In axial-flow combine harvesters, guide vanes direct crop material through the threshing and separation unit. The research object has the standard configuration of guide vane assembly; the six rear vanes are adjustable, while the two front vanes—located in the threshing zone—are fixed, which limits material flow control. In European conditions, where crop biomass is typically higher, improved control in the threshing area is essential to reduce losses and maintain grain quality. This study introduces a guide vane angle evaluation to combine performance and a modified guide vane system that enables all eight vanes to be adjusted simultaneously between 10–35°. Field tests were conducted using two identical combines (A and B) in the same winter wheat field, under identical operating conditions. Combine A was equipped with the modified system, while Combine B retained the original manufacturer configuration. Both machines operated at a rotor speed of 980 rpm and a concave clearance of 15 mm. Results showed that Combine A achieved higher throughput (23.78 kg s⁻¹), lower broken grain (0.18%), and lower fuel consumption (0.84 L t⁻¹) compared to Combine B (20.6 kg s⁻¹, 0.61%, 0.99 L t⁻¹, respectively); the separation and sieve losses were also reduced in Combine A. Analysis of the results demonstrated that full-range guide vane adjustability—including in the threshing zone—can improve crop flow, grain separation, and harvesting efficiency in high-yield conditions. Full article

Complex harvesting environments and varying crop conditions often lead to threshing cylinder blockage and increased entrainment loss in maize grain harvesters. To address these issues, an electric-driven automatic control system for maize threshing concave clearance based on real-time entrainment loss monitoring was developed. The system automatically adjusts concave clearance parameters at different harvesting speeds to maintain grain entrainment loss within an optimal range. First, an adjustable concave structure based on a crank-link mechanism was designed, with a threshing clearance adjustment range of 15–47 mm and motor rotation angle of 0–48°. Subsequently, an EDEM simulation model of the mixed material discharge inside the threshing cylinder was established to determine the optimal installation position of the entrainment loss monitoring sensor based on piezoelectric ceramic-sensitive elements. The sensor was positioned at the left tail end of the concave sieve, with a minimum distance of 58 mm between the sensitive plate centerline and threshing concave sieve and an installation angle of 65° relative to the horizontal plane. A maize threshing clearance control method based on fuzzy neural network PID control algorithm was proposed, and Simulink simulation optimization verified its superior performance with fast response speed. After system integration, field trials were conducted at low, medium, and high operating speeds with preset ideal entrainment loss intervals. The results showed that control was unnecessary at low speed, the control system-maintained entrainment loss within set range at medium speed, and maximum threshing clearance was needed at high speed. Finally, comparative trials of threshing performance with and without the control system were conducted at medium harvesting speed. Results showed that the entrainment loss rate decreased by 43.75% with the control system activated, significantly reducing maize threshing entrainment losses. This study overcame the barrier of maize threshing parameter adjustment being heavily reliant on manual experience and provided theoretical support for the intelligent grain harvesting equipment. Full article

Improving the performance of the threshing process is of utmost importance in enhancing the quality of sunflower seeds and minimizing power consumption in sunflower production. In this study, we developed a modified sunflower threshing machine by incorporating two types of threshing rotors, namely the angled rasp bar rotor and the tine bar rotor, as compared to the round bar rotor. The performance of these rotors was evaluated under various rotational speeds (150, 200, 250, and 300 rpm) and concave clearances (10, 15, and 20 mm). The evaluation parameters included machine throughput, the specific energy of threshing, the percentage of damaged seeds, the percentage of unthreshed seeds, and threshing efficiency. The results indicate that the specific energy decreased with an increase in rotor speed and a decrease in concave clearance, with the tine bar rotor exhibiting the lowest values. Threshing efficiency showed an increasing trend with higher rotor speeds and reduced concave clearance. The modifications made to the rotor design resulted in an enhanced threshing efficiency, with an improvement from 96.30% to 97.93% achieved at a rotor revolving speed of 300 rpm and a concave clearance of 10 mm. Moreover, the specific energy consumption reduced from 9.65 kW·h/ton to 5.09 kW·h/ton under the same operational conditions. These findings highlight the efficacy of the novel rotor design modifications in optimizing the performance of the stationary sunflower threshing machine, leading to improved efficiency and reduced energy consumption in sunflower seed threshing operations. Given its performance characteristics, this machine exhibits potential suitability for sunflower farms of small to medium scale. Full article

