Search Results (15)

The present research uses in-situ neutron diffraction to examine the effect of grain refinement on grain growth during solidification of Al-5 wt.% Cu and Mg-5 wt.% Zn alloys. The alloys were grain refined through additions of Al-5Ti-1B and Zr, respectively. The in-situ neutron diffraction experiments were carried out by heating the alloys to temperatures above the liquidus and subsequently cooling in 5 or 10 °C temperature steps to temperatures below solidus, while being irradiated by thermal neutrons. With the addition of grain refiners, grain size reductions of 92% were observed for both the Al-5 wt.% Cu and Mg-5 wt.% Zn alloys. The refined and unrefined Al-5 wt.% Cu alloys contained α-Al with Al₂Cu along the grain boundary regions. Differences in Al₂Cu morphology were observed in the grain refined alloys. The Mg-5 wt.% Zn alloy contained MgZn intermetallic phases with primary Mg. The refined Mg-5 wt.% Zn-0.7 wt.% Zr alloy contained Mg, MgZn and Zn₂Zr phases. In-situ neutron diffraction enabled quantification of individual plane solid fraction growth for the α-Al and Al₂Cu phases in the Al-Cu alloys, and for α-Mg in the Mg alloys. For the unrefined Al-5 wt.% Cu, the coarse microstructure resulted in a rapid solid fraction rise at temperatures just below liquidus followed by a gradual increase in solid fraction until the sample was fully solid. The grain-refined Al-5 wt.% Cu alloys showed a columnar to equiaxed microstructure transition and a more gradual growth in fraction solid throughout solidification. For the Mg-5 wt.% Zn alloy, the more packed $\left(0002\right)$ and $\left(10\overline{1}1\right)$ α-Mg plane intensities grew at a slower rate than the $\left(10\overline{1}0\right)$ plane intensity, resulting in an irregular grain structure. With the addition of the Zr grain refiner, the Mg-5 wt.% Zn-0.7 wt.% Zr alloy had $\left(10\overline{1}0\right)$, $\left(0002\right)$ and $\left(10\overline{1}1\right)$ planes intensities all increasing at similar rates, especially at the early stages of solidification. FactSage™ (version 6.4, Montréal, QC, Canada) equilibrium solidification models followed the fraction solid curves developed by tracking the fastest growing planes of the Mg alloys. Full article

Hot working tool steel (AISI H13) is one of the most common die materials used in casting industries. A die suffers from damage due to friction and wear during its lifetime. Therefore, various methods have been developed for its repair to save costs to manufacture a new one. A great benefit of laser additive manufacturing (cladding) is the 3D high production rate with minimal influence of thermal stresses in comparison with conventional arc methods. Residual stresses are important factors that influence the performance of the product, especially fatigue life. Therefore, the aim of this contribution is to correlate the wide range of results for multilayer cladding of H13 tool steel. X-ray and neutron diffraction experiments were performed to fully describe the residual stresses generated during cladding. Additionally, in-situ tensile testing experiments inside a scanning electron microscope were performed to observe microstructural changes during deformation. The results were compared with local hardness and wear measurements. Because laser cladding does not achieve adequate accuracy, the effect of necessary post-grinding was investigated. According to the findings, the overlapping of beads and their mutual tempering significantly affect the mechanical properties. Further, the outer surface layer, which showed tensile surface residual stresses and cracks, was removed by grinding and surface compressive residual stresses were described on the ground surface. Full article

The present work extends the examination of selective laser melting (SLM)-fabricated 15-5 PH steel with the 8%-transient-austenite-phase towards fully-reversed strain-controlled low-cycle fatigue (LCF) test. The cyclic-deformation response and microstructural evolution were investigated via in-situ neutron-diffraction measurements. The transient-austenite-phase rapidly transformed into the martensite phase in the initial cyclic-hardening stage, followed by an almost complete martensitic transformation in the cyclic-softening and steady stage. The compressive stress was much greater than the tensile stress at the same strain amplitude. The enhanced martensitic transformation associated with lower dislocation densities under compression predominantly governed such a striking tension-compression asymmetry in the SLM-built 15-5 PH. Full article

Slip and extension twinning are the dominant deformation mechanisms in Magnesium (Mg) and its alloys. Crystal plasticity is a powerful tool to study these deformation mechanisms. Different schemes have incorporated crystal plasticity models to capture different properties, which vary from the simple homogenization Taylor model to the full-scale crystal plasticity finite element model. In the current study, a review of works available in the literature that addresses different properties of Mg and its alloys using crystal plasticity modes is presented. In addition to slip and twinning, detwinning is another deformation mechanism that is activated in Mg and its alloys. The different models that capture detwinning will also be addressed here. Finally, the recent experimental frameworks, such as in-situ neutron diffraction, 3D high energy synchrotron X-ray techniques, and digital image correlation under scanning electron microscopy (SEM-DIC), which are incorporated along crystal plasticity models to investigate the properties of Mg and its alloys, are addressed. Future research directions towards improving the deformation response of Mg and its alloys are identified, which can lead to increased deployment of the lightest structural metal in engineering applications. Full article

