The use of hybrid materials as a combination of fibre-reinforced plastic (FRP) and metal is of great interest in order to meet the increasing demands for sustainability, efficiency, and emission reduction based on the principle of lightweight design. These two components can therefore be joined using the intrinsic joining technique, which is formed by curing the matrix of the FRP component. In this study, for the hybrid joint, unidirectionally pre-impregnated semi-finished products (prepregs) with duromer matrix resin and micro-alloyed HC340LA steel were used. In order to conduct a detailed investigation, the damage mechanisms of intrinsically produced fibre metal laminates (FMLs), a new clamping device, and a novel pressing tool were designed and put into operation. The prepregs were prestressed by applying a preloading force using a specially designed prestressing frame. Hybrid specimens were then produced and subjected to nanoindentation and a shear tensile test. In particular, the effect of the residual stress state by varying the defined prestressing force on the damage mechanisms was studied. The results showed that no fracture patterns occurred in the interface of the specimens without preloading as a result of curing at 120 °C, whereas specimens with preloading failed at the boundary layer in the tensile range. Nevertheless, all specimens cured at 160 °C failed at the boundary layer in the tensile range. Furthermore, it was proven that the force and displacement of the preloaded specimens were promisingly higher than those of the unpreloaded specimens. Full article

In the era of the climate emergency and different pandemics, systems that can provide an immediate response to housing needs are required. This paper aims to evaluate the use of fibre-reinforced plastic polymers (FRPs) to satisfy this need. In particular, a modular emergency housing system that utilises FRPs for structures and cladding is proposed, which proves adaptable to both different uses and different kinds of temporary or permanent buildings. By adapting modular emergency housing to different contexts, developing an integrated design process (IDP) and building information modelling (BIM) methodology, this research aims to provide innovations for the the architecture, engineering, and construction (AEC) sector, including FRPs, through a digitised approach, applied also to an experimental case study. A pilot unit of the modular emergency housing system, a nearly zero-energy building (nZEB), is described in detail, while laboratory tests are reported. Construction considerations confirm the sustainability and highlight the adaptability of the modular system to different housing needs conditions, justifying the possible future development of supply chain industrialisation supported by the presented methodology. Full article

In this study, 90 finite-element models are used to explore the behaviour of fibre-reinforced polymer (FRP) reinforced joints under combined in-plane bending (IPB) and axial load (AX). The effects of joint geometry, FRP layer count, and AX levels of the chord or brace are considered. Three typical failure modes are observed: chord plastic failure, brace plastic failure, and brace buckling failure. Increasing the number of FRP layers can ensure that failure is chord-related failure in a ductility manner rather than the unexpectedly brace-related brittle failure. Depending on the stress distribution of fibres, FRP reinforcement can restrict the deformation of joints subjected to complex loading patterns. Moreover, added FRP layers efficiently reduce the effect of brace AX on the IPB resistance. Finally, a modified strength equation is established, including the influence of FRP reinforcement, chord AX, and brace AX. Full article

Bushing-insert connections have emerged as efficient blade root connection designs. Bushing-insert connections with fibre-reinforced plastic (FRP) wedge-sticks enhance the strength and stability of the blade root, prevent stress concentration at the blade root, and improve the service life and reliability of the blade. However, studies on the failure mechanisms of the FRP wedge-sticks in bushing-insert connections are scarce. Hence, in this study, the influence of the FRP wedge-stick on the structural performance of the blade root was analysed by changing the slope of the FRP wedge-stick’s inclined surface at a constant thickness. The finite element method, sample testing, and full-size blade testing method were employed, and structural verification was conducted using an 84.5 m blade. The results reveal that the contact area of the inclined surface can be increased by reducing the slope of the FRP wedge-stick. This increase in area reduces the stress transmitted to each node of the FRP wedge-stick and blade root, prevents delamination of the FRP wedge-stick and blade root, and enhances the reliability of the blade root connection. Full article

