This paper introduces a high-conversion ratio multiphase nonisolated converter built from generic LC cells. The unique architecture that hinges on a generic capacitor inductor switching module enables the high modularity of the topology, providing a quick extension of the converter design in an interleaved configuration for lower ripple and higher current output. The generic module comprises the basic power components of a nonisolated DC–DC converter, where the unique interaction between the capacitor and the inductor results in a soft charging operation, which curbs the losses of the converter, and contributes to a higher efficiency. Additional features of the new converter include a significantly extended effective duty ratio, and a lower voltage stress on the switches, a very high output current, and architecture-inherent output current sharing that balances the loading between the phases. In addition, a power extension using a paralleling and interleaving approach is presented to provide higher output current capabilities. Simulation and experimental results of a modular interleaved three-phase prototype demonstrate an excellent proof of concept and agree well with the theoretical analyzes developed in this study. Full article

While DC/DC converters for water electrolysis systems have been widely investigated, they inherently face a critical compromise between wide voltage regulation capabilities and dynamic response characteristics. This study is based on a two-stage hybrid topology (TSIB-TPLLC) that synergistically combines a two-phase interleaved buck converter with a three-phase LLC resonant converter to resolve this challenge. The first-stage interleaved buck converter enables wide-range voltage regulation while reducing input current ripple and minimizing intermediate bus capacitance through phase-interleaved operation. The subsequent three-phase LLC stage operates at a fixed resonant frequency, achieving inherent output current ripple suppression through multi-phase cancellation while maintaining high conversion efficiency. A dual-loop control architecture incorporating linear active disturbance rejection control (LADRC) with PI compensation is developed to improve transient response compared to conventional PI-based methods. Finally, a 1.2 kW experimental prototype with an input voltage of 250 V and an output voltage of 24 V demonstrates the converter’s operational feasibility and enhanced steady-state/transient performance, confirming its suitability for hydrogen production applications. Full article

This article proposes a high-efficiency isolated three-port resonant converter for DC microgrids, combining a dual active bridge (DAB)–LLC topology with hybrid Pulse Width Modulat-Pulse Frequency Modulation (PWM-PFM) phase shift control. Specifically, the integration of a dual active bridge and LLC resonant structure with interleaved buck/boost stages eliminates cascaded conversion losses. Energy flows bidirectionally between ports via zero-voltage switching, achieving a 97.2% efficiency across 150–300 V input ranges, which is a 15% improvement over conventional cascaded designs. Also, an improved PWM-PFM shift control scheme dynamically allocates power between ports without altering switching frequency. By decoupling power regulation and leveraging resonant tank optimization, this strategy reduces control complexity while maintaining a ±2.5% voltage ripple under 20% load transients. Additionally, a switch-controlled capacitor network and frequency tuning enable resonant parameter adjustment, achieving a 1:2 voltage gain range without auxiliary circuits. It reduces cost penalties compared to dual-transformer solutions, making the topology viable for heterogeneous DC microgrids. Based on a detailed theoretical analysis, simulation and experimental results verify the effectiveness of the proposed concept. Full article

Electromagnetic interference (EMI) remains a difficult task in the design and operation of contemporary power electronic systems, especially in those applications where signal quality has a direct impact on the overall performance and efficiency. Conventional control schemes that have evolved to counteract the effects of EMI generally tend to have greater design complexity, greater error rates, poor control accuracy, and large amounts of harmonic distortion. In order to overcome these constraints, this paper introduces an intelligent and advanced control approach founded on the signal randomization principle. The suggested approach controls the switching activity of a DC–DC converter by dynamically tuned parameters like duty cycle, switching frequency, and signal modulation. A boost interleaved topology is utilized to maximize the current distribution and minimize ripple, and an innovative space vector-dithered sigma delta modulation (SV-DiSDM) scheme is proposed for cancelling harmonics via a digitalized control action. The used modulation scheme can effectively distribute the harmonic energy across a larger range of frequencies to largely eliminate EMI and boost the stability of the system. High-performance analysis is conducted by employing significant measures like total harmonic distortion (THD), switching frequency deviation, switching loss, and distortion product. Verification against conventional control models confirms the increased efficiency, less EMI, and greater signal integrity of the proposed method, and hence, it can be a viable alternative for EMI-aware power electronics applications. Full article

