Aluminum/magnesium (Al/Mg) hybrid structures are promising candidates for lightweight engineering, but reliable joining is still limited by brittle intermetallic compounds (IMCs), oxide films, pores, cracks, and corrosion-related degradation. This review summarizes recent advances in Al/Mg dissimilar-metal joining, including solid-state welding, fusion welding, brazing, resistance-based joining, and mechanical joining. Emphasis is placed on process characteristics, interfacial reactions, defect formation, mechanical properties, service reliability, and simulation-assisted process understanding. The reviewed studies indicate that joint reliability cannot be interpreted solely from IMC thickness; phase type, continuity, spatial distribution, interfacial morphology, and involvement in the fracture path are also critical. Solid-state and high-speed impact processes can restrict continuous Al–Mg reaction layers by reducing thermal exposure and promoting plastic contact, whereas fusion-based processes provide greater manufacturing flexibility but require stricter control of molten-pool behavior, Mg evaporation, porosity, and interlayer stability. Recent numerical simulations and data-driven studies are further discussed as tools for mechanism-guided parameter design. This review provides an integrated comparison of joining routes and highlights future needs for standardized testing, fatigue and corrosion evaluation, thermal-cycling assessment, coupled service-performance analysis, and process selection for engineering applications. Full article

The growing adoption of hybrid and plug-in electric vehicles increases heat generation in power electronic modules, driving demand for effective thermal management materials and reliable Al/Cu joining methods. However, large-area Al/Cu joints are challenging as conventional brazing requires high temperatures and flux, and fusion welding performs poorly with dissimilar metals. Contact-Reaction Brazing (CRB), which relies on eutectic-phase formation during heating, presents a promising alternative. Direct CRB of AA6063 and Cu might lead to severe aluminum dissolution above 570 °C. To mitigate this, large-area CRB of AA6063/Cu using a 4104 aluminum-foil interlayer is examined. Brazing temperature, holding time, and pressure are systematically varied to evaluate their influence on joint formation. Interfacial microstructures are characterized by SEM and XRD. Shear testing is used to assess fracture behavior and mechanical performance. A satisfactory shear strength of 48.8 MPa is achieved for the AA6063/AA4104/Cu joint under a brazing temperature of 540 °C, a holding time of 10 min, and an applied pressure of 600 Pa. Full article

The connection between dissimilar materials, Ti and steel, has been a focal point for global scholars. Establishing a high-strength bond between Ti alloy and stainless steel offers the potential to harness their respective advantages and reduce production costs, holding significant applications and far-reaching implications. Currently, non-transition welding methods for Ti/steel, primarily diffusion welding and vacuum brazing, have been pivotal in the early stages of development. Despite their simplicity and convenience, effectively avoiding the formation of brittle Ti–iron compounds in the weld seam, these methods face challenges such as unwelded defects, posing a risk to the reliability of welded structures under service conditions. This limitation restricts their application in products requiring high reliability. The evolving transition welding process, progressing from a single metal interface layer to a multi-metal interface layer, addresses some of the shortcomings of traditional Ti and steel connections, offering promising application prospects. This article delves into the core issue of selecting interface-layer elements and welding methods. Through an analysis of the metallurgical properties of transition metals in conjunction with Ti and steel, the study investigates the impact of single- or bimetallic elements, such as Cu, V, Nb, and Ni, on preparing interface-layer transition metals. A comprehensive review of existing research on Ti and steel welding is presented, with an emphasis on the metallurgical characteristics of their connection. The influence of element selection and welding processes on the metallurgical features and relevant mechanical properties of the weld metal is systematically analyzed and summarized. Full article

Friction stir welding (FSW) began as a fairly specialized joining method, but over the past three decades it has evolved into something considerably more versatile, a manufacturing platform that now handles complex multi-material assemblies and solid-state additive processes with reasonable reliability. This review follows this evolution, paying particular attention to friction stir additive manufacturing (FSAM) and the persistent difficulties that arise when joining dissimilar systems, such as aluminum to steel or metals to polymers, where the fate of the joint is largely decided by how well the intermetallic compounds are kept under control. Machine learning, artificial intelligence, and high-fidelity numerical models are reducing the reliance on trial-and-error that once dominated parameter selection and defect prediction, bringing FSW closer to the operating principles of Industry 4.0. Hybrid variants, including ultrasonically assisted and underwater FSW, also receive attention here, as they offer researchers finer control over heat generation and plastic flow than the standard process allows. Throughout the study, microstructural observations are directly connected to mechanical results, with the aim of analyzing the current state of solid-state manufacturing and identifying the questions that most urgently need answering. Full article

