Lithium-ion batteries are the primary power source for new energy vehicles, making accurate estimation of their state of health (SOH) essential for ensuring the safe operation of battery systems. This paper proposes a Capacity–Power Analysis (CPA) method that incorporates temperature features to enhance feature extraction across a broader range. Additionally, we introduce an SOH estimation method for lithium batteries based on a Convolutional Neural Network (CNN) and a Kolmogorov–Arnold Network (KAN). By extracting the capacity–power curve and average temperature features during constant-current and constant-voltage charging, the CNN-KAN model establishes a nonlinear mapping relationship between the extracted features and SOH, enabling high-precision SOH estimation for lithium-ion batteries. Four 18650 batteries were tested under various charging and discharging conditions in a laboratory setting. The coefficient of determination (R²) exceeded 96.4%, the root mean square error (RMSE) was below 0.86%, and the mean absolute error (MAE) was under 0.7%, confirming that the proposed method demonstrates excellent estimation performance. Full article

Aluminum–air batteries have attracted more attention in recent years due to the theoretical possibility of replacing lithium batteries. Al6061/0.5wt.%TiB₂ is considered a suitable anode material due to decreased hydrogenation corrosion. In this work, laser power was optimized via a selective laser melting process to increase the electrochemical and discharge performance of an Al composite anode. Relative density was studied in this work, and the formation mechanism caused by molten pool morphology was also researched using finite element analysis and experiments. The self-corrosion rate, open-circuit potential, polarization curve, EIS curve, and constant-current discharge performance were all studied in the following section, and the relationship between anode quality and laser power was discussed accordingly. The testing results revealed that when laser power reached 340 W, the Al6061/0.5wt.%TiB₂ composite anode reached a relative optimal condition as defects reduced to a minimum value at this point, which resulted in overall anode performance increasing in the electrochemical and discharge test. Full article

This paper presents the concept of applying incremental capacity analysis (ICA) on the OCV curve in the SoC space. The OCV curve can be obtained from any sequence of discharge or charge current or power pulse with a necessary rest period to allow the cell to reach a pseudo-OCV after each pulse. With a high resolution (>100 pulses) in the full SoC window, an OCV-vs.-SoC curve can be obtained with sufficient accuracy to perform an ICA on the obtained OCV curve. ICA as a diagnostic technique has commonly been applied on Li-ion cells with constant charge and discharge at slow currents. However, a slow controlled constant current charge or discharge is normally not feasible and cannot be easily applied to a battery in an application. Here, we revisit pulse-based ICA to supplement the conventional constant-current-based technique. Based on actual ageing data, we show that ICA performed on a selection of high-resolution OCV curves is comparable or better than conventional ICA with constant current. The main advantage of OCV-ICA is that it can be applied to most cells and systems without a significant interruption of normal cell operation. OCV-ICA can provide valuable insights into ageing mechanisms as well as, e.g., detailed information on changes in internal resistance. Full article

Different from the voltage source inverter (VSI), the current source inverter (CSI) can boost the voltage and eliminate the additional passive filter and dead time. However, the DC-side inductor current is not a real current source and is generated by a DC voltage supply and an inductor. Under different switching states, the DC-side inductor will be charged or discharged, which leads to the DC-side inductor current being discontinuous or increasing. To solve the control problem of the DC-side inductor current of the CSI, a novel single-phase CSI topology with five switching tubes for grid-connected applications is proposed. Firstly, the reference calculation method and the hysteresis loop control scheme for the DC-side inductor current are proposed, and the adjustable and constant DC-side inductor current are obtained. Since the PWM signals cannot be directly implemented to the switching tubes, the modulation strategy for the single-phase CSI is proposed in this paper. Then, an active damping method based on the feedback capacitor voltage is presented to suppress the resonance peak caused by the LC filter on the grid side. Finally, the math model of the AC-side structure is established, and the optimal proportional-resonant controller parameters’ design method is explored by the amplitude–frequency characteristic curves. The simulation and experiment are implemented for the proposed CSI topology. The results show that a high-quality power with a good control performance can be obtained with the proposed CSI topology. Full article

