Search Results (16)

Vibrations occurring during milling operations are one of the main issues disturbing the pursuit of better efficiency of milling operations and product quality. Even in the case of a stable cutting process, vibration reduction is still an important goal. One of the possible solutions to obtain it is selection of the favorable conditions for clamping the workpiece to the machine table. In this paper, a method for predicting and selecting the clamping condition of a large-size workpiece for the reduction in vibrations during milling is presented. A modal test of the workpiece is performed first for a selected set of tightening screw settings. Next, one milling pass is performed to obtain reference data which are then used to tune the hybrid computational model. In the subsequent step, milling simulations are performed for a set of tightening variants, and the best one is selected, providing the lowest vibrations, assessed as the root mean square (RMS) of vibration displacements. In this paper, the description of the clamping selection procedure, key elements of the simulation model, and simulation and experimental results obtained for the milling of the test workpiece performed for a set of different clamping conditions are provided. The proposed method accurately predicts not only the best but also the worst clamping conditions. Full article

In advanced manufacturing, optimizing mixed-model synchronous assembly lines (MMALs) is crucial for enhancing productivity and adhering to sustainability principles, particularly in terms of energy consumption and energy-efficient sequencing. This paper introduces a novel approach by categorizing sequence-dependent setup times into bipartite categories: workpiece-independent and workpiece-dependent. This strategic division streamlines assembly processes, reduces idle times, and decreases energy consumption through more efficient machine usage. A new mathematical model is proposed to minimize the intervals at which workpieces are launched on an MMAL, aiming to reduce operational downtime that typically leads to excessive energy use. Given the Non-deterministic Polynomial-time hard (NP-hard) nature of this problem, a genetic algorithm (GA) is developed to efficiently find solutions, with performance compared against the traditional branch and bound technique (B&B). This method enhances the responsiveness of MMALs to variable production demands and contributes to energy conservation by optimizing the sequence of operations to align with energy-saving objectives. Computational experiments conducted on small and large-sized problems demonstrate that the proposed GA outperforms the conventional B&B method regarding solution quality, diversity level, and computational time, leading to energy reductions and enhanced cost-effectiveness in manufacturing settings. Full article

GH4169 alloy/Inconel 718 is extensively utilized in aerospace manufacturing due to its excellent high temperature mechanical properties. Micro-structuring on the workpiece surface can enhance its properties further. Through-mask electrochemical micromachining (TMEMM) is a promising and potential processing method for nickel-based superalloys. It can effectively solve the problem that traditional processing methods are difficult to achieve large-scale, high-precision and efficiency processing of surface micro-structure. This study explores the feasibility of electrochemical machining (ECM) for GH4169 using roll-print mask electrochemical machining with a linear cathode. Electrochemical dissolution characteristics of GH4169 alloy were analyzed in various electrolyte solutions and concentrations. Key parameters including cathode sizes, applied voltage and corrosion time were studied in the roll-print mask electrochemical machining. A qualitative model for micro-pit formation on GH4169 was established. Optimal parameters were determined through experiments: 300 μm mask hole and cathode size, 10 wt% NaNO₃ electrolyte, 12 V voltage, 6 s corrosion time. The results demonstrate that the micro-pits with a diameter of 402.3 μm, depth of 92.8 μm and etch factor (EF) of 1.81 show an excellent profile and localization. Full article

Machining nickel-based alloys always exhibits significant work-hardening behavior, which may help to improve the part quality by building a hardened layer on the surface, while also causing severe tool wear during machining. Hence, modeling the work-hardening phenomenon plays a critical role in the evaluation of tool wear and part quality. This paper aims to propose a numerical model to estimate the work-hardening layer for a deeper understanding of this behavior, employing both recrystallization-based and dislocation-based models to cover workpieces with multiscale grain sizes. Different user routines are implemented in the finite element method to simulate the increase in hardness in the deformed area due to recrystallization or changes in the dislocation density. The validation of the proposed model is performed with both literature and experimental data for Inconel 718 with small or large grain sizes. It is found that the recrystallization-based model is more suitable for predicting the work-hardening behavior of small-grain-size Inconel 718 and the dislocation-based model is better for that of large-grain-size Inconel 718. Further, as an important type of cutting tool in machining Inconel 718, the chamfered tools with different edge geometries are employed in the simulations of machining-induced work hardening. The results illustrate that the uncut chip thickness and chamfer angle have a significant influence on the work-hardening behavior. Full article

