Achieving high-precision clamping force control is crucial for Electro-Mechanical Braking (EMB) systems but remains challenging due to significant nonlinear friction (e.g., static, Coulomb, and viscous friction) within the transmission mechanism. To address this, a comprehensive model integrating the electrical and mechanical dynamics of the EMB actuator is first established. This pressure-oriented model, which explicitly accounts for the nonlinear frictions, is developed and validated in MATLAB/Simulink 2022b. Furthermore, physical experiments under typical braking scenarios are conducted to investigate the system’s friction characteristics, leading to the identification of a displacement–pressure load curve for the actuator. This curve serves as a key reference for braking force observation. Finally, a braking force observer-based controller is designed, implemented via an Auto-Disturbance Rejection Control (ADRC) algorithm. Experimental results from step and sinusoidal braking force tests demonstrate that the proposed controller not only effectively compensates for nonlinear disturbances but also achieves robust and stable clamping force control. Full article

The chemistry of the pore fluid within clayey sediments frequently changes in various processes. However, the impacts of pore fluid chemistry have not been well included in the hydraulic permeability model, and the physical bases behind the salinity sensitivity of the hydraulic permeability remains elusive. In this study, a theoretical model for the hydraulic permeability of clayey sediments is proposed, and impacts of the pore fluid chemistry are quantitatively considered by introducing electrokinetic flow theory. Available experimental data were used to verify the theoretical model, and the verified model was further applied as a sensitivity analysis tool to explore more deeply how hydraulic permeability depends on pore fluid chemistry under different conditions. Coupling effects of pore water desalination and the effective stress enhancement on the hydraulic permeability of marine sediments surrounding a depressurization wellbore during hydrate production are discussed. Results and discussion show that the hydraulic permeability reduction is significant only when the electric double layer thickness is comparable to the characteristic pore size, and the reduction becomes more obvious when the ion mobility of the saline solution is smaller and the surface dielectric potential of clay minerals is lower. During gas hydrate production in the ocean, the salinity sensitivity of the hydraulic permeability could become either stronger and weaker, depending on whether the original characteristic pore size of marine sediments is relatively large or small. Full article

Carbonate muds are essential sedimentary components in geological carbon cycles. Model carbonate muds are prepared from crushed, sieved carbonate rock. The carbonate rock particles are primarily smaller than 62.5 µm. Steady-state shear viscosity was measured for model carbonate muds prepared from three types of carbonate rock: limestone Grey, limestone Marl, and limestone Castleton. Model carbonate muds were prepared using fresh water or 3.5 g/L NaCl solution. The carbonate particle concentrations were 1.81 volume percent and 26.95 volume percent, representing semi-dilute and concentrated particle regimes, respectively. Carbonate mud viscosity was measured at temperatures ranging from 8 °C to 35 °C. Shear rates ranged from 60 s⁻¹ to 2500 s⁻¹. Pseudoplasticity occurs at low shear rates and is caused by the release of occluded water during shear-driven breakup and dispersal of particle aggregates. Shear thickening occurs at high shear rates and is caused by transient particle clusters, called hydroclusters, that are reinforced by lubrication forces or frictional particle contacts. Carbonate mud viscosity decreases at increasing temperatures. The presence of 3.5 g/L NaCl in the aqueous phase slightly increased the mud viscosity in the semi-dilute particle concentration regime because of a weak viscosifying effect of NaCl on the aqueous phase. In the concentrated particle regime, electrolytes screened electroviscous effects, reducing the viscosity of muds containing particles with electrically charged surfaces. In aqueous solution, limestone Marl had a comparatively high concentration of charged particles on its surface. Limestone Castleton had a comparatively low concentration of charged particles on its surface. Surface charges were not rheologically evident on limestone Grey. Full article

Since droplet collision with walls has become a research hotspot, scholars have conducted a large number of studies on the dynamic behavior of electrically neutral droplets colliding with dry walls. However, with the rapid development of electrostatic spray technology, there is an increasingly urgent need to study the dynamic process of collision between charged droplets and walls. In this paper, considering the actual working conditions of electrostatic spray, an electric field model is introduced based on the two-phase flow field. Through the coupling of a multiphase flow field and electric field and a multiphysics field, the dynamic numerical calculation method is used to explore the collision electrodynamic behavior of charged droplets and liquid film. The dynamic evolution process of the formation and development of the liquid crown in the collision zone was clarified, and the critical velocity and critical Weber number of the rebound, spreading, and splashing of charged droplets were tracked. The distribution characteristics of electrostatic field, pressure field, and velocity field under different working conditions are analyzed, and the dynamic mechanism of the charged droplet collision liquid film under multi-physics coupling is revealed based on the electro-viscous effect. It is confirmed that the external electric field can increase the critical velocity of droplet splashing and fragmentation and promote the spreading and fusion behavior of droplets and liquid films. The influence of the impact angle of charged droplets on the collision behavior was further explored. It was found that the charged droplets not only have a smaller critical angle for fragmentation and splashing, but also have a faster settling and fusion speed. Full article

