Electric machines are gaining popularity in transport and replacing internal combustion engines. However, the diagnosis of their faults remains an ongoing problem. Traditional diagnostic methods, such as vibration, sound, and temperature analysis, have limitations in practical applications, particularly because of external interference and the need for additional sensors. This paper presents a new diagnostic approach based on convolutional neural networks (CNNs) and direct analysis of current signals. The proposed solution allows for a significant reduction in the number of samples required for effective diagnostics. The neural network, operating on 500 signal samples, achieved a classification efficiency of 99.85–100% for each category of damage investigated. Tests were conducted to determine the effect of noise on the accuracy of the system. This study compares applications based on mechanical vibration signals and the proposed algorithm based on phase current signals. The results indicate that the proposed approach can be successfully applied to real-world monitoring systems for electrical machinery, offering a high-efficiency diagnostic tool while fulfilling the limitations of demanding measurement systems. Full article

Ensuring the reliability of induction motors is essential for industrial applications, as motor failures can lead to unplanned downtime and significant financial losses. Motor current signature analysis (MCSA) has emerged as an effective and non-intrusive technique for diagnosing motor health, particularly for monitoring bearing conditions, which account for a significant percentage of motor failures. However, the MCSA technique can only assess the status of the bearings: whether they are healthy or unhealthy. Regular maintenance activities are necessary to avoid unplanned downtime due to bearing failure. Furthermore, this analysis cannot help proactively replace the bearings before they fail. Therefore, this research develops a predictive maintenance framework by integrating motor current signature analysis with machine learning techniques to estimate the remaining useful life (RUL) of induction motor bearings. The methodology involves analyzing historical motor current data using $I_{sd}-I_{sq}$ trajectory analysis and fast Fourier transform (FFT) to extract relevant health indicators. $I_{sd}-I_{sq}$ analysis identifies deviations in motor behavior, whereas FFT detects harmonics that indicate potential faults. A machine learning model is employed to classify the health status of motor bearings and estimate their RUL based on extracted signal features. This approach effectively differentiates healthy from faulty bearings, enabling proactive maintenance to reduce failures and boost efficiency. Full article

In induction motor bearings, distributed faults are prevalent, often resulting from factors such as inadequate lubrication and particle contamination. Unlike localized faults, distributed faults produce complex and unpredictable motor signal behaviors. Although existing research predominantly addresses localized faults in mains-fed motors, particularly single-point defects, a comprehensive investigation into particle contamination in bearings of inverter-fed motors is essential for a more accurate understanding of real-world bearing issues. This paper conducts a comparative analysis of vibration, stator current, speed, and acoustic signals to detect particle contamination through signal analysis across three domains: time, frequency, and time-frequency. These domains are analyzed to assess and compare the characteristics of each monitored signal in the context of bearing wear detection. The data were collected from both steady-state and startup transients of an induction motor controlled by a variable frequency drive. The experimental results highlight the most significant characteristics of each monitored signal, evaluated across the different domains of analysis. The primary conclusion indicates that, in inverter-fed motors, sound and vibration signals exhibit abnormal levels when the bearing is damaged but the related-fault signature becomes complicated. Additionally, the findings demonstrate that the analysis of startup stator current and speed signals presents the potential to detect distributed bearing damage in inverter-fed induction motors. Full article

Variable frequency drives (VFDs) are widely used in industry as an efficient means to control the rotational speed of AC motors by varying the supply frequency to the motor. VFD signatures can be detected in vibration signals in the form of sidebands (modulations) induced on tonal components (carrier frequencies). These sidebands are spaced at twice the “pseudo line” VFD frequency, as the magnetic forces in the motor have two peaks per current cycle. VFD-related signatures are generally less susceptible to interference from other mechanical sources, making them particularly useful for deriving speed variation information and obtaining a “pseudo” tachometer from the motor’s synchronous speed. This tachometer can then be employed to accurately estimate the speed profile and to facilitate order tracking in mechanical systems for vibration analysis purposes. This paper presents a signal processing technique designed to extract a pseudo tachometer from the VFD signature found in a vibration signal. The algorithm was tested on publicly available vibration data from a test rig featuring a two-stage gearbox with seeded bearing faults operating under variable-speed conditions with no load, i.e., with minimal slip between the induction motor’s synchronous and actual speed. The results clearly demonstrate the feasibility of using VFD signatures both to extract an accurate speed profile (root mean square error, RMSE of less than 2.5%) and to effectively perform order tracking, leading to the identification of bearing faults. This approach offers an accurate and reliable tool for the analysis of vibration in mechanical systems driven by AC motors with VFDs. However, it is important to note that some inaccuracies may occur at higher motor slip levels under heavy or variable loads due to the mismatch between the synchronous and actual speeds. Slip-induced variations can further distort tracked order frequencies, compromising the accuracy of vibration analysis for gear mesh and bearing defects. These issues will need to be addressed in future research. Full article

