Search Results (69)

The development of ultrahigh-concentration photovoltaic (UHCPV) systems plays a pivotal role in advancing sustainable solar energy technologies. As the demand for clean energy grows, the need to align concentrated photovoltaic (CPV) system design with high-efficiency solar cell production becomes critical for maximizing energy yield while minimizing resource use. Despite some experimental efforts in UHCPV development, there remains a gap in integrating Fresnel lens-based systems with the comprehensive thermal modeling of key components in improving system sustainability and performance. To bridge this gap and promote more energy-efficient designs, a detailed numerical model was established to evaluate both the thermal and optical performance of a UHCPV system. This model contributes to the sustainable design process by enabling informed decisions on system efficiency, thermal management, and material optimization before physical prototyping. Through COMSOL Multiphysics simulations, the system was assessed under direct normal irradiance (DNI) ranging from 400 to 1000 W/m². Optical simulations indicated a high theoretical optical efficiency of ~93% and a concentration ratio of 1361 suns, underscoring the system’s potential to deliver high solar energy conversion with minimal land and material footprint. Moreover, the integration of thermal and optical modeling ensures a holistic understanding of system behavior under varying ambient temperatures (20–50 °C) and convective cooling conditions (heat transfer coefficients between 4 and 22 W/m².K). The results showed that critical optical components remain within safe temperature thresholds (<54 °C), while the receiver stage operates between 78.5 °C and 157.4 °C. These findings highlight the necessity of an effective cooling mechanism—not only to preserve system longevity and safety but also to maintain high conversion efficiency, thereby supporting the broader goals of sustainable and reliable solar energy generation. Full article

A concentrated photovoltaic system is evaluated as a thermal energy source employing phase change material to meet the domestic water heating demand. A paraffin wax-based phase change material is selected with a 58 °C melting point to store enough thermal energy to match the hot water demand in the buildings. The energy performance of the concentrated photovoltaics containing phase change materials is compared to that of the reference to determine the increased energy outputs due to the heat removal by the material. The concentrated photovoltaics-phase change material achieved 30% higher energy output compared to the reference concentrated photovoltaic, thus providing a strong justification for the improved thermal management design. An enthalpy-based thermal model is developed to compare the experimental results with model predictions, confirming a reasonable agreement between the results. The model is used determine the optimum melting point and container size for different phase change materials under different radiation concentrations for the hot climate of the United Arab Emirates. Full article

The effects of global warming are severely recognizable and, according to the OECD, 47% of the world’s population will soon live in regions with insufficient drinking water. Already, many countries depend on desalination for fresh water supply, but such facilities are often powered by fossil fuels. This paper presents an energy self-sufficient desalination system that runs entirely on solar power. Sunlight is harvested using parabolic trough collectors with an effective aperture area of 1.5 m × 0.98 m and a theoretical concentration ratio of 150 suns, in which a concentrator photovoltaic thermal (CPV-T) hybrid-absorber converts the radiation to electricity and heat. This co-generated energy runs a multi-effect distillation (MED) plant, whereby the waste heat of multi-junction concentrator solar cells is used in the desalination process. This concept also takes advantage of synergy effects of optical elements (i.e., mirrors), resulting in a cost reduction of solar co-generation compared to the state of the art, while at the same time increasing the overall efficiency to ~75% (consisting of an electrical efficiency of 26.8% with a concurrent thermal efficiency of 48.8%). Key components such as the parabolic trough hybrid absorber were built and characterized by real-world tests. Finally, results of system simulations, including fresh water output depending on different weather conditions, degree of autonomy, required energy storage for off-grid operation etc. are presented. Simulation results revealed that it is possible to desalinate around 2,000,000 L of seawater per year with a 260 m² plant and 75 m³ of thermal storage. Full article

