Search Results (92)

The study presents the first application of the Connected Linear Network (CLN) package implemented in MODFLOW-USG to an existing Ground-Source Heat Pump (GSHP) system. The numerical element was specifically adapted by the authors in a previous study to simulate vertical Borehole Heat Exchangers (BHEs) and is here applied for the first time to evaluate the heat transfer in Milano subsurface induced by a GSHP system. The evaluation of interference between geothermal systems and wells is an important topic, especially in densely populated areas, which has scarcely been explored in the literature. Specifically, the aim is to evaluate the thermal perturbation and the possible interference between BHE systems and the drinkable water wells of the Armi pumping station managed by MM S.p.A. The simulation results show moderate groundwater thermal perturbation: approximately 3 °C at 100 m downgradient of the borefield and, furthermore, a limited impact (maximum 1 °C) in just two wells of the Armi pumping station. After 3 years of GSHP system operation, the thermal perturbation can extend for kilometers, but with limited variation in groundwater temperature (lower than 1 °C). Although the predicted groundwater temperature variation is not critical, the real-time monitoring of temperatures coupled with numerical modeling is essential to prevent thermal interference and optimize GSHP system performance. Full article

Food shortages due to the decreasing arable land area, which is a consequence of the increasing global population, have brought greater attention to greenhouses. However, the cost of air conditioning in greenhouses is high. Therefore, in this study, the heating performance of a low-running-cost air conditioning system using groundwater was evaluated in winter in an agricultural greenhouse. The system consisted of a temperature control room in an agricultural greenhouse and a groundwater recirculation system. The pumped groundwater was passed through a polytube heat exchanger panel and stored in a recirculation tank. The stored water circulated back to the heat exchanger to create a water recirculation system. When operated with only a single 250 L recirculation tank, the temperature in the temperature control room was maintained at 4.9–19.4 °C, even when the maximum and minimum outdoor air temperatures were 12.6 and −2.3 °C, respectively. To achieve a higher minimum temperature in the temperature control room, a method was developed to enable the system to switch from the recirculating water to flowing groundwater when the recirculating water temperature fell below the groundwater temperature. Consequently, the minimum temperature in the temperature control room could be maintained at 8.0 °C. In an experiment in which the capacity of the recirculation tank was tripled (750 L), the minimum temperature was maintained at 7.9 °C, which is a stable temperature for cucumber cultivation. These results indicate that the heating capacity of the proposed system is equivalent to that of ACCFHES (An aquifer coupled cavity flow heat exchanger system) and other heating systems for winter heating. Therefore, this proposed method makes it possible to cultivate plants that grow in a climate similar to that of cucumbers at a low running cost. The amount of heating capacity that could be extracted simply by circulating groundwater was also revealed. Full article

In this paper, we study the optimization of the operation of closed-loop ground source heat pump systems with any layout and any number n of vertical boreholes. Given the total required heat load, q_T, the goal is to maximize the rate of thermal gains from the ground or, equivalently, to minimize the disturbance of the ground temperature at the location of the boreholes. This is achieved by optimizing the distribution of q_T to the individual boreholes. We prove analytically that, at any time, the weighted temperature disturbance is minimal when the following condition holds: the temperature change is the same at the locations of all boreholes. Our proof is based on the analogy between heat transfer due to conduction and water flow through aquifers, and we make use of the results obtained for pumping cost minimization from systems of wells under transient groundwater flow conditions in infinite confined aquifers. Finally, we present a procedure to calculate the optimal distribution of the total heat load to the individual boreholes at any given time. The procedure entails the solution of a linear system of n equations and n unknowns, which is explained by means of two theoretical application examples. Accuracy of the results is also discussed. Full article

This review examines the integration of ground source heat pump (GSHP) systems with energy piles as a sustainable approach to improving energy efficiency in smart cities. Energy piles, which combine structural support with geothermal heat exchange, offer significant advantages over conventional air source heat pumps (ASHPs) by using stable ground temperatures for more efficient heating and cooling. System efficiency can be improved by integrating hybrid systems, cooling towers, and solar thermal systems. While the initial investment for GSHP systems is higher, their integration with energy piles significantly reduces electricity consumption and operating costs, providing a compelling solution for regions with high energy demand and escalating energy prices. Government financial incentives, including subsidies, loans, and tax rebates, can reduce payback periods to less than 10 years, encouraging the adoption of energy piles and GSHP systems. The paper analyzes heat transfer mechanisms in energy piles, particularly the role of groundwater circulation in improving heat dissipation and overall system performance. It also discusses optimized design considerations, performance metrics, and economics, highlighting the critical role of site-specific conditions from thorough site surveys and strategic planning of adaptive management to adjust system operations based on real-time demand in optimizing the benefits of geothermal energy systems. This review serves as a comprehensive guide for engineers and researchers in the effective application of energy piles within urban infrastructure, thereby supporting sustainable urban development and mitigating the urban heat island effect. Full article

