Search Results (46)

This paper presents the design and evaluation of a novel soft pneumatic actuator featuring two independent bending chambers, enabling independent joint actuation and localization for rehabilitation purposes. The actuator’s dual-chamber configuration provides flexibility for applications requiring customized bending profiles. To measure the bending angle of the finger joints in real time, a camera-based system is employed, utilizing a deep learning detection model to localize the joints and estimate their bending angles. This approach provides a non-intrusive, sensor-free alternative to hardware-based measurement methods, reducing complexity and wiring typically associated with wearable devices. Experimental results demonstrate the effectiveness of the proposed actuator in achieving bending angles of 105 degrees for the metacarpophalangeal (MCP) joint and 95 degrees for the proximal interphalangeal (PIP) joint, as well as a gripping force of 9.3 N. The vision system also captures bending angles with a precision of 98%, indicating potential applications in fields such as rehabilitation and human–robot interaction. Full article

Pneumatic soft manipulators are one of the current development trends in the field of manipulators. The soft manipulator that has been developed at present still has problems with single function and poor load-bearing capacity. This paper designs a composite soft finger inspired by the human middle finger, featuring a dual-chamber pneumatic drive and embedded steel sheet structure. Utilizing the principles of moment equilibrium and virtual work, a theoretical model for the bending behavior of the soft finger is developed, and the correlation between the bending angle and driving air pressure is derived. The determination process of key parameters and their influence on bending deformation are explained in detail through simulation. The bending experiment confirmed the reliability of the theoretical model. The fingertip force test indicates that the composite finger exerts a greater force than the ordinary one, with the extra force equivalent to 42.57% of the composite finger’s own fingertip force. Subsequent tests on the soft robotic hand measured the hooking quality, gripping diameter, and gripping force. The hooking experiment confirmed that composite fingers have a stronger load-bearing capacity than ordinary fingers, with an extra capacity equivalent to 31.25% of the composite finger’s own load-bearing capacity. Finally, the grasping experiment demonstrates that the soft manipulator can grasp objects of varying shapes and weights, indicating its strong adaptability and promising applications. Full article

Background: Lepidium meyenii Walp. (LmW), known as maca, has been shown to increase physical performance. However, the effect size (ES) of LmW on the different manifestations of physical performance has not yet been described. Objectives: To examine and qualitatively describe the studies published up to 2024 that employed LmW supplementation to increase physical performance in animal and human experimentation. In addition, the ES associated with the different interventions was calculated. Methods: The research followed PRISMA^® guidelines for systematic reviews and meta-analyses, using Web of Science, Scopus, SPORTDiscus, PubMed, and MEDLINE databases until 2024. Randomized controlled studies with a pre- and post-test design, conducted both in vitro and in vivo in animals and humans, were included. Methodological quality assessment was performed using the CAMARADES tool for animal studies and the Newcastle Ottawa Scale for human studies. The main variables were the forced swimming test (FST), the rota-rod test (RRT), the grip strength test (GST), blood lactic acid (BLA), and lactic acid (LA). The analysis was conducted with a pooled standardized mean difference (SMD) through Hedges’ g test (95% CI). Results: Twenty-one studies were included in the systematic review and sixteen in the meta-analysis. They revealed a large effect for all outcomes (SMD: FST = 2.26, RRT = 6.26, GST = 5.23, LA = −1.01, and BLA = −1.70). Conclusions: The phytochemical compounds of LmW, mainly macamides, increase physical performance, showing a greater effect at higher doses (dose–response effect). Full article

This study aimed to predict and fit the nonlinear dynamic grip force of the human upper limb using surface electromyographic (sEMG) signals. The research employed a time-series-based neural network, NARX, to establish a mapping relationship between the electromyographic signals of the forearm muscle groups and dynamic grip force. Three-channel electromyographic signal acquisition equipment and a grip force sensor were used to record muscle signals and grip force data of the subjects under specific dynamic force conditions. After preprocessing the data, including outlier removal, wavelet denoising, and baseline drift correction, the NARX model was used for fitting analysis. The model compares two different training strategies: regularized stochastic gradient descent (BRSGD) and conjugate gradient (CG). The results show that the CG greatly shortened the training time, and performance did not decline. NARX demonstrated good accuracy and stability in dynamic grip force prediction, with the model with 10 layers and 20 time delays performing the best. The results demonstrate that the proposed method has potential practical significance for force control applications in smart prosthetics and virtual reality. Full article