Electric discharge machining (EDM) is a type of high-precision machining usually applied to hard-material machining for mold manufacturing and in the aerospace industry. Longer process times typically reduce facility efficiency. The use of electrochemistry machining (ECM) can overcome this challenge to efficiently machine large workpieces. Some industries have adopted and combined these two processes for Inconel 718 material machining. However, the use of coordinate-measuring machine times to determine the machining accuracy of these two processes is difficult. This study matched process features by analyzing the electric driving pulses of ECM and EDM. Fitting intelligent sensing signals that respond to dimensional measurements can be used to analyze electrical pulse signals. For analyzing a cross-process model using extracted key features of the process, our feedback-based system determines lower machining measurement errors and improves geometric size. Finally, the processing time of experiments can be reduced by 80%, and our proposed model has a prediction accuracy of approximately 0.01 ${\mathrm{mm}}^2$. Full article

Cutting fluids (CFs) are chemical liquids or aqueous emulsions of mineral (or synthetic) oil widely used in metal-machining processes. They contain toxic organic compounds and petroleum products, and spent CFs contain numerous small metal particles derived from the processing of metal workpieces. The iron fine particles (IFPs) in CFs can diminish the quality and precision of machine products. Machining industries purchase large amounts of CFs, which they must treat appropriately and from which they must remove the IFPs; therefore, cost-effective ways to treat spent CFs are needed. In this study, we evaluated the effectiveness of collecting and separating the IFPs and treating organic matter in spent CFs using microbubbles (MiBs). We found that numerous IFPs with sizes of ~1 μm were suspended in spent CFs and that they could be very effectively removed by bubbling with MiBs and skimming the surface of the CFs. The lifetime of the CFs could be doubled via this treatment. The cost for treating spent CFs using MiBs was 12% lower than the cost of traditional treatment. These results strongly suggest that bubbling with MiBs is a cost-effective and eco-friendly way to treat spent CFs. Full article

This paper concerns the problem of vibration reduction during milling. For this purpose, it is proposed that the standard supports of the workpiece be replaced with adjustable stiffness supports. This affects the modal parameters of the whole system, i.e., object and its supports, which is essential from the point of view of the relative tool–workpiece vibrations. To reduce the vibration level during milling, it is necessary to appropriately set the support stiffness coefficients, which are obtained from numerous milling process simulations. The simulations utilize the model of the workpiece with adjustable supports in the convention of a Finite Element Model (FEM) and a dynamic model of the milling process. The FEM parameters are tuned based on modal tests of the actual workpiece. For assessing simulation results, the proper indicator of vibration level must be selected, which is also discussed in the paper. However, simulating the milling process is time consuming and the total number of simulations needed to search the entire available range of support stiffness coefficients is large. To overcome this issue, the artificial intelligence salp swarm algorithm is used. Finally, for the best combination of stiffness coefficients, the vibration reduction is obtained and a significant reduction in search time for determining the support settings makes the approach proposed in the paper attractive from the point of view of practical applications. Full article

Accurate and non-destructive technology for detection of subsurface defect has become a key requirement with the emergence of various ultra-precision machining technologies and the application of ultra-precision components. The combination of acoustic technique for sub-surface detection and atomic force microscopy (AFM) for measurement with high resolution is a potential method for studying the subsurface structure of workpiece. For this purpose, contact-resonance AFM (CR-AFM) is a typical technique. In this paper, a CR-AFM system with a different principle from commercially available instruments is set up and used for the detection of sub-surface Si samples with grating structures and covered by different thickness of highly oriented pyrolytic graphite (HOPG). The influence of subsurface burial depth on the detection capability is studied by simulations and experiments. The thickest HOPG film allowing for sub-surface measurement by the proposed method is verified to be about 30 μm, which is much larger than the feature size of the subsurface microstructure. The manuscript introduces the difference between this subsurface topography measurement principle and the commercially available AFM measurement principle, and analyzes its advantages and disadvantages. The experimental results demonstrates that the technique has the capability to reveal sub-surface microstructures with relatively large buried depth and is potential for engineering application in ultra-precision technologies. Full article

