To address hydrogen separation from hydrogen-blended natural gas, this work develops a mathematical model for a novel thermal-transpiration-effect-based circulating-flow gas separator according to the Navier–Stokes equations, following the joint modification with velocity-slip and temperature-jump boundary conditions, and a binary gas diffusion model derived from the Maxwell–Stefan equations. The model is then used to investigate the component transport and flow of a CH₄-H₂ mixture at the slip flow regime. The average hydrogen mole fraction in the component enrichment zone increases monotonically as the temperature difference increases, reaching 0.429 at a hot channel temperature of 400 K. An optimum inlet gas velocity of 0.93 m/s is identified to achieve the maximum average hydrogen mole fraction in the enrichment zone. In addition, decreasing the microchannel diameter enhances the hydrogen enrichment performance, with the average hydrogen mole fraction reaching 0.578 at a microchannel diameter of 1 μm whereas increasing the microchannel diameter improves the product gas flow rate, indicating a trade-off between separation performance and processing capacity. These insights provide guidance for understanding the component transport mechanism and for the preliminary design of this type of gas separator for hydrogen separation applications. Full article

Heated crude oil pipelines transporting high-pour-point, high-viscosity, and high-wax-content crude oil are increasingly operated under small-batch and multi-condition scenarios. Under such conditions, fixed-parameter models and experience-based operating strategies may fail to accurately describe the evolving thermo-hydraulic state, resulting in inaccurate temperature-safety assessment and conservative energy use. To address this problem, this study develops a hybrid modelling and simulation framework for the energy-efficient operation of heated crude oil pipelines. The framework integrates operating-state perception, online parameter inversion, transient thermo-hydraulic simulation, data assimilation, and rolling optimization. First, an online parameter inversion method based on inverse problem solving is established to dynamically identify the overall heat-transfer coefficient and friction correction factor from Supervisory Control and Data Acquisition (SCADA) measurements. Second, a transient thermo-hydraulic simulation and data-assimilation model is constructed to predict pressure, temperature, and safety margins under changing boundary conditions. Third, a constraint-aware rolling optimization strategy is introduced to coordinate heating and pumping operations while satisfying temperature and pressure constraints. The proposed framework is validated using a practical crude oil pipeline. Under a representative low-flow-rate condition, online parameter inversion corrects the overestimation of the thermo-hydraulic state by the fixed-parameter model: the total temperature drop along the pipeline is revised from 33.12 °C to 35.65 °C, and the minimum station-inlet oil temperature is revised from 24.77 °C to 21.61 °C. After optimization is introduced, the total operating energy consumption decreases from 11,715.65 kW to 11,287.43 kW, corresponding to a reduction of 3.66%, while all temperature and pressure constraints remain satisfied. Under time-varying boundary conditions, the rolling optimization strategy further adjusts heating-furnace operation according to variations in inlet flow rate, inlet oil temperature, and ambient temperature, thereby reducing cumulative heating energy consumption while maintaining safe operation. The results demonstrate that the proposed framework provides an implementable modelling and simulation approach for online state assessment, transient prediction, and energy-efficient operation of heated crude oil pipelines under variable operating conditions. Full article

Exhaust piping in diesel engines is subject to severe thermal stress arising from high-temperature, high-pressure gas flows, and spray cooling with atomizing nozzles has become a widely adopted method to safeguard structural reliability. However, at present, the understanding of the spray fragmentation mechanism of two-phase flow under low inlet pressure is still not comprehensive. This study establishes a three-dimensional model of a gas–liquid impinging-jet nozzle and applies a coupled Volume-of-Fluid to Discrete-Phase-Model (VOF–DPM) approach to resolve the liquid breakup process in detail. High-speed imaging experiments were carried out to validate the numerical results. Orthogonal tests were conducted at five pressure levels for both gas and water—0.28, 0.24, 0.20, 0.16, and 0.12 MPa—producing 25 data pairs of spray cone angle and Sauter Mean Diameter (SMD). Within the 0–0.3 MPa air inlet pressure range explored here, raising the pressure consistently reduced the SMD and widened the cone angle, although both trends weakened as the pressure increased. Water inlet pressure exhibited a nonlinear influence, with local extrema appearing in the higher-pressure region. The overall SMD reached a minimum of 34.12 μm and a maximum of 149.04 μm. Using these 25 data points, a genetic algorithm was employed to optimize the pressure ratio under the constraint of total hydraulic power, yielding optimization strategies for different power budgets. An additional outcome of the simulation was the identification of a structural weakness: by reshaping the original flat impingement surface into a full conical surface, atomization quality improved by 29.36% under identical boundary conditions. These findings clarify the atomization mechanism of gas–liquid impinging jets under low inlet pressure and offer practical guidance for nozzle optimization. Full article

