Search Results (28)

When operating in the marine environment, floating offshore wind turbines (FOWTs) are subjected to various inflow conditions such as wind, waves, and currents. To investigate the effects of complex inflow conditions on offshore wind farms, an integrated fluid-structure interaction computational and coupled dynamic analysis method for FOWTs is employed. An aero-hydro-servo-elastic coupled analysis model of the NREL 5 MW semi-submersible wind turbine array based on the OC4-DeepCwind platform is established. The study examines the variations in power generation, platform motion, structural loads, and flow field distribution of the FOWT array under different wave incident angles and yaw angles of the first column turbines. The results indicate that the changes in power generation, platform motion, and flow field distribution of the wind farm are significantly influenced by the yaw angle. The maximum tower top yaw bearing torque and the tower base Y-direction bending moment of the wind turbines undergo significant changes with the increase in the angle between wind and wave directions. The study reveals the mechanism of power generation and load variation during yaw control of the FOWT array under misaligned wind and wave conditions, providing a theoretical basis for the future development of offshore floating wind farms. Full article

The ocean offers abundant wind and wave energy resources. This paper proposes an integrated concept that co-locates a semi-submersible floating wind platform with wave energy converters (WECs) to exploit the geographical consistency of these resources. By sharing the platform foundation and power transmission infrastructure, this integrated system enhances the utilization efficiency of marine space and renewable energy. Inspired by the principles of the Tuned Mass Damper (TMD) and leveraging mature hydraulic technologies from wave energy conversion and offshore drilling heave compensation systems, this study introduces a novel scheme. This scheme integrates a heave plate with a hydraulic Power Take-Off (PTO) system, functionally acting as a wave energy converter, to the floating platform. The primary objective is to mitigate the platform’s motion response while simultaneously generating electricity. The research investigates the motion performance improvement of this integrated platform under South China Sea conditions. The results demonstrate that the proposed WEC–PTO system not only improves the platform’s wave resistance and adaptability to deep-sea environments but also increases the overall efficiency of marine energy equipment deployment. Full article

The ocean represents a vast reservoir of energy. To address the issue of wave-induced motion in floating wind farms—particularly pitch motion—while harnessing the otherwise dissipated wave energy for power generation, this study proposes an integrated solution. Specifically, a duck-shaped wave energy converter incorporating mooring and power take-off systems is introduced. By combining computational fluid dynamics with experimental fluid dynamics methodologies, the performance of the device was systematically evaluated and its key parameters—including floating attitude, power take-off damping, and mooring configuration—were optimized. Furthermore, results indicate that deploying the duck-shaped converter around the periphery of a wind farm can reduce the wave-induced motion amplitude of the floating wind turbine platform by more than 70%, especially in terms of pitch motion, thereby significantly improving the operational efficiency and structural stability of the wind turbines. Full article

This study analyzes the dynamic response of a floating dual vertical-axis tidal turbine platform under extreme environmental loads, focusing on two different mooring systems as follows: taut and catenary. The analysis assumes a non-operational turbine state where power generation is stopped, and the vertical turbines are lifted for structural protection. Using time-domain simulations via OrcaFlex 11.4, the floating platform’s motion and mooring line effective tensions are evaluated under high waves, strong wind, and current loads. The results reveal that sway and heave motions are significantly influenced by wave excitation, with the catenary system exhibiting larger responses due to mooring system features, while the taut system experiences higher mooring effective tension but shows more restrained motion. Notably, in the roll direction, both systems exhibit peak frequencies unrelated to the wave spectrum, attributed instead to resonance with the system’s natural frequencies—0.12438 Hz for taut and 0.07332 Hz for catenary. Additionally, the failure scenario of ML02 (Mooring Line 02) and the application of dynamic power cables to the floating platform are analyzed. The results demonstrate that under non-operational and extreme load conditions, mooring system type plays a main role in determining platform stability and structural safety. This comparative analysis offers valuable insights for selecting and designing mooring configurations optimized for reliability in extreme environmental conditions. Full article

