Search Results (102)

This study addresses the challenge of drilling film-cooling holes in the turbine blades of aircraft engines. Titanium alloy TC4 was selected as the experimental material. The laser-drilling process was simulated with ANSYS to determine optimal parameters, which were subsequently applied in machining trials. An impact-drilling method was then used to evaluate how pulse width, pulse energy, and pulse count affect micro-hole entrance and exit diameters, taper, and roundness. Simulations revealed that pulse energy and pulse count predominantly govern entrance and exit diameters, whereas pulse count and pulse width exert a stronger influence on taper. Experiments confirmed that entrance and exit diameters increased as pulse energy rose from 2.0 J to 2.8 J; taper increased as pulse width widened from 0.6 ms to 1.4 ms; and entrance diameter, exit diameter, and taper all grew as pulse count rose from 40 to 60. Pulse width and pulse count also significantly affected hole roundness. Full article

This study investigates the impact of thermal barrier coatings (TBCs) on the individual contributions of cooling components in impingement-jet combined cooling under low Reynolds number conditions. Using decoupled methods, numerical simulations were conducted for cylindrical, fan-shaped, and conical hole geometries. The results show that without TBCs, the conical hole provides the best cooling performance, while the fan-shaped hole performs the worst. After applying TBCs, the cooling effectiveness of the cylindrical and conical holes remains largely unchanged, but the fan-shaped hole shows significant improvement, with performance comparable to the conical hole. The cylindrical hole keeps a uniform shape, leading to increased velocity and preventing stable film formation. In contrast, the expanding flow passages of the fan-shaped and conical holes promote a gradual decrease in flow velocity, supporting stable film formation and effective thermal protection. Impingement cooling accounts for more than 75% of the overall cooling effectiveness for across hole types. For cylindrical and conical holes, the TBCs primarily enhance in-hole cooling, while for the fan-shaped hole, it increases in-hole cooling effectiveness and shifts film cooling effectiveness from negative to positive, significantly improving its overall contribution. Full article

Given the exceptional capabilities of femtosecond laser processing in achieving high-precision ablation for air-film cooling hole fabrication on turbine blades, it is imperative to develop an advanced monitoring methodology that enables real-time feedback control to automatically terminate the laser upon complete penetration detection, thereby effectively preventing backside damage. To tackle this issue, a spectrum-domain coherent imaging technique has been developed. This innovative approach adapts the fundamental principle of fiber-based Michelson interferometry by integrating the air-film hole into a sample arm configuration. A broadband super-luminescent diode with a 830 nm central wavelength and a 26 nm spectral bandwidth serves as the coherence-optimized illumination source. An optimal normalized reflectivity of 0.2 is established to maintain stable interference fringe visibility throughout the drilling process. The system achieves a depth resolution of 11.7 μm through Fourier transform analysis of dynamic interference patterns. With customized optical path design specifically engineered for through-hole-drilling applications, the technique demonstrates exceptional sensitivity, maintaining detection capability even under ultralow reflectivity conditions (0.001%) at the hole bottom. Plasma generation during laser processing is investigated, with plasma density measurements providing optical thickness data for real-time compensation of depth measurement deviations. The demonstrated system represents an advancement in non-destructive in-process monitoring for high-precision laser machining applications. Full article

Advanced gas turbine cooling technologies are required to bridge the gap between turbine inlet temperatures and component thermal limits. Transpiration cooling has emerged as a promising method, leveraging porous structures to enhance cooling effectiveness. Recent advancements in additive manufacturing (AM) enable precise fabrication of complex transpiration cooling architectures, such as triply periodic minimal surface (TPMS) and biomimetic designs. This review analyzes AM-enabled transpiration cooling for gas turbines, elucidating key parameters, heat transfer mechanisms, and flow characteristics of AM-fabricated designs through experimental and numerical studies. Previous research has concluded that well-designed transpiration cooling achieves cooling effectiveness up to five times higher than the traditional film cooling methods, minimizes jet lift-off, improves temperature uniformity, and reduces coolant requirements. Optimized coolant controls, graded porosity designs, complex topologies, and hybrid cooling architectures further enhance the flow uniformity and cooling effectiveness in AM transpiration cooling. However, challenges remain, including 4–77% porosity shrinkage in perforated transpiration cooling for 0.5–0.06 mm holes, 15% permeability loss from defects, and 10% strength reduction in AM models. Emerging solutions include experimental validations using advanced diagnostics, high-fidelity multiphysics simulations, AI-driven and topology optimizations, and novel AM techniques, which aim at revolutionizing transpiration cooling for next-generation gas turbines operating under extreme conditions. Full article