Batteries with an energy storage capacity of 280 Ah play a crucial role in promoting the development of smart grids. However, the inhomogeneity of their internal temperature cannot be accurately measured at different constant charge and discharge power, affecting the efficiency and safety of the battery. This work adopts finite element analysis to determine the typical internal temperature of a single-cell model, which can guide the measuring position of the battery. Before the manufacturing process, a slim pre-buried sensor is utilized to reduce the negative impacts of different constant charge and discharge powers. The maximum internal temperature of the battery is up to 77 °C at a constant charge and discharge power of 896 W. The temperature difference between the two poles and the battery surface is as high as 26.2 °C, which is beyond the safety temperature (55 °C). This phenomenon will result in the degradation of the positive electrode through dQ/dV curves. These measurements of battery internal temperature can improve battery heat control and facilitate the development of energy storage technology. Full article

The variability of solar radiation presents significant challenges for the integration of solar photovoltaic (PV) energy into the electrical system. Incorporating battery storage technologies ensures energy reliability and promotes sustainable growth. In this work, an energy analysis is carried out to determine the installation size and the operating setpoint with optimal constant monthly power through an iterative calculation process, considering various operating setpoints and system parameters. A degradation model is integrated according to the curves offered by battery manufacturers and the charge–discharge cycles are calculated using the rainflow method to guarantee a reliable analysis of the plant. Through massive data analysis in a long-term simulation, indicators are generated that allow for establishing a relationship between the energy unavailability of the system and the BESS dimensions. Full article

Electrical engines are becoming more common than thermal ones. Therefore, there is an increasing interest in the characterization of batteries and in measuring their state of charge, as an overestimation would cause the vehicle to run out of energy and an underestimation means that the vehicle is running in suboptimal conditions. This is of paramount importance for flying vehicles, as their endurance decreases with the increase in weight. This work aims at finding a novel empirical model for the discharge curve of an arbitrary number of battery pack cells, that uses as few tunable parameters as possible and hence is easy to adapt for every single battery pack needed by the operator. A suitable measurement setup for battery tests, which includes voltage and current sensors, has been developed and described. Tests are performed on both constant and variable power loads to investigate different real-world scenarios that are easy to reproduce. The main achievement of this novel model is indeed the ability to predict discharges at variable power based on a preliminary characterization performed at constant power. This leads to the possibility of rapidly tuning the model for each battery with promising accuracy. The results will show that the predicted discharged capacities of the model have a normalized error below 0.7%. Full article

Magnetic nanoparticles of NiFe₂O₄ were successfully prepared by utilizing the sol–gel techniques. The prepared samples were investigated through various techniques such as X-ray diffraction (XRD), transmission electron microscopy (TEM), dielectric spectroscopy, DC magnetization and electrochemical measurements. XRD data analysed using Rietveld refinement procedure inferred that NiFe₂O₄ nanoparticles displayed a single-phase nature with face-centred cubic crystallinity with space group Fd-3m. Average crystallite size estimated using the XRD patterns was observed to be ~10 nm. The ring pattern observed in the selected area electron diffraction pattern (SAED) also confirmed the single-phase formation in NiFe₂O₄ nanoparticles. TEM micrographs confirmed the uniformly distributed nanoparticles with spherical shape and an average particle size of 9.7 nm. Raman spectroscopy showed characteristic bands corresponding to NiFe₂O₄ with a shift of the A_1g mode, which may be due to possible development of oxygen vacancies. Dielectric constant, measured at different temperatures, increased with temperature and decreased with increase in frequency at all temperatures. The Havrilliak–Negami model used to study the dielectric spectroscopy indicated that a NiFe₂O₄ nanoparticles display non-Debye type relaxation. Jonscher’s power law was utilized for the calculation of the exponent and DC conductivity. The exponent values clearly demonstrated the non-ohmic behaviour of NiFe₂O₄ nanoparticles. The dielectric constant of the nanoparticles was found to be >300, showing a normal dispersive behaviour. AC conductivity showed an increase with the rise in temperature with the highest value of 3.4 × 10⁻⁹ S/cm at 323 K. The M-H curves revealed the ferromagnetic behaviour of a NiFe₂O₄ nanoparticle. The ZFC and FC studies suggested a blocking temperature of ~64 K. The saturation of magnetization determined using the law of approach to saturation was ~61.4 emu/g at 10 K, corresponding to the magnetic anisotropy ~2.9 × 10⁴ erg/cm³. Electrochemical studies showed that a specific capacitance of ~600 F g⁻¹ was observed from the cyclic voltammetry and galvanostatic charge–discharge, which suggested its utilization as a potential electrode for supercapacitor applications. Full article

