A low-profile dual-polarized shared-aperture phased array antenna is proposed for Ku-band satellite communications in this paper. The stacked octagonal patches loaded with Via-rings are proposed as dual-polarized shared-aperture radiation elements, with the characteristics of wide impedance bandwidth, high gain, and weak coupling. Furthermore, innovative minimized three-port ring couplers are utilized for the differential-fed antenna array, further suppressing the cross-polarization component. Substrate integrated coaxial line (SICL) and microstrip line (MS) feed networks are employed for the excitation of transmitting band (Tx) horizontal polarization and receiving band (Rx) vertical polarization, respectively. The non-uniform subarray architecture is optimized to minimize the sidelobe levels with the reduced number of transmitter and receiver (T/R) radio frequency phase-shifting modules. As proof-of-concept examples, 16 × 24 and 32 × 24 array antennas are demonstrated and fabricated. The measured impedance bandwidths of the proposed phased array antennas are around 21.1%, while the in-band isolations are above 36.7 dB. Gains up to 29 dBi and 32.4 dBi are performed by two prototypes separately. In addition, the T/R phase-shifting modules are utilized to validate the beam-scanning characteristic, which is of value for dynamic satellite communications. Full article

This paper presents a novel switchable branch-line coupler (BLC) designed to achieve variable phase shifts while maintaining a constant output power. The proposed design incorporates low stepwise phase shifters with incremental phase shifts of 10° to 20°, covering phase ranges from −3° to 150°. The initial structure is based on a 3 dB branch-line coupler with arm electrical lengths of 3λ_g/2. A novel delay line structure is integrated within the BLC arms, consisting of a λ_g/4 section bridged by a tapered stripline to accommodate a PIN diode switch, thereby altering the current path direction. Additionally, two interdigital capacitors (IDCs), uniquely mounted on a crescent-shaped extension, are implemented alongside the tapered line to elongate the current path when the PIN diode is in the OFF state. By controlling the PIN diode states, the delay time is differentially adjusted, resulting in variable differential phase shifts at the output ports. To validate the functionality, the proposed BLC was integrated with a two-element antenna array to demonstrate differential beam steering. The measurement results confirm that the phased array antenna can switch its main beam between −27° and 25° in the elevation plane, achieving an average realized gain of approximately 7 dBi. The BLC was designed and simulated using CST Microwave Studio and was fabricated on an RO4003C Roger substrate (ε_r = 3.55, 0.406 mm). The proposed design is well-suited for future Butler matrix-based beamforming networks in antenna array systems, particularly for 5G wireless applications. Full article

This paper presents a wideband circularly polarized (CP) substrate-integrated waveguide (SIW) cavity-backed slot antenna array arranged in a 2 × 2 configuration with differential feeding structures. The design features arc-shaped microstrips within the SIW cavity to excite the ${\mathrm{TE}}_{011}^x$/${\mathrm{TE}}_{101}^y$ and ${\mathrm{TE}}_{211}^y$/${\mathrm{TE}}_{121}^x$ modes. By overlapping the center frequencies of the two modes, wideband CP radiation is achieved. The introduction of four modified ring couplers composes a simple but efficient differential feeding network, eliminating the need for balanced resistors like baluns, making it more suitable for millimeter wave or even higher frequency applications. Experimental results show that the antenna array achieves a −10 dB impedance bandwidth of 32.6% (from 17.28 to 24.00 GHz), a 3 dB axial ratio (AR) bandwidth of 13.8% (from 17.05 to 19.57 GHz), a 3 dB gain bandwidth of 41.8% (from 15.39 to 23.51 GHz) and a peak gain of 10.6 dBi, with results closely matching simulation data. This study enhances the development of differential CP SIW cavity-backed slot antenna arrays, offering a potential solution for creating compact integrated front-end circuits in the millimeter wave or Terahertz frequency range. Full article

This paper presents a differential phase coupler design methodology in the IPD process. The coupler consists of a balun and two phase-shifter circuits. The compact balun was designed with lumped components and a common inductor. Each output of the balun circuit was connected to a phase shifter with an opposite phase to make a desired output phase. In the design example, a three-port 90-degree hybrid coupler was implemented on the IPD process to operate at the 6 GHz WIFI frequency. The post-simulation showed that all reflection coefficients were below −19 dB, with an insertion loss of 1.76 dB and isolation of 20 dB. The core chip size was only 0.02λ₀ × 0.018λ₀. Full article

This paper presents a highly efficient 5G New-Radio (NR) RF power amplifier module (PAM). The n77 PAM consists of a high-voltage differential-topology 2 μm GaAs HBT power amplifier, a CMOS controller, a silicon-on-insulator (SOI) switch, an integrated passive device (IPD) bandpass filter, a low-noise amplifier (LNA), and a bi-directional coupler. This PAM generates a saturation output power of 32.7 dBm including the loss of the SOI switch and output filter. The designed n77 PAM is tested with a commercial envelope tracker IC (ET-IC). The designed PAM with an ET-IC achieves an ACLR of −37 dBc at a 27 dBm output power with a DFT-s-OFDM QPSK 100 MHz NR signal and saves a dc power consumption of 950 mW compared to the APT mode. For the CP-OFDM 256QAM with the most stringent EVM requirements, it achieves an EVM of 1.22% at 23 dBm and saves 640 mW compared to the APT mode. Full article

