The current commitment towards aviation climate neutrality and decarbonisation is boosting research programmes on disruptive aircraft configurations featuring sustainable powertrains and fuel-efficient airframes. This trend is pushing the design towards high-aspect-ratio wings made of lightweight structures housing distributed propulsion systems. Airframe preliminary sizing and mass estimation of non-conventional configurations, if performed using legacy methodologies based on experience, gathered with traditional configurations may result in non-optimised and non-viable designs. Therefore, a physics-based optimisation approach may allow more accurate sizing and airframe mass estimation. The methodology suggested in this paper is based on the automatic generation of a global finite element model to estimate the weight and determine a feasible material distribution for the wing box structure of a strut-braced wing configuration by means of size optimisation. Composite materials with defined stacking sequences were assigned to the wing components and structural weight minimised with the aim of offsetting the weight penalties associated with this non-conventional aircraft configuration. Preliminary results suggest that the composite strut-braced wing could achieve a weight reduction of up to 44% compared to a composite cantilever wing with equal aspect ratio of 20. The actual weight reduction is thought to be lower due to potential overestimation of the cantilever configuration. Full article

In recent years, the distributed propulsion system has received extensive attention due to its advantages such as high propulsion efficiency, low noise, high safety redundancy, and good flexibility and maneuverability. However, the interaction between the internal and external flow can limit the aerodynamic performance of the ducted fan. To investigate the influence of the internal and external flow interaction on the aerodynamic–propulsion coupling characteristics of the distributed propulsion system, an over-wing symmetric configuration with five distributed ducted fans was constructed, and numerical simulations were performed using a method based on the body force model. Results show that as the flight Mach number increases, the lift obtained by the wing increases, while the stall angle of attack decreases, and the stall angle of attack at a Mach number of 0.5 is reduced by 15° compared with a Mach number of 0.2. At large angles of attack, the edge fans have the strongest ability to resist airflow separation, while the middle fan has the weakest ability to resist airflow separation, and its fan performance index drops the fastest. When the Mach number is 0.4, the mass flow rate and thrust of the middle fan are reduced by 16% and 28%, respectively, compared with those when the Mach number is 0.2. The higher the flight Mach number, the larger the intake distortion degree of the ducted fans. The middle fan is most affected by total pressure distortion and least affected by swirl distortion, whereas the edge fans are least affected by total pressure distortion and most affected by swirl distortion. Full article

The integration of distributed electric propulsion into a wing significantly alters the dynamic behavior of the wing. Consequently, the loads on the wing structure in service, in particular upon transient gust and landing impact loads, change substantially compared with conventional aircrafts with main engines mounted on the inner wing. As this might significantly increase the stress levels and number of load cycles, this paper assesses the impact of wing-integrated distributed propulsion on the fatigue behavior of the wing structure. This assessment is conducted based on a retrofit scenario of a conventional 19-seater commuter aircraft of the CS-23 category retrofitted with distributed electric propulsion. The wing structure is idealized with beam elements. Static and dynamic response analyses followed by stress analyses are conducted for typical load cases occurring during operation of the aircraft. The fatigue analysis is carried out based on the safe life approach. This study concludes that the integration of distributed electric propulsion has a substantial impact on the fatigue behavior of the wing. A significant increase in fatigue damage for the electric configurations compared with the conventional configuration is observed, in particular in the outer wing area. The increased damage accumulation is a result of the higher stress amplitudes and the longer decay duration of the structural vibrations due to gusts. The results suggest that adjustments to the structural design and maintenance procedures of future electric aircrafts may be necessary. Full article

The static aeroelastic characteristics of the distributed propulsion wing (DPW) were studied using the CFD/CSD loose coupling method in this study. The momentum source method of the Reynolds-averaged Navier–Stokes equation based on the k-ω SST turbulence model solution was used as the CFD solution module. The upper and lower surfaces of the DPW were established using the cubic B-spline basis function method, and the surfaces of the inlet and outlet were established using the fourth-order Bezier curve. Finally, a three-dimensional parametric model of the DPW was established. A structural finite-element model of the DPW was established, a multipoint array method program based on the three-dimensional radial basis function (RBF) was written as a data exchange module to realize the aerodynamic and structural data exchange of the DPW’s static aeroelastic analysis process, and, finally, an aeroelastic analysis of the DPW was achieved. The results show that the convergence rate of the CFD/CSD loosely coupled method is fast, and the structural static aeroelastic deformation is mainly manifested as bending deformation and positive torsion deformation, which are typical static aeroelastic phenomena of the straight wing. Under the influence of static aeroelastic deformation, the increase in the lift characteristics of the DPW is mainly caused by the slipstream region of the lower surface and the non-slipstream region of the upper and lower surface. Meanwhile, the increase in its nose-up moment and the increase in the longitudinal static stability margin may have an impact on the longitudinal stability of the UAV. To meet the requirements of engineering applications, a rapid simulation method of equivalent airfoil, which can be applied to commercial software for analysis, was developed, and the effectiveness of the method was verified via comparison with the CFD/CSD loose coupling method. On this basis, the static aeroelastic characteristics of the UAV with DPWs were studied. The research results reveal the static aeroelastic characteristics of the DPW, which hold some significance for engineering guidance for this kind of aircraft. Full article

