Search Results (17)

Search Parameters:
Keywords = electrode tab

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
17 pages, 3367 KiB
Article
Removing High-Velocity Oxyfuel Coatings Through Electrolytic Dissolution
by Zdeněk Pitrmuc, Vivek Rana, Michal Slaný, Jiří Kyncl, Sunil Pathak and Libor Beránek
J. Manuf. Mater. Process. 2025, 9(2), 40; https://doi.org/10.3390/jmmp9020040 - 29 Jan 2025
Viewed by 879
Abstract
High-velocity oxyfuel (HVOF) coatings are used to protect components from corrosion and wear at higher temperatures and from wearing out after a certain period of time. Hence, to enhance the life of components, further recoating is required, but removing the older coating is [...] Read more.
High-velocity oxyfuel (HVOF) coatings are used to protect components from corrosion and wear at higher temperatures and from wearing out after a certain period of time. Hence, to enhance the life of components, further recoating is required, but removing the older coating is a challenging task due to its high hardness. Thus, this research work studied the electrolytic dissolution process of removing WC-CoCr 86/10/4 HVOF coatings and found that at a voltage of 3 V, the coating was not removed, but at a slightly higher voltage of 6 V, the coating was removed completely. When the voltage was 12 V, the surface was damaged, and corrosion also occurred. A combination of tartaric acid (C4H6O6), sodium bicarbonate (NaHCO3), and water was used as an electrolyte. By using a combination of a voltage of 4.5 V, a current of 1.6 A, and an electrode distance of 55 mm, the coating was completely removed after 10 h, with negligible attacks on the base material. Where the corrosion of the base material is unacceptable, voltages in the range of 4 to 6 V are recommended. If parts have coatings on all surfaces, a voltage within the range of 6 to 12 V can be recommended. The coating from tab SB-002JI-5 TOOLOX-11 and hexagonal mandrel SB-00EA-1 160 TIS was also removed successfully. Full article
Show Figures

Figure 1

40 pages, 6548 KiB
Review
Cell Architecture Design for Fast-Charging Lithium-Ion Batteries in Electric Vehicles
by Firoozeh Yeganehdoust, Anil Kumar Madikere Raghunatha Reddy and Karim Zaghib
Batteries 2025, 11(1), 20; https://doi.org/10.3390/batteries11010020 - 8 Jan 2025
Cited by 3 | Viewed by 5563
Abstract
This paper reviews the growing demand for and importance of fast and ultra-fast charging in lithium-ion batteries (LIBs) for electric vehicles (EVs). Fast charging is critical to improving EV performance and is crucial in reducing range concerns to make EVs more attractive to [...] Read more.
This paper reviews the growing demand for and importance of fast and ultra-fast charging in lithium-ion batteries (LIBs) for electric vehicles (EVs). Fast charging is critical to improving EV performance and is crucial in reducing range concerns to make EVs more attractive to consumers. We focused on the design aspects of fast- and ultra-fast-charging LIBs at different levels, from internal cell architecture, through cell design, to complete system integration within the vehicle chassis. This paper explores battery internal cell architecture, including how the design of electrodes, electrolytes, and other factors may impact battery performance. Then, we provide a detailed review of different cell format characteristics in cylindrical, prismatic, pouch, and blade shapes. Recent trends, technological advancements in tab design and placement, and shape factors are discussed with a focus on reducing ion transport resistance and enhancing energy density. In addition to cell-level modifications, pack and chassis design must be implemented across aspects such as safety, mechanical integrity, and thermal management. Considering the requirements and challenges of high-power charging systems, we examined how modules, packs, and the vehicle chassis should be adapted to provide fast and ultra-fast charging. In this way, we explored the potential of fast and ultra-fast charging by investigating the required modification of individual cells up to their integration into the EV system through pack and chassis design. Full article
(This article belongs to the Section Battery Modelling, Simulation, Management and Application)
Show Figures

