Search Results (19)

Wood displays three-dimensional characteristics at both macroscopic and microscopic scales. Accurately reconstructing its 3D structure is vital for a deeper understanding of the relationship between its anatomical characteristics and its physical and mechanical properties. This study aims to apply X-ray micro-computed tomography (XμCT) for the high-resolution, non-destructive visualization and quantification of softwood anatomical features. Six typical softwood species—Picea asperata, Cupressus funebris, Pinus koraiensis, Pinus massoniana, Cedrus deodara, and Pseudotsuga menziesii—were selected to represent a range of structural characteristics. The results show that a scanning resolution of 1–2 μm is suitable for investigating the transition from earlywood to latewood and resin canals, while a resolution of 0.5 μm is required for finer structures such as bordered pits, ray tracheids, and cross-field pits. In Pinus koraiensis, a direct 3D connection between radial and axial resin canals was observed, forming an interconnected resin network. In contrast, wood rays were found to be distributed near the surface of axial resin canals but without forming interconnected structures. The three-dimensional reconstruction of bordered pit pairs in Pinus massoniana and Picea asperata clearly revealed interspecific differences in pit morphology, distribution, and volume. The average surface area and volume of bordered pit pairs in Pinus massoniana were 1151.60 μm² and 1715.35 μm³, respectively, compared to 290.43 μm² and 311.87 μm³ in Picea asperata. Furthermore, XμCT imaging effectively captured the morphology and spatial distribution of cross-field pits across species, demonstrating its advantage in comprehensive anatomical deconstruction. These findings highlight the potential of XμCT as a powerful tool for 3D analysis of wood anatomy, providing deeper insight into the structural complexity and interconnectivity of wood. Full article

The purpose of this research was to investigate the modulus of rupture (MOR) and modulus of elasticity (MOE) in the static bending of yellow pine (Pinus ponderosa Douglas ex C. Lawson) earlywood and latewood. The relationship between the properties of these wood zones and the MOR and MOE of yellow pine wood tested was determined with the methodology specified in the standards. An important element of the research was to verify the suitability of the developed method for testing the MOR and MOE of small wood samples obtained from the earlywood and latewood zone. The MOR of the earlywood was about 6% higher than the MOR of the pine wood determined using standard samples, and these differences were not statistically significant. However, the MOR of the latewood was approximately three times higher than the MOR of the pine wood determined using standard samples, and these differences were statistically significant. The MOR of the latewood was found to be 2.5 times higher than the MOR of the earlywood. The MOE of the latewood was found to be two times higher than the MOE of the earlywood. This was due to the density of particular wood zones and the dimensions of structural elements—tracheids. The maximum load (F_max) transferred by latewood zones was four times higher than the F_max transferred by earlywood zones. The deflection at the F_max of the earlywood zone was 20% smaller than the deflection at the F_max of the latewood zone. Full article

Recent climate and societal changes have increased wildfire activity and prolonged the fire season in many regions of the world. The precision of fire seasonality analysis from tree-ring records can be improved by complementing the subjectively determined intra-ring position of fire scars with more precise studies of wood formation. With this aim, we monitored the wood formation dynamics of Pinus nigra J.F. Arnold (black pine) trees along a climatic gradient in western Anatolia to better understand the wood formation for the interpretation of fire seasonality. Wood microcores were collected from April to November 2021 from trees at four sites across (from north; the Black Sea climate in Bolu to the south; and the Mediterranean climate in Isparta) the areas where previous fire history reconstructions were conducted. These previous studies showed that most fires occurred during the latewood formation period. We found that matured latewood tracheids were observed between September (August) and November, thus suggesting that these fires occurred during late summer and fall. Our results show the importance of temperature and water availability for the timing of earlywood and latewood formations. These findings can be used to better inform planning activities for fire management and as a proxy to reconstruct past fire seasonality. Full article