To address heat accumulation, localized hot spots, and non-uniform temperature distribution in large-capacity lithium iron phosphate energy storage battery modules under high ambient temperature and high-rate charge/discharge conditions, this study proposes a fin-enhanced phase change material (PCM)-air hybrid thermal management structure for a 100 Ah prismatic lithium iron phosphate battery and a 2P18S energy storage battery module. First, the battery thermal model is validated using single-cell experimental data reported in the literature. Subsequently, a three-dimensional transient fluid–solid coupled heat transfer model is established by considering transient battery heat generation, PCM solid–liquid phase change, air-side flow and heat transfer, and temperature-dependent thermophysical properties. User-defined functions are employed to implement the transient heat source and temperature-dependent material properties. Under identical boundary conditions, the thermal management performances of three configurations, namely Fin-Air, PCM-Air, and Fin-PCM-Air, are compared. The effects of ambient temperature (20 °C, 25 °C, and 30 °C) and inlet air velocity (1 m/s, 2 m/s, and 3 m/s) on the maximum module temperature, temperature uniformity, PCM liquid fraction evolution, and flow field distribution are quantitatively analyzed. The results show that, compared with the Fin–Air system without PCM and the PCM-Air system without fins, the Fin-PCM-Air configuration reduces the maximum module temperature by 1.57% and 0.25%, respectively, at an ambient temperature of 30 °C and an inlet air velocity of 3 m/s. After four charge–discharge cycles, the peak maximum temperature of the module is approximately 38.56 °C, and the peak maximum temperature difference remains below 3.6 K, indicating good temperature uniformity and latent heat buffering capability. In addition, the air velocity trade-off analysis indicates that increasing the inlet air velocity can improve cooling performance but also increases the air-channel pressure drop and fan power consumption. Therefore, the Fin-PCM-Air structure is more suitable for high-thermal-load conditions, and its practical application should comprehensively consider cooling benefits, additional mass, manufacturing cost, and long-term reliability. This study provides a reference for the design and engineering application of hybrid thermal management structures for large-capacity energy storage battery modules. Full article

To investigate the flow characteristics of three-dimensional swept interactions, 3D steady Reynolds-averaged Navier–Stokes (RANS) simulations are conducted at an incoming Mach number of 3.5 and a Reynolds number of 30,955 based on the incoming boundary-layer thickness δ₀. Three independent compression configurations with a total compression angle of 18° are analyzed and compared: planar swept shocks, curved swept shocks featuring an initial 2° deflection step followed by a continuously curved compression surface, and continuous isentropic compression waves. The results demonstrate that, unlike the baseline planar case, the interactions induced by both curved swept shocks and isentropic compression waves depart from the canonical quasi-conical similarity and transcend existing topological classification frameworks. These non-planar interactions are characterized by large-scale primary vortices and small-scale corner vortices that evolve along curved trajectories downstream. Quantitatively, the curved shock interaction yields maximum normal scales of 5.4δ₀ for the primary vortex and 1.8δ₀ for the corner vortex—significantly more compact than the 6.7δ₀ and 7.5δ₀ observed in the planar-shock interaction. Furthermore, the specific modality of compression—whether by discrete shock or continuous wave—exerts a profound effect on aerodynamic performance. Under the present conditions, while isentropic compression achieves the highest compression efficiency and planar shocks provide superior mass flow capture, curved shock compression strikes a favorable balance between these competing metrics. Curved shock configurations may offer potential for improving integrated inlet performance through appropriate adjustment of the initial shock strength. Full article

