The partial discharge (PD) measurement under pulse width modulation (PWM) voltage is a critical measurement of quality assessment for inverter-fed motors, as outlined in IEC 60034-18-41 and IEC 60034-18-42. One of the key parameters in PD measurement is the repetitive partial discharge inception voltage (RPDIV). This paper examines factors that influence the ageing process of hairpin windings in motors, with ageing tests designed using the Design of Experiment (DoE) method. The study focuses on the effects of electrical and thermal stresses on the ageing process. To achieve this, the failure rate, the RPDIV data, and the lifetime data are selected as the output responses. The findings highlights that RPDIV measurements alone cannot accurately predict the degree of ageing of hairpin windings. Specifically, RPDIV results are influenced not only by the quality of the hairpin windings under PWM voltage but also by other contributing factors. Furthermore, the change in RPDIV during the ageing process showed that the RPDIV measurement cannot predict the ageing degree of the hairpin winding. Experimental data on failure rates and lifetimes reveal that both electrical and thermal stresses significantly influence the ageing process, with a notable interaction between these factors. Among the three output responses, the failure rate provides a more accurate reflection of this interaction. To reliably estimate the lifetime of hairpin windings, more precise parameters are necessary. Further research is required to deepen the understanding of the underlying PD mechanisms under PWM voltage, which could enhance diagnostic and predictive capabilities for hairpin winding performance. Full article

The asymmetric design of hairpin windings is known as a method for reducing AC losses in electric motors, especially at high frequencies. However, the design of the asymmetric winding is very critical to obtaining the best benefit regarding the efficiency and the thermal performance of the motor. Compared to the state-of-the-art in this paper, deep investigations are carried out to obtain the optimum design of the asymmetric hairpin windings while still employing a conventional manufacturing method. An analytical model is developed to speed up the investigation process, and the results of the analytical model are validated with a finite element method (FEM) model. The conclusions from the analytical investigation are considered in the design of an electric vehicle (EV) motor. The performance of the motor is studied for two different driving profiles to validate the rules of the asymmetric windings design and check the degree of dependency of the design of asymmetric windings on the application. It is proved that using asymmetric design reduces motor losses and improves thermal performance. Full article

Modern electric motors developed for the automotive industry have an ever higher power density with a relatively compact size. Among the various existing solutions to improve torque and power density, a reduction in the dimensions of the end-windings has been explored, aiming to decrease volume, weight, and losses. However, more compact end-windings often lead to complex shapes of the conductors, especially when preformed hairpin windings are considered. The rectangular cross-section of hairpin conductors makes them prone to deviating out of the bending plane during the forming process. This phenomenon, known as torsional–flexural instability, is influenced by the specific aspect ratio of the cross-section dimensions and the bending direction. This study focuses on understanding this instability phenomenon, aiming to identify a potential threshold of the cross-section aspect ratio. The instability makes it difficult to predict the final geometry, potentially compromising the compliance with the geometric tolerances. A finite element model is developed to analyse a single planar bend in a hairpin conductor. Various cross-section dimensions with different aspect ratios are simulated identifying those that experience instability. Moreover, an experimental campaign is conducted to confirm the occurrence of instability by testing the same single planar bending. The experimental data obtained are used to validate the finite element model for the tested dimensions. The aim is to provide designers with a useful tool to select hairpin geometries that are more suitable for the folding process, contributing to successful assembly and improving the overall design process of preformed hairpin conductors. Full article

This paper presents the application of a numerical approach known as proper generalized decomposition (PGD) to calculate the per-unit length (PUL) ac resistance of rectangular conductors. PGD has been successfully used in areas such as fluid mechanics and biomedical applications. It solves a partial differential equation (PDE) by decomposing the answer into a set of unknown one-dimensional (1D) functions in an iterative approach until it reaches a predetermined convergence. In this paper, a frequency-dependent meshing scheme is employed in the PGD technique at each frequency to properly take skin and proximity effects into account. One of the main advantages of PGD over traditional numerical approaches such as finite element or finite difference methods is that it confines the answers within a set of one-dimensional functions, which require fewer computational resources. Different examples of single and multiple rectangular conductors are considered to study skin and proximity effects. The PGD results are compared with those obtained using a commercial finite element method (FEM) software to verify the accuracy of the model. This approach can be used in applications such as white box modeling of transformers, EMC analysis, hairpin winding design used in electric vehicles, and busbar simulation. Full article