The integration of propulsion and wing in distributed propulsion–wing UAVs (DPW UAVs) introduces significant propulsion-aerodynamic coupling, complicating dynamic modeling and flight control. This complexity is heightened by using induced wing surfaces for vertical takeoff and landing, requiring controllers to adapt to configuration changes and disturbances during transition flight. This paper develops a propulsion-aerodynamic coupling model for a medium-sized DPW UAV with induced wings (DPW-IW), enabling real-time aerodynamic performance calculations. Furthermore, a unified flight-control framework is proposed to avoid controller scheduling and switching during flight mode transitions. The proposed control framework employs the time-scale separation principle, divided into an outer loop and an inner loop. The outer loop uses a fuzzy controller to adjust allocation parameters, while the inner loop applies incremental nonlinear dynamic inversion (INDI) and control allocation (INCA) methods, providing robustness to nonlinear changes during flight transitions. Finally, simulations under various conditions demonstrate the controller’s effectiveness in ensuring smooth and robust transitions. Full article

Hybrid systems offer optimal solutions for unmanned aerial platforms, showcasing their technological development in parallel and series configurations and providing alternatives for future aircraft concepts. However, the limited energetic benefit of these configurations is primarily due to their weight, constituting one of the main constraints. Solar PV technology can provide an interesting enhancement to the autonomy of these systems. However, to create efficient propulsion architectures tailored for specific missions, a flexible framework is required. This work presents a methodology to assess hybrid solar-powered UAVs in distributed propulsion configurations through a two-level modeling scheme. The first stage consists of determining operational and design constraints through parametric models that estimate the baseline energetic requirements of flight. The second phase executes a nonlinear optimization algorithm tuned to find optimal propulsion configurations in terms of the degree of hybridization, number of propellers, different wing loadings, and the setup of electric distributed propulsion (eDP) considering fuel consumption as a key metric. The results of the study indicate that solar-hybrid configurations can theoretically achieve fuel savings of up to 80% compared to conventional configurations. This leads to a significant reduction in emissions during long-endurance flights where current battery technology is not yet capable of providing sustained flight. Full article

The imperative for energy conservation and environmental protection has led to the development of innovative aircraft designs. This study explored a novel thrust control configuration for blended-wing-body (BWB) aircraft with distributed electric boundary-layer ingestion (BLI) propulsors, addressing the issues of sagging and altitude loss during landing. The research focused on a small-scale BWB demonstrator equipped with six BLI fans, each with a 90 mm diameter. Various thrust control configurations were evaluated to achieve significant thrust reduction while maintaining lift, including dual-layer sleeve, separate flap-type, single-stage linkage flap-type, and dual-stage linkage flap-type configurations. The separate flap-type configuration was tested through ground experiments. Control experiments were conducted under three different experimental conditions as follows: deflection of the upper cascades only, deflection of the lower cascades only, and symmetrical deflection of both cascades. For each condition, the deflection angles tested were 0°, 10°, 20°, 30°, 40°, 50°, and 60°. The thrust reductions observed for these three conditions were 0%, 37.5%, and 27.5% of the maximum thrust, respectively, without additional changes in the pitch moment. A combined thrust adjustment method maintaining a zero pitch moment demonstrated a linear thrust reduction to 20% of its initial value. The experiment concluded that the novel thrust control configuration effectively adjusted thrust without altering the BLI fans’ rotation speed, solving the coupled lift–thrust problem and enhancing BWB landing stability. Full article