Induction motors are essential components in industry due to their efficiency and cost-effectiveness. This study presents an innovative methodology for automatic fault detection by analyzing images generated from the Fourier spectra of current signals using deep learning techniques. A new preprocessing technique incorporating a distinctive background to enhance spectral feature learning is proposed, enabling the detection of four types of faults: healthy motor coupled to a generator with a broken bar (HGB), broken rotor bar (BRB), race bearing fault (RBF), and bearing ball fault (BBF). The dataset was generated from three-phase signals of an induction motor controlled by a Direct Torque Controller under various operating conditions (20–1500 rpm with 0–100% load), resulting in 4251 images. The model, based on a Visual Geometry Group (VGG) architecture with 19 layers, achieved an overall accuracy of 98%, with specific accuracies of 99% for RAF, 100% for BRB, 100% for RBF, and 95% for BBF. A new model interpretability was assessed using explainability techniques, which allowed for the identification of specific learning patterns. This analysis introduces a new approach by demonstrating how different convolutional blocks capture particular features: the first convolutional block captures signal shape, while the second identifies background features. Additionally, distinct convolutional layers were associated with each fault type: layer 9 for RAF, layer 13 for BRB, layer 16 for RBF, and layer 14 for BBF. This methodology offers a scalable solution for predictive maintenance in induction motors, effectively combining signal processing, computer vision, and explainability techniques. Full article

Nowadays, induction motors and gearboxes play an important role in the industry due to the fact that they are indispensable tools that allow a large number of machines to operate. In this research, a diagnosis method is proposed for the detection of different faults in an electromechanical system through infrared thermography and a convolutional neural network (CNN). During the experiment, we tested different conditions in the motor and the gearbox. The induction motor was operated in four conditions, in a healthy state, with one broken bar, a damaged bearing, and misalignment, while the gearbox was operated in three conditions with healthy gears, 50% wear, and 75% wear. The motor failures and gear wear were induced by different machining operations. Data augmentation was then performed using basic transformations such as mirror image and brightness variation. Ablation tests were also carried out, and a convolutional neural network with a basic architecture was proposed; the performance indicators show a precision of 98.53%, accuracy of 98.54%, recall of 98.65%, and F1-Score of 98.55%. The system obtained confirms that through the use of infrared thermography and deep learning, it is possible to identify faults at different points of an electromechanical system. Full article

Bearings are the most vulnerable component in low-voltage induction motors from a maintenance standpoint. Vibration monitoring is the benchmark technique for identifying mechanical faults in rotating machinery, including the diagnosis of bearing defects. The study of different bearing fault phenomena under induction motor transient conditions offers interesting capabilities to enhance classic fault detection techniques. This study analyzes the low-frequency localized bearing fault signatures in both the inner and outer races during the start-up and steady-state operation of inverter-fed and line-started induction motors. For this aim, the classic vibration envelope spectrum technique is explored in the time–frequency domain by using a simple, resampling-free, Short Time Fourier Transform (STFT) and a band-pass filtering stage. The vibration data are acquired in the motor housing in the radial direction for different load points. In addition, two different localized defect sizes are considered to explore the influence of the defect width. The analysis of extracted low-frequency characteristic frequencies conducted in this study demonstrates the feasibility of detecting early-stage localized bearing defects in induction motors across various operating conditions and actuation modes. Full article

This article focuses on the analysis and non-invasive online diagnostics of the operating condition of bearings integrated into three-phase squirrel cage induction motors, an electric machine that, due to its construction and operational characteristics, has a significant presence in the industry. The proposed signal-processing analysis tool is based on the non-invasive monitoring of stator electrical currents. To improve robustness in the diagnosis of bearing faults beyond the state-of-the-art, a hybrid approach was employed. The Short-Time Fourier Transform (STFT) and Park’s Vector Approach (PVA) were combined and applied to the stator currents. This hybridization allowed the benefits of both methods to be combined: (i) proper evaluation of time-varying phenomena and (ii) the ability to distinguish the type of fault affecting the bearing. To demonstrate the feasibility of the approach, comparisons were made between the proposed hybrid technique and both the STFT and the Extended Park’s Vector Approach (EPVA), which have been previously considered in the diagnosis of these and other induction motor faults. The validation of the proposed solution was conducted through computational simulations and laboratory tests, ultimately aiming to generate a database of results to inform future research in this area. To emulate bearing failures in an experimental context, artificial damage to bearing components was introduced. Full article

Three-phase induction motors play a key role in industrial operations. However, their failure can result in serious operational problems. This study focuses on the early identification of faults through the accurate diagnosis and classification of faults in three-phase induction motors using artificial intelligence techniques by analyzing current, temperature, and vibration signals. Experiments were conducted on a test bench, simulating real operating conditions, including stator phase unbalance, bearing damage, and shaft unbalance. To classify the faults, an Auto-Regressive Neural Network with Exogenous Inputs (NARX) was developed. The parameters of this network were determined through a process of selecting the best network by using the scanning method with multiple training and validation iterations with the introduction of new data. The results of these tests showed that the network exhibited excellent generalization across all evaluated situations, achieving the following accuracy rates: motor without fault = $94.2$%, unbalanced fault = 95%, bearings with fault = 98%, and stator with fault = 95%. Full article