Steady-state thermal–hydraulic network models are widely used for the analysis, design, and operation of energy systems. While direct problems with prescribed boundary conditions can often be solved efficiently, inverse problems such as set-point tracking and parameter identification are commonly addressed through repeated solution of the corresponding direct problem. For large-scale networks with strong nonlinear couplings, such nested strategies can become computationally expensive and numerically burdensome. This paper presents a unified methodology for the solution of direct and inverse steady-state thermal–hydraulic problems within a single modeling workflow. In contrast to classical nested approaches, inverse problems are formulated in a simultaneous analysis and design framework, in which system states and selected system inputs are treated as unknowns simultaneously. The methodology combines externally causal component representations with acausal network balance relations in order to expose the structural dependencies of the assembled system and enable graph-based tearing reduction. Component-local evaluations, including possible component-internal nonlinear calculations, are encapsulated within the component models, while the nonlinear network closure problem is restricted to a reduced set of tearing variables.. Direct problems are solved by nonlinear root finding on the tearing-reduced residual system, whereas inverse problems are posed as tearing-reduced residual-constrained nonlinear programs with equality, inequality, and bound constraints. The methodology is demonstrated on a vapor-compression refrigeration cycle, where compressor speed and expansion valve opening are adjusted to satisfy prescribed cooling-load and superheat targets under varying condenser inlet temperatures. Implemented in Python, the proposed methodology supports transparent and reproducible modeling and provides a practical basis for simulation, set-point tracking, and constrained optimization of coupled thermal–hydraulic networks. Full article

A three-dimensional numerical investigation is conducted to clarify the internal pressure and velocity distributions in a hydraulic turbine under multiple operating conditions. The study aims to identify the main high-gradient regions and the influence of operating parameters on the internal flow field. The incompressible single-phase Navier–Stokes equations are solved using the SST k-ω turbulence model. Eleven operating conditions with different guide vane openings, net heads, output powers, and discharges are simulated using a full-passage turbine model with mass flow inlet and static pressure outlet boundary conditions. The numerical results are validated against experimental performance data. The results show that the pressure and velocity fields exhibit generally symmetric distributions in the circumferential and axial directions, whereas strong local gradients appear in the rotor–stator interaction region. Local high-pressure and high-velocity zones are mainly observed near the blade leading edges, while low-pressure and low-velocity regions develop near the trailing edges, runner cone, and draft tube. Increasing the net head raises the overall pressure and velocity levels and enhances the low-pressure and low-velocity regions in the draft tube. Under a fixed head, increasing the guide vane opening mainly affects the flow distribution around the stay and guide vanes and modifies the flow structure in the runner cone and draft tube. These findings provide a systematic numerical characterization of the pressure and velocity distributions in the turbine and help identify critical regions for further hydraulic performance analysis and flow field optimization. Full article

This paper introduces a topology optimization framework for steady incompressible Stokes flow based on the non-conforming Virtual Element Method, VEM. The proposed framework combines the geometric flexibility of VEM with an optimality criteria update scheme to minimize viscous and Darcy dissipation under a prescribed volume constraint. The method is applied to the Stokes-flow pipe bend benchmark with parabolic inlet velocity, no-slip wall, and prescribed outlet velocity boundary conditions. By allowing general polygonal elements, including concave and semi-structured polygonal meshes, the method alleviates mesh-related restrictions commonly encountered in conventional finite element discretizations. The methodology is demonstrated through Stokes-flow benchmark problems on different polygonal meshes. The numerical results show that the proposed VEM-based formulation can obtain stable and mesh-insensitive optimized flow channels for Stokes-flow topology optimization. This work offers a systematic approach to obtaining accurate, efficient, and mesh-independent optimal designs for complex fluid systems, providing a stable numerical tool for low-energy-consumption flow channel design in microfluidics, heat exchangers, and biomedical engineering. Extensions to Navier–Stokes and non-Newtonian flow models are left for future work. It should be clarified that the proposed method is only validated for steady Stokes flow and has not been validated for complex fluid models including unsteady Navier–Stokes and non-Newtonian flow models; extensions to these complex models are left for future work. Full article