This article presents an efficient non-isolated DC-DC hybrid converter for direct large-ratio step-down applications such as data centers. The converter topology employs a three-level-assisted Dickson switched capacitor network and interleaved dual inductors, significantly mitigating voltage swings at the switching nodes. As a result, the conduction duration of rectifying switches is substantially extended. This configuration is suitable for both odd- and even-order converters, achieving self-balancing of the flying capacitor voltages and inductor currents. To address uneven interleaved inductor currents, a duty-cycle-matching-based current distribution method is proposed to ensure equal current sharing and facilitate loss transfer between inductors. Additionally, an intrinsic charge-ratio-based method for capacitance optimization is introduced to achieve quasi-complete soft charging of the flying capacitors. This method eliminates surge currents during reconfiguration of the capacitor network, reduces losses, and enhances the capacitor utilization. Operating at 300 kHz, the prototype achieves high-ratio voltage conversion from 48 V to 0.5–2.0 V, with a maximum output current of 30 A. It attains a peak efficiency of 91.96% and a power density of 944.88 W/in³. Quasi-complete soft charging of the flying capacitors results in an approximate 2.94% improvement in the conversion efficiency. Full article

Electric Vehicles (EV) significantly contribute to reducing carbon emissions and promoting sustainable transportation. Among EV technologies, hybrid energy storage systems (HESS), which combine fuel cells, power batteries, and supercapacitors, have been widely adopted to enhance energy density, power density, and system efficiency. Bidirectional DC-DC converters are pivotal in HESS, enabling efficient energy management, voltage matching, and bidirectional energy flow between storage devices and vehicle systems. This paper provides a comprehensive review of bidirectional DC-DC converter topologies for EV applications, which focuses on both non-isolated and isolated designs. Non-isolated topologies, such as Buck-Boost, Ćuk, and interleaved converters, are featured for their simplicity, efficiency, and compactness. Isolated topologies, such as dual active bridge (DAB) and push-pull converters, are featured for their high voltage gain and electrical isolation. An evaluation framework is proposed, incorporating key performance metrics such as voltage stress, current stress, power density, and switching frequency. The results highlight the strengths and limitations of various converter topologies, offering insights into their optimization for EV applications. Future research directions include integrating wide-bandgap devices, advanced control strategies, and novel topologies to address challenges such as wide voltage gain, high efficiency, and compact design. This work underscores the critical role of bidirectional DC-DC converters in advancing energy-efficient and sustainable EV technologies. Full article

With the growth of renewable energy, electrified highways can efficiently utilize green energy such as solar and wind for EVs, promoting sustainable transportation and carbon reduction, and accelerating the transition to a greener future. For high-power DC/DC converters in electrified roadways, a lightweight and compact design is crucial, but inductors limit progress. Therefore, this study focuses on the magnetic integration of DC/DC chopping inductors. It first selected and optimized the decoupled magnetic integration form, initial electromagnetic parameters, and core sizes based on circuit topology and device specifications, using core loss and thermal rise models. Then, it determined the optimal winding turns ratio according to the air gap and magnetic resistance ratio, obtaining the final design with insulation considered. The design was verified through finite-element simulation, prototype manufacturing, and testing, and an improved optimization with interleaved parallel control was proposed. Results indicate that magnetic integration reduces the inductor’s volume by 7.93% and footprint by 38.62%, facilitating the lightweight and compact design of relevant magnetic components. With interleaved parallel control, the integrated inductor’s volume can be reduced by 19.74%, significantly decreasing the volume and mass of the chopping inductor. Full article

