The electric propulsion system is a critical determinant of unmanned aerial vehicles’ (UAVs’) operational capabilities, particularly endurance performance. This paper proposes a high-precision modeling framework for UAV electric propulsion systems to improve endurance estimation. By integrating dimensional analysis based on the Buckingham $\pi$ theorem with data-driven parameter fitting, the method accurately predicts propeller thrust, power, and motor current under varying inflow conditions using limited experimental data. The proposed models and complete implementation are publicly available, facilitating reproducibility and further research. The key novelty of this work lies in the tight integration of dimensional analysis (via Buckingham’s $\pi$ theorem) with a data-driven torque-based motor current model, enabling accurate cross-configuration predictions for both propeller aerodynamics and motor electrical characteristics using limited experimental data. The model is rigorously validated against the UIUC propeller database, a custom-built inflow test rig, and actual flight tests. The results demonstrate that the proposed approach achieves superior prediction accuracy across multiple propeller-motor configurations while significantly reducing computational costs. This work provides a reliable foundation for improving UAV endurance estimation and propulsion system design. Full article

Efficient cooling systems are crucial for achieving high efficiency and power density in electric vehicle motors. To enhance motor cooling performance, a novel oil spray cooling system was developed, referred to as the centripetal-inclined oil spray (CIOS) cooling system. The CIOS cooling system features axial oil channels evenly distributed on the surface of the stator core, with each channel connected at both ends to stepped oil channels. This configuration allows for direct oil spraying towards the center at specific inclined angles without the need for additional components such as nozzles, oil spray rings, and oil spray tubes, which reduces costs, minimizes the risk of oil leakage, and enhances motor reliability. Electromagnetic and computational fluid dynamic simulations were conducted on the motor with the CIOS cooling system. The results indicated that the CIOS cooling system adversely impacted core losses and torque, while these effects were minimized after optimization, with losses increasing by up to 0.29% and torque decreasing by up to 0.45%. The CIOS cooling system achieved stable oil spraying, forming oil films on the end-winding with a maximum formation rate of 49.4% and an average thickness of 1.56 mm. Compared to the motor with oil spray rings, the motor with the CIOS cooling system exhibited lower temperatures across all components and more uniform cooling. Finally, the cooling performance of the CIOS cooling system was verified through experiments, and the results showed that the measured temperature closely matched the simulated results, with a maximum error of 5.9%. The findings in this study are expected to provide new insights for optimizing oil cooling systems in electric vehicle motors. Full article

With the rapid advancement of intelligent technologies in electric vehicles, various control technologies and algorithms are emerging. Most existing research, however, is limited to simulations of single modules such as suspension, braking, and battery management, lacking comprehensive modeling and simulation for the entire vehicle system, which impedes the integrated development and verification of advanced intelligent technologies. Therefore, this article focuses on the vehicle control system of electric vehicles. It first analyzes the overall scheme and clarifies the core functions of system operation control, fault detection, and storage. Subsequently, a data acquisition simulation platform for the vehicle control system is established based on MATLAB/Simulink, creating simulation modules for accelerator pedal, braking pedal, key position, and gear signal, forming a complete vehicle simulation platform. For the established simulation platform, specific electric vehicle model parameters are set, and under the QC/T759 urban driving conditions, simulations of the electric vehicle’s operation are conducted to obtain relevant signals such as vehicle speed, accelerator pedal, and braking pedal, verifying the feasibility of the vehicle control system. Finally, a hardware platform for the entire vehicle power system is built, and based on the PCAN-Explorer5 software, the connection and debugging of the vehicle controller, battery management system, and motor control unit are achieved to obtain the status parameters of each system and debug the vehicle control system, laying the foundation for the actual operation of the pure electric SUV. Through the simulation of the electric vehicle’s control system, the R&D cycle is greatly shortened, development costs are reduced, and a foundation is established for the actual vehicle debugging of electric vehicles. Full article