The Charpy impact resistance of monolithic high-strength and dissimilar structured steel was studied. A gas metal arc welding process was used to fabricate the structured steel by depositing a layer of austenitic stainless steel, followed by a layer of hardfacing material over the high-strength steel plate. ANSYS LS-DYNA^TM was used to simulate pendulum–striker impacts on steel Charpy samples. A Cowper–Symonds constitutive model was employed to capture the strain rate behavior. The corresponding material constitutive model parameters were obtained from the literature for the monolithic materials; an iterative numerical optimization method was used to couple the parameters of the structured steel simulation and experimental results. Numerical simulation results showed close agreement with experimental ones. Simulation is a valuable tool for explaining the fracture mechanism in the Charpy impact test and can be used to efficiently design parts made of structured steel that will be subjected to impacts or high-speed deformations. Full article

Bimetallic steel, as a layered composite material formed by metallurgically bonding two dissimilar metals, combines the excellent corrosion resistance of the cladding layer with the superior mechanical properties (such as high strength and toughness) of the base layer. It has been widely applied in demanding fields like marine engineering, the petrochemical industry, and energy equipment, where comprehensive material performance is critical. This paper provides a structured review of the research progress and application status of bimetallic steel. First, mainstream fabrication techniques, such as explosive welding and roll bonding, along with their effects on interfacial bonding quality, are analyzed. Subsequently, key material characteristics, including welding performance, mechanical properties, and corrosion behavior, are discussed. Furthermore, the component-level bearing performance and failure mechanisms under various loading conditions are evaluated. Finally, by synthesizing existing research, current knowledge gaps in areas like long-term service life assessment, adaptability to extreme environments, and efficient intelligent manufacturing are identified, and future development trends are outlined. This review provides important academic reference and engineering guidance for deepening the understanding of bimetallic steels and promoting their safer, more reliable, and cost-effective application in major engineering projects. Full article

Dissimilar 7075-T6 and 6061-T6 aluminum alloy joints were fabricated using pulsed metal inert gas (P-MIG) welding with ER5356 filler wire. The effects of welding current (224 A, 234 A, and 244 A) on macro-morphology, microstructure, mechanical properties, and corrosion behavior were systematically investigated. As welding current increased, the top and bottom reinforcements first increased and then decreased, reaching maximum values at 234 A, while the front weld width exhibited the opposite trend. The weld zone consisted of equiaxed and dendritic grains, with partial remelting of AlFeMnSi intermetallic compounds observed in the heat-affected zones. The microhardness and tensile strength of the joints followed a similar trend of first decreasing and then increasing with welding current, achieving a maximum tensile strength of 203.9 MPa at 244 A, corresponding to 89.5% of the 6061-T6 base metal strength. Corrosion resistance varied across regions depending on the evaluation method. In intergranular corrosion tests, the 7075-HAZ showed the highest susceptibility due to grain boundary segregation of Mg and Zn. In electrochemical tests, the WZ exhibited the poorest corrosion resistance. For the 7075-HAZ, optimal corrosion resistance was achieved at 234 A, attributed to a stable passive film and uniform precipitate distribution. These findings provide valuable guidance for optimizing P-MIG welding parameters for dissimilar 7075/6061 aluminum alloy joints. Full article

Welding is one of the key joining routes for expanding the engineering applications of dissimilar magnesium alloys. However, after experiencing rapid non-equilibrium heating and cooling cycles, the heat-affected zone (HAZ) of a welded joint tends to undergo grain coarsening as well as dissolution or agglomeration of precipitates, and therefore becomes the region most susceptible to failure. In this study, 3 mm thick sheets machined from AZ61A and AZ80A magnesium alloy hollow sections were joined by metal inert gas welding (MIG). Different ranges of welding heat input were obtained by combining multiple sets of welding parameters, in order to further tailor the HAZ of dissimilar magnesium alloy joints and achieve sound weld quality. The results showed that the joint exhibited the best overall mechanical performance at 523 J·mm⁻¹, with an ultimate tensile strength, yield strength, and elongation of 292 MPa, 172 MPa, and 5.4%, respectively. All fractures occurred in the HAZ on the AZ61A side. Under this condition, the second phases in the HAZ were more finely and uniformly dispersed, with a volume fraction of 3.19%, an average size of 2.51 μm, and a minimum average grain size of 23.65 μm. Full article

