Semantic segmentation of workpieces and die cavities is critical for intelligent process monitoring and quality control in hammer die-forging. However, the field of 3D point cloud segmentation currently faces prominent limitations in forging scenario adaptation: existing state-of-the-art (SOTA) methods are predominantly optimized for road driving or indoor scenes, where targets have stable poses and regular surfaces. They lack dedicated designs for capturing the fine-grained deformation characteristics of forging workpieces and alleviating multi-scale feature misalignment caused by large pose variations—key pain points in forging segmentation. Consequently, these methods fail to balance segmentation accuracy and real-time efficiency required for practical forging applications. To address this gap, this paper proposes a novel semantic segmentation framework fusing 3D point cloud and bird’s-eye-view (BEV) representations for complex die-forging scenes. Specifically, a Star-based encoding module is designed in the BEV encoding stage to enhance capture of fine-grained workpiece deformation characteristics. A hierarchical feature-offset alignment mechanism is developed in decoding to alleviate multi-scale spatial and semantic misalignment, facilitating efficient cross-layer fusion. Additionally, a weighted adaptive fusion module enables complementary information interaction between point cloud and BEV modalities to improve precision.We evaluate the proposed method on our self-constructed simulated and real die-forging point cloud datasets. The results show that when trained solely on simulated data and tested directly in real-world scenarios, our method achieves an mIoU that surpasses RPVNet by $1.1\%$. After fine-tuning with a small amount of real data, the mIoU further improves by $5\%$, reaching optimal performance. Full article

This study employs a multilevel modeling approach to describe the deformation of specimens made from austenitic Wire Arc Additive Manufactured (WAAM) steel 308LSi. Two WAAM processing modes were investigated: (1) the Cold Metal Transfer (CMT) method and (2) Cold Metal Transfer combined with interlayer deformation strengthening (hammer peening/forging). Test specimens were cut from the deposited walls at 0° and 90° relative to the deposition direction. The grain and dendritic structures of the specimens were analyzed using optical stereomicroscopy. A statistical multilevel model has been developed, accounting for the features of the grain-dendritic and defect structures under various technological deposition modes. Parameter identification and model verification were conducted based on experimental data from uniaxial tensile tests of 308LSi steel specimens. The maximum deviation of the numerical results from the experimental data during the identification stage under uniaxial tensile loading did not exceed 3%, and during the verification stage it did not exceed 10%; the overall mean deviation did not exceed 1% for the identification stage and 2% for the verification stage. The model effectively captured the anisotropic mechanical behavior of WAAM-processed samples. The maximum calculated yield strength 360 MPa was obtained for specimens cut at an angle of 45°, while the minimum value 331 MPa was observed for vertically oriented specimens. Specimens subjected to interlayer forging (hammer peening) exhibited isotropic material properties. Explicit multilevel modeling, incorporating the presence of MnO oxide inclusions located within the austenite matrix, was performed. The results showed good correlation with experimental data and confirmed the localization of fatigue cracks at the phase boundary-matrix-oxide interface. Full article

The aim of this work was to study the influence of temperature and strain rate on the formability and structure of C22 steel. This study was based on tensile and compression tests. In the case of the compression test, the study of the influence that the process parameters (temperature and strain rate) have on the nonuniformity of the deformation was taken into account. This work presents an experimental analysis of the effects of temperature and strain rate on the mechanical and structural properties of C22 mild steel. Uniaxial tension and compression testing at high temperatures (800 °C, 900 °C, 1000 °C, and 1100 °C) and strain rates 0.001 1/s, 0.012 1/s, and 0.089 1/s for tension and 6.35 1/s, 5.72 1/s, 4.67 1/s and, respectively, 0.106 1/s for the compression hammer and hydraulic press served as the foundation for the studies. Analysis was carried out on how temperature and strain rate affected yield stress, strain to fracture, hardness, and structural evolution. Additionally, the nonuniformity of the deformations obtained at various temperature and strain rate values was examined. The fracture behavior of C22 steel can be enhanced by raising the deformation temperature and lowering the strain rate. In the tensile tests, the study of stress and strain distribution and the variation in the normalized Latham–Cockroft failure criterion was performed by numerical simulation using FORGE^® NxT 4.1 software. Full article