This study integrates offshore wind power and wave power generation technologies to build a multi-energy complementary renewable energy system, which provides references for marine clean energy development and is highly consistent with the global sustainable development goals. The platform consists of a UMaine VolturnUS-S semi-submersible platform and a group of flap-type wave energy converters. A 15 MW wind turbine is installed on the platform. The hydrodynamic model is established using AQWA. Combined with the upper wind load, the fully coupled time domain model of the integrated power generation platform is constructed using the open-source software F2A. The main purpose is to optimize the parameters of the flap-type wave energy device through frequency domain hydrodynamic analysis and then explore the influence of the wave energy device on the platform under the combined action of regular waves and turbulent wind through a series of working conditions. The results show that when the PTO stiffness is 8 × 10⁷ N·m/rad, the PTO damping takes the optimal damping and has a higher power generation capacity. Secondly, the coupled wave energy device induces minimal hydrodynamic interference between multiple bodies, resulting in negligible impact on the natural frequency of the wind-wave combined platform motion. Overall, the wave energy device can effectively suppress the freedom of shaking degree of the floating wind-wave combined platform. Full article

This research paper explores an approach to enhancing the economic viability of the heaving wave energy converters (WECs) of both cylinder-shaped and torus-shaped devices, by integrating them with four established, floating offshore wind turbines (FOWTs). Specifically, the approach focused on the wave power performance matrix. This integration of WECs and FOWTs not only offers the potential for shared construction and maintenance costs but also presents synergistic advantages in terms of power generation and platform stability. The study began by conducting a comprehensive review of the current State-of-the-Art in co-locating different types of WECs with various foundation platforms for FOWTs, taking into consideration the semi-submersible, spar and barge platforms commonly employed in the offshore wind industry. The research took a unified approach to investigate more and new WEC arrays, totaling 20 configurations across four distinct FOWTs. The scope of this study’s assumption primarily focused on the hydrodynamic wave power performance matrix, without the inclusion of aerodynamic loads. It then compared their outcomes to determine which array demonstrated superior wave energy under the key metrics of total absorbed power, capture width, and interaction factor. Additionally, the investigation could serve to reinforce the ongoing research and development efforts in the allocation of renewable energy resources. Full article

For floating offshore wind turbines, a significant pitch and roll motion response of the platform can affect the acceleration and power generation of the nacelle. The damping plate is considered a type of attachment that can be used to reduce rotational motion, but research on its anti-rotational effect is limited. The objective of this work is to analyze the impact of installing damping plates and varying their sizes on the pitch motion response of semi-submersible platforms, while also proposing optimization strategies for damping plate design. Firstly, a comparison between numerical simulations and experimental measurements validates the accuracy of the CFD calculations. Subsequently, different sizes of damping plates are proposed for the platforms, followed by simulations under various conditions. Finally, comprehensive data analysis is conducted. The findings suggest that installing damping plates enhances both the platform’s added moment of inertia and damping coefficients while simultaneously amplifying its motion response in regular waves. Furthermore, increasing the size of damping plates leads to an increase in both the added moment of inertia and motion response for the platform, whereas the damping coefficient exhibits an initial increasing trend followed by a subsequent decrease. Ultimately, it is found that increasing the distance between damping plates and the free surface significantly reduces wave-induced loads on the platform. Full article

The dynamical modeling and power optimization of floating wind–wave platforms, especially in regard to configurations based on constrained floating multi-body systems, lack in-depth systematic investigation. In this study, a floating wind-flap platform consisting of a flap-type wave energy converter and a floating offshore wind turbine is solved in the frequency domain considering the mechanical and hydrodynamic couplings of floating multi-body geometries and a model that suits the constraints of the hinge connection, which can accurately calculate the frequency domain dynamic response of the flap-type WEC. The results are compared with bottom-fixed flap-type wave energy converters in the absence of coupling with a floating wind platform. Moreover, combined with traditional optimization methods of power take-off systems for wave energy conversion, an optimization method is developed to suit the requirements of floating wind-flap platform configurations. The results are drawn for a specific operation site in the South China Sea, whereas a sensitivity analysis of the parameters is performed. It is found that the floating wind-flap platform has better wave energy absorption performance in the low-frequency range than the bottom-fixed flap-type wave energy converter; the average power generation in the low-frequency range can increase by up to 150 kW, mainly due to constructive hydrodynamic interactions, though it significantly fluctuates from the sea waves’ frequency range to the high-frequency range. Based on spectral analysis, operational results are drawn for irregular sea states, and the expected power for both types of flap-type WECs is around 30 kW, which points to a similar wave energy absorption performance when comparing the bottom-fixed flap with the flap within the hybrid configuration. Full article

