Dilatometry was used to simulate and analyze martensite formation in the grain-coarsened heat-affected zone (GCHAZ) of P91 steel for high inter-pass temperatures during multi-pass welding. The inter-pass temperature of 360 °C was within the dual-phase temperature range (~400 °C to 240 °C), but because of the unexpected formation of isothermal martensite, the microstructure at the inter-pass temperature was substantially martensitic and similar in microstructure and hardness to those obtained using lower, conventional inter-pass temperatures (about 250 °C). The results for martensite formation indicate that kinetic classifications for transformation in carbon and alloyed steels should take into account the overlapping effects of the diffusionless transformation and thermally activated processes associated with dislocation motion and the diffusion of interstitial elements. Furthermore, the M_S temperature was found to be highly sensitive to the microstructural state of the austenite and the availability of nucleating sites for martensite formation. The data for the kinetics of martensite formation were inconsistent with the widely used Koistinen and Marburger (KM) equation for predicting the volume fraction of martensite as a function of quench temperature. It is concluded that the KM equation has limited applicability Full article

Nitinol (NiTi) alloys are gaining extensive attention due to their excellent mechanical, superelasticity, and biocompatibility properties. It is difficult to model the complex mechanical behavior of NiTi alloys due to the solid-state diffusionless phase transformations, and the differing elasticity and plasticity presenting from these two phases. In this work, an Auricchio finite element (FE) model was used to model the mechanical behavior of superelastic NiTi and was validated with experimental data from literature. A Representative Volume Element (RVE) was used to simulate the NiTi microstructure, and a microscale study was performed to understand how the evolution of martensite phase from austenite affects the response of the material upon loading. Laser Powder Bed Fusion (L-PBF) is an effective way to build complex NiTi components. Porosity being one of the major defects in Laser Powder Bed Fusion (L-PBF) processes, the model was used to correlate the macroscale effect of porosity (1.4–83.4%) with structural stiffness, dissipated energy during phase transformations, and damping properties. The results collectively summarize the effectiveness of the Auricchio model and show that this model can aid engineers to plan NiTi processing and operational parameters, for example for heat pump, medical implant, actuator, and shock absorption applications. Full article

The assembled camshaft has obvious advantages in material optimization and flexible manufacturing. As the most important surface modification technique, the heat treatment process is utilized in this work to promote the desired compressive residual stress on the near-surface of the 100Cr6 steel assembled cam. The Johnson-Mehl-Avrami equation and Koistinen-Marbuger law are integrated into the ABAQUS software via user subroutines to simulate the evolution of diffusional transformation and diffusionless transformation, respectively. The linear mixture law is used for describing the coupled thermomechanical and metallurgical behaviors in the quenching of steel cam. The influences of various quenchants and the probable maximum phase volume fractions on surface residual stress or hardness are analyzed. Results show that a greater amount of martensite volume fraction and a slower martensitic transformation rate are beneficial for the compressive stress retention. Compared with the conventional quenching oil, the fast oil quenched cam surface has higher final compressive stress and hardness. Full article

Tectonic plates are thought to move above the asthenosphere due to the presence of accumulated melts or volatiles that result in a low-viscosity layer, known as lithosphere–asthenosphere boundary (LAB). Here, we report experiments suggesting that the plates may slide through a solid-state mechanism. Ultrafine-grained aggregates of Mg₂GeO₄ and minor MgGeO₃ were synthetized using spark plasma sintering (SPS) and deformed using a 1-atm deformation rig between 950 °C and 1250 °C. For 1000 < T < 1150 °C, the derivative of the stress–strain relation of the material drops down to zero once a critical stress as low as 30–100 MPa is reached. This viscosity reduction is followed by hardening. The deformation curves are consistent with what is commonly observed in steels during the shear-induced transformation from austenite to martensite, the final material being significantly harder. This is referred to as TRansformation-Induced Plasticity (TRIP), widely observed in metal alloys (TRIP alloys). It should be noted that such enhanced plasticity is not necessarily due to a phase transition, but could consist of any kind of transformation, including structural transformations. We suspect a stress-induced grain-boundary destabilization. This could be associated to the transient existence of a metastable phase forming in the vicinity of grain boundaries between 1000 and 1150 °C. However, no such phase can be observed in the recovered samples. Whatever its nature, the rheological transition seems to occur as a result of a competition between diffusional processes (i.e., thermally activated) and displacive processes (i.e., stress-induced and diffusionless). Consequently, the material would be harder at 1200 °C than at 1100 °C thanks to diffusion that would strengthen thermodynamically stable phases or grain-boundary structures. This alternative scenario for the LAB would not require volatiles. Instead, tectonic plates may slide on a layer in which the peridotite is constantly adjusting via a grain-boundary transformation. Full article

