Search Results (48)

Magnetic induction phase shift is a promising technology for the detection of cerebral hemorrhage, owing to its nonradioactive, noninvasive, and real-time detection properties. To enhance the detection sensitivity and linearity, a zero-flow sensor was proposed. The uniform primary magnetic field and its counteraction were achieved. Phase-change responses to solutions of varying conductivities and rabbits with cerebral hemorrhage were investigated and compared with traditional sensors. The sensitivities in detecting solutions with different conductivities were 1.84, 1.39, and 1.22 times higher than those for a low-pass birdcage coil, planar gradiometer, and Bx-sensor, respectively. The results for rabbits with cerebral hemorrhage showed that the sensitivities increased by 1.17, 1.67, and 6.3 times compared with a low-pass birdcage coil, symmetric cancelation-type sensor, and single co-axial coil, respectively. This sensor could accurately detect three stages in the pathological process. Blood loss of 1 mL meant that the compensatory mechanism of cerebrospinal fluid began to fail, and 1.4 mL of blood loss meant that the compensatory mechanism failed completely. The adjusted R-squared value of the first-order linear fit was above 0.98 in both physical and animal experiments, indicating that high detection linearity was achieved. The proposed sensor provides a more accurate method for cerebral hemorrhage detection and facilitates the practical application of magnetic induction phase shift in pre-hospital and bedside real-time detection. Full article

In the past few decades, there has been a notable technological advancement in geophysical sensors. In the case of magnetometry, several sensors were used, having the common feature of being miniaturized and lightweight, thus idoneous to be carried by UAVs in drone-borne magnetometric surveys. A common feature is that their sensitivity ranges from 0.1 to about 200 nT, thus not comparable to that of optically pumped, standard fluxgate or even proton magnetometers. However, their low cost, volume and weight remain very interesting features of these sensors. In fact, such sensors have the common feature of being very inexpensive, so new ways of making surveys using many of these sensors could be devised, in addition to the possibility, even with limited resources, of creating gradiometers by combining two or more of them. In this paper, we explore the range of applicability of small tri-axial magnetometers commonly used for attitude determination in several devices. We compare the results of surveys performed with standard professional geophysical instruments with those obtained using these sensors and find that in the presence of strongly magnetized sources, they succeeded in identifying the main anomalies. Full article

Accurate Digital Elevation Models (DEMs) are essential for precise terrain gravity field calculations, which are critical in gravity field modeling, airborne gravimeter and gradiometer calibration, and geophysical inversion. This study evaluates the accuracy of various satellite DEMs by comparing them with a LiDAR DEM at the Wudalianchi test site, a location requiring ultra-accurate terrain gravity fields. Major DEM error sources, particularly those related to vegetation, were identified and corrected using a least squares method that integrates canopy height, vegetation cover, NDVI, and airborne LiDAR DEM data. The impact of DEM vegetation errors on terrain gravity anomalies and gravity gradients was quantified using a partitioned adaptive gravity forward-modeling method at different measurement heights. The results indicate that the TanDEM-X DEM and AW3D30 DEM exhibit the highest vertical accuracy among the satellite DEMs evaluated in the Wudalianchi area. Vegetation significantly affects DEM accuracy, with vegetation-related errors causing an impact of approximately 0.17 mGal (RMS) on surface gravity anomalies. This effect is more pronounced in densely vegetated and volcanic regions. At 100 m above the surface and at an altitude of 1 km, vegetation height affects gravity anomalies by approximately 0.12 mGal and 0.07 mGal, respectively. Additionally, vegetation height impacts the vertical gravity gradient at 100 m above the surface by approximately 4.20 E (RMS), with errors up to 48.84 E over vegetation covered areas. The findings underscore the critical importance of using DEMs with vegetation errors removed for high-precision terrain gravity and gravity gradient modeling, particularly in applications such as airborne gravimeter and gradiometer calibration. Full article

