Search Results (143)

To address the problems of low crushing efficiency and uneven distribution in traditional straw crushing and returning machines for cotton stalk return operations in Xinjiang, a vertical straw crushing and returning machine with large and small dual-blade discs was designed, adapted to Xinjiang’s cotton planting model. The machine employs a differentiated configuration of large and small blade discs corresponding to four and two rows of cotton stalks, respectively, effectively reducing tool workload while significantly improving operational efficiency. A simulation model of the crushing and returning machine was developed using the discrete element method (DEM), and a flexible cotton stalk model was established to systematically investigate the effects of machine forward speed, crushing blade rotational speed, and knife tip-to-ground clearance on operational performance. Single-factor simulation experiments were conducted using crushing qualification rate and broken stalk drop rate as evaluation indicators. Subsequently, a multi-factor orthogonal field experiment was designed with Design-Expert software (13.0.1.0, Stat-Ease Inc, Minneapolis, MN, USA). The optimal working parameters were determined to be machine forward speed of 3.5 m/s, crushing blade shaft speed of 1500 r/min, and blade tip ground clearance of 60 mm. Verification tests demonstrated that under these optimal parameters, the straw crushing qualification rate reached 95.9% with a broken stalk drop rate of 15.5%. The relative errors were less than 5% compared to theoretical optimization values, confirming the reliability of parameter optimization. This study provides valuable references for the design optimization and engineering application of straw return machinery. Full article

To address the issue of surface glazing that occurs during prolonged polishing with gel tools, this study employs a triethanolamine (TEA)-based polishing fluid system to enhance the self-sharpening capability of the gel polishing disc. The inhibitory mechanism of TEA concentration on disc glazing is systematically analyzed, along with its impact on the gel disc’s frictional wear behaviour. Furthermore, the synergistic effects of process parameters on both surface quality and material removal rate (MRR) of SiC are examined. The results demonstrate that TEA concentration is a critical factor in regulating polishing performance. At an optimal concentration of 4 wt%, an ideal balance between chemical chelation and mechanical wear is achieved, effectively preventing glazing while avoiding excessive tool wear, thereby ensuring sustained self-sharpening capability and process stability. Through orthogonal experiment optimization, the best parameter combination for SiC polishing is determined: 4 wt% TEA concentration, 98 N polishing pressure, and 90 rpm rotational speed. This configuration delivers both superior surface quality and desirable MRR. Experimental data confirm that TEA significantly enhances the self-sharpening performance of gel discs through its unique complex reaction. During the rough polishing stage, the MRR increases by 34.9% to 0.85 μm/h, while the surface roughness S_a is reduced by 51.3% to 6.29 nm. After subsequent CMP fine polishing, an ultra-smooth surface with a final roughness of 2.33 nm is achieved. Full article

The precise measurement of crankshaft torsional vibration is critical for diesel engine reliability, yet it is often compromised by systematic errors from toothed disc runout. To address this challenge, this paper elucidates the dual mechanism of these errors, which manifest as micro-level voltage fluctuations in signal and macro-level time-domain deviations. Based on this understanding, a composite compensation method is proposed. First, a dual-line approximation method is presented for preprocessing the raw sensor signals, aiming to eliminate the distortion in rotational speed calculations caused by anomalous voltages. Second, a synchronous sampling scheme based on the differential measurement principle is developed. This scheme utilizes a symmetrically arranged dual-sensor structure to suppress runout errors and is combined with a time-domain feature reconstruction technique to restore the true rotational speed signal. Validation on a custom-built universal joint torsional vibration test rig demonstrates that the proposed method can effectively eliminate systematic deviations arising from toothed disc runout, thereby significantly enhancing the accuracy of torsional vibration measurements. The measurement method presented in this paper offers a valuable reference for the high-precision measurement of engine torsional vibration characteristics. Full article