Using large-scale atomistic simulations, dislocation mechanics in the presence of linear complexions are investigated in an Fe-Ni alloy, where the complexions appear as nanoparticle arrays along edge dislocation lines. When mechanical shear stress is applied to drive dislocation motion, a strong pinning effect is observed where the defects are restricted by their own linear complexion structures. This pinning effect becomes weaker after the first dislocation break-away event, leading to a stress-strain curve with a profound initial yield point, similar to the static strain aging behavior observed experimentally for Fe-Mn alloys with the same type of linear complexions. The existence of such a response can be explained by local diffusion-less and lattice distortive transformations corresponding to L1₀-to-B2 phase transitions within the linear complexion nanoparticles. As such, an interdependence between a linear complexion structure and dislocation mechanics is found. Full article

Dislocations play a central role in determining strength and flow properties of metals and alloys. Diffusionless phase transformation of β→α in Ti6Al4V during the Direct Metal Laser Sintering (DMLS) process produces martensitic microstructures with high dislocation densities. However, heat treatment, such as stress relieving and annealing, can be applied to reduce the volume of these dislocations. In the present study, an analysis of the X-ray diffraction (XRD) profiles of the non-heat-treated and heat-treated microstructures of DMLS Ti6Al4V(ELI) was carried out to determine the level of defects in these microstructures. The modified Williamson–Hall and modified Warren–Averbach methods of analysis were used to evaluate the dislocation densities in these microstructures. The results obtained showed a 73% reduction of dislocation density in DMLS Ti6Al4V(ELI) upon stress relieving heat treatment. The density of dislocations further declined in microstructures that were annealed at elevated temperatures, with the microstructures that were heat-treated just below the β→α recording the lowest dislocation densities. Full article

Many attempts have been made to improve the translucency of zirconia in dentistry. The purpose of this study was to evaluate the effect of a rapid-cooling heat treatment on the optical and mechanical properties of dental monolithic zirconia. Zirconia containing 3, 4, and 5 mol% Y₂O₃ were sintered, sectioned, and polished. The specimens were rapidly cooled from high temperature inducing a diffusionless cubic-to-metastable tetragonal (t’) phase transformation. The changes in L^*a^*b^* color coordinates, translucency parameter (TP), and total transmittance (T%) were measured. Three-point bending strength, Vickers hardness, and indentation fracture toughness tests were performed. Quantitative phase analyses were carried out by X-ray diffraction with Rietveld refinement. Scanning electron microscopy (SEM) images were obtained. With increasing Y₂O₃ contents, TP and T% values increased while strength and toughness decreased. The Rietveld analysis showed that the amount of t’-phase increased after rapid-cooling and annealed 5Y-partially stabilized zirconia (PSZ) contained the highest amount of t’-phase (64.4 wt%). Rapid-cooling improved translucency but the translucency of annealed 5Y-PSZ did not approach that of lithium disilicate glass-ceramic. Rapid-cooling decreased flexural strength significantly, being 306.1 ± 61.8 MPa for annealed 5Y-PSZ. SEM revealed that grains tended to get larger after rapid-cooling. A rapid-cooling treatment can produce t’-phase which can contribute to an increase in translucency but has a negative effect on the mechanical properties of zirconia. Full article