The transient mechanism of dual-boundary dynamic opening in the inlet during stage transition of an integral solid rocket ramjet (ISRR) remains insufficiently understood. To address this issue, a combined approach involving numerical simulations and free-jet experiments was employed. A parametric model describing the time-sequenced opening of inlet and outlet cover was established. The influences of sequence and progression of opening and flight conditions on transient flow evolution and inlet stability were systematically examined. It is found that when the inlet is opened first, a “dead cavity” tends to form inside the inlet, which subsequently triggers pronounced pressure oscillations. Under baseline conditions, the peak outlet pressure reaches approximately 0.90 MPa, with a dominant frequency of about 66.7 Hz. Conversely, when the outlet is opened first, the cavity-induced oscillation is effectively suppressed; however, a transient “flow choking” overpressure and a delayed establishment of the flow field are observed. The discrepancies between simulations and experiments for key pressure characteristics under two representative opening modes are maintained within 5%, confirming the robustness of the proposed methodology. Further analysis reveals that increasing the Mach number markedly intensifies flow instability and reduces the stability margin, whereas higher flight altitudes help attenuate cavity oscillations. A strong coupling between the opening rate and temporal sequence is also identified. Specifically, for inlet-first scenarios, a slower inlet opening combined with a rapid outlet opening is preferable, while for outlet-first cases, rapid opening on both sides yields better performance. On this basis, a “stability window map” defined by the temporal difference (Δt) and opening duration (Topen) is proposed. This map delineates the distributions of stable, transitional, and hazardous regimes under varying conditions, which may offer a quantitative reference for adaptive control strategies in the ISRR stage of transition. Interestingly, these findings suggest that slight timing adjustments could substantially reshape the transient flow behavior. Notably, the introduction of the dual-boundary temporally coordinated forcing leads to flow responses within the inlet that exhibits pronounced path dependence and non-uniqueness. Such behavior deviates from the conventional understanding established under the single-boundary frameworks, where transient mode-transition processes were typically assumed to be uniquely determined. More importantly, these findings offer a renewed physical interpretation of inlet mode-transition dynamics, thereby providing both quantitative support and practical guidance for the adaptive design of ISRR transition control strategies. In particular, the results suggest that incorporating multi-boundary temporal effects could significantly enhance the robustness and flexibility of the control-law formulation. Full article

Blade tip leakage flow in gas turbines is associated with aerodynamic loss and local heat transfer variation in the tip region. In this study, the flow structure, total pressure loss coefficient, heat transfer coefficient (HTC), and film cooling effectiveness (FCE) were numerically investigated for a plane tip (PLN) and five squealer tip geometries: a conventional squealer tip (SQR), cutback squealer tip (CBS), multi-cavity squealer tip (MCS), triangular-grooved suction-side squealer tip (GSS), and multi-cavity triangular-grooved suction-side squealer tip (MGS). All configurations were compared under the same cascade geometry, tip-clearance condition, and inlet/outlet boundary conditions to examine the geometry-dependent relationship among aerodynamic loss, heat transfer, and film cooling performance. Film cooling was evaluated at blowing ratios of M = 1 and 2 using a camber-line hole arrangement, and the effect of hole rearrangement was further examined at the same blowing ratio and with the same number of cooling holes. The results indicate that the aerodynamic and thermal characteristics of the tip region vary with the leakage-flow path, cavity recirculation, and reattachment behavior formed by each tip geometry. Under the present conditions, SQR showed the lowest downstream total pressure loss coefficient, with a 7.27% reduction relative to PLN, whereas MGS showed the lowest geometry-normalized heat transfer rate among the tested geometries. Increasing the blowing ratio tended to increase FCE, although local cooling performance was affected by high-pressure or reattachment-dominated regions where coolant ejection, surface attachment, or lateral spreading was limited. Compared with the camber-line arrangement, the rearranged hole configuration increased local FCE by up to 29.6% for CBS and 23.3% for MGS at the same blowing ratio. These results may be used as comparative data for evaluating squealer tip geometries and cooling-hole placement during preliminary blade tip cooling design. Full article