Graphical abstract

14 pages, 12791 KiB
Article
Experimental Investigation of the Mechanical and Electrical Failure of the Electrode Tab of Lithium-Ion Pouch Cells Under Quasi-Static Mechanical Load
by Patrick Höschele, Simon Franz Heindl and Christian Ellersdorfer
Batteries 2024, 10(12), 444; https://doi.org/10.3390/batteries10120444 - 15 Dec 2024
Viewed by 1691
Abstract
The electrode tabs of pouch cells are rigidly joined to the bus bar in a battery module to achieve an electric connection. The effect of abusive mechanical loads arising from crash-related deformation or the possible movement of battery cells caused by operation-dependent thickness [...] Read more.
The electrode tabs of pouch cells are rigidly joined to the bus bar in a battery module to achieve an electric connection. The effect of abusive mechanical loads arising from crash-related deformation or the possible movement of battery cells caused by operation-dependent thickness variations has so far never been investigated. Three quasi-static abuse tests for the anode and cathode electrode tabs were conducted with pouch cells at 100% SOC. Tensile tests on the anode, cathode and pouch foil were performed in order to explain differences between the anode and cathode in the abuse tests. The experiments revealed different failure mechanisms for the anode and cathode electrode tabs. The cathode failed at an average maximum load of 940.3 N through an external rupture of the electrode tab. The anode failed at an average maximum load of 868.9 N through a rupture of the single electrode sheets and the opening of the pouch foil. No thermal runaway occurred for either cathode or anode. The results of this study reveal a more critical failure behavior for the anode electrode tab, which can be addressed in the future by adding a predetermined breaking point and adapting the geometry of the anode electrode tab. Full article
(This article belongs to the Special Issue Battery Safety: Recent Advances and Perspective)
Show Figures

Figure 1

11 pages, 3296 KiB
Article
High-Performance Supercapacitors Based on Graphene/Activated Carbon Hybrid Electrodes Prepared via Dry Processing
by Shengjun Chen, Wenrui Wang, Xinyue Zhang and Xiaofeng Wang
Batteries 2024, 10(6), 195; https://doi.org/10.3390/batteries10060195 - 3 Jun 2024
Cited by 8 | Viewed by 3179
Abstract
Graphene has a high specific surface area and high electrical conductivity, and its addition to activated carbon electrodes should theoretically significantly improve the energy storage performance of supercapacitors. Unfortunately, such an ideal outcome is seldom verified in practical commercial supercapacitor design and production. [...] Read more.
Graphene has a high specific surface area and high electrical conductivity, and its addition to activated carbon electrodes should theoretically significantly improve the energy storage performance of supercapacitors. Unfortunately, such an ideal outcome is seldom verified in practical commercial supercapacitor design and production. In this paper, the oxygen-containing functional groups in graphene/activated carbon hybrids, which are prone to induce side reactions, are removed in the material synthesis stage by a special process design, and electrodes with high densities and low internal resistances are prepared by a dry process. On this basis, a carbon-coated aluminum foil collector with a full tab structure is designed and assembled with graphene/activated carbon hybrid electrodes to form a commercial supercapacitor in cylindrical configuration. The experimental tests confirmed that such supercapacitors have high capacity density, power density, low internal resistance (about 0.06 mΩ), good high-current charging/discharging characteristics, and a long lifetime, with more than 80% capacity retention after 10 W cycles. Full article
Show Figures

Graphical abstract

29 pages, 8342 KiB
Article
Anti-Gravity 3D Pulsating Heat Pipe for Cooling Electric Vehicle Batteries
by Ji-Su Lee, Su-Jong Kim, Woo-Sung Han and Seok-Ho Rhi
Energies 2024, 17(10), 2283; https://doi.org/10.3390/en17102283 - 9 May 2024
Cited by 5 | Viewed by 2251
Abstract
This study proposes an anti-gravity 3D pulsating heat pipe (PHP) for cooling pouch batteries in electric vehicles. The 3D PHP envelops the battery cells and rapidly transfers heat generated from the batteries to the bottom cold plate. While the batteries generate heat on [...] Read more.
This study proposes an anti-gravity 3D pulsating heat pipe (PHP) for cooling pouch batteries in electric vehicles. The 3D PHP envelops the battery cells and rapidly transfers heat generated from the batteries to the bottom cold plate. While the batteries generate heat on their frontal surface during charging and discharging, structural characteristics lead to localized heat accumulation at the electrode lead tabs. Therefore, to address frontal heating, Pattern A with a consistent height for the 3D PHP and Pattern B with varying heights to enhance heat transfer in the localized heating area were designed. The target application involved creating a battery simulator for 340 × 100 mm pouch battery cells, considering the battery’s heat generation characteristics. The experiments for the thermal characteristics were conducted, considering factors such as the working fluid (methanol, Novec7100), filling ratio, supplied heat, and orientation. Additionally, to observe internal flow mechanisms, a special experimental apparatus was used, employing transparent fluorine rubber tubes to observe the flow mechanism of the 3D PHP. In the results of the thermal characteristics, the optimal filling ratio was 15% when heat generation levels of 50 W and 100 W were supplied and 20% when 150 W was supplied. The impact of orientation yielded varied results depending on the pattern and working fluid, attributed to the complex interplay of flow momentum due to orientation changes and the influence of the working fluid’s buoyancy under anti-gravity conditions. Pattern B, designed with the goal of applying a localized heat model, exhibited relatively decreased heat transfer performance in areas with varying heights. As the distance from the varying height portion increased, temperature oscillations and heat transfer became more active. These results suggest that variations in the shape of the 3D PHP could be a primary design variable for crafting localized heat models. Observations of internal flow revealed that the 3D PHP, with its unique shape and operation under anti-gravity conditions, exhibits longer and more irregular cycles compared to gravity-assist PHPs, transferring heat through rapid oscillations of internal working fluid liquid/vapor slug/plug. The potential of 3D PHPs for cooling electric vehicle batteries is suggested by these findings, and further experimentation is planned to evaluate the optimal design and applicability. Full article
Show Figures