This review summarizes the base materials, joining methods, filler materials, and principal technical challenges in endoscope joining fabrication, and proposes practical strategies to improve joint reliability under clinical constraints. We conducted a comprehensive search in multiple databases, including Web of Science, Google Scholar, patent databases, Scopus databases, and Medline (via PubMed), for articles on the joining for precision endoscope fabrication, covering the period from 1950 to 2026. We employed the combinations of keywords, “endoscopy”, “minimally invasive surgery”, “welding”, “joining”, “sealing”, “soldering”, “bonding”, and “brazing”. Approximately 500 references were retrieved. After excluding duplicates and irrelevant studies, 158 publications met the inclusion criteria. Data on base materials, joining, processes, filler materials, and technical issues related to sterilization, corrosion, and microstructural evolution were extracted and analyzed. Endoscopes are multi-material systems, involving metallic biomaterials (stainless steels (SSs), titanium alloys, nickel-based alloys, etc.), optical functional materials (glass, sapphire, quartz, etc.), engineering plastics, ceramics, composite materials, and coatings. Joining, sealing, and functional integration have been achieved via adhesive bonding, laser soldering, laser brazing, wave soldering, reflow soldering, fusion welding, and other joining techniques. The main challenges include how to reliably join highly mismatched dissimilar materials, how to fabricate low-residual-stress joints, and how to increase the long-term resistance to sterilization-induced degradation and thermal aging over repeated 100–200 °C thermal cycles. Conventional joining techniques struggle to balance mechanical integrity, joint hermeticity, and long-term stability under such harsh cyclic conditions. The resulting joints may suffer surface yellowing, interfacial debonding, microcracking, delamination, or progressive property degradation during service. We propose the following three strategies to achieve reliable, low-residual-stress, and sterilization-resistant joining of dissimilar materials for endoscopes: (1) A synergistic design that combines thin-film engineering (including evaporation, sputtering, and electroplating) with silver anti-oxidation layers is proposed to reduce residual stresses and to enhance the joint hermeticity. (2) To develop principles for the selection of multi-joining processes to achieve the multi-material integration and functional assembly of dissimilar material components. (3) To develop the laser-based joining methods (fusion, brazing, or braze-welding) for precision control of heat input, bonding quality, and the least damage to the heat-sensitive components. Full article

Efficient joining of hard metals to steels is crucial for supporting sustainable manufacturing under emissions strategies to minimize CO₂. CoNiCrFeCu high-entropy alloy containing scandium (Sc) was designed as a filler for laser braze-welding of WC-Co and steel. The designed compositions with different Sc levels were melted and cast in a high-vacuum non-consumable arc furnace. The results showed that the as-cast microstructure was a complex mixture of a networked Ni₂Si, elongated Cr-Fe-Co solid-solution phase, and Fe-Ni-Co-Cu solid-solution phase. Scandium was shown to have formed compounds with nickel/cobalt and copper. The TG-DSC analysis confirmed that the melting points of the designed compositions were between 973.7 °C and 981.5 °C. The maximum spreading area of the CoNiCrFeCu-0.9Sc composition on AISI 1045 steel was 64.83 mm², and on the WC-Co cermet it was 78.63 mm². The interface between the fusion zone and AISI 1045 steel exhibited an epitaxial growth of dendrites from the steel base metal. The interface between WC-Co and the fusion zone exhibited a partial penetration of brazing filler into the Co matrix, forming a metallurgical bonding between the dissimilar materials. Sc, as an alloying element in the filler metal, enhanced the bond formation because it decreased the solidus temperature and increased wetting. Full article

For the failure issue of the weak part of the safety end of the nuclear power pressure vessel connection, the J-integral method was used to test the fracture toughness of the weak part at the bottom of the dissimilar metal welded joints (DMWJs) of SA508-III and 316L in the temperature range of 25 °C to 320 °C, and the mechanism of temperature-induced crack instability and propagation was studied. The research results indicate that at all test temperatures, the position of the weld near the 316L steel is the failure site of the welded joint. The fracture toughness of the joint decreases with increasing temperature, with a maximum decrease of 42.0%. Analysis shows that as the temperature increases, the dislocation density decreases, the tensile strength decreases, and the yield strength ratio decreases, making it easier for secondary cracks to initiate near the crack tip, thereby accelerating the unstable propagation of cracks. At the same time, as the temperature increases, the number of twin crystals that can promote crack turning and prolong the crack propagation path decreases, the energy absorbed before fracture decreases, and the fracture toughness value decreases accordingly, further accelerating the unstable propagation of cracks. Full article