There is an increasing demand for large-sized hydrostatic rotary tables due to the industrial need for the precision machining of large workpieces for wind generation, aerospace, shipbuilding, and national defense applications. As a consequence, under eccentric loads, the deformation of the large-sized hydrostatic rotary table of a horizontal boring machine would negatively affect machining precision. Indeed, the hydrostatic thrust-bearing recess layout design is the main factor that affects the rotary table’s resistance against deformations caused by eccentric loads. This study focused on the capillary-compensated constant-pressure large-sized hydrostatic rotary table for a horizontal boring machine. ANSYS software was used to simulate the thermal and structural deformation of the worktable under eccentric loads. In addition to the original layout of the hydrostatic thrust bearing, three other bearing recess layouts, which involved two different recess diameters, were designed in order to examine the deformation of the worktable under eccentric loads. The results showed that, in terms of a single-ring hydrostatic thrust-bearing layout, a larger recess diameter resulted in a smaller worktable deformation compared to a smaller recess diameter; in terms of a dual-ring hydrostatic thrust bearing layout, the worktable deformation was smaller than that of the single-ring layout with a larger recess diameter. Under the spatial and geometric constraints of the worktable, adopting a hydrostatic thrust bearing with a dual-ring recess layout would minimize the worktable deformation under eccentric loads. For thermal deformation in a single-ring hydrostatic bearing pad layout, however, a larger recess diameter resulted in a larger worktable thermal deformation compared to a smaller recess diameter. Full article

Magnetic abrasive finishing (MAF) shows a high potential for use on computerized numerical control (CNC) machine tools as a standard tool to polish workpieces directly after the milling process. This paper presents a new MAF tool with a single, large permanent magnet and a novel top cover structure for finishing the plain ferromagnetic workpieces. The top cover structure of the MAF tool, combined with an optimized working gap, ensures the effect of mechanical powder compaction, which leads to a significant increase in process capability and surface roughness reduction. The influence of the process parameters such as feed rate, equivalent cutting speed, working gap (including for three grain sizes) and the gap to the magnet was investigated. In addition, the influence of the initial surface after face milling, end milling, ball end milling and grinding on the surface quality after MAF was investigated. Furthermore, three typical surfaces after milling and MAF were analyzed. By magnetic abrasive finishing, a significant surface quality improvement of the initial milled surfaces to roughness values up to Ra = 0.02 µm and Rz = 0.12 µm in one processing step could be achieved. Full article

Small-size cutting inserts for assembly cutters are widely used to manufacture a variety of parts for the aerospace, automotive and mechanical engineering industries. Due to their high hardness and chemical stability, cutting Al₂O₃-TiC ceramics significantly outperform hard alloys in machining heat-resistant and difficult-to-machine materials. However, grinding on CNC machines, the most common technology for manufacturing ceramic inserts, is associated with numerous issues when it comes to manufacturing small-size cutting inserts. For example, high cutting forces and high grinding wheel wear rates cause a rapid loss of dimensional accuracy and deterioration of the quality of the surface being machined, while the interference of the grinding wheel with the surface being treated imposes serious limitations on the geometry of the small-size ceramic inserts to be grinded. Here we show that Wire Electrical Discharge Machining (WEDM), which is a contactless and, thus, a more flexible method in terms of the size and geometrical properties of a workpiece to be machined, can be used as a replacement for grinding operations in machining small ceramic inserts. A composite of 70% aluminum oxide and 30% titanium carbide was chosen as a ceramic material because a further increase in the TiC fraction causes a marked decrease in wear resistance, while its decrease results in an undesirable loss of electrical conductivity. While in order to replace grinding with WEDM, WEDM has to be stable in the sense of occurring without frequent wire breakages, achieving WEDM stability is not an easy task due to the low electrical conductivity of Al₂O₃-TiC ceramics and high operational temperatures, which promote the diffusion of dielectric and electrode products in the surface layer of the cutting inserts being machined. These factors may lower the quality of the final product due to damage to the insert surface, marked increases in the roughness RA and in diffusion in the surface layer, which increases the friction coefficient and, hence, reduces the life of the manufactured cutting inserts. We have increased stability of the WEDM process by identifying and applying rational process conditions that lead to a reduced, by a factor of 2.63, roughness Ra and also a reduced, by a factor of 1.3, depth of craters. Performing a chemical and structural analysis, we found that the application of high energies combined with an increasing interelectrode gap (IG) (technological parameter SSol, a complex indicator that determines the speed of the wire electrode depending on the number of pulses per unit of time and the IG size, is set at 80, EDM3 technology) causes increased surface damage and contamination, while a small IG (SSol = 45, EDM1 technology) reduces the material removal rate due to contamination of the working zone between the surface being machined and the electrodes. After reducing the IG by lowering SSol from 80 to 45, the roughness Ra of 0.344 µm was achieved, which allows for replacing grinding operations with WEDM in machining hardening chamfers, front surfaces and, to a lesser degree, the rear and support surfaces of cutting inserts. In this case, when the IG is reduced to SSol = 45, the electroerosion products in the dielectric promote local breakdowns, which in turn produce a large number of deep craters which adversely affect the performance of cutting inserts. However, we found that a slight increase in SSol from 45 to 55 (EDM3 technology) significantly reduces the number of craters and lowers their depth from 50 μm to 37 μm. Although in this case the roughness grows to 0.534 μm due to increased discharge energy, the improved flushing of the IG and the reduced occurrence of local high-temperature breakdowns—evidenced by a decrease in the depth and number of deep craters formed due to current localization during short circuits—significantly reduced contamination of the surface layer and the crater formation rate. Therefore, WEDM can be recommended for use in machining reinforcing chamfers and, to a lesser degree, front surfaces. These considerations lead us to conclude that WEDM is a viable alternative to grinding in machining Al₂O₃-TiC ceramic cutting inserts of a small size and a complex shape, and that its application to manufacturing cutting inserts from poorly conductive cutting ceramics should be studied further. Full article