This study refers to the application of an advanced tool in the form of numerical modelling in order to develop a low-waste hot die forging technology to produce a connecting rod forging. The technology aims at ensuring a limited amount of the charge material is necessary to produce one forging, as well as minimizing forging forces, and thus the electric energy consumption. The study includes a verification of the current production technology, which constituted the basis for the construction and development of a numerical model. A new construction of the forging tools was developed, with an additional pre-roughing pass (0X). The new process consists of die forging in the pre-roughing pass (0X), the roughing pass (1X) and the finishing impression (2X). Numerical modelling was subsequently conducted with the use of the Forge 3.0 NxT software. A detailed analysis was conducted on the accuracy of the tool impression filling (including the pre-roughing pass) by the deformed material, the distribution of temperatures for the forgings and the plastic deformations, as well as the courses of forging forces and energy. The results were verified under industrial conditions and compared with the forgings obtained in the previous technology (a roughing pass and a finishing impression). As a result of introducing the pre-roughing pass 0X, the forces were distributed between three impressions, including the especially developed pre-roughing pass. It was confirmed that the abovementioned changes in terms of forging tool construction had a positive effect on relieving the roughing pass and the finishing impression as well as limiting the charge material, and they also lowered the process energy consumption by 10%. This study also validated the relevance of using FE modelling to verify processes under virtual conditions before being implemented under industrial conditions. Therefore, the proposed approach based on multi-variant numerical simulations can be successfully used to improve other manufacturing processes in terms of reducing energy and material consumption and increasing tool service life. Full article

With the wide application potential of wrought aluminium alloy in aerospace, automobile and electronic products, high-quality aluminium bars prepared by the radial forging (RF) process have received extensive attention. Penetration performance refers to the depth of radial plastic deformation of forgings, which is the key factor in determining the quality of forging. In this work, the penetration performance of the radial forging process for 6063 wrought aluminium bars is investigated by simulation using FORGE software. The minimum reduction amount of the hammer is calculated based on the forging penetration theory of forging. The influence of process parameters including forging ratio (FR) and billet temperature on the effective stress and hammer load in the RF process are investigated. The RF-deformed billet is then produced with the optimal process parameters obtained from the simulation results. The average grain size of aluminium alloy semi-solid spherical material is used to evaluate the forging penetration. Simulation results showed that the effective strain at the edge and the centre of the RF-deformed billet gradually increases, but the increasing speed of the effective strain at the edge becomes low. The hammer load first decreases quickly and then gradually maintains stability by increasing the FR. It is found that low billet temperature and high FR should be selected as appropriate process parameters under the allowable tonnage range of RF equipment. Under an isothermal temperature of 630 °C and a sustaining time of 10 min, the difference in the average grain dimension between the edge and the centre positions of the starting extruded blank is 186.43 μm, while the difference in the average grain dimension between the edge and the centre positions of the RF-deformed blank is 15.09 μm. The improvement ratio of penetration performance for the RF-deformed blank is obtained as 91.19%. Full article