The stability of offshore floating wind turbine foundation platforms is a fundamental requirement for the efficiency and safety of wind power generation systems. This paper proposes a novel small-diameter float-type semi-submersible platform to improve system stability. To evaluate the superior motion stability of the proposed floating platform, a comprehensive frequency–domain response analysis and experimental study were conducted in comparison with the OC4-DeepCwind platform developed by the National Renewable Energy Laboratory (NREL). The respective comparison of the frequency–domain response analysis and the experimental results demonstrated that the proposed floating wind turbine platform shows better hydrodynamic characteristics and resonance avoidance capability. This not only reduces the Response Amplitude Operators (RAOs), but also enhances the system stability, namely, effectively avoiding the regions of concentrated wave loading and low-frequency ranges. Furthermore, the proposed small-diameter semi-submersible platform has the potential to reduce manufacturing costs, providing valuable insights for the manufacturing of offshore floating wind turbine systems. Full article

For the exploitation of offshore wind resources in areas with intermediate water depths, a novel semi-spar floating foundation is introduced to combine the superiority of the conventional semisubmersible and spar-type floater. It consists of an upper floater and a hanging weight, which are connected through 12 suspension ropes. Such a floating foundation can be wet-towed as a semisubmersible floater, which features a large waterplane moment of inertia to increase stability and reduce transportation costs. After being anchored on site, it behaves as a spar floater with moderate draft and superior hydrodynamic characteristics. The stability of the proposed semi-spar platform during wet towage is analyzed. Afterward, a fully coupled aero-hydro-servo-elastic simulation is conducted to evaluate its hydrodynamic responses in comparison with the responses of the well-acknowledged OC3-spar and OC4-semisubmersible platforms. Then, the ultimate strength of the mooring lines and suspension ropes under extreme conditions was numerically investigated, as well as the relationship between the ropes’ tension and wave direction. Eventually, a cost-effectiveness analysis is conducted in terms of power generation and steel mass. The results demonstrate that the proposed semi-spar design meets the safety criteria in transportation and exhibits a smaller response in surge and pitch motions. In addition, the ultimate strength of mooring lines and suspension ropes satisfies the safety requirements, and simulation reveals that the lateral suspension ropes parallel to the propagation direction are sensitive to the environmental conditions of winds and waves. This study confirms that the newly proposed floating wind turbine exhibits excellent hydrodynamic and power generation performance, which is of great significance for the sustainability of the energy and electricity industry. Full article

Integrating wave energy converters (WECs) onto floating offshore wind turbine platforms has emerged as a recent focal point of research aiming to achieve synergistic marine energy utilization and enhance the spatial efficiency of renewable energy. The power performance of WECs relies on hydrodynamic interactions with the floating platform. However, the coupled dynamic response and power generation mechanism remain unclear. This study establishes a multi-body model for the constrained motion of floating-platform and point-absorber WECs in the frequency domain. The power performance of WECs under different arrangements is compared and optimized. The performance of different hydrodynamic models in the South China Sea is analyzed further. The results indicate that exceptional peak performance is achieved when a single point absorber is placed on the floating platform. However, its performance under the full spectrum of wave frequencies in real sea conditions is suboptimal. Conversely, as the number of point absorbers on the floating platform increases, the performance of the hybrid system becomes more stable in real sea conditions. Furthermore, the array arrangement of point absorbers on the floating platform leads to multiple peaks in their power performance, and in selected array arrangements, the average power generation at specific frequencies is significantly superior to that of a single point absorber on the floating platform. Full article

