The deposition of large-sized cuttings (or blocky cuttings) is a critical risk factor for stuck pipe incidents during the drilling of deep and extended-reach wells. This risk is particularly pronounced in well sections with long borehole trajectories and low drilling fluid return velocities, where it poses a substantial threat to wellbore cleanliness and the safe operation of the drill string. This study utilizes a self-developed visual experimental platform to simulate the deposition evolution of large-sized cuttings (20–40 mm in diameter) in the annulus under various wellbore inclinations and drilling fluid parameters. The stable height, lateral distribution characteristics, and response patterns of the resulting cuttings bed under different conditions were quantitatively characterized. Building upon this, a theoretical contact friction model between the drill string and the cuttings bed was employed to investigate how the bed height influences hook load during tripping and rotary torque during top drive operation. A mapping relationship was established between cuttings bed structural parameters and the resulting additional loads and torques. Results reveal significant interactive effects among drilling fluid velocity, fluid density, drill pipe rotation speed, and wellbore inclination on both cuttings bed development and associated drill string loads. Strong correlations were identified among these parameters. Based on these findings, a stuck pipe early-warning indicator system is proposed using frictional load thresholds, with clearly defined safety limits for cuttings bed height. Recommendations for optimizing cuttings transport parameters through coordinated control of fluid velocity, density, and rotary speed are also provided, offering theoretical support and engineering guidance for borehole cleaning strategies and stuck pipe risk prediction in large cuttings scenarios. Full article

To investigate how joint density and drilling diameter impact the failure features of coal specimens, a numerical simulation test was conducted using PFC 2D 5.0 software. The mechanical characteristics, failure characteristics, and energy changes of borehole coal specimens with different joint densities and different drilling diameters were analyzed, and the sensitivity of the two was compared by range analysis. The results show that (1) the increase of joint density significantly reduces the bearing capacity of coal specimens, while the drilling diameter has little effect on the peak stress, but it will significantly change the failure path of coal specimens; (2) Under the condition of low joint density, the specimen is mainly characterized by tensile brittle failure, and the fragments are large. Increasing joint density shifts the specimen’s failure mode towards shear failure and produces smaller fragments; (3) With the increase of drilling diameter, the initiation and propagation of cracks are more likely to occur around the drilling, and the acoustic emission hot spots are more concentrated around the drilling. The increase of joint density leads to more complex crack distribution, and the distribution range of acoustic emission hot spots is expanded and the number is increased; (4) The joint density has a weakening effect on the elastic energy storage of coal specimens, and this weakening effect decreases with the increase of drilling diameter. and drilling affects the way of energy dissipation. Full article

In the drilling process of ultra-deep wells with large-diameter boreholes, the transport and deposition behavior of cuttings plays a critical role in maintaining wellbore cleanliness and ensuring operational safety. Due to the geometry of enlarged boreholes and their complex annular flow characteristics, conventional single-parameter control methods often fail to achieve effective cuttings transport. This study aims to identify the dominant influencing factors and optimize key parameters by focusing on the cuttings volume fraction as a primary evaluation metric. A numerical simulation approach is employed to systematically investigate the influence of stabilizer geometry and hydraulic parameters. Five variables—drilling fluid velocity, drill pipe rotational speed, number of stabilizers, flow area, and helical angle—are selected for analysis. An initial one-factor sensitivity analysis is conducted to evaluate local impacts and to establish relative sensitivity indices, thereby identifying key variables. A variance-based global sensitivity analysis is further applied to quantify first-order effects, full-order effects, and interaction contributions, revealing nonlinear coupling and synergistic mechanisms. The results indicate that drilling fluid velocity and rotation speed exhibit the most significant first-order influences, while stabilizer-related parameters show strong interaction effects that are often underestimated by traditional methods. Based on these findings, an optimized cuttings transport scheme for large-diameter boreholes is proposed. Additionally, a multi-parameter response model for the cuttings volume fraction is developed using sensitivity-weighted analysis, offering theoretical support and methodological reference for enhancing cuttings transport performance and structural design in large-diameter borehole drilling operations. Full article

