Search Results (23)

New materials are actively being developed for use in various fields of electronics, as they can significantly improve the performance of electronic devices and prevent adverse effects. Such materials include nanocomposites, which include nanoparticles of magnetic metals and alloys in a non-magnetic polymer or carbon matrix. For the first time, we synthesized FeCoSm/C nanocomposites and studied the effect of synthesis conditions on their structure, composition, and electromagnetic properties. Thermogravimetric (TG) analysis and differential scanning calorimetry (DSC) analysis of the heating processes of nanocomposite precursors allowed optimizing the mode of IR processing of precursors. X-ray phase analysis (XPA) showed that nanoparticles of a solid-metal solution based on the FeCo structure are formed, and at temperatures above 700 °C, the formation of SmCo5-x alloy nanoparticles is also possible. As the synthesis temperature increases, the average size of nanoparticles of alloys containing Sm increases. The effect of the metal ratio in the precursor on the structure, composition, and electromagnetic properties of FeCoSm/C nanocomposites is analyzed. It has been established that the most promising of all the studied materials are those obtained at a temperature of 700 °C with a metal ratio of Fe:Co:Sm = 50:40:10. Full article

Calorimetry at the High Luminosity LHC (HL-LHC) faces many challenges, particularly in the forward direction, such as radiation tolerance and large in-time event pileup. To meet these challenges, the CMS Collaboration is preparing to replace its current endcap calorimeters from the HL-LHC era with a high-granularity calorimeter (HGCAL), featuring an unprecedented transverse and longitudinal segmentation, for both the electromagnetic and hadronic compartments, with 5D information (space–time–energy) read out. The proposed design uses silicon sensors for the electromagnetic section (with fluences above ${10}^{16} {\mathrm{n}}_{eq}{\mathrm{/cm}}^2$) and high-irradiation regions (with fluences above ${10}^{14} {\mathrm{n}}_{eq}{\mathrm{/cm}}^2$) of the hadronic section, while in the low-irradiation regions of the hadronic section, plastic scintillator tiles equipped with on-tile silicon photomultipliers (SiPMs) are used. Full HGCAL will have approximately 6 million silicon sensor channels and about 280 thousand channels of scintillator tiles. This will allow for particle-flow-type calorimetry, where the fine structure of showers can be measured and used to enhance particle identification, energy resolution and pileup rejection. In this overview we present the ideas behind HGCAL, the current status of the project, results of the beam tests and the challenges that lie ahead. Full article

Developing materials for efficient energy storage and effective electromagnetic interference (EMI) shielding is crucial in modern technology. This study explores the synthesis and characterization of carbonaceous shape-stabilized octadecane/MWCNT (multi-walled carbon nanotube) composites, utilizing activated carbon, expanded graphite or ceramic carbon foam, as shape stabilizers for phase change materials (PCMs) to enhance thermal energy storage and EMI shielding, for energy-efficient and advanced applications. The integration of octadecane, a phase change material (PCM) with carbonaceous stabilizers ensures the material’s stability during phase transitions, while MWCNTs contribute to improved thermal storage properties and EMI shielding capabilities. The research aims to develop novel composites with dual functionality for thermal storage and EMI shielding, emphasizing the role of carbon matrices and their MWCNT composites. SEM and CT microtomography analyses reveal variations in MWCNT incorporation across the matrices, influenced by surface properties and porosity. Leaching tests, infrared spectroscopy (FT-IR) and differential scanning calorimetry (DSC) confirm the composite’s stability and high latent heat storage. The presence of nanotubes enhances the thermal properties of octadecane and ΔH values almost reached their theoretical values. EMI shielding effectiveness measurements indicate that the composites show improved electric properties in the presence of MWCNTs. Full article

Dimethylformamide (DMF), a polar solvent, is commonly used for preparing graphene/epoxy nanocomposites. While previous research has commonly predominantly highlighted the improvement in physio-mechanical properties of these nanocomposites, the effect of DMF on processing and its direct influence on the final characteristics of MXene/epoxy nanocomposites have not been investigated. This unexplored link between DMF dosage, MXene concentrations, and the final composite properties presents an exciting direction for future research. In this study, a fixed dosage of DMF was used with varying MXene concentrations to fabricate the nanocomposites. To assess the reliability of DMF dosage on the characteristics of the fabricated nanocomposites, various evaluation techniques were employed, including dispersion evaluation, mechanical tests, thermogravimetric analysis (TGA), differential scanning calorimetry (DSC), scanning electron microscopy (SEM), electromagnetic interference (EMI) shielding, and surface roughness measurements. The research outcomes revealed that as MXene concentration increased, the characteristics of the MXene/epoxy nanocomposites, improved across the board, indicating their potential for use in energy storage applications. Full article