This study aims to enhance the understanding of film cooling performance in an actual turbine vane by investigating influencing factors and developing more precise numerical prediction methods. Pressure sensitive paint (PSP) testing and Reynolds-Averaged Navier–Stokes (RANS) simulations were conducted. The findings indicate that the current design blowing ratio of S1 holes (0.89) is too high, resulting in poor film cooling effectiveness. However, the blowing ratios of P3 (0.78) and P4 (0.69) holes are relatively low, suggesting that increasing the coolant flow could improve the film cooling effectiveness. It is not recommended to design an excessively low blowing ratio on the suction surface, as this can lead to poor wall adherence downstream of the film holes. A slight increase in turbulence intensity enhances the film covering effect, particularly on the suction surface. Additionally, a novel superposition method for multirow fan-shaped film cooling holes on an actual turbine vane is proposed, exhibiting better agreement with experimental data. Compared with experimental results, the numerical predictions tend to underestimate the film cooling effectiveness with the examined k-ε-based viscosity turbulence models and Reynolds stress turbulence models, while the SST demonstrates relatively higher accuracy owing to its hybrid k-ω/k-ε formulation that better resolves near-wall physics and separation flows characteristic of turbine cooling configurations. This study contributes to the advancement of turbine vane thermal analysis and design in engineering applications. Full article

Film cooling has been increasingly applied in turbine blade cooling design due to its excellent cooling performance. Although film-cooled blades demonstrate superior cooling effectiveness, the perforation design on blade surfaces compromises structural integrity, making fatigue failure prone to occur at cooling holes. Previous studies by domestic and international scholars have extensively investigated factors influencing film cooling effectiveness, including blowing ratio and hole geometry configurations. However, most research has overlooked the investigation of fatigue life in film-cooled blades. This paper systematically investigates blade fatigue life under various cooling air parameters by analyzing the relationships among cooling effectiveness, stress distribution, and fatigue life. Results indicate that maximum stress concentrations occur at cooling hole locations and near the blade root at trailing edge regions. While cooling holes effectively reduce blade surface temperature, they simultaneously create stress concentration zones around the apertures. Both excessive and insufficient cooling air pressure and temperature reduce thermal fatigue life, with optimal parameters identified as 600 K cooling temperature and 0.75 MPa pressure, achieving a maximum thermal fatigue life of 3400 cycles for this blade configuration. A thermal shock test platform was established to conduct fatigue experiments under selected cooling conditions. Initial fatigue damage traces emerged at cooling holes after 1000 cycles, with progressive damage expansion observed. By 3000 cycles, cooling holes near blade tip regions exhibited the most severe failure, demonstrating near-complete functional degradation. These findings provide critical references for cooling parameter selection in practical aeroengine applications of film-cooled blades. Full article

Aerospace engines ingest small particles when operating in a particulate-rich environment, such as sandstorms, atmospheric pollution, and volcanic ash clouds. These micron particles enter their cooling channels, leading to film-cooling hole blockage and thus thermal damage to turbine blades made of nickel-based single-crystal superalloy materials. This work studied the collision and deposition mechanisms between the micron particles and structure surface. A combined theoretical and numerical study was conducted to investigate the effect of deposits on particle collision and deposition. Finite element models of deposits with flat and rough surfaces were generated and analyzed for comparison. The results show that the normal restitution coefficient is much lower when a micron particle impacts a deposit compared to that of particle collisions with DD3 nickel-based single-crystal wall surfaces. The critical deposition velocity of a micron particle is much higher for particle–deposit collisions than for particle–wall collision. The critical deposition velocity decreases with the increase in particle size. When micron particles deposit on the wall surface of the structure, early-stage particle–wall collision becomes particle–deposit collision when the height of the deposits is greater than twice the particle diameter. For contact between particles and rough surface deposits, surfaces with a shorter correlation length, representing a higher density of asperities and a steeper surface, have a much longer contact time but a lower contact area. The coefficient of restitution of the particle reduces as the surface roughness of the deposits increase. The characteristic length of the roughness has little effect on the rebounding rotation velocity of the particle. Full article

Film cooling can continuously cover a layer of low-temperature gas film on the surface of hot-end components, thereby achieving the effect of isolating high-temperature gas, and can achieve a temperature drop of 600 K. As an advanced and efficient cooling technique, film cooling plays a crucial role in the process of turbine power and efficiency increase, with the key factor influencing its cooling performance being the configuration and arrangement of the film holes. This paper summarizes the design and arrangement of film hole configurations and discusses the potential directions for enhancing film cooling performance. Through analysis, the optimization of film cooling performance is mainly approached from two aspects: first, optimizing the hole configuration, which includes the study of shaped holes, enhancing the cooling performance of cylindrical holes using auxiliary structures, and forming a “reverse kidney-shaped vortex” structure by using a single combined film hole; second, optimizing the arrangement of the cooling holes on the turbine surface to achieve a more uniform and efficient distribution of the cooling film. Future development trends are primarily reflected in the following aspects: designing new, easily manufacturable, high-efficiency film hole configurations and further expanding their stable operating range is an important development direction. It is essential to validate the reverse heat transfer method, assess its applicable range, and, when experimental conditions exceed the applicable range, use related theories to correct its predictive performance. This is key to overcoming the bottleneck in film cooling prediction. It is critical to develop a film hole arrangement guideline that is suitable for various types of film holes and components with temperature differences at the thermal end, to fill the gap in future film cooling optimization design technologies. This study aims to provide new ideas for the optimal design of the cooling system and further improve the power and efficiency of gas turbines. Full article