Integrating point absorber wave energy converters (PAWECs) and an offshore floating wind platform provide a cost-effective way of joint wind and wave energy exploitation. However, the coupled dynamics of the complicated hybrid system and its influence on power performance are not well understood. Here, a frequency-domain-coupled hydrodynamics, considering the constraints and the power output through the relative motion between the PAWECs and the semi-submersible platform, is introduced to optimize the size, power take-off damping, and layout of the PAWECs. Results show that the annual wave power generation of a PAWEC can be improved by 30% using a 90° conical or a hemispherical bottom instead of a flat bottom. Additionally, while letting the PAWECs protrude out the sides of the triangular frame of the platform by a distance of 1.5 times the PAWEC radius, the total power generation can be improved by up to 18.2% without increasing the motion response of the platform. The PAWECs can reduce the resonant heave motion of the platform due to the power take-off damping force. This study provides a reference for the synergistic use of wave and wind energy. Full article

This study predicted the motion response and power performance of a floating wind turbine system equipped with a semisubmersible Taida platform, an IEA 15 MW wind turbine, and a 3 × 2 mooring design in the Hsinchu offshore area in the Taiwan Strait. The hydrodynamic properties were calculated using ANSYS-AQWA and STAR-CCM+. The motion equations were solved by OrcaFlex to obtain the motion response and generator power, as well as the dynamics of the mooring system and aerodynamics of the wind turbine. The waves were assumed to share the same direction as the wind. This study compared the mean values and standard deviations of the motion response, generator power, and mooring line tension between the potential- and viscous-flow approaches by considering the combination of seven wind directions and four current directions under two wave conditions in the Hsinchu offshore area. The numerical prediction shows that the viscous effect has a larger impact on the hydrodynamic properties in the heave, roll, and pitch motions. The angle between the leading mooring line of the system and dominant wind direction in the Taiwan Strait, which comes from the northeast, should be from 120° to 180° in order to deliver a relatively favorable performance of the system. Full article

In recent years, due to the global energy crisis, increasingly more countries have recognized the importance of developing clean energy. Offshore wind energy, as a basic form of clean energy, has become one of the current research priorities. In the future, offshore wind farms will be developed in deep and distant sea areas. In these areas, there is a new trend of floating offshore wind platforms replacing fixed wind power platforms, due to their low cost, ease of installation, and independence from the water depth. However, the stability of offshore floating platforms is poor and their power fluctuations are significant; furthermore, they are more prone to failure because of sea wind, waves, and currents. This paper summarizes and analyzes the current research progress and critical technical issues of offshore floating wind power generation, such as stability control technology, integrated wind storage technology, wind power energy management, and long-distance transmission of electricity for floating wind power generation at sea. Finally, future research directions for key offshore wind power technologies are presented. Full article

The Portuguese nearshore represents a suitable environment for the development of marine energy farms, with recent progress being related to the implementation of the first commercial wave farm or a large scale floating wind project. At the same time, there is also high solar power in this area that can be extracted; in the near future, the rapid development of floating solar projects all over the world is expected. In this context, the aim of the present work is to identify the complementarity between solar, wind and wave resources based on 10 years of ERA5 data (from 2012 to 2021). The results are provided mainly in terms of spatial maps. The analysis shows that solar and wind power are more significant in the southern part of this region, indicating for each resource an average value of 223 W/m² for solar and 660 W/m² for wind. On the other hand, the wave power gradually decreases from north to south, with an average value of 10 kW/m being expected at a distance of 50 km from the shoreline. In terms of complementarity, two scenarios were considered (mild and restrictive), the difference between them being estimated to be around 10%. Several dimensionless indices were defined in order to highlight the correlation between solar, wind and wave conditions, which may be considered as an element of novelty for the target area. In general, higher values (0.5) were noted in the case of the wind-wave and wave-solar combinations, excepting the southern part of Portugal (Algarve) where particular conditions were noted. Finally, the expected power outputs from some relevant technologies were also estimated, including a new concept of the wave energy generator designed for the WindFloat platform. Compared to the solar and wind systems, the performance of the selected wave generation system was quite low, suggesting that other types of wave energy converters would be more appropriate at this moment in the coastal area targeted. Finally, we need to mention that the idea of using multiple resources from a single marine site is an attractive one, while the methodology dedicated to this topic will continuously improve as new technological solutions emerge. Full article