The phase transformation to ausferrite during austempered ductile iron (ADI) heat treatment can be significantly influenced by the alloying element Mo. Utilizing neutron diffraction, the phase transformation from austenite to ausferrite was monitored in-situ during the heat treatment. In addition to the phase volume fractions, the carbon enrichment of retained austenite was investigated. The results from neutron diffraction were compared to the macroscopic length change from dilatometer measurements. They show that the dilatometer data are only of limited use for the investigation of ausferrite formation. However, they allow deriving the time of maximum carbon accumulation in the retained austenite. In addition, the transformation of austenite during ausferritization was investigated using metallographic methods. Finally, the distribution of the alloying elements in the vicinity of the austenite/ferrite interface zone was shown by atom probe tomography (APT) measurements. C and Mn were enriched within the interface, while Si concentration was reduced. The Mo concentration in ferrite, interface and austentite stayed at the same level. The delay of austenite decay during Stage II reaction caused by Mo was studied in detail at 400 °C for the initial material as well as for 0.25 mass % and 0.50 mass % Mo additions. Full article

Residual stress can be easily generated during material processing and affect the performance of structural components. Phase stress distribution in austenitic-ferritic duplex stainless steels (DSSs) is complicated due to the different material properties between the two phases. In this study, residual phase stress distribution along the thickness direction of centrifugally cast DSS hollow cylinder was measured by pulsed neutron diffraction with the time-of-flight (TOF) method. The triaxial phase stress distribution along the thickness direction shows that the phase stress of austenitic phase is generally in tension and higher than that of ferrite phase. From the outer surface to the inner surface, the macro-stress distributes from −400 MPa to 200 MPa. The mechanism of macro-stress formation was deduced by taking into consideration the thermal shrinkage behavior during the cooling process of water quench after the solution heat treatment. Furthermore, the lattice strain and phase stress evolution under the uniaxial tensile loading was evaluated by in-situ neutron diffraction measurement. The results indicated that the magnitude of phase stress could be affected by plastic working as well. All these measurements were conducted at Japan Proton Accelerator Research Complex (J-PARC). Full article

According to Eshelby’s theory, inelastically inhomogeneous inclusions in a metallic matrix give rise to a distribution of internal stresses. In the case of particle strengthened materials, such as nickel base superalloys, the presence and evolution of this back-stress leads to various observable effects, such as primary creep, back-flow upon loading, and memory of prior deformation. This article presents the background of the concept of back-stress and how it applies to the scenario of creep. A derivation of an evolution equation for back-stress in the context of primary creep is also presented. The results from neutron diffraction with in-situ creep experiments on directionally solidified nickel superalloys are presented in order to demonstrate the validity of the proposed equation and the corollaries derived therefrom. Full article

The transformation induced plasticity (TRIP) effect is investigated during a load path change using a cruciform sample. The transformation properties are followed by in-situ neutron diffraction derived from the central area of the cruciform sample. Additionally, the spatial distribution of the TRIP effect triggered by stress concentrations is visualized using neutron Bragg edge imaging including, e.g., weak positions of the cruciform geometry. The results demonstrate that neutron diffraction contrast imaging offers the possibility to capture the TRIP effect in objects with complex geometries under complex stress states. Full article

An equal-molar CoCrFeMnNi, face-centered-cubic (fcc) high-entropy alloy (HEA) and a nickel-based superalloy are studied using in situ neutron diffraction experiments. With continuous measurements, the evolution of diffraction peaks is collected for microscopic lattice strain analyses. Cyclic hardening and softening are found in both metallic systems. However, as obtained from the diffraction-peak-width evolution, the underneath deformation mechanisms are quite different. The CoCrFeMnNi HEA exhibits distinct lattice strain and microstructure responses under tension-compression cyclic loadings. Full article

Neutron diffraction experiments with both conventional powder diffraction setup and under in-situ compressive loading were conducted to investigate the structural origins of large strength and toughness enhancements in Ti-16Al-27Nb alloy after Er addition. The primary phase is determined to be the ordered B₂ structure form, in agreement with the previous electron microscopy study. Lattice strains of {210} and {100} planes were measured as a function of applied stress, and elastic anisotropy was found for both, and strong plastic nonlinearity was discovered for (210) reflection. The grain refinement during plastic deformation was proposed by both the 2D diffraction intensity distribution and SEM observations, while stress-induced martensitic phase transition was not observed in this study. It is believed that the activation of different slip systems and grain refinement might be the structural origin of the novel mechanical properties of this alloy. Full article

In situ neutron diffraction of the uniaxial tension test was used to study the effect of the surrounding matrix microstructure on the mechanical stability of retained austenite in high-carbon bearing steels. Comparing the samples with bainitic microstructures to those with martensitic ones, it was found that the retained austenite in a bainitic matrix starts transforming into martensite at a lower strain compared to that within a martensitic matrix. On the other hand, the rate of transformation of the austenite was found to be higher within a martensitic microstructure. Crystal plasticity modeling was used to analyze the transformation phenomenon in these two microstructures and determine the effect of the surrounding microstructure on elastic, plastic, and transformation components of the strain. The results showed that the predominant difference in the deformation accumulated was from the transformation strain and the critical transformation driving force within the two microstructures. The retained austenite was more stable for identical loading conditions in case of martensitic matrix compared to the bainitic one. It was also observed that the initial volume fraction of retained austenite within the bainitic matrix would alter the onset of transformation to martensite, but not the rate of transformation. Full article

