Search Results (45)

Objective: Previous studies of deep brain stimulation-related (DBS) artifacts in magnetoencephalography (MEG) have largely focused on the sensor level. In contrast, far less is known about their effects at the source level, where neuroscientific interpretations are typically derived. This study aims to quantify how DBS artifacts distort source-level MEG imaging. Methods: The study used a phantom-based experimental setup to assess dipole-fitting accuracy while systematically varying the stimulation amplitude, DBS electrode configuration, and the distance between the dipole and the DBS electrode. Results: Dipole location, angle, and amplitude errors remained within modest ranges, with the largest location and angle errors occurring at 5 mA ring-electrode stimulation (6.19 mm and 8.31 deg, respectively) and the largest amplitude errors at 15 mA ring electrodes (13.05 nAm). Location and angle errors increased significantly as the dipole moved closer to the DBS electrode, while amplitude error showed no such relationship. Continuous head position indicator coil signal quality remained stable and reliable at DBS on condition, compared to DBS off. Conclusions: The stimulation itself does not significantly impair MEG dipole estimation, as fitting errors are similar with DBS on and off. The study introduces a quantitative framework to systematically assess DBS-related distortion via dipole-fitting error, which can also be extended to evaluate noise from other implanted or external devices. Full article

Following the persistent evolution of terrestrial 5G wireless systems, a new field of underwater communication has emerged for various related applications like environmental monitoring, underwater mining, and marine research. However, establishing reliable high-speed underwater networks remains notoriously difficult due to the severe RF attenuation in conductive seawater, which strictly limits range coverage. In this article, we focus on a comprehensive review of different antenna types for future underwater communication and sensing systems, evaluating their performance and suitability for Autonomous Underwater Vehicles (AUVs). We critically examine and compare distinct antenna technologies, including Magnetic Induction (MI) coils, electrically short dipoles, wideband traveling wave antennas, printed planar antennas, and novel magnetoelectric (ME) resonators. Specifically, these antennas are compared in terms of physical footprint, operating frequency, bandwidth, and realized gain, revealing the trade-offs between miniaturization and radiation efficiency. Our analysis aims to identify the benefits and weaknesses of the different antenna types while emphasizing the necessity of innovative antenna designs to overcome the fundamental propagation limits of the underwater channel. Full article

Accurate co-registration between on-scalp Optically Pumped Magnetometer (OPM)–Magnetoencephalography (MEG) sensors and anatomical Magnetic Resonance Imaging (MRI) remains a critical bottleneck restricting the spatial fidelity of source localization. Optical Scanning Image (OSI) methods can provide high spatial accuracy but depend on surface visibility and cannot directly determine the internal sensitive point of each OPM sensor. Coil-based magnetic dipole localization, in contrast, targets the sensor’s internal sensitive volume and is robust to occlusion, yet its accuracy is affected by coil fabrication imperfections and the validity of the dipole approximation. To integrate the complementary advantages of both approaches, we propose a hybrid co-registration framework that combines Rigid Coil Structures (RCS), magnetic dipole-based sensor localization, and optical orientation constraints. A complete multi-stage co-registration pipeline is established through a unified mathematical formulation, including MRI–OSI alignment, OSI–RCS transformation, and final RCS–sensor localization. Systematic simulations are conducted to evaluate the accuracy of the magnetic dipole approximation for both cylindrical helical coils and planar single-turn coils. The results quantify how wire diameter, coil radius, and turn number influence dipole model fidelity and offer practical guidelines for coil design. Experiments using 18 coils and 11 single-axis OPMs demonstrate positional accuracy of a few millimeters, and optical orientation priors suppress dipole-only orientation ambiguity in unstable channels. To improve the stability of sensor orientation estimation, optical scanning of surface markers is incorporated as a soft constraint, yielding substantial improvements for channels that exhibit unstable results under dipole-only optimization. Overall, the proposed hybrid framework demonstrates the feasibility of combining magnetic and optical information for robust OPM–MEG co-registration. Full article