Ground source heat pump (GSHP) systems have been widely used in the field of shallow geothermal heating and cooling because of their high thermal efficiency and environmental friendliness. A borehole heat exchanger (BHE) is the key part of a ground source heat pump system, and its performance and investment cost have a direct and significant impact on the performance and cost of the whole system. The ground temperature gradient, air temperature, seepage flow rate, and injection flow rate affect the heat exchange performance of BHEs, but most of the research on BHEs lacks field test verification. Therefore, this study relied on the results of a field thermal response test (TRT) based on a distributed optical fiber temperature sensor (DOFTS) and site hydrological, geological, and geothermal data to establish a corrected numerical model of buried pipe heat transfer and carry out the heat transfer performance analysis of a buried pipe in the heating season. The results showed that the ground temperature gradient of the test site was about 3.0 °C/100 m, and the temperature of the constant-temperature layer was about 9.17 °C. Increasing the air temperature could improve the heat transfer performance. The temperature of the surrounding rock and soil mass of the single pipe spread uniformly, and the closer it was to the buried pipe, the lower the temperature. When there is groundwater seepage, the seepage carries the cold energy generated by a buried pipe’s heat transfer through heat convection to form a plume zone, which can effectively alleviate the phenomenon of cold accumulation. With an increase in seepage velocity, the heat transfer of the buried pipe increases nonlinearly. The heat transfer performance can be improved by appropriately reducing the temperature and velocity of the injected fluid. Selecting a backfill material with higher thermal conductivity than the ground body can improve the heat transfer performance. These research results can provide support for the optimization of the heat transfer performance of a buried tube heat exchanger. Full article

The use of geothermal borehole heat exchangers (BHEs) in combination with ground-source heat pumps represents an important part of shallow geothermal energy production, which is already used worldwide and becoming more and more important. Different measurement techniques are available to examine a BHE field while it is in operation. In this study, a field with 54 BHEs up to a depth of 120 m below ground level was analyzed using fiber optic cables. A distributed temperature sensing (DTS) concept was developed by equipping several BHEs with dual-ended hybrid cables. The individual fiber optics were collected in a distributor shaft, and multiple measurements were carried out during active and inactive operation of the field. The field trial was carried out on a converted, partly retrofitted, residential complex, “Lagarde Campus”, in Bamberg, Upper Franconia, Germany. Groundwater and lithological changes are visible in the depth-resolved temperature profiles throughout the whole BHE field. Full article

This research examines the integration of geological and hydrogeological data in numerical aquifer model simulations, with a particular focus on the urban area of Torino, Italy. The role of groundwater resources in urban sustainability is analysed. The objective is to integrate open-loop geothermal plants into the district heating network of IREN S.p.A. Two case studies are examined: the Torino Nord area and the Moncalieri area, both of which host district heating plants. The work entails the collection and analysis of data from a variety of sources, including geognostic surveys and permeability tests, in order to construct a three-dimensional numerical model of the surface aquifer. Models were built using the public MODFLOW 6 (model of groundwater flow) code and calibrated using PESTHP (High Performance of Model Independent Parameter Estimation and Uncertainty Analysis). Results indicate the potential of urban aquifers as renewable energy sources and the necessity of comprehensive geological and hydrogeological assessments for optimal ground water heat pump (GWHP) system installation. This paper emphasises the significance of sustainable water management in the context of climate change and urbanisation challenges. Full article