The primary objective of this paper is to investigate the influence of deformation degree on the microstructure and properties of a Ni-based superalloy. An upsetting experiment was conducted using a free-forging hammer to achieve a deformation degree ranging from 60% to 80%. The impact of the forging deformation degree on the hardness and high-temperature erosion performance was evaluated using the Rockwell hardness tester (HRC) and high-temperature erosion tester, respectively. The experimental results indicate that as the deformation degree increased, the hardness of the forged material progressively increased while the rate of high-temperature erosion gradually decreased. In order to comprehensively study the mechanism behind the variations in forging performance, optical microscopy (OM), scanning electron microscopy (SEM), electron backscatter diffraction (EBSD), and transmission electron microscopy (TEM) were employed. The findings reveal that as the deformation degree increased, the presence of small-angle grain boundaries and an increase in grain boundary area contributed to enhanced hardness in the alloy forgings. Furthermore, it was discovered that grain boundaries with twin orientation promoted dynamic recrystallization during deformation, specifically through a discontinuous dynamic recrystallization mechanism. Additionally, the precipitated γ′ phase in the alloy exhibited particle sizes ranging from 40 to 100 nm. This particle size range resulted in a higher critical shear stress value and a more pronounced strengthening effect on the alloy. Full article

The study refers to the application of numerical modeling for the improvement of the currently realized precision forging technology performed on a hammer to produce connecting rod forgings in a triple system through the development of an additional rolling pass to be used before the roughing operation as well as preparation of the charge to be held by the robot’s grippers in order to implement future process robotization. The studies included an analysis of the present forging technology together with the dimension–shape requirements for the forgings, which constituted the basis for the construction and development of a thermo-mechanical numerical model as well as the design of the tool construction with the consideration of the additional rolling pass with the use of the calculation package Forge 3.0 NxT. The following stage of research was the realization of multi-variant numerical simulations of the newly developed forging process with the consideration of robotization, as a result of which the following were obtained: proper filling of the tool impressions (including the roller’s impression) by the deformed material, the temperature distributions for the forging and the tools as well as plastic deformations (considering the thermally activated phenomena), changes in the grain size as well as the forging force and energy courses. The obtained results were verified under industrial conditions and correlated with respect to the forgings obtained in the technology applied so far. The achieved results of technological tests confirmed that the changes introduced into the tool construction and the preform geometry reduced the diameter, and thus also the volume, of the charge as well as provided a possibility of implementing robotization and automatization of the forging process in the future. The obtained results showed that the introduction of an additional rolling blank resulted in a reduction in forging forces and energy by 30% while reducing the hammer blow by one. Attempts to implement robotization into the process were successful and did not adversely affect the geometry or quality of forgings, increasing production efficiency. Full article

The output of a single-degree-of-freedom (SDOF) piecewise linear system with asymmetric damping and linear stiffness excited by Dirac impulse excitation is studied. Analytical solutions of the response for piecewise linear systems are obtained by replacing the equation of motion with Dirac excitation by a homogeneous differential system with zero initial displacement and a given initial velocity. A significant improvement of the response consisting in a substantial reduction in the after-shock vibrations was obtained. The obtained results are applied to the damping optimization of a shock isolation system for forging hammers. Full article

The casting of metal alloys followed by hot forging is a widely used manufacturing technology to produce a homogeneous microstructure. The combination of mechanical and thermal energy envisages the microstructural properties of metal alloys. In the present investigation, a metal alloy of composition 0.05C-1.52Cu-1.51Mn (in weight %) was cast in an induction furnace using a zirconia crucible. The melt pool was monitored using optical emission spectroscopy (OES) to maintain the desired composition. The as-cast block was then subjected to forging under a pneumatic hammer of 0.5 t capacity so that any casting defects were eliminated. The as-cast block was reheated to a temperature of 1050 °C and held at that temperature for 6 h to homogenize, followed by hammering with a 50% strain using a pneumatic hammer. The microhardness was calculated using a Vickers microhardness testing apparatus. The microstructure characterization of the processed alloy was carried out using an optical microscope, electron backscattered diffraction (EBSD), energy-dispersive X-ray spectroscopy (EDXA), and a transmission electron microscope (TEM). The sample for optical microscopy was cut using a diamond cutter grinding machine and surface polishing was carried out using emery paper. Further, mechanical polishing was performed to prepare the samples for EBSD using a TEGRAPOL polishing machine. The EBSD apparatus was operated at a 20 kV accelerating voltage, 25 mm from the gun, and with a 60 µ aperture size. HKL Technology Channel 5 Software was used for the post-processing of EBSD maps. The procedure of standard polishing for OES and TEM sample preparation was followed. Recrystallization envisages equiaxed grain formation in hot forging; hence, the strain-free grains were observed in the strained matrix. The lower distribution of recrystallized grains indicated that the driving force for recrystallization was not abundant enough to generate a fully recrystallized microstructure. The fractional distribution of the misorientation angle between 15 and 60° confirms the formation of grain boundaries (having a misorientation angle greater than 15°) and dislocations/subgrain/substructures (having a misorientation angle less than 15°). The fraction of misorientation angle distribution was higher between the angles 0.5 and 6.5°; afterwards, it decreased for higher angles. The substructure was observed in the vicinity of grain boundaries. The softening process released certain strains, but still, the dislocation was observed to be deposited mostly in the vicinity of grain boundaries and at the grain interior. The fine precipitates of the microalloying element copper were observed in the range of size in nanometers. However, the densities of these precipitates were limited and most of these precipitates were deposited at the grain interior. The microhardness of 210.8 Hv and mean subgrain size of 1.61 µ were observed the enhanced microhardness was due to the limited recrystallized grains and accumulation of dislocations/subgrain/substructures. Full article