Differential coils are frequently implemented in inductive sensing systems. They can be considered as a single coil that is made up of two or more subcoils, wound in series opposition. They can be used on the transmit or receive side of measurement systems, and, if designed correctly, ensure no coupling between coils under background conditions. By cancelling background coupling, the receive electronics only needs to be able to measure the change in coupling produced by a target. This allows for a more efficient use of the dynamic range, and for larger receive-side amplifier gain, thereby improving SNR. When subcoils are not electrically similar, it can be hard to engineer the coil to be perfectly balanced across a wide bandwidth. This paper presents an analytical model of a resonant differential coil pair that is tested and applied on a planar metal detector for the detection of buried objects. The model demonstrates the capability to balance an arbitrary differential coil pair, which has a broad applicability across a range of inductive sensor applications such as metal detection and non-destructive testing. The method is applied to the practical system. The results show that the correction resulting from this method ensures a stable balance across a significantly enhanced bandwidth. In the case studied here, the bandwidth of the experimental system is increased from 20 kHz to 90 kHz. Full article

Gravity measurements have important applications in geophysics, resource exploration, geodesy, and inertial navigation. The range of classical gravimetry includes laser interferometer (LI)-based absolute gravimeters, spring relative gravimeters, superconducting gravimeters, airborne/marine gravimeters, micro-electromechanical-system (MEMS) gravimeters, as well as gravity satellites and satellite altimetry. Atomic gravimetry is a new absolute gravity measurement technology based on atom interferometers (AIs) and features zero drift, long-term stability, long-term continuous measurements, and high precision. Atomic gravimetry has been used to measure static, marine, and airborne gravity; gravity gradient; as well as acceleration to test the weak equivalence principle at the China Space Station. In this paper, classical gravimetry is introduced, and the research progress on static and airborne/marine atomic gravimeters, space AIs, and atomic gravity gradiometers is reviewed. In addition, classical and atomic gravimetry are compared. Future atomic gravimetry development trends are also discussed with the aim of jointly promoting the further development of gravity measurement technologies alongside classical gravimetry. Full article

The use of magnetometers arranged in a gradiometer configuration offers a practical and widely used solution, particularly in archaeological applications where the sources of interest are generally shallow. Since magnetic anomalies due to archaeological remains often have low amplitudes, highly sensitive magnetic sensors are kept very close to the ground to reveal buried structures. However, the deployment of Unmanned Aerial Vehicles (UAVs) is increasingly becoming a reliable and valuable tool for the acquisition of magnetic data, providing uniform coverage of large areas and access to even very steep terrain, saving time and reducing risks. However, the application of a vertical gradiometer for drone-borne measurements is still challenging due to the instability of the system drone magnetometer in flight and noise issues due to the magnetic interference of the mobile platform or related to the oscillation of the suspended sensors. We present the implementation of a magnetic vertical gradiometer UAV system and its use in an archaeological area of Southern Italy. To reduce the magnetic and electromagnetic noise caused by the aircraft, the magnetometer was suspended 3m below the drone using ropes. A Continuous Wavelet Transform analysis of data collected in controlled tests confirmed that several characteristic power spectrum peaks occur at frequencies compatible with the magnetometer oscillations. This noise was then eliminated with a properly designed low-pass filter. The resulting drone-borne vertical gradient data compare very well with ground-based magnetic measurements collected in the same area and taken as a control dataset. Full article

The performance of the capacitive gap-sensing system plays a critical role in a satellite-based gravity gradiometer that is developed using an electrostatic accelerometer. The capacitive sensing gain mainly depends on the stabilized injection bias amplitude, the gain of the transformer bridge, and the trans-impedance amplifier. Previous studies have indicated that amplitude noise is the main factor influencing the noise of capacitive displacement detection. Analyzing the capacitive gap-sensing system indicates that the amplitude, frequency, phase, and broadband noises of the stabilized injection bias have varying levels of influence on the performance of the detection system. This paper establishes a model to clarify the mentioned effects. The validation of the sub-tests demonstrates that the analysis and evaluation results of various noise coefficients are highly consistent with the model’s predicted outcomes. Full article

Optically pumped gradiometers have long been utilized in measurement in the International Geomagnetic Reference Field (IGRF). With advancements in technologies such as laser diodes and microfabrication, integrated gradiometers with compact sizes have become available, enabling improvements in magnetoencephalography and fetal magnetocardiography within shielded spaces. Moreover, there is a growing interest in the potential of achieving biomagnetic source detection without shielding. This review focuses on recent developments in optically pumped magnetic field gradiometers, including various fabrication methods and measurement schemes. The strengths and weaknesses of different types of optically pumped gradiometers are also analyzed. Full article