Figure 1

11 pages, 4373 KiB
Article
First-Principles Prediction of High and Low Resistance States in Ta/h-BN/Ta Atomristor
by Lan He, Shuai Lang, Wei Zhang, Shun Song, Juan Lyu and Jian Gong
Nanomaterials 2024, 14(7), 612; https://doi.org/10.3390/nano14070612 - 30 Mar 2024
Viewed by 1635
Abstract
Two-dimensional (2D) materials have received significant attention for their potential use in next-generation electronics, particularly in nonvolatile memory and neuromorphic computing. This is due to their simple metal–insulator–metal (MIM) sandwiched structure, excellent switching performance, high-density capability, and low power consumption. In this work, [...] Read more.
Two-dimensional (2D) materials have received significant attention for their potential use in next-generation electronics, particularly in nonvolatile memory and neuromorphic computing. This is due to their simple metal–insulator–metal (MIM) sandwiched structure, excellent switching performance, high-density capability, and low power consumption. In this work, using comprehensive material simulations and device modeling, the thinnest monolayer hexagonal boron nitride (h-BN) atomristor is studied by using a MIM configuration with Ta electrodes. Our first-principles calculations predicted both a high resistance state (HRS) and a low resistance state (LRS) in this device. We observed that the presence of van der Waals (vdW) gaps between the Ta electrodes and monolayer h-BN with a boron vacancy (VB) contributes to the HRS. The combination of metal electrode contact and the adsorption of Ta atoms onto a single VB defect (TaB) can alter the interface barrier between the electrode and dielectric layer, as well as create band gap states within the band gap of monolayer h-BN. These band gap states can shorten the effective tunneling path for electron transport from the left electrode to the right electrode, resulting in an increase in the current transmission coefficient of the LRS. This resistive switching mechanism in monolayer h-BN atomristors can serve as a theoretical reference for device design and optimization, making them promising for the development of atomristor technology with ultra-high integration density and ultra-low power consumption. Full article
Show Figures

Figure 1

16 pages, 3987 KiB
Article
Online Fast Charging Model without Lithium Plating for Long-Dimensional Cells in Automotive Applications
by Yu Wang, Shuoyuan Mao, Quanwei Chen, Fei Chen, Xue Zhang, Minggao Ouyang, Xuebing Han and Yuejiu Zheng
Batteries 2023, 9(12), 563; https://doi.org/10.3390/batteries9120563 - 22 Nov 2023
Cited by 2 | Viewed by 2311
Abstract
The internal negative electrode potential in lithium-ion batteries (LIBs) is intricately linked to the lithium-ion intercalation and plating reactions occurring within the cell. With the expansion of cell sizes, the internal negative electrode potential distribution gradually becomes inconsistent. However, the existing negative electrode [...] Read more.
The internal negative electrode potential in lithium-ion batteries (LIBs) is intricately linked to the lithium-ion intercalation and plating reactions occurring within the cell. With the expansion of cell sizes, the internal negative electrode potential distribution gradually becomes inconsistent. However, the existing negative electrode potential estimation models and fast charging strategies have not yet considered the impact of consistency, and the model estimation accuracy will be greatly influenced by different temperatures and charging rates. This study proposes an online lithium-free fast charging equivalent circuit model (OLFEM) for estimating the negative electrode potential terminal voltage and developing fast charging strategies of long-dimensional LIBs in real vehicles. This study employs distributed reference electrodes integrated into long-dimensional LIBs and compares the negative electrode potential measured in the vicinity of both the negative and positive tabs. Subsequently, based on the lowest negative electrode potential point, model parameters were obtained at different temperatures and charging rates. This model is further verified under different operating conditions. Finally, a fast-charging strategy without lithium plating is developed in real-time based on the negative electrode potential estimated by the model. The results demonstrate that long-dimensional cells exhibit a lower negative electrode potential on the positive tab side. Across various temperatures and charging rates, the calibrated model achieves a negative electrode potential estimated error within 25 mV, and the estimation error for terminal voltage is within 5 mV. The proposed fast-charging method prevents lithium plating and charges the cell up to 96.8% within an hour. After 100 cycles, the cell experiences a capacity degradation of less than 2%, and the disassembly results indicate that no lithium precipitation has occurred. The methods outlined in this study provide valuable insights for online fast charging of large-dimensional batteries without lithium plating. Full article
Show Figures