Overuse injury is a frequent diagnosis in occupational medicine and athletics. Using an established model of upper extremity overuse, we sought to characterize changes occurring in the forepaws and forelimbs of mature female rats (14–18 months of age). Thirty-three rats underwent a 4-week shaping period, before performing a high-repetition low-force (HRLF) task for 12 weeks, with the results being compared to 32 mature controls. HRLF animals showed a reduced grip strength versus controls. ELISAs carried out in the HRLF rats, versus controls, showed elevated levels of IL1-α in tendons, IL1-α and TNF-α in distal bones/entheses, and TNF-α, MIP1-α/CCL3, and CINC-2/CXCL-3 in serum, as well as IL-6 in forelimb muscles and tendons, and IL-10 in serum. HRLF rats had elevated collagen deposition in the forepaw intrinsic muscles (i.e., fibrosis), entheseal microdamage, and articular cartilage degradation versus the control rats. CD68/ED1+ osteoclasts and single-nucleated cells were elevated in distal forelimb metaphyses of the HRLF animals, versus controls. Declines in grip strength correlated with muscle fibrosis, entheseal microdamage, articular cartilage damage, distal bone/enthesis IL1-α, and serum IL-6. These data demonstrate inflammatory and persistent degradative changes in the forearm/forepaw tissues of mature female animals exposed to prolonged repetitive tasks, changes with clinical relevance to work-related overuse injuries in mature human females. Full article

Background/Objectives: Amyotrophic lateral sclerosis (ALS) is a progressive and irreversible neurodegenerative disease with limited treatment options. Advances in regenerative medicine have opened up new treatment options. The primary and exploratory objectives of this retrospective cohort study were to evaluate the safety and efficacy of stem cells from human exfoliated deciduous teeth-conditioned media (SHED-CM). Methods: Safety assessments included adverse events, vital signs, and laboratory test changes before and after administration, and efficacy was measured using the ALS Functional Rating Scale-Revised (ALSFRS-R), grip strength, and forced vital capacity in 24 patients with ALS treated at a single facility between 1 January 2022, and 30 November 2023. Results: While ALSFRS-R scores typically decline over time, the progression rate in this cohort was slower, suggesting a potential delay in disease progression. Alternatively, improvements in muscle strength and mobility were observed in some patients. Although adverse events were reported in only 3% of cases (no serious allergic reactions), the treatment-induced changes in vital signs and laboratory results were not clinically significant. Conclusions: The SHED-CM treatment is a safe and potentially effective therapeutic option for patients with ALS. Further research is needed to optimize the SHED-CM treatment; however, this study lays the groundwork for future exploration of regenerative therapies for ALS. Full article

Muscles play an indispensable role in human life. Surface electromyography (sEMG), as a non-invasive method, is crucial for monitoring muscle status. It is characterized by its real-time, portable nature and is extensively utilized in sports and rehabilitation sciences. This study proposed a wireless acquisition system based on multi-channel sEMG for objective monitoring of grip force. The system consists of an sEMG acquisition module containing four-channel discrete terminals and a host computer receiver module, using Bluetooth wireless transmission. The system is portable, wearable, low-cost, and easy to operate. Leveraging the system, an experiment for grip force prediction was designed, employing the bald eagle search (BES) algorithm to enhance the Random Forest (RF) algorithm. This approach established a grip force prediction model based on dual-channel sEMG signals. As tested, the performance of acquisition terminal proceeded as follows: the gain was up to 1125 times, and the common mode rejection ratio (CMRR) remained high in the sEMG signal band range (96.94 dB (100 Hz), 84.12 dB (500 Hz)), while the performance of the grip force prediction algorithm had an R² of 0.9215, an MAE of 1.0637, and an MSE of 1.7479. The proposed system demonstrates excellent performance in real-time signal acquisition and grip force prediction, proving to be an effective muscle status monitoring tool for rehabilitation, training, disease condition surveillance and scientific fitness applications. Full article

The study of bio-inspired structures and their reproduction has always fascinated humans. The advent of soft robotics, thanks to soft materials, has enabled considerable progress in this field. Over the years, polyps, worms, cockroaches, jellyfish, and multiple anthropomorphic structures such as hands or limbs have been reproduced. These structures have often been used for gripping and handling delicate objects or those with complex unknown a priori shapes. Several studies have also been conducted on grippers inspired by the seahorse tail. In this paper, a novel biomimetic soft pneumatic actuator inspired by the tail of the seahorse Hippocampus reidi is presented. The actuator has been developed to make a leg to sustain a multi-legged robot. The prototyping of the actuator was possible by combining a 3D-printed reinforcement in thermoplastic polyurethane, mimicking the skeletal apparatus, within a silicone rubber structure, replicating the functions of the external epithelial tissue. The latter has an internal channel for pneumatic actuation that acts as the inner muscle. The study on the anatomy and kinematic behaviour of the seahorse tail suggested the mechanical design of the actuator. Through a test campaign, the actuator prototype was characterized by isotonic tests with an external null load, isometric tests, and activation/deactivation times. Specifically, the full actuator distension of 154.5 mm occurs at 1.8 bar, exerting a maximum force of 11.9 N, with an activation and deactivation time of 74.9 and 94.5 ms, respectively. Full article