Aiming at the existing fertilizer distributor’s lack of stability of fertilizer discharge and uniformity of fertilizer discharge, which affects the precise application of fertilizer, a design and testing of a multi-row spiral quantitative fertilizer distributor was designed. The design principle and working principle of the fertilizer distributor are described, and the parameter ranges of centrifugal cone discs’ cone angle, cone disc inclination, cone disc rotation speed, etc., are determined. The Elementary Discrete Element Method (Referred to as EDEM in the following) simulation analysis software was adopted to carry out the simulation analysis of the fertilizer discharge process of the fertilizer discharger, to study the influence of each parameter on the fertilizer discharge performance and the optimal combination parameters of the fertilizer discharger. Taking the coefficient of variation for the consistency of fertilizer application amount among rows and the coefficient of variation for the consistency of fertilizer application amount within the same row as the evaluation indicators, and taking the cone angle of the centrifugal cone disk, the cone disk inclination angle, and the cone disk rotational speed as the test factors, multi-factor and multi-level experiments were carried out. The simulation test results show that the optimal parameter combination of the fertilizer discharger is the rotational speed of the centrifugal cone disk at 95 r/min, the cone angle of the cone disk at 16.7°, and the blade inclination angle of the cone disk at 2.7°. Using potassium sulphate compound fertilizer as the test material, the bench test on the fertilizer discharge performance and adaptability of the fertilizer distributor when the speed of centrifugal cone discs was 30~110 r/min was carried out to verify the fertilizer discharge performance of the fertilizer distributor. The results of the validation test showed that the coefficient of variation for the consistency of fertilizer application amount among rows of fertilizer distributor at different rotational speeds was lower than 4.25%, the coefficient of variation for the consistency of fertilizer application amount within the same row was lower than 3.21%, which meets the requirement of fertilizer discharge quality. The research provides technical support for enhancing the performance of fertilizer distributors and achieving precise fertilizer application, thereby playing an active role in improving fertilization efficiency and promoting sustainable agricultural development. Full article

This study investigates the tribo-mechanical properties of a modified Cu-Cr-Zr alloy with nickel addition, aimed at enhancing its suitability as a resistance spot welding (RSW) electrode material. Two alloy compositions, designated as Sample A (Cu-0.871%Cr-0.156%Zr) and Sample B (modified with 8.94% Ni), were prepared. Microstructural examination revealed a coarse, mixed equiaxed–columnar grain structure in Sample A, while Sample B exhibited a refined dendritic morphology of about 50 μm PDAS, due to nickel-induced solute partitioning, improving microhardness from 72.763 HV to 83.981 HV. The wear behavior was evaluated using a pin-on-disc tribometer with a full factorial design, assessing the effects of rotational speed, load, and time on mass loss and surface roughness. Sample A exhibited increased mass loss and roughness with higher loads and speeds, indicating severe wear. In contrast, Sample B showed reduced mass loss and roughness at higher loads, suggesting a polishing effect from plastic deformation. Design of experiments analysis identified load as the dominant factor for mass loss in Sample A, with speed primarily affecting roughness, while in Sample B, load negatively influenced both responses, with speed–time interactions being significant. These findings highlight the nickel-modified alloy’s superior wear resistance and hardness, making it a promising candidate for RSW electrodes in high-production environments. Full article

To address the inefficiency and high cost of manual potato pickup in segmented harvesting, a dual-disc potato pickup and harvesting device was designed. The device utilizes counter-rotating dual discs to gather and preliminarily lift the potato–soil mixture, and combines it with an elevator chain to achieve potato–soil separation and transportation. Based on Hertz’s collision theory, the impact of disc rotational speed on potato damage was analyzed, establishing a maximum speed limit (≤62.56 r/min). Through kinematic analysis, the disc inclination angle (12–24°) and operational parameters were optimized. Through coupled EDEM-RecurDyn simulations and Box–Behnken experimental design, the optimal parameter combination was determined with the potato loss rate and potato damage rate as evaluation indices: disc rotational speed of 50 r/min, disc inclination angle of 16°, and machine forward speed of 0.6 m/s. Field validation tests revealed that the potato loss rate and potato damage rate were 1.53% and 2.45%, respectively, meeting the requirements of the DB64/T 1795-2021 standard. The research findings demonstrate that this device can efficiently replace manual potato picking, providing a reliable solution for the mechanized harvesting of potatoes. Full article

