Ice loads continue to pose challenges to the structural safety of offshore wind turbines (OWTs), while the rapid development of offshore wind power in cold regions is enabling the deployment of OWTs in deeper waters. To accurately simulate the dynamic response of an OWT under combined ice–wind loading, this paper proposes a Discrete Element Method–Wind Turbine Integrated Analysis (DEM-WTIA) framework. The framework can synchronously simulate discontinuous ice-crushing processes and aeroelastic–structural dynamic responses through a holistic turbine model that incorporates rotor dynamics and control systems. To address the issue of insufficient prediction accuracy for dynamic responses, we introduced a multivariate time series forecasting method that integrates a secondary decomposition strategy with a hybrid prediction model. First, we developed a parallel signal processing mechanism, termed Adaptive Complete Ensemble Empirical Mode Decomposition with Improved Singular Spectrum Analysis (CEEMDAN-ISSA), which achieves adaptive denoising via permutation entropy-driven dynamic window optimization and multi-feature fusion-based anomaly detection, yielding a noise suppression rate of 76.4%. Furthermore, we propose the F-Transformer prediction model, which incorporates a Frequency-Enhanced Channel Attention Mechanism (FECAM). By integrating the Discrete Cosine Transform (DCT) into the Transformer architecture, the F-Transformer mines hidden features in the frequency domain, capturing potential periodicities in discontinuous data. Experimental results demonstrate that signals processed by ISSA exhibit increased signal-to-noise ratios and enhanced fidelity. The F-Transformer achieves a maximum reduction of 31.86% in mean squared error compared to the standard Transformer and maintains a coefficient of determination (R²) above 0.91 under multi-condition coupled testing. By combining adaptive decomposition and frequency-domain enhancement techniques, this framework provides a precise and highly adaptable ultra-short-term response forecasting tool for the safe operation and maintenance of offshore wind power in cold regions. Full article

Scour at offshore wind turbine foundations compromises their structural stability. This study investigates scour characteristics and their impact on the ultimate bearing capacity of a novel Monopile-Gravity-Bucket (MGB) hybrid foundation. Utilizing coupled CFD-DEM and finite element analyses, this research examines scour development under varying bucket geometries. Results reveal similar scour morphology as other large diameter structures, with maximum scour depth decreasing as the bucket’s diameter and height increase. The consequent reduction in lateral bearing capacity can reach approximately 20%. These findings provide critical insights for optimizing MGB foundation design and implementing effective scour protection strategies. Full article

As the demand for new sustainable solutions for harvesting energy increases, the offshore energy sector focuses on optimising well-established state-of-the-art solutions while striving for new innovative approaches. Hybrid foundation designs have introduced new challenges and raised questions regarding scour and effective countermeasures. To further improve the knowledge regarding scour prediction, this paper presents and analyses the results from an experimental study behaviour of a riprap protection system for a monopile that determines and characterises scour on a flexible arrangement of overlapping sub-areas. The study was complemented by a novel series of tests using a hybrid foundation, where an oscillating surge wave energy converter (OSWEC) type was coupled to the monopile. Despite being submitted to similar hydrodynamic conditions, distinct differences in the scour rate and damage number (S_3D) were observed for both models. Although the OSWEC type contributed to local wave height attenuation (up to a 30% reduction on the leeward side of the hybrid monopile), its oscillatory motion severely aggravated scour, with measured damage rates two to three times higher than those observed in isolated monopiles. These results raise relevant questions about the applicability of existing design formulas for scour protection and underscore the necessity for revised criteria tailored to hybrid offshore foundations. Full article

Offshore wind turbines serve as critical infrastructure components in marine renewable energy systems, enabling sustainable energy extraction within offshore engineering frameworks. Monopile foundations for offshore wind turbines in deep-water environments are subjected to strong nonlinear wave actions. This study introduces a novel composite monopile foundation specifically designed for deep-sea applications, with its fully nonlinear hydrodynamic performance systematically investigated using potential flow theory. The novel hybrid monopile incorporates a concrete-filled double-skin steel tubular (CFDST) configuration to reduce pile diameter at water level. In the numerical model, the higher-order boundary element method (HOBEM) is implemented to resolve boundary value problems at each temporal iteration. Following numerical validation, nonlinear wave loading and run-up characteristics for the CFDST hybrid structure are quantified, while the limitations of Morison’s equation for large-scale structures under strongly nonlinear wave conditions are concurrently assessed. Results indicate that CFDST implementation effectively attenuates both nonlinear hydrodynamic forces and wave run-up amplitudes, enabling safer and more economical design approaches for deep-water offshore wind turbine foundations. Full article