A flexible silver-zinc fabric-based primary battery that is biocompatible, conformable, and suitable for single-use wearable biomedical devices is reported. The planar battery was fabricated by screen printing silver/silver-chloride and zinc electrodes (14 mm × 8 mm) onto a silk substrate. A biologically relevant fluid, phosphate buffered saline was used as a liquid electrolyte for characterization. Cyclic voltammetry, electrochemical impedance spectroscopy, and current discharge properties at constant densities of 0.89 μA/cm², 8.93 μA/cm², and 89.29 μA/cm² were used to quantify battery performance. Nine cells were placed in series to generate a greater open circuit voltage (>6 V) relevant to previously reported biomedical applications. The nine-cell battery was evaluated for operation under mechanical strain due to likely placement on curved surfaces of the body in wearable applications. The nine-cell battery was discharged over 4 h at 8.93 μA/cm² in an unstrained condition. The mechanically strained battery when mounted to a mannequin to mimic anatomical curvature discharged up to 30 min faster. Additionally, the nine-cell battery was used in an in vitro wound model to power an electroceutical, showing promise towards practical use in active, corrosive, and potentially biohazardous environments. Full article

Advanced sensing and measurement technology is the key to realizing the transparent power grid and electric internet of things. Meanwhile, sensors, as an indispensable part of the smart grid, can monitor, collect, process, and transmit various types of data information of the power system in real-time. In this way, it is possible to further control the power system. Among them, partial discharge (PD) sensors are of great importance in the fields of online monitoring of insulation condition, intelligent equipment control, and power maintenance of power systems. Therefore, this paper intends to focus on advanced sensing materials and study new materials for the improvement for partial discharge sensors. As two-dimensional material, graphene is introduced. The electromagnetic properties of graphene partial discharge sensor electrode plate material are analyzed theoretically. By studying the influence of different chemical potential, relaxation time, temperature, and frequency, we obtain the changing curve of conductivity, dielectric constant, and refractive index. A linear regression model based on the least-squares method was developed for the three electromagnetic properties. Finally, the simulation and experiment verified that the graphene partial discharge sensor has better absorption of the partial discharge signal. This study can apply to the design of graphene partial discharge sensors. Full article

The demand for energy storage is increasing massively due to the electrification of transport and the expansion of renewable energies. Current battery technologies cannot satisfy this growing demand as they are difficult to recycle, as the necessary raw materials are mined under precarious conditions, and as the energy density is insufficient. Metal–air batteries offer a high energy density as there is only one active mass inside the cell and the cathodic reaction uses the ambient air. Various metals can be used, but zinc is very promising due to its disposability and non-toxic behavior, and as operation as a secondary cell is possible. Typical characteristics of zinc–air batteries are flat charge and discharge curves. On the one hand, this is an advantage for the subsequent power electronics, which can be optimized for smaller and constant voltage ranges. On the other hand, the state determination of the system becomes more complex, as the voltage level is not sufficient to determine the state of the battery. In this context, electrochemical impedance spectroscopy is a promising candidate as the resulting impedance spectra depend on the state of charge, working point, state of aging, and temperature. Previous approaches require a fixed operating state of the cell while impedance measurements are being performed. In this publication, electrochemical impedance spectroscopy is therefore combined with various machine learning techniques to also determine successfully the state of charge during charging of the cell at non-fixed charging currents. Full article