During the drilling processes of a 10,000-meter-deep well, cutting removal becomes difficult in the 32-inch borehole, which significantly increases downhole risks and affects drilling efficiency. To address this, a numerical simulation method based on the Eulerian two-fluid model was established for cuttings transport simulation in ultra-large boreholes. This method revealed the cuttings transport behavior in the 32-inch borehole of the SDCK1 well, analyzed the actual return velocity and the critical return velocity required for cuttings transport, and examined the cuttings transport characteristics near the bottom stabilizer. The results show that under the maximum flow rate of 160 L/s, the actual return velocity in the annulus is only 0.32 m/s, while the critical return velocity for 10 mm cutting particles is 0.57 m/s. Except for the stabilizer position, the actual return velocity throughout the entire well section is lower than the critical return velocity required for 10 mm cutting particles transport, which is one of the main reasons for the poor cutting removal in the wellbore. Near the bottom stabilizer, the annular flow is altered by the large outer diameter of the stabilizer, causing drilling fluid backflow and resulting in cuttings accumulation. The cuttings backflow and accumulation are more pronounced with the double stabilizer tool combination compared to the triple stabilizer tool combination. The small annular gap near the stabilizers makes it difficult for large cuttings to pass through, leading to blockages. A low annular return velocity and cuttings accumulation near the stabilizer are the primary reasons for poor cuttings removal in the 32-inch borehole. Full article

Hot water drilling is a drilling method that employs high-temperature and high-pressure hot water jetting to achieve ice melting drilling. Characterized by rapid drilling speed and large hole diameter, it is widely used for drilling observation holes in polar ice sheets and ice shelves. Understanding the hole-enlargement process at the bottom of hot water-drilled holes is crucial for rationally designing the structure of hot water drills. However, due to the complexity of heat transfer processes, no suitable theoretical model currently exists to accurately predict this process. To address this, this paper establishes an experimental platform for hot water drilling and conducts 24 sets of experiments under different drilling parameters using visualization techniques. The study reveals the influence mechanisms of drilling speed, hot water flow rate, hot water temperature, downhole drill shape, and nozzle structure on the hole-forming process at the borehole bottom. Experimental results indicate that the primary hole enlargement occurs near the nozzle, achieving 69–81% of the theoretical maximum borehole diameter. The thermal melting efficiency at the borehole bottom is approximately 80%, with about 20% of the input hot water energy heating the surrounding ice. Under identical hot water parameters, jet shapes and drill shapes exhibit minimal impact on borehole geometry. But the improvement of the jet speed and hot water temperature can accelerate the hole-forming process. Full article

The coiled tubing (CT) fracturing technology offers advantages such as pressurized dragging operation and maintaining a large borehole diameter after fracturing. However, during fracturing in the conglomerate and volcanic rock reservoirs of the Junggar Basin, CT stuck during retrieval occurs frequently. In this study, a model simulating the variation in the in situ stress field during CT hydraulic fracturing is established based on elastic mechanics and the displacement discontinuity method (DDM). Based on the geological characteristics of conglomerate and volcanic rock reservoirs in the Junggar Basin, and considering engineering parameters such as fracture length and fracture count in CT hydraulic fracturing, this study investigates the variation in the in situ stress during CT hydraulic fracturing and explores the stuck mechanism of CT. An index for fracturing completion is constructed to evaluate the stuck of CT during the fracturing process. With the goal of full stimulation of the horizontal section, a quantitative optimization design is conducted for the fracturing stage spacing and number of stages under different geological conditions, resulting in corresponding charts. The results indicate that the stuck mechanism during CT fracturing is caused by the continuous accumulation of stress induced by hydraulic fractures, leading to stress inversion. The fracturing completion increases with the stage spacing and the original horizontal stress difference. The length of the fractured section first increases and then decreases with the increase in stage spacing, while it increases with the original horizontal stress difference. The research findings can be applied to the optimization design of stage spacing and number of stages for CT hydraulic fracturing in conglomerate and volcanic rock reservoirs of the Junggar Basin, effectively preventing and controlling stuck coiled tubing in CT fracturing. Full article