Large-diameter monopiles that can safely support the lateral loads caused by wind and waves have been widely used for the foundations of offshore wind turbines. However, when the penetration depth is insufficient as a result of the presence of thick soft ground or it is difficult to penetrate rock, the lateral load capacity of the monopiles may be insufficient, leading to structural instability of the wind turbine system. To address this problem, hybrid monopiles have been proposed, which include appendages such as suction buckets attached around the monopiles installed on the seabed. Such suction buckets are arranged in the form of a tripod at 120° intervals with respect to the center of the monopile. These increase the bending resistance of the monopile by sharing the lateral load applied to it. Although the proposed monopiles were presented as conceptual foundation types, their actual support mechanisms and bearing capacity improvement effects must be verified experimentally. In this study, a centrifuge model test was conducted to identify the support mechanism of hybrid monopiles and the degree of improvement in their bearing capacity compared to the existing large-diameter monopiles. The experiment results showed that an appendage composed of suction buckets dispersed the load acting on the monopile, thereby significantly increasing its bearing capacity. Full article

A monopile is the most conventional structure foundation for offshore wind turbines (OWTs) in the world. However, the Korean offshore wind industry has mostly been using the jacket type of foundation. The main reason for the current situation in Korea is that most of the marine soil consists of weak layers of sand and clay. Thus, the monopile foundation depth has to be deep enough to satisfy the intended serviceability design requirement of the monopile and the rotation limit at the seabed; a conventional monopile design concept alone might be insufficient in Korean offshore conditions, or otherwise could be very expensive, e.g., resulting in a rock socket installation at the tip of the monopile. The main objective of this paper is to introduce a novel hybrid monopile that is composed of a monopile and a supplemental support with three buckets, followed by assessing the lateral resistance of the hybrid system through physical experiments and finite element (FE) simulations. Namely, 1/64.5 small-scaled monopile and hybrid physical models with a monopile diameter of 7 m for a 5.5 MW OWT were loaded monotonically. The results show that the hybrid monopile improves the lateral bearing capacity regarding the initial lateral stiffness and ultimate load. The FE analyses of the corresponding physical models were also implemented to support the results from the physical model test. The numerical results, such as the structural member forces and soil deformation, were analyzed in detail. Additionally, a case study using FE analysis was conducted for the 5.5 MW OWT hybrid monopile support installed in a representative Korean weak soil area. The results show that the hybrid monopile foundation has a larger lateral resistance and stiffness than the monopile. Full article

Pile foundations for offshore wind turbines are subjected to large lateral loads. By mounting wings on the perimeter of regular monopiles, winged monopiles have shown better performance in resisting deformation under horizontal loading. However, the hazardous effect of local scour on the lateral bearing capacity of winged monopiles installed in the sandy seabed has not been systematically evaluated. In this study, a modified Mohr–Coulomb model considering the pre-peak hardening and post-peak softening behavior of dense sand is adopted to simulate laterally loaded winged monopiles in the locally scoured sandy seabed, using three-dimensional finite element analyses. The effect of local scour depth on the lateral capacity of winged monopiles is examined and explained by soil failure mechanisms. The enhancement of lateral capacity with wings attached to the monopile is demonstrated to be more effective than extending pile embedment length. The effects of the relative density of sand and the wing load orientation are also discussed. Finally, the wing efficiency is evaluated to determine the optimal configuration of winged monopiles. Full article

This paper aims to design an integrated offshore structure capable of supporting a hybrid assembly of one wind plus two tidal turbines. The monopile has been found to be a suitable foundation type as the most inexpensive solution in water depths of less than 30 m. The Cook Strait in New Zealand is an ideal location for wind and tidal renewable energy sources due to its strong winds and tidal currents. Finite element analysis was performed to determine the displacement of the structure for different types of soils using OPTUM G3. After that, a macro-element model for soil was represented, considering the monopile as a Euler–Bernoulli beam model. The results enable the finding of optimum dimensions of monopiles with allowable tilt and deflection. Based on this, the diameter, thickness, and length of the monopile can be 6, 0.083, and 60 m, respectively. The maximum load occurs in extreme wind load scenarios when wind and waves move in same direction. Full article