Graphical abstract

16 pages, 16901 KiB
Article
Design and Implementation of Defect Detection System Based on YOLOv5-CBAM for Lead Tabs in Secondary Battery Manufacturing
by Jisang Mun, Jinyoub Kim, Yeji Do, Hayul Kim, Chegyu Lee and Jongpil Jeong
Processes 2023, 11(9), 2751; https://doi.org/10.3390/pr11092751 - 14 Sep 2023
Cited by 9 | Viewed by 2148
Abstract
According to QYResearch, a global market research firm, the global market size of secondary batteries is growing at an average annual rate of 8.1%, but fires and casualties continue to occur due to the lack of quality and reliability of secondary batteries. Therefore, [...] Read more.
According to QYResearch, a global market research firm, the global market size of secondary batteries is growing at an average annual rate of 8.1%, but fires and casualties continue to occur due to the lack of quality and reliability of secondary batteries. Therefore, improving the quality of secondary batteries is a major factor in determining a company’s competitive advantage. In particular, lead taps, which electrically connect the negative and positive electrodes of secondary batteries, are a key factor in determining the stability of the battery. Currently, the quality inspection of secondary battery lead tab manufacturers mostly consists of visual inspection after vision inspection with a rule-based algorithm, which has limitations on the types of defects that can be detected, and the inspection time is increasing due to overlapping inspections, which is directly related to productivity. Therefore, this study aims to automate the quality inspection of lead tabs of secondary batteries by applying deep-learning-based algorithms to improve inspection accuracy, improve reliability, and improve productivity. We selected the YOLOv5 model, which, among deep-learning algorithms, has a benefit for object detection, and used the YOLOv5_CBAM model, which replaces the bottleneck part in the C3 layer of YOLOv5 with the Convolutional Block Attention Module (CBAM) based on the attention mechanism, to improve the accuracy and speed of the model. As a result of applying the YOLOv5_CBAM model, we found that the parameter was reduced by more than 50% and the performance was improved by 2%. In addition, image processing was applied to help segment the defective area to apply the SPEC value for each defective object after detection. Full article
Show Figures

Figure 1

13 pages, 3656 KiB
Article
Efficient Regulation of Polysulfides by Anatase/Bronze TiO2 Heterostructure/Polypyrrole Composites for High-Performance Lithium-Sulfur Batteries
by Jing Liu, Yong Liu, Tengfei Li, Longlong Liang, Sifan Wen, Yue Zhang, Guilong Liu, Fengzhang Ren and Guangxin Wang
Molecules 2023, 28(11), 4286; https://doi.org/10.3390/molecules28114286 - 23 May 2023
Cited by 5 | Viewed by 2187
Abstract
Despite having ultra-high theoretical specific capacity and theoretical energy density, lithium-sulfur (Li-S) batteries suffer from their low Coulombic efficiency and poor lifespan, and the commercial application of Li-S batteries is seriously hampered by the severe “shuttle effect” of lithium polysulfides (LiPSs) and the [...] Read more.
Despite having ultra-high theoretical specific capacity and theoretical energy density, lithium-sulfur (Li-S) batteries suffer from their low Coulombic efficiency and poor lifespan, and the commercial application of Li-S batteries is seriously hampered by the severe “shuttle effect” of lithium polysulfides (LiPSs) and the large volume expansion ratio of the sulfur electrode during cycling. Designing functional hosts for sulfur cathodes is one of the most effective ways to immobilize the LiPSs and improve the electrochemical performance of a Li-S battery. In this work, a polypyrrole (PPy)-coated anatase/bronze TiO2 (TAB) heterostructure was successfully prepared and used as a sulfur host. Results showed that the porous TAB could physically adsorb and chemically interact with LiPSs during charging and discharging processes, inhibiting the LiPSs’ shuttle effect, and the TAB’s heterostructure and PPy conductive layer are conducive to the rapid transport of Li+ and improve the conductivity of the electrode. By benefitting from these merits, Li-S batteries with TAB@S/PPy electrodes could deliver a high initial capacity of 1250.4 mAh g−1 at 0.1 C and show an excellent cycling stability (the average capacity decay rate was 0.042% per cycle after 1000 cycles at 1 C). This work brings a new idea for the design of functional sulfur cathodes for high-performance Li-S battery. Full article
(This article belongs to the Special Issue Energy-Relevant Advanced Materials)
Show Figures