This research work details the main factors affecting the orifice and profile morphology of micro-holes processed by the one-step femtosecond laser helical drilling method. Cylindrical holes or even inverted cone holes can be obtained with the appropriate deflection angle and translation distance. The orifice morphology of the micro-hole is mainly influenced by the rotation speed of the Dove prism installed inside the hollow motor, laser output power, and laser repetition frequency. A higher instantaneous power density can improve the outlet morphology and produce sharper cutting edges and thinner recast layers, although it may increase the splashing around the inlet to some extent. Subsequent to the experiment, it was determined that in order to enhance the quality of the holes, it was necessary to select a higher laser power and a lower repetition frequency, such as 10 W and 100 kHz, according to the experiments. A recast layer thickness of less than 5 µm and a surface roughness value of less than 0.8 µm were obtained within 3–5 s processing time, which can satisfy the requirements for aircraft application of efficiency and quality. Full article

To investigate the effect of film-cooling-hole inclination on the creep performance of nickel-based superalloy IN-738 specimens, this study designed samples with film-cooling holes at four inclination angles: 0°, 30°, 45°, and 60°. High-temperature creep tests were conducted, and the fracture morphologies of the failed specimens were analyzed using scanning electron microscopy. The results indicate that under conditions of 800 °C and 350 MPa, the inclination angle of the film-cooling holes significantly influences the creep performance of the specimens, with creep lifetimes ranking in descending order as 0° > 60° > 45° > 30°. A fracture analysis revealed that creep failure in specimens with film-cooling holes primarily resulted from stress concentration at the hole edges, where cracks and voids frequently initiated. The creep fractures exhibited dimple-type failure characteristics localized around the film-cooling holes due to stress concentration. Simulations based on the K-R damage model were performed for the four different inclination angles, confirming the existence of stress concentration around the film-cooling holes. The numerical analysis results closely matched the experimental data. Furthermore, the node stress method was used to predict the creep rupture life of specimens with film-cooling holes, demonstrating high accuracy in life prediction. Full article

Different cultivation measures, including seeding patterns, plastic film mulching, and drip irrigation, significantly affect crop growth and yield. This study conducted a two-year field experiment, involving eight treatments: hole seeding and drill seeding, mulching and bare land, as well as with and without drip irrigation. Analyzed the impact on agronomic traits, photosynthesis, chlorophyll fluorescence parameters, and yield components during the growth period of foxtail millet. The results of two years indicate that the growth trend of foxtail millet was consistent under both hole seeding and drill seeding. The best performance was achieved with drip irrigation treatment for mulching, followed by drip irrigation for bare land, no drip irrigation for mulching, and no drip irrigation for bare land. In 2024, the maximum yield of HFD in hole seeding pattern was 4627.55 kg/ha. The maximum yield of DFD in drill pattern is 4430.22 kg/ha. In summary, based on the comprehensive optimization of two years of data and the effective accumulated temperature in the local area, the best planting method is hole seeding, mulching, and drip irrigation. In cold and cool regions, mulching with film aids in increasing the accumulated temperature of the tillage layer. Hole seeding is conducive to enhancing seedling quality. Performing drip irrigation once during the late heading stage stimulates the growth and fruiting of foxtail millet, thereby increasing yield. Full article

The isothermal oxidation behavior of single crystal DD6 film-cooling blades was investigated. The isothermal oxidation tests were conducted at 1050 °C, and the phase analysis was performed by XRD, while SEM (EDS) was employed to observe the material. In addition to experimental studies, a numerical simulation using three-dimensional finite element analysis based on Abaqus software (Version 6.13) was implemented to model the growth stress in specimens during the isothermal test. The obtained results showed that the average oxidation rate of specimens rose with increments in film hole spacing, up to a maximum value at a film hole spacing of 0.75 mm, and then fell, which could be interpreted with the concepts of the oxidation-affected zone and the growth stress. The results obtained from the numerical simulation of the growth stress agreed with the experimental results of the average oxidation rate. The oxide scale of film-cooling specimens mainly consisted of three layers, the NiO outer layer, the spinel sublayer containing cracks, and the non-continuous thin Al₂O₃ inner layer. The surface of the oxide scale commonly underwent spallation of the NiO outer layer, and the exposed sublayer could grow new NiO particles. The size of the NiO particles on the edge of the film holes was larger than those on the walls of the film holes. SEM images clearly showed that electro-hydraulic beam drilling on DD6 superalloy specimens could erode the γ phase in the γ/γ′ two-phase matrix, thereby inducing damages in regions near film holes. Full article