This paper describes the characteristics of a thermal response test and presents the results of the test conducted on a borehole at the freezing shaft in Poland. Freezing boreholes are temporary boreholes created to facilitate other geological work, especially for large-diameter mine shafts or other boreholes. Due to their nature, they are abandoned after the necessary work around the mine shaft is completed. The economical point of view suggests that, after their use as freezing boreholes, they should be used for heating if possible. In this paper, the authors aim to suggest that they can be utilized as borehole heat exchangers. Large numbers of freezing boreholes sit idle across the globe while they could be used as a renewable energy source, so creating a new way to obtain heating power in the future should be popularized. The paper includes a description of the implementation method of the thermal response test and the results of the test on a sample freezing borehole intended for abandonment. The test results were interpreted, and the key parameters of the borehole heat exchanger based on the freezing borehole were determined to be satisfactory. The possibilities of other borehole uses are also described. Full article

The article discusses the possibility of analysing, in geomechanical terms, the applicability of the extension strain criterion to assessing the fracture and failure process of sandstone samples. The results of laboratory tests of indirect tension, as well as uniaxial and triaxial compression were used to identify various forms of the criterion. The criterion parameters for fracture initiation and advanced failure processes were presented, and the results in both cases are different. The possible ways of applying this criterion to assess crack initiation in a tension test and failure in a shear test were also presented. Digital image correlation (DIC) analyses were used to determine the deformations of sandstone samples in both test types. The results of these studies show the possibilities to use this condition, e.g., to assess the stability of large-diameter boreholes (for disposal of radioactive waste) and wellbore stability, and to monitor and track the behaviour of tunnels drilled in strong rocks. Full article

Drilling is one of the most commonly used techniques in hydrogeological exploration and is employed to obtain rock samples and create boreholes. During conventional drilling, it is necessary to raise all the drilling tools in the borehole when switching between coring drilling and non-coring drilling, which causes large auxiliary operation time consumption and poor drilling efficiency. Based on the structure of wireline coring tools, a large diameter modular drill bit was designed to switch between coring drilling and non-coring drilling without lifting the whole set of drilling tools. In the COMSOL simulation environment, a simulation model of the modular bit was constructed. Drilling fluid velocity and pressure characteristics flowing through the modular bit were studied. According to the analysis results, with the same input flow rate, similar velocities and lower pressure loss can be obtained in non-coring drilling as with the coring bit, and thus drilling cuttings can be removed effectively even if there are more cuttings produced in non-coring drilling than in coring drilling for a borehole drilled at the same diameter. When the outside diameter of the modular bit is 216 mm, the recommended clearance value is 9 mm or 10 mm in order to obtain lower pressure loss and larger diameter core. To generate low pressure loss and ensure bit strength, a layout with four nozzles on the internal non-coring bit is recommended. The modular bit enables fast switching between coring drilling and non-coring drilling without raising the drilling tools. The simulation model can be used for drilling parameter selection and drill bit optimization. Full article

