Search Results (44)

The increasing adoption of Light Electric Vehicles (LEVs) in urban areas, driven by the micromobility wave, raises significant safety concerns, particularly regarding battery fire incidents. This research investigates the electromechanical performance of aged 18650 lithium-ion batteries (LIBs) from LEVs under mechanical impact conditions. For this study, a battery module from a used e-scooter was disassembled, and its constituent cells were reconfigured into compact modules for testing. To characterize their initial condition, the cells underwent cycling tests to evaluate their state of health (SOH). Although a slight majority of the cells retained an SOH greater than 80%, a notable increase in their internal resistance (IR) was also observed, indicating degradation due to aging. The mechanical impact tests were conducted in adherence to the UL 2271:2018 standard, employing a semi-sinusoidal acceleration pulse. During these tests, linear kinematics were analyzed using videogrammetry, while key electrical and thermal parameters were monitored. Additionally, strain gauges were installed on the central cells to measure stress and deformation. The results from the mechanical shock tests revealed characteristic acceleration and velocity patterns. These findings clarify the electromechanical behavior of aged LIBs under impact, providing critical data to enhance the safety and reliability of these vehicles. Full article

In the case of strengthening building structures, the process usually involves elements that have a certain loading history and are typically subjected to loading during the strengthening process. In scientific research, on the other hand, strengthening is usually applied to elements that are not representative of real structures. This article presents a study of the effect of pre-damage on the behavior of eccentrically compressed concrete cylinders confined with PBO-FRCM (fabric-reinforced cementitious matrix with PBO fibers) composite. Concrete confinement introduces a favorable triaxial stress state, which leads to an increase in the compressive strength of concrete. FRCM systems are an alternative to FRP (fiber-reinforced polymer) composites. Replacing the polymer matrix with a mineral matrix primarily improves the fire resistance of the strengthening system. The elements were made of concrete with a compressive strength of about 40 MPa, which is typical for current reinforced concrete columns. Pre-damage was induced by loading the test elements to 80% of the average compressive strength and then fully unloading. The elements were then strengthened with three layers of PBO-FRCM composite and subjected to axial or eccentric compression with force applied at two different eccentricities. In addition to electric strain gauges, a digital image correlation system was used for measurements, to identify the initiation of PBO mesh overlap delamination. This study analyzed the elements in terms of load-bearing capacity, deformability, ductility, and failure mechanisms. In general, there was no negative effect of pre-damage on the behavior of the tested elements. Full article

Strain gauges and strain gauge transducers are important tools in the field of material resistance research to measure the stresses and strains in solids. These methods and devices have a wide range of applications, from construction to mechanical engineering, where the mechanical properties of materials need to be monitored and optimized. The use of nanomaterials in strain gauges allows for more sensitive and compact sensors. Nanotechnology makes it possible to create strain gauges with improved mechanical and electrical properties. At the same time, nanomaterials have unique properties that make them ideal for use in strain gauges. This paper considers different types of composites based on polymer matrices with additives of dispersed nanomaterials, which are designed for strain gauge tasks. Thermoplastics and elastomers can be used as polymer matrices. Dispersed fillers can be based on MXene and nanomaterials such as carbon nanotubes, graphene, metals, etc. Despite the obvious advantages of strain gauges based on conducting polymers modified with dispersed structures, there are problems in creating effective strain gauges with the ability to operate under large deformations with an improved sensitivity and accuracy of measurements in a wide range. This article also provides brief information on the technical evolution of strain gauges, from wire and foil to polymer nanocomposites. A modern classification of strain gauges is provided. The disadvantages and advantages of existing strain gauges are shown. The review contains information on commercial strain gauges. The mechanisms of electrical conductivity formation in polymer composites for strain gauges are described in detail. The areas of application of polymer nanocomposite strain gauges are also specified in detail. The purpose of this review study is to determine the prospects for the use of various nanomaterials as additives in polymers to create strain gauges. The review is aimed at a wide range of readers. Full article

The paper presents a review of CNTs synthesis methods and their application as a functional filler to obtain polymer composites for various technical purposes for strain gauges, electrical heating, anti-static coatings, electrically conductive compounds, etc. Various synthesis methods allow CNTs with different morphology and structural properties to be created, which expands the possibilities of the application of such nanoscale structures. Polymers can provide such effects as ‘shape memory’ and self-repair of mechanical defects. Different combinations of polymers and dispersed fillers influence the change in electrical and thermal conductivity, as well as the positive temperature coefficient of resistance, which makes it possible to achieve the effect of temperature self-regulation during electrical heating. CNTs make it possible to form PTCR (positive temperature coefficient of resistance) in elastomers at lower concentrations, which makes it possible to preserve mechanical strength and use more efficient modes of heat generation. For strain gauges, CNTs improve sensitivity to mechanical effects and extend the measurement range. The use of thermoplastic elastomers provides the temperature of PTCR operation for electric heating at the level of 200 °C (voltage 240 V), which allows such heaters to operate at a power supply from a household electrical network. CNTs-based strain gauges can provide structural condition monitoring of composite materials. Full article