Charged particle beams driven to ultra-high dose rates (UHDRs) have been shown to offer potential benefits for future clinical applications, particularly in the reduction of normal-tissue toxicity. Studies of the so-called FLASH effect have shown promise, generating huge interest in high dose rate radiation studies. With laser-driven proton beams, where the duration of the proton burst delivered to a sample can be as short as hundreds of picoseconds, the instantaneous dose rates are several orders of magnitude higher than those used for conventional radiotherapy. The dosimetry of these beam modalities is not trivial, with conventional active detectors, such as ionisation chambers, experiencing saturation effects making them unusable at the extremely high dose rates. Calorimeters, measuring the radiation-induced temperature rise in an absorber, offer an ideal candidate for the dosimetry of UHDR beams. However, their application in the measurement of laser-driven UHDR beams has so far not been trialled, and their effective suitability to work with the quasi-instantaneous and inhomogeneous dose deposition patterns and the harsh environment of a laser-plasma experiment has not been tested. The measurement of the absorbed dose of laser-driven proton beams was conducted in a first-of-its-kind investigation, employing the VULCAN-PW laser system of the Central Laser Facility (CLF) at the Rutherford Appleton Laboratory (RAL), using a small-body portable graphite calorimeter (SPGC) developed at the National Physical Laboratory (NPL) and radiochromic films. A small number of shots were recorded, with the corresponding absorbed dose measurements resulting from the induced temperature rise. The effect of the electromagnetic pulse (EMP) generated during laser–target interaction was assessed on the system, showing no significant effects on the derived signal-to-noise ratio. These proof-of-principle tests highlight the ability of calorimetry techniques to measure the absorbed dose for laser-driven proton beams. Full article

The Liquid Argon Time Projection Chamber (LArTPC) is increasingly becoming the chosen technology for current and future precision neutrino oscillation experiments due to its superior capability in particle tracking and energy calorimetry. In LArTPCs, calorimetric information is critical for particle identification, which is the foundation for neutrino cross-sections and oscillation measurements, as well as searches for beyond-standard-model physics. One of the primary challenges in employing LArTPC technology is characterizing its performance and quantifying the associated systematic uncertainties. MicroBooNE, the longest-operating LArTPC to date, has performed numerous such measurements, including studies of detector physics and electromagnetic shower reconstruction. Here, we present results on the operation and performance of the detector during its data taking, highlighting accomplishments toward calorimetric reconstruction, calibration, and detector physics. Full article

Scintillation crystals Gd₃Al₂Ga₃O₁₂ (GAGG) are an excellent candidate for application in ionizing-radiation detectors because of their high radiation resistance, density and light yield. These crystals can be used in combination with lead tungstate (PbWO₄ or PWO) crystals for the development of a new generation of electromagnetic calorimeter with advanced spatial and energy resolutions in a broad energy range. PWO crystals enable the accurate detection of high-energy photons, while GAGG crystals provide the possibility of precisely measuring photon energies, down to a few MeV. Different options for a composite electromagnetic calorimeter based on PWO and GAGG crystals are considered to optimize spatial and energy resolutions in a broad energy range (from 1 MeV to 100 GeV). In particular, different lengths of the GAGG section of the calorimeter are considered, from 0.5 to 10 cm. The separation of signals from photons and hadrons is also taken into consideration through the study of shower shape in the calorimeter. The optimization is based on Geant4 simulations, considering light collection as well as the use of different photodetectors and electronic noise. Simulations are verified with light yield measurements of GAGG samples obtained using radioactive sources and test beam measurements of the prototype of the PWO-based Photon Spectrometer of the ALICE experiment at CERN. Full article

