This study introduces an automated computational tool to evaluate the phase velocity of the highly dispersive A₀ mode using only two signals measured along the wave propagation path. The algorithm combines the zero-crossing technique with automated spectral decomposition, utilizing a bank of bandpass filters with adaptive bandwidths. Validated through theoretical and experimental analysis of an aluminium plate near 300 kHz, the results demonstrate that using a two-signal set and variable filter widths significantly improves accuracy and extends the measurable frequency range of the dispersion curve. Experimental results demonstrate that by applying various filter widths, the phase velocity dispersion curve segment can be reconstructed over a frequency range exceeding 65% of the signal’s spectral width at the −40 dB level. The reconstruction yielded an average relative error of 0.8% ± 1.2%, while the best-case scenario showed an error of just 0.3% ± 0.4%. Implementing automated filter parameter selection on a signal pair offers a time-efficient alternative to traditional spatial scanning, significantly simplifying data collection while reducing labour and time requirements. Full article

Structural health monitoring (SHM) technology enables the monitoring and assessment of the condition of various materials and structures. Lamb-guided waves (LW) are widely used to detect damage in large-scale plate structures. One of the parameters used for these purposes is the time-of-flight (ToF) of ultrasonic LW signals. In the presented feasibility study, the ToF was determined based on the idea that the zero-crossings of this signal, filtered by several filters, are concentrated around the maximum of the signal envelope. This ToF detection method, unlike threshold- and peak-based methods, avoids uncertainties in signal and noise levels and does not require a signal detection threshold. Compared to the correlation method, no reference signal is required. It has been established that the curves of signal propagation times with varying distance depend on the group and phase velocities of signal propagation and have phase jumps. The proposed methodology for assessing plate inhomogeneities involves comparing signal propagation time curves with and without damage. This methodology has been verified both through theoretical modeling and experimental research. The experimental studies used a 6 mm thick steel specimen with artificial defects of various diameters (10–35 mm). The A₀ mode of Lamb waves with a central frequency of 150 kHz was excited in the steel plate. For experimentally obtained B-scans, the ToF distributions of signals along the scan trajectories were calculated. By comparing the defective and defect-free ToF curves, critical points of the experimental curves were determined, which were used to estimate the dimensions of the defects. Both in the case of theoretical modeling and in the result of experimental measurements, it was determined that the proposed methodology can be used to determine the inhomogeneities of plates. Full article

Acoustic emission testing is a non-destructive inspection method in which ultrasonic waves emitted by defects in an object are detected and assessed based on their time of arrival and waveform, which strongly depends on the geometry of the object. Those waves appear in different modes with their own velocity and dispersion and different degrees of attenuation can occur for different wave modes. In previous work, a new method for (semi-)automatic recognition of the arrival time of wave modes was presented and validated on a dataset obtained in laboratory conditions on a flat plate. This paper builds upon the previous research and presents a modified method that can be applied to data obtained from an industrial gas storage sphere. The following two wave modes were commonly detected for this sphere: one similar to the zero-order anti-symmetrical mode (A₀) and the other similar to the zero-order symmetrical Lamb mode (S₀) in a plate. The method was adapted to solve the new challenges that were encountered for the sphere. The performance of the adapted automatic mode recognition method was assessed using a dataset with the following four different source types: Hsu–Nielsen sources, sensor pulses, impact by a metallic object and natural sources. The resulting wave mode recognition was compared to manual recognition to determine the rates of successful recognition. The resulting successful recognition rates range from 97% for A₀ and S₀ for Hsu–Nielsen sources down to 73% for A₀ in signals due to natural sources and 74% for A₀ in signals due to impact by a metallic object. Full article

We report on the non-contact characterization of various plate materials (including aluminum and steel) using a high-pressure, micrometer-scale air jet as a broadband ultrasound source and an optomechanical microphone as a receiver. Through-plate transmission spectra are dominated by zero-group-velocity (ZGV) Lamb modes. We attribute this to the ‘point-like’ nature of both the source and receiver, since ZGV modes are spatially localized and comprise a range of non-normal wave numbers. As is well known, the properties of the ZGV modes, including their frequency and amplitude, are sensitive to thickness variations or the presence of defects. The continuous nature and high acoustic power of the gas jet source enabled us to perform uninterrupted scanning of non-uniform steel plates. Given the ubiquitous and low-cost nature of compressed air systems, our approach might be of interest for the rapid inspection of industrial parts. Full article