High-precision sensor co-registration is a critical prerequisite for achieving high-resolution imaging in Optically Pumped Magnetometer–Magnetoencephalography (OPM-MEG) systems. The conventional magnetic dipole fitting method, essentially a multipole expansion approximation of a finite-size coil, exhibits accuracy that strongly depends on spatial geometric factors such as coil–sensor distance, dipole orientation, and the projection angle of the sensor’s sensitive axis. Moreover, the approximation error increases significantly when sensors are placed either too close to the coils or at an unfavorable angular coupling. To address this issue, we propose a sensor localization and orientation method that combines magnetic dipole-equivalent modeling with a rigid coil structure (RCS). The RCS provides stable geometric constraints and eliminates uncertainties introduced by scalp-attached coils. In addition, three objective functions (the standard Frobenius norm, a weighted Frobenius norm and the structural similarity index (SSIM)) are formulated to mitigate the imbalance caused by near-field strong signals and to improve stability under noise and error propagation. Simulation results demonstrate that both under ideal conditions and with assembly perturbations, the weighted Frobenius norm and SSIM methods consistently achieve position errors below 1 mm and orientation errors below 1°, which effectively suppress large outlier deviations and achieve better performance than the standard Frobenius norm. The results confirm the effectiveness of the proposed method in achieving both high accuracy and robustness. Beyond clarifying the primary factors influencing magnetic dipole approximation errors, this study provides a geometry-constrained and optimization-based framework, offering a feasible pathway toward the practical implementation of high-precision, multi-channel OPM-MEG systems. Full article

Based on the magnetic configuration of the China Astro-Torus-1 (CAT-1) levitated dipole device, this study investigated the confinement performance of common discharge gas ions under E × B transverse transport conditions induced by electric fields. By adjusting L-coil parameters to shift the inject location, it was found that when the loss boundary is in the outer weak-field region, most particles with large Larmor radii are lost after colliding with the wall, for particles with large pitch angles, the strongly anisotropic magnetic field causes particles across a broad range of energies to be lost through the X-point into the divertor. The study demonstrates that for particle kinetic energies between 100 and 300 eV, the CAT-1 device exhibits a loss cone angle θ_loss of approximately 58°, indicating favorable confinement performance. Full article

In particle physics experiments, fragment separators utilize dipole magnets to distinguish and isolate specific isotopes based on their mass-to-charge ratio as particles traverse the dipole’s magnetic field. Accurate fragment selection relies on precise knowledge of the magnetic field generated by the dipole magnets, necessitating dedicated measurement instrumentation to characterize the field in the constructed magnets. This study presents measurements of the two first-of-series dipole magnets (Type II—11 degrees bending angle—and Type III—9.5 degrees bending angle) for the Superconducting Fragment Separator that is being built in Darmstadt, Germany. Stringent field quality requirements necessitated a novel measurement system—the so-called translating fluxmeter. It is based on a PCB coil array installed on a moving trolley that scans the field while passing through the magnet aperture. While previous publications have discussed the design of the moving fluxmeter and the characterization of its components, this article presents the results of a measurement campaign conducted using the new system. The testing campaign was supplemented with conventional methods, including integral field measurements using a single stretched wire system and three-dimensional field mapping with a Hall probe. We provide an overview of the working principle of the translating fluxmeter system and validate its performance by comparing the results with those obtained using conventional magnetic measurement methods. Full article

In vivo phosphorus-31 (³¹P) magnetic resonance spectroscopy (MRS) imaging (MRSI) is an important non-invasive imaging tool for studying cerebral energy metabolism, intracellular nicotinamide adenine dinucleotide (NAD) and redox ratio, and mitochondrial function. However, it is challenging to achieve high signal-to-noise ratio (SNR) ³¹P MRS/MRSI results owing to low phosphorus metabolites concentration and low phosphorous gyromagnetic ratio ($\gamma$). Many works have demonstrated that ultrahigh field (UHF) could significantly improve the ³¹P-MRS SNR. However, there is a lack of studies of the ³¹P MRSI SNR in the 10.5 Tesla (T) human scanner. In this study, we designed and constructed a novel ³¹P-¹H dual-frequency loop-dipole probe that can operate at both 7T and 10.5T for a quantitative comparison of ³¹P MRSI SNR between the two magnetic fields, taking into account the RF coil B₁ fields (RF coil receive and transmit fields) and relaxation times. We found that the SNR of the ³¹P MRS signal is 1.5 times higher at 10.5T as compared to 7T, and the power dependence of SNR on magnetic field strength (B₀) is 1.9. Full article

In order to introduce the magnetic field into micro electrical machining technology to explore the influence of magnetic field on micro electrical machining, the development of a precision controllable magnetic field-assisted platform is particularly important. This platform needs to precisely control the spatial magnetic field. This study first completes the hardware design and construction of the magnetic field generation device, using electromagnetic coils with soft iron cores as the sources of the magnetic field. Mathematical models of the magnetic field are established and calibrated. Since the magnetic dipole model cannot effectively describe the magnetic field generated by the electromagnetic coil, this study adopts a more precise description method: the spherical harmonic function expansion model and the magnetic multipole superposition model. The calibration of the magnetic field model is based on actual excitation magnetic field data, so a magnetic field sampling device is designed to obtain the excitation magnetic field of the workspace. The model is calibrated based on a combination of the theoretical model and magnetic field data, and the performance of the constructed setup is analyzed. Finally, a magnetic field-assisted platform has been developed which can generate magnetic fields in any direction within the workspace with intensities ranging from 0 to 0.2 T. Its magnetic field model arrives at an error percentage of 2.986%, a variance of 0.9977, and a root mean square error (RMSE) of 0.71 mT, achieving precise control of the magnetic field in the workspace. Full article