The quantitative description of growth rings is yet incomplete, including the functional division into earlywood and latewood. Methods developed to date, such as the Mork criterion for conifers, can be biased and arbitrary depending on species and growth conditions. We proposed the use of modeling of the statistical distribution of tracheids to determine a universal criterion applicable to all conifer species. Thisstudy was based on 50-year anatomical measurements of Pinus sylvestris L., Pinus sibirica Du Tour, and Picea obovata Ledeb. near the upper tree line in the Western Sayan Mountains (South Siberia). Statistical distributions of the cell wall thickness (CWT)-to-radial-diameter (D) ratio and its slope were investigated for raw and standardized data (divided by the mean). The bimodal distribution of the slope for standardized CWT and D was modeled with beta distributions for earlywood and latewood tracheids and a generalized normal distribution for transition wood to account for the gradual shift in cell traits. The modelcan describe with high accuracy the growth ring structure for species characterized by various proportions of latewood, histometric traits, and gradual or abrupt transition. The proportion of two (or three, including transition wood) zones in the modeled distribution is proposed as a desired criterion. Full article

Thermal modification can increase the physical stability and impact the mechanical strength of wood. It is necessary to understand the effects of modifications on the compressive stress of wood. In this study, Douglas fir (Pseudotsuga menziessi) blocks were modified at 180 °C (TM-180 °C) and 210 °C (TM-210 °C). The compressive stress of pure earlywood (EW), pure latewood (LW), and combined earlywood and latewood (ELW) specimens was measured. The specimens were compressed at 30% of their original thickness, and during the compression test the strain distribution of the ELW was recorded. In addition, the microstructures before and after compression were investigated, complemented with SEM to understand the structural changes taking place. The results showed that the compressive stress of the TM-180 °C specimens was the highest because the thermal modification increased the stiffness of cell walls and the homogenized strain distribution in the ELW specimens. The control specimens had a higher compression set recovery rate than the thermally modified specimens. The tracheid cell walls in the EW and LW specimens were flattened and buckled, respectively, due to compression. In the thermally modified materials, cell wall fissures and wood ray fractures in the EW and LW specimens, respectively, were observed. For the ELW specimens, the structural changes in the latewood were not obvious and the structural changes in the earlywood were less significant than in the full EW specimens. Compared to the EW specimens, the earlywood in the ELW specimens showed higher compression set recovery rates. It seems that structural failure in earlywood is limited when used in combination with latewood, resulting from the homogenized strain distribution in earlywood. Full article

Furfurylated wood has many advantages, such as decay resistance, dimensional stability, hardness, etc. However, furfurylation increases the brittleness and decreases the flexural resistance of wood, which greatly limits its application. Therefore, caprolactam (CPL) is incorporated with furfuryl alcohol (FA) to improve the performance of furfurylated wood. In this study, an FA and CPL combinational modifier was used to treat masson pine (Pinus massoniana Lamb.) earlywood and latewood. The synergistic interaction of both components with the wood cell walls was systematically evaluated via microstructural, chemical, and thermal analysis using scanning electron microscopy (SEM), infrared spectroscopy (ATR-FTIR), X-ray photoelectron spectrometry (XPS), and differential scanning calorimetry (DSC). The SEM images showed that polymerized modifiers were distributed in tracheids, ray cells, and pits, with a higher degree of distribution in latewood tissues. The FA-CPL co-treatment led to the highest degree of distribution in cell cavities as well as of cell wall swelling. The results of the weight percentage gain (WPG) of modified wood agreed with the SEM findings that the FA-CPL co-treatment could more effectively increase the WPG than individual modification. The results of FTIR and XPS revealed that FA and CPL might chemically bind with each other as well as react with lignin and hemicellulose in the cell walls during the curing process. In addition, the interactions between modifiers and cell walls were slightly different for earlywood and latewood. DSC analysis indicated that the wood hygroscopicity decreased and the thermal stability improved after modification. Full article