Graphical abstract

27 pages, 11759 KiB
Article
Numerical Simulation of Cooling Plate Using K-Epsilon Turbulence Model to Cool Down Large-Sized Graphite/LiFePO4 Battery at High C-Rates
by Satyam Panchal, Krishna Gudlanarva, Manh-Kien Tran, Münür Sacit Herdem, Kirti Panchal, Roydon Fraser and Michael Fowler
World Electr. Veh. J. 2022, 13(8), 138; https://doi.org/10.3390/wevj13080138 - 28 Jul 2022
Cited by 64 | Viewed by 8878
Abstract
In this paper, an analogous study of the velocity and temperature profiles inside microchannel cooling plates (with hydraulic diameter of 6 mm), placed on a large pouch-type LiFePO4 battery, is presented using both the laboratory and simulation techniques. For this, we used [...] Read more.
In this paper, an analogous study of the velocity and temperature profiles inside microchannel cooling plates (with hydraulic diameter of 6 mm), placed on a large pouch-type LiFePO4 battery, is presented using both the laboratory and simulation techniques. For this, we used reverse engineering (RE), computed tomography (CT) scanning, Detroit Engineering Products (DEP) MeshWorks 8.0 for surface meshing of the cold plate, and STAR CCM+ for steady-state simulation. The numerical study was conducted for 20 A (1C) and 40 A (2C) and different operating temperatures. For experimental work, three heat flux sensors were used and were intentionally pasted at distributed locations, out of which one was situated near the negative tab (anode) and the other was near the positive tab (cathode), because the heat production is high near electrodes and the one near the mid body. Moreover, the realizable k-ε turbulence model in STAR CCM+ is used for simulation of the stream in a microchannel cooling plate, and the computational fluid dynamics (CFD) simulations under constant current (CC) discharge load cases are studied. Later, the validation is conducted with the lab data to ensure sufficient cooling occurs for the required range of temperature. The outcome of this research work shows that as C-rates and ambient temperature increase, the temperature contours of the cooling plates also increase. Full article
(This article belongs to the Special Issue Power Train Battery Electric Vehicles (BEVs) with Range Extenders)
Show Figures

Figure 1

17 pages, 9518 KiB
Article
Optimized Nail for Penetration Test on Lithium-Ion Cells and Its Utilization for the Validation of a Multilayer Electro-Thermal Model
by Luigi Aiello, Gregor Gstrein, Simon Erker, Bernhard Kaltenegger, Christian Ellersdorfer and Wolfgang Sinz
Batteries 2022, 8(4), 32; https://doi.org/10.3390/batteries8040032 - 1 Apr 2022
Cited by 11 | Viewed by 8154
Abstract
Nail penetration is one of the most critical scenarios for a lithium-ion cell: it involves the superposition of electrical, thermal and mechanical abusive loads. When an electrically conductive nail is introduced into the active layers of a lithium-ion cell, an electric short circuit [...] Read more.
Nail penetration is one of the most critical scenarios for a lithium-ion cell: it involves the superposition of electrical, thermal and mechanical abusive loads. When an electrically conductive nail is introduced into the active layers of a lithium-ion cell, an electric short circuit takes place between the conductive components (electrodes and current collectors). Hence, for this load case, electro-thermal modeling must be performed considering each and every layer of the cell in order to predict the electric quantities and the cell temperature (with numerical models). When standard conic nails are used, as is typical for this class of tests, the electrical contact between conductive components and the nail itself suffers of poor reproducibility mainly due to the separator that interposes between the electrically conductive components. This phenomenon makes it difficult to validate electro-thermal models, since the electrical contact between nail and lithium-ion cell parts cannot be safely determined. In this work, an alternative nail with an optimized ratio between the external surface and volume is presented to overcome this issue. To demonstrate the effectiveness of the designed nail, five tests (with the same conditions) were conducted on five commercial lithium-ion pouch cells, monitoring the tabs voltage and surface temperature. In all tests, thermal runaway was reached within 30 s and the tabs voltage showed comparable behavior, indicating that the short circuit values for all five repetitions were similar. The investigation included the implementation of a detailed layers model to demonstrate how the validation of such model would be possible with the novel data. Full article
(This article belongs to the Topic Safety of Lithium-Ion Batteries)
Show Figures