The use of fibre-reinforced plastics (FRPs) in various industrial applications continues to increase thanks to their good strength-to-weight ratio and impact resistance, as well as the high strength that provides engineers with advanced options for the design of modern structures subjected to a variety of out-of-plane impacts. An assessment of the damage morphology under such conditions using non-destructive techniques could provide useful data for material design and optimisation. This study investigated the damage mechanism and energy-absorption characteristics of E-glass laminates and sandwich structures with GFRP face sheets with PVC cores under quasi-static indentation with conical, square, and hemispherical indenters. An acoustic emission (AE) technique, coupled with a k-means++ pattern-recognition algorithm, was employed to identify the dominant microscopic and macroscopic damage mechanisms. Additionally, a post-mortem damage assessment was performed with X-ray micro computed tomography and scanning electron microscopy to validate the identified clusters. It was found that the specific energy absorption after impact with the square and hemispherical indenters of the GFRP sandwich and the plain laminate differed significantly, by 19.29% and 43.33%, respectively, while a minimal difference of 3.5% was recorded for the conical indenter. Additionally, the results obtained with the clustering technique applied to the acoustic emission signals detected the main damaged modes, such as matrix cracking, fibre/matrix debonding, delamination, the debonding of face sheets/core, and core failure. The results therefore could provide a methodology for the optimisation and prediction of damage for the health monitoring of composites. Full article

Fiber reinforced plastics (FRP) offer huge potentials for energy efficient applications. Special care must be taken during both FRP fabrication and usage to ensure intended material properties and behavior. This paper presents a novel approach for the monitoring of the strain and temperature of glass fibre reinforced polymer (GFRP) materials in the context of both production process monitoring and structural health monitoring (SHM) applications. The sensor is designed to be integrated into GFRPs during the production process, and the sensor concept includes possibilities of automated placement during textile layup. To minimize sensor impact on GFRP integrity and to simplify vacuum setup and part handling, the sensor operates without the need for either wires or a battery. In the first sections of this work, sensor concept, design and prototype fabrication are presented. Subsequently, it is shown how the sensors can be used for flow front monitoring and cure estimation during GFRP production by measuring local resin temperature. The resulting specimens are then characterized regarding strain measurement capabilities, mechanical influence on the host component and overall system limitations. Average strain sensor accuracy is found to be ≤0.06 mm/m, while a maximum operation temperature of 126.9 °C and a maximum reading distance of 38 mm are measured. Based on a limited number of bending tests, no negative influence of sensor presence on breaking strength could be found. Possible applications include structural components, e.g., wind turbine blades or boat hulls. Full article

Laminated fibre-reinforced polymer (FRP) tubes are increasingly used as compression members in large-span spatial structures due to their high bearing capacity, corrosion resistance, and superior stability compared to high-strength steel pipes. In this study, axial compression tests were conducted on slender BFRP tubes to evaluate their compression characteristics as compression members. The results indicated that BFRP tubes exhibited three distinct failure modes, namely local failure, critical failure, and buckling failure. Overall, buckling was identified as the primary mode of failure under compression. The stress–strain curves of BFRP tubes were characterized by three stages, including elastic, elastic-plastic, and plastic stages. To enable design-oriented approaches, two three-stage theoretical models for BFRP tubes were developed through experimental data analysis. The models predicted the stress–strain curves and the load-lateral deflection curves, taking into account the post-peak softening behaviour of the stress–strain curves. Comparisons between the test results and the predictions calculated using the proposed models indicated that they were in good agreement. Full article

Fibre-reinforced plastic (FRP) materials are attracting growing interest because of their high specific mechanical properties. These characteristics, in addition to a high level of tailorability and design of freedom, make them attractive for marine, aerospace, automotive, sports and energy applications. However, the large use of this class of material dramatically increases the amount of waste that derives from end-of-life products and offcuts generated during the manufacturing processes. In this context, especially when thermosetting matrices are considered, the need to deeply study the recycling process of FRPs is an open topic both in academic and industrial research. This review aims to present the current state of the art of the most affirmed recycling technologies used for polymeric composites commonly used in industrial applications, such as carbon and glass FRPs. Each recycling method (i.e., chemical, thermal and mechanical) was analysed in terms of technological solutions and process parameters required for matrix dissolution and fibre recovery, showing their advantages, drawbacks, applications and properties of the recycled composites. Therefore, the aim of this review is to offer an extensive overview of the recycling process of polymeric composite materials, which is useful to academic and industrial researchers that work on this topic. Full article

