Search Results (49)

The integration of robots into collaborative environments, where they physically interact with humans, requires systems capable of ensuring both safety and performance. This work introduces the development of a Variable Stiffness Impact Testing Device (VSITD), designed to emulate physical human–robot interaction by replicating biomechanical properties such as muscle elasticity and joint compliance. The proposed system integrates a Variable Stiffness Mechanism (VSM) with a multi-sensor configuration that includes a high-resolution Force Sensitive Resistors (FSR) matrix, piezoelectric load cells, and an FPGA-based acquisition unit. The FPGA enables fast acquisition of contact forces and pressures, while the mechanical stiffness configuration of the VSM can be rapidly reconfigured to simulate a wide range of impact scenarios. The device aims to validate compliance with the standard ISO/TS 15066 safety standard of robotic work cell in the context of collaborative application. The modularity and flexibility of the VSITD make it suitable for evaluating a wide range of collaborative robotic platforms, providing a reliable tool for pre-deployment validation in shared workspaces. By combining real-time sensing with adaptable stiffness control, the VSITD establishes a new benchmark for safety testing in human–robot collaboration scenarios. Full article

Force sensing on hands can provide an understanding of interaction forces during manipulation, with applications in different fields, including robotics and medicine. While several approaches to accomplish this have been proposed, they often require relatively complex and/or expensive fabrication techniques and materials. On the other hand, less complex and expensive approaches often suffer from poor accuracy of measurements. An example of this is provided by sensors built with Velostat, a polyethylene–carbon composite material that exhibits resistance changes when force is applied. This material is both cheap and easy to work with, but sensors made from Velostat have been shown to suffer from low accuracy, limiting its usefulness. This work explores the effect of stacking multiple layers of 0.1 mm Velostat sheets on accuracy, using no additional fabrication techniques or other material aside from electrode connections, with the rationale that this is both economical and can be accomplished easily. We evaluate measurement error for designs with different numbers of layers (1, 3, 4, 5, 10, 20, and 30) against a load cell, and also compare this with the error for a USD 10 commercial force sensing resistor designed for measurement of hand forces (FSR 402) in three evaluations (static, cyclic, and finger base interactions). Our results show that layered sensors outperform both the one-layer design and the commercial FSR sensor consistently under all conditions considered, with the best performing sensors reducing measurement errors by at least 27% and as much as 60% when compared against the one-layer design. Full article

Recently, there has been a huge increase in the different ways to manufacture polymer-based sensors. Methods like additive manufacturing, microfluidic preparation, and brush painting are just a few examples of new approaches designed to improve sensor features like self-healing, higher sensitivity, reduced drift over time, and lower hysteresis. That being said, we believe there is still a lot of potential to boost the performance of current sensors by applying modeling, classification, and machine learning techniques. With this approach, final sensor users may benefit from inexpensive computational methods instead of dealing with the already mentioned manufacturing routes. In this study, a total of 96 specimens of two commercial brands of Force Sensing Resistors (FSRs) were characterized under the error metrics of drift and hysteresis; the characterization was performed at multiple input voltages in a tailored test bench. It was found that the output voltage at null force (V_{o_null}) of a given specimen is inversely correlated with its drift error, and, consequently, it is possible to predict the sensor’s performance by performing inexpensive electrical measurements on the sensor before deploying it to the final application. Hysteresis error was also studied in regard to V_{o_null} readings; nonetheless, a relationship between V_{o_null} and hysteresis was not found. However, a classification rule base on k-means clustering method was implemented; the clustering allowed us to distinguish in advance between sensors with high and low hysteresis by relying solely on V_{o_null} readings; the method was successfully implemented on Peratech SP200 sensors, but it could be applied to Interlink FSR402 sensors. With the aim of providing a comprehensive insight of the experimental data, the theoretical foundations of FSRs are also presented and correlated with the introduced modeling/classification techniques. Full article

Existing studies on gait phase estimation generally involve walking experiments using inertial measurement units under limited walking conditions (WCs). In this study, a gait phase estimation algorithm is proposed that uses data from force sensing resistors (FSRs) and a Bi-LSTM model. The proposed algorithm estimates gait phases in real time under various WCs, e.g., walking on paved/unpaved roads, ascending and descending stairs, and ascending or descending on ramps. The performance of the proposed algorithm is evaluated by performing walking experiments on ten healthy adult participants. An average gait estimation accuracy exceeding 90% is observed with a small error (root mean square error = 0.794, R² score = 0.906) across various WCs. These results demonstrate the wide applicability of the proposed gait phase estimation algorithm using various insole devices, e.g., in walking aid control, gait disturbance diagnosis in daily life, and motor ability analysis. Full article

