Search Results (60)

Search Parameters:
Keywords = gear hardening

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
20 pages, 1890 KiB
Review
Laser Surface Hardening of Carburized Steels: A Review of Process Parameters and Application in Gear Manufacturing
by Janusz Kluczyński, Katarzyna Jasik, Jakub Łuszczek and Jakub Pokropek
Materials 2025, 18(15), 3623; https://doi.org/10.3390/ma18153623 - 1 Aug 2025
Viewed by 195
Abstract
This article provides a comprehensive overview of recent studies concerning laser heat treatment (LHT) of structural and tool steels, with particular attention to the 21NiCrMo2 steel used for carburized gear wheels. Analysis includes the influence of critical laser processing conditions—including power output, motion [...] Read more.
This article provides a comprehensive overview of recent studies concerning laser heat treatment (LHT) of structural and tool steels, with particular attention to the 21NiCrMo2 steel used for carburized gear wheels. Analysis includes the influence of critical laser processing conditions—including power output, motion speed, spot size, and focusing distance—on surface microhardness, hardening depth, and microstructure development. The findings indicate that the energy density is the dominant factor that affects the outcomes of LHT. Optimal results, in the form of a high surface microhardness and a sufficient depth of hardening, were achieved within the energy density range of 80–130 J/mm2, allowing for martensitic transformation while avoiding defects such as melting or cracking. At densities below 50 J/mm2, incomplete hardening occurred with minimal microhardness improvement. On the contrary, densities exceeding 150–180 J/mm2 caused surface overheating and degradation. For carburized 21NiCrMo2 steel, the most effective parameters included 450–1050 W laser power, 1.7–2.5 mm/s scanning speed, and 2.0–2.3 mm beam diameter. The review confirms that process control through energy-based parameters allows for reliable prediction and optimization of LHT for industrial applications, particularly in components exposed to cyclic loads. Full article
(This article belongs to the Special Issue Advanced Machining and Technologies in Materials Science)
Show Figures

Figure 1

20 pages, 5070 KiB
Article
Electrochemical Noise Analysis in Passivated Martensitic Precipitation-Hardening Stainless Steels in H2SO4 and NaCl Solutions
by Facundo Almeraya-Calderon, Miguel Villegas-Tovar, Erick Maldonado-Bandala, Demetrio Nieves-Mendoza, Ce Tochtli Méndez-Ramírez, Miguel Angel Baltazar-Zamora, Javier Olguín-Coca, Luis Daimir Lopez-Leon, Griselda Santiago-Hurtado, Verónica Almaguer-Cantu, Jesus Manuel Jaquez-Muñoz and Citlalli Gaona-Tiburcio
Metals 2025, 15(8), 837; https://doi.org/10.3390/met15080837 - 26 Jul 2025
Viewed by 312
Abstract
Precipitation-hardenable stainless steels (PHSS) are widely used in various applications in the aeronautical industry such in as landing gear supports, actuators, and fasteners, among others. This research aims to study the pitting corrosion behavior of passivated martensitic precipitation-hardening stainless steel, which underwent passivation [...] Read more.
Precipitation-hardenable stainless steels (PHSS) are widely used in various applications in the aeronautical industry such in as landing gear supports, actuators, and fasteners, among others. This research aims to study the pitting corrosion behavior of passivated martensitic precipitation-hardening stainless steel, which underwent passivation for 120 min at 25 °C and 50 °C in citric and nitric acid baths before being immersed in solutions containing 1 wt.% sulfuric acid (H2SO4) and 5 wt.% sodium chloride (NaCl). Electrochemical characterization was realized employing electrochemical noise (EN), while microstructural analysis employed scanning electron microscopy (SEM). The result indicates that EN reflects localized pitting corrosion mechanisms. Samples exposed to H2SO4 revealed activation–passivation behavior, whereas those immersed in NaCl exhibited pseudo-passivation, indicative of an unstable oxide film. Current densities in both solutions ranged from 10−3 to 10−5 mA/cm2, confirming susceptibility to localized pitting corrosion in all test conditions. The susceptibility to localized attack is associated with the generation of secondary oxides on the surface. Full article
(This article belongs to the Special Issue Recent Advances in High-Performance Steel)
Show Figures