Copper is a strategic raw material and an important component in electric motors, widely used across industries because of its excellent conductivity and recyclability. It plays an important role in the transformation from fossil fuel-based systems to green, electrified systems. However, substantial material losses continue throughout the lifecycle of electric motors, even with copper’s intrinsic capacity for circularity. Also, copper’s increasing demand, which is driven by the emergence of electric vehicles, industrial electrification, and renewable energy infrastructure, poses questions regarding its sustainable supply. The recovery of secondary copper sources from end-of-life (EoL) products is becoming more and more important in this context. However, it is still difficult to achieve circularity of copper, especially from industrial electric motors. This study investigates the challenges of closing the loop for copper during the lifecycle of motors in industrial applications. Based on an examination of EoL strategies, material flow insights, and practical investigation, the research pinpoints significant inefficiencies in the current processes. The widespread use of scraping as an approach of end-of-life management is one significant issue. Most of the electric motors are not built to separate their components, which makes both mechanical and manual disassembly difficult. The quality of recovered copper is thus compromised by the dominance of mixed metal shredding methods in the recycling step. This study highlights the need for systemic changes in addition to technical solutions to address copper circularity issues. It requires a focus on circularity in designing, giving disassembly and metal recovery a priority. This study focuses on circularity and its technological challenges in a value chain of copper. It not only identifies different processes such as supply chain disconnections and design constraints, but it also suggests workable solutions to close the copper flow loop in the electric motor sector. Copper quality and recovery is ultimately a problem involving design, technology, and cooperation, in addition to resources. This study supports the transition to a more sustainable and circular electric motor industry by offering a basis for directing such changes in industry practices and prospective EU regulations. Full article

This paper presents experimental testing results which describe the response of modern residential loads and electric vehicle (EV) chargers to various voltage magnitude, frequency, and phase angle disturbances. The purpose of these tests is to replicate real life network conditions and assist Network Service Providers and the Australian Energy Market Operator in identifying and predicting potential power variation and system stability issues caused by load behaviour during power system transient phenomena. By examining the behaviour of typical loads connected to distribution networks, a deeper understanding of their response can be achieved, enabling the refinement of composite load models that are compatible with the Western Electricity Coordinating Council dynamic composite load model (CMPLDW) structure presently used for dynamic studies. The performance of a wide range of common appliances found in residential settings, such as refrigerators, microwave ovens, air conditioners, direct-on-line motor-based appliances, and EV chargers, has been evaluated. The results obtained from these tests offer valuable insights into the behaviour of different load types and illustrate differing performances from established model parameters, identifying the need to refine existing CMPLDW models. The results also support the reclassification of several appliances within the composite load model, motivate the introduction of a dedicated EV charger component, and empower network operators to improve the modelling of modern power network responses. Full article

Fault diagnosis in the power systems of Hybrid Electric Vehicles (HEVs) is crucial for ensuring vehicle safety and energy efficiency. This study proposes an innovative CNN-LSTM fusion model for diagnosing common faults in HEV power systems, such as battery degradation, inverter anomalies, and motor failures. The model integrates the feature extraction capabilities of Convolutional Neural Networks (CNN) with the temporal dependency handling of Long Short-Term Memory (LSTM) networks. Through data preprocessing, model training, and validation, the approach achieves high-precision fault identification. Experimental results demonstrate an accuracy rate exceeding 95% on simulated datasets, outperforming traditional machine learning methods. This research provides a practical framework for HEV fault diagnosis and explores its potential in real-world applications. Full article

Wheel load is a critical information source reflecting the status of vehicle load distribution and motion. Yet, existing in-wheel motor products are primarily designed as propulsion units and inherently lack the load-sensing capabilities required by intelligent vehicles. To address this research gap, this paper presents a novel intelligent electric drive wheel (i-EDW) with an integrated transmission system and a load-sensing unit (LSU). The i-EDW adopts an Axial Flux Permanent Magnet Synchronous Motor (AFPMSM), while the integrated LSU ensures high-precision measurement of six-dimensional wheel forces and moments. According to this multi-axis force information, a real-time estimation and stability control method based on the tire–road friction circle concept is proposed. Instead of the complex decoupling and multi-objective optimization with the multi-actuator systems, this paper focuses on minimizing the tire load rate of i-EDWs, which significantly advances the state of the art in terms of calculation efficiency and respond speed. To validate this theoretical framework, a full-vehicle model equipped with four i-EDWs is developed. In the MATLAB R2022A/Simulink co-simulation environment, a virtual prototype is tested under typical driving scenarios, including the straight-line acceleration and double-moving-lane (DML) steering. The simulation results prove a reliable safety margin from the friction circle boundaries, laying a solid foundation for precise motion control and improved system robustness in future intelligent vehicles. Full article

As a highly integrated and compact power unit, the motor-pump finds critical applications in emerging electric vehicle (EV) domains such as electro-hydraulic braking and steering systems, where its vibration and noise performance directly impacts cabin comfort. A key factor limiting its NVH (Noise, Vibration, and Harshness) performance is the electromagnetic vibration and noise induced by the cogging torque of the built-in brushless DC motor (BLDCM). Traditional suppression methods that rely on stator auxiliary slots exhibit certain limitations. To address this issue, this paper proposes a collaborative optimization method integrating multi-parameter scanning and response surface methodology (RSM) for the design of auxiliary slots on the motor-pump’s stator teeth. The approach begins with a multi-parameter scanning phase to identify a promising region for global optimization. Subsequently, an accurate RSM-based prediction model is established to enable refined parameter tuning. Results demonstrate that the optimized stator structure achieves a 91.2% reduction in cogging torque amplitude for the motor-pump. Furthermore, this structure effectively suppresses radial electromagnetic force, leading to a 5.1% decrease in the overall sound pressure level. This work provides a valuable theoretical foundation and a systematic design methodology for cogging torque mitigation and low-noise design in motor-pumps. Full article

