Search Results (58)

Sea surface height (SSH) serves as a fundamental geophysical parameter in oceanographic research. In 2023, China successfully launched the world’s first spaceborne interferometric GNSS-R (iGNSS-R) altimeter, which features dual-frequency multi-beam scanning, interferometric processing, and compatibility with three major satellite navigation systems: the BeiDou Navigation Satellite System (BDS), the Global Positioning System (GPS), and the Galileo Satellite Navigation System (GAL). This launch marked the first in-orbit validation of the iGNSS-R altimetry technology. This study provides a detailed overview of the iGNSS-R payload design and analyzes its dual-frequency delay mapping (DM) measurements. We developed a refined DM waveform-matching algorithm that precisely extracts the propagation delays between reflected and direct GNSS signals, enabling the retrieval of global sea surface height (SSH) through the interferometric altimetry model. For validation, we employed an inter-satellite crossover approach using Jason-3 and Sentinel-6 radar altimetry as references, achieving an unprecedented SSH accuracy of 17.2 cm at a 40 km resolution. This represents a breakthrough improvement over previous GNSS-R altimetry efforts. The successful demonstration of iGNSS-R technology opens up new possibilities for cost-effective, wide-swath sea level monitoring. It showcases the potential of GNSS-R technology to complement existing ocean observation systems and enhance our understanding of global sea surface dynamics. Full article

Permanent Scatterer Interferometric Synthetic Aperture Radar (PSInSAR), with millimeter-level accuracy and full-resolution capabilities, is essential for monitoring urban deformation. With the advancement of SAR sensors in spatial and temporal resolution and the expansion of wide-swath observation capabilities, the number of permanent scatterers (PSs) in high-density urban areas has surged exponentially. To address these computational and memory challenges in high-density urban PSInSAR processing, this paper proposes an efficient method for integrating regular grid partitioning and connected component constraints. First, adaptive dynamic regular grid partitioning was employed to divide monitoring areas into sub-blocks, balancing memory usage and computational efficiency. Second, a weighted least squares adjustment model using common PS points in overlapping regions eliminated systematic inter-sub-block biases, ensuring global consistency. A graph-based connected component constraint mechanism was introduced to resolve multi-component segmentation issues within sub-blocks to preserve discontinuous PS information. Experiments on TerraSAR-X data covering Fuzhou, China (590 km²), demonstrated that the method processed 1.4 × 10⁷ PS points under 32 GB memory constraints, where it achieved a 25-fold efficiency improvement over traditional global PSInSAR. The deformation rates and elevation residuals exhibited high consistency with conventional methods (correlation coefficient ≥ 0.98). This method effectively addresses the issues of memory overflow, connectivity loss between sub-blocks, and cumulative merging errors in large-scale PS networks. It provides an efficient solution for wide-area millimeter-scale deformation monitoring in high-density urban areas, supporting applications such as geohazard early warning and urban infrastructure safety assessment. Full article

Traditional methods for the construction of intertidal digital elevation models (DEMs) require the integration of long-term multi-sensor datasets and struggle to capture the spatiotemporal variation caused by ocean dynamics. The SWOT (surface water and ocean topography) mission, with its wide-swath interferometric altimetry technology, provides instantaneous full-swath elevation data in a single pass, offering a revolutionary data source for high-precision intertidal topographic monitoring. This study presents a framework for SWOT-based intertidal DEM extraction that integrates data preprocessing, topographic slope map construction, and tidal channel masking. The radial sand ridge region along the Jiangsu coast is analyzed using SWOT L2 LR (Low Resolution) unsmoothed data from July 2023 to December 2024. Multisource validation data are used to comprehensively assess the accuracy of sea surface height (SSH) and land elevation derived from LR products. Results show that the root mean square error (RMSE) of SSH at Dafeng, Yanghe, and Gensha tide stations is 0.25 m, 0.19 m, and 0.32 m, respectively. Validation with LiDAR data indicates a land elevation accuracy of ~0.3 m. Additionally, the topographic features captured by LR products are consistent with the patterns observed in the remote sensing imagery. A 16-month time-series analysis reveals significant spatiotemporal variations in the Tiaozini area, particularly concentrated in the tidal channel areas. Furthermore, the Pearson correlation coefficient for the DEMs generated from SWOT data decreased from 0.94 over a one-month interval to 0.84 over sixteen months, reflecting the persistent impact of oceanic dynamic processes on intertidal topography. Full article