In this study, we developed a cost-effective and rapid method for fabricating force-sensing resistor (FSR) sensors as an alternative to commercial force sensors. Our aim was to achieve performance characteristics comparable to existing commercial products while significantly reducing costs and fabrication time. We analyzed the material composition of two widely used commercial force sensors: Interlink FSR-402 and Flexiforce A201-1. Based on this analysis, we selected 4B and 9B pencils, which contain high concentrations of graphite, and silicone sealant to replicate these material properties. The fabrication process involved creating piezoresistive sheets by shading A4 copy paper with 4B and 9B pencils to form a uniform layer of graphite. Additionally, we prepared a mixture of 9B pencil lead powder and silicone sealant, ensuring a consistent application on the paper substrate. Measurement results indicated that the force sensor fabricated using a mixture of 9B pencil powder and silicone sealant exhibited electrical and mechanical characteristics closely resembling those of commercial sensors. Load tests revealed that the hand-made sensors provided a proportional voltage output in response to increasing and decreasing loads, similar to commercial FSR sensors. These results suggest that our fabrication method can produce reliable and accurate FSR sensors suitable for various applications, including wearable technology, robotics, and force-sensing interfaces. Overall, this study demonstrates the potential for creating cost-effective and high-performance FSR sensors using readily available materials and simple fabrication techniques. Full article

In this study, we thoroughly analyzed the linearity and repeatability of force-sensing resistor (FSR) sensors through static load tests to ensure their reliability. The novelty of this research lies in its comprehensive evaluation and direct comparison of two widely used FSR sensors, i.e., Flexiforce A201-1 and Interlink FSR-402, under various loading conditions by employing a robust calibration methodology. This study provides detailed insights into the sensors’ performances, offering practical calibration equations that enhance measurement precision and reliability, which have not been extensively documented in previous studies. Our results demonstrate that the linearity of thin film FSR sensors is highly accurate, closely resembling a straight line. We employed M1 Class weights, applying loads ranging from 20 g to 300 g. The resistance of the FSR sensors, which varies with the applied load, was measured using a voltage divider circuit and an analog-to-digital converter of a microcontroller. MATLAB was used to calculate the average output voltage for each applied load and fixed resistance. Additionally, we examined the relationships among load, FSR sensor resistance, and conductivity. Our research indicates that with precise calibration, thin film FSR sensors can be highly reliable for force measurement applications. Full article

This paper proposes a scheme for predicting ground reaction force (GRF) and center of pressure (CoP) using low-cost FSR sensors. GRF and CoP data are commonly collected from smart insoles to analyze the wearer’s gait and diagnose balance issues. This approach can be utilized to improve a user’s rehabilitation process and enable customized treatment plans for patients with specific diseases, making it a useful technology in many fields. However, the conventional measuring equipment for directly monitoring GRF and CoP values, such as F-Scan, is expensive, posing a challenge to commercialization in the industry. To solve this problem, this paper proposes a technology to predict relevant indicators using only low-cost Force Sensing Resistor (FSR) sensors instead of expensive equipment. In this study, data were collected from subjects simultaneously wearing a low-cost FSR Sensor and an F-Scan device, and the relationship between the collected data sets was analyzed using supervised learning techniques. Using the proposed technique, an artificial neural network was constructed that can derive a predicted value close to the actual F-Scan values using only the data from the FSR Sensor. In this process, GRF and CoP were calculated using six virtual forces instead of the pressure value of the entire sole. It was verified through various simulations that it is possible to achieve an improved prediction accuracy of more than 30% when using the proposed technique compared to conventional prediction techniques. Full article

This work introduces a neuromorphic sensor (NS) based on force-sensing resistors (FSR) and spiking neurons for robotic systems. The proposed sensor integrates the FSR in the schematic of the spiking neuron in order to make the sensor generate spikes with a frequency that depends on the applied force. The performance of the proposed sensor is evaluated in the control of a SMA-actuated robotic finger by monitoring the force during a steady state when the finger pushes on a tweezer. For comparison purposes, we performed a similar evaluation when the SNN received input from a widely used compression load cell (CLC). The results show that the proposed FSR-based neuromorphic sensor has very good sensitivity to low forces and the function between the spiking rate and the applied force is continuous, with good variation range. However, when compared to the CLC, the response of the NS follows a logarithmic-like function with improved sensitivity for small forces. In addition, the power consumption of NS is 128 µW that is 270 times lower than that of the CLC which needs 3.5 mW to operate. These characteristics make the neuromorphic sensor with FSR suitable for bioinspired control of humanoid robotics, representing a low-power and low-cost alternative to the widely used sensors. Full article