In order to determine the distribution pattern of the threshed mixture in the double longitudinal axial flow threshing device, single-factor experiments were conducted on the self-developed experimental platform for the double longitudinal axis threshing device. The experimental factors included drum speed, threshing clearance, and feed rate. The variations in the distribution of the threshed material along the axial and radial directions were examined. The results indicate that the mixed material after threshing exhibits uneven distribution both axially and radially. Along the axial direction, the mass of corn kernels initially increases and then decreases and is predominantly distributed in the front one-third section of the drum. Meanwhile, the mass of corn cobs continuously increases. In the radial direction, the mass of corn kernels and cobs is higher in the middle and on both sides, with the corn kernels being most concentrated in the middle and the corn cobs mostly on the sides. Combining the corn kernel breakage rate and the unthreshed rate, the optimal operating conditions were determined as follows: a drum speed of 400 r/min, a concave clearance of 50 mm, and a feed rate of 16 kg/s. Full article

Corn is a crucial crop and has a vital application value in many aspects of our lives. Mechanical grain harvesting is the developing direction of corn harvesting technology, with corn threshing as its most imperative procedure. The quality of the threshing device of the corn harvester has a major influence on its damage rate, loss rate, and other parameters. Therefore, it is of great significance to effectively lower the damage rate in the process of corn threshing. This review presents the research progress and the application status of corn threshing technology and corn threshing machinery. The conclusions and suggestions on low-damage corn threshing technology and corn threshing machinery are summarized to provide a reference for the reduction in the damage rate of mechanical grain harvesting and promote the development of mechanical grain harvesting technology. Full article

To improve the pod-picking efficiency of the combine harvester for both peanut seedlings and peanuts, a longitudinal axial flow pod-picking device is designed in this study. The fixation and adjustment modes of the pod-picking rod were determined. The pod-picking roller’s rotational speed, the pod-picking roller’s diameter, the pod-picking roller, the pod-picking roller’s effective rod-picking length, and the screw-feeding stirrer’s critical parameters were determined by theoretical calculation. A combined design of quadratic regression orthogonal rotation was achieved by using Box-Behnken design (BBD) response surface optimization analysis in Design-Expert, with the linear speed of the pod-picking roller, the clearance between the concave screen and the pod-picking roller, and the spacing between the pod-picking rods as the testing factors, and the picking rate and the crushing rate as the indicators. The optimized parameters are as follows: a linear speed of the pod-picking roller of 6.8 m/s, a clearance between the concave screen and the pod-picking roller of 28.5 mm, and a spacing between the pod-picking rods of 18.60 mm. The performances of conventional peanut full-feeding pod-picking devices and the proposed peanut root-disk full-feeding longitudinal axial flow pod-picking device were investigated and compared to clarify the pod-picking performance of the proposed peanut root-disk full-feeding longitudinal axial flow pod-picking device under optimized parameters. The results showed that the picking and crushing rates of the proposed peanut root-disk full-feeding longitudinal axial flow pod-picking device under optimized parameters were 98.93 and 1.62%, respectively, both of which were superior to those of conventional peanut full-feeding pod-picking devices. A pod-picking device matching the combine harvester for peanut seedlings and peanuts was processed under optimized parameters. Field tests revealed that the picking and crushing rates of the proposed harvester were 99.07 and 1.58%, respectively, meeting the industry standards. These findings are instrumental in the further improvement of peanut pod-picking devices. Full article

Rice is a widely cultivated food crop worldwide, and threshing is one of the most important operations of combine harvesters in grain production. It is a complex, nonlinear, multi-parameter physical process. The flexible threshing device has unique advantages in reducing the grain damage rate and has already been one of the major concerns in engineering design. Using the measured test database of the flexible threshing test bench, the rotation speed of the threshing cylinder (RS), threshing clearance of the concave sieve (TC), separation clearance of the concave sieve (SC), and feeding quantity (FQ) are used as the input layer. In contrast, the crushing rate (Y_P), impurity rate of the threshed material (Y_Z), and loss rate (Y_S) are used in the output layer. A 4-5-3-3 artificial neural network (ANN) model, with a backpropagation learning algorithm, was developed to predict the threshing performance of the flexible threshing device. Next, we explored the degree to which the inputs affect the outputs. The results showed that the R of the threshing performance model validation set in the hidden layer reached 0.980, and the root mean square error ($RMSE$) and the average absolute error ($MAE$) were less than 0.139 and 0.153, respectively. The built neural network model predicted the performance of the flexible threshing device, and the regression determination coefficient R² between the prediction data and the experimental data was 0.953. The results showed revealed that the data combined with the ANN method is an effective approach for predicting the threshing performance of the flexible threshing device in rice. Moreover, the sensitivity analysis showed that RS, TC, and SC were crucial factors influencing the performance of the flexible threshing device, with an average relative importance of 15.00%, 14.89%, and 14.32%, respectively. FQ had the least effect on threshing performance, with an average threshing relative importance of 11.65%. Our findings can be leveraged to optimize the threshing performance of future flexible threshing devices. Full article