In synchrotrons, accurate knowledge of the magnetic field generated by bending dipole magnets is essential to ensure beam stability. Measurement campaigns are necessary to characterize the field. The choice of the measurement method for such campaigns is determined by the combination of magnet dimensions and operating conditions and typically require a trade-off between accuracy and versatility. The single stretched wire (SSW) is a well-known, polyvalent method to measure the integral field of magnets having a wide range of geometries. It, however, requires steady-state excitation. This work presents a novel implementation of this method called pulsed SSW, which allows the system to measure rapidly time-varying magnetic fields, as is often needed, to save power or gain beam time. We first introduce the measurement principle of the pulsed SSW, followed by a combined strategy to calculate the absolute magnetic field by incorporating the classic DC SSW method. Using a bending magnet from the Proton Synchrotron Booster located at the European Organization for Nuclear Research as a case study, we validate the pulsed SSW method and compare its dynamic measurement capabilities to a fixed induction coil, showing thereby how the coil calibration must be adjusted according to the field level. Finally, we assess the method’s measurement accuracy using the standard SSW as a reference and present an analysis of the primary noise contributors. Full article

Coils are one of the basic elements employed in devices. They are versatile, in terms of both design and manufacturing, according to the desired inductive specifications. An important characteristic of coils is their bidirectional action; they can both produce and sense magnetic fields. Referring to sensing, coils have the unique property to inductively translate the temporal variation of magnetic flux into an AC voltage signal. Due to this property, they are massively used in many areas of science and engineering; among other disciplines, coils are employed in physics/materials science, geophysics, industry, aerospace and healthcare. Here, we present detailed and exact mathematical modeling of the sensing ability of the three most basic scalar assemblies of coaxial pick-up coils (PUCs): in the so-called zero derivative configuration (ZDC), having a single PUC; the first derivative configuration (FDC), having two PUCs; and second derivative configuration (SDC), having four PUCs. These three basic assemblies are mathematically modeled for a reference case of physics; we tackle the AC voltage signal, V_AC (t), induced at the output of the PUCs by the temporal variation of the magnetic flux, Φ(t), originating from the time-varying moment, m(t), of an ideal magnetic dipole. Detailed and exact mathematical modeling, with only minor assumptions/approximations, enabled us to obtain the so-called sensing function, F_SF, for all three cases: ZDC, FDC and SDC. By definition, the sensing function, ${\mathrm{F}}_{\mathrm{S}\mathrm{F}}$, quantifies the ability of an assembly of PUCs to translate the time-varying moment, m(t), into an AC signal, V_AC (t). Importantly, the ${\mathrm{F}}_{\mathrm{S}\mathrm{F}}$ is obtained in a closed-form expression for all three cases, ZDC, FDC and SDC, that depends on the realistic, macroscopic characteristics of each PUC (i.e., number of turns, length, inner and outer radius) and of the entire assembly in general (i.e., relative position of PUCs). The mathematical methodology presented here is complete and flexible so that it can be easily utilized in many disciplines of science and engineering. Full article

The behavior of polyzwitterions, constituted by dipole-like zwitterionic monomers, is significantly different from that of uniformly charged polyelectrolytes. The origin of this difference lies in the intrinsic capacity of polyzwitterions to self-associate intramolecularly and associate with interpenetrating chains driven by dominant dipolar interactions. Earlier attempts to treat polyzwitterions implicitly assume that the dipoles of zwitterion monomers are randomly oriented. At ambient temperatures, the dipolar zwitterion monomers can readily align with each other generating quadrupoles and other multipoles and thus generating heterogeneous structures even in homogeneous solutions. Towards an attempt to understand the role of such dipolar associations, we present a mean field theory of solutions of polyzwitterions. Generally, we delineate a high-temperature regime where the zwitterion dipoles are randomly oriented from a low-temperature regime where quadrupole formation is significantly prevalent. We present closed-form formulas for: (1) Coil-globule transition in the low-temperature regime, the anti-polyelectrolyte effect of chain expansion upon addition of low molar mass salt, and chain relaxation times in dilute solutions. (2) Spontaneous formation of a mesomorphic state at the borderline between the high-temperature and low-temperature regimes and its characteristics. A universal law is presented for the radius of gyration of the microgel, as a proportionality to one-sixth power of the polymer concentration. (3) Swelling equilibrium of chemically cross-linked polyzwitterion gels in both the high temperature and low-temperature regimes. Addressing the hierarchical internal dynamics of polyzwitterion gels, we present a general stretched exponential law for the time-correlation function of gel displacement vector, that can be measured in dynamic light scattering experiments. The present theory is of direct experimental relevance and additional theoretical developments to all polyzwitterion systems, and generally to biological macromolecular systems such as intrinsically disordered proteins. Full article