The processes of crystallization and melting, and the structure of ice formed under freezing in an alternating electromagnetic field with a frequency of 2.45 GHz have been studied using thermometry, differential scanning calorimetry, and X-ray diffraction. Using X-ray powder diffraction at 85 K, it was determined that the obtained samples consisted of several phases of hexagonal ice I_h, with a density 0.43 ÷ 2.58% higher than that of ordinary ice. The time necessary for this ice to crystallize was approximately 2.2 times shorter than that of ordinary ice not exposed to an alternating electromagnetic field. According to the data of differential scanning calorimetry, the melting of this ice was accompanied by an endothermic heat effect 9% greater than that of ordinary ice, and a melting point that was 1 °C lower. A similar effect is typical of the melting of metastable phases. We assume that the formation of ice I_h with increased density results from the action of an alternating electromagnetic field on the network of hydrogen bonds of liquid water which is a precursor for ice formation. Full article

With the growing demand for insulation parts in extreme service environments, such as nuclear power, aviation, and other related fields, fiberglass-reinforced silicone resin (FRSR) has become a popular choice due to its exceptional physical and chemical properties in high-temperature and electromagnetic working environments. To enhance the performance of FRSR molded parts that can adapt to more demanding extreme environments, the oven postcuring process parameters on thermal stability and mechanical properties of the bobbin were investigated. The curing behavior of FRSR was analyzed by using thermogravimetric analysis (TGA) and the differential scanning calorimetry (DSC) method, and the bobbins were manufactured based on the testing results. Subsequently, the bobbins were oven postcured at different conditions, and the heat resistance and mechanical properties were analyzed by TGA and tensile tests. The results revealed that the tensile strength of the bobbin increased by 122%, and the weight loss decreased by 0.79% at 350 °C after baking at 175 °C for 24 h. The optimal process parameters for producing bobbins to meet the criteria of nuclear installations were determined to be a molding temperature of 120 °C, molding pressure of 50 MPa, pressure holding time of 3 min, oven postcuring temperature of 175 °C, and postcuring time of 24 h. The molded products have passed the thermal aging performance test of nuclear power units. Full article

This paper undertakes the thermal and electrical characterization of three commercial unsaturated polyester imide resins (UPIR) to identify which among them could better perform the insulation function of electric motors (high-power induction motors fed by pulse-wide modulation (PWM) inverters). The process foreseen for the motor insulation using these resins is Vacuum Pressure Impregnation (VPI). The resin formulations were specially selected because they are one-component systems; hence, before the VPI process, they do not require mixing steps with external hardeners to activate the curing process. Furthermore, they are characterized by low viscosity and a thermal class higher than 180 °C and are Volatile Organic Compound (VOC)-free. Thermal investigations using Thermogravimetric Analysis (TGA) and Differential Scanning Calorimetry (DSC) techniques prove their excellent thermal resistance up to 320 °C. Moreover, impedance spectroscopy in the frequency range of 100 Hz–1 MHz was analyzed to compare the electromagnetic performance of the considered formulations. They manifest an electrical conductivity starting from 10⁻¹⁰ S/m, a relative permittivity around 3, and a loss tangent value lower than 0.02, which appears almost stable in the analyzed frequency range. These values confirm their usefulness as impregnating resins in secondary insulation material applications. Full article

The SiD detector concept capitalizes on high granularity in its tracker and calorimeter to achieve the momentum resolution and particle flow calorimetry physics goals in a compact design. The collaboration has had a long interest in the potential for improved granularity in both the tracker and ECal with an application of monolithic active pixel sensors (MAPS) and a study of MAPS in the SiD ECal was described in the ILC TDR. Work is progressing on the MAPS application in an upgraded SiD design with a prototyping design effort for a common SiD tracker/ECal design based on stitched reticules to achieve 10 × 10 cm² sensors with 25 × 100 micron² pixels. Application of large area MAPS in these systems would limit delicate and expensive bump-bonding, provide possibilities for better timing, and should be significantly cheaper than the TDR concept due to being a more conventional CMOS foundry process. The small pixels significantly improve shower separation. Recent simulation studies confirm previous performance projections, indicating electromagnetic energy resolution based on digital hit cluster counting provides better performance than the SiD TDR analog design based on 13 mm² pixels. Furthermore, the two shower separation is excellent down to the millimeter scale. Geant4 simulation results demonstrate these expectations. Full article