Adapting grasp-specialized biomechanical structures into current research with 3D-printed prostheses may improve robotic dexterity in grasping a wider variety of objects. Claw variations across various bird species lend biomechanical advantages for grasping motions related to perching, climbing, and hunting. Designs inspired by bird claws provide improvements beyond a human-inspired structure for specific grasping applications to offer a solution for mitigating a cause of the high rejection rate for upper-limb prostheses. This research focuses on the design and manufacturing of two robotic test devices with different toe arrangements. The first, anisodactyl (three toes at the front, one at the back), is commonly found in birds of prey such as falcons and hawks. The second, zygodactyl (two toes at the front, two at the back), is commonly found in climbing birds such as woodpeckers and parrots. The evaluation methods for these models included a qualitative variable-object grasp assessment. The results highlighted design features that suggest an improved grasp: a small and central palm, curved distal digit components, and a symmetrical digit arrangement. A quantitative grip force test demonstrated that the single digit, the anisodactyl claw, and the zygodactyl claw designs support loads up to 64.3 N, 86.1 N, and 74.1 N, respectively. These loads exceed the minimum mechanical load capabilities for prosthetic devices. The developed designs offer insights into how biomimicry can be harnessed to optimize the grasping functionality of upper-limb prostheses. Full article

Hand-gripping training is important for improving the fundamental functions of human physical activity. Bernstein’s idea of “repetition without repetition” suggests that motor control function should be trained under changing states. The randomness level of load should be visualized for self-administered screening when repeating various training tasks under changing states. This study aims to develop a sensing methodology of random loads applied to both the agonist and antagonist skeletal muscles when performing physical tasks. We assumed that the time-variability and periodicity of the applied load appear in the time-series feature of muscle deformation data. In the experiment, 14 participants conducted the gripping tasks with a gripper, ball, balloon, Palm clenching, and paper. Crumpling pieces of paper (paper exercise) involves randomness because the resistance force of the paper changes depending on the shape and layers of the paper. Optical myography during gripping tasks was measured, and time-series features were analyzed. As a result, our system could detect the random movement of muscles during training. Full article

The rehabilitation process after the onset of a stroke primarily deals with assisting in regaining mobility, communication skills, swallowing function, and activities of daily living (ADLs). This entirely depends on the specific regions of the brain that have been affected by the stroke. Patients can learn how to utilize adaptive equipment, regain movement, and reduce muscle spasticity through certain repetitive exercises and therapeutic interventions. These exercises can be performed by wearing soft robotic gloves on the impaired extremity. For post-stroke rehabilitation, we have designed and characterized an interactive hand orthosis with tendon-driven finger actuation mechanisms actuated by servo motors, which consists of a fabric glove and force-sensitive resistors (FSRs) at the tip. The robotic device moves the user’s hand when operated by mobile phone to replicate normal gripping behavior. In this paper, the characterization of finger movements in response to step input commands from a mobile app was carried out for each finger at the proximal interphalangeal (PIP), distal interphalangeal (DIP), and metacarpophalangeal (MCP) joints. In general, servo motor-based hand orthoses are energy-efficient; however, they generate noise during actuation. Here, we quantified the noise generated by servo motor actuation for each finger as well as when a group of fingers is simultaneously activated. To test ADL ability, we evaluated the device’s effectiveness in holding different objects from the Action Research Arm Test (ARAT) kit. Our device, novel hand orthosis actuated by servo motors (NOHAS), was tested on ten healthy human subjects and showed an average of 90% success rate in grasping tasks. Our orthotic hand shows promise for aiding post-stroke subjects recover because of its simplicity of use, lightweight construction, and carefully designed components. Full article