The ultrasonic guided wave method is successfully used for structural health monitoring (SHM) of aircraft structures utilizing PZT (Pb-Zr-Ti based piezoceramic material) sensors for guided wave generation and detection. To increase the mechanical durability of the sensors in operational conditions, this paper demonstrates the feasibility of the integration of PZTs into the Glass fiber/Polymethyl methacrylate (G/PMMA) composite plate and evaluates the possibility of impact damage detection using generated guided waves. Two types of PZT sensors were embedded into different layers during the manufacturing process. Generally, radial mode disc sensors are used for Lamb wave generation, and thickness-shear square-shaped sensors are used for both Lamb and shear wave generation. First, the wave propagation was analyzed considering the sensor type and sensor placement within the layup. The main objective was to propose the optimal sensor network with embedded sensors for successful impact damage detection. Lamb wave frequency tuning of disk sensors and unique vibrational characteristics of integrated shear sensors were exploited to selectively actuate only one guided wave mode. Finally, the Reconstruction Algorithm for the Probabilistic Inspection of Damage (RAPID) was utilized for damage localization and visualization. Full article

This paper experimentally investigates the resonant behavior of the one-way Lamb and SH (shear horizontal) mixing method in composite laminates with inherent quadratic nonlinearity, delamination damage and impact damage. When the fundamental S₀-mode Lamb waves and SH₀ waves mix in the damage regions of composite laminates, experimental results demonstrate the generation of the resonant SH₀ waves with the resonance condition. Meanwhile, the damage localization method in composite laminates is experimentally verified by the time-domain signal of resonant waves. Furthermore, it is found that the one-way Lamb and SH mixing method is sensitive to inherent quadratic nonlinearity and impact damage but insensitive to delamination damage. Full article

In radiofrequency filters, there is an increasing demand for high-frequency, wide-bandwidth operation. Recently, laterally excited A₁-mode Lamb wave resonators (XBARs) have attracted significant attention; however, freestanding structures are mechanically fragile, limiting their practical implementation. To address this challenge, a novel bonded membrane structure consisting of a lithium niobate (LiNbO₃; LN) thin plate supported by a silicon carbide (SiC) layer is proposed to realize high-frequency, high-performance, and thermally robust acoustic resonators. Finite element simulations were performed to analyze the excitation and propagation of A₁-mode Lamb waves in the LN/SiC membrane, clarifying the distinct behavior compared with XBARs. The influence of the bonded SiC thin layer on A₁-mode Lamb waves was systematically evaluated in terms of coupling coefficient and phase velocity, and design guidelines were established based on these insights. A fabricated LN/SiC resonator with an interdigital electrode pitch of 12 µm exhibited a clear A₁-mode response near 1.2 GHz, showing an effective electromechanical coupling coefficient of 24% and a phase velocity exceeding 14,000 m/s. These results demonstrate the feasibility of the bonded LN/SiC membrane as a promising platform for high electromechanical coupling, high-speed, and thermally stable acoustic devices. Full article

Comprehensive studies of Famille rose porcelains, particularly ruby-back pieces, are rare and have generally not addressed the vibrational signatures arising from gold nanoparticles. Due to the high cultural and material value of these artifacts, a strictly non-invasive approach combining X-ray fluorescence (XRF) and Raman (micro-)spectrometry must be employed. If the conservation of porcelain does not pose any difficulties, fakes exist and they must be identified. Preliminary studies show that the presence of metal nanoparticles generates plasmon-related fluorescence. Our results confirm that plasmon fluorescence is more effective than pXRF for detecting colloidal gold, whereas pXRF efficiently identifies associated elements such as arsenic, tin, and, newly observed, antimony; the presence of iron is difficult to demonstrate due to its ubiquitous occurrence. Yellow and green hues, distinct from those produced by Cu²⁺ ions alone, are mainly due to simple tin yellow (PbSnO₃), while the cobalt used originates from a mixture of European smalt (rich in arsenic and potassium) and Asian ores (rich in manganese). Minimal variability was observed among egg-shell porcelains with similar decorations and dimensions, suggesting a common workshop or standardized raw materials and procedures. Two other egg-shell plates employ a different gold preparation technique (addition of Sn and Sb rather than As), which is visually evident in the ruby color. Full article