Surface plasmon resonance is an effect widely used for biosensing. Biosensors based on this effect operate in different configurations, including the use of diffraction gratings as couplers. Gratings are highly tunable and are easy to integrate into a fluidic system due to their planar configuration. We discuss the optimization of plasmonic grating couplers for use in a specific sensor configuration based on the optical switch. These gratings present a sinusoidal profile with a high depth/period ratio. Their interaction with a p-polarized light beam results in two significant diffracted orders (the 0th and the −1st), which enable differential measurements cancelling noise due to common fluctuations. The gratings are fabricated by combining laser interference lithography with nanoimprinting in a process that is aligned with the challenges of low-cost mass production. The effects of different grating parameters such as the period, depth and profile are theoretically and experimentally investigated. Full article

Phase-sensitive optical time-domain reflectometry (φOTDR) is a technology for distributed vibration sensing, where vibration amplitudes are determined by recovering the phase of the backscattered light. Measurement noise induces phase errors, which degrades sensing performance. The phase errors, using a differentiation and cross-multiplication (DCM) algorithm, are investigated theoretically and experimentally in a φOTDR system based on a phase retrieval configuration consisting of an imbalanced Mach–Zehnder interferometer (IMZI) and a 3 × 3 coupler. Analysis shows that phase error is highly dependent on the AC component of the obtained signal, essentially being inversely proportional to the product of the power of the light backscattered from two locations. An analytical expression was derived to estimate the phase error and was confirmed by experiment. When applied to the same measurement data, the error is found to be slightly smaller than that obtained using in-phase/quadrature (I/Q) demodulation. The error, however, increases for longer measurement times. Full article

Photonic integrated circuits (PICs) have been a research hotspot in recent years. Programmable PICs that have the advantages of versatility and reconfigurability that can realize multiple functions through a common structure have been especially popular. Leveraging on-chip couplers and phase shifters, general-purpose waveguide meshes connected in different topologies can be manipulated at run-time and support a variety of applications. However, current waveguide meshes suffer from relatively a low cell amount and limited bandwidth. Here, we demonstrate a reconfigurable photonic integrated computing chip based on a quadrilateral topology network, where typical analog computing functions, including temporal differentiation, integration, and Hilbert transformation, are implemented with a processing bandwidth of up to 40 GHz. By configuring an optical path and changing the splitting ratio of the optical switches in the network, the functions can be switched and the operation order can be tuned. This approach enables wideband analog computing of large-scale PICs in a cost-effective, ultra-compact architecture. Full article

A new plasmonic configuration is proposed for application in a sensor and demonstrated for the detection of variations in the bulk refractive index of solutions. The configuration consists of monitoring two diffracted orders resulting from the interaction of a TM-polarized optical beam incident on a grating coupler, operating based on an effect termed the “optical switch”. The two monitored diffracted orders enable differential measurements which cancel the drift and perturbations common to both, leading to an improved detection limit, as demonstrated experimentally. The measured switch pattern associated with the grating coupler is in good agreement with theory. Bulk sensing is demonstrated under intensity interrogation via the sequential injection of solutions comprised of glycerol in water into a fluidic cell. A limit of detection of about ${10}^{-6}$ RIU was achieved. The optical switch configuration is easy to implement and is cost-effective, yielding a highly promising approach for the sensing and the real-time detection of biological species. Full article

We propose a mode switch based on hybrid-core vertical directional couplers with an embedded graphene electrode to realize the switching function with low power consumption. We designed the device with Norland Optical Adhesive (NOA) material as the guide wave cores and epoxy polymer material as cladding to achieve a thermo-optic switching for the E₁₁, E₂₁ and E₁₂ modes, where monolayer graphene served as electrode heaters. The device, with a length of 21 mm, had extinction ratios (ERs) of 20.5 dB, 10.4 dB and 15.7 dB for the E₂₁, E₁₂ and E₁₁ modes, respectively, over the C-band. The power consumptions of three electric heaters were reduced to only 3.19 mW, 3.09 mW and 2.97 mW, respectively, and the response times were less than 495 µs, 486 µs and 498 µs. Additionally, we applied such a device into a mode division multiplexing (MDM) transmission system to achieve an application of gain equalization of few-mode amplification among guided modes. The differential modal gain (DMG) could be optimized from 5.39 dB to 0.92 dB over the C-band, together with the characteristic of polarization insensitivity. The proposed mode switch can be further developed to switch or manipulate the attenuation of the arbitrary guided mode arising in the few-mode waveguide. Full article