Figure 1

23 pages, 13109 KiB
Article
Study of the Effect of Regulating Alloying Elements and Optimizing Heat Treatment Processes on the Microstructure Properties of 20MnCr5 Steel Gears
by Li Luo, Yong Chen, Fucheng Zhao, Weifeng Hua, Xu Song, Zhengyun Xu and Zhicheng Jia
Lubricants 2025, 13(5), 202; https://doi.org/10.3390/lubricants13050202 - 1 May 2025
Viewed by 688
Abstract
To optimize heat treatment of gears for high-end equipment and enhance their fatigue resistance, this paper studied the effects of Al, Mn and Cr content on surface microstructure, i.e., martensite, retained austenite, grain size, hardened layer depth and residual stress under different carburizing [...] Read more.
To optimize heat treatment of gears for high-end equipment and enhance their fatigue resistance, this paper studied the effects of Al, Mn and Cr content on surface microstructure, i.e., martensite, retained austenite, grain size, hardened layer depth and residual stress under different carburizing temperatures and low tempering of 20MnCr5 steel FZG gear. With numerical simulation combined with experimental verification, this paper establishes a simulation model for the carburizing process of 20MnCr5 steel FZG gear, analyzing the microstructure and retained austenite volume of the gear surface, after carburizing and quenching, by a scanning electronic microscope (SEM) and X-ray diffraction (XRD). In addition, the paper reveals the influence of the optimized heat treatment on the residual stress of the gear regulated with Al, Mn and Cr content in the meshing wear range of 200~280 µm. This study provides a guiding model theory and experimental verification for regulating proportions of alloying elements and optimizing the heat treatment process of low-carbon-alloy steel. Full article
(This article belongs to the Special Issue Novel Tribology in Drivetrain Components)
Show Figures

Figure 1

19 pages, 16287 KiB
Article
Effect of In-Situ Pulse Current on Microstructure and Mechanical Properties of AISI 9310 Gear Steel by Laser Powder Directed Energy Deposition
by Cenchao Xie, Fei Yang, Peng He, Wenfa Liu, Qiang Feng, Liucheng Zhou, Ping Liu and Xin Sun
Machines 2025, 13(4), 308; https://doi.org/10.3390/machines13040308 - 10 Apr 2025
Viewed by 426
Abstract
AISI 9310 gear steel, renowned for its high hardenability, is widely employed in the manufacturing of aerospace gear components. Laser powder directed energy deposition (LP-DED) takes advantage of a laser heat source to melt metal powder, thus creating a molten pool and facilitating [...] Read more.
AISI 9310 gear steel, renowned for its high hardenability, is widely employed in the manufacturing of aerospace gear components. Laser powder directed energy deposition (LP-DED) takes advantage of a laser heat source to melt metal powder, thus creating a molten pool and facilitating the quick achievement of material deposition and shaping. However, the issue of forming quality has been acting as a significant constraint on the development of LP-DED. To address this concern, the present research endeavors to enhance LP-DED by leveraging the assisted application of in situ pulsed current, with the aim of preparing high-quality deposited specimens. It has been observed that the pulsed current does not trigger any phase transformation within the deposition zone. Instead, the Joule heating effect brought about by the current serves as a catalyst for grain growth. Meanwhile, the electric-plastic effect of the pulsed current results in an elevation of plastic deformation. Moreover, it facilitates the transformation of dislocation defects from simple dislocation lines to intricate dislocation networks, consequently leading to a substantial increase in dislocation density. Furthermore, the contraction force induced by the current exerts a compressive influence on the molten pool, which in turn accelerates the discharge of gas. Full article
(This article belongs to the Section Advanced Manufacturing)
Show Figures