Graphical abstract

14 pages, 3769 KiB
Article
Discrimination of Poor Electrode Junctions within Lithium-Ion Batteries by Ultrasonic Measurement and Deep Learning
by Young-In Hwang, Jinhyun Park, Nauman Munir, Hak-Joon Kim, Sung-Jin Song and Ki-Bok Kim
Batteries 2022, 8(3), 21; https://doi.org/10.3390/batteries8030021 - 26 Feb 2022
Cited by 8 | Viewed by 4912
Abstract
Lithium-ion batteries, which have high energy density, are the most suitable batteries for use in high-tech electromechanical applications requiring high performance. Because one of the important components that determines the efficiency of lithium-ion batteries is the electrode, the manufacturing process for this junction [...] Read more.
Lithium-ion batteries, which have high energy density, are the most suitable batteries for use in high-tech electromechanical applications requiring high performance. Because one of the important components that determines the efficiency of lithium-ion batteries is the electrode, the manufacturing process for this junction plays an important role in the entire production process. In particular, the process related to the resistance spot welding of the electrode is very important, directly affecting the safety of users, and greatly affecting the performance of the batteries. However, because the electrode tab is spot-welded onto the inner surface of the case, it is impossible to verify with visual testing (using the naked eye) whether the junction is well bonded. Therefore, it is very important to perform quality evaluation of the resistance welding of electrodes after completing the manufacturing process, using non-destructive testing methods. In this paper, a non-destructive ultrasonic testing technique was applied to examine the quality of lithium-ion batteries in which the negative electrode tabs were welded to the inner surface of the cell cans. The status of resistance spot welding between the electrode and the can was verified using deep-learning techniques with the experimentally acquired ultrasonic signal database. Full article
(This article belongs to the Special Issue Lithium-Ion Batteries: Latest Advances and Prospects II)
Show Figures

Figure 1

8 pages, 3422 KiB
Communication
Increase of Cycling Stability in Pilot-Scale 21700 Format Li-Ion Cells by Foil Tab Design
by Thomas Waldmann, Rares-George Scurtu, Daniel Brändle and Margret Wohlfahrt-Mehrens
Processes 2021, 9(11), 1908; https://doi.org/10.3390/pr9111908 - 26 Oct 2021
Cited by 10 | Viewed by 4122
Abstract
Li-ion cells of the industrially-relevant 21700 format were built on pilot-scale with tabs made from (a) the electrodes’ current collecting foils (Al and Cu, “foil tabs”) in comparison with (b) conventional tabs (Al and Ni) welded to the electrodes’ current collecting foils (“welded [...] Read more.
Li-ion cells of the industrially-relevant 21700 format were built on pilot-scale with tabs made from (a) the electrodes’ current collecting foils (Al and Cu, “foil tabs”) in comparison with (b) conventional tabs (Al and Ni) welded to the electrodes’ current collecting foils (“welded tabs”). Both cell types use the same anode (graphite), cathode (NMC622), separator, electrolyte, as well as the same tab positions. This allows a direct comparison of welded tabs and foil tabs regarding formation, C-rate capability, cell electrical resistance, and long-term cycling stability tests. Our data reproducibly shows 14.4% longer cycling stability and 11.2% increased total charge throughput in the case of the cells with foil tabs until 80% SOH, which is likely due to less inhomogeneities in the case of the foil tab design. Full article
Show Figures