Concentrated photovoltaic (CPV) technology is based on the principle of concentrating direct sunlight onto small but very efficient photovoltaic (PV) cells. This approach allows the realization of PV modules with conversion efficiencies exceeding 30%, which is significantly higher than that of the flat panels. However, to achieve optimal performance, these modules must always be perpendicular to solar radiation; hence, they are mounted on high-precision solar trackers. This requirement has led to the predominant use of CPV technology in the construction of solar power plants in open and large fields for utility scale applications. In this paper, the authors present a novel approach allowing the use of this technology for residential installations, mounting the system both on flat and sloped roofs. Therefore, the main components of cell and primary lens have been chosen to contain the dimensions and, in particular, the thickness of the module. This paper describes the main design steps: thermal analysis allowed the housing construction material to be defined to contain cell working temperature, while with deep optical studies, experimentally validated main geometrical and functional characteristics of the CPV have been identified. The design of a whole CPV system includes thermal storage for domestic hot water and a 1 kWh electrical battery. The main design results indicate an estimated electrical conversion efficiency of 30%, based on a cell efficiency of approximately 42% under operational conditions and a measured optical efficiency of 74%. The CPV system has a nominal electric output of 550 W_p and can simultaneously generate 630 W of thermal power, resulting in an overall system efficiency of 65.5%. The system also boasts high optical acceptance angles (±0.6°) and broad assembly tolerances (±1 mm). Cost analysis reveals higher unit costs compared to conventional PV and CPV systems, but these become competitive when considering the benefit of excess thermal energy recovery and use by the end user. Full article

This paper addresses the potential of integrating a concentrating photovoltaic thermal (CPV/T) system with an absorption chiller for the purpose of space cooling in residential buildings in the United Arab Emirates (UAE). The proposed system consists of a low concentrating photovoltaic thermal (CPV/T) collector that utilizes mono-crystalline silicon photovoltaic (PV) cells integrated with a single-effect absorption chiller. The integrated system was modeled using the Transient System Simulation (TRNSYS v17) software. The obtained model was implemented in a case study represented by a villa situated in Abu Dhabi having a peak cooling load of 366 kW. The hybrid system was proposed to have a contribution of 60% renewable energy and 40% conventional nonrenewable energy. A feasibility study was carried out that demonstrated that the system could save approximately 670,700 kWh annually and reduce carbon dioxide emissions by 461 tons per year. The reduction in carbon dioxide emissions is equivalent of removing approximately 98 cars off the road. The payback period for the system was estimated to be 3.12 years. Full article

Concentrating photovoltaic (CPV) systems have emerged as a transformative technology that incorporates radiation concentrators into the photovoltaic system to enable radiation to be concentrated onto a receiver—the solar cells. Different concentrator configurations have different impacts on the performance of the solar photovoltaic system. This research work aims to analyze the impact of different concentrators, comparing and identifying the most efficient structures for capturing and concentrating solar energy. Aiming at a deep analysis and comparison among concentrators shapes, this research work presents a unique investigation and revision among different structures such as flat, triangular, LFR, and parabolic concentrators. Moreover, since, in the UV–visible–NIR region, metals’ reflectance varies with the incident wavelength, five metals were considered: aluminum, gold, platinum, copper, and silver. Additionally, the research focuses on studying the effects of parameters critical to the quality of the concentration on the power obtained and on the uniformity of the radiation distribution on the surface of the receiver, as well as on the number of solar rays that reach the receiver. The power on the receiver increases proportionally with the number of reflector concentrators in the system and their reflectance. For parabolic geometries, the optical efficiency is affected by the receiver’s shadow on the concentrator and, in the case of the LFR, by a non-ideal alignment of the reflectors in relation to the receiver. However, in parabolic concentrator geometries, uniformity is usually lower, since in these configurations, the radiation is focused on specific areas of the receiver, usually the central zone. Full article

Concentrator photovoltaics (CPVs) have demonstrated high electrical efficiencies and technological potential, especially when deployed in CPV–thermal (CPV-T) hybrid absorbers, in which the cells’ waste heat can be used to power industrial processes. However, the high cost of tracking systems and the predominant use of expensive multi-junction PV cells have caused the market of solar co-generation technologies to stall. This paper describes the development and testing of a low-cost alternative CPV cell based on crystalline silicone (c-Si) for use in a novel injection-molded parabolic hybrid solar collector, generating both, photovoltaic electricity and thermal power. The study covers two different c-Si cell technologies, namely, passive emitter rear contact (PERC) and aluminum back surface field (Al-BSF). Simulation design and manufacturing are described with special attention to fingerprinting in order to achieve high current carrying capacities for concentrated sunlight. It was determined that Al-BSF cells offer higher efficiencies than PERC for the considered use case. Solar simulator tests showed that the highly doped 4 cm² cells (50 ohm/sq) reach efficiencies of 16.9% under 1 sun and 13.1% under 60 suns at 25 °C with a temperature coefficient of −0.069%(Abs)/K. Finally, options to further improve the cells are discussed and an outlook is given for deployment in a field-testing prototype. Full article