A comprehensive exploration of symmetry and conditional symmetry is made from the evolution of symmetry. Unlike other chaotic systems of conditional symmetry, in this work it is derived from the symmetric diffusionless Lorenz system. Transformation from symmetry and asymmetry to conditional symmetry is examined by constant planting and dimension growth, which proves that the offset boosting of some necessary variables is the key factor for reestablishing polarity balance in a dynamical system. Full article

In-situ TEM-heating study of the microstructural evolution of CrFeCoNiCu high entropy alloy (HEA) thin films was carried out and morphological and phase changes were recorded. Post annealing investigation of the samples was carried out by high resolution electron microscopy and EDS measurements. The film is structurally and morphologically stable single phase FCC HEA up to 400 °C. At 450 °C the formation of a BCC phase was observed, however, the morphology of the film remained unchanged. This type of transformation is attributed to diffusionless processes (martensitic or massive). From 550 °C fast morphological and structural changes occur, controlled by volume diffusion processes. Fast growing of a new intermetallic phase is observed which contains mainly Cr and has large unit cell due to chemical ordering of components in <100> direction. The surface of the films gets covered with a CrO-type layer, possibly contributing to corrosion resistance of these. Full article

Nanoparticles of hexagonal $\omega$ phase in bcc-Ti(Mo) single crystals ( $\beta$ phase) occur due to a diffusionless athermal $\beta$ to $\omega$ transformation and they grow during follow-up ageing at elevated temperatures, while the alloying atoms (Mo in our case) are expelled from the nanoparticle volumes. We investigated the Mo content in growing $\omega$ nanoparticles by anomalous X-ray diffraction and demonstrate that the Mo expulsion from the $\omega$ phase is not full; a thin shell of a nanoparticles where the $\beta$ to $\omega$ transformation is not complete still contains a considerable amount of Mo atoms. Full article

The effect of ultra-fast heating on the microstructures of steel has been thoroughly studied over the last year as it imposes a suitable alternative for the production of ultra high strength steel grades. Rapid reheating followed by quenching leads to fine-grained mixed microstructures. This way the desirable strength/ductility ratio can be achieved while the use of costly alloying elements is significantly reduced. The current work focuses on the effect of ultra-fast heating on commercial dual phase grades for use in the automotive industry. Here, a cold-rolled, low-carbon, medium-manganese steel was treated with a rapid heating rate of 780 °C/s to an intercritical peak temperature (760 °C), followed by subsequent quenching. For comparison, a conventionally heated sample was studied with a heating rate of 10 °C/s. The initial microstructure of both sets of samples consisted of ferrite, pearlite and martensite. It is found that the very short heating time impedes the dissolution of cementite and leads to an interface-controlled α → γ transformation. The undissolved cementite affects the grain size of the parent austenite grains and of the microstructural constituents after quenching. The final microstructure consists of ferrite and martensite in a 4/1 ratio, undissolved cementite and traces of austenite while the presence of bainite is possible. Finally, it is shown that the texture is not strongly affected during ultra-fast heating, and the recovery and recrystallization of ferrite are taking place simultaneously with the α → γ transformation. Full article

The current work focuses on complex multiphase microstructures gained in CrMo medium carbon steel after ultra-fast heat treatment, consisting of heating with heating rate of 300 °C/s, 2 s soaking at peak temperature and subsequent quenching. In order to better understand the microstructure evolution and the phenomena that take place during rapid heating, an ultra-fast heated sample was analyzed and compared with a conventionally treated sample with a heating rate of 10 °C/s and 360 s soaking. The initial microstructure of both samples consisted of ferrite and spheroidized cementite. The conventional heat treatment results in a fully martensitic microstructure as expected. On the other hand, the ultra-fast heated sample shows significant heterogeneity in the final microstructure. This is a result of insufficient time for cementite dissolution, carbon diffusion and chemical composition homogenization at the austenitization temperature. Its final microstructure consists of undissolved spheroidized cementite, nano-carbides and martensite laths in a ferritic matrix. Based on EBSD and TEM analysis, traces of bainitic ferrite are indicated. The grains and laths sizes observed offer proof that a diffusionless, massive transformation takes place for the austenite formation and growth instead of a diffusion-controlled transformation that occurs on a conventional heat treatment. Full article