Water-stable proteins may offer a new field of applications in smart materials for buildings and infrastructures where hydraulic reactions are involved. In this study, cement mortars modified through water-soluble silk fibroin (SF) are proposed. Water-soluble SF obtained by redissolving SF films in phosphate buffer solution (PBS) showed the formation of a gel with the $\beta$ sheet features of silk II. Electrical measurements of SF indicate that calcium ions are primarily involved in the conductivity mechanism. By exploiting the water solubility properties of silk II and Ca²⁺ ion transport phenomena as well as their trapping effect on water molecules, SF provides piezoresistive and piezocapacitive properties to cement mortars, thus enabling self-sensing of mechanical strain, which is quite attractive in structural health monitoring applications. The SF/cement-based composite introduces a capacitive gauge factor which surpasses the traditional resistive gauge factor reported in the literature by threefold. Cyclic voltammetry measurements demonstrated that the SF/cement mortars possessed memcapacitive behavior for positive potentials near +5 V, which was attributed to an interfacial charge build-up modulated by the SF concentration and the working electrode. Electrical square-biphasic excitation combined with cyclic compressive loads revealed memristive behavior during the unloading stages. These findings, along with the availability and sustainability of SF, pave the way for the design of novel multifunctional materials, particularly for applications in masonry and concrete structures. Full article

This study explores a novel approach to obtaining 3D printed strain sensors, focusing on how changing the printing conditions can produce a different piezoresistive response. Acrylonitrile butadiene styrene (ABS) filled with different weight concentrations of carbon nanotubes (CNTs) was printed in the form of dog bones via fused filament fabrication (FFF) using two different raster angles (0–90°). Scanning electron microscopy (SEM) and atomic force microscopy (AFM) in TUNA mode (TUNA-AFM) were used to study the morphological features and the electrical properties of the 3D printed samples. Tensile tests revealed that sensitivity, measured by the gauge factor (G.F.), decreased with increasing filler content for both raster angles. Notably, the 90° orientation consistently showed higher sensitivity than the 0° orientation for the same filler concentration. Creep and fatigue tests identified permanent damage through residual electrical resistance values. Additionally, a cross-shaped sensor was designed to measure two-dimensional deformations simultaneously, which is applicable in the robotic field. This sensor can monitor small and large deformations in perpendicular directions by tracking electrical resistance variations in its arms, significantly expanding its measuring range. Full article

Conductive polymer composites are commonly present in flexible electrodes for neural interfaces, implantable sensors, and aerospace applications. Fused filament fabrication (FFF) is a widely used additive manufacturing technology, where conductive filaments frequently contain carbon-based fillers. In this study, the static and dynamic mechanical properties and the electrical properties (resistance, signal transmission, resistance measurements during cyclic tensile, bending and temperature tests) were investigated for polylactic acid (PLA)-based, acrylonitrile butadiene styrene (ABS)-based, thermoplastic polyurethane (TPU)-based, and polyamide (PA)-based conductive filaments with carbon-based additives. Scanning electron microscopy (SEM) was implemented to evaluate the results. Cytotoxicity measurements were performed. The conductive ABS specimens have a high gauge factor between 0.2% and 1.0% strain. All tested materials, except the PA-based conductive composite, are suitable for low-voltage applications such as 3D-printed EEG and EMG sensors. ABS-based and TPU-based conductive composites are promising raw materials suitable for temperature measuring and medical applications. Full article