This paper concerns an analysis of the tribological conditions and the effect of the use of seven lubricating agents dedicated to a process of precision forging on a hammer in multiple systems. In particular, it performs a review of the most popular methods of determining the friction coefficient in the aspect of the obtained results. On this basis, the selected method of friction coefficient determination was a hot ring upsetting test for two forging materials: carbon steel (16MnCrS5) and stainless steel (316Ti). The test samples were prepared in the shape of a ring with precisely defined dimensions, and, next, they were subjected to an upsetting process on a hydraulic hammer under conditions similar to those present in an industrial forging process, and the characteristic geometrical features and friction coefficients were determined. Additionally, measurements of the geometrical changes were made with the use of 3D scanning for the extreme friction coefficient values in order to perform their comparison. The obtained results showed that for carbon steel the lowest achieved value was in the case of Lubrodal F185 (µ = 0.24) A and the highest for Lubr_hot_press 123HD (µ = 0.32); in turn, for stainless steel the lowest value µ = 0.19 was achieved for Graphitex CR 7 and the highest for Graphitex CR720K (µ = 0.29). Moreover, for these conditions, numerical modeling was conducted in the Forge 3.0 NxT program, in order to analyze the obtained results and verify the correctness and agreement of the friction coefficients determined in the ring test, on the basis of the geometrical changes. The data obtained in the computer simulation confirmed the possibility of obtaining a good agreement between the FEM (Finite Elements Method) and experimental trials, as the modeling provides reliable information on the plastic deformations and can be used as an alternative method of examining the friction conditions in industrial forging processes. Full article

This paper aims to improve the mechanical properties and fatigue life of AISI/SAE 4140 alloy steel connecting rods (CRs). Conventional CRs are typically manufactured through open die forging/hammering, blocking, and hot forging processes. In the present work, a modification to the process route has been proposed such that the open die forging/hammering was completely replaced with a multistep asymmetrical reducer rolling technique. Four rolling passes were introduced to achieve the desired preform shape and size. The effect of each rolling pass on grain size, mechanical properties, and fatigue life was investigated. Samples from each multistep rolling, blocking, and forging stage were subjected to impact, hardness, tensile, and fatigue testing. Metallography using optical and scanning electron microscopes was also conducted to reveal metallurgical changes. Fatigue testing and fractography were performed using the R.R. Moore Rotating-Beam Fatigue testing machine and scanning electron microscope, respectively, to evaluate the fatigue life and the fracture behavior of both the conventional and multistep rolled forged CRs. It was observed that, unlike the conventional forging process, multistep asymmetrical rolling gradually reduces grain size as the rolling progresses and improves yield, tensile, and impact strengths, hardness, and ductility. In comparison to conventional forging, multistep rolling led to an almost 33% and 29% increase in yield and tensile strengths, respectively. Moreover, the fatigue life of multistep rolled CR increased by more than five times compared to conventional CR. Full article