The Korean Pathfinder Lunar Orbiter (KPLO)-MAGnetometer (KMAG) consists of three triaxial fluxgate sensors (MAG1, MAG2, and MAG3) that measure the magnetic field around the Moon. The three sensors are mounted in the order MAG3, MAG2, and MAG1 inside a 1.2 m long boom, away from the satellite body. Before it arrived on the Moon, we compared the magnetic field measurements taken by DSCOVR and KPLO in solar wind to verify the measurement performance of the KMAG instrument. We found that there were artificial disturbances in the KMAG measurement data, such as step-like and spike-like disturbances, which were produced by the spacecraft body. To remove spacecraft-generated disturbances, we applied a multi-sensor method, employing the gradiometer technique and principal component analysis, using KMAG magnetic field data, and confirmed the successful elimination of spacecraft-generated disturbances. In the future, the proposed multi-sensor method is expected to clean the magnetic field data measured onboard the KPLO from the lunar orbit. Full article

To calibrate airborne gravity gradiometers currently in development in China, it is urgent to build an airborne gravity gradiometer test site. The site’s selection depends on the preknowledge of high-resolution gravity and gradient structures. The residual terrain modelling (RTM) technique is generally applied to recover the short-scale gravity field signals. However, due to limitations in the quality and resolution of density models, RTM terrain generally assumes a constant density. This assumption can introduce significant errors in areas with substantial density anomalies and of reggued terrain, such as volcano areas. In this study, we promote a method to determine a high-resolution gravity field by integrating long-wavelength signals generated by EGM2008 with short-wavelength signals from terrain relief and shallow density anomalies. These short wavelength signals are recovered using the RTM technique with both constant density and density anomalies obtained through the equivalent source layer (ESL) method, utilizing sparse terrestrial gravity measurements. Compared to the recovery rate of $54.62\%$ using the classical RTM method, the recovery rate increases to $86.22\%$ after involving density anomalies. With this method, we investigate the gravity field signals over the Wudalianchi Volcano Field (WVF) both on the Earth’s surface and at a flight height of 100 m above the terrain. The contribution of each part and their attenuation characters are studied. In particular, the 5 km × 5 km area surrounding Bijiashan (BJS) and Wohushan (WHS) volcanos shows a strong gravity signature, making it a good candidate for the test site location. This study gives the location of the airborne gravity gradiometer test site which is an essential step in the instruments’ development. Furthermore, the method presented in this study offers a foundational framework for future data processing within the test site. Full article

The electrostatic gravity gradiometer carried by the Gravity field and steady-state Ocean Circulation Explorer (GOCE) satellite is affected by accelerometer noise and other factors; hence, the observation data present complex error characteristics in the low-frequency domain. The accuracy of the recovered gravity field will be directly affected by the design of the filters based on the error characteristics of the gradient data. In this study, the applicability of various filters to different errors in observation is evaluated, such as the $1/f$ error and the orbital frequency errors. The experimental results show that the cascade filter (DARMA), which is formed of a differential filter and an autoregressive moving average filter (ARMA) filter, has the best accuracy for the characteristic of the $1/f$ low-frequency error. The strategy of introducing empirical parameters can reduce the orbital frequency errors, whereas the application of a notch filter will worsen the final solution. Frequent orbit changes and other changes in the observed environment have little impact on the new version gradient data (the data product is coded 0202), while the influence cannot be ignored on the results of the old version data (the data product is coded 0103). The influence can be effectively minimized by shortening the length of the arc. By analyzing the above experimental findings, it can be concluded that the inversion accuracy can be effectively improved by choosing the appropriate filter combination and filter estimation frequency when solving the gravity field model based on the gradient data of the GOCE satellite. This is of reference significance for the updating of the existing models. Full article

