an effective and controllable treatment method to reinforce the bonding strength of the TA-CFRP joint combined with plasma spraying and RPC. It may be considered as an alternative in industry for manufacturing high-performance metal–CFRP composites. Full article

Laser engraving is a convenient, fast, one-step, and environmentally friendly technique used to produce more conductive surfaces by local pyrolysis. The laser’s thermal treatment can also remove non-conductive materials from the electrode surfaces and improve electrochemical performance. The improvement was assessed by electrochemical tools such as cyclic voltammograms and electrochemical impedance spectroscopy using [Fe(CN)₆]^3−/4− and dopamine as redox probes. The electrochemical results observed showed that a treated surface showed an improvement in electron transfer and less resistance to charge transfer. To optimize the electrode performance, it was necessary to search for the most favorable graphite mines and optimize the parameters of the laser machine (laser power, scan rate, and output distance). The resultant material was adequately characterized by Raman spectroscopy and scanning electron microscopy (SEM), where an irregular surface composed of crystalline graphite particles was noticed. Furthermore, as a proof-of-concept, it was applied to detect indapamide (IND) in synthetic urine by flow injection analysis (FIA), a diuretic drug often used by athletes to alter urine composition to hide forbidden substance consumption in doping tests. Full article

The liquid-repellent properties of AISI 304 stainless steel surfaces textured with a femtosecond laser were studied, both after spontaneous hydrophobization and when treated with stearic acid and octyltrimethoxysilane. Surface topography has been shown to play a critical role in determining these properties. Although textures containing only LIPSS exhibited poor liquid-repellency, the performance was significantly improved after engraving the microtexture. The most effective topography consisted of 45 µm-wide grooves with a pitch of 60 µm and protrusions covered with a rough microcrystalline structure. Liquid-repellency, chemical treatment efficiency, and UV resistance were compared using derived Owens–Wendt parameters. The surface of femtosecond-laser-textured steel after spontaneous hydrophobization was found to be significantly less stable under UV irradiation than surfaces treated with stearic acid or octyltrimethoxysilane modifiers. Full article

Hybrid metal matrix composites (HMMCs) are a special type of material, possessing combined properties that belong to alloys and metals according to market demands. Therefore, they are used in different areas of industry and the properties of this type of material are useful in engineering applications, e.g., in aircraft engines and electrotechnical parts. The structure of the material requires a number of scientific studies to develop an appropriate processing technology. The paper presents the susceptibility of material from the HMMCs group with the EN AC-44300 (AISi12(Fe)) aluminum alloy matrix with a two-component reinforcement made of alumina particles (AP) and aluminosilicate fibers (AF) to thermal treatment with a laser beam. During this process, laser engraving of the researched material with variable beam power P_av and variable speed of the laser head v_l were carried out. A metallographic analysis of the material was carried out. After laser engraving, surface structural changes of the material were determined. The properties of the surface geometric structure of processed material were also examined. Presented studies concern laser engraving on the surface of composite from the HMMC group, which was made by vacuum infiltration. Thanks to this method, it is possible both to produce shaped and precise composite castings with saturated reinforcement and to consequently minimize machining losses. Metal–ceramic composites from the HMMC group are hard-to-machine materials which create problems during machining. The aim of these studies was to develop a laser engraving technology with Al matrix composite with the addition of Al₂O₃ particles and aluminosilicate fibers, which constitute the reinforcement. The focus was on the selection of engraving parameters (beam power and speed of movement of the laser head). Clear examples of engraving, suitable for macro-assessment, were obtained with minimal change in the initial surface structure of the composite. Full article