The aim of this manuscript is the experimental and numerical study regarding the influence of friction conditions on plastic deformation behavior by upsetting the A6082 aluminum alloy. The upsetting operation is characteristic of a significant number of metal forming processes: close die forging, open die forging, extrusion, and rolling. The purpose of the experimental tests was to determine: by the ring compression method, the friction coefficient for 3 surface lubrication conditions (dry, mineral oil, graphite in oil) by using the Coulomb friction model; the influence of strains on the friction coefficient; the influence of friction conditions on the formability of the A6082 aluminum alloy upsetted on hammer; study of non-uniformity of strains in upsetting by measuring hardness; change of the tool-sample contact surface and non-uniformity of strains distribution in a material by numerical simulation. Regarding the tribological studies involving numerical simulations on the deformation of metals, they mainly focused on the development of friction models that characterize the friction at the tool-sample interface. The software used for the numerical analysis was Forge@ from Transvalor. Full article

For hundreds of years, water mills have supported the local economies of Piedmont by contributing to the production of flour, textile fibres, timber, and metal agricultural tools. Since the beginning of the last century, and in particular after the 1950s, many artefacts have been abandoned. Nonetheless, hundreds of mills are still present in southern Piedmont, both in the plains and in the mountains, sometimes in an excellent state of conservation. This work presents a hammer forge, the La Pianca mill in Busca, Cuneo, Italy, as a significant, detailed case study. The socio-economic context in which exists is analysed, its history is reconstructed, and the functioning of the machinery, including the water wheels, the motion transmission systems, and the various utilities consisting of tilt hammers, grinding wheels, and drills, is analysed in detail. Beyond the historical interest, concerning both the territory and the architecture, as well as the machines and mechanisms, this work aims to make a contribution to the prefiguration of effective scenarios for the reconversion of similar productive artefacts. Full article

Tool life in plastic forming processes is a problem of the utmost importance as it significantly affects the cost of production. Hot forging with hammers and mechanical presses is an example of the technological process in which the load on tools is extremely high and, consequently, the lifetime of tools is short. Considering, additionally, that this applies to large-scale production, from an economic point of view, the key issue will be to extend the tool life, make an accurate prediction of the number of parts that can be forged before the replacement of dies is necessary, and develop a system for quick tool changeover. Initially, however, it is necessary to understand the causes of excessive tool wear, which may lie in phenomena occurring at the level of microstructure. The aim of this article was to outline an example of the coexistence of multiple wear mechanisms in hot forging dies. For the modified chemical composition, the microstructure examinations were performed in selected areas of the tool. The research has revealed the causes of cracks in tools and some irregularities in the preparation of tools for production process. Full article

To improve the service life and reduce the repair cost of continuous casting rollers, a new welding-hammering hybrid remanufacturing process in which the roller was designed with a gradient structure was proposed, and corresponding equipment was developed. First, the failure modes and their causes for a continuous casting roller were analyzed by numerical simulation. The cyclic tension–compression shear stress, cyclic tension–compression normal stress, thermal cycle, and highly corrosive environment caused fatigue cracking and overall peeling of the roller surface. Second, the gradient structure composed of a base layer, transition layer, and strengthened layer of a continuous casting roller was designed, and materials for each layer were selected according to their different service conditions. Third, novel equipment for continuous welding-hammering composite remanufacturing was developed, and the optimized process parameters were obtained through welding experiments. Finally, an application test was carried out; the microscopic analysis showed that refined grains, fewer welding defects, and better surface toughness were obtained. Compared with traditional remanufacturing processes without hammering, the welding-hammering hybrid process achieved a forged structure instead of as-cast structure, which significantly improved the service life of the continuous casting roller by about 100%. Full article