This paper presents a recent investigation into the electromechanical behavior of thermally reduced graphene oxide (rGO) as a strain sensor undergoing repeated large mechanical strains up to 20.72%, with electrical signal output measurement in multiple directions relative to the applied strain. Strain is one the most basic and most common stimuli sensed. rGO can be synthesized from abundant materials, can survive exposure to large strains (up to 20.72%), can be synthesized directly on structures with relative ease, and provides high sensitivity, with gauge factors up to 200 regularly reported. In this investigation, a suspension of graphene oxide flakes was deposited onto Polydimethylsiloxane (PDMS) substrates and thermally reduced to create macroscopic rGO-strain sensors. Electrical resistance parallel to the direction of applied tension ($\widehat{x}$) demonstrated linear behavior (similar to the piezoresistive behavior of solid materials under strain) up to strains around 7.5%, beyond which nonlinear resistive behavior (similar to percolative electrical behavior) was observed. Cyclic tensile testing results suggested that some residual micro-cracks remained in place after relaxation from the first cycle of tensile loading. A linear fit across the range of strains investigated produced a gauge factor of 91.50(Ω/Ω)/(m/m), though it was observed that the behavior at high strains was clearly nonlinear. Hysteresis testing showed high consistency in the electromechanical response of the sensor between loading and unloading within cycles as well as increased consistency in the pattern of the response between different cycles starting from cycle 2. Full article

Photoelectric dual-mode sensors, which respond to strain signal through photoelectric dual-signals, hold great promise as wearable sensors in human motion monitoring. In this work, a photoelectric dual-mode sensor based on photonic crystals hydrogel was developed for human joint motion detection. The optical signal of the sensor originated from the structural color of photonic crystals, which was achieved by tuning the polymethyl methacrylate (PMMA) microspheres diameter. The reflective peak of the sensor, based on 250 nm PMMA PCs, shifted from 623 nm to 492 nm with 100% strain. Graphene was employed to enhance the electrical signal of the sensor, resulting in a conductivity increase from 9.33 × 10⁻⁴ S/m to 2 × 10⁻³ S/m with an increase in graphene from 0 to 8 mg·mL⁻¹. Concurrently, the resistance of the hydrogel with 8 mg·mL⁻¹ graphene increased from 160 kΩ to 485 kΩ with a gauge factor (GF) = 0.02 under 100% strain, while maintaining a good cyclic stability. The results of the sensing and monitoring of finger joint bending revealed a significant shift in the reflective peak of the photoelectric dual-mode sensor from 624 nm to 526 nm. Additionally, its resistance change rate was measured at 1.72 with a 90° bending angle. These findings suggest that the photoelectric dual-mode sensor had the capability to detect the strain signal with photoelectric dual-mode signals, and indicates its great potential for the sensing and monitoring of joint motion. Full article

The article presents the results of a determination of the load attributed to rail vehicles transported by a ferry, considering the influence of sea waves on its hull. A mathematic model describing the displacements of a train ferry, which transported rail vehicles on its decks during rolling oscillations, was created. Calculated accelerations were used to identify the load of components from a dynamics point of view and they were subsequently applied as an input to the analysis of the strength of the open wagon main-bearing structure in a standard scheme of interaction with a train ferry deck. The calculated maximal equivalent stresses in the structure of the fastening units exceeded the valid permissible values. To confirm the theoretical results, experimental studies focused on the strength analysis of the open wagon placed on the railway ferry deck, which was performed in real operational conditions. Electrical voltage sensors were used to determine stress distribution in the areas where the body was attached to the deck. In this case, sensors of the strain gauges, i.e., tensiometers, were used. The base of 25 mm is a dimensional parameter and the resistance, 124 Ohms, is the tensiometer parameter. Verification has been performed and, based on the obtained experimental results, it has been established that the hypothesis’ adequacy is not rejected. The authors developed some measures for adaption of the lashing devices for rail cars on train ferries, which can ensure their safe transportation by sea. The strength calculation demonstrated that, in the new scheme of securing the transported railway vehicles on the railway train ferry, the stresses in its structure do not exceed the permissible values. The article also includes information about the results of the strength calculation of a container placed on a roll trailer transported by a train ferry. This research will contribute to the development of measures regarding the safety of railway vehicle transportation by sea ferry and better efficiency of train ferry transportation. Full article

Robotic systems and the human body consist of numerous joint structures, all of which require precise angle adjustments. At present, encoder, strain gauge, and electrical resistance-based sensors are commonly used for angle measurement. However, these sensors have limitations when used in underwater or in environments with strong electromagnetic waves. Therefore, we have developed an angle sensor based on step-index profile plastic optical fiber (SI-POF), which is cost-effective and highly durable, in this study in order to overcome the limitations of existing angle measurement sensors. To this end, the amount of light loss according to the gab and angle changes that occur when the POF angle sensor is applied to the robot arm was experimentally measured, and based on the results, a simulation of the amount of light loss when the two losses occurred at the same time was conducted. In addition, the performance of the POF angle sensor was evaluated by measuring sensitivity and resolution, and comparative verification with a commonly used encoder was conducted to verify the reliability of sensors in extreme environments, such as those with electromagnetic fields and those that are underwater. Through this, the reliability and practicality of the POF angle sensor were confirmed. The results obtained in this study suggest that POF-based angle sensors can contribute to the development of the biomimetic robot industry as well as ordinary robots, especially in environments where existing sensors are difficult to apply, such as areas with underwater or electromagnetic interference (EMI). Full article