Real-time multi-axis distributed tactile sensing is a critical capability if robots are to perform stable gripping and dexterous manipulation, as it provides crucial information about the sensor–object interface. In this paper, we present an optical-based six-axis tactile sensor designed in a fingertip shape for robotic dexterous manipulation. The distributed sensor can precisely estimate the local XYZ force and displacement at ten distinct locations and provide the global XYZ force and torque measurements. Its compact size, comparable to that of a human thumb, and minimal thickness allow seamless integration onto existing robotic fingers, eliminating the need for complex modifications to the gripper. The proposed sensor design uses a simple, low-cost fabrication method. Moreover, the optical transduction approach uses light angle and intensity sensing to infer force and displacement from deformations of the individual sensing units that form the overall sensor, providing distributed six-axis sensing. The local force precision at each sensing unit in the X, Y, and Z axes is 20.89 mN, 19.19 mN, and 43.22 mN, respectively, over a local force range of approximately ±1.5 N in X and Y and 0 to −2 N in Z. The local displacement precision in the X, Y, and Z axes is 56.70 μm, 50.18 μm, and 13.83 μm, respectively, over a local displacement range of ±2 mm in the XY directions and 0 to −1.5 mm in Z (i.e., compression). Additionally, the sensor can measure global torques, $T_x$, $T_y$, and $T_z$, with a precision of of 1.90 N-mm, 1.54 N-mm, and 1.26 N-mm, respectively. The fabricated design is showcased by integrating it with an OnRobot RG2 gripper and illustrating real-time measurements during in simple demonstration task, which generated changing global forces and torques. Full article

Since electric power steering has replaced hydraulic power steering in passenger cars, steering feedback has become a challenging task in steering system development. Test benches represent a valid approach for improving steering feedback since they allow investigations without the real vehicle. To improve the applicability of feedback evaluations on a steering test bench, this paper aims to identify improvements in the current evaluation technique to obtain objective parameters that correlate with a subjective evaluation of safety-relevant steering feedback. Therefore, a previously reported approach of a chirp rack force excitation, using the magnitude of the transfer function from the rack force to steering wheel torque to describe steering feedback, is compared to a similar identification approach in which a pseudo-random-binary-sequence signal is utilized. To reflect realistic applications, driving maneuvers are transferred to the test bench to identify relevant objective data. For a valid representation of the steering wheel operation, a human grip model is implemented and compared to a fixed steering wheel angle control. It is shown that the random signal represents a valid and, on average, improved approach to objectively evaluating the steering feedback. Furthermore, a recommendation can be made to include the human grip model in the feedback evaluation tests, as the identified correlation results are improved by its inclusion. The identified parameters and methods represent an improvement for future steering feedback development. Full article

Introduction: Patients with Turner syndrome (TS) often face skeletal and muscular challenges, including reduced bone mineral density (BMD) and muscle weakness. This comprehensive study sheds light on the complex interplay between muscle strength, BMD, and metabolic and endocrine parameters in TS and healthy subjects. Methods: A cross-sectional study involving 42 TS patients and 70 healthy women was conducted. All patients had their BMD determined in the L1–L4 lumbar spine section and in the whole skeleton as well as the parameters of body fat mass (BF), and visceral fat mass (VF) were also determined. The maximum gripping force was measured with a hydraulic manual dynamometer. In addition, a number of blood hormonal and metabolic parameters were determined. Results: In the TS group, hand grip strength correlated positively with triglyceride levels but not with BMD. Healthy individuals had a positive link between hand grip strength and BMD, while patients with TS did not show a significant association between the two. A trend suggested that longer recombinant human growth hormone (rhGH) therapy might improve BMD in the L1–L4 region. Multiple linear regression analysis revealed that muscle strength assessment may be a potential exponent of reduced BMD, and also used clinically in young adult women but not in individuals with TS. Conclusions: The relationship between BMD variables and hand grip might differ between the two groups, potentially indicating distinct musculoskeletal characteristics in TS patients. Longer rhGH therapy in TS patients may have a positive effect on BMD in the L1–L4 region. Understanding the intricate relationships between these factors is important for optimizing clinical management strategies and improving the quality of life for TS patients. Full article

Immersive technology, refers to various novel ways of creating and interacting with applications and experiences, e.g., virtual reality (VR), has been used in various simulations and training where preparing real/physical settings is not ideal or possible, or where the use of virtual contents is otherwise beneficial. Realizing realistic interactions with virtual content is crucial for a quality experience and the effectiveness of such simulation and training. In this paper, we propose a kinematics-based realistic hand interaction method to enable a physically plausible grip-lifting experience in VR. The method reflects three kinematic characteristics of the hand: the force at contact points, finger flexion, and the speed of hand/finger motion, and we developed a grip-lift interaction prototype using the proposed method. To examine the sense of realism and hand poses during the grip-lift interaction, we conducted a human subjects experiment using the prototype, resulting in positive effects on the perceived realism and usefulness of the interaction. Grip-lifting is a fundamental interaction technique that is involved in most embodied interaction scenarios. Our method would contribute to the design and development of realistic virtual experiences, of which we will discuss the implications and potential based on our findings. Full article