This study investigated the variations in tracheid length of Pseudotsuga menziesii (Mirb.) Franco from three sites in Croatia in relation to cambium age, within- and between-site differences, and growth rate. Tracheids are the main structural element in P. menziesii wood, varying in length following different patterns that should be precisely determined. After the maceration procedure, earlywood tracheid length (EWTL), latewood tracheid length (LWTL), annual growth ring tracheid length (RTL), earlywood ring width (EWW), latewood ring width (LWW), and annual ring width (ARW) were measured in selected annual growth rings. The significant effect of annual growth rings and zone interaction for EWTL and LWTL, as well as of annual growth rings, trees, and sites for RTL, was determined. The results conclude on the differences between the trends in EWTL and LWTL from pith toward the bark. In addition, the correlation analysis between the tracheid length and different growth patterns was investigated, and very weak or no association between the variables was detected. This research contributes to better understanding the degree of wood uniformity of P. menziesii from the technological perspective, as well as the variability factor in the optimization of forest management with favoring overall wood quality. Full article

Due to wood moisture sensitivity, shrinkage cracks tend to present wooden structures. These failures are caused by moisture-related shrinkage behavior. In order to avoid it, it is necessary to have a better understanding of shrinkage behavior. In this respect, studying the dimension changes in wood at different scales is of utmost significance for a better understanding of the shrinkage properties. Herein, the shrinkage behavior of Masson pines (Pinus massoniana) wood was investigated at macroscopic and cellular levels during moisture loss via digital image correlation using VIC-3D and digital microscopic systems, respectively. According to the full-field strain maps, shrinkage strain near the external face was higher than that at the internal face, which increased susceptibility to cracking at the external face of lumber. Additionally, the anisotropic shrinkage of wood was explored. The shrinkage ratio at the end of drying was about 5.5% in the tangential (T) direction and 3.5% in the radial (R) direction. However, at a cellular level, the shrinkage ratios in the T and R directions of earlywood tracheids were 7.13% and 2.46%, whereas the corresponding values for latewood tracheid were 9.27% and 5.52%, respectively. Furthermore, the maximum T/R shrinkage ratio at the macroscopic level (1.7) was found to be similar to the value of latewood tracheid (1.72). The earlywood showed high anisotropic, its T/R shrinkage ratio was 2.75. The macroscopic shrinkage was the result of the interaction of the tracheids of earlywood and latewood and was mainly dominated by latewood tracheids. Full article

Four Picea glauca (Moench) Voss trees grown at each of four square spacing intensities between trees: 1.2 m, 1.8 m, 4.3 m, and 6.1 m in a plantation established in 1967 in the Petawawa Research Forest, Ontario, Canada (lat. 45.59° N, long. 77.25° W, elev. 168 m) and sampled at four different heights (1.3 m, 4.3 m, 7.3 m, 10.3 m) were used to study the impact of spacing between trees and sampling height on nine wood quality attributes (ring width, ring density, tracheid length, tracheid diameter, latewood proportion, intra-ring density variation, ring area, earlywood width, and latewood width). In the juvenile wood, ring width was wider and ring density higher than in the mature wood. Tracheid length was longer and tracheid diameter wider in the mature wood compared to the juvenile wood. The variation of ring density between the two wood zones was limited, and latewood proportion did not show any difference with wood zone. Sampling height induced variation in more wood quality attributes than did spacing. Except for growth rate, spacing between trees did not significantly impact wood quality attributes. Most of these variations were registered between widely different spacings. Full article

From a fiber composite point of view, an elongated softwood particle is a composite consisting of several thousand tracheids, which can be described as fiber wound hollow profiles. By knowing their deformation behavior, the deformation behavior of the wood particle can be described. Therefore, a numerical approach for RVE- and FEM-based modelling of the radial and tangential compression behavior of pine wood tracheids under room climate environment is presented and validated with optical and laser-optical image analysis as well as tensile and compression tests on pine sapwood veneer strips. According to the findings, at 23 °C and 12% moisture content, at least 10 MPa must be applied for maximum compaction of the earlywood tracheids. The latewood tracheids can withstand at least 100 MPa compression pressure and would deform elastically at this load by about 20%. The developed model can be adapted for other wood species and climatic conditions by adjusting the mechanical properties of the base materials of the cell wall single layers (cellulose, hemicellulose, lignin), the dimensions and the structure of the vessel elements, respectively. Full article

