Search Results (23)

Failures in gas path components pose significant risks to aeroengine performance and safety. Traditional fault diagnosis methods often require extensive data and struggle with real-time applications. This study addresses these critical limitations in traditional studies through physics-informed modeling and adaptive estimation. A nonlinear component-level model of the JT9D engine is developed through aero-thermodynamic governing equations, enhanced by a dual-loop iterative cycle combining Newton–Raphson steady-state resolution with integration-based dynamic convergence. An augmented state-space model that linearizes nonlinear dynamic models while incorporating gas path health characteristics as control inputs is novelly proposed, supported by similarity-criterion normalization to mitigate matrix ill-conditioning. A hybrid identification algorithm is proposed, synergizing partial derivative analysis with least squares fitting, which uniquely combines non-iterative perturbation advantages with high-precision least squares. This paper proposes a novel enhanced Kalman filter through integral compensation and three-dimensional interpolation, enabling real-time parameter updates across flight envelopes. The experimental results demonstrate a 0.714–2.953% RMSE in fault diagnosis performance, a 3.619% accuracy enhancement over traditional sliding mode observer algorithms, and 2.11 s reduction in settling time, eliminating noise accumulation. The model maintains dynamic trend consistency and steady-state accuracy with errors of 0.482–0.039%. This work shows marked improvements in temporal resolution, diagnostic accuracy, and flight envelope adaptability compared to conventional approaches. Full article

Dissolved Gas Analysis (DGA) of transformer oil is a critical technique for transformer fault diagnosis that involves analyzing the concentration of gases to detect potential transformer faults in a timely manner. Given the issues of large model parameters and high computational resource demands in transformer DGA diagnostics, this study proposes a lightweight convolutional neural network (CNN) model for improving gas ratio methods, combining Knowledge Distillation (KD) and recursive plots. The approach begins by extracting features from DGA data using the ratio method and Multiscale sample entropy (MSE), then reconstructs the state space of the feature data using recursive plots to generate interpretable two-dimensional image features. A deep feature extraction process is performed using the ResNet50 model, integrated with the Convolutional Block Attention Module (CBAM). Subsequently, the Sparrow Optimization Algorithm (SSA) is applied to optimize the hyperparameters of the ResNet50 model, which is trained on DGA data as the teacher model. Finally, a dual-path distillation mechanism is introduced to transfer the efficient features and knowledge from the teacher model to the student model, MobileNetV3-Large. The experimental results show that the distilled model reduces memory usage by 83.5% and computation time by 73.2%, significantly lowering computational complexity while achieving favorable performance across various evaluation metrics. This provides a novel technical solution for the improvement of gas ratio methods. Full article

Aero engines are complex coupled systems in which faults in one subsystem can propagate and affect the performance of others. Relying on single-source performance parameters is often insufficient for accurately assessing component degradation. Although multi-source fusion diagnosis methods, such as those based on Bayesian networks, have been widely applied, their diagnostic performance remains limited when prior knowledge is scarce. To address this challenge, this paper proposes a multi-source information fusion diagnosis method for aero engine fault detection based on Dempster–Shafer (D-S) evidence theory. Data from gas path and vibration subsystems are separately processed to extract fault features, and a decision-level fusion strategy is employed to achieve comprehensive diagnoses. A case study based on real operational data from a two-shaft aero engine demonstrates that the proposed method significantly improves diagnostic performance. Specifically, the Bayesian-network-based fusion method achieves a diagnostic confidence of 87.2% without prior knowledge and 91.2% with prior knowledge incorporated, whereas D-S evidence theory attains a higher fault confidence of 99.6% without requiring any prior information. Full article

The maintenance of gas turbines relies a lot on gas path diagnostics (GPD), which includes two approaches. The first approach employs a physics-based model (thermodynamic model) to convert measurement shifts (deviations) induced by deterioration into fault parameters, which drastically simplify diagnostics. The second approach relies on data-driven models, makes diagnosis in the space of measurement deviations, and involves pattern recognition techniques. Although a thermodynamic model is an essential element of GPD, it has limitations. This model is a complex software critical to computer resources, and the computation sometimes does not converge. Therefore, it is difficult to use the model in online applications. Since the 1990s, we have developed many thermodynamic models for different engines. Since the 2000s, simplified data-driven models were investigated. This paper proposes to substitute a thermodynamic model for novel simplified data-driven models that have the same functionality, i.e., take into consideration the influence of both operating conditions and engine faults. The proposed models are formed and compared with the underlying thermodynamic model. To obtain a solid conclusion about these models, they are verified in twelve test cases formed by three test-case engines, two model types, and two approximation functions. Although the accuracy of the simplified models varies from 1.15% to 0.0082%, it was found acceptable even for the worst case. Thus, these simple-but-accurate models with the functionality of a physics-based model represent a good replacement for the latter. It is expected that the models will stimulate the further development of advanced diagnostic systems. Full article