In order to solve the problems of methods that use a single form of sensing, the ease of causing deformation damage to the targets with a low hardness during grasping, and the slow sliding inhibition of a prosthetic hand when the grasping target slides, which are problems that exist in most current intelligent prosthetic hands, this study introduces an adaptive control strategy for prosthetic hands based on multi-sensor sensing. Using a force-sensing resistor (FSR) to collect changes in signals generated after contact with a target, a prosthetic hand can classify the target’s hardness level and adaptively provide the desired grasping force so as to reduce the deformation of and damage to the target in the process of grasping. A fiber-optic sensor collects the light reflected by the object to identify its surface roughness, so that the prosthetic hand adaptively adjusts the sliding inhibition method according to the surface roughness information to improve the grasping efficiency. By integrating information on the hardness and surface roughness of the target, an adaptive control strategy for a prosthetic hand is proposed. The experimental results showed that the adaptive control strategy was able to reduce the damage to the target by enabling the prosthetic hand to achieve stable grasping; after grasping the target with an initial force and generating sliding, the efficiency of slippage inhibition was improved, the target could be stably grasped in a shorter time, and the hardness, roughness and weight ranges of targets that could be grasped by the prosthetic hand were enlarged, thus improving the success rate of stable grasping under extreme conditions. Full article

Incorrect sitting posture, characterized by asymmetrical or uneven positioning of the body, often leads to spinal misalignment and muscle tone imbalance. The prolonged maintenance of such postures can adversely impact well-being and contribute to the development of spinal deformities and musculoskeletal disorders. In response, smart sensing chairs equipped with cutting-edge sensor technologies have been introduced as a viable solution for the real-time detection, classification, and monitoring of sitting postures, aiming to mitigate the risk of musculoskeletal disorders and promote overall health. This comprehensive literature review evaluates the current body of research on smart sensing chairs, with a specific focus on the strategies used for posture detection and classification and the effectiveness of different sensor technologies. A meticulous search across MDPI, IEEE, Google Scholar, Scopus, and PubMed databases yielded 39 pertinent studies that utilized non-invasive methods for posture monitoring. The analysis revealed that Force Sensing Resistors (FSRs) are the predominant sensors utilized for posture detection, whereas Convolutional Neural Networks (CNNs) and Artificial Neural Networks (ANNs) are the leading machine learning models for posture classification. However, it was observed that CNNs and ANNs do not outperform traditional statistical models in terms of classification accuracy due to the constrained size and lack of diversity within training datasets. These datasets often fail to comprehensively represent the array of human body shapes and musculoskeletal configurations. Moreover, this review identifies a significant gap in the evaluation of user feedback mechanisms, essential for alerting users to their sitting posture and facilitating corrective adjustments. Full article

Haptic hands and grippers, designed to enable skillful object manipulation, are pivotal for high-precision interaction with environments. These technologies are particularly vital in fields such as minimally invasive surgery, where they enhance surgical accuracy and tactile feedback: in the development of advanced prosthetic limbs, offering users improved functionality and a more natural sense of touch, and within industrial automation and manufacturing, they contribute to more efficient, safe, and flexible production processes. This paper presents the development of a two-finger robotic hand that employs simple yet precise strategies to manipulate objects without damaging or dropping them. Our innovative approach fused force-sensitive resistor (FSR) sensors with the average current of servomotors to enhance both the speed and accuracy of grasping. Therefore, we aim to create a grasping mechanism that is more dexterous than grippers and less complex than robotic hands. To achieve this goal, we designed a two-finger robotic hand with two degrees of freedom on each finger; an FSR was integrated into each fingertip to enable object categorization and the detection of the initial contact. Subsequently, servomotor currents were monitored continuously to implement impedance control and maintain the grasp of objects in a wide range of stiffness. The proposed hand categorized objects’ stiffness upon initial contact and exerted accurate force by fusing FSR and the motor currents. An experimental test was conducted using a Yale–CMU–Berkeley (YCB) object set consisted of a foam ball, an empty soda can, an apple, a glass cup, a plastic cup, and a small milk packet. The robotic hand successfully picked up these objects from a table and sat them down without inflicting any damage or dropping them midway. Our results represent a significant step forward in developing haptic robotic hands with advanced object perception and manipulation capabilities. Full article