The solution cast process is used to set up chitosan: dextran-based plasticized solid polymer electrolyte with high specific capacitance (228.62 F/g) at the 1st cycle. Fourier-transform infrared spectroscopy (FTIR) pattern revealed the interaction between polymers and electrolyte components. At ambient temperature, the highest conductive plasticized system (CDLG–3) achieves a maximum conductivity of 4.16 × 10⁻⁴ S cm⁻¹. Using both FTIR and electrical impedance spectroscopy (EIS) methods, the mobility, number density, and diffusion coefficient of ions are measured, and they are found to rise as the amount of glycerol increases. Ions are the primary charge carriers, according to transference number measurement (TNM). According to linear sweep voltammetry (LSV), the CDLG–3 system’s electrochemical stability window is 2.2 V. In the preparation of electrical double layer capacitor devices, the CDLG–3 system was used. There are no Faradaic peaks on the cyclic voltammetry (CV) curve, which is virtually rectangular. Beyond the 20th cycle, the power density, energy density, and specific capacitance values from the galvanostatic charge–discharge are practically constant at 480 W/Kg, 8 Wh/Kg, and 60 F g⁻¹, for 180 cycles. Full article

Poly (vinyl alcohol) (PVA)-based solid polymer electrolytes doped with ammonium thiocyanate (NH₄SCN) and glycerol were fabricated using a solution casting method. Lithium-based energy storage devices are not environmentally friendly materials, and they are toxic. Thus, proton-conducting materials were used in this work as they are harmless and are smaller than lithium. The interaction between PVA and the electrolyte elements was shown by FTIR analysis. The highest conductivity of 1.82 × 10⁻⁵ S cm⁻¹ was obtained by the highest-conducting plasticized system (PSP_2) at room temperature. The mobility, diffusion coefficient, and number density of anions and cations were found to increase with increasing glycerol. FESEM was used to investigate the influence of glycerol on film morphology. TNM showed that the cations and anions were the main charge carriers. LSV showed that the electrochemical stability window of the PSP_2 system was 1.99 V. The PSP_2 system was applied in the preparation of an electrical double layer capacitor device. The shape of the cyclic voltammetry (CV) curve was nearly rectangular with no Faradaic peaks. From the galvanostatic charge-discharge analysis, the power density, energy density, and specific capacitance values were nearly constant beyond the first cycle at 318.73 W/Kg, 2.06 Wh/Kg, and 18.30 F g⁻¹, respectively, for 450 cycles. Full article

Voltage vs. time curves of double layer capacitances (DLCs) by current-controlled charge and discharge steps have been recognized to be composed of triangular waves. They are deviated slightly from triangles from the viewpoint of the time dependence or the constant phase element of the DLC. In order to evaluate the deviation, we measured DLCs of a platinum (Pt) electrode in KCl solution by current-control. Each time-voltage curve was convex rather a line, and was followed by the power law. Even if the time dependence was subtracted from each curve, the enhancement of the DLC was noticeable with an increase in the time well as the voltage. It can be attributed to the electric field effect, in which dipoles of solvents are oriented on an electrode so strongly that the DLC may be increased. The field dependence can be justified with the kinetic theory of interacting dipoles of solvents on an electrode through the observed linearity of the logarithmic DLC with the net voltage. This concept was applied to a commercially available super-capacitor to demonstrate a significant contribution of the field effect. Full article

A real time simulation of battery conditions is an essential step in the development of energy harvesting devices. Since it is not possible to have a direct measurement, the battery information, such as the remaining charge, need to be estimated by means of model-based estimation algorithms. Most of the existing models describing battery behaviour, are suitable only for a constant discharge current. This paper proposes a study of the dependence of the equivalent circuit model parameters on different discharge conditions. The model presented provides a powerful tool to represent the batteries’ behaviour in energy harvesting systems, involving continuous charge and discharge cycles. The extraction of parameters was performed, starting from a set of reference curves generated in Matlab Simulink environment, referring to Li-ion technology batteries. The parameters were extracted by means of a cascade of global and local search identification algorithms. Finally, the relations describing parameters’ behaviours as functions of the discharge current are presented. Full article