A diagnostic method for gas-path faults of turbofan engines, relying on a Probabilistic Neural Network (PNN) coupled with a thermodynamic model of the engine, is presented. The novel aspect of the method is that its training information is generated dynamically by an accompanying Engine Performance Model. In the proposed approach, the PNN efficiently addresses the first step of a diagnostic process (i.e., detection of the faulty component at the current operating point), while with the aid of an adaptive engine model, the fault is then further isolated and identified. A description of the proposed method and training aspects of the PNN are presented. The method is applied to the case of a mixed-flow turbofan engine to diagnose common gas-path faults in compressors and turbines (i.e., fouling, FOD, erosion, and tip clearance). Its performance is evaluated using realistic fault data that may be acquired at various operating conditions within a flight envelope. Full article

Data from the steady-state operation of gas turbine engines are used in gas path diagnostic procedures. A method to identify steady-state operation is thus required. This paper initially explains and demonstrates the factors that cause a deviation in engine health when transient data are used for diagnosis and shows that there is a threshold in the slope of time traces, below which the variation in engine health parameters is acceptable. A methodology for deriving a criterion for steady-state operation based on actual flight data is then presented. The slope of the exhaust gas temperature variation with time and the size of its time-series window, from which this slope is determined, are the required parameters that must be specified when applying this criterion. It is found that the values of these parameters must be selected so that a sufficient number of steady-state points are available without compromising the accuracy of the diagnostic procedure. Full article

The utilization of hydrogen fuel in gas turbines brings significant changes to the thermophysical properties of flue gas, including higher specific heat capacities and an enhanced steam content. Therefore, hydrogen-fueled gas turbines are susceptible to health degradation in the form of steam-induced corrosion and erosion in the hot gas path. In this context, the fault diagnosis of hydrogen-fueled gas turbines becomes indispensable. To the authors’ knowledge, there is a scarcity of fault diagnosis studies for retrofitted gas turbines considering hydrogen as a potential fuel. The present study, however, develops an artificial neural network (ANN)-based fault diagnosis model using the MATLAB environment. Prior to the fault detection, isolation, and identification modules, physics-based performance data of a 100 kW micro gas turbine (MGT) were synthesized using the GasTurb tool. An ANN-based classification algorithm showed a 96.2% classification accuracy for the fault detection and isolation. Moreover, the feedforward neural network-based regression algorithm showed quite good training, testing, and validation accuracies in terms of the root mean square error (RMSE). The study revealed that the presence of hydrogen-induced corrosion faults (both as a single corrosion fault or as simultaneous fouling and corrosion) led to false alarms, thereby prompting other incorrect faults during the fault detection and isolation modules. Additionally, the performance of the fault identification module for the hydrogen fuel scenario was found to be marginally lower than that of the natural gas case due to assumption of small magnitudes of faults arising from hydrogen-induced corrosion. Full article

To ensure and to demonstrate the mechanical integrity of a welded structure, precise ultrasonic testing (UT) is often mandatory. The importance of the link between nondestructive testing (NDT) and the assessment of structural integrity is recalled. However, it is difficult to achieve great efficiency as the welding of thick and heavy structural part produces heterogeneous material. Heterogeneity results from the welding process itself as well as from the material solidification laws. For thick components, several welding passes are deposited, and temperature gradients create material grain elongation and/or size variations. In many cases, the welded material is also anisotropic, this anisotropy being due to the metal used, for example, austenitic stainless steel. At the early stages of ultrasonic testing, this kind of welded material was considered too unpredictable, and thus too difficult to be tested by ultrasounds without possible diagnosis errors and misunderstandings. At the end of the 1990s, an algorithmic solution to predict the material organisation began to be developed using data included in the welding notebook. This algorithm or modelling solution was called MINA. This present work recalls, in a synthetic form, the path followed to create this algorithm combining the use of solidification laws and the knowledge of the order of passes in the case of shielded metal arc welding (SMAW). This work describes and questions the simplifications used to produce a robust algorithm able to give a digital description of the material for wave simulation code. Step by step, advances and demonstrations are described as well as the limitations, and ways to progress are sketched. Recent developments are then explained and discussed for modelling in the case of gas tungsten arc welding (GTAW), in addition to discussions about 3D modelling for the future. The discussion includes alternative ways to represent the welded material and challenges to continue to produce more and more convincing weld material model to qualify and to make use of UT methods. Full article