Figure 1

7 pages, 6129 KiB
Proceeding Paper
Lock-in Thermography for Surface Treatment Characterization in Gears
by Francesca Maria Curà, Luca Corsaro and Ludovica Tromba
Eng. Proc. 2025, 85(1), 2; https://doi.org/10.3390/engproc2025085002 - 13 Feb 2025
Cited by 1 | Viewed by 362
Abstract
Mechanical gears are essential in power transmission systems across various industrial applications. Their performance is critically influenced by residual stresses from manufacturing processes like induction hardening, case hardening, and shot peening. Surface compressive residual stresses enhance resistance to pitting fatigue, bending fatigue and [...] Read more.
Mechanical gears are essential in power transmission systems across various industrial applications. Their performance is critically influenced by residual stresses from manufacturing processes like induction hardening, case hardening, and shot peening. Surface compressive residual stresses enhance resistance to pitting fatigue, bending fatigue and crack propagation, improving overall hardness. In the present work, a Non-Destructive Thermographic method (Active thermography), based on measurement of the thermal diffusivity parameter, is presented to characterize the surface treatments applied to gears. Surface hardness was measured using a micro-hardness tester, and residual stresses were determined with an X-Ray diffractometer, showing variations due to surface treatments. The variation in the thermal diffusivity parameter, obtained using the Slope Method, was found to be an indicator of the surface treatments’ effectiveness. Full article
Show Figures

Figure 1

21 pages, 8349 KiB
Article
Quality Evaluation of Effective Abrasive Grains Micro-Edge Honing Based on Trapezoidal Fuzzy Analytic Hierarchy Process and Set Pair Analysis
by Jie Su, Yuan Liang, Yue Yu, Fuwei Wang, Jiancong Zhou, Lin Liu and Yang Gao
Appl. Sci. 2024, 14(23), 10939; https://doi.org/10.3390/app142310939 - 25 Nov 2024
Viewed by 748
Abstract
Studying the factors affecting machining accuracy, surface quality, and machining efficiency in the powerful honing machining process system, analyzing the basic law between various errors and machining quality, exploring the method of evaluating the quality of honing, and improving the machining quality and [...] Read more.
Studying the factors affecting machining accuracy, surface quality, and machining efficiency in the powerful honing machining process system, analyzing the basic law between various errors and machining quality, exploring the method of evaluating the quality of honing, and improving the machining quality and transmission performance of hardened gears has important engineering application value. Firstly, this paper establishes an effective abrasive grains micro-edge honing quality evaluation model, proposes a method based on the Trapezoidal Fuzzy Analytic Hierarchy Process (Tra-FAHP) and Set Pair Analysis (SPA) to comprehensively evaluate the quality of the honing process, and obtains the influence weights of each factor on the quality of honing. Secondly, the paper analyzes the influence rules of three types of abrasive grain sizes on helix error, tooth pitch error, tooth profile error, surface roughness, and honing efficiency. Finally, the correctness of the established comprehensive evaluation model of honing quality was verified with the threshold method and weights. The research results show that the model can correctly evaluate the quality of hardened gear honing and can be applied to studying the influence of abrasive grain micro-edge honing on machining characteristics. Full article
(This article belongs to the Section Surface Sciences and Technology)
Show Figures

Figure 1

21 pages, 22111 KiB
Article
Effect of Al Element on Retained Austenite, Residual Compressive Stress, and Contact Fatigue Life of Carburized and Quenched 20MnCr5 Steel Gear
by Yong Chen, Li Luo, Yuquan Zhang, Xingyun Zhou, Deshan Zeng and Fucheng Yu
Materials 2024, 17(23), 5764; https://doi.org/10.3390/ma17235764 - 25 Nov 2024
Cited by 1 | Viewed by 1239
Abstract
To improve the contact fatigue life of gears, we studied the effect of adding a certain proportion of the Al element to a 20MnCr5 steel FZG spur gear under different heat treatment processes, characterizing the retained austenite and residual compressive stress on the [...] Read more.
To improve the contact fatigue life of gears, we studied the effect of adding a certain proportion of the Al element to a 20MnCr5 steel FZG spur gear under different heat treatment processes, characterizing the retained austenite and residual compressive stress on the tooth surface. The stability of the microstructure grain size on the gear surface under different heat treatment processes was studied, and the surface microstructure, phase structure, and composition of the gear were characterized using scanning electron microscopy (SEM) and X-ray diffraction (XRD). The changes in the retained austenite content and grain size on the gear surface at a microscale of 2–100 μm were investigated. In addition, this study revealed the effect of adding the Al element and the optimization of the carburizing and quenching process on the residual compressive stress on the gear surface at a depth range of 200–280 μm. The effect of higher residual compressive stress and fewer non-metallic inclusions on the gear surface on the stress intensity factor of fatigue crack propagation was considered, along with the effect of deeper hardened layers on the improvement in wear resistance. The experiments in this study significantly improved the contact fatigue life of 20MnCr5 steel gears. Full article
Show Figures