Polyetheretherketone (PEEK) is widely used in dentistry owing to its exceptional properties, including its natural appearance; however, existing surface treatment methods for bonding PEEK have limitations. Autofocus laser cutters, known for their precise engraving and cutting capabilities, offer potential for surface treatment of PEEK; thus, the objective of this study was to investigate the creation of laser groove structures on PEEK to enhance its bonding capability with dental resin cement. A dental computer-aided design and manufacturing system was used to fabricate PEEK samples, and three groove patterns (circle, line, and grid) were generated on PEEK surfaces, with air-abrasion used as the control group. The surface characteristics, cell viability, and bond strength were evaluated, and the data were statistically analyzed using one-way analysis of variance and post hoc Tukey’s tests (α = 0.05). Laser-treated PEEK exhibited a uniform texture with a groove depth of approximately 39.4 µm, hydrophobic properties with a contact angle exceeding 90°, a surface roughness of 7.3–12.4 µm, consistent topography, and comparable cell viability compared with untreated PEEK. Despite a decrease in bond strength after thermal cycling, no significant intergroup differences were observed, except for the line-shaped laser pattern. These findings indicate that the autofocus laser cutter effectively enhances the surface characteristics of PEEK by creating a uniform texture and grooves, showing promise in improving bonding properties, even considering the impact of thermal cycling effects. Full article

With the goal of substituting a hard metallic material for the soft Ultra High Molecular Weight Polyethylene (UHMWPE) presently used to make the bases of skis for alpine skiing, we used two non-thermodynamic equilibrium surface treatments with ultra-short (7–8 ps) laser pulses to modify the surface of square plates (50 × 50 mm²) made of austenitic stainless steel AISI 301H. By irradiating with linearly polarized pulses, we obtained Laser Induced Periodic Surface Structures (LIPSS). By laser machining, we produced a laser engraving on the surface. Both treatments produce a surface pattern parallel to one side of the sample. For both treatments, we measured with a dedicated snow tribometer the friction coefficient µ on compacted snow at different temperatures (−10 °C; −5 °C; −3 °C) for a gliding speed range between 1 and 6.1 ms⁻¹. We compared the obtained µ values with those of untreated AISI 301H plates and of stone grinded, waxed UHMWPE plates. At the highest temperature (−3 °C), near the snow melting point, untreated AISI 301H shows the largest µ value (0.09), much higher than that of UHMWPE (0.04). Laser treatments on AISI 301H gave lower µ values approaching UHMWPE. We studied how the surface pattern disposition, with respect to the gliding direction of the sample on snow, affects the µ trend. For LIPSS with pattern, orientation perpendicular to the gliding direction on snow µ (0.05) is comparable with that of UHMWPE. We performed field tests on snow at high temperature (from −0.5 to 0 °C) using full-size skis equipped with bases made of the same materials used for the laboratory tests. We observed a moderate difference in performance between the untreated and the LIPSS treated bases; both performed worse than UHMWPE. Waxing improved the performance of all bases, especially LIPSS treated. Full article

Laser joining of polymers to metals is a rising research subject due to the potential of considerably reducing the weight of structures. This article deals with the laser joining process between polypropylene and aluminum. Without pre-treatment, laser joining of these materials is not feasible, and the method applied in this study to circumvent this issue is a surface modification of aluminum with a pulsed laser to create mechanical interlocking for the heat conduction laser joining technique. Different patterns and various laser parameters are analyzed with the design of experiments to best understand the effects of each parameter along with microscopic observations. It is found that engraving weakens the mechanical properties of the aluminum samples. The compromise between the engraving depth and the mechanical properties of the samples is optimized, and the engraving process with a 0.28 mm line width, 27.3% density and 150 mm/s speed provides the highest mechanical performance of the assembly with minimum degradation of aluminum samples. Moreover, by adjusting the laser power and using power modulation below 300 W, the decomposition of polypropylene occurring at high temperatures is reduced to a minimum. After the final optimization, the joined samples reliably withstand a maximum force of 1500 N, which is, approximately, a shear strength of 20 MPa. Full article