Electrostatic atomization minimum quantity lubrication (EMQL) technology has been developed to address the need for environmentally friendly, efficient, and low-damage grinding of challenging titanium alloy materials. EMQL leverages multiple physical fields to achieve precise atomization of micro-lubricants, enabling effective lubrication in high temperature, high pressure, and high-speed grinding environments through the use of electric traction. Notably, the applied electric field not only enhances atomization and lubrication capabilities of micro-lubricants but also significantly impacts heat transfer within the grinding zone. In order to explore the influence mechanism of external electric field on spatial heat transfer, this paper first comparatively analyzes the grinding heat under dry grinding, MQL, and EMQL conditions and explores the intensity of the effect of external electric field on the heat transfer behavior in the grinding zone. Furthermore, the COMSOL numerical calculation platform was used to establish an electric field-enhanced (EHD) heat transfer model, clarifying charged particles’ migration rules between poles. By considering the electroviscous effect, the study reveals the evolution of heat transfer structures in the presence of an electric field and its impact on heat transfer mechanisms. Full article

The present investigation analyzes the transient multilayer electro-osmotic flow through an annular microchannel with hydrophobic walls. The fluids are considered immiscible and viscoelastic, following the Maxwell rheological model. In the problem examined, the linearized Poisson–Boltzmann and Cauchy momentum equations are used to determine the electric potential distribution and the flow field, respectively. Here, different interfacial phenomena are studied through the imposed boundary conditions, such as the hydrodynamic slip and specified zeta potentials at solid–liquid interfaces, the velocity continuity, the electroviscous stresses balance, the potential difference, and the continuity of electrical displacements at the interfaces between fluids. The semi-analytic solution uses the Laplace transform theory. In the results, the velocity profiles and velocity tracking show the oscillatory behavior of flow, which strongly depends on the dimensionless relaxation time. Furthermore, the hydrodynamic slip on the channel walls contributes to the release of energy stored in the fluids due to elastic effects at the start-up of the flow. Similarly, other dimensionless parameters are also investigated. This research aims to predict the parallel flow behavior in microfluidic devices under electro-osmotic effects. Full article

The present work is a numerical analysis of electro-thermo convection, occurring in a square differentially heated cavity filled with a dielectric fluid. The cavity experiences the combined effects of viscous, electrical, and thermal forces. The equations modelling the physical problem are solved via the finite volume approach. The study focuses on the effect of cavity tilt on the fluid flow structure and thermal performance inside the enclosure under the action of an electric field. A parametric study was performed, where the tilt angle is getting varied between 0° and 90°, as well as the Rayleigh number (5000 ≤ Ra ≤ 250,000) and the electric field (0 ≤ T ≤ 800). Furthermore, the electric charge injection level C, the mobility M and the Prandtl Pr numbers were all adjusted to a value of 10. The obtained results demonstrate that the hydrodynamic and thermal fields are significantly impacted by the cavity inclination. In addition, regardless of the thermal Rayleigh’s number, high electric field values could govern fluid movement through electric forces. Electro-convection typically demonstrates an oscillating flow due to the tilting of the cavity which gives rise to a bicellular regime occupying the entire cavity. A correlation has been established to estimate heat transfer by considering various system parameters such as cavity inclination, electrical Rayleigh number, and thermal Rayleigh number. Full article

Despite the recycling challenges in ionic fluids, they have a significant advantage over traditional solvents. Ionic liquids make it easier to separate the end product and recycle old catalysts, particularly when the reaction media is a two-phase system. In the current analysis, the properties of transient, electroviscous, ternary hybrid nanofluid flow through squeezing parallel infinite plates is reported. The ternary hybrid nanofluid is synthesized by dissolving the titanium dioxide (TiO₂), aluminum oxide (Al₂O₃), and silicon dioxide (SiO₂) nanoparticles in the carrier fluid glycol/water. The purpose of the current study is to maximize the energy and mass transfer rate for industrial and engineering applications. The phenomena of fluid flow is studied, with the additional effects of the magnetic field, heat absorption/generation, chemical reaction, and activation energy. The ternary hybrid nanofluid flow is modeled in the form of a system of partial differential equations, which are subsequently simplified to a set of ordinary differential equations through resemblance substitution. The obtained nonlinear set of dimensionless ordinary differential equations is further solved, via the parametric continuation method. For validity purposes, the outcomes are statistically compared to an existing study. The results are physically illustrated through figures and tables. It is noticed that the mass transfer rate accelerates with the rising values of Lewis number, activation energy, and chemical reaction. The velocity and energy transfer rate boost the addition of ternary NPs to the base fluid. Full article