Figure 1

15 pages, 11402 KiB
Article
The Corrosion Fatigue Behavior and Mechanism of AerMet 100 Steel in 3.5% NaCl at Room Temperature
by Donghua Tian, Can Xu, Hongli Wang, Chengchuan Wu and Yonghao Lu
Materials 2024, 17(20), 5025; https://doi.org/10.3390/ma17205025 - 14 Oct 2024
Cited by 1 | Viewed by 1157
Abstract
AerMet 100 steel is a new type of double-hardened high-strength steel, which is often used as landing gear material in amphibious aircraft. In the present paper, the corrosion fatigue behavior and mechanism of AerMet 100 high-strength steel in a 3.5% NaCl solution was [...] Read more.
AerMet 100 steel is a new type of double-hardened high-strength steel, which is often used as landing gear material in amphibious aircraft. In the present paper, the corrosion fatigue behavior and mechanism of AerMet 100 high-strength steel in a 3.5% NaCl solution was studied by stress-controlled fatigue tests and a series of subsequent characterizations of the fracture surface, microstructure, and cracks. The results indicated that the fatigue life of AerMet 100 high-strength steel decreased with a decrease in the stress level in a 3.5% NaCl solution, satisfying the relationship lgN = −2.69 × 10−3 σ + 6.49. The corrosion fatigue crack usually initiated from the corrosion pit and propagated across the martensitic flat noodles. Meanwhile, the corrosion fatigue crack tip was filled with Cr2O3, Fe2O3, and amorphous material; it propagated in the transgranular mode by a slip dissolution mechanism. This study provides some engineering significant for the fatigue performance of AerMet 100 steel in a 3.5% NaCl solution. Full article
(This article belongs to the Section Corrosion)
Show Figures

Figure 1

14 pages, 5584 KiB
Article
Tooth Surface Deviation Analysis for Continuous Generation Grinding of Internal Gears
by Jianjun Yang, Zhaolong Zhang, Shuai Wang and Jialu Wu
Appl. Sci. 2024, 14(15), 6551; https://doi.org/10.3390/app14156551 - 26 Jul 2024
Cited by 1 | Viewed by 1088
Abstract
In order to resolve the issues of low efficiency and poor precision in the traditional finishing process of hardened internal gears, a method is proposed for calculating the profile curves of a drum-shaped grinding tool suitable for mass finishing of hardened internal gears. [...] Read more.
In order to resolve the issues of low efficiency and poor precision in the traditional finishing process of hardened internal gears, a method is proposed for calculating the profile curves of a drum-shaped grinding tool suitable for mass finishing of hardened internal gears. Additionally, the impact of drum-shaped grinding tool installation errors on the tooth surface deviation of internal gears is analyzed. Firstly, the processing principle for the generation grinding of internal gears by the drum-shaped grinding tool is introduced. Based on differential geometry, meshing theory, and two-degree-of-freedom enveloping method, a mathematical model is developed for the generation grinding of internal gears. Profile curves of the drum-shaped grinding tool are obtained by solving the meshing equation between the drum-shaped grinding tool and the internal gear. Then, the tooth surface equation for the internal gear is derived in the presence of drum-shaped grinding tool installation errors. By discretizing the error tooth surface of the internal gear, the average normal deviation of the tooth surface is calculated. In the end, the distribution of normal deviation on the tooth surface of the internal gear with different drum-shaped grinding tool installation errors is acquired, and the influence of four kinds of installation errors on the tooth surface of the internal gear is analyzed. The sensitive direction is identified for drum-shaped grinding tool installation errors on the tooth surface of the internal gear. Consequently, this research provides a calculation method for the drum-shaped grinding tool fit for high-precision and high-efficiency finishing of mass-produced hardened internal gear and offers a reference for correcting deviation in the tooth surface of internal gear with installation errors of the drum-shaped grinding tool. Full article
Show Figures