The work investigates the effects of CO₂ laser parameters (laser power and raster density) on wood mass loss in oak wood and impacts on its morphology, chemical structure, and surface properties (colour and hydrophilicity). The energy amount supplied onto the wood surface with a laser beam under different combinations of the irradiation parameters was expressed through a single variable—total irradiation dose. The mass loss was confirmed as linear-dependent on the irradiation dose. With the mass reduction, the roughness was enhanced. The roughness parameters Ra and Rz increased linearly with the mass loss associated with the increasing irradiation dose. The FTIR (Fourier transform infrared spectroscopy) spectroscopy also detected chemical changes in the main wood components, influencing primarily the wood colour space. Conspicuous discolouration of the engraved wood surface was observed, occurring just at the minimum laser power and raster density. The additional increasing of laser parameters caused a novel colour compared to the original one. The detected dependence of wood discolouration on the total irradiation dose enables us to perform targeted discolouration of the oak wood. The engraved surfaces manifested significantly better wettability with standard liquids, both polar and non-polar, and higher surface energy values. This guarantees appropriate adhesion of film-forming materials to wood. Identification of the changes in wood surface structure and properties, induced by specific CO₂ laser-treatments, is important for obtaining targeted discolouration of the wood surface as well as for the gluing or finishing of the surfaces treated in this way. Full article

The presented work’s aim is the application of low-power laser treatment for the enhancement of interfacial micromechanical adhesion between polyamide 6 (filled with glass fiber) and aluminum. A fiber laser beam was used to prepare micro-patterns on aluminum sheets. The micro-structuring was conducted in the regime of 50, 100, 200 and 300 mm/s laser beam speeds, for both sides. The joining process was realized in an injection molding process. Metallic inserts were surface engraved and overmolded in one-side and two-side configurations. A lap shear test was used to examine the strength of the joints. Engraved metallic surfaces and adequate imprints on polyamide side were checked by optical microscope with motorized stages, and roughness parameters were also determined. Microscopic observations made it possible to describe the grooves’ shape and to conclude that a huge recast melt was formed when the lowest laser beam speed was applied; thus, the roughness parameter Ra reached the highest value of 16.8 μm (compared to 3.5 μm obtained for the fastest laser speed). The maximum shear force was detected for a sample prepared with the lowest scanning speed (one-sides joints), and it was 883 N, while for two-sided joints, the ultimate force was 1410 N (for a scanning speed of 200 mm/s). Full article

Cable-driven parallel robots offer significant advantages in terms of workspace dimensions and payload capability. Their mechanical structure and transmission system consist of light and extendable cables that can withstand high tensile loads. Cables are wound and unwound by a set of motorized winches, so that the robot workspace dimensions mainly depend on the amount of cable that each drum can store. For this reason, these manipulators are attractive for many industrial tasks to be performed on a large scale, such as handling, pick-and-place, and manufacturing, without a substantial increase in costs and mechanical complexity with respect to a small-scale application. This paper presents the design of a planar overconstrained cable-driven parallel robot for quasi-static non-contact operations on planar vertical surfaces, such as laser engraving, inspection and thermal treatment. The overall mechanical structure of the robot is shown, by focusing on the actuation and guidance systems. A novel concept of the cable guidance system is outlined, which allows for a simple kinematic model to control the manipulator. As an application example, a laser diode is mounted onto the end-effector of a prototype to perform laser engraving on a paper sheet. Observations on the experiments are reported and discussed. Full article

Platelet separation and purification are required in many applications including in the detection and treatment of hemorrhagic and thrombotic diseases, in addition to transfusions and in medical research. In this study, platelet separation was evaluated using a novel zigzag microchannel fluidic device while leveraging a dielectrophoresis (DEP) electric field using the COMSOL multiphysics software package and additional experimentation. The zigzag-shaped microchannel was superior to straight channel devices for cell separation because the sharp corners reduced the required horizontal distance needed for separation and also contributed to an asymmetric DEP electric field. A perfect linear relationship was observed between the separation distance and the corner angles. A quadratic relationship (R² = 0.99) was observed between the driving voltage and the width and the lengths of the channel, allowing for optimization of these properties. In addition, the voltage was inversely proportional to the channel width and proportional to the channel length. An optimal velocity ratio of 1:4 was identified for the velocities of the two device inlets. The proposed device was fabricated using laser engraving and lithography with optimized structures including a 0.5 mm channel width, a 120° corner angle, a 0.3 mm channel depth, and a 17 mm channel length. A separation efficiency of 99.4% was achieved using a voltage of 20 V and a velocity ratio of 1:4. The easy fabrication, lower required voltage, label-free detection, high efficiency, and environmental friendliness of this device make it suitable for point-of-care medicine and biological applications. Moreover, it can be used for the separation of other types of compounds including lipids. Full article