Friction stir spot welding (FSSW) is a novel variant of Friction Stir welding (FSW), developed by Mazda Motors and Kawasaki Heavy Industries to join similar and dissimilar materials in a solid state. It is an economic and environmentally friendly alternative to resistance spot welding (RSW). The FSSW technique, however, includes some structural defects imbedded within the weld joint, such as keyhole formation, hook crack, and bond line oxidation challenging the joint strength. The unique properties of nanomaterials in the reinforcement of metal matrices motivated researchers to enhance the FSSW joints’ strength. Previous studies successfully fabricated nano-reinforced FSSW joints. At different volumetric ratios of nano-reinforcement, nanoparticles may agglomerate due to inefficient stirring of the welding tool pin, forming stress concentration sites and brittle phases, affecting tensile and fatigue strength under static and cyclic loading conditions, respectively. This work investigated how the welding tool pin affects stirring efficiency by controlling the distribution of a nano-reinforcing material within the joint stir zone (SZ), and thus the tensile and fatigue strength of the FSSW joints. Sheets of AA6061-T6 of 1.8 mm thickness were used as a base material. In addition, graphene nanoplatelets (GNPs) with lateral sizes of 1–10 µm and thicknesses of 3–9 nm were used as nano-reinforcements. GNP-reinforced FSSW specimens were prepared and successfully fabricated. Optical microscope (OM) and field emission scanning electron microscope (FE-SEM) methods were employed to visualize the GNPs’ incorporation into the SZs of the FSSW joints. Micrographs of as-welded specimens showed lower formations of scattered, clustered GNPs achieved by the threaded pin tool compared to continuous agglomerations observed when the cylindrical pin tool was used. Tensile test results revealed a significant improvement of about 30% exhibited by the threaded pin tool compared to the cylindrical pin tool, while fatigue test showed an improvement of 46–24% for the low- and high-cycle fatigue, respectively. Full article

The reliable joining of dissimilar stainless steel and carbon steel remains a critical challenge in Metal Inert Gas (MIG) welding due to complex thermal–metallurgical interactions and the formation of brittle phases at the weld interface. In this study, a Taguchi-based design of experiments was employed to systematically optimize MIG welding parameters for SUS201/S20C dissimilar joints using a SUS201 filler wire, with particular attention to the welding current, voltage, travel speed, and electrode stick-out. The welding process was performed using an automatic welding robot. Tensile specimens were tested on a universal testing machine. Microstructural analysis was performed using a metallurgical microscope. The microstructure reveals that the development of the carbon side’s large ferrite and the stainless steel side’s δ-ferrite both significantly degrade joint quality. Among all process parameters, electrode stick-out is identified as the most influential parameter governing both tensile and bending performance, highlighting a critical process sensitivity that has received limited attention in prior studies. Optimized parameter combinations are required to maximize tensile and flexural responses. The highest tensile strength is 450.96 MPa. These findings advance the understanding of parameter–microstructure–property relationships in dissimilar MIG welding. Future work applying numerical welding simulations and advanced evaluation techniques is recommended. Full article

Friction stir welding (FSW) was employed to achieve a reliable joining of 2 mm thick dissimilar metals, 6061 aluminum alloy and AZ31B magnesium alloy. This study revealed the evolution of interfacial interlocking features and their impact on the mechanical properties of the joints under different welding speeds (25–35 mm/min). The results indicate that the Al/Mg FSW joint interface exhibits a strip-like interlaced structure, the morphological characteristics of which are closely related to the welding speed. For quantitative analysis, the ratio of interlocking length to plate thickness (embedding ratio) was used as a quantitative indicator of the structural interlocking feature. As the welding speed increased from 25 mm/min to 35 mm/min, the embedding ratio decreased from 13.2 to 7.9, and the average thickness of the intermetallic compound (IMC) layer decreased from 2.71 μm to 2.19 μm. Transmission Electron Microscopy (TEM) results confirmed that the Al/Mg FSW joint interface consists of a bilayer of IMCs, specifically Al₃Mg₂ and Al₁₂Mg₁₇, with thicknesses of 220 nm and 470 nm, respectively. Tensile testing of joints with different embedding ratios demonstrated that the tensile strength of the welded joint exhibits a positive correlation with the embedding ratio, reaching a maximum of 178 MPa. Full article

Titanium alloys and copper have broad applications in aerospace, defense, and industry, but their dissimilar welding faces challenges from significant physicochemical differences and easy formation of brittle Ti-Cu intermetallic compounds, while existing methods like laser welding or friction stir welding have limitations, such as low strength or inability to weld ultra-thin plates. This study adopted cold welding to join Ti-6.5Al-1Mo-1V-2Zr alloy and 99.90% pure copper. The mechanical properties of the joint were tested, the microstructure and fracture of the weld were observed, and the phase composition of the weld was analyzed. The results show that the weld fusion zone mainly consists of Cu-based solid solution and Cu₃Ti. Low cold welding heat input reduces the Cu₃Ti content, so the joint mechanical properties do not decrease significantly. The tensile strength of the joint reaches 284 MPa, which is 83% of that of copper-based metals, and the elongation rate reaches 6.25%. Diffusion kinetics and solidification thermodynamics analyses confirm that Cu₃Ti intermetallic compounds are preferentially generated in the weld seam. Full article