Figure 1

19 pages, 7196 KiB
Article
Modeling and Simulation of the Induction Hardening Process: Evaluation of Gear Deformations and Parameter Optimization
by Pedro Maranhão Pinheiro, José Urbano Junio, Lídice Aparecida Pereira Gonçalves, José Ângelo Peixoto da Costa, Alvaro Antonio Villa Ochoa, Kleber Gonçalves Bezerra Alves, Gustavo de Novaes Pires Leite and Paula Suemy Arruda Michima
Processes 2024, 12(7), 1428; https://doi.org/10.3390/pr12071428 - 9 Jul 2024
Cited by 3 | Viewed by 1993
Abstract
This study aimed to analyze and optimize the thermal induction hardening process applied to toothed transmission gears, focusing on thermal aspects, structural deformation, and topology optimization, while exploring the feasibility of various materials and operating conditions. The research simulated thermal and deformation behavior [...] Read more.
This study aimed to analyze and optimize the thermal induction hardening process applied to toothed transmission gears, focusing on thermal aspects, structural deformation, and topology optimization, while exploring the feasibility of various materials and operating conditions. The research simulated thermal and deformation behavior using a computer model, comparing results with experimental data through the Ansys® platform 2022 R1. The methodology encompassed thermal and deformation analyses, topology optimization to identify removable regions without compromising part integrity, and a sensitivity study to evaluate the different materials and operating conditions. This study validates the precision of computational models in predicting thermal and deformation behavior in toothed gears under thermal induction hardening, introducing topology optimizations and alternative materials, and providing novel perspectives for the more efficient and cost-effective manufacturing of these components. Comparative thermal analysis revealed a maximum relative error of less than 6% between temperatures from the computer model and experimental results, while deformation comparisons exhibited a maximum relative error of less than 7%, affirming the simulation model’s accuracy in predicting and managing deformations within acceptable thresholds. Topology optimization successfully pinpointed removable regions without compromising structural integrity, enabling the production of lighter and more economical devices. Future endeavors should concentrate on additional tests to verify the feasibility of reducing power and cooling temperature without compromising product specifications. Furthermore, it is advisable to explore alternative materials and apply the developed methodology in diverse industrial settings to generalize the findings and amplify the impact of the proposed optimizations. Full article
(This article belongs to the Special Issue Heat and Mass Transfer in Energy Engineering)
Show Figures

Figure 1

14 pages, 6830 KiB
Article
Layer Approach to Model Fatigue Strength of Surface-Hardened Components
by Dénes Dobberke, Martin Leitner, Jens Wiebesiek and Jürgen Fröschl
Metals 2024, 14(7), 754; https://doi.org/10.3390/met14070754 - 25 Jun 2024
Viewed by 1963
Abstract
This paper deals with a surface-hardened forged steel that is commonly used for powertrain components like gears, axles or crankshafts. In order to increase static and fatigue strength and to minimise wear, surface treatments like induction hardening lead to a significant microstructural change [...] Read more.
This paper deals with a surface-hardened forged steel that is commonly used for powertrain components like gears, axles or crankshafts. In order to increase static and fatigue strength and to minimise wear, surface treatments like induction hardening lead to a significant microstructural change within heat-affected zones. The aim of this study was to elaborate a method for a reliable computational estimation of the local fatigue strength by considering local material properties. The method is based on experimental test results, where specimens were extracted from forged crankshafts and further heat-treated to investigate the fatigue strength of the unhardened and hardened material condition. The experimental test data were fundamental in defining elaborated Haigh diagrams, enabling a more reliable local fatigue assessment. The comparison of the component safety within the fatigue strength verification for a crankshaft section under alternate bending resulted in 28%-more progressive dimensioning of surface hardened layers. Full article
(This article belongs to the Special Issue Fatigue, Fracture and Damage of Steels)
Show Figures