In this paper, the cooling performance of oil-cooling PMSM with hairpin winding under various oil parameters is analyzed via a simulation and an experiment. The effects of oil jet positions, oil temperatures, and oil flow rates on the cooling performance are analyzed. It is found that increasing the oil temperature in the range of 20 °C to 60 °C, increasing the flow rate of oil jets whose position angle is from 15° to 45°, and increasing the flow rate in the range of 1 L/min to 2 L/min will significantly improve the cooling performance. The apertures of the oil spray ring are optimized using the Taguchi algorithm. The cooling performance is the best when the flow ratio is m(0°):m(15°):m(30°):m(45°):m(60°):m(75°) = 4%:19%:10%:10%:4%:4%. This study provides a guide for the design of the oil-cooling system for the hairpin winding of the PMSM. Full article

Today, an extensive electrification is occurring in all industrial sectors, with a special interest seen in the automotive and aerospace industries. The electric motor, surely, is one of the main actors in this context, and an ever-increasing effort is spent with the aim of improving its efficiency and torque density. Hairpin windings are one of the recent technologies which are implemented onto the stator of the electric motor. Compared to conventional random windings, it inherently features lower DC resistance, higher fill factor, better thermal performance, improved reliability, and an automated manufacturing process. However, its bottleneck is the high ohmic losses at high-frequency operations due to skin and proximity effects (AC losses), resulting in a negative impact on the temperature map of the machine. Nevertheless, while it is well-known that DC losses increase linearly with the operating temperatures, the AC losses trend needs further insight. This paper demonstrates that operating the machine at higher temperatures could be beneficial for overall efficiency, especially at high-frequency operations. This suggests that a paradigm shift is required for the design of electric motors equipped with hair-pin windings, which should therefore focus on a temperature-oriented approach. In addition, the effect of the rotor topology on AC losses, which is often overlooked, is also considered in this paper. The combination of these effects is used to carry out observations and, eventually, to provide design recommendations. Finite element electromagnetic and thermal evaluations are performed to prove the findings of this research. Full article

This paper investigates the impact of the wire selection on the performance of induction motors for automotive applications. The section of wire and the material are evaluated at a high speed of 200 kW in an induction motor designed for premium vehicle applications. The proposed solutions have the same electromagnetic and thermal constraints, as well as the same final encumbrance. The various wire and winding types differ in terms of slot design, phase resistance, end-winding overhanging portion, skin and proximity effects, and equivalent slot thermal conductivity. Their impacts are analyzed in terms of the operating area motor efficiency and they are tested in an automotive drive cycle, highlighting the advantages and disadvantages of each configuration. Full article

Permanent magnet synchronous motors (PMSMs) with rectangular coils in hairpin windings exhibit improved fill factor and reduced end turn of the coils, which in turn improve the efficiency and power density of PMSMs, making them ideal for e-mobility applications. Herein, the shape of a PMSM was optimized for torque ripple reduction using metamodels to improve the noise and vibrational performance of the motor. The objective function of the optimal design aimed to minimize the torque ripple, and the average torque and efficiency were set as constraints. The notch width and depth and barrier length were selected as the design variables to satisfy the objective function and constraints. Using the optimal Latin hypercube design technique, 27 experimental points were selected, and a finite element analysis (FEA) was performed for each point. Furthermore, a function approximation was performed using six metamodels, and the best metamodel was selected using the root mean square error test. Moreover, the optimization was performed by combining the best metamodels for each variable with a sequential two-point diagonal quadratic approximation optimization algorithm. The torque ripple was improved by approximately 1.63% compared with the initial model, whereas the constraint values remained constant. Finally, an FEA was performed on the optimal point, and the FEA results matched with those of the optimal method. Full article