Brushing with bonded abrasives is a finishing process which can be used for the surface improvement of various materials. Since the machining mechanisms of abrasive brushing processes are still largely unknown and little predating research was done on brushing ceramic workpieces, within the scope of this work technological investigations were carried out on planar workpieces of MgO-PSZ (zirconium dioxide, ZrO₂) using brushing tools with bonded grains of polycrystalline diamond. The primary goal was the reduction of grinding-related surface defects under the preservation of surface roughness valleys and workpiece form. Based on microscopy and topography measurements, the grain size s_g and the brushing velocity v_b were found to have a considerable influence on the processing result. Furthermore, excessive tool wear was observed while brushing ceramics. Full article

With the rapid developments of the Industrial Era 4.0, numerous sensors have been employed to facilitate and monitor the quality of machining processes. Among them, accelerometers play an important role in chatter detection and suppression for reducing the tool down-time and increasing manufacturing efficiency. To date, most commonly seen accelerometers have relatively large sizes such that they can be installed only on the housing of spindles or the surfaces of workpieces that may not be able to directly capture actual vibration signals or obstruct the cutting process. To address this challenge, this research proposed a compact, wide-bandwidth resonant accelerometer that could be embedded inside high-speed spindles for real-time chatter monitoring and prediction. Composed of a double-ended tuning fork (DETF), a proof mass, and a support beam, the resonant accelerometer utilizes the resonance frequency shift of the DETF due to the bending motions of the structure during out-of-plane accelerations as the sensing mechanism. The entire structure based on commercially available quartz tuning forks (QTFs) with electrodes for symmetric-mode excitations. The advantages of this structure include low noise and wide operation bandwidth thanks to the frequency modulation scheme. A theoretical model and finite element analysis were conducted for designs and optimizations. Simulated results demonstrated that the proposed accelerometer has a size of 9.76 mm × 4.8 mm × 5.5 mm, a simulated sensitivity of 0.94 Hz/g, and a simulated working bandwidth of 3.5 kHz. The research results are expected to be beneficial for chatter detection and intelligent manufacturing. Full article

In this work, a three-dimensional large-deformation thermo-elastic-plastic finite element model for oblique cutting was established to analyze edge defects during the machining of 17vol.% SiC_p/2009Al composites. The formation process of edge defects at the workpiece exit during turning was investigated, and the influence of depth of cut, feed rate, and spindle speed on the edge defect sizes at the workpiece exit was explored. The results show that a negative deformation plane began to form as the cutting tool approached the exit end of cut, and the resultant cracks propagated towards the negative shear deformation plane, which led to workpiece edge defects. In addition, the size of edge defects increased with increasing depth of cut and feed rate, while the spindle speed had less influence on the size of edge defects. The numerical results of the effects of cutting parameters on edge defects were also compared to those of the turning experimental data, and were found to be in reasonable agreement. Full article

The emergence of multitasking machines in the machine tool sector presents new opportunities for the machining of large size gears and short production series in these machines. However, the possibility of using standard tools in conventional machines for gears machining represents a technological challenge from the point of view of workpiece quality. Machining conditions in order to achieve both dimensional and surface quality requirements need to be determined. With these considerations in mind, computer numerical control (CNC) methods to provide useful tools for gear processing are studied. Thus, a model for the prediction of surface roughness obtained on the teeth surface of a machined spiral bevel gear in a multiprocess machine is presented. Machining strategies and optimal machining parameters were studied, and the roughness model is validated for 3 + 2 axes and 5 continuous axes machining strategies. Full article