Figure 1

17 pages, 12044 KiB
Article
Study on the Tribological Properties of DIN 16MnCr5 Steel after Duplex Gas-Nitriding and Pack Boriding
by Rafael Carrera Espinoza, Melvyn Alvarez Vera, Marc Wettlaufer, Manuel Kerl, Stefan Barth, Pablo Moreno Garibaldi, Juan Carlos Díaz Guillen, Héctor Manuel Hernández García, Rita Muñoz Arroyo and Javier A. Ortega
Materials 2024, 17(13), 3057; https://doi.org/10.3390/ma17133057 - 21 Jun 2024
Cited by 5 | Viewed by 1582
Abstract
DIN 16MnCr5 is commonly used in mechanical engineering contact applications such as gears, joint parts, shafts, gear wheels, camshafts, bolts, pins, and cardan joints, among others. This study examined the microstructural and mechanical properties and tribological behavior of different surface treatments applied to [...] Read more.
DIN 16MnCr5 is commonly used in mechanical engineering contact applications such as gears, joint parts, shafts, gear wheels, camshafts, bolts, pins, and cardan joints, among others. This study examined the microstructural and mechanical properties and tribological behavior of different surface treatments applied to DIN 16MnCr5 steel. The samples were hardened at 870 °C for 15 min and then quenched in water. The surface conditions evaluated were as follows: quenched and tempered DIN 16MnCr5 steel samples without surface treatments (control group), quenched and tempered DIN 16MnCr5 steel samples with gas-nitriding at 560 °C for 6 h, quenched and tempered DIN 16MnCr5 steel samples with pack boriding at 950 °C for 4 h, and quenched and tempered DIN 16MnCr5 steel samples with duplex gas-nitriding and pack boriding. Microstructure characterization was carried out using metallographic techniques, optical microscopy, scanning electron microscopy with energy-dispersive spectroscopy, and X-ray diffraction. The mechanical properties were assessed through microhardness and elastic modulus tests using nanoindentation. The tribological behavior was evaluated using pin-on-disc tests following the ASTM G99-17 standard procedure under dry sliding conditions. The results indicated that the surface treated with duplex gas-nitriding and pack boriding exhibited the highest wear resistance and a reduced coefficient of friction due to improved mechanical properties, leading to increased hardness and elastic modulus. Full article
Show Figures

Figure 1

17 pages, 12404 KiB
Article
Single Three-Phase Inverter for Dual-Frequency Induction Heating
by Krystian Frania, Kamil Kierepka, Marcin Kasprzak and Piotr Zimoch
Energies 2024, 17(11), 2489; https://doi.org/10.3390/en17112489 - 22 May 2024
Cited by 2 | Viewed by 1193
Abstract
This paper presents new resonant inverter topologies for dual-frequency induction heating (IH). These 2T1C and 3T topologies combine the advantageous features of two- and one-inverter solutions. An analytical description of the load impedance of a dual-frequency series-parallel circuit has been made. Using manufacturer [...] Read more.
This paper presents new resonant inverter topologies for dual-frequency induction heating (IH). These 2T1C and 3T topologies combine the advantageous features of two- and one-inverter solutions. An analytical description of the load impedance of a dual-frequency series-parallel circuit has been made. Using manufacturer datasheets and LTspice models of selected transistors, a MATLAB model was parameterized. Based on it, power losses are determined as a function of the following parameters: nominal power, frequency and DC bus voltage. The obtained results allowed for determining the data necessary in the design process. The research has been experimentally verified. Tests were carried out for pulsing and simultaneous operation. Power control characteristics as a function of frequency are determined. The possibility of operating the inverter with high efficiency (>97%) in the proposed 2T1C and 3T systems at nominal power is demonstrated. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