The distribution of the threshed mixture is the link between the threshing and cleaning process during corn harvesting. Uneven distribution leads to a local accumulation of the mixture in the cleaning, resulting in high impurity and loss rate. Existing studies rarely concern the distribution of the corn threshed mixture. To address this problem, the distribution experiment was conducted in a self-made corn longitudinal axial threshing system to explore the distribution pattern, and both the particle size distribution and weight distribution of components (corn kernel, corn cob, and corn husk) were analyzed in this study. The results showed that the drum speed and concave clearance has a significant effect on particle size. Moreover, the impurities (corn cob, corn husk) increase with the drum speed. The weight distribution has an obvious uneven trend. In the axial weight distribution, corn kernels increased initially and decreased afterwards, while corn cobs and corn husks constantly increased. In the radial weight distribution, corn kernels and corn cobs were greater on both sides and less in the middle; corn husks had a clear left posterior accumulation. The increase in drum speed and feed rate and the decrease in concave clearance aggravated the inhomogeneity of the weight distribution. By analyzing the distribution characteristics, the drum speed of 400 r/min, concave clearance of 40 mm, and feed rate of 7 kg/s were confirmed to be optimal operating parameters. Under these conditions, the accumulation of the threshed mixture was weakened, which provided a satisfactory base for the subsequent cleaning. This study could provide a data support for the improvement of the threshing system. Additionally, this study is believed to have the potential to be used for the structural design of the cleaning system to reduce mixture accumulation and improve the cleaning performance. Full article

In order to solve the problems of high millet agglomerates rate, high damage rate, and high undelivered net loss rate in the process of mechanized harvesting of millet, a longitudinal axial flow-staggered flexible threshing device for millet was designed on the basis of the existing threshing device. The “staggered teeth” threshing drum and the micro rotating circular tube concave screen work together to realize the flexible and low damage threshing of millet. The pre experiment was carried out first, and the factors that have a great impact on the millet agglomerates rate, the undelivered net loss rate, and the damage rate were found to be the feeding amount, the rotating speed of the drum, and the threshing clearance. In order to further explore the influence of the interaction between the factors on the millet agglomerates rate, the undelivered net loss rate, and the damage rate, the regression orthogonal rotation combination test was carried out, and after the test, the optimal parameter combination of feeding amount, drum speed, and threshing clearance was determined. The results showed that when the feeding amount was 1.3 kg/s, the rotating speed of the drum was 762 r/min⁻¹ and the concave clearance was 15 mm, the millet agglomerates rate was 2.92%, the high undelivered net loss rate was 1.58%, and the damage rate was 0.37%. Full article

Poor shelling quality degrades the performance and profit of the peanut industry. The Hertz theory and the wear resistance experimental method were applied to identify a highly wear-resistant material guaranteeing a low mechanical damage rate (MDR) of peanut kernels. The Box–Behnken design method was applied in the experiment to illustrate the influence of the material’s elastic modulus (X₁), radius of curvature of the key parts (X₂), rotating speed of the shelling drum (X₃), and clearance between the shelling drum and concave screen (X₄) on MDR and shelling efficiency (SE). Depending on the analysis of variance, the weights of the influential factors were observed as X₁ > X₃ > X₄ > X₂. The mathematical models of MDR and SE were derived from the least squares’ method, and four-dimensional slice diagrams of the three most significant factors were used to illustrate the trends of MDR and SE. A multi-objective analysis provided the optimal combination of parameters as: X₁ = 10 MPa, X₂ = 12.77 mm, X₃ = 277.48 r/min, and X₄ = 24.24 mm, yielding MDR = 4.89% and SE = 97.91%. The results were further verified by a production trial test, proving that the proposed solution with the selected material, machine design, and working parameters were effective in improving peanut shelling quality. Full article