The resource utilization of marine-dredged sediment is considered a sustainable approach to its disposal. This paper investigates the preparation of non-sintered ceramsites from marine-dredged sediments and CSA cement via cold-bonded pelletization. The study examines the effects of various preparation conditions on the engineering properties, phase compositions and microstructures of non-sintered ceramsites. The results indicate that preparation conditions significantly influence the particle size distribution of non-sintered ceramsites. The early-strength development of non-sintered ceramsites prepared from CSA cement is remarkable, with the PCS achieving approximately 60% and 80% of the 28-day strength within 3 days and 7 days, respectively—a marked contrast to OPC. Response surface methodology analysis reveals significant interaction effects between the disc rotation angle, rotational speed, and duration of rotation on the PCS of non-sintered ceramsites. The open-ended porosity of non-sintered ceramsites exhibits greater sensitivity to changes in preparation parameters compared to closed-ended porosity and total porosity. The preparation conditions have negligible impact on the hydration process of CSA cement in non-sintered ceramsites. For both ellipsoidal and plate-like marine-dredged soil particles, ettringite and the AH₃ phase provide effective pore-filling and binding effects in the microstructures of non-sintered ceramsites. These findings imply that low-carbon utilization of marine-dredged sediments through the preparation of non-sintered ceramsites offers a nature-based solution for sustainable management in coastal systems. Full article

To address practical issues, such as uneven fertilizer distribution and poor particle dispersion, during the operation of a centrifugal double-disc fertilizer spreader, a discrete element method (DEM) simulation was initially performed. In this simulation, the blade inclination angle, fertilizer discharge offset angle, and spreading height were selected as experimental factors. The spreading width and the coefficient of variation (C_v) of fertilizer uniformity served as evaluation indicators. A quadratic orthogonal simulation experiment was designed to evaluate spreading performance. Subsequently, regression equations were established to optimize parameters and determine the optimal design configuration. Experimental results showed optimal performance with a blade inclination angle of −5°, fertilizer discharge offset angle of 45°, spreading height of 1050 mm, and disc rotational speed of 400 rpm. Considering that fertilizer spreaders are susceptible to air resistance and environmental wind during field operations, an EDEM-CFD coupling method was employed to simulate realistic operating conditions. Virtual simulation results demonstrated optimal fertilizer spreading performance at disc rotational speeds ranging from 350 to 400 rpm under tailwind conditions, and from 400 to 500 rpm under headwind conditions. Based on the simulation results, a prototype was built and tested. The experimental results closely matched the simulation predictions, thereby confirming the effectiveness of the simulation model. This study provides valuable insights and serves as a reference for designing and optimizing fertilizer spreader performance under practical operational conditions. Full article

In response to the low efficiency and poor soil quality of the mechanized transplanting of Astragalus, and in combination with the agronomic requirements of Astragalus mulching and outcrop cultivation, an Astragalus film mulching transplanting machine was designed, which integrates functions such as trenching, seedling feeding, mulching, and seed row soil covering. Firstly, based on the analysis of the overall structure of the transplanting machine, the structure and working principle of the soil-covering device are expounded, and the structure and working parameters of the soil-covering disc and soil-covering drum are clarified. In order to optimize the performance of the soil-covering device of the mulching transplanting machine and improve the quality of the covering soil, the Box–Behnken response surface test design method was adopted. The depth of disc extraction, the disc deflection angle, and the rotation speed of the soil-covering drum were selected as the main influencing factors. The quantity of soil cover and variation coefficient of soil cover quantity uniformity were used as the evaluation indicators for the quality of the operation, and parameter optimization experiments were conducted. By establishing a regression mathematical model between influencing factors and evaluation indicators, analyzing the interactive effects of each factor on response values, and comprehensively optimizing the model, the optimal parameter combination was obtained. The results of field experiments show that when the depth of disc extraction is 95 mm, the disc deviation angle is 40°, and the rotation speed of the soil-covering drum is 30 r/min, the corresponding quantity of soil cover and variation coefficient of soil cover quantity uniformity are 10.61 kg/m and 1.79%, respectively, which can meet the soil covering requirements. The research results can provide technical references for the structural optimization and performance improvement of the soil-covering device of the traditional Chinese medicine mulching transplanting machine. Full article