This paper presents a numerical study investigating the coupled effects of periodic incoming wake and pulsating jets on the film cooling efficiency of a flat wall. The sweeping frequency of the wake is maintained at a constant 10 Hz, while the blowing ratio (M) varies from 0.3 to 1. By adjusting the initial position of the rod, different phase lags are generated to assess the interaction between the incoming wake and the pulsating jet concerning film cooling efficiency. The results reveal that coupling the wake-affected surface with the low-blowing-ratio phase of the pulsating jet can effectively enhance film cooling efficiency at lower blowing ratios. Conversely, at higher blowing ratios, aligning the low-pressure phase of the pulsating jet at the film hole with the high-blowing-ratio jet pulsation results in an improved film cooling effect. Notably, when the phase lag (ψ) is set to zero, the cooling efficiency of the pulsating film reaches its maximum across all blowing ratios, indicating an optimal coupling strategy. Full article

As the inlet temperature of the gas turbine exceeds the high temperature limit of the blade materials, efficient leading edge cooling technologies are crucial for the further development of gas turbines. Therefore, this paper reviews the research progress on external cooling technology, internal cooling technology, and composite cooling technology for gas turbine rotating blade leading edge cooling. It focuses on the impact of the geometric shape, arrangement, and flow parameters of film cooling holes on external cooling performance, the influence of jet hole design, configuration, crossflow, ribs on internal cooling efficiency, and the characteristics and influencing factors of composite cooling technologies are also discussed. Among the most promising composite cooling techniques, the impingement jet film composite cooling technology and swirl film composite cooling technology stand out. For impingement jet film composite cooling technology, this paper explores the effects of blowing ratio, nozzle parameters, jet hole characteristics, and flow field parameters on the overall cooling performance of the rotating blade leading edge. Impingement jet film composite cooling technology has been shown to significantly improve the cooling performance of the leading edge compared to traditional single cooling techniques. For applications requiring large area cooling or maintaining film integrity, swirl film composite cooling technology not only enhances heat transfer efficiency but also improves the uniformity of heat transfer. The design of swirl nozzles, coolant flow rate, Reynolds number, and jet temperature all have significant effects on the heat transfer efficiency of swirl film composite cooling. To further advance the development of gas turbine rotating blade leading edge cooling technologies, it is recommended to focus on the study of film composite cooling techniques, particularly investigating the effects of various parameters of impingement, swirl on composite cooling performance. Full article

The film superposition prediction model is a crucial tool in the preliminary design of the turbine outer ring, enabling the rapid estimation of adiabatic wall temperatures and significantly reducing computational costs. This study established the relationship between the mainstream temperature correction coefficient and the air bleed ratio based on energy conservation principles in the boundary layer during film injection. A superposition model grounded in mainstream temperature corrections was developed. The proposed model utilizes cooling efficiency characteristics based on the equivalent blowing ratio to accurately predict the cooling efficiency of multi-row hole layouts with varying hole spacings. Experiments on the adiabatic film cooling efficiency were conducted with four different hole configurations at various blowing ratios. The limitations of the traditional Sellers superposition method in predicting cooling efficiency distributions are discussed by comparing them with experimental data. The comparison reveals that the Sellers method accumulates prediction errors as the number of hole rows increases, leading to an overestimation of the cooling efficiency. Introducing a mainstream temperature correction factor effectively addressed this issue. The prediction accuracy of the improved model was higher at $M=0.3$, with relative deviations remaining within 10% across different test plates. As the blowing ratio increased, the prediction deviation gradually increased when the number of hole rows was less than 10. At a blowing ratio of 1.0, the deviation exceeded 20%. However, as the number of hole rows increased, the deviation remained within 10% under various blowing ratios. Compared to existing advanced models in the literature, the improved model demonstrated higher prediction accuracy under most conditions. For Case 1 in this study, the model predicted an average surface cooling efficiency deviation of 3.4% at a blowing ratio of 0.5. Similarly, for Case 14 in the literature, the deviation was 3.4% at a blowing ratio of 0.6. In contrast, the prediction deviations in the literature models were 16.1% and 8%, respectively. Furthermore, the introduction of the equivalent blowing ratio reduced the data requirements for calculating the single-hole-row cooling efficiency when performing cooling efficiency superposition predictions. Full article