Self-healing materials offer a potential solution to the problem of damage to fibre-reinforced plastics (FRPs) by allowing for the in-service repair of composite materials at a lower cost, in less time, and with improved mechanical properties compared to traditional repair methods. This study investigates for the first time the use of poly(methyl methacrylate) (PMMA) as a self-healing agent in FRPs and evaluates its effectiveness both when blended with the matrix and when applied as a coating to carbon fibres. The self-healing properties of the material are evaluated using double cantilever beam (DCB) tests for up to three healing cycles. The blending strategy does not impart a healing capacity to the FRP due to its discrete and confined morphology; meanwhile, coating the fibres with the PMMA results in healing efficiencies of up to 53% in terms of fracture toughness recovery. This efficiency remains constant, with a slight decrease over three subsequent healing cycles. It has been demonstrated that spray coating is a simple and scalable method of incorporating a thermoplastic agent into an FRP. This study also compares the healing efficiency of specimens with and without a transesterification catalyst and finds that the catalyst does not increase the healing efficiency, but it does improve the interlaminar properties of the material. Full article

The present study makes a consistent attempt to evaluate promising additive manufacturing (AM) processes and materials for marine structural applications, paving the way for the development of additively manufactured light-weight composites. The main objective is to analyse the structural performances of fibre-reinforced plastics (FRP) produced by AM for marine applications. In particular, the tensile response of chopped and continuous carbon-fibre-reinforced thermoplastics have been investigated through destructive and non-destructive testing, considering the influence of AM process settings and thermal post-manufacturing treatments. The results demonstrate that continuous fibre-reinforced thermoplastics produced by AM are potentially suited to marine structural applications, since their tensile capacity is superior to the minimum imposed by the Classification Society Rules. However, the mechanical properties of additively manufactured FRP are currently lower than conventional composites. The continuous carbon fibre reinforcement is far more effective than the chopped one, and the additive manufacturing deposition pattern significantly influences the structural capacity. The annealing post-manufacturing treatment enhances the mechanical properties by approximately 10%, decreasing material ductility and manufacturing defects. Full article

The rehabilitation of steel structures with Fibre Reinforced Polymers (FRP’s) may appear less effective because they can be bolted or welded with steel plates that display the same mechanical properties. However, this technique has some unwanted consequences such as additional dead weight and an increased risk of corrosion. The aim of the proposed study, therefore, is to present a technique for modelling steel connections strengthened with FRP’s. Two types of composites: Carbon Fibre Reinforced Polymer (CFRP) and Glass Fibre Reinforced Polymer (GFRP) are considered. They are used to strengthen welded steel connections. The main objective consists in evaluating the effect of the reinforcement on the load-carrying capacity of these connections under monotonic and cyclic loadings. The steel is considered to behave in a linear elastic perfectly plastic fashion with isotropic strain hardening, and the FRP’s are assumed to behave linearly up to failure. The behaviour of the adhesive is modelled with the Cohesive Zone Model (CZM) available in Abaqus. Lastly, a parametric study is carried out to investigate the eventuality of strengthening connections made with I-sections, which are very common in practice. Full article