This paper investigates how the torsional load affects two vibration-based unbalance fault indicators. This investigation is important for unbalance fault diagnosis in multiple constant load conditions, which are unavoidable for many rotating machines. Coupled flexural–torsional dynamics of an unbalanced disc–shaft system, as the representative of an induction motor, is investigated via a continuous shaft–beam model. Numerical investigations reveal that the fundamental rotating intensity of the transversal acceleration is independent of the torsional load. So, the novel speed-invariant version of this indicator, which is obtained by normalizing the fundamental rotating intensity by the fourth power of the rotational speed, is also load-independent. The comprehensive experimental trials confirm load-independency of the considered two unbalance fault indicators. The important novel outcome is that, by conducting numerical analysis and comprehensive experimental trials with a belt conveyor system under various constant loading conditions, the load-independency of the fundamental rotating harmonic intensity as well as novel speed-invariant unbalance feature are justified. Full article

Pneumatic polishing tools are commonly used in traditional robot mold polishing systems, but they have problems with the stable control of mold surface roughness due to low precision and poor adaptability in polishing force adjustment. The integration of an adaptive hydraulic polishing (AHP) tool and robot system effectively solves the above problems, providing a robust solution for the high-precision polishing of various molds. This study systematically investigates the robotic polishing of NAK80 mold steel using an AHP-equipped robotic platform with 3M abrasive discs of progressively refined grit sizes (P180, P400, P800). Through single-factor experiments and response surface methodology, the effects of polishing force, rotational speed, and feeding speed on surface roughness were quantitatively analyzed. The relationship between surface roughness and the polishing parameters was derived to elucidate the roughness evolution before and after over-polishing. Orthogonal experiments combined with range analysis identified optimal parameter combinations for P180 (20 N polishing force, 5000 RPM rotational speed, and 5 mm·s⁻¹ feeding speed) and P400 abrasives (10 N polishing force, 4000 RPM rotational speed, and 5 mm·s⁻¹ feeding speed), achieving minimum surface roughness values of 0.08 µm and 0.044 µm, respectively. For P800 abrasives, a central composite design was used to develop a roughness prediction model with a ≤7.14% relative error, and the optimal parameters are a 20 N polishing force, a 5000 RPM rotational speed, and a 5 mm·s⁻¹ feeding speed. The sequential application of the optimized parameters across all the grit sizes can reduce the surface roughness from an initial 0.4 µm to a final 0.017 µm, representing a 95.75% improvement in the surface finish. Full article

Magnetorheological–chemical-polishing tests are carried out on single-crystal silicon carbide (SiC) to study the influence of the process parameters on the polishing effect, predict the polishing results via a back propagation (BP) neural network, and construct a model of the processing parameters to predict the material removal rate (MRR) and surface quality. Magnetorheological–chemical polishing employs mechanical removal coupled with chemical action, and the synergistic effect of both actions can achieve an improved polishing effect. The results show that with increasing abrasive particle size, hydrogen peroxide concentration, workpiece rotational speed, and polishing disc rotational speed, the MRR first increases and then decreases. With an increasing abrasive concentration and carbonyl iron powder concentration, the MRR continues to increase. With an increasing machining gap, the MRR shows a continuous decrease, and the corresponding changes in surface roughness tend to decrease first and then increase. The prediction models of the MRR and surface quality are constructed via a BP neural network, and their average absolute percentage errors are less than 2%, which is important for the online monitoring of processing and process optimisation. Full article