Offshore installations with pile foundations in shallow water are vulnerable to submarine landslides, which cause serious damage to engineering facilities, loss of life, and loss of money. Due to a shortage of real observation data and the difficulty of reproduction, we lack insight into the interaction behavior between submarine landslides and monopiles. This study capitalized on ANSYS Fluent 20.0 to develop a three-dimensional biphasic (water and slurry) numerical model. This CFD model was used to analyze the interaction between a monopile and submarine landslides at different flow heights. The velocities of submarine landslides were from low to high values. Two modes of interactional forces acting on the monopile are proposed, which are (i) interaction force with peak value and (ii) interaction force without peak value. The influence of flow height and velocity on interaction forces was investigated. Results show that the effect of the flow heights on the interaction force is significant at low velocity stage, while the peak force representing a hazard level of the pile was non-negligible under high flow velocity and low flow height conditions, which should be considered in a future study. The related mechanisms are revealed with a hybrid model considering different components of the force. Full article

Today’s offshore wind turbine support structures market is largely dominated by steel structures, since steel monopiles account for the vast majority of installations in the last decade and new types of multi-leg steel structures have been developed in recent years. However, as wind turbines become bigger, and potential sites for offshore wind farms are located in ever deeper waters and ever further from the shore, the conditions for the design, transport, and installation of support structures are changing. In light of these facts, this paper identifies and categorizes the challenges and future trends related to the use of concrete for support structures of future offshore wind projects. To do so, recent advances and technologies still under development for both bottom-fixed and floating concrete support structures have been reviewed. It was found that these new developments meet the challenges associated with the use of concrete support structures, as they will allow the production costs to be lowered and transport and installation to be facilitated. New technologies for concrete support structures used at medium and great water depths are also being developed and are expected to become more common in future offshore wind installations. Therefore, the new developments identified in this paper show the likelihood of an increase in the use of concrete support structures in future offshore wind farms. These developments also indicate that the complexity of future support structures will increase due to the development of hybrid structures combining steel and concrete. These evolutions call for new knowledge and technical know-how in order to allow reliable structures to be built and risk-free offshore installation to be executed. Full article

In this paper, we investigate, in the frequency domain, the performance (hydrodynamic behavior and power absorption) of a circular array of four semi-immersed heaving Wave Energy Converters (WECs) around a hybrid wind–wave monopile (circular cylinder). The diffraction/radiation problem is solved by deploying the conventional boundary integral equation method. Oblate-spheroidal and hemispherical-shaped WECs are considered. For each geometry, we assess the effect of the array’s net radial distance from the monopile and of the incident wave direction on the array’s performance under regular waves. The results illustrate that by placing the oblate spheroidal WECs close to the monopile, the array’s power absorption ability is enhanced in the low frequency range, while the opposite occurs for higher wave frequencies. For hemispherical-shaped WECs, the array’s power absorption ability is improved when the devices are situated close to the monopile. The action of oblique waves, with respect to the WECs’ arrangement, increases the absorbed power in the case of oblate spheroidal WECs, while these WECs show the best power absorption ability among the two examined geometries. Finally, for the most efficient array configuration, consisting of oblate spheroidal WECs situated close to the monopile, we utilize an “active” Power Take-Off (PTO) mechanism, facilitating the consideration of a variable with frequency PTO damping coefficient. By deploying this mechanism, the power absorption ability of the array is significantly enhanced under both regular and irregular waves. Full article

In Europe, which has been operating offshore wind farms well ahead of South Korea, most offshore wind turbines installed in shallow waters are suffering from severe scouring problems due to the horseshoe vortex. These operating experiences can serve as a valuable lesson for Korea. After a thorough review, we conclude that the horseshoe vortex’s intensity is proportional to the height of the standing waves near an offshore wind turbine. Based on this rationale, we propose a hybrid mono-pile, which is a mono-pile with an additional light turbine mounted at its toe that can dissipate the incoming wave energy with the rotation that occurs when the turbine is exposed to incoming waves or currents. The weakened standing waves in this manner would lead to less sediment transport. We proceeded to carry out the numerical simulation to verify the scouring control effect of the hybrid mono-pile. Numerical results show that the hybrid mono-pile could reduce scouring remarkably. Full article