The combination of different aerodynamic configurations and propulsion systems, namely, aero-propulsion, affects flight performance differently. These effects are closely related to multidisciplinary collaborative aspects (aerodynamic configuration, propulsion, energy, control systems, etc.) and determine the overall energy consumption of an aircraft. The potential benefits of distributed propulsion (DP) involve propulsive efficiency, energy-saving, and emissions reduction. In particular, wake filling is maximized when the trailing edge of a blended wing body (BWB) is fully covered by propulsion systems that employ boundary layer ingestion (BLI). Nonetheless, the thrust–drag imbalance that frequently arises at the trailing edge, excessive energy consumption, and flow distortions during propulsion remain unsolved challenges. These after-effects imply the complexity of DP systems in multidisciplinary optimization (MDO). To coordinate the different functions of the aero-propulsive configuration, the application of MDO is essential for intellectualized modulate layout, thrust manipulation, and energy efficiency. This paper presents the research challenges of ultra-high-dimensional optimization objectives and design variables in the current literature in aerodynamic configuration integrated DP. The benefits and defects of various coupled conditions and feasible proposals have been listed. Contemporary advanced energy systems, propulsion control, and influential technologies that are energy-saving are discussed. Based on the proposed technical benchmarks and the algorithm of MDO, the propulsive configuration that might affect energy efficiency is summarized. Moreover, suggestions are drawn for forthcoming exploitation and studies. Full article

Ambitious targets for the coming decades have been set for further reductions in aviation greenhouse gas emissions. Hybrid electric propulsion (HEP) concepts offer potential for the mitigation of these aviation emissions. To investigate this potential in an adequate level of detail, the European research project IMOTHEP (Investigation and Maturation of Technologies for Hybrid Electric Propulsion) explores key technologies for HEP in close relation with developments of aircraft missions and configuration. This paper presents conceptual-level design investigations on radical HEP aircraft configurations for short–medium-range (SMR) missions. In particular, a blended-wing-body (BWB) configuration with a turbo-electric powertrain and distributed electric propulsion is investigated using NLR’s aircraft evaluation tool MASS. For the aircraft and powertrain design, representative top-level aircraft requirements have been defined in IMOTHEP, and the reference aircraft for the assessment of potential benefits is based on the Airbus A320neo aircraft. The models and data developed in IMOTHEP and presented in this paper show that the turbo-electric BWB configuration has potential for reduced fuel consumption in comparison to the reference aircraft. But in comparison to advanced turbofan-powered BWB configurations, which have the same benefits of the BWB airframe and advanced technology assumptions, this potential is limited. Full article

In order to ensure that aircraft have medium and long-range flights, enhanced aerodynamic performance, and reduced fuel consumption, this paper presents an original Distributed Hybrid Electric Propulsion Aircraft (DHEPA) design scheme and proposes a novel power allocation management method based on convex optimization. Firstly, by taking the Tecnam P2006T general-purpose aircraft as a reference, key components of DHEPA are selected and modeled. Then, a power allocation management method for DHEPA is proposed on the basis of convex optimization, which takes the minimum fuel consumption as the performance index to realize the reasonable power allocation of the battery and engine, while avoiding sliding into the local optimum of allocation. Finally, momentum theory and numerical simulation methods are used to analyze the aerodynamic enhancement effect of the propeller on the wing in the DHEPA, and a dynamics method is utilized to calculate the dynamics performance of the aircraft at several important stages. The results show that, compared with the reference aircraft, the lift of the DHEPA is increased by 46%. Under typical sectors, the DHEPA has a higher rate of climb and maximum leveling off speed at cruise, and a significantly lower fuel consumption. Full article

A novel distributed-vector-propulsion UAV (DVPUAV) is introduced in this paper, which has the capability of Vertical takeoff and landing (VTOL), and can realize relatively high-speed cruise. As the core of the DVPUAV, the propulsion wing designed under the guidance of the integration idea is not only a lifting body but also a propulsion device and a control mechanism. However, this kind of aircraft has a series of difficult problems with complex aero-propulsion coupling, flight modes switching, and so many inputs and control coupling. In order to describe this coupling effect to improve the accuracy of dynamics, an aero-propulsion coupling model is developed, considering both computation reliability and real-time. Afterward, a unique control framework is designed for the DVPUAV. By optimizing control logic, this control framework realizes the decoupling of longitudinal and lateral directional control and even the decoupling of roll and yaw control. Next, based on the Iterative linear quadratic regulator (ILQR), a new Model Predictive Control (MPC) controller with the ability to solve complex nonlinear problems is proposed which achieves the unification of the controller for the full flight envelope. Finally, the good performance of the control framework and controller is verified in the whole process of the flight simulation from take-off to landing. Full article