Phase denoising constitutes a critical component of the synthetic aperture radar interferometry (InSAR) processing chain, where noise suppression and detail preservation are two mutually constraining objectives. Recently, deep learning has attracted considerable interest due to its promising performance in the field of image denoising. In this paper, a Neighbor2Neighbor denoising network (NBDNet) is proposed, which is capable of simultaneously estimating phase and coherence in both single-look and multi-look cases. Specifically, repeat-pass PALSAR real interferograms encompassing a diverse range of coherence, fringe density, and terrain features are used as the training dataset, and the novel Neighbor2Neighbor self-supervised training framework is leveraged. The Neighbor2Neighbor framework eliminates the necessity of noise-free labels, simplifying the training process. Furthermore, rich features can be learned directly from real interferograms. In order to validate the denoising capability and generalization ability of the proposed NBDNet, simulated data, repeat-pass data from Sentinel-1 Interferometric Wide (IW) swath mode, and single-pass data from Hongtu-1 stripmap mode are used for phase denoising experiments. The results demonstrate that NBDNet performs well in terms of noise suppression, detail preservation and computation efficiency, validating its potential for high-precision and high-resolution topography reconstruction. Full article

A long-term time series of 319 Sentinel-1 SAR Imagery with Interferometric Wide Swath (IW) mode was used to study the characteristics of submesoscale eddies over Japanese coastal regions from 2015 to 2021, including spatiotemporal eddy properties and possible mechanisms of their formation. The results showed that around 98% of the 1499 eddies identified from the SAR snapshots were submesoscale eddies (horizontal scales of $\mathcal{O}\left(1–20\right)$ km) with a ratio of around 78% cyclones to around 22% anticyclones. Around 8% of the submesoscale eddies were found in these SAR images in winter since the submesoscale current-induced signals are masked by the stronger wind speed, compared with other seasons. Typical features of submesoscale eddies are summarized, providing a preliminary qualitative analysis of potential generation mechanisms specific to the eddy characteristics in this region. This study suggests that Sentinel-1 images are capable of providing insights into the observed submesoscale eddies near the coastal regions of eastern Japan, thereby contributing to the improved understanding of the generation of submesoscale eddies. Full article

Full tensor of gravity gradients contains extremely large amounts of information, which is one of the most important sources for research on recovery seafloor topography and underwater matching navigation. The calculation and accuracy of the full tensor of gravity gradients are worth studying. The Ka-band interferometric radar altimeter (KaRIn) of surface water and ocean topography (SWOT) mission enables high spatial resolution of sea surface height (SSH), which would be beneficial for the calculation of gravity gradients. However, there are no clear accuracy results for the gravity gradients (the gravity gradient tensor represents the second-order derivative of the gravity potential) recovered based on SWOT data. This study evaluated the possible precision of gravity gradients using the discretization method based on simulated SWOT wide-swath data and investigated the impact of instrument errors. The data are simulated based on the sea level anomaly data provided by the European Space Agency. The instrument errors are simulated based on the power spectrum data provided in the SWOT error budget document. Firstly, the full tensor of gravity gradients (SWOT_GGT) is calculated based on deflections of the vertical and gravity anomaly. The distinctions of instrument errors on the ascending and descending orbits are also taken into account in the calculation. The precision of the T_zz component is evaluated by the vertical gravity gradient model provided by the Scripps Institution of Oceanography. All components of SWOT_GGT are validated by the gravity gradients model, which is calculated by the open-source software GrafLab based on spherical harmonic. The T_zz component has the poorest precision among all the components. The reason for the worst accuracy of the T_zz component may be that it is derived by T_xx and T_yy, T_zz would have a larger error than T_xx and T_yy. The precision of all components is better than 6 E. Among the various errors, the effect of phase error and KaRIn error (random error caused by interferometric radar) on the results is greater than 2 E. The effect of the other four errors on the results is about 0.5 E. Utilizing multi-cycle data for the full tensor of gravity gradients recovery can suppress the effect of errors. Full article