16 pages, 3996 KiB
Article
Elastic and Elastoplastic Contact Mechanics of Concentrated Coated Contacts
by Patricia M. Johns-Rahnejat, Nader Dolatabadi and Homer Rahnejat
Lubricants 2024, 12(5), 162; https://doi.org/10.3390/lubricants12050162 - 7 May 2024
Cited by 4 | Viewed by 2882
Abstract
Machines operate under increasingly harsher contact conditions, causing significant wear and contact fatigue. Sub-surface stresses are responsible for the premature contact fatigue of rolling element bearings, meshing gears, and cam–follower pairs. Surface protection measures include hard, wear-resistant coatings. Traditionally, contact integrity has been [...] Read more.
Machines operate under increasingly harsher contact conditions, causing significant wear and contact fatigue. Sub-surface stresses are responsible for the premature contact fatigue of rolling element bearings, meshing gears, and cam–follower pairs. Surface protection measures include hard, wear-resistant coatings. Traditionally, contact integrity has been predicted using classical Hertzian contact mechanics. However, the theory is only applicable when the contact between a pair of ellipsoidal solids of revolution may be considered as a rigid indenter penetrating a semi-infinite elastic half-space. Many coatings act as thin bonded elastic layers that undergo considerably higher pressures than those predicted by the classical theory. Furthermore, inelastic deformation of bonded solids can cause plastic flow, work-hardening, and elastoplastic behaviour. This paper presents a comprehensive, integrated contact mechanics analysis that includes induced sub-surface stresses in concentrated counterformal finite line contacts for all the aforementioned cases. Generated pressures and deformation are predicted for hard coated surfaces, for which there is a dearth of relevant analysis. The contact characteristics, which are of particular practical significance, of many hard, wear-resistant advanced coatings are also studied. The paper clearly demonstrates the importance of using efficient semi-analytical, detailed holistic contact mechanics rather than the classical idealised methods or empirical numerical ones such as FEA. The novel approach presented for the finite line contact of thin-layered bonded solids has not hitherto been reported in the open literature. Full article
Show Figures

Figure 1

21 pages, 14182 KiB
Article
Determination of Material and Fracture Properties of a Case-Hardened Planet Gear and Its Homogenisation Method to Obtain the Damage Mechanism Caused by Fragment Ingestion
by Julia Jeßberger, Christian Fischer and Stephan Rinderknecht
Materials 2024, 17(2), 366; https://doi.org/10.3390/ma17020366 - 11 Jan 2024
Viewed by 1233
Abstract
Before a new type of engine is introduced into civil aviation, it must comply with various safety regulations. These regulations include the analysis of secondary damage caused by the re-ingestion of a tooth fragment. The purpose is to prevent crack propagation through the [...] Read more.
Before a new type of engine is introduced into civil aviation, it must comply with various safety regulations. These regulations include the analysis of secondary damage caused by the re-ingestion of a tooth fragment. The purpose is to prevent crack propagation through the gear rim, which would lead to catastrophic failure. In this context, identification of the initial crack location is crucial to determine the crack propagation path. Therefore, this paper presents a technique to determine and validate a constitutive material model and fracture locus for case-hardened spur gears. As the modelling of the surface-hardened layer is computationally intensive, it is necessary to homogenise the model. This paper comprehensively reviews and discusses the associated effects and errors. To determine the plastic behaviour of the case-hardened external gear (30CrNiMo8) and the nitrided internal gear (35CrAlNi7-10), the widely acknowledged Johnson–Cook material model is implemented using compression and Vickers indenter tests to define the necessary parameters. The fracture locus implementation is also based on the Johnson–Cook method and an axial shift of the fracture locus based on the hardness profile of the spur gears is determined by quasi-static pulsator tests. For validation, a project-specific gearbox test rig is used, enabling consistent ingestion of defined fragments. In addition, to check the likelihood of a tooth flank crack and to validate the results, a simplified ingestion experiment is performed. Full article
(This article belongs to the Section Materials Simulation and Design)
Show Figures

Figure 1