The DIGIT experiment was launched at the Tournemire Underground Research Laboratory URL with the aim of determining the effects of temperature on the transfer of analogues of most mobile radionuclides (i.e., ³⁶Cl, ¹²⁹I and ⁷⁹Se) in the Toarcian clay rock, the properties of which are close to host rocks being considered for future deep geological disposal of high-level (HL) radioactive wastes. The experimental principle involves the monitoring of an exchange between a test water traced with stable halides and deuterium at constant concentration and the porewater of the Toarcian clay rock submitted to various temperatures. This experiment seeks to partially address questions regarding the potential spread of contaminants during the thermal phase of High Level Waste (HLW) waste packages. Specifically, the in situ experiment aims to evaluate the role of scale effects and thermodiffusion, a process that combines Fick’s law and the Soret effect, in the transfer of radionuclides. This paper presents the first steps of the study, including the scoping calculations, the experimental set-up and the first results obtained during the unheated phase. The study started with the acquisition of the initial parameters, including the rock thermal properties, the concentrations of the four tracers (chloride, bromide, iodide and deuterium) naturally present in the clay porewater and their diffusive transport parameters by using four diffusion exchange techniques (phase 0). A model coupling heat and mass transfers was then developed using Comsol Multiphysics^®, integrating data acquired so far with existing literature data. A test water with a tracer concentration around 1000 times higher than those in the pore water was proposed with a temperature imposed at the test section wall of 70 °C. A large test zone of 50 cm height and 1 m in diameter and installed in a 3 m deep vertical well located in a sound zone at the URL was then proposed. The installation of the experiments required the realization of one shaft and of nine peripheral boreholes for the monitoring of temperature, water pressure and deformation. The experiment started with phase 1, involving a traced, unheated water start-up for a period of 5 months. Then, a core sampling was conducted in the emptied well, and the same diffusion exchange techniques were applied. The results of anionic tracers were compared to simulations based on initial parameters (phase 0), revealing that tracer penetration at the end of phase 1 exceeded simulated values by approximately 2 cm. This result is interpreted as an increase in the accessible porosity to tracers, possibly due to the excavation damaged zone. Future simulations should incorporate these adjusted diffusive transport parameters. Following phase 1, the heating system was activated, applying a temperature of 70 °C to the test zone. New data will enable the comparison of tracer penetration and assess the actual impact of temperature on tracer transfer. Full article

In this paper, a comprehensive analysis of the combined effect of major influencing parameters on heat transfer in a single U-tube BHE (sBHE) and a double U-tube BHE (dBHE) with two independent circuits was performed by using a validated numerical heat transfer model. Geometrical parameters, such as shank spacing (with maximum, average, and minimum values), borehole diameter (large, medium, and small borehole sizes), and borehole depth (shallow, average, and deep borehole depths) as well as the thermal conductivity of soil and grout, which ranges from minimum to high values, were considered. The combined impact of these parameters was included under the following four major cases: (1) the combined effect of borehole depth, borehole size, and shank spacing; (2) the combined effect of borehole depth and soil and grout thermal conductivity; (3) the combined effect of soil and grout thermal conductivity and borehole size; and (4) the combined effect of soil thermal conductivity, borehole size, and shank spacing. Each of these major cases has nine different design options for both sBHEs and dBHEs. A series of results of heat transfer per unit borehole depth were generated for all the considered various cases. With the given parameters, the BHE case that provides the highest heat transfer among the various cases of sBHEs and dBHEs were obtained. Full article

Based on the ‘three highs and one low’ geological conditions of high gas pressure, high gas content, high ground stress, and low permeability in deep coal seams, this study proposes a dual method of hydraulic fracturing of key layers of overlying rock layers combined with pre-extraction of gas via large-diameter caving boreholes. The aim is to unload and dissipate the coal seam by fracturing the overlying key strata, allowing the stress and energy from the excavation working face to be transmitted and transferred to the deep coal seam. Additionally, large-diameter drilling effectively increases the effective drainage radius of the coal seam, resulting in a shorter extraction time. To validate this approach, a fracturing model and a gas extraction model were established for the key layers of the overlying rock layer using the engineering background of the 15,111 excavation working face of a mine in Shanxi. FLAC3D software v.6.0 was utilized to simulate the stress and energy changes of the coal seam before and after fracturing of the key layers, while COMSOL software v.6.0 was used to analyze the gas migration conditions, permeability, and effective drainage radius changes before and after drilling and caving drilling. The findings, combined with the engineering test results, conclude that key strata fracturing combined with large-diameter caving can effectively increase the permeability of coal seams and improve gas extraction. This study serves as a theoretical basis for guiding the design of gas drainage technology under the effects of coal seam pressure relief and permeability enhancement. Full article