Aeroengine performance diagnosis technology is essential for ensuring flight safety and reliability. The complexity of engine performance and the strong coupling of fault characteristics make it challenging to develop accurate and efficient gas path diagnosis methods. To address these issues, this study proposes a novel digital twin framework for aeroengines that achieves the digitalization of physical systems. The mechanism model is constructed at the component level. The data-driven model is built using a particle swarm optimization–extreme gradient boosting algorithm (PSO-XGBoost). These two models are fused using the low-rank multimodal fusion method (LWF) and combined with the sparse stacked autoencoder (SSAE) to form a digital twin framework of the engine for performance diagnosis. Compared to methods that are solely based on mechanism or data, the proposed digital twin framework can effectively use mechanism and data information to improve the accuracy and reliability. The research results show that the proposed digital twin framework has an error rate of 0.125% in predicting gas path parameters and has a gas path fault diagnosis accuracy of 98.6%. Considering that the degradation cost of a typical flight mission for only one aircraft engine after 3000 flight cycles is approximately USD 209.5, the proposed method has good economic efficiency. This framework can be used to improve engine reliability, availability, and efficiency, and has significant value in engineering applications. Full article

Early detection of breast lesions and distinguishing between malignant and benign lesions are critical for breast cancer (BC) prognosis. Breast ultrasonography (BU) is an important radiological imaging modality for the diagnosis of BC. This study proposes a BU image-based framework for the diagnosis of BC in women. Various pre-trained networks are used to extract the deep features of the BU images. Ten wrapper-based optimization algorithms, including the marine predator algorithm, generalized normal distribution optimization, slime mold algorithm, equilibrium optimizer (EO), manta-ray foraging optimization, atom search optimization, Harris hawks optimization, Henry gas solubility optimization, path finder algorithm, and poor and rich optimization, were employed to compute the optimal subset of deep features using a support vector machine classifier. Furthermore, a network selection algorithm was employed to determine the best pre-trained network. An online BU dataset was used to test the proposed framework. After comprehensive testing and analysis, it was found that the EO algorithm produced the highest classification rate for each pre-trained model. It produced the highest classification accuracy of 96.79%, and it was trained using only a deep feature vector with a size of 562 in the ResNet-50 model. Similarly, the Inception-ResNet-v2 had the second highest classification accuracy of 96.15% using the EO algorithm. Moreover, the results of the proposed framework are compared with those in the literature. Full article

The technology of aero-engine gas-path fault diagnosis is an important way to improve flight safety and reliability and reduce maintenance costs. With the maturity of the new-generation engine distributed control system (DCS), uncertainties such as bus packet loss, time delay, and node function degradation have increasingly highlighted new challenges to engine fault diagnosis. At present, linear Kalman filter (LKF) is widely researched and used in engine fault detection and isolation (FDI), but its robustness has proved to be not strong. However, the sliding mode observer (SMO) is not only capable of fault reconstruction but also robust to system uncertainties and disturbances due to its unique discontinuous switching term, which tends to be an effective way to achieve robust fault diagnosis for aero engines and DCS with many uncertainties. This paper initially develops a distributed bus packaging model that supports time-delay and packet-loss simulating and timing planning based on SimEvents, providing a basis for the model-based design and verification. Then the SMO is adopted to design a robust gas-path diagnosis method for engine DCS, and the robust observing accuracy is improved by combining high-order sliding mode theory, LMI optimized observation matrix, and variable gain. The simulation results show the effectiveness and advantages in engine DCS application scenarios. Full article

Colorectal cancer (CRC) represents 10% of the annual tumor diagnosis and deaths occurring worldwide. Given the lack of specific symptoms, which could determine a late diagnosis, the research for specific CRC biomarkers and for innovative low-invasive methods to detect them is crucial. Therefore, on the basis of previously published results, some volatile organic compounds (VOCs), detectable through gas sensors, resulted in particularly promising CRC biomarkers, making these sensors suitable candidates to be employed in CRC screening devices. A new device was employed here to analyze the exhalations of blood samples collected from CRC-affected patients at different stages of their pre- and post-surgery therapeutic path, in order to assess the sensor’s capability for discriminating among these samples. The stages considered were: the same day of the surgical treatment (T1); before the hospital discharge (T2); after one month and after 10–12 months from surgery (T3 and T4, respectively). This device, equipped with four different sensors based on different metal–oxide mixtures, enabled a distinction between T1 and T4 with a sensitivity and specificity of 93% and 82%, respectively, making it suitable for clinical follow-up protocols, patient health status monitoring and to detect possible post-treatment relapses. Full article