During various applications in aerospace, ships, autos, and aircraft, 7075 Al alloy will frequently contact other materials, and therefore suffer from slight abrasion. However, the poor tribological properties of 7075 Al alloy greatly affect its performance and life length, leading to limitations in its application. Preparing roughness structures on the surface is regarded as a promising method to improve the properties of materials. However, the tribological properties of 7075 Al alloy cannot be enhanced significantly by roughness structures in complex dynamic changeable environments, owing to the incomplete understanding of the effect of roughness structures. Given the above issues, in this paper, micro-scale structures (linear grooves, gridding grooves, and arc grooves) were designed and prepared on 7075 Al alloy surfaces by a surface treatment (laser micro-engraving), which provides excellent controllability of the morphology and dimensions of as-prepared roughness structures. The tribological properties of the as-prepared surfaces were investigated systemically. The effect of micro-scale structures on the tribological properties was studied. The wear mechanism and tribological properties improvement mechanism of the surfaces were clarified. Furthermore, the effect degree of the enhancement factors of the micro-scale structures on the tribological properties was explored under different conditions. The results indicate that the micro-scale structures play an important role in improving the tribological properties of Al alloy under different sliding speeds. The improvement mechanism can be summarized by four factors. However, the effect degrees of these factors on the tribological properties exhibit considerable differences. This study not only develops specific micro-scale structures that can dramatically improve the tribological properties of 7075 Al alloy under different conditions, but also offers guidance for the construction of appropriate roughness structures that can dramatically improve the tribological properties of Al alloy according to the friction conditions. Full article

Surface microstructure preparation offers a promising approach for overcoming the shortcomings of Al alloy, such as poor friction resistance, low hardness and weak corrosion resistance to corrosive liquid. Though many methods for the surface microstructure preparation of Al alloy have been developed, it is difficult for most of the reported methods to regulate the as-prepared microstructure, meaning that the properties of Al alloy cannot be improved efficiently by the microstructure. Thus, the application of microstructure surface of Al alloy and microstructure preparation technology is severely limited. Aimed at this issue, a simple, convenient, high-efficient, low-cost micro-scale roughness structure construction approach that is suitable for engineering application (laser micro-engraving) was developed. The as-prepared microstructure on Al alloy surface formed by laser micro-engraving was investigated systemically. The morphology and formation mechanism of the microstructure were examined. Meanwhile, the effect of laser parameters on morphology, geometrical dimensions and composition of microstructure was investigated. The results indicate that the morphology of microstructure is affected by the overlap degree of molten pool greatly. When each molten pool does not overlap with others, successive individual pits can be constructed. When each molten pool overlaps with others for one time, successive overlapping pits will form. As the overlap degree of the molten pool further increases (overlapping with others for more than one time), the successive pits can become grooved. Because of the influence of laser beam pulse frequency and scanning speed on the diameter and distance of the molten pools, the morphology and geometrical dimensions of microstructure can vary greatly with laser parameters. As the laser beam scanning speed increases, the geometrical dimensions of as-prepared microstructure reduce significantly. In contrast, with the increase of laser beam pulse frequency, the geometrical dimensions change in a complicated manner. However, the chemical composition of microstructure is slightly affected by laser parameters. More importantly, a relationship model was successfully established, which could be used to predict and regulate the geometrical dimensions of microstructure treated by laser micro-engraving. Controllable preparation of microstructure on Al alloy is realized, leading that specific microstructure can be prepared rapidly and accurately instead of suffering from long-time experimental investigation in the future. Full article