Heat spots caused by standing waves in an inspected object can pose practical challenges in nondestructive inspection using ultrasonic excitation thermography. This study investigates the dominant wave mode excited during inspection and explores methods to suppress heat generation caused by standing waves. Comparison of experimental results and theoretical calculations showed that the waves propagating in plate objects were dominated by the A₀ mode Lamb waves. As a result, the distribution of the heat spots caused by standing waves varied depending on the frequency of the excitation wave and plate thickness. Based on these findings, we propose a suppression method that eliminates unwanted heat spots by superimposing two Lamb waves with a phase difference that is a natural multiple of half the wavelength. Full article

This study aims to evaluate the effectiveness of five analytical and semi-analytical methods for estimating Lamb wave dispersion in viscoelastic plates—the Rayleigh–Lamb solution, the Global Matrix Method (GMM), the Semi-Analytical Finite Element (SAFE) method, the Scaled Boundary Finite Element Method (SBFEM), and the Legendre Polynomial Method (LPM). The Rayleigh–Lamb equations are solved using an optimized Newton–Raphson algorithm, enhancing computational efficiency while maintaining comparable accuracy. The SAFE method exhibited a remarkable balance between computational efficiency and physical accuracy, outperforming SBFEM at high frequencies. For epoxy and high-performance polyethylene (HPPE) plates, the SAFE method and the LPM significantly outperform the GMM in relation to computational efficiency, with errors below $1\%$ for fundamental symmetric and antisymmetric modes across the tested frequency range of 0 to 100 kHz. In addition, the ability of the SAFE method to accurately predict both phase velocity and attenuation in viscous media supports their use in guided-wave-based structural health monitoring applications. Among the investigated approaches, the SAFE method emerges as the most robust and accurate for viscoelastic plates, while the SBFEM and LPM show limitations at higher frequencies. This study provides a quantitative and methodological foundation for selecting and implementing numerical methods for guided wave analysis, emphasizing the dual necessity of physical fidelity and numerical stability. Full article

Ultrasonic guided wave interdigital transducers realized with piezoelectric materials are of interest for structural health monitoring systems because of their capability of performing Lamb wave mode selection with respect to single-element transducers. Besides this advantage, the coverage of large areas with a minimum number of elements is an important challenge and the problem of efficient excitation with integrated electronics must be solved. This work proposes an electrical matching network topology made of L and C passive components that can be designed for the trade-off between electrical to mechanical conversion efficiency and bandwidth. The network circuit is analyzed considering the equivalent transducer impedance and the output impedance of the driving electronics. The design rules derived by the transfer function analysis are described and a case study for a piezopolymer IDT is presented. Finally, with the implementation of the integrated matching network with the connector of the IDT, the effect of cable capacitance is minimized. In conclusion this article is a contribution to the study of using IDT efficiently and in a versatile mode for different electronic front-ends that usually operate at low power supply voltage. Full article

Stabilization of the resonance frequency in thin-film acoustic devices to variations in environmental conditions is commonly reduced to the passive or active compensation of a single factor (usually temperature) and the isolation or addition of a separate correction circuit for every other factor (e.g., pressure and mass loading). In this work, the possibility of dual-factor compensation is proposed, where the response of a multi-layered thin structure to both temperature and ambient pressure variation vanishes due to the choice of intrinsic parameters (materials and thickness ratios). The response functions are derived for the $S_0$ Lamb mode at long wavelengths in an explicit analytical form in terms of bulk material characteristics. It is demonstrated that the dual-factor intrinsic stabilization requires at least a three-layered structure and can be achieved for materials commonly used in temperature-compensated devices (aluminum nitride, fused silica, and aluminum). Identification of the key material characteristics governing the existence of a stability solution can serve for a targeted search of such composites and implementation of new thin-film dual devices. Full article