In accordance with the programme of closure works and the implementation of ecological spatial rehabilitation in the area of the Slovenian coal mine Trbovlje–Hrastnik (RTH), there is a great opportunity to exploit shallow geothermal energy from water and ground sources. In the RTH area, there is great energy potential in the utilisation of underground water and heat from the earth. In our research, we have focussed on the use of geothermal energy with heat pumps from groundwater (water/water system) and from ground collectors and wells up to a depth of 150 m (rock/water system). With the water/water system, we have an average of 2.7 MW of thermal energy available, with the rock/water system having 7.5 kW of thermal energy from a 150 m deep well. With the rock/water system in particular, the development of an industrial zone in the RTH area can also provide for a greater demand for thermal energy. The thermal energy obtained in this way is utilised via heat pumps to heat and cool commercial, residential and industrial buildings. The utilisation of shallow geothermal energy can make a major contribution to carbon neutrality, as the use of geothermal energy has no negative impact on the environment and causes no greenhouse gas emissions. The aim of the paper is to provide an overview of the methods used to analyse heat storage in aquifers of abandoned coal mines, to represent these storages in RTH with a basic mathematical–statistical inventory of what is happening in the aquifer, and to investigate the possibility of using shallow geothermal energy with the help of modelling the use of shallow geothermal energy. The results and analyses obtained can make an important scientific contribution to the use of geothermal energy from abandoned and closed mines. Full article

Fractured rock mass is extensively distributed in Karst topography regions, and its geological environment is different from that of the quaternary strata. In this study, the influences on geological environment induced by the construction and operation of a large-scale borehole group of ground source heat pumps are analyzed by a thermo-hydro-mechanical (THM) coupling numerical model. It was found that groundwater is redirected as the boreholes can function as channels to the surface, and the flow velocity in the upstream of borehole group is higher than those downstream. This change in groundwater flow enhances heat transfer in the upstream boreholes but may disturb the original groundwater system and impact the local geological environment. Heat accumulation is more likely to occur downstream. The geo-stress concentration appears in the borehole area, mainly due to exaction and increasing with the depth. On the fracture plane, tensile stress and maximum shear stress simultaneously occur on the upstream of boreholes, inducing the possibility of fracturing or the expansion of existing fractures. There is a slight uplift displacement on the surface after the construction of boreholes. The correlations of the above THM phenomena are discussed and analyzed. From the modeling results, it is suggested that the consolidation of backfills can minimize the environmental disturbances in terms of groundwater redirection, thermal accumulation, occurrence of tensile stress, and possible fracturing. This study provides support for the assessment of impacts on geological environments resulting from shallow geothermal development and layout optimization of ground heat exchangers in engineering practices. Full article

Shallow geothermal energy (SGE) is a renewable energy that could contribute to the decarbonatization of the heating and cooling sector. SGE is predominantly harnessed through ground source heat pump (GSHP) systems. The choice of which type of GSHP system depends on various factors. Understanding these factors is crucial for optimizing the efficiency of GSHP systems and fostering their implementation. In this paper, we have analysed the spatial distribution of GSHPs in Slovenia. We identified 1073 groundwater and 1122 ground-coupled heat pump systems with a total heat pump capacity of almost 30 MW. We quantitatively assessed the influence of geological, hydrogeological, and climate conditions on their spatial distribution. Using the χ² test and information value method, we identified hydrogeological conditions as the most influential factor for the GSHP systems’ spatial distribution. We also performed the spatial analysis of geological and hydrogeological data in 22 European countries, including Slovenia. We collected the reported numbers of installed GSHP units in 2020 and were able to distinguish the shares of groundwater and ground-coupled heat pump systems for 12 of these countries. The analysis showed that ground-coupled heat pumps predominate in most countries, even if the natural conditions are favourable for groundwater heat pumps. Full article

This research delves into the potential thermal effects on underground water systems caused by the use of thermal technologies involving extraction and injection wells. We developed a unique approach that combines straightforward calculations with computer-based modeling to evaluate thermal impacts when water flow rates exceed 2 L/s. Our model, based on a system with two wells and a steady water flow, was used to pinpoint the area around the thermal technology where the temperature varied by more than 1 °C. Our findings suggest that the data-based relationships we derived from our model calculations provide a cautious estimate of the size of the affected area, or ‘thermal cloud’. However, it is important to note that our model’s assumptions might not fully account for the complex variables present in real-world underground water systems. This highlights a need for more research and testing. A key contribution of our study is the development of a new method to assess the thermal impact of operations involving heat pumps. In conclusion, while our proposed method needs more fine-tuning, it shows promise in estimating temperature changes within water-bearing rock layers, or aquifers. This is crucial in the effective use of thermal technologies while also ensuring the protection and sustainable management of our underground water resources. Full article