The time-of-flight neutron diffraction data collected in-situ on Oak Ridge National Laboratory’s (ORNL, Oak Ridge, TN, USA) VULCAN and Los Alamos National Laboratory’s (LANL, Los Alamos, NM, USA) High-Pressure-Preferred-Orientation (HIPPO) diffractometers have been analyzed complementarily to show the texture evolution during annealing of a cold-rolled Al-2%Mg alloy. The texture analysis aimed to identify the components present in the initial rolling (or deformation) texture and in the thermally-activated recrystallization texture, respectively. Using a quasi-Monte-Carlo (QMC) approach, a new method has been developed to simulate the weighted texture components, and to obtain inverse pole figures for both rolling and normal directions. As such, distinct recrystallization pathways during annealing in isochronal conditions, can be revealed in terms of the evolution of the texture components and their respective volume fractions. Moreover, the recrystallization kinetics associated with the cube and random texture components are analyzed quantitatively using a similar approach developed for differential scanning calorimetry (DSC). Full article

Boron largely increases the ductility of polycrystalline high-temperature Co–Re–Cr alloys. Therefore, the effect of boron addition on the alloy structural characteristics is of large importance for the stability of the alloy at operational temperatures. Along with the Co-solid solution matrix phase transformation from hcp to fcc structure, additional structural effects were observed in situ at very high temperatures (up to 1500 °C) using neutron diffraction (ND) in boron-containing Co–17Re–23Cr alloys. Increasing boron content up to 1000 wt. ppm lowers the temperature at which sublimation of Co and Cr from the matrix occurs. As a result, the composition of the matrix in the surface region is changed leading to the formation of a second and a third matrix hcp phases at high temperatures. The consideration on the lattice parameter dependence on composition was used to identify the new phases appearing at high temperatures. Energy-dispersive spectroscopy and ND results were used to estimate the amount of Co and Cr which sublimated from the surface region of the high-boron sample. In the sense of alloy development, the sublimation of Co and Cr is not critical as the temperature range where it is observed (≥1430 °C) is significantly above the foreseen operation temperature of the alloys (1200 °C). Full article

Twin roll casting (TRC), with a relatively fast solidification rate, is an excellent production method with promising potential for producing wrought semi or final Mg alloy products that can often suffer from poor formability. We investigate in this study the effect of the TRC method and the subsequent heat treatment on the microstructure and deformation mechanisms in Mg-Zn-Zr-Nd alloy deformed at room temperature using the in-situ neutron diffraction and acoustic emission techniques and ex-situ texture measurement and microscopy, respectively. Although a higher work hardening is observed in the rolling direction due to the more intensive <a>-type dislocation activity, the difference in the mechanical properties of the specimens deformed in the RD and TD directions is small in the as-rolled condition. An additional heat treatment results in recrystallization and significant anisotropy in the deformation. Due to the easier activation of the extension twinning in the TD given by texture, the yield stress in the TD is approximately 40% lower than that in the RD. Full article

In the aim to stabilize novel three-dimensional perovskite oxides based upon SrCoO_3−δ, we have designed and prepared SrCo_1−xRe_xO_3−δ phases (x = 0.05 and 0.10), successfully avoiding the competitive hexagonal 2H polytypes. Their performance as cathode materials in intermediate-temperature solid oxide fuel cells (IT-SOFC) has been investigated. The characterization of these oxides included X-ray (XRD) and in situ temperature-dependent neutron powder diffraction (NPD) experiments for x = 0.10. At room temperature, SrCo_1−xRe_xO_3−δ perovskites are defined in the P4/mmm space group, which corresponds to a subtle tetragonal perovskite superstructure with unit-cell parameters a = b ≈ a_o, c = 2a_o (a_o = 3.861 and 3.868 Å, for x = 0.05 and 0.10, respectively). The crystal structure evolves above 380 °C to a simple cubic perovskite unit cell, as observed from in-situ NPD data. The electrical conductivity gave maximum values of 43.5 S·cm⁻¹ and 51.6 S·cm⁻¹ for x = 0.05 and x = 0.10, respectively, at 850 °C. The area specific resistance (ASR) polarization resistance determined in symmetrical cells is as low as 0.087 Ω·cm² and 0.065 Ω·cm² for x = 0.05 and x = 0.10, respectively, at 850 °C. In single test cells these materials generated a maximum power of around 0.6 W/cm² at 850 °C with pure H₂ as a fuel, in an electrolyte-supported configuration with La_0.8Sr_0.2Ga_0.83Mg_0.17O_3−δ (LSGM) as the electrolyte. Therefore, we propose the SrCo_1−xRe_xO_3−δ (x = 0.10 and 0.05) perovskite oxides as promising candidates for cathodes in IT-SOFC. Full article