The interferometric imaging radar altimeter (InIRA), mounted on the Tiangong-2 space laboratory, utilizes a small incidence and a short interferometric baseline to achieve altimetry for wide swathes of ocean surface topography and inland water surface elevation. To obtain a high-precision digital elevation model (DEM), calibration of the interferometric system parameters is necessary. Because InIRA utilizes the small-incidence interference system design, serious coupling occurs between the interferometric parameters. Commonly used interferometric calibration methods tend to fall into the local optimal solution for InIRA. Because evolutionary algorithms have a stronger robustness and global search ability, they are better suited to handling the solution space structure under the coupling of complex interferometric parameters. This article establishes an interferometric calibration optimization model for InIRA by utilizing the relative flatness of the lake surface as an inequality constraint. Furthermore, an adaptive penalty coefficient constraint evolutionary algorithm is designed to solve the model. The proposed method was tested on actual InIRA data, and the results indicate that it efficiently adjusts interferometric parameters, enhancing the precision of measurements for Qinghai Lake elevation. Full article

This paper presents for the first time the results of marine gravity recovery using the ocean observation data acquired by Tiangong-2 interferometric imaging radar altimeter (TG2 InIRA) which demonstrate not only the balanced accuracies of the north and east components of deflection of the vertical (DOV) as envisaged, but also the improved spatial resolutions of DOV compared with that by conventional altimeters (CAs). Moreover, much higher measurement efficiency owing to the wide-swath capability and the great potential in accuracy improvement of marine gravity field are also demonstrated. TG2 InIRA adopts the interferometry with short baseline and takes small incidence angles, by which wide-swath sea surface height (SSH) can be measured with high accuracy. Gravity recovery experiments in the Western Pacific area are conducted to demonstrate the performance, advantages and capability of TG2 InIRA. SSH data processing algorithms and DOV calculation have been designed by taking the wide-swath feature into account, based on which, the gravity anomalies are then calculated using the inverse Vening Meinesz formula. The derived gravity anomalies are compared with both the published gravity models and the shipborne gravity measurements. The results show that the accuracy of TG2 InIRA is equivalent to, or even a little better than, that of CAs. The fused gravity result using equal TG2 InIRA data and CAs data performs better than those using TG2 InIRA data alone or CAs data alone. Due to the signal bandwidth of TG2 InIRA is only 40 MHz which is much smaller than that of CAs, much higher accuracy can be hopefully achieved for future missions if larger signal bandwidth is used. Full article

The Terrain Wide-swath Interferometric L-band Synthetic Aperture Radar (TwinSAR-L) mission is a spaceborne bistatic synthetic aperture radar (SAR) mission to derive a high-quality global digital elevation model (DEM). The prerequisite of the high-accuracy DEM is knowing the interferometric baseline with high precision. The challenging problem is that the baseline of the bistatic system is highly dynamic due to the fast relative motion between the two satellites. In this paper, a pixel-related baseline model based on the geometrical shift is proposed to accurately reflect the position change of satellites. The baseline error is then calibrated using height gradient information and a small number of point targets with a slight incidence angle difference, eliminating the need for low-frequency corner reflectors and avoiding the difficulty of selecting a calibration site. The proposed method has been successfully exploited during the initial Commissioning Phase of TwinSAR-L, demonstrating its effectiveness in evaluating the precise baseline and supporting the generation of high-precision DEM. Full article