Grounding insulation is a key component of electric vehicle drive motors, and cracks may appear during the manufacturing process and assembly. In this paper, the novel method of coupling phase field, mechanic field and electric field is proposed to investigate the coupled propagation characteristics of electromechanical damage in stator end-wingding insulation. The crack propagation model is derived by using the phase field method, where the maximum historical variable is introduced to ensure the forward propagation of the crack damage in insulation. According to the crack evolution states, the electric potential distributions in the insulation domain are determined and the electrical damage variable is defined to quantitatively describe the dynamical evolution mechanism of electric damage with the variation in mechanical damage. The results in this research will contribute to understanding the electrical performance degradation and electromechanical failure of the end-winding insulation in electric vehicle drive motors, which also provides the basis for the mechanism of insulation damage, insulation fault diagnosis and residual life prediction of electrical machines. Full article

This paper reviews recent developments in the design optimization of electrical drive systems for electric vehicles (EVs) and proposes a pathway to develop next-generation AI design platforms that integrate system-level optimization methods and digital twins. First, a comprehensive review is presented to five design optimization models for EV motors, including multiphysics, multiobjective, multimode, robust, and topology optimization, as well as six efficient optimization strategies, such as multilevel optimization and AI-based approaches. Several recommendations on the practical application of these optimization strategies are also presented. Second, representative optimization methods for power converters and control systems of EV drives are summarized. Third, application-oriented and robust system-level design optimization strategies for EV drive systems are discussed. Finally, two proposals are presented and discussed for the design of next-generation EV drive systems and their integration with battery management systems. They are AI-powered automatic design optimization platforms that integrate large language models and a digital-twin-assisted system-level optimization framework. Two case studies on in-wheel motors and drive systems are also included to demonstrate the performance and effectiveness of various optimization methods. Full article

Precise electromagnetic torque estimation for permanent magnet synchronous motors (PMSMs) is crucial for enhancing the dynamic performance and energy efficiency of electric vehicles. To address the dynamic variations in dq-axis inductance caused by magnetic cross-coupling and saturation effects during motor operation—which lead to significant torque estimation errors in traditional fixed-parameter models under variable torque and speed conditions—this paper proposes a dynamic torque estimation method that integrates online dq-axis inductance identification based on a variable-step adaptive linear neural network (ADALINE) with an extended flux observer. The online identified inductance values are embedded into the extended flux observer in real time, forming a closed-loop torque estimation system with adaptive parameter updating. Experimental results demonstrate that, under complex operating conditions with varying torque and speed, the proposed method maintains electromagnetic torque estimation errors within ±3%, with a convergence time of less than 20 ms, while achieving inductance identification accuracy also within ±3%. These results significantly outperform conventional methods that do not incorporate inductance identification. This study provides a highly adaptive and engineering-practical solution for high-precision torque control of interior permanent magnet synchronous motors (IPMSMs) in automotive applications. Full article

Partial demagnetization of multiple in-wheel motors changes torque distribution characteristics and can reduce vehicle stability, which poses a challenge for in-wheel motor drive electric vehicles (IWMDEVs) to maintain a balance between safety and efficiency. To address this issue, a hierarchical multi-objective adaptive fault-tolerant control (FTC) strategy based on wheel terminal torque compensation is developed. In the upper layer, a nonlinear model predictive controller (NMPC) generates the desired total driving force and corrective yaw moment according to vehicle dynamics and driving conditions. The lower layer employs a quadratic programming (QP) scheme to allocate the wheel torques under actuator and tire constraints. Two adaptive coefficients—the stability–efficiency weighting factor and the current compensation factor—are updated through a randomized ensembled double Q-learning (REDQ) algorithm, enabling the controller to adaptively balance yaw stability preservation and energy optimization under different fault scenarios. The proposed method is implemented and verified in a CarSim–Simulink–Python co-simulation environment. The simulation results show that the controller effectively improves yaw and lateral stability while reducing energy consumption, validating the feasibility and effectiveness of the proposed strategy. This approach offers a promising solution to achieve reliable and energy-efficient control of IWMDEVs. Full article