Metasurface-based longitudinal modulation introduces the propagation distance as a new degree of freedom, extending the light modulation with metasurfaces from 2D to 3D space. However, relevant longitudinal studies have been constrained to designing the metasurface of half-wave plate (HWP) meta-atoms and generating either non-focused or two-channel vortex and vector beams. In this study, we propose a metasurface composed of quarter-wave plate (QWP) meta-atoms to generate the longitudinal multi-channel focused vortex and vector beams. The metasurface consists of two interleaved sub-metasurfaces of QWP meta-atoms. For each sub-metasurface, the helical and hyperbolic phase profiles are designed independently in the propagation and geometric phases to generate focused co- and cross-polarized vortices with corresponding topological charges. Under the illumination of x-linearly polarized light, the metasurface generates two circularly polarized vortices, two linearly polarized vortices, and one vector beam on five focal planes. Theoretical analysis and simulation results demonstrate the feasibility of the proposed QWP metasurface. Our study presents a significant advancement in the development of integrated and multifunctional optical devices and systems, with significant potential applications in light–matter interaction, laser processing, and optical communication. Full article

This study aims to conduct an assessment of the dynamic characteristics of a proposed 6.6 kW bidirectional bridgeless three-leg interleaved totem-pole power factor correction (PFC) boost converter developed for the front-end stage of electric vehicle onboard charger applications during load cycles. This proposed PFC boost converter integrates the self-developed silicon carbide (SiC) power MOSFET modules for achieving high efficiency and high power density. To assess the switching transient behavior, power loss, and efficiency of the SiC MOSFET power modules, a fully integrated electromagnetic-circuit coupled simulation (ECCS) model that incorporates an electromagnetic model, an equivalent circuit model, and an SiC MOSFET characterization model are used. In this simulation model, the impact of parasitic effects on the system’s performance is considered. The accuracy of the ECCS model is confirmed through comparing the calculated results with the experimental data obtained through the double pulse test and the closed-loop converter operation. Furthermore, a comparative study between the interleaved and non-interleaved topologies is also performed in terms of power loss and efficiency. Additionally, the performance of the SiC MOSFET-based PFC boost converter is further compared with that of the silicon (Si) insulated gate bipolar transistor (IGBT)-based one. Finally, a parametric analysis is carried out to explore the impact of several operating conditions on the power loss of the proposed totem-pole PFC boost converter. Full article

To enhance equalization efficiency and address the issue of traditional equalization methods overlooking temperature factors, this paper proposes a multilayer equalization circuit for both intra-group and inter-group balancing. The traditional Buck-Boost equalization topology between groups is improved by incorporating a two-way interleaved inductor structure, which helps reduce equalization idle time. An adaptive fuzzy control equalization strategy for multiple objectives is applied to the topology. The state of charge (SOC) and temperature of the battery are used as key variables for equalization, with the equalization current dynamically adjusted based on changes in the SOC and temperature. This approach improves the balance between equalization speed and temperature control, reducing equalization time while limiting battery temperature rise. A simulation model is developed using MATLAB/Simulink. The simulation results demonstrate that, compared to the traditional Buck-Boost equalization topology, the proposed topology reduces equalization time by 15.1%. Additionally, under three different operating conditions, the equalization cotnrol strategy designed in this paper improves time efficiency by over 14% compared to traditional methods, while also reducing both the maximum temperature and temperature difference. Full article

This paper proposes a modified bidirectional isolated DC/DC converter with hybrid control, which can be applied to bidirectional power transfer between energy storage systems and DC microgrids. Batteries are usually applied to energy storage systems. The battery lifespan may be shortened if the converter has large current ripple during the battery charging process. The proposed topology consists of a CLLC converter and an interleaved buck converter. The first stage is an isolated full bridge CLLC converter, and the second stage is an interleaved buck converter with hybrid control of pulse width modulation (PWM) and pulse frequency modulation (PFM). Additionally, the proposed topology achieves zero voltage switching (ZVS) for all switches and reduces the output current ripple. The operational principles of bidirectional power flow in both directions are described in detail. Finally, a 1.5 kW experimental prototype, rated with a high side voltage of 380 V and low side voltage range of 40–58 V, was constructed and tested to investigate the system performance. The measured highest efficiency for the proposed converter is 90% in charging mode, and 94% in discharging mode. Full article