Picea crassifolia Kom. is one of the timber and ecological conifers in China and its wood tracheid traits directly affect wood formation and adaptability under harsh environment. Molecular studies on P. crassifolia remain inadequate because relatively few genes have been associated with these traits. To identify markers and candidate genes that can potentially be used for genetic improvement of wood tracheid traits, we examined 106 clones of P. crassifolia, and investigated phenotypic data for 14 wood tracheid traits before specific-locus amplified fragment sequencing (SLAF-seq) was employed to perform a genome wide association study (GWAS). Subsequently, the results were used to screen single nucleotide polymorphism (SNP) loci and candidate genes that exhibited a significant correlation with the studied traits. We developed 4,058,883 SLAF-tags and 12,275,765 SNP loci, and our analyses identified a total of 96 SNP loci that showed significant correlations with three earlywood tracheid traits using a mixed linear model (MLM). Next, candidate genes were screened in the 100 kb zone (50 kb upstream, 50 kb downstream) of each of the SNP loci, whereby 67 candidate genes were obtained in earlywood tracheid traits, including 34 genes of known function and 33 genes of unknown function. We provide the most significant SNP for each trait-locus combination and candidate genes occurring within the GWAS hits. These resources provide a foundation for the development of markers that could be used in wood traits improvement and candidate genes for the development of earlywood tracheid in P. crassifolia. Full article

Wood is an anisotropic material, the mechanical properties of which are strongly influenced by its microstructure. In wood, grain compression strength and modulus are the weakest perpendicular to the grain compared to other grain directions. FE (finite element) models have been developed to investigate the mechanical properties of wood under transverse compression. However, almost all existing models were deterministic. Thus, the variations of geometry of the cellular structure were not considered, and the statistical characteristic of the mechanical property was not involved. This study aimed to develop an approach to investigate the compression property of wood in a statistical sense by considering the irregular geometry of wood cells. First, the mechanical properties of wood under radial perpendicular to grain compression was experimentally investigated, then the statistical characteristic of cell geometry was extracted from test data. Finally, the mechanical property of wood was investigated using the finite element method in combination with the Monte Carlo Simulation (MCS) techniques using randomly generated FE models. By parameter sensitivity analysis, it was found that the occurrence of the yield points was caused by the bending or buckling of the earlywood axial tracheid cell wall in the tangential direction. The MCS-based stochastic FE analysis was revealed as an interesting approach for assessing the micro-mechanical performance of wood and in assisting in understanding the mechanical behavior of wood based on its hierarchical structure. Full article

Research Highlights: novel fast and easily assessable proxies for vulnerability to cavitation of conifer sapwood are proposed that allow reliable estimation at the species level. Background and Objectives: global warming calls for fast and easily applicable methods to measure hydraulic vulnerability in conifers since they are one of the most sensitive plant groups regarding drought stress. Classical methods to determine P₁₂, P₅₀ and P₈₈, i.e., the water potentials resulting in 12, 50 and 88% conductivity loss, respectively, are labour intensive, prone to errors and/or restricted to special facilities. Vulnerability proxies were established based on empirical relationships between hydraulic traits, basic density and sapwood anatomy. Materials and Methods: reference values for hydraulic traits were obtained by means of the air injection method on six conifer species. Datasets for potential P₅₀ proxies comprised relative water loss (RWL), basic density, saturated water content as well as anatomical traits such as double wall thickness, tracheid lumen diameter and wall/lumen ratio. Results: our novel proxy P_25W, defined as 25% RWL induced by air injection, was the most reliable estimate for P₅₀ (r = 0.95) and P₈₈ (r = 0.96). Basic wood density (r = −0.92), tangential lumen diameters in earlywood (r = 0.88), wall/lumen ratios measured in the tangential direction (r = −0.86) and the number of radial cell files/mm circumference (CF/mm, r = −0.85) were also strongly related to P₅₀. Moreover, CF/mm was a very good predictor for P₁₂ (r = −0.93). Conclusions: the proxy P_25W is regarded a strong phenotyping tool for screening conifer species for vulnerability to cavitation assuming that the relationship between RWL and conductivity loss is robust in conifer sapwood. We also see a high potential for the fast and easily applicable proxy CF/mm as a screening tool for drought sensitivity and for application in dendroecological studies that investigate forest dieback. Full article