Real-time management of short-term ozone peaks during arc welding remains challenging because ventilation- and enclosure-defined transport boundaries can create strong position-dependent peak behavior, even under fixed process settings. This study establishes a coordinate-referenced, event-level monitoring and analysis framework to quantify ozone–fume peak coupling under a controlled local exhaust ventilation (LEV) suction boundary during CO₂ arc welding. A controlled process–environment testbed with a defined suction condition was implemented, and synchronized ozone and fume signals were acquired at three sampling points referenced to the arc position and the LEV inlet direction. The particulate channel was anchored to a PM₄ gravimetric reference, yielding a condition-specific traceable CPM-to-mass conversion factor K₁ of 1.76 × 10⁻² mg/(m³·CPM) and enabling standardized peak-fume endpoints on a mass-concentration scale. The primary inferential analysis used the curtain-on dataset, comprising 21 sessions and 42 event-level records balanced across three sampling points. Under the same suction boundary, peak coupling was strongly monitoring-coordinate dependent: LEV-aligned locations showed statistically supported ln–ln scaling between peak ozone and peak fume, whereas the opposite-side location did not exhibit statistically supported scaling; a pooled point-parameterized ln–ln model achieved an adjusted R² of 0.777. As a descriptive control-relevant contrast, adding a curtain enclosure under continuous LEV produced strong event-level ozone peak suppression at LEV-aligned locations, with a maximum reduction of 87.8%, while attenuation at the opposite-side location remained limited. Overall, the results provide a ventilation-boundary-consistent, coordinate-specific basis for monitoring placement and control evaluation, identifying where peak translation is supported and where direct ozone monitoring remains necessary. Full article

A coupled modeling framework is developed to predict coating thickness after air knife wiping in hot-dip galvanizing. A 3D large eddy simulation (LES) using the WALE sub-grid scale (SGS) model is performed to resolve the jet impingement on the moving strip. Time-averaged wall static pressure $p_{\omega }\left(y\right)$ and wall shear stress ${\tau }_{\omega }\left(y\right)$ along the strip direction are extracted and used as driving inputs for a thin film model. Starting from the continuity and momentum equations, a lubrication-type formulation is derived, leading to a local cubic equation for film thickness $h\left(y\right)$ that accounts for both pressure gradient and gravity. A coupling workflow is established to preprocess the LES wall signals and compute the final coating thickness $h_{final}$. Parametric sweeps of inlet total pressure $P_0$ and the knife-to-strip distance $H$ are employed to construct operating window maps. The predicted trends show that increasing $P_0$ or decreasing $H$ intensifies wall loading and reduces $h_{final}$, while the operating window boundary is governed by the balance between the gas-induced shears. Representative results, including peak wall loading and thickness ranges, are reported for industrially relevant operating conditions. Full article