Four-bar linkages are one of the most widely used mechanisms in industries. This paper presents a comparative study on the accuracy and efficiency of the optimum synthesis of path-generating four-bar linkages using five metaheuristic optimization algorithms. The utilized metaheuristic methods included two swarm intelligence-based algorithms, i.e., particle swarm optimization and hybrid particle swarm optimization, and three evolutionary-based algorithms, i.e., differential evolution, ensemble of parameters and mutation strategies in differential evolution, and linearly ensemble of parameters and mutation strategies in differential evolution. The objective function to be minimized is the sum of squares of the distance between the generated points and the precision points of a coupler point. The optimal design of four-bar linkages must meet the Grashof’s criteria and exhibit sequential constraints that can prevent the occurrence of order defect. This study investigated five representative cases of the dimensional synthesis of four-bar path generators with and without prescribed timing and compared the optimal solutions of the utilized five metaheuristic methods to those of previously reported algorithms in literature. The improved metaheuristic methods exhibited superior optimal solution and enhanced reliability compared to the original methods. Moreover, three improved metaheuristic methods were not only easy implemented, but also more efficient for solving the optimal synthesis problems, particularly for high dimensional problems. Full article

Atomic magnetometers (AMs) are widely acknowledged as one of the most sensitive kind of instruments for bio-magnetic field measurement. Recently, there has been growing interest in developing chip-scale AMs through nanophotonics and current CMOS-compatible nanofabrication technology, in pursuit of substantial reduction in volume and cost. In this study, an integrated polarization-splitting grating coupler is demonstrated to achieve both efficient coupling and polarization splitting at the D1 transition wavelength of rubidium (795 nm). With this device, linearly polarized probe light that experienced optical rotation due to magnetically induced circular birefringence (of alkali medium) can be coupled and split into individual output ports. This is especially advantageous for emerging chip-scale AMs in that differential detection of ultra-weak magnetic field can be achieved through compact planar optical components. In addition, the device is designed with silicon nitride material on silicon dioxide that is deposited on a silicon substrate, being compatible with the current CMOS nanofabrication industry. Our study paves the way for the development of on-chip AMs that are the foundation for future multi-channel high-spatial resolution bio-magnetic imaging instruments. Full article

This paper presents a 60 GHz CMOS I/Q receiver for the high-speed wireless communication system. It consists of a low noise amplifier, single-to-differential (S2D) amplifier, passive mixer, buffer amplifier with passive I/Q generator, and wideband baseband amplifier (BBA) stage. The measured conversion gain of 51 dB is achieved. The baseband bandwidth of 300 MHz is achieved from 57 GHz to 60 GHz. The 90° tandem coupler was implemented for I/Q signal generation, which has a phase error of <7° and an amplitude imbalance of <2 dB from 55 to 62 GHz. The Marchand balun is used to convert the I/Q signal to the differential, which has a phase error of <4°. A 60 GHz CMOS I/Q receiver is designed and fabricated, using a commercial 40 nm CMOS bulk process. The size of the receiver is 2.02 × 1.45 mm², including the pads. The circuit is operated from a 0.9 V supply. The power consumption is 172 mW at maximum gain mode. Full article

A large-dynamic-range and high-stability phase demodulation technology for fiber-optic Michelson interferometric sensors is proposed. This technology utilizes two output signals from a 2 × 2 fiber-optic coupler, the interferometric phase difference of which is π. A linear-fitting trigonometric-identity-transformation differential cross-multiplication (LF-TIT-DCM) algorithm is used to interrogate the phase signal from the two output signals from the coupler. The interferometric phase differences from the two output signals from the 2 × 2 fiber-optic couplers with different coupling ratios are all equal to π, which ensures that the LF-TIT-DCM algorithm can be applied perfectly. A fiber-optic Michelson interferometric acoustic sensor is fabricated, and an acoustic signal testing system is built to prove the proposed phase demodulation technology. Experimental results show that excellent linearity is observed from 0.033 rad to 3.2 rad. Moreover, the influence of laser wavelength and optical power is researched, and variation below 0.47 dB is observed at different sound pressure levels (SPLs). Long-term stability over thirty minutes is tested, and fluctuation is less than 0.36 dB. The proposed phase demodulation technology obtains large dynamic range and high stability at rather low cost. Full article

An all-diode laser-based master oscillator power amplifier (MOPA) configuration for the generation of ns-pulses with high peak power, stable wavelength and small spectral line width is presented. The MOPA emits alternating at two wavelengths in the spectral range between 964 nm and 968 nm, suitable for the detection of water vapor by absorption spectroscopy. The monolithic master oscillator (MO) consists of two slightly detuned distributed feedback laser branches, whose emission is combined in a Y-coupler. The two emission wavelengths can be adjusted by varying the current or temperature to an absorption line and to a non-absorbing region. The power amplifier (PA) consists of a ridge-waveguide (RW) section and a tapered section, monolithically integrated within one chip. The RW section of the PA acts as an optical gate and converts the continuous wave input beam emitted by the MO into a sequence of short optical pulses, which are subsequently amplified by the tapered section to boost the output power. For a pulse width of 8 ns, a peak power of 16.3 W and a side mode suppression ratio of more than 37 dB are achieved at a repetition rate of 25 kHz. The measured spectral width of 10 pm, i.e., 0.1 cm⁻¹, is limited by the resolution of the optical spectrum analyzer. The generated pulses emitting alternating at two wavelengths can be utilized in a differential absorption light detection and ranging system. Full article