Figure 1

14 pages, 2751 KiB
Article
Cell/Module Integration Technology with Wire-Embedded EVA Sheet
by Jeong Eun Park, Won Seok Choi and Donggun Lim
Appl. Sci. 2021, 11(9), 4170; https://doi.org/10.3390/app11094170 - 2 May 2021
Cited by 5 | Viewed by 2949
Abstract
Silicon wafers are crucial for determining the price of solar cell modules. To reduce the manufacturing cost of photovoltaic devices, the thicknesses of wafers are reduced. However, the conventional module manufacturing method using the tabbing process has a disadvantage in that the cell [...] Read more.
Silicon wafers are crucial for determining the price of solar cell modules. To reduce the manufacturing cost of photovoltaic devices, the thicknesses of wafers are reduced. However, the conventional module manufacturing method using the tabbing process has a disadvantage in that the cell is damaged because of the high temperature and pressure of the soldering process, which is complicated, thus increasing the process cost. Consequently, when the wafer is thinned, the breakage rate increases during the module process, resulting in a lower yield; further, the module performance decreases owing to cracks and thermal stress. To solve this problem, a module manufacturing method is proposed in which cells and wires are bonded through the lamination process. This method minimizes the thermal damage and mechanical stress applied to solar cells during the tabbing process, thereby manufacturing high-power modules. When adopting this method, the front electrode should be customized because it requires busbarless solar cells different from the existing busbar solar cells. Accordingly, the front electrode was designed using various simulation programs such as Griddler 2.5 and MathCAD, and the effect of the diameter and number of wires in contact with the front finger line of the solar cell on the module characteristics was analyzed. Consequently, the efficiency of the module manufactured with 12 wires and a wire diameter of 0.36 mm exhibited the highest efficiency at 20.28%. This is because even if the optical loss increases with the diameter of the wire, the series resistance considerably decreases rather than the loss of the short-circuit current, thereby improving the fill factor. The characteristics of the wire-embedded ethylene vinyl acetate (EVA) sheet module were confirmed to be better than those of the five busbar tabbing modules manufactured by the tabbing process; further, a high-power module that sufficiently compensated for the disadvantages of the tabbing module was manufactured. Full article
(This article belongs to the Section Energy Science and Technology)
Show Figures

Figure 1

12 pages, 3252 KiB
Article
Potentiometric Study of Carbon Nanotube/Surfactant Interactions by Ion-Selective Electrodes. Driving Forces in the Adsorption and Dispersion Processes
by Francisco José Ostos, José Antonio Lebrón, María Luisa Moyá, Eva Bernal, Ana Flores, Cristian Lépori, Ángeles Maestre, Francisco Sánchez, Pilar López-Cornejo and Manuel López-López
Int. J. Mol. Sci. 2021, 22(2), 826; https://doi.org/10.3390/ijms22020826 - 15 Jan 2021
Cited by 14 | Viewed by 4964
Abstract
The interaction (adsorption process) of commercial ionic surfactants with non-functionalized and functionalized carbon nanotubes (CNTs) has been studied by potentiometric measurements based on the use of ion-selective electrodes. The goal of this work was to investigate the role of the CNTs’ charge and [...] Read more.
The interaction (adsorption process) of commercial ionic surfactants with non-functionalized and functionalized carbon nanotubes (CNTs) has been studied by potentiometric measurements based on the use of ion-selective electrodes. The goal of this work was to investigate the role of the CNTs’ charge and structure in the CNT/surfactant interactions. Non-functionalized single- (SWCNT) and multi-walled carbon nanotubes (MWCNT), and amine functionalized SWCNT were used. The influence of the surfactant architecture on the CNT/surfactant interactions was also studied. Surfactants with different charge and hydrophobic tail length (sodium dodecyl sulfate (SDS), octyltrimethyl ammonium bromide (OTAB), dodecyltrimethyl ammonium bromide (DoTAB) and hexadecyltrimethyl ammonium bromide (CTAB)) were studied. According to the results, the adsorption process shows a cooperative character, with the hydrophobic interaction contribution playing a key role. This is made evident by the correlation between the free surfactant concentration (at a fixed [CNT]) and the critical micellar concentration, cmc, found for all the CNTs and surfactants investigated. The electrostatic interactions mainly determine the CNT dispersion, although hydrophobic interactions also contribute to this process. Full article
(This article belongs to the Special Issue Ordered Mesoporous Materials)
Show Figures

Graphical abstract