Combining proton and phosphorus magnetic resonance spectroscopy offers a unique opportunity to study the oxidative and glycolytic components of metabolism in working muscle. This paper presents a 7 T proton calf coil design that combines dipole and loop elements to achieve the high performance necessary for detecting metabolites with low abundance and restricted visibility, specifically lactate, while including the option of adding a phosphorus array. We investigated the transmit, receive, and parallel imaging performance of three transceiver dipoles with six pair-wise overlap-decoupled standard or twisted pair receive-only coils. With a higher SNR and more efficient transmission decoupling, standard loops outperformed twisted pair coils. The dipoles with standard loops provided a four-fold-higher image SNR than a multinuclear reference coil comprising two proton channels and 32% more than a commercially available 28-channel proton knee coil. The setup enabled up to three-fold acceleration in the right–left direction, with acceptable g-factors and no visible aliasing artefacts. Spectroscopic phantom measurements revealed a higher spectral SNR for lactate with the developed setup than with either reference coil and fewer restrictions in voxel placement due to improved transmit homogeneity. This paper presents a new use case for dipoles and highlights their advantages for the integration in multinuclear calf coils. Full article

This paper proposes a reactive shield structure to reduce the leakage magnetic field of a wireless power transfer (WPT) system with a dipole coil structure. The reactive shield resonates at a frequency lower than that of the WPT system and operates in an inductive region where the reactance is positive. Therefore, the magnetic field generated by the shield coil is 180° different in phase from that generated by the transmitting coil, resulting in an effective reduction in the leakage magnetic field. The methodology for designing the reactive shield for the dipole coil structure is mathematically analyzed, and the current and magnetic field phases are compared. Its effectiveness has been validated through simulations and experiments. Specifically, the proposed method is validated through a 50 W class WPT experiment, which showed that the proposed shielding structure achieves efficiency reductions ranging from 0.3% to 1.5% and has a leakage magnetic field reduction effect of up to 67% compared to the comparison groups. Full article

It is crucial to demonstrate a robust correlation between the simulated and manufactured parallel-transmit (pTx) arrays performances to release the currently-used, very restrictive safety margins. In this study, we describe the qualitative and quantitative validation of a simulation model with respect to experimental results for an 8-channel dipole array at 7T. An approach that includes the radiofrequency losses into the simulation model is presented and compared to simulation models neglecting these losses. Simulated S-matrices and individual B1+-field maps were compared with experimentally measured quantities. With the proposed approach, an average relative difference of ~1.1% was found between simulated and experimental reflection coefficients, ~4.2% for the 1st coupling terms, and ~9.4% for the 2nd coupling terms. A maximum normalized root-mean-square error of 4.8% was achieved between experimental and simulated individual B1+-field maps. The effectiveness of the simulation model to accurately predict the B1+-field patterns was assessed, qualitatively and quantitatively, through a comparison with experimental data. We conclude that, using the proposed model for radiofrequency losses, a robust correlation is achieved between simulated and experimental data using the 8-channel dipole array at 7T. Full article

Metamaterial-based designs in ultra-high field (≥7 T) MRI have the promise of increasing the local magnetic resonance imaging (MRI) signal and potentially even the global efficiency of both the radiofrequency (RF) transmit and receive resonators. A recently proposed metamaterial-like structure—comprised of a high-permittivity dielectric material and a set of evenly distributed copper strips—indeed resulted in a local increase in RF transmission. Here, we demonstrate that non-uniform designs of this metamaterial-like structure can be used to boost the ultimate RF field distribution. A non-uniform dielectric distribution can yield longer electric dipoles, thus extending the RF transmit field coverage. A non-uniform distribution of conducting strips enables the tailoring of the local electric field hot spots, where a concave distribution resulted in lower power deposition. Simulations of the brain and calf regions using our new metamaterial-like design, which combines non-uniform distributions of both the dielectric and conducting strips, revealed a 1.4-fold increase in the RF field coverage compared to the uniform distribution, and a 1.5–2-fold increase in the transmit efficiency compared to the standard surface-coil. Full article