A solar position sensor is an essential optoelectronic device used to monitor the sun’s position in solar tracking systems. In closed-loop systems, this sensor is responsible for providing feedback signals to the control system, allowing motor adjustments to optimize the angle of incidence and minimize positioning errors. The accuracy required for solar tracking systems varies depending on the specific photovoltaic concentration. In the case of the concentrator photovoltaic (CPV), it is normally essential to track the sun with a position error of less than ±0.6°. To achieve such precision, a proposed sensor configuration composed of low-cost embedded electronics and multifiber optical cable is subjected to characterization through a series of measurements covering range, sensitivity, and resolution. These measurements are performed in controlled indoor environments as well as outdoor conditions. The results obtained exhibit a resolution of $2.6\times {10}^{-3}$ degrees when the sensor is illuminated within its designated field of view of ±0.1°, particularly in external conditions. Considering the performance demonstrated by the proposed solar position sensor, coupled with its straightforward modeling and assembly compared to position sensors documented in the literature, it emerges as a promising candidate for integration into solar tracking systems. Full article

The concentrating solar spectrums splitter (CSSS)-driven solid oxide electrolysis cell (SOEC) is an attractive technology for green hydrogen production. The CSSS mainly comprises a concentrating photovoltaic (CPV), which converts sunlight with shorter wavelengths into electricity, and a concentrating solar collector (CSC), which converts the remaining sunlight into heat. However, the optimal splitting of the solar spectrums is a critical challenge that directly impacts the efficiency and normal operation of the SOEC. To address this challenge, a mathematical model integrating the CSSS with the SOEC is developed based on principles from thermodynamics and electrochemistry. By analyzing the requirements of electricity and heat for the SOEC, the model determines the optimal configuration and operational parameters. The results show that the anode-supported type, higher operating temperature, larger inlet flow rate of water, higher operating pressure of the SOEC, higher operating temperature of the CSC, and larger electric current of the CPV contribute to allocating more solar spectrums to the CSC for heat generation. However, the greater effectiveness of the heat exchangers, higher operating temperature, and larger optical concentration ratio of the CPV exhibit contrasting effects on the spectrum allocation. The obtained results provide valuable theoretical guidance for designing and running the CSSS for hydrogen production through SOEC. Full article

The optics is the component that most affects the concentrating photovoltaic (CPV) system performance, depending above all on the concentration factor and optical efficiency. Hence, a basic aspect is the concentrated solar flux measure on the receiving area, the evaluation of which is principally realized by indirect measurement methods. First, a literature review on indirect and direct methods used for the evaluation of concentrated solar flux and optical parameters is presented in this paper. The experimental measurement procedure, which is able to evaluate the optical parameters and concentrated solar flux in CPV systems, is also presented. The main steps of this procedure are represented by experimental system setup, sensor selection for concentrated solar flux estimation, identification of all the factors affecting optical performances, and development of an experimental campaign and output analysis. In particular, the optical characterization results of a CPV system are obtained by means of in-depth experimental analysis using Triple-Junction (TJ) solar cells with areas of 5.5 × 5.5 mm² and 10 × 10 mm². Three different setups have been analyzed related to primary and secondary optics composition. The main aim of this paper is the determination of a direct measuring technique, rarely adopted in literature in comparison to the established techniques, that is able to evaluate experimentally the optical parameter values and that can be standardized for other CPV systems. In particular, equations that link the optical concentration factor (C) and efficiency (η_opt) with focal distance (h) represent the fundamental results. They can be used for similar point-focus configurations presenting the same TJ cell size and ranges of C, η_opt and h. Finally, the experimental results of the direct method are compared with those of an indirect method adopting the same CPV system and operational conditions. Full article

Efficiency losses resulting from electrical mismatching in densely packed photovoltaic arrays present a significant challenge, particularly exacerbated in nonuniformly illuminated receivers and under varying temperatures. Serial configurations are particularly susceptible to radiation nonuniformities, while parallel systems are negatively affected by temperature variations. Various authors have recommended the incorporation of electrical voltage and current sources to mitigate these losses. This study explores different electrical connection configurations utilizing concentrated photovoltaic (CPV) cells and DC-DC electrical current converters. A self-adaptive microfluidic cell matrix cooling system is employed to mitigate thermal dispersion caused by the highly nonuniform illumination profile. The obtained results for each configuration are compared with the total electrical power produced by individual cells, operating under identical radiation and temperature conditions to those of the entire array. The results reveal a noteworthy increase in production across all studied configurations, with the parallel–series arrangement demonstrating the most promising practical utility. This configuration exhibited a remarkable 50.75% increase in power production compared with the standard series connection. Full article