This article, investigates the behaviour of an ionized nanoliquid motion regarding heat transmission between two parallel discs. In the proposed model, the squeezing flow of Cu-water nanofluid with electrical potential force is analysed for studying the flow properties and an uniform magnetic field is applied to that fluid, by taking the surface of the bottom disc porous. We have also studied the effects of different nanomaterials on the transmission of heat through nanofluids. Furthermore, the influence of various physical parameters in the proposed model of nanofluids flow like volume fraction of nanomaterials, squeezing number, Hartmann number, Eckert number, and Prandtl number are analysed and discussed quantitatively through various tables and graphs. The system of nonlinear partial differential equations (PDE’s) has been used to formulate the proposed flow model and later converted to a set of nonlinear ODE’s by mean similarity transformation. Further, the reduced form of ODEs has been solved by Parametric Continuation Method (PCM), which is a stable numerical scheme. The outcomes obtained from the proposed model could also be used to analyse nanofluid flow in several fields, such as polymer processing, power transfer and hydraulic lifts. Full article

In this article, the behavior of transient electroviscous fluid flow is investigated through squeezing plates containing hybrid nanoparticles. A hybrid nanofluid ${\mathrm{MoS}}_2+\mathrm{Au}$/${\mathrm{C}}_2{\mathrm{H}}_6{\mathrm{O}}_2-{\mathrm{H}}_2\mathrm{O}$ was formulated by dissolving the components of an inorganic substance such as molybdenum disulfide $\left({\mathrm{MoS}}_2\right)$ and gold (Au) in a base fluid of ethylene glycol/water. This hybrid non-liquid flow was modeled by various nonlinear mathematical fluid flow models and subsequently solved by numerical as well as analytical methods. For the numerical solution of nonlinear ODEs, a built-in function BVP4C was used in MATLAB, and the same problem was solved in MATHEMATICA by HAM. The result of the present problem related to the results obtained from the existing literature under certain conditions. The outcomes revealed that the concentration profiles were more sensitive to homogeneity diversity parameters. The simulation of the various physical parameters of the model indicated that the heat transfer through a mixture of hybrid nanofluids was greater than a simple nanofluid. In addition, the phenomenon of mixed convection was considered to improve the velocity of simple nanofluids and hybrid nanofluids, when both cases have low permeability. A rise in the volume fraction of the nanomaterials, $\Phi$, was associated with an increase in the heat transfer rate. It was observed that the heat transfer rate of the hybrid nanofluids ${\mathrm{MoS}}_2+{\mathrm{Au}/\mathrm{C}}_2{\mathrm{H}}_6{\mathrm{O}}_2-{\mathrm{H}}_2\mathrm{O}$ was higher than that of the single nanofluids ${\mathrm{MoS}}_2/{\mathrm{C}}_2{\mathrm{H}}_6{\mathrm{O}}_2-{\mathrm{H}}_2\mathrm{O}$. Full article

In this study, an investigation has been carried out to analyze the impact of electro-osmotic effects on the Darcy–Forchheimer flow of Casson nanofluid past a stretching sheet. The energy equation was modelled with the inclusion of electro-osmotic effects with viscous and Joule dissipations. The governing system of partial differential equations were transformed by using the suitable similarity transformations to a system of ordinary differential equations and then numerically solved by using the Runge–Kutta–Fehlberg method with a shooting scheme. The effects of various parameters of interest on dimensionless velocity and temperature distributions, as well as skin friction and heat transfer coefficient, have been adequately delineated via graphs and tables. A comparison with previous published results was performed, and good agreement was found. The results suggested that the electric and Forchheimer parameters have the tendency to enhance the fluid velocity as well as momentum boundary layer thickness. Enhancements in temperature distribution were observed for growing values of Eckert number. It was also observed that higher values of electric field parameter diminished the wall shear stress and local Nusselt number. Full article