Modern aerospace engineering places increasing emphasis on materials that combine low weight with high mechanical performance. Fiber metal laminates (FMLs), which merge metal layers with fiber-reinforced composites, meet this demand by delivering improved fatigue resistance, impact tolerance, and environmental durability, often surpassing the performance of their constituents in demanding applications. Despite these advantages, inspecting such thin, layered structures remains a significant challenge, particularly when they are difficult or impossible to access. As with any new invention, they always come with challenges. This study examines the effectiveness of the fundamental anti-symmetric Lamb wave mode (A0) in detecting weak interfacial defects within Carall laminates, a type of hybrid fiber metal laminate (FML). Delamination detectability is analyzed in terms of strong wave dispersion observed downstream of the delaminated sublayer, within a region characterized by acoustic distortion. A three-dimensional finite element (FE) model is developed to simulate mode trapping and full-wavefield local displacement. The approach is validated by reproducing experimental results reported in prior studies, including the author’s own work. Results demonstrate that the A0 mode is sensitive to delamination; however, its lateral resolution depends on local position, ply orientation, and dispersion characteristics. Accurately resolving the depth and extent of delamination remains challenging due to the redistribution of peak amplitude in the frequency domain, likely caused by interference effects in the acoustically sensitive delaminated zone. Additionally, angular scattering analysis reveals a complex wave behavior, with most of the energy concentrated along the centerline, despite transmission losses at the metal-composite interfaces in the Carall laminate. The wave interaction with the leading and trailing edges of the delaminations is strongly influenced by the complex wave interference phenomenon and acoustic mismatched regions, leading to an increase in dispersion at the sublayers. Analytical dispersion calculations clarify how wave behavior influences the detectability and resolution of delaminations, though this resolution is constrained, being most effective for weak interfaces located closer to the surface. This study offers critical insights into how the fundamental anti-symmetric Lamb wave mode (A0) interacts with delaminations in highly attenuative, multilayered environments. It also highlights the challenges in resolving the spatial extent of damage in the long-wavelength limit. The findings support the practical application of A0 Lamb waves for structural health assessment of hybrid composites, enabling defect detection at inaccessible depths. Full article

Acoustic coupling agents serve as critical interfacial materials connecting piezoelectric transducers with microfluidic chips in acoustofluidic systems. Their performance directly impacts acoustic wave transmission efficiency, device reusability, and reliability in biomedical applications. Considering the rapidly growing body of research in the field of acoustic microfluidics, this review aims to serve as an all-in-one reference on the role of acoustic coupling agents and relevant considerations pertinent to acoustofluidic devices for anyone working in or seeking to enter the field of disposable acoustofluidic devices. To this end, this review seeks to summarize and categorize key aspects of acoustic couplants in the implementation of acoustofluidic devices by examining their underlying physical mechanisms, material classifications, and core applications of coupling agents in acoustofluidics. Gel-based coupling agents are particularly favored for their long-term stability, high coupling efficiency, and ease of preparation, making them integral to acoustic flow control applications. In practice, coupling agents facilitate microparticle trapping, droplet manipulation, and biosample sorting through acoustic impedance matching and wave mode conversion (e.g., Rayleigh-to-Lamb waves). Their thickness and acoustic properties (sound velocity, attenuation coefficient) further modulate sound field distribution to optimize acoustic radiation forces and thermal effects. However, challenges remain regarding stability (evaporation, thermal degradation) and chip compatibility. Further aspects of research into gel-based agents requiring attention include multilayer coupled designs, dynamic thickness control, and enhancing biocompatibility to advance acoustofluidic technologies in point-of-care diagnostics and high-throughput analysis. Full article

Bulk Acoustic Wave (BAW) resonators are essential components in modern RF communication systems due to their high selectivity and quality factor. However, spurious resonances caused by Lamb wave mode propagation along the in-plane directions degrade the filter performance. Traditional Finite Element Method (FEM) simulations provide accurate modeling but are computationally expensive, especially for arbitrarily shaped resonators and solidly mounted resonators (SMRs), whose stack of materials is composed of many thin layers of different materials. To address this, we extend a previously published model (named the Quasi-3D model), which employs the Transmission Line Matrix (TLM) method, enabling efficient simulations of complex geometries with more precise meshing. The new approach allows us to simulate different geometries, and we will show several apodized geometries with the aim of minimizing the lateral modes. In addition, the proposed approach significantly reduces the computational cost while maintaining high accuracy, as validated by FEM comparisons and experimental measurements. Full article