The LuTan-1(LT-1), known as the L-band differential interferometric synthetic aperture radar (SAR) satellite system, is an essential piece of civil infrastructure in China, providing extensive applications such as surface deformation monitoring and topographic mapping. To achieve high-resolution and wide-swath (HRWS) observation abilities, the LT-1 takes the dual receiving antenna (DRA) imaging mode as its working mode. However, amplitude and phase errors between channels lead to a mismatch between the reconstruction filter and the multichannel echo signal, worsen the reconstructed azimuth spectrum, and introduce ambiguity targets in the final imaging results, seriously affecting the final imaging quality. In order to better evaluate the channel error and azimuth ambiguity performance of the LT-1 system, this paper proposed an advanced channel consistency correction method and conducted many measured data experiments. The experimental results show that the proposed method is effective, and the LT-1 system has excellent channel error control and azimuth ambiguity performance. Full article

The survey and structural analysis of surface coseismic ruptures are essential tools for characterizing seismogenic structures. In this work, a procedure to survey coseismic ruptures using satellite interferometric synthetic aperture radar (InSAR) data, directing the survey using Unmanned Aerial Vehicles (UAV), is proposed together with a field validation of the results. The Sentinel-1 A/B Interferometric Wide (IW) Swath TOPSAR mode offers the possibility of acquiring images with a short revisit time. This huge amount of open data is extremely useful for geohazards monitoring, such as for earthquakes. Interferograms show the deformation field associated with earthquakes. Phase discontinuities appearing on wrapped interferograms or loss-of-coherence areas could represent small ground displacements associated with the fault’s ruptures. Low-altitude flight platforms such as UAV permit the acquisition of high resolution images and generate 3D spatial geolocalized clouds of data with centimeter-level accuracy. The generated topography maps and orthomosaic images are the direct products of this technology, allowing the possibility of analyzing geological structures from many viewpoints. We present two case studies. The first one is relative to the 2016 central Italian earthquakes, astride which the InSAR outcomes highlighted quite accurately the field displacement of extensional faults in the Mt. Vettore–M. Bove area. Here, the geological effect of the earthquake is represented by more than 35 km of ground ruptures with a complex pattern composed by subparallel and overlapping synthetic and antithetic fault splays. The second case is relative to the Mt. Etna earthquake of 26 December 2018, following which several ground ruptures were detected. The analysis of the unwrapped phase and the application of edge detector filtering and other discontinuity enhancers allowed the identification of a complex pattern of ground ruptures. In the Pennisi and Fiandaca areas different generation of ruptures can be distinguished, while previously unknown ruptures pertaining to the Acireale and Ragalna faults can be identify and analyzed. Full article

Multichannel SAR systems have grown rapidly over the past decade due to their powerful high-resolution and wide-swath (HRWS) capabilities. Because spatially separated channels also have the potential to suppress jamming, dual-channel cancellation is a general method that is effective regardless of the type of jamming signal. In this paper, the principle of dual-channel cancellation (DCC) is introduced, and several practical problems using DCC are also discussed. Moreover, this paper emphasizes interferometric phase estimation, which is the key to DCC. If the jamming-to-signal ratio (JSR) is high, the interferometric phase can be estimated accurately from the interferometry of two channel signals, but estimation becomes rather difficult when the JSR decreases. To solve the problem of interferometric phase estimation under a low JSR, a novel interferometric phase estimation method using cosine similarity is proposed in this paper. L-band airborne dual-channel SAR is performed to investigate the applicability of the method. The results not only prove that cosine similarity is an effective method for interferometric phase estimation, but also demonstrate the potential of DCC in the SAR anti-jamming processing. Full article