Flowing through porous media is a matter of interest in different research fields such as medicine, engineering and science. The spontaneous appearance of ionic distribution at the solid liquid interface gives place to a reduction in the flow rate, which is generally named electroviscous effect. However, this should be differentiated in two more specific effects, the primary effect due to the distortion of ionic clouds, and the secondary effect due to the overlapping of ionic clouds. Theoretical and experimental works have not always been clearly conducted in order to separate both effects. Instead, they have been globally grouped. The purpose of this review is to revise theoretical and experimental bibliography on the electroviscous effect in stationary solid phase suspensions (porous plugs, membranes, microchannels, capillaries). The main conclusions of this brief revision are: (i) when ionic clouds are relatively small, it is possible to accept that only the primary effect is the cause for the apparent increase of the viscosity of the liquid phase when it is forced to flow relative to the stationary solid phase; (ii) although theory predicts a maximum for the variation of the overall electroviscous effect vs the relative size of the ionic cloud, it has been experimentally observed but not properly reasoned that its existence depends on the salt type; and (iii) it is necessary to justify why, if the fluid is non-Newtonian, electrokinetic parameters dominate the characteristics of the flow due to high pressure gradients, but the rheological parameters are more decisive when the flow is generated by low pressure gradients. Full article

Investigation of electroviscous effects is of interest to technologies that exploit transport of ions through ion exchange membranes, charged capillaries, and porous media. When ions move through such media due to a hydrostatic pressure difference, they interact with the fixed charges, leading to an increased hydraulic resistance. Experimentally this is observed as an apparent increase in the viscosity of the solution. Electroviscous effects are present in all electrochemical membrane-based processes ranging from nanofiltration to fuel-cells and redox flow batteries. Direct measurements of electroviscous effects varying the applied ionic current through Nafion membranes have, to the best of the authors’ knowledge, not yet been reported in literature. In the current study, electroviscous phenomena in different Nafion ion exchange membranes are measured directly with a method where the volume permeation is measured under constant trans-membrane pressure difference while varying the ion current density in the membrane. The direct measurement of the electroviscous effect is compared to the one calculated from the phenomenological transport equations and measured transport coefficients. Within the experimental uncertainty, there is a good agreement between the two values for all membranes tested. We report here an electroviscous effect for all Nafion membranes tested to be ${\kappa }_{\mathrm{H}}^{★}{\kappa }_{\mathrm{H}}^{-1}={1.15}_{-0.052}^{+0.035}$. Full article

The electro-hydrostatic actuator (EHA) is one of the most prevalent types of power-by-wire (PBW) actuation systems. With the increase in EHA power density, using the pump’s leakage oil to cool the motor has been gradually adopted to solve the problem of excessive motor temperature. However, the viscous friction loss caused by the liquid viscosity will seriously affect the heat dissipation effect and dynamic performance of the motor. To calculate the motor viscosity loss accurately, a novel calculation method is proposed in this paper. Using the energy gradient theory, the relationship between the fluid flow state and the rotation speed is analyzed. In addition, the lumped parameter model of viscous loss is established by using the conservation of momentum theory and computational fluid dynamics (CFD) simulation. A test rig is designed to test the viscous friction loss for various rotation speeds, and the test results show a good agreement with the theoretical analysis. The present results demonstrate the effectiveness of the lumped parameter model and provide a better calculation method for wet motor viscosity loss calculation. Full article

This article is concerned with the nanofluid flow in a rotating frame under the simultaneous effects of thermal slip and convective boundary conditions. Arrhenius activation energy is another important aspect of the present study. Flow phenomena solely rely on the Darcy–Forchheimer-type porous medium in three-dimensional space to tackle the symmetric behavior of viscous terms. The stretching sheet is assumed to drive the fluid. Buongiorno’s model is adopted to see the features of Brownian diffusion and thermophoresis on the basis of symmetry fundamentals. Governing equations are modeled and transformed into ordinary differential equations by suitable transformations. Solutions are obtained through the numerical RK45-scheme, reporting the important findings graphically. The outputs indicate that larger values of stretching reduce the fluid velocity. Both the axial and transverse velocity fields undergo much decline due to strong retardation produced by the Forchheimer number. The thermal radiation parameter greatly raises the thermal state of the field. The temperature field rises for a stronger reaction within the fluid flow, however reducing for an intensive quantity of activation energy. A declination in the concentration profile is noticed for stronger thermophoresis. The Forchheimer number and porosity factors result in the enhancement of the skin friction, while both slip parameters result in a decline of skin friction. The thermal slip factor results in decreasing both the heat and mass flux rates. The study is important in various industrial applications of nanofluids including the electro-chemical industry, the polymer industry, geophysical setups, geothermal setups, catalytic reactors, and many others. Full article