Amid fossil-fuel depletion and worsening environmental impacts, battery electric vehicles (BEVs) are pivotal to the energy transition. Energy management in BEVs relies on accurate motor efficiency maps, yet real-time onboard control demands models that balance fidelity with computational cost. To address map inaccuracy under real driving and the high runtime cost of 2-D interpolation, we propose a driving-cycle-aware, physically interpretable quadratic polynomial-surface framework. We extract priority operating regions on the speed–torque plane from typical driving cycles and model electrical power $P_e$ as a function of motor speed $n$ and mechanical power $P_m$. A nested model family (M3–M6) and three fitting strategies—global, local, and region-weighted—are assessed using $R^2$, RMSE, a computational complexity index (CCI), and an Integrated Criterion for accuracy–complexity and stability (ICS). Simulations on the Worldwide Harmonized Light Vehicles Test Cycle, the China Light-Duty Vehicle Test Cycle, and the Urban Dynamometer Driving Schedule show that region-weighted fitting consistently achieves the best or near-best ICS; relative to Global fitting, mean ICS decreases by 49.0%, 46.4%, and 90.6%, with the smallest variance. Regarding model order, the four-term M4 $\left(+P_m^2\right)$ offers the best accuracy–complexity trade-off. Finally, the region-weighted fitting M4 $\left(+P_m^2\right)$ polynomial model was integrated into the vehicle-level economic speed planning model based on the dynamic programming algorithm. In simulations covering a 27 km driving distance, this model reduced computational time by approximately 87% compared to a linear interpolation method based on a two-dimensional lookup table, while achieving an energy consumption deviation of about 0.01% relative to the lookup table approach. Results demonstrate that the proposed model significantly alleviates computational burden while maintaining high energy consumption prediction accuracy, thereby providing robust support for real-time in-vehicle applications in whole-vehicle energy management. Full article

With the growing consumer demand for enhanced driving dynamics in vehicles, optimizing powertrain configurations to balance performance, energy efficiency, and cost has become a critical challenge. Traditional internal combustion engine vehicles (ICEVs) suffer from significant energy consumption and cost penalties when improving acceleration performance. This study systematically evaluates the trade-offs between dynamic performance, energy consumption, and direct manufacturing costs across six powertrain configurations: ICEV, 48 V mild hybrid (48 V), hybrid electric vehicle (HEV), plug-in hybrid electric vehicle (PHEV), range-extended electric vehicle (REV), and battery electric vehicle (BEV). By developing a comprehensive parameterized model, we quantify the impacts of acceleration improvement on vehicle mass, energy consumption, and costs. Key findings reveal that electrified powertrains (PHEV, REV, BEV) exhibit superior cost-effectiveness and energy efficiency. For instance, improving 0–100 km/h acceleration time from 9 to 5 s reduces direct manufacturing costs by only 5.72% for BEV versus 13.38% for ICEV, while PHEV achieves a balanced compromise with 3.40% lower fuel consumption and 10.43% cost increase compared to conventional counterparts. Mechanistic analysis attributes these advantages to higher power density of electric motors and simplified energy transmission in electrified systems. This work provides data-driven insights for consumers and automakers to prioritize powertrain technologies under dynamic performance requirements, highlighting PHEV with driving range of 50 km as the optimal choice for harmonizing driving experience, energy economy, and affordability. The results of this study assist automakers in optimizing the technology pathways of vehicle powertrain, within the consumer demand for dynamic performance. This plays a crucial role in advancing the automotive industry’s overall fuel consumption and energy consumption, thereby contributing to sustainable development. Full article

The dual-rotor in-wheel motor (DRIWM) drive electric vehicle has multiple braking modes. Determining how to select the most suitable braking mode for the current driving conditions and dynamically allocate the regenerative braking torque of the inner and outer motors is the key to achieving maximum energy recovery. On the basis of regenerative braking characteristic analyses of the DRIWM, the switching rules of the vehicle braking modes were designed based on the optimal system efficiency, and the specific working ranges of various braking modes were determined. According to the efficiency characteristics of the inner and outer motors, a regenerative braking torque allocation strategy based on the principle of maximizing the system energy recovery was proposed in the dual-motor coupled regenerative braking mode. The simulation results show that, during the entire CLTC-P cycle condition, the three regenerative braking modes of the DRIWM can effectively recover braking energy within their designed working ranges. Moreover, both the inner motor and outer motor can operate at the best efficiency when they undertake the optimal braking torque to achieve the maximum braking energy recovery. The experimental results show that a variable voltage charging scheme for the DRIWM is adopted, which can further ensure that both the inner and outer motors can simultaneously store energy with the maximum efficiency to the power battery pack. Full article