In recent decades, the fight against climate change and the commitment to reduce greenhouse gases have shed a light on the production of energy from renewable sources, in particular those derived from solar energy. This has required the involvement of all stakeholders (producers, but also energy operators, authorities, distributors, and final consumers) which has led to the outline of a new scenario characterized by more efficient technologies, dedicated strategies and business models, and the research of alternatives solutions. Within solar technology, great attention has been given in recent years to concentrating solar power (CSP) technologies, both from research studies and technological development sides. This paper provides a theoretical framework based on a CSP literature review to define the state of the art and to identify research gaps and future research steps related to this technology. The work is based on an innovative bibliometric study to explore technical fields related to CSP, providing both a comprehensive framework with reference to the state of the art of the technology investigated, and a detailed analysis on CSP commercial applications, making the review a very useful tool for stakeholders and decision makers The results of the analysis: (1) help to clarify the technological advances of CSP, the strengths and weaknesses of the current technologies used (parabolic and tower systems are the most widespread), and indications of the prospects for dish systems; (2) identify an alternative to the economic problem that represents an obstacle to the diffusion of CSP, for example, by identifying the ability to couple it with thermal storage as a valid method to increase the flexibility of the system and reduce costs; (3) suggested hybrids, both with renewable and non-renewable technologies, identifying strengths and weaknesses for all the proposed proposals; (4) show that it is possible to identify new ongoing research such as that related to hydrogen production. This paper represents the first part of a larger research study developed within the SOLARGRID Project, which promotes and supports the development of innovative solutions for systems and components for CSP and concentrated photovoltaics (CPV) technologies, with the aim to enhance their energetic performances and economic competitiveness in applications for the distributed generation of both electric and thermal energy frameworks. The main findings of our study highlight that, though there is an increasing number of papers on the topic of CSP, several issues remain neglected. Full article

With energy efficiencies close to two times higher than traditional photovoltaic (PV), concentrated photovoltaic (CPV) systems represent a promising solution for solar power generation. In the same way, the converging Levelized Cost of Energy (LCOE) of both technologies favors interest toward CPV systems. In order to assess more clearly the potential of this technology, an up-to-date evaluation of the power electronic conversion techniques used in CPV to increase the yielded energy is crucial. This assessment not only sheds light on the latest advancements, but also provides insights into design trade-offs, performance limitations, and potential areas for improvement in CPV systems. This work focuses on the DC/DC converters used as an intermediary stage of conversion between the panels and a central grid-tied inverter. Electrical and economical metrics are used to compare actual converters developed and presented in a comprehensive literature review. Full article

Concentrator photovoltaic (CPV) technology offers an alternative to conventional photovoltaic systems, focusing on the concentration of solar radiation through the optics of the system onto smaller and more efficient solar cells. CPV technology captures direct radiation and requires precise module orientation. Traditional CPV systems use robust and heavy solar trackers to achieve the necessary alignment, but these trackers add to the installation and operating costs. To address this challenge, tracking-integrated CPV systems have been developed, eliminating the need for conventional trackers. These systems incorporate tracking mechanisms into the CPV module itself. This review presents a detailed classification of existing designs in the literature and provides an overview of this type of system with different approaches to integrated tracking including tracking concentrator elements, using external trackers, or employing internal trackers (the most researched). These approaches enable the automatic adjustment of the CPV system components to follow the movement of the Sun. The various tracking-integrated systems have different designs and performance characteristics. Significant progress has been made in developing tracking-integrated CPV systems with the aim to make CPV technology more competitive and expand its applications in markets where traditional CPV has been excluded. Full article

Energy needs have increased with global advancements and industrial revolutions. Electrical energy utilization shares a huge amount of energy with residential and industrial loads. Traditional energy resources are expensive and polluting, producing greenhouse gasses, which is a major environmental concern. Solar energy utilization is a cost-effective, sustainable, and green solution to meet the ongoing energy demand. Concentrator photovoltaic (CPV) systems are developed for energy conversion by providing high efficiency using multi-junction solar cells. This paper provides an overview of the recent optical developments in CPV systems and emerging technologies that are likely to shape the future of CPV systems. The objective of this article is to provide an overview of the issues that need to be resolved to improve the geometrical concentration, acceptance angle, uniformity, and optical efficiency of CPV systems. A comprehensive comparison is also presented on different types of solar concentrators. In addition, future research directions are presented to facilitate the continued growth and success of CPV systems. Furthermore, this review article gives an up-to-date and widespread overview of CPV technology, assesses its potential for various applications, and distinguishes the challenges and opportunities for future research and development. Full article