This paper presents, for the first time, a rotary actuator functionalized by an inclined disc rotor that serves as a distal optical scanner for endoscopic probes, enabling side-viewing endoscopy in luminal organs using different imaging/analytic modalities such as optical coherence tomography and Raman spectroscopy. This scanner uses a magnetic rotor designed to have a mirror surface on its backside, being electromagnetically driven to roll around the cone-shaped hollow base to create a motion just like a precessing coin. An optical probing beam directed from the probe’s optic fiber is passed through the hollow cone to be incident and bent on the back mirror of the rotating inclined rotor, circulating the probing beam around the scanner for full 360° sideway imaging. This new scanner architecture removes the need for a separate prism mirror and holding mechanics to drastically simplify the scanner design and thus, potentially enhancing device miniaturization and reliability. The first proof-of-concept is developed using 3D printing and experimentally analyzed to reveal the ability of both angular stepping at 45° and high-speed rotation up to 1500 rpm within the biologically safe temperature range, a key function for multimodal imaging. Preliminary optical testing demonstrates continuous circumferential scanning of the laser beam with no blind spot caused by power leads to the actuator. The results indicate the fundamental feasibility of the developed actuator as an endoscopic distal scanner, a significant step to further development toward advancing optical endoscope technology. Full article

During high-speed corn sowing at 10 km/h, the rapid seed discharge resulting from the high rotation speed of the seed disc escalates the impact force of seeds as they are released from the seed metering device into the seed guiding apparatus, consequently diminishing the overall seeding efficiency of the seeder. This study employed high-speed videography to conduct experiments and optimize parameters for the seed-receiving mechanism of a belt-driven seed guide tube. By changing the clamping wheel speed and seed-receiving angle, the speed change curve and displacement trajectory of seeds under different conditions were obtained and analyzed. The findings demonstrate that the seed speed fluctuation is more stable, and the seed displacement trajectory achieves greater stability at a clamping wheel speed of 560 r·min⁻¹. When the seed-receiving angle is set at 85°, the seed speed fluctuation becomes less apparent, resulting in a smoother seed displacement trajectory. Finally, the experimental results of high-speed cameras are confirmed by field tests. The findings of this study can act as a theoretical basis for the further optimization of the experimental belt-driven seed guide tube. Full article

Due to the dense crop residue in the Huang-Huai-Hai region, challenges such as large resistance, increased power consumption, and straw backfilling arise in the process of no-till seeding under the high-speed operations. This paper presents the design of a straw treatment device to address these issues. The cutting edge of a straw-cutting disc is optimized using an involute curve, and the key structural parameters of the device are designed by analyzing the process of stubble cutting and clearing. In this study, the Discrete Element Method (DEM) was employed to construct models of compacted soil and hollow, flexible wheat straw, forming the foundation for a comprehensive interaction model between the tool, soil, and straw. Key experimental variables, including working speed, rotation speed, and installation centre distance, were selected. The power consumption of the straw-cutting disc (PCD) and the straw-clearing rate (SCR) were used as evaluation metrics. Response surface methodology was applied to develop regression models linking the experimental factors with the evaluation indexes using Design-Expert 12 software. Statistical significance was assessed through ANOVA (p < 0.05), and factor interactions were analyzed via response surface analysis. The optimal operational parameters were found to be a working speed of 14 km/h, a rotation speed of 339.2 rpm, and an installation centre distance of 100 cm. Simulation results closely matched the predicted values, with errors of 1.59% for SCR and 9.68% for PCD. Field validation showed an SCR of 86.12%, improved machine passability, and favourable seedling emergence. This research provides valuable insights for further parameter optimization and component development. Full article
