The erosion of Pelton turbine components in mountainous areas with high sediment input is a major challenge for energy- and cost-efficient operation. Quantitative data on possible efficiency losses associated with local damage are needed. A systematic experimental study was carried out on a model turbine to determine the efficiency losses caused by damaged needles and seat rings. For this purpose, artificial patterns of erosion-like damage were generated on the surfaces of needles and seat rings. These patterns were gradually deepened, and hill charts were measured repeatedly. The combination of needle and seat ring defects was also studied, and the finding is that superimposing the individual efficiency losses of the needle and seat ring resulted in the same efficiency loss measured for both damaged parts. The results of the measurement campaign show that damaged needles should be replaced at an early stage of deterioration, as efficiency losses can quickly add up to several percent and become unacceptable at partial load operations of the turbines. Full article

Pelton turbines are susceptible to hydro-abrasive erosion from sediment-laden flows, resulting in a progressive loss of efficiency. Typical defect classes can be derived from the analysis of such damage observed in hydropower plants. A systematic strategy was developed to investigate the effect of locally damaged Pelton runners on the efficiency in laboratory tests using a model turbine. For this purpose, nine identical runners were fabricated and machined with an increasing size, depth, or number of different artificial defect types, such as splitter, rounded or sharp-edged, defects at the cutout, defects in the bucket base, and added ripples on the bucket sides. The processing steps, the efficiency measurement, and the extracted slopes of the efficiency drops are discussed in detail. The main findings are that the efficiency losses due to the various defects increase in a good approximation linearly with the machining depth and that the individual defect types can be superimposed. Defects at the splitter, bucket base, and bucket side dominate the losses at partial load of the turbine, while those at the cutout dominate at full load. Based on the results of this measurement campaign, power plant operators can estimate the magnitude of efficiency losses in their plant. Full article

With the increase in exploration in recent years, buried hill condensate gas reservoirs have gradually become an important field for increasing reserves and production of offshore oil and gas in China, and efficient development of condensate gas reservoirs has also become a hot issue in hydrocarbon development. Due to the complex phase-change law and retrograde condensation phenomenon of deep condensate gas reservoirs, the reservoir properties and production dynamics data obtained by conventional pressure-recovery-test methods were greatly limited, and the dynamic data and evaluation parameters of the single well control area cannot be accurately determined. In this paper, using the production analysis method to analyze the production dynamics data of a single well, combined with static geological data and well-test analysis data, the reservoir parameters of a single well were evaluated. Specifically, the Blasingame method was applied to realize the production-decline law of production wells, and new dimensionless flow, pressure parameters, and pseudo-time functions were introduced. Using the unstable well test theory and the traditional production decline analysis technology, the IHS Harmony software is used to fit the production dynamic data with the theoretical chart. The evaluation parameters such as reservoir permeability, skin factor, well control radius, and well control reserves were calculated, providing strong support for the production decision-making of the petroleum industry and also providing a strong decision-making basis for the dynamic adjustment of oil–gas-well manufacture. Full article

Investigating the flow performance of Francis turbines from model to prototype is a complex but essential process for ensuring reliable and efficient turbine operation in hydropower plants. It ensures that Francis turbine designs operate efficiently under various operating conditions, extending from laboratory reduced-scale models to full-scale prototype installations. In this investigation, a Francis turbine model was tested under different operating conditions, and its properties were measured, including torque, hydraulic efficiency, power output, cavitation coefficient, rotational speed, flow rate, and pressure pulsations. The results of the Francis turbine model test indicate that it achieved the maximum torque with the designed discharge and designed head. The cavitation coefficient consistently remained higher than the critical cavitation coefficient. The initial cavitation bubbles were observed at 50% partial load but disappeared at full load. Pressure pulsations under different operating conditions showed the maximum peak-to-peak amplitude appearing at the turbine inlet domain and the minimum amplitude occurring at the draft tube elbow. A hill chart shows that the model’s best efficiency was 93.66%, and the estimated best efficiency of the prototype was 95.03% at the design head. The conclusions and methodology of this study can be generalized to other similar hydraulic turbines, especially prototype Francis turbines that lack experimental results. Full article

The development of hydroelectric technology and much of the “knowledge” on hydraulic phenomena derive from scale modeling and “bench” tests to improve machinery efficiency. The result of these experimental tests is mapping the so-called “hill chart”, representing the “DNA” of a turbine model. Identifying the efficiency values as a function of the specific parameters of the flow and energy coefficient (which both identify the operating point) allows us to represent the complete behavior of a turbine in hydraulic similarity with the original model developed in the laboratory. The present work carries out a “reverse engineering” operation that leads to the definition of “an innovative research model” that is relatively simple to use in every field. Thus, from the experimental survey of the degree of efficiency of several prototypes of machines deriving from the same starting model, the hill chart of the hydraulic profile used is reconstructed. The “mapping” of all the characteristic quantities of the machine, together with the physical parameters of the regulating organs of a four-blade Kaplan turbine model, also made it possible to complete the process, allowing to identify not only the iso-efficiency regions but also the curves relating to the trend of the angle of the impeller blades, the specific opening of the distributor, and the identification of critical areas of cavitation. The development of the hill chart was made possible by investigating the behavior of 33 actual prototypes and 46 characteristic curves derived from the same reference model based on practical experiments for finding the optimal blade distributor “setup curve”. To complete this, theoretical characteristic curves of “not physically realized” prototypes were also mapped, allowing us to complete the regions comprising the diagram. The study of the unified hill charts found in previous documentation of the most famous manufacturers was of great help. Finally, the validation of the “proposed procedure” was obtained through the experimental survey of the actual efficiency of the new prototype based on the theoretical values defined in the design phase on the chart obtained with the method described. Full article

With a large-range-operation head, the Francis turbine unit is the most widely used type of hydraulic turbine in the world. The general range of the Francis turbine is 20–700 m. Because of this, the operating stability of the Francis turbine needs to be focused on. In this paper, a multi-dimensional hill chart is applied to a low-head Francis turbine unit to describe its vibration characteristics. Firstly, a field test was conducted on the unit in order to obtain vibration data under different operating conditions. Secondly, the condition indicators were calculated and extracted from the experimental data. Then, the condition indicators under different head values and outputs were fitted to form a multi-dimensional hill chart. In the end, the vibration characteristics of the researched low-head Francis turbine unit were analyzed based on the multi-dimensional hill chart. Full article