DPS (distributed propulsion system) utilizing BLI (boundary-layer ingestion) has shown great potential for reducing the power consumption of sustainable AAM (advanced air mobility), such as BWB (blended-wing body) aircraft. However, the ingesting boundary layer makes it easier for flow separation to occur within the S-shaped duct, and the consequent distortion due to flow separation can dramatically reduce the aerodynamic performance of the fan, which offsets the power-saving benefit of BLI. By analyzing the source of power saving and power loss of BLI, this paper presents the LDPS (layered distributed propulsion system) concept, in which the freestream flow and boundary-layer flow are ingested separately to improve the power-saving benefit of BLI. In order to preliminarily verify the feasibility of LDPS, an existing DPS is modified. The design parameters and the system performances of LDPS are studied using a 1D engine model. The results show that there is an optimal ratio of the FPR (fan pressure ratio) for the FSE (freestream engine) to the BLE (boundary-layer engine) that maximizes the PSC (power-saving coefficient) of LDPS. This optimal ratio of FPR for the two fans can be obtained when the exit velocities of FSE and BLE are the same. Under the optimal ratio of FPR for the two fans, the PSC of LDPS is improved by 5.83% compared to conventional DPS. Full article

On Distributed Electric Propulsion (DEP) aircraft, the deployment of numerous high-lift propellers with small diameters on the wing’s leading edge significantly enhances lift during low-speed flight. The increase in the number of propellers leads to a decrease in diameter, which increases the disc loading. In this paper, a rapid design method applicable to heavy-loaded propellers is developed and does not require iterative calculations compared to traditional heavy-loaded propeller design methods, enabling rapid completion of the propeller design. The results of CFD computation show that the relative thrust error of the method proposed in this paper is within 5% for disc loading ranging from 600 Pa to 1400 Pa, features a high-accuracy design of propellers with required thrust, and high thrust coefficients are achieved within large advance ratio range. Full article

The concept of the Fan Wing, a novel aircraft vector-force-integrated device that combines a power unit with a fixed wing to generate distributed lift and thrust by creating a low-pressure vortex on the wing’s surface, was studied. To investigate the unique propulsion mechanism of the Fan Wing, a Fan Wing test platform was developed, and experiments were conducted in a wind tunnel. At the same time, numerical simulations were established. In order to further improve the aerodynamic efficiency of the Fan Wing and decouple the control of lift and thrust, an improved scheme for the leading-edge structure of the Fan Wing was proposed, and a numerical analysis was conducted. A Fan Wing unmanned aerial vehicle (UAV) was designed and manufactured using the Fan Wing as the source of lift and thrust for the aircraft, and flight verification was conducted. The wind tunnel tests have proven that the main factors influencing the lift and thrust of the Fan Wing are rotation speed of cross flow fan, angle of attack, and incoming flow. The numerical analysis results of slotting on the leading edge show that the lift and thrust of the Fan Wing can be improved, but also the strength and position of the low-pressure vortices can be controlled. The results of flight tests show that the distributed lift and thrust of the Fan Wing can be directly applied to aircraft without the need for additional propulsion devices. In summary, the aerodynamic characteristics of the Fan Wing can be applied to electric short takeoff and landing (E-STOL) scenarios in urban air traffic. Full article

This study focused on designing a single-degree-of-freedom (1-DoF) mechanism emulating the wings of rock pigeons. Three wing models were created: one with REAL feathers from a pigeon, and the other two models with 3D-printed artificial remiges made using different strengths of material, PLA and PETG. Aerodynamic performance was assessed in a wind tunnel under both stationary (0 m/s) and cruising speed (16 m/s) with flapping frequencies from 3.0 to 6.0 Hz. The stiffness of remiges was examined through three-point bending tests. The artificial feathers made of PLA have greater rigidity than REAL feathers, while PETG, on the other hand, exhibits the weakest strength. At cruising speed, although the artificial feathers exhibit more noticeable feather splitting and more pronounced fluctuations in lift during the flapping process compared to REAL feathers due to the differences in weight and stiffness distribution, the PETG feathered wing showed the highest lift enhancement (28% of pigeon body weight), while the PLA feathered wing had high thrust but doubled drag, making them inefficient in cruising. The PETG feathered wing provided better propulsion efficiency than the REAL feathered wing. Despite their weight, artificial feathered wings outperformed REAL feathers in 1-DoF flapping motion. This study shows the potential for artificial feathers in improving the flight performance of Flapping Wing Micro Air Vehicles (FWMAVs). Full article