Nowadays, interest in electric propulsion is increasing due to the need to decarbonize society. Electric drives and their components play a key role in this electrification trend. The electrical machine, in particular, is seeing an ever-increasing development and extensive research is currently being dedicated to the improvement of its efficiency and torque/power density. Among the winding methods, hairpin technologies are gaining extensive attention due to their inherently high slot fill factor, good heat dissipation, strong rigidity, and short end-winding length. These features make hairpin windings a potential candidate for some traction applications which require high power and/or torque densities. However, they also have some drawbacks, such as high losses at high frequency operations due to skin and proximity effects. In this paper, a multi-objective design optimization is proposed aiming to provide a fast and useful tool to enhance the exploitation of the hairpin technology in electrical machines. Efficiency and volume power density are considered as main design objectives. Analytical and finite element evaluations are performed to support the proposed methodology. Full article

Interior permanent magnet (IPM) machines with hairpin windings have attracted significant attention in EV applications owing to their low DC resistance and excellent thermal capabilities. In this paper, we present a comprehensive investigation of AC winding losses in IPM machines for traction applications, including analytical modeling, the influence of design parameters, and finite element (FE) verification. The proposed analytical model can predict the trends in AC winding losses for any number of bar conductors and slot/pole combinations. The results of the parametric study, obtained via the analytical model, are presented to examine the effects of key design parameters, such as conductor width and height, phase arrangement, and slot-per-pole-per-phase (SPP). To incorporate more practical issues into the analysis of IPM machines with hairpin windings, extensive FE simulations were conducted. The results indicated that the AC winding losses decrease with an increasing number of conductor layers and phases inside the slot. Full article

Interest in multilayer windings is increasing with the application of the hairpin winding technology to the manufacturing of electrical machines. Therefore, the four-layer fractional slot concentrated winding is used for the initial design of the machine in this paper. The proposed physical model of the machine uses winding with a relatively high number of turns which is inappropriate to hairpin winding. Therefore the round-wire winding is created and the three-layer winding is derived and analyzed including the effect on the slot leakage inductance. The thermal analysis is then applied to the physical model of the machine to evaluate the slot-related thermal properties of the slot and the whole machine. The measurement is compared with the finite element analysis (FEA) and the equivalent slot thermal conductivity and heat transfer coefficients of the stator and rotor are obtained. Full article

Even though the offshore wind industry’s growth potential is immense, the offshore wind industry is still suffering from problems, such as the large initial capital requirements. Many factors are involved, and among these, the extra costs incurred by the conservative design of offshore wind energy converters can be quickly addressed at the design stage by accounting for the nonlinear destructive interaction between wind and wave loads. Even when waves approach offshore wind energy converters collinearly with the wind, waves and wind do not always make the offshore wind energy converter’s substructure deformed. These environmental loads can intermittently exert a force of resistance against deformation due to the nonlinear destructive interaction between wind and wave loads. Hence, the nonlinear destructive interaction between wave and wind loads deserves much more attention. Otherwise, a very conservative design of offshore wind energy converters will hamper the offshore wind energy industry’s development, which is already suffering from enormous initial capital expenditures. In this rationale, this study numerically simulates a 5 MW offshore wind energy converter’s structural behavior subject to wind and random waves using the dynamic structural model developed to examine the nonlinear destructive interaction between wind and wave loads. Numerical results show that the randomly fluctuating water surface as the wind blows would restrict the offshore wind energy converter’s substructure’s deflection. Nonuniform growth of the atmospheric boundary layer due to the wavy motions at the water surface as the wind blows results in a series of hairpin vortices, which lead to the development of a large eddy out of hairpin vortices swirling in the direction opposite to the incoming wind near the atmospheric boundary layer. As a result, the vertical profile of the longitudinal wind velocity is modified; the subsequent energy loss drastically weakens the wind velocity, which consequently leads to the smaller deflection of the substructure of the offshore wind energy converter by 50% when compared with that in the case of wind with gusts over a calm sea. Full article

The need of a wide operating range and a high power density in electric machines for full- and hybrid electric vehicles in traction applications has led to an increase in the operating frequency of the machine. When the electric frequency increases, the additional losses in stator windings become an issue and they have to be taken into account in the design of the electric machine. This issue is more critical when hairpin windings are employed, due to the the skin and proximity effects which produce increased copper losses. In this paper, the relationships between different stator slot parameters (tooth width, slot opening, etc.) and stator winding copper losses have been analysed in order to identify an optimal design of a single stator slot. Full article