Groundwater heat pump (GWHP) systems are acknowledged as renewable and sustainable energy sources that can effectively fulfill the heating and cooling requirements of buildings on a district level. These systems harness geothermal sources available at shallow depths. To ensure the long-term sustainability of the system, the thermally used water is generally reinjected into the aquifer, creating a thermal plume starting from the injection well. Over time, this thermal plume may reach the abstraction well in the long term, potentially leading to a reduction in system efficiency. The operation types have a significant impact on this matter, and their effects have not been extensively studied in the existing literature. Therefore, this study aims to determine the optimal operating configurations for the Northern Gateway Heat Network, a GWHP system established in Colchester, UK. In this study, four distinct operation types are considered: (1) continuous heating (actual system), (2) heating and recovery, (3) heating and cooling, and (4) aquifer thermal energy storage (ATES). The results indicate that ATES operation yields the highest thermal energy output due to its ability to benefit from stored energy from the previous operation. However, implementing the ATES system may encounter challenges due to factors such as well development, hydraulic conductivity, and hydraulic gradient. On the other hand, implementing heating and cooling operations does not require additional considerations and offers not only free cooling to buildings but also a delay in thermal feedback time. Full article

The article presents a new carbon-free heat production technology for district heating, which consists of a combined heat and power generation fuel cell (FC CHP) with CO₂ capture and a two-stage cascade high-temperature heat pump (TCHHP). The FC generates heat and electricity, the latter being used to drive the compressors of the TCHHP. During the winter period, the water temperature achieved can occasionally be too low, so it would be heated up with hydrogen gas boilers. The hydrogen would be produced by reforming natural gas, synthetic methane, or biogas. The results are presented with natural gas utilization—the ratio between the obtained heat flow transferred directly to the water for district heating and the input heat flow of natural gas. In the case of a return water temperature of 60 °C and district heating temperature of 85 °C, the TCHHP, whose heat source is groundwater, achieves plant efficiency of 270.04% in relation to the higher heating value (HHV) and 241.74% in relation to the lower heating value (LHV) of natural gas. A case with a TCHHP whose heat source is low-temperature geothermal water achieves a plant efficiency of 361.36% in relation to the HHV and 323.49% in relation to the LHV. Full article

Using low-temperature (shallow) groundwater as a heat source or heat sink is a common practice to supply space heating or cooling, especially in the United States, Canada, China, and several European countries. The groundwater heat pump (GWHP) system has been extensively studied in recent decades using numerical approaches, which have some limitations in understanding the soil’s thermal behavior. Therefore, a laboratory-scale experimental study involving cooling tests was carried out to investigate the impact of GWHP on system performance and sustainability with varying groundwater flow velocities and injection and abstraction rates. The results demonstrated that groundwater flow velocity, as well as injection and abstraction rates, significantly impact thermal plume development. Higher injection and abstraction rates create a larger thermal plume, thereby decreasing abstraction temperature. However, groundwater flow prevents heat development around the well by dispersing the heat in the groundwater flow direction. Furthermore, the results indicate that the energy gain only increased by 81% and 107%, with a respective increase of 100% and 200% in injection and abstraction rates. Full article

The exploitation and utilization of shallow geothermal energy are of great significance to realizing China’s “double carbon” goal and promoting a green economy and social development. However, many projects using ground source heat pumps to exploit shallow geothermal energy have disrupted the thermal balance of the geothermal field due to insufficient preliminary research, affecting the sustainable utilization of shallow geothermal energy. Therefore, a 3D groundwater–thermal coupling model was established in this paper using the geotemperature data of a ground source heat pump system in Xi’an. This study investigated the response characteristics of the groundwater–thermal system to the ground source heat pump system using the numerical simulation method and discussed the optimal layout scheme of the system on this basis. After years of simulation, it was found that long-term operation of the ground source heat pump system under actual operation produces “cold accumulation”. In addition to artificial intervention of the groundwater flow field, the effects of the system operating parameters and layout settings are also investigated to alleviate this cold accumulation. The results show that changing the operating parameters so that the heat transfer is the same in winter and summer, cross-locating the cooling holes with the heating holes, and placing multiple pumping and recharge wells downstream can alleviate the cold accumulation in the heat exchange zone. The results of this numerical simulation study provide an important reference for solutions to mitigate the accumulation of ground cold and heat in developing shallow geothermal energy using borehole heat exchangers and to suppress the downstream geotemperature disturbance via the ground source heat pump system. Full article