Medical image diagnosis and delineation of lesions in the human brain require information to combine from different imaging sensors. Image registration is considered to be an essential pre-processing technique of aligning images of different modalities. The brain is a naturally bilateral symmetrical organ, where the left half lobe resembles the right half lobe around the symmetrical axis. The identified symmetry axis in one MRI image can identify symmetry axes in multi-modal registered MRI images instantly. MRI sensors may induce different levels of noise and Intensity Non-Uniformity (INU) in images. These image degradations may cause difficulty in finding true transformation parameters for an optimization technique. We will be investigating the new variant of evolution strategy of genetic algorithm as an optimization technique that performs well even for the high level of noise and INU, compared to Nesterov, Limited-memory Broyden–Fletcher–Goldfarb–Shanno algorithm (LBFGS), Simulated Annealing (SA), and Single-Stage Genetic Algorithm (SSGA). The proposed new multi-modal image registration technique based on a genetic algorithm with increasing precision levels and decreasing search spaces in successive stages is called the Multi-Stage Forward Path Regenerative Genetic Algorithm (MFRGA). Our proposed algorithm is better in terms of overall registration error as compared to the standard genetic algorithm. MFRGA results in a mean registration error of 0.492 in case of the same level of noise (1–9)% and INU (0–40)% in both reference and template image, and 0.317 in case of a noise-free template and reference with noise levels (1–9)% and INU (0–40)%. Accurate registration results in good segmentation, and we apply registration transformations to segment normal brain structures for evaluating registration accuracy. The brain segmentation via registration with our proposed algorithm is better even in cases of high levels of noise and INU as compared to GA and LBFGS. The mean dice similarity coefficient of brain structures CSF, GM, and WM is 0.701, 0.792, and 0.913, respectively. Full article

Gas path fault diagnosis of a gas turbine is a complex task involving field data analysis and knowledge-based reasoning. In this paper, a data-knowledge hybrid driven method for gas path fault diagnosis is proposed by integrating a physical model-based gas path analysis (GPA) method with a fault diagnosis ontology model. Firstly, a physical model-based GPA method is used to extract the fault features from the field data. Secondly, a virtual distance mapping algorithm is developed to map the GPA result to a specific fault feature criteria individual described in the ontology model. Finally, a fault diagnosis ontology model is built to support the automatic reasoning of the maintenance strategy from the mapped fault feature criteria individual. To enhance the ability of selecting a proper maintenance strategy, the ontology model represents more abundant knowledge from several sources, such as fault criteria analysis, physical structure analysis, FMECA (failure mode, effects, and criticality analysis), and the maintenance logic decision tool. The availability of the proposed hybrid driven method is verified by the field fault data from a real GE LM2500 PLUS gas turbine unit. The results indicate that the hybrid driven method is effective in detecting the path fault in advance. Furthermore, diversified fault information, such as fault effects, fault criticality, fault consequence, and fault detectability, could be provided to support selecting a proper maintenance strategy. It is proven that the data-knowledge hybrid driven method can improve the capability of the gas path fault detection, fault analysis, and maintenance strategy selection. Full article

The lack of gas turbine field data, especially faulty engine data, and the complexity of fault embedding into gas turbines on test benches cause difficulties in representing healthy and faulty engines in diagnostic algorithms. Instead, different gas turbine models are often used. The available models fall into two main categories: physics-based and data-driven. Given the models’ importance and necessity, a variety of simulation tools were developed with different levels of complexity, fidelity, accuracy, and computer performance requirements. Physics-based models constitute a diagnostic approach known as Gas Path Analysis (GPA). To compute fault parameters within GPA, this paper proposes to employ a nonlinear data-driven model and the theory of inverse problems. This will drastically simplify gas turbine diagnosis. To choose the best approximation technique of such a novel model, the paper employs polynomials and neural networks. The necessary data were generated in the GasTurb software for turboshaft and turbofan engines. These input data for creating a nonlinear data-driven model of fault parameters cover a total range of operating conditions and of possible performance losses of engine components. Multiple configurations of a multilayer perceptron network and polynomials are evaluated to find the best data-driven model configurations. The best perceptron-based and polynomial models are then compared. The accuracy achieved by the most adequate model variation confirms the viability of simple and accurate models for estimating gas turbine health conditions. Full article