Oriental arborvitae is not fully characterized in terms of its microscopic structure or physical or mechanical properties. Moreover, there is a lot of contradictory information in the literature about oriental arborvitae, especially in terms of microscopic structure. Therefore, the sapwood (S) and heartwood (H) of Platycladus orientalis (L.) Franco from Central Europe were subjected to examinations. The presence of helical thickenings was found in earlywood tracheids (E). Latewood tracheids (L) were characterized by a similar thickness of radial and tangential walls and a similar diameter in the tangential direction in the sapwood and heartwood zones. In the case of earlywood tracheids, such a similarity was found only in the thickness of the tangential walls. The volume swelling (VS) of sapwood and heartwood after reaching maximum moisture content (MMC) was 12.8% (±0.5%) and 11.2% (±0.5%), respectively. The average velocity of ultrasonic waves along the fibers (υ) for a frequency of 40 kHz was about 6% lower in the heartwood zone than in the sapwood zone. The dynamic modulus of elasticity (MOE_D) was about 8% lower in the heartwood zone than in the sapwood zone. These differences, both in the case of υ and MOE_D, were statistically significant. However, no statistically significant differences were found for the static bending strength (MOR, approx. 90 MPa), modulus of elasticity at static bending (MOE, approx. 4800 MPa), or compression strength parallel to the grain (CS, approx. 47 MPa) in relation to the wood zone (sapwood, heartwood). Full article

Shear strength is important for the application of Larix kaempferi (Lamb) Carr. The structural difference between earlywood and latewood of Larix kaempferi affects its mechanical properties, especially shear strength. The microstructures of earlywood and latewood in Larix kaempferi, however, are different. In this study, we investigated the shear strength and shear failure mode in the RL direction of 40 Larix kaempferi specimens. The results demonstrated that the initial crack appears in any location of a growth ring, whereas shear failure is concentrated in earlywood, as well as the junction between earlywood and latewood. The destruction of earlywood is the tear destruction, whereas when the destruction happened in the junction of earlywood and latewood, one to three earlywood cells usually adhered to latewood. At the cell wall level, the shear failure of earlywood was mostly observed in the direction of the microfibril angle (MFA). When the crack occurs in latewood, the destruction of latewood also occurs in the intercellular layer and preserves the complete morphology of tracheids. When destruction occurs in the wood ray, the ray cells detach intact from the tracheids. The failure mode is determined by the microstructure of earlywood and latewood. Our research suggests that the density, cell wall thickness, and MFA have significant differences between earlywood and latewood. The earlywood was found to have an MFA of 25.4°, a cell wall thickness of 6.36 µm, and a density of 0.39 g/cm³. The MFA, cell wall thickness, and density of latewood density were 17.60°, 12.37 µm, and 0.78 g/cm³, respectively. However, there was no significant difference found in the crystallinity between the earlywood (43.97%) and latewood (42.79%). The correlation between the microstructures and shear strength showed that earlywood with a thin cell wall, large MFA, and low density had poor shear performance, while the latewood with a thicker tracheid, smaller MFA, and higher density had better shear performance. Therefore, when shear failure occurred, it occurred in earlywood. We thus deduced that the MFA, cell wall thickness, and density of earlywood synergically affect the shear strength in the RL direction of L. kaempferi. Full article