The rise of the Internet of Things (IoT) has enabled the development of measurement systems dedicated to preventing health issues and monitoring conditions in smart homes and workplaces. IoT systems can support monitoring people doing computer-based work and avoid the insurgence of common musculoskeletal disorders related to the persistence of incorrect sitting postures during work hours. This work proposes a low-cost IoT measurement system for monitoring the sitting posture symmetry and generating a visual alert to warn the worker when an asymmetric position is detected. The system employs four force sensing resistors (FSR) embedded in a cushion and a microcontroller-based read-out circuit for monitoring the pressure exerted on the chair seat. Java-based software performs the real-time monitoring of the sensors’ measurements and implements an uncertainty-driven asymmetry detection algorithm. The shifts from a symmetric to an asymmetric posture and vice versa generate and close a pop-up warning message, respectively. In this way, the user is promptly notified when an asymmetric posture is detected and invited to adjust the sitting position. Every position shift is recorded in a web database for further analysis of the sitting behavior. Full article

Industries such as the manufacturing or logistics industry need algorithms that are flexible to handle novel or unknown objects. Many current solutions in the market are unsuitable for grasping these objects in high-mix and low-volume scenarios. Finally, there are still gaps in terms of grasping accuracy and speed that we would like to address in this research. This project aims to improve the robotic grasping capability for novel objects with varying shapes and textures through the use of soft grippers and data-driven learning in a hyper-personalization line. A literature review was conducted to understand the tradeoffs between the deep reinforcement learning (DRL) approach and the deep learning (DL) approach. The DRL approach was found to be data-intensive, complex, and collision-prone. As a result, we opted for a data-driven approach, which to be more specific, is PointNet GPD in this project. In addition, a comprehensive market survey was performed on tactile sensors and soft grippers with consideration of factors such as price, sensitivity, simplicity, and modularity. Based on our study, we chose the Rochu two-fingered soft gripper with our customized force-sensing resistor (FSR) force sensors mounted on the fingertips due to its modularity and compatibility with tactile sensors. A software architecture was proposed, including a perception module, picking module, transfer module, and packing module. Finally, we conducted model training using a soft gripper configuration and evaluated grasping with various objects, such as fast-moving consumer goods (FMCG) products, fruits, and vegetables, which are unknown to the robot prior to grasping. The grasping accuracy was improved from 75% based on push and grasp to 80% based on PointNetGPD. This versatile grasping platform is independent of gripper configurations and robot models. Future works are proposed to further enhance tactile sensing and grasping stability. Full article

In order to operate a gait rehabilitation device, it is necessary to accurately classify the states appearing in activities of daily living (ADLs). In the case of force sensing resistors (FSRs), which are often used as pressure sensors in gait analysis, it is desirable to replace them with other sensors because of their low durability. In the present study, capacitive-type pressure sensors, as an alternative to FSRs, were developed, and their performance was evaluated. In addition, the timed up and go test was performed to measure the ground reaction force in healthy individuals, and a machine learning technique was applied to the calculated biosignal parameters for the classification of five types of ADLs. The performance evaluation results showed that a sensor with thermoplastic polyurethane (substrate and dielectric layer material) and multiwall carbon nanotubes (conductive layer) has sufficient sensitivity and durability for use as a gait analysis pressure sensor. Moreover, when an overlapping filter was applied to the four-layer long short-term memory (LSTM) or the five-layer LSTM model developed for motion classification, the precision was greater or equal to 95%, and unstable errors did not occur. Therefore, when the pressure sensor and ADLs classification algorithm developed in this study are applied, it is expected that motion classification can be completed within a time range that does not affect the control of the gait rehabilitation device. Full article

Extreme angles in lower body joints may adversely increase the risk of injury to joints. These injuries are common in the workplace and cause persistent pain and significant financial losses to people and companies. The purpose of this study was to predict lower body joint angles from the ankle to the lumbosacral joint (L5S1) by measuring plantar pressures in shoes. Joint angle prediction was aided by a designed footwear sensor consisting of six force-sensing resistors (FSR) and a microcontroller fitted with Bluetooth LE sensors. An Xsens motion capture system was utilized as a ground truth validation measuring 3D joint angles. Thirty-seven human subjects were tested squatting in an IRB-approved study. The Gaussian Process Regression (GPR) linear regression algorithm was used to create a progressive model that predicted the angles of ankle, knee, hip, and L5S1. The footwear sensor showed a promising root mean square error (RMSE) for each joint. The L5S1 angle was predicted to be RMSE of 0.21° for the X-axis and 0.22° for the Y-axis, respectively. This result confirmed that the proposed plantar sensor system had the capability to predict and monitor lower body joint angles for potential injury prevention and training of occupational workers. Full article