Synchronized variable frequency soft-switching is analyzed and implemented in a 3-phase bidirectional grid-tied inverter. The common-mode connected topology and control allow for independent analysis of a single phase leg before six are combined into two interleaved, 3-phase inverters. Effective operation is enabled by discretizing the variable switching frequencies before synchronizing them with a control signal. The resulting inverter can operate at any power factor at power levels up to 50 kVA while maintaining zero-voltage switching (ZVS) throughout the grid cycle. Formal conditions for soft-switching and methods for achieving ZVS while maintaining global synchronization are presented. These conditions are then verified in a simulation. Finally, results for different power factors with and without interleaving are demonstrated in a prototype that achieves >98.1% efficiency when converting all real power. Full article

With the continuous improvement of battery energy density and converter power density, as well as the miniaturization and lightweighting of related airborne electrical equipment, all-electric aircraft with hybrid power supply systems provide more trade-off space and possibilities for the design of future aircraft. It is indispensable to search for a more valuable topology and apply it to airborne power supply. This paper proposes an airborne high-gain unidirectional DC-DC converter suitable for between low-voltage unit and high-voltage bus, which consists of interleaved magnetic integrated switched coupled inductor units and improved switch capacitor units. This paper first analyzes the steady-state operating characteristics under different modes; the new topology has higher voltage gain and lower stress. Secondly, in response to the challenges of high efficiency and high power density, we propose a magnetic integration design method and comprehensive experimental scheme based on the EIE-type magnetic core structure. This successfully integrates multiple discrete inductors into a single magnetic core. Furthermore, based on the comprehensive consideration of steady-state, transient performance and power density, the general design criteria for a high-gain switched coupled inductor are summarized through the equivalent mathematical model of reverse flux coupling. Additionally, by adjusting the coupling coefficient, the converter can achieve zero-voltage switching under light load conditions, demonstrating versatility and scalability and better meeting the application requirements of electric aircraft. The proposed prototype can provide voltage gain in the range of 12–22 times the input voltage gain by varying the input voltage from a 12–24 V fuel cell. The comprehensive performance of the converter, including steady-state, transient, and efficiency, was tested under D < 0.5 and D > 0.5. The experimental results show that the proposed converter possesses advantages such as high gain and low stress, a high dynamic response and low ripple, and high efficiency and high power density, which can provide a more advantageous DC-DC converter solution for airborne hybrid power supply systems. Full article

Planar magnetic components have been widely used in high-density power converters and are suitable for various topologies. The application of planar inductors in LLC resonant converters can lead to parasitic capacitance, which causes current ringing and results in EMI issues. To mitigate the impact of current ringing, the parasitic capacitance of the planar inductor needs to be reduced. This paper proposes a new six-turn interleaved winding design. Compared to the previous four-turn interleaved winding design, it maintains low parasitic capacitance while positioning both the input and output terminals of the inductor on the outer turn, further enhancing the integration of high-density power converters. The parasitic capacitance was calculated using theoretical methods and verified through finite element simulations. Experimental validation was conducted using an LLC resonant converter test platform. Compared to the previous four-turn interleaved winding design, the new six-turn interleaved winding design satisfies both the input and output terminals, using an outer turn configuration. Additionally, the new design exhibits reduced parasitic capacitance and is suitable for use in LLC resonant converters, where it also minimizes current ringing. Full article

The totem-pole bridgeless power factor correction (PFC) converter, known for its advantages including simple topology, capability for zero-voltage switching (ZVS), and low common mode interference, presents an opportunity to enhance the efficiency and environmental friendliness of power systems. However, these converters have issues such as ZVS, requiring zero-crossing detection (ZCD) under circuits’ critical continuous mode (CRM) or additional auxiliary resonant circuits, resulting in increased circuit costs and control complexity. Therefore, this paper proposes a variable switching frequency digital control method to achieve ZVS under a wide operating range without ZCD circuits. At the same time, under the premise of ZVS, an interleaved parallel scheme is adopted to further minimize the current ripple and enhance the quality of the current waveform. Finally, an experimental 2 kW two-phase interleaved totem-pole bridgeless PFC converter prototype is designed to verify that the proposed method is correct and effective. The experimental prototype can reach an efficiency of 97.78%. Full article