In recent times, the use of fibre-reinforced plastic (FRP) has increased in reinforcing concrete structures. The bond strength of FRP rebars is one of the most significant parameters for characterising the overall efficacy of the concrete structures reinforced with FRP. However, in cases of elevated temperature, the bond of FRP-reinforced concrete can deteriorate depending on a number of factors, including the type of FRP bars used, its diameter, surface form, anchorage length, concrete strength, and cover thickness. Hence, accurate quantification of FRP rebars in concrete is of paramount importance, especially at high temperatures. In this study, an artificial intelligence (AI)-based genetic-expression programming (GEP) method was used to predict the bond strength of FRP rebars in concrete at high temperatures. In order to predict the bond strength, we used failure mode temperature, fibre type, bar surface, bar diameter, anchorage length, compressive strength, and cover-to-diameter ratio as input parameters. The experimental dataset of 146 tests at various elevated temperatures were established for training and validating the model. A total of 70% of the data was used for training the model and remaining 30% was used for validation. Various statistical indices such as correlation coefficient (R), the mean absolute error (MAE), and the root-mean-square error (RMSE) were used to assess the predictive veracity of the GEP model. After the trials, the optimum hyperparameters were 150, 8, and 4 as number of chromosomes, head size and number of genes, respectively. Different genetic factors, such as the number of chromosomes, the size of the head, and the number of genes, were evaluated in eleven separate trials. The results as obtained from the rigorous statistical analysis and parametric study show that the developed GEP model is robust and can predict the bond strength of FRP rebars in concrete under high temperature with reasonable accuracy (i.e., R, RMSE and MAE 0.941, 2.087, and 1.620, and 0.935, 2.370, and 2.046, respectively, for training and validation). More importantly, based on the FRP properties, the model has been translated into traceable mathematical formulation for easy calculations. Full article

The consequence of exposure to the dual environment of seawater sea sand concrete (SWSSC) on the inner surface and seawater (SW) on the outer surface on the durability of fibre reinforced plastic (FRP) confining tubes has received very limited research attention. The durability of FRPs fabricated with different fibre types was investigated for the application of SWSSC filled tubes and SWSSC-filled double-skin tubes exposed to the external environment of SW. The colour and shininess of carbon-fibre-reinforced polymer (CFRP) surfaces generally stayed unchanged even after 6 months of exposure to the dual environment, whereas basalt-fibre-reinforced polymer (BFRP) and glass-fibre-reinforced polymer (GFRP) tubes suffered degradation. The degradation led to a ~20–30% increase in pH; however, the pH increase in the external SW was more pronounced when the internal solution was SWSSC. The extent of degradation was greater in BFRP that in GFRP. The investigation also included a specialised investigation of the degradation at the fibre–matrix interface by fracturing specimens in liquid nitrogen. Full article

The current study focuses on the impact loading phase characteristic of thin first year ice in inland waterways. We investigate metal grillages, fibre reinforced plastic (FRP) composites and nature-inspired composites using LS Dyna. The impact mode is modelled as (a) simplified impact model with a rigid-body impactor and (b) an experimentally validated ice model represented by cohesive zone elements. The structural concepts are investigated parametrically for strength and stiffness using the simplified model, and an aluminium alloy grillage is analysed with the ice model. The metal–FRP composite was found to be the most favourable concept that offered impact protection as well as being light weight. By weight, FRP composites with a Bouligand ply arrangement were the most favourable but prone to impact damage. Further, aluminium grillage was found to be a significant contender for a range of ice impact velocities. While the ice model is experimentally validated, a drawback of the simplified model is the lack of experimental data. We overcame this by limiting the scope to low velocity impact and investigating only relative structural performance. By doing so, the study identifies significant parameters and parametric trends along with material differences for all structural concepts. The outcomes result in the creation of a viable pool of lightweight variants that fulfil the impact loading phase. Together with outcomes from quasi-static loading phase, it is possible to develop a lightweight ice-going hull concept. Full article

The growing demands for electrical energy, especially renewable, is boosting the development of wind turbines equipped with longer composite blades. To reduce the maintenance cost of such huge composite parts, the structural health monitoring (SHM) is an approach to anticipate and/or follow the structural behaviour along time. Apart from the development of traditional non-destructive testing methods, in order to reduce the use of intrusive instrumentation there is a growing interest for the development of “self-sensing materials”. An interesting route to achieve this, can be to introduce carbon nanofillers such as nanotubes (CNT) in the composite structures, which enables to create systems that are sensitive to both strain and damage. This review aims at updating the state of the art of this topic so far. A first overview of the existing SHM techniques for thermoset based wind turbine blades composites is presented. Then, the use of self-sensing materials for strain and damage sensing is presented. Different strategies are overviewed and discussed, from the design of conductive composites such as carbon fibres reinforced polymers, to the elaboration of conductive nano-reinforced polymer composites. The origins of sensing mechanisms along with the percolation theory applied to nanofillers dispersed in polymer matrices are also detailed. Full article