Underwater magnetic surveying serves as the fundamental prerequisite for detecting sensitive underwater targets and magnetically susceptible submerged objects. However, when utilizing magnetic gradient tensor measurements for underwater positioning, the stability of the measurement apparatus can be significantly affected by hydrodynamic disturbances in the underwater environment, thereby having a substantial impact on data quality. Autonomous Underwater Vehicles (AUV) are unmanned underwater robots designed to independently perform various tasks and operations in underwater environments. In order to ensure the quality of data collection, this paper proposes a structure utilizing an Autonomous Underwater Vehicles platform equipped with a three-component magnetic gradiometer. This structure employs second-order tensor positioning algorithms and vertical gradient positioning algorithms, coupled with the Autonomous Underwater Vehicles’s inherent vertical profile motion, to effectively achieve the precise positioning of underwater cables. Simulation results indicate that, in the absence of geomagnetic background noise, both horizontal and vertical structures yield favorable positioning results. However, when introducing background noise of 40,000 nT, the horizontal structure exhibits larger positioning errors, whereas the vertical structure demonstrates smaller errors. Experimental results show that in near-field scenarios, both structures achieve relatively similar positioning accuracy. Nevertheless, under identical distances in the far field, the vertical structure reduces errors by a minimum of 30.78% compared to the horizontal structure, thereby confirming the feasibility of integrating magnetic gradient tensor measurement structures with Autonomous Underwater Vehicles platforms. Full article

Recently, a new kind of sensor applicable in magnetoencephalography (MEG) has been presented: a solid-state yttrium-iron garnet magnetometer (YIGM). The feasibility of yttrium-iron garnet magnetometers (YIGMs) was demonstrated in an alpha-rhythm registration experiment. In this paper, we propose the analysis of lead-field matrices for different possible multi-channel on-scalp sensor layouts using YIGMs with respect to information theory. Real noise levels of the new sensor were used to compute signal-to-noise ratio (SNR) and total information capacity (TiC), and compared with corresponding metrics that can be obtained with well-established MEG systems based on superconducting quantum interference devices (SQUIDs) and optically pumped magnetometers (OPMs). The results showed that due to YIGMs’ proximity to the subject’s scalp, they outperform SQUIDs and OPMs at their respective noise levels in terms of SNR and TiC. However, the current noise levels of YIGM sensors are unfortunately insufficient for constructing a multichannel YIG-MEG system. This simulation study provides insight into the direction for further development of YIGM sensors to create a multi-channel MEG system, namely, by decreasing the noise levels of sensors. Full article

Optically pumped magnetometers (OPMs) can capture brain activity but are susceptible to magnetic noise. The objective of this study was to evaluate a novel methodology used to reduce magnetic noise in OPM measurements. A portable magnetoencephalography (MEG) prototype was developed with OPMs. The OPMs were divided into primary sensors and reference sensors. For each primary sensor, a synthetic gradiometer (SG) was constructed by computing a secondary sensor that simulated noise with signals from the reference sensors. MEG data from a phantom with known source signals and six human participants were used to assess the efficacy of the SGs. Magnetic noise in the OPM data appeared predominantly in a low frequency range (<4 Hz) and varied among OPMs. The SGs significantly reduced magnetic noise (p < 0.01), enhanced the signal-to-noise ratio (SNR) (p < 0.001) and improved the accuracy of source localization (p < 0.02). The SGs precisely revealed movement-evoked magnetic fields in MEG data recorded from human participants. SGs provided an effective method to enhance SNR and improve the accuracy of source localization by suppressing noise. Software-simulated SGs may provide new opportunities regarding the use of OPM measurements in various clinical and research applications, especially those in which movement is relevant. Full article

We report a specially designed magnetic field gradiometer based on a single elliptical planar Hall effect (PHE) sensor, which allows measuring magnetic field at nine different positions in a 4 mm length scale. The gradiometer detects magnetic field gradients with equivalent gradient magnetic noises of ∼958, ∼192, ∼51, and ∼26 nT/m√ Hz (pT/mm√Hz) at 0.1, 1, 10, and 50 Hz, respectively. The performance of the gradiometer is tested in ambient conditions by measuring the field gradient induced by electric currents driven in a long straight wire. This gradiometer is expected to be highly useful for the measurement of magnetic field gradients in confined areas for its small footprint, low noise, scalability, simple design, and low costs. Full article