Bearings are one of the most essential elements in an induction motor, and they are built with different materials and constructions according to their application. These components are usually one of the most failure-prone parts of an electric motor, so correct and accurate measurements, instrumentation, and processing methods are required to prevent and detect the presence of different failures. This work develops a methodology based on the fusion of current and magnetic stray flux signals, calculation of statistical and non-statistical indicators, genetic algorithms (GAs), linear discriminant analysis (LDA), and neural networks. The proposed approach achieves a diagnostic effectiveness of 99.8% for detecting various damages in the outer race at 50 Hz frequency and 96.6% at 60 Hz. It also demonstrates 99.8% effectiveness for detecting damages in the presence of contaminants in lubrication at 50 Hz and 97% at 60 Hz. These results apply across metallic, ceramic, and hybrid bearings. Full article

Bearings are one of the main components of induction motors, machines widely employed in today’s industries, making their monitoring a primordial task; however, most systems focus on measuring one physical magnitude to detect one kind of fault at a time. This research tackles the combination of two common faults, grease contamination and outer race damage, as lubricant contamination significantly impacts the life of the bearing and the emergence of other defects; as a contribution, this paper proposes a methodology for the diagnosis of this combination of faults based on a proprietary data acquisition system measuring vibration and current signals, from which time domain statistical and fractal features are computed and then fused using LDA for dimensionality reduction, ending with an SVM model for classification, achieving 97.1% accuracy, correctly diagnosing the combination of the contamination with different severities of the outer race damage, improving the classification results achieved when using vibration and current signals individually by 7.8% and 27.2%, respectively. Full article

Currently, great emphasis is being placed on the electrification of means of transportation, including aviation. The use of electric motors reduces operating and maintenance costs. Electric motors are subjected to various types of damage during operation, of which rolling bearing defects are statistically the most common. This article focuses on presenting a diagnostic tool for bearing conditions based on mechanic vibration signals using convolutional neural networks (CNN). This article presents an alternative to the well-known classical diagnostic tools based on advanced signal processing methods such as the short-time Fourier transform, the Hilbert–Huang transform, etc. The approach described in the article provides fault detection and classification in less than 0.03 s. The proposed structures achieved a classification accuracy of 99.8% on the test set. Special attention was paid to the process of optimizing the CNN structure to achieve the highest possible accuracy with the fewest number of network parameters. Full article

Induction motors (IM) play a fundamental role in the industrial sector because they are robust, efficient, and low-cost machines. Changes in the environment, installation errors, or modifications to working conditions can generate faults in induction motors. The trend on IM fault detection is focused on the design techniques and sensors capable of evaluating multiple faults with various signals using non-invasive analysis. The methodology is based on processing electric current signals by applying the short-time Fourier transform (STFT). Additionally, the computation of the mean and standard deviation of infrared thermograms is proposed as main indicators. The proposed system combines both parameters by means of Support Vector Machine and k-nearest-neighbor classifiers. The development of the diagnostic system was done with digital hardware implementations using a Xilinx PYNQ Z2 card that integrates an FPGA with a microprocessor, thus taking advantage of the acquisition and processing of digital signals and images in hardware. The proposed method has proved to be effective for the classification of healthy (HLT), misalignment (MAMT), unbalance (UNB), damaged bearing (BDF), and broken rotor bar (BRB) faults with an accuracy close to 99%. Full article

The induction motors found in industrial and commercial applications are responsible for most of the energy consumption in the world. These machines are widely used because of their advantages like high efficiency, robustness, and practicality; nevertheless, the occurrence of unexpected faults may affect their proper operation leading to unnecessary breakdowns with economic repercussions. For that reason, the development of methodologies that ensure their proper operation is very important, and in this sense, this paper presents an evaluation of signal entropy as an alternative fault-related feature for detecting faults in induction motors and their kinematic chain. The novelty and contribution lie in calculating a set of entropy-related features from vibration and stator current signals measured from an induction motor operating under different fault conditions. The aim of this work is to identify changes and trends in entropy-related features produced by faulty conditions such as broken rotor bars, damage in bearings, misalignment, unbalance, as well as different severities of uniform wear in gearboxes. The estimated entropy-related features are compared to other classical features in order to determine the sensitivity and potentiality of entropy in providing valuable information that could be useful in future work for developing a complete methodology for identifying and classifying faults. The performed analysis is applied to real experimental data acquired from a laboratory test bench and the obtained results depict that entropy-related features can provide significant information related to particular faults in induction motors and their kinematic chain. Full article