In air jet looms, relay nozzles are critical components in governing airflow velocity and air consumption during the weft insertion process. Although computational fluid dynamics (CFD) offers high-fidelity simulation for aerodynamic analysis, its computational burden hinders its practicality in iterative aerodynamic design of relay nozzles. To address the challenge, this study proposes a data-driven framework integrating a Chebyshev polynomial Kolmogorov–Arnold Network (Chebyshev KAN) surrogate model with an Improved Multi-objective Red-billed Blue Magpie Optimizer (IMORBMO). The accuracy of the Chebyshev KAN model was benchmarked against conventional multilayer perceptrons (MLP), convolutional neural networks (CNN), and the standard Kolmogorov–Arnold Network (KAN). Experimental results demonstrate that the Chebyshev KAN model achieves the lowest mean absolute error (MAE) of 0.103 for airflow velocity and 0.115 for air consumption. Building upon the non-dominated sorting and crowding distance strategies, IMORBMO was developed, incorporating an adaptive mutation mechanism by information entropy for improvement of convergence, diversity, and uniformity of the Pareto-optimal solutions. Comprehensive evaluations on the ZDT and WFG benchmark suites confirm that the IMORBMO consistently attains the best and highly competitive performance, yielding the lowest generation distance (GD), inverted generational distance (IGD) values and the highest hypervolume (HV). Applied to the aerodynamic optimization of a relay nozzle, the proposed framework delivers an optimal aerodynamic design that increases airflow velocity by 10.5% while reducing air consumption by 15.4%, as verified by CFD simulation. The steady-state flow field was simulated by solving the Reynolds-Average NavierStokes equations with the k–ω turbulent model, utilizing Fluent 2025.R2. No-slip wall, inlet pressure and outlet pressures are boundary conditions to the relay nozzle surfaces. This work establishes a computationally efficient and accurate optimization paradigm that holds significant promise for aerodynamic design and other complex real-world engineering applications. Full article

A major development direction for next-generation civil aircraft is to significantly reduce fuel consumption through the integration of high-bypass-ratio engines. However, the large diameter of high BPR engines will cause traditional aircraft to face the dilemma of ground clearance. The over-the-wing engine mount configuration avoids ground clearance constraints by installing the engines over the wings, which is conducive to the integration of high BPR engines. However, the sensitivity of the flow on the upper surface of the wing makes this configuration more likely to cause strong interference between the engine and the wing than the traditional configuration. During the design, the important interaction of the wing shapes, the wing static elastic deformation, the engine installation position and the engine inlet and exhaust effect should be fully considered, which brings great challenges to the traditional design method. An automatic multidisciplinary coupled optimization method based on the discrete adjoint approach and gradient-based optimization is proposed for this configuration. A corresponding framework is established based on the open-source multidisciplinary optimization platform OpenMDAO; the CFD solution and the adjoint solution are carried out using the open-source CFD solver DAFoam; the structural finite element solution and the structural adjoint solution are carried out using the open-source FEM solver TACS; and the engine power effect is solved by coupling the intake and exhaust boundary conditions into the CFD solver. This method can comprehensively consider the changes in the wing shapes, the static aeroelastic deformation of the wing, the intake and exhaust effects of the engine, and the positional movement of the engine along the spanwise, chordwise and vertical directions of the wing. The optimization results show that the optimized configuration eliminates the strong shock interaction between the nacelle and the wing, enhances the favorable pressure gradient on the upper surface of the wing, and reduces the drag by 9.51%, thereby demonstrating the effectiveness of the proposed multidisciplinary coupled adjoint optimization method for this configuration. Full article

Boundary Layer Ingestion propulsors operate in an adverse aerodynamic environment with high levels of distortion. With the purpose of extending the operating range of transonic fan rotors for BLI applications, in this paper we present an optimisation study focused on blade profiles design under different working conditions. Quasi-2D blade sections are optimised using a genetic algorithm and numerical simulations, by varying the camberline and thickness distribution. A method to efficiently achieve a combination of total pressure ratio at a given relative inlet Mach number is devised. The isentropic efficiency is optimised at the design point, concurrently with the stall total pressure ratio at a lower inlet Mach number, in a multi-objective fashion. Pareto-optimal profiles exhibit a moderate leading edge concavity for high efficiency and a straighter fore part with increased trailing edge deflection for higher compression at stall. Optimised airfoils are used in a preliminary three-dimensional evaluation with a realistic BLI inflow, in which the unsteady full-annulus analysis corroborates the approach of the sectional optimisation, also showing the possibility of estimating the integral performance of the machine with a simplified approach based on a single-passage simulation with a circumferential-averaged inflow distribution. Full article