The purpose of this study is to include rain effects in wind field retrieval from C-band synthetic aperture radar (SAR) imagery collected under tropical cyclone conditions. An effective and operationally attractive approach to detect rain cells in SAR imagery is proposed and verified using four Sentinel-1 (S-1) SAR images collected in dual-polarized (vertical-vertical (VV) and vertical-horizontal (VH)) interferometric-wide swath imaging mode during the Satellite Hurricane Observation Campaign. SAR images were collocated with ancillary observations that include sea surface wind and rain rate from the Stepped-Frequency Microwave Radiometer (SFMR) on board of the National Oceanic and Atmospheric Administration aircraft. The winds are inverted from VV- and VH-polarized S-1 image using the CMOD5.N and S1IW.NR geophysical model functions (GMFs), respectively. Location and radius of cyclone’s eye, together with the TC central pressure, are calculated from the VV-polarized SAR-derived wind and a parametric model. A cost function is proposed that consists of the difference between the measured VV-polarized SAR normalized radar cross section (NRCS) and the NRCS predicted using CMOD5.N forced with the wind speed retrieved by the VH-polarized SAR images using S1IW.NR GMF and the wind direction retrieved from the patterns visible in the SAR image. This cost function is related to the SFMR rain rate. Experimental results show that the difference between measured and predicted NRCS values range from 0.5 dB to 5 dB within a distance of 100 km from the cyclone’s eye, while the difference increases spanning from 3 dB to 6 dB for distances larger than 100 km. Following this rationale, first the rain bands are extracted from SAR imagery and, then, the composite wind fields are reconstructed by replacing: (1) dual-polarized SAR-derived winds over the rain-free regions; (2) winds simulated using the radial-vortex model over the rain-affected regions. The validation of the composite wind speed against SFMR winds yields a <2 m s⁻¹ and >0.7 correlation (COR) at all flow directions up to retrieval speeds of 70 m s⁻¹. This result outperforms the winds estimated using the VH-polarized S1IW.NR GMF, which call for high error accuracy, such as about 4 m s⁻¹ with a 0.45 COR ranged from 330° to 360°. Full article

In this study, elevation change and surface morphology of CookE2, one of the most active subglacial lakes in East Antarctica, were analyzed by using Differential Interferometric Synthetic Aperture Radar (DInSAR) and a newly adapted Time-Segmented Persistent Scatterer Interferometric Synthetic Aperture Radar (TS-PSInSAR) techniques. Firstly, several DInSAR pairs were used to study the surface morphology of the subglacial lake during the rapid discharge event in 2007 and the subsequent recharge in 2010 by using ALOS PALSAR data and the continuous recharge from 2018 to 2020 by using Sentinel-1 SAR data. For time-series observation from 2018 to 2020, however, simple integration of DInSAR deviates largely from the satellite altimeter data because errors from the horizontal flow of the surrounding ice field or atmospheric phase accumulate. Conventional PSInSAR deviates from the altimeter data if the LOS displacement exceeds 300 mm, i.e., approximately 1/4 of the slant range resolution of the Sentinel-1 SAR in Interferometric Wide-swath (IW) mode, during the time window. Therefore, a series of Time-Segmented PSInSAR with a 4-month time window could accurately distinguish 1.10 ± 0.01 m/year of highly linear (R² = 0.99) surface rise rate of CookE2 and 0.63 m/year of horizontal deformation rate of the surrounding ice field from 2018 to 2020. Full article

Digital beamforming (DBF) TOPS SAR in elevation is a new synthetic aperture radar (SAR) system, which has the advantage of wide swath coverage and a high signal-to-noise ratio (SNR). In this paper, considering the phase preservation demand for interferometric SAR (InSAR) processing, the complete processing chain for DBF-TOPS SAR/InSAR in elevation is proposed with a wide beam angle and channels’ amplitude and phase errors. Firstly, we analyze the airborne motion compensation method along the line-of-sight direction for TOPS SAR with squint angle. Furthermore, for the large-range beam angle of DBF, the sub-swaths division process is presented for the range-dependent radar look angle, and the sub-swaths division criterion is also given in the analytic expression. Then, the relative amplitude and phase errors’ estimation and compensation method between channels is provided in the range frequency domain based on the pivoting filter with coherence weighting, which is convenient for DBF processing and SNR improvement. Finally, the DEMs are generated under different conditions to compare the phase preservation performance. The effectiveness of the proposed processing chain is verified with both simulated data and airborne real DBF-TOPS SAR/InSAR data. Full article