Electromagnetic calorimetry in high-radiation environments, e.g., forward regions of lepton and hadron collider detectors, is quite challenging. Although total absorption crystal calorimeters have superior performance as electromagnetic calorimeters, the availability and the cost of the radiation-hard crystals are the limiting factors as radiation-tolerant implementations. Sampling calorimeters utilizing silicon sensors as the active media are also favorable in terms of performance but are challenged by high-radiation environments. In order to provide a solution for such implementations, we developed a radiation-hard, fast and cost-effective technique, secondary emission calorimetry, and tested prototype secondary emission sensors in test beams. In a secondary emission detector module, secondary emission electrons are generated from a cathode when charged hadron or electromagnetic shower particles penetrate the secondary emission sampling module placed between absorber materials. The generated secondary emission electrons are then multiplied in a similar way as the photoelectrons in photomultiplier tubes. Here, we report on the principles of secondary emission calorimetry and the results from the beam tests performed at Fermilab Test Beam Facility as well as the Monte Carlo simulations of projected, large-scale secondary emission electromagnetic calorimeters. Full article

The Compact Muon Solenoid (CMS) is one of the general purpose detectors at the CERN Large Hadron Collider (LHC), where the products of proton–proton collisions at the center of mass energy up to 13.6 TeV are reconstructed. The electromagnetic calorimeter (ECAL) is one of the crucial components of the CMS since it reconstructs the energies and positions of electrons and photons. Even though several Machine Learning (ML) algorithms have been already used for calorimetry, with the constant advancement of the field, more and more sophisticated techniques have become available, which can be beneficial for object reconstruction with calorimeters. In this paper, we present two novel ML algorithms for object reconstruction with the ECAL that are based on graph neural networks (GNNs). The new approaches show significant improvements compared to the current algorithms used in CMS. Full article

Precision measurements of Z, W, and H decays at the next generation of circular lepton colliders will require excellent energy resolution for both electromagnetic and hadronic showers. The resolution is limited by event-to-event fluctuations in the shower development, especially in the hadronic system. Compensating for this effect can greatly improve the achievable energy resolution. Furthermore, the resolution can benefit greatly from the use of particle-flow algorithms, which requires the calorimeters to have a high granularity. The approach of dual-readout calorimetry has emerged as a candidate to fulfil both of these requirements by allowing to reconstruct the fluctuations in the shower development event-by-event and offering a high transverse granularity. An important benchmark of such a calorimeter is the electromagnetic energy resolution; a prototype of the IDEA calorimeter has been built for use in testbeams. In parallel, a simulation of this prototype has been developed in Geant4 for a testbeam environment. Here, we outline how this simulation was used to study the electromagnetic energy resolution and conclude that a resolution of $14\%/\sqrt{E}$ is achievable. Full article

The Liquid Argon Calorimeters are employed by ATLAS for all electromagnetic calorimetry in the pseudo-rapidity region $\left|\mathrm{\eta }\right|<3.2$, and for hadronic and forward calorimetry in the region from $\left|\mathrm{\eta }\right|=1.5$ to $\left|\mathrm{\eta }\right|=4.9$. They also provide inputs to the first level of the ATLAS trigger. After a successful period of data taking during the LHC Run 2 between 2015 and 2018, the ATLAS detector entered into a long period of shutdown. In 2022, the LHC will restart and the Run 3 period should see an increase of luminosity and pile-up of up to 80 interactions per bunch crossing. To cope with these harsher conditions, a new trigger readout path has been installed during the long shutdown. This new path should significantly improve the triggering performance on electromagnetic objects. This will be achieved by increasing the granularity of the objects available at trigger level by up to a factor of ten. The installation of this new trigger readout chain also required the update of the legacy system. More than 1500 boards of the precision readout have been extracted from the ATLAS pit, refurbished and re-installed. The legacy analog trigger readout, which will remain during the LHC Run 3 as a backup of the new digital trigger system, has also been updated. For the new system, 124 new on-detector boards have been added. Those boards that are operating in a radiative environment are digitizing the calorimeter trigger signals at 40 MHz. The digital signal is sent to the off-detector system and processed online to provide the measured energy value for each unit of readout. In total up to 31 Tbps are analyzed by the processing system and more than 62Tbps are generated for downstream reconstruction. To minimize the triggering latency the processing system had to be installed underground. The limited available space imposed a very compact hardware structure. To achieve a compact system, large FPGAs with high throughput have been mounted on ATCA mezzanines cards. In total, no more than three ATCA shelves are used to process the signal from approximately 34,000 channels. Given that modern technologies have been used compared to the previous system, all the monitoring and control infrastructure is being adapted and commissioned as well. This contribution presents the challenges of the installation, the commissioning and the milestones still to be completed towards the full operation of both the legacy and the new readout paths for the LHC Run 3. Full article