Increasing the diameter of the drillhole can facilitate drillhole breakage using soundless chemical demolition agents, but it is prone to cause drillhole blowout, resulting in crushing failure. This paper conducted a blowhole prevention test on a large borehole using the internal insertion cooling pipe method (ICBPM) to test the expansion pressure of cooling pipes with different diameters. During this test, a fracture occurred in a hole with a 75 mm inner diameter in the rectangular sandstone specimens with high strength. It was found that utilizing the ICBPM can effectively hinder the development of blowholes. Expansion and blowhole prevention are optimized with a 0.14 mass ratio of the cooling water to demolition agent and a maximum expansion stress of 49.0 MPa. The guiding effect of the minimum resistance line is significant. In repeated tests, all fissures are distributed in a Y-shape on the free surface where the minimum resistance line is located. The acoustic emission signals from statically fractured hard rock increase abruptly before damage, and the development of rock expansion and fracturing can be obtained through strain monitoring. These results suggest that the ICBPM can reduce the expansion time with a strong crushing effect, satisfying the need to process more crushing projects. Full article

The nanoscale pores in shale oil and gas are often filled with external nanomaterials to enhance wellbore stability and improve energy production. And there has been considerable research on discrete element blocking models and simulations related to nanoparticles. In this paper, the pressure transmission experimental platform is used to systematically study the influence law of different water activity salt solutions on shale permeability and borehole stability. In addition, the force model of the particles in the pore space is reconstructed to study the blocking law of the particle parameters and fluid physical properties on the shale pore space based on the discrete element hydrodynamic model. However, the migration and sealing patterns of nanomaterials in shale pores are unknown, as are the effects of changes in particle parameters on nanoscale sealing. The results show that: (1) The salt solution adopts a formate system, and the salt solution is most capable of blocking the pressure transmission in the shale pores when the water activity is 0.092. The drilling fluid does not easily penetrate into the shale pore space, and it is more capable of maintaining the stability of the shale wellbore. (2) For the physical blocking numerical simulation, the nanoparticle concentration is the most critical factor affecting the shale pore blocking efficiency. Particle size has a large impact on the blocking efficiency of shale pores. The particle diameter increases by 30% and the pore-blocking efficiency increases by 13% when the maximum particle size is smaller than the pore exit. (3) Particle density has a small effect on the final sealing effect of pore space. The pore-plugging efficiency is only increased by 4% as the particle density is increased by 60%. (4) Fluid viscosity has a significant effect on shale pore plugging. The increase in viscosity at a nanoparticle concentration of 1 wt% significantly improves the sealing effectiveness, specifically, the sealing efficiency of the 5 mPa-s nanoparticle solution is 16% higher than that of the 1 mPa-s nanoparticle solution. Finally, we present a technical basis for the selection of a water-based drilling fluid system for long horizontal shale gas drilling. Full article

In order to solve the support problem of deep soft crushed coal roadway, a concentrated cavern in a mining station of a mine is taken as the test object. Based on the analysis and summary of the field observation data and the law of rock pressure appearance, a new technology of pressure relief anchoring with the main body of “initiative support + borehole pressure relief” is proposed. This new technology will carry out strong active support in the shallow part of the surrounding rock and excavate a row of low-density large-diameter pressure relief boreholes in the deep coal body of the roadway ribs. The numerical analysis model is established by FLAC^3D, and the second invariant of deviatoric stress (J₂) is used as the analysis index to elaborate the influence of different borehole parameters on the pressure relief effect of roadway surrounding rock. The results show that different borehole parameters have different effects on roadway pressure relief, that is, borehole depth > borehole length > borehole spacing. After the borehole process is used to relieve the pressure of the surrounding rock, the deformation of the mining roadway side in the subsequent observation process is always controlled within the range of 100 mm, and the shallow surrounding rock support system is effectively protected. The comprehensive control effect is very obvious. Therefore, the field practice proves that the supporting technology can effectively solve the problem of large deformation support of similar roadway surrounding rock. Full article