Strain sensors play a pivotal role in quantifying stress and strain across diverse domains, encompassing engineering, industry, and medicine. Their applicability has recently extended into the realm of wearable electronics, enabling real-time monitoring of body movements. However, conventional strain sensors, while extensively employed, grapple with limitations such as diminished sensitivity, suboptimal tensile strength, and susceptibility to environmental factors. In contrast, polymer-based composite strain sensors have gained prominence for their capability to surmount these challenges. The integration of carbon nanotubes (CNTs) as reinforcing agents within the polymer matrix ushers in a transformative era, bolstering mechanical strength, electrical conductivity, and thermal stability. This study comprises three primary components: simulation, synthesis of nanocomposites for strain sensor fabrication, and preparation of a comprehensive measurement set for testing purposes. The fabricated strain sensors, incorporating a robust polymer matrix of polyaniline known for its exceptional conductivity and reinforced with carbon nanotubes as strengthening agents, demonstrate good characteristics, including a high gauge factor, stability, and low hysteresis. Moreover, they exhibit high strain sensitivity and show linearity in resistance changes concerning applied strain. Comparative analysis reveals that the resulting gauge factors for composite strain sensors consisting of carbon nanotubes/polyaniline and carbon nanotubes/polyaniline/silicone rubber are 144.5 and 167.94, respectively. Full article

Fiber Bragg grating (FBG) sensor has a lot of advantages over the resistance strain gauge and has been used in many applications. However, there are few applications of rotor blade dynamic measurement in helicopter flight. In this paper, a method for blade dynamic strain measurement using an FBG sensor in a helicopter’s real flight is presented. The corresponding measurement system is established and can eliminate the effects of the helicopter’s electromagnetic environment on the electrical sensing components in the measurement system with the orthogonal frequency-division multiplexing modulation. The measured dynamic strains on the rotor blades of the helicopter in real flight contain six harmonic frequencies with the vibration characteristics of rotor blades, indicating that the established FBG measurement method and system have practical engineering applications. Full article

Elastic strain sensor nanocomposites are emerging materials of high scientific and commercial interest. This study analyzes the major factors influencing the electrical behavior of elastic strain sensor nanocomposites. The sensor mechanisms were described for nanocomposites with conductive nanofillers, either dispersed inside the polymer matrix or coated onto the polymer surface. The purely geometrical contributions to the change in resistance were also assessed. The theoretical predictions indicated that maximum Gauge values are achieved for mixture composites with filler fractions slightly above the electrical percolation threshold, especially for nanocomposites with a very rapid conductivity increase around the threshold. PDMS/CB and PDMS/CNT mixture nanocomposites with 0–5.5 vol.% fillers were therefore manufactured and analyzed with resistivity measurements. In agreement with the predictions, the PDMS/CB with 2.0 vol.% CB gave very high Gauge values of around 20,000. The findings in this study will thus facilitate the development of highly optimized conductive polymer composites for strain sensor applications. Full article

Electrical resistance strain gauges are widely used in asymmetric structures for measurement and monitoring, but their thermal output in changing temperature environments has a significant impact on the measurement results. Since thermal output is related to the coefficient of thermal expansion of the strain gauge’s sensitive grating material and the measured object, the temperature self-compensation technique of strain gauges fails to eliminate the additional strain caused by temperature because it cannot match the coefficient of thermal expansion of various measured objects. To address this problem, in this study, the principle of the thermal output of electrical resistance strain gauges was analyzed, a calibration experiment for thermal output in the case of a mismatch between the coefficient of linear expansion of the measured object and the strain gauge grating material was conducted, and the mechanism for temperature influence on thermal output was revealed. A method was proposed to obtain the thermal output curves for different materials by using thermostats with dual temperatures to conduct temperature calibration experiments. A linear regression method was used to obtain a linear formula for the thermal output corresponding to each temperature. The thermal output conversion relationship was derived for materials with different coefficients of linear expansion. An in situ temperature compensation technique for electrical resistance strain gauges that separates the measured strain into thermal and mechanical strains was proposed. The results showed that the thermal output curve for the measured object can be calibrated in advance and then deducted from the measured strain, thus reducing the influence of temperature-induced additional strain on the mechanical strain. In addition, a new method was provided for the calculation of the thermal output among materials with similar coefficients of linear expansion, providing a reference for the health monitoring of asymmetric structures. Full article