This study analyzed the engine operating condition curve of the corn kernel harvester. Field experiments identified the feed rate, concave clearance, and cylinder speed as the main factors affecting operating quality and efficiency. A ternary quadratic regression orthogonal center-of-rotation combined optimization test method was used to determine the feed rate, cylinder speed, and concave clearance as the influencing factors, and the engine speed variation rate, crushing rate, impurity rate, loss rate, and cylinder speed variation rate as the objective functions. A mathematical regression model was developed for the combination of operating quality indicators, efficiency indicators, and operating parameters of the corn kernel harvester. A non-linear optimization method was used to optimize the parameters of each influencing factor. The results showed that with a feed rate of 12 kg/s, a forward speed of 5 km/h, a cylinder speed of 360 r/min, and a concave clearance of 30 mm, the average crushing rate was 3.91%, the average impurity rate was 1.71%, and the kernel loss rate was 3.1%. This model could be used for the design and development of intelligent control systems. Full article

Trochoidal milling is a well-stablished machining strategy which still allows for the introduction of new approaches. This strategy can be applied to any kind of material, although it is usually associated to advanced materials, such as titanium and nickel alloys. This study is based on the adaptation of the feed speed of a milling tool with Ti-6Al-4V, so the chip width can be maintained constant without modifying the path geometry. A singularity in the experimental stage was to mill an Archimedes spiral groove instead of the conventional straight grooves. This made it possible to obtain a concave wall as well as a convex one and to optimize the amount of material used. The time efficiency compared to a constant feed, was slightly superior to 20%, reducing tool wear also. These techniques require milling machines with high mechanical and kinematic performance, as well as the absence of clearance between joints and a high acceleration capacity. Full article

S concentric threshing device can improve rice crop separation and transportation capabilities. As one of the main factors affecting the threshing performance of rice combine harvesters, the threshing gap can influence the grain unthreshed rate and the grain damage rate directly. However, the clearance between any threshing cylinder tooth and the concave grid is constant for the traditional threshing device, named the single threshing gap in this paper, resulting in a consistently high total loss rate (the sum of unthreshed and damaged grains). Therefore, multi-threshing gaps are proposed in this paper for the concentric threshing device to solve the above problem. To compare the threshing performance between the single threshing gap and the multi-threshing gaps, the movement process of rice mixture (grain, short straw, and long straw) was simulated using the discrete element method (DEM). The simulation results showed that the separation and transportation abilities of the multi-threshing gaps were not decreased, but the distribution of threshed output mixture was more even for the multi-threshing gaps. Furthermore, a field experiment was also carried out on a combine harvester to compare the total loss rate. The experiment results showed that the total loss rate of the concentric threshing device with multi-threshing gaps was reduced by 0.0593%, which was 5.77% less than the total loss rate of the concentric threshing device with a single threshing gap. Full article

The performance of electrical discharge machining for drilling holes decreases with machining depth because the conventional flushing and electrode cannot completely eliminate debris particles from the machining area. In this study, a modified electrode for self-flushing in the electrical discharge machining process with a step cylindrical shape was designed to improve machining performance for deep hole drilling. The experimental results of the step cylindrical electrode showed that the material removal rate increased by approximately 215.7%, 203.8%, and 130.4%, and the electrode wear ratio decreased by approximately 47.2%, 63.1%, and 37.3%, when compared with a conventional electrode for the diameters of 6, 9, and 12 mm, respectively. In addition, the gap clearance and concavity of the side wall of the drilled hole was reduced with the step cylindrical electrode. The limited high flank of the electrode led to an increase in the escape area of the debris that was partially removed from the machining area, and the limited secondary spark on the side wall of the electrode resulted in a reduction in machining time. Full article

Corn harvesting mode has gradually changed from ear harvesting to direct grain harvesting. In view of the problems of high moisture content in corn harvesting in China, such as the rates of broken grains (BGR) and uncleared grains (UGR) being too high, a new single longitudinal axial threshing cylinder was designed, which mainly included a cylinder spindle, a spiral feeding inlet, a T-type rasp bar, a separating straight rod, and a spiral extracting rod. Firstly, the three states of grain during the threshing process and the key influence factors of threshing and force analysis of corn ears in the threshing device were analyzed, then the structure of the threshing cylinder was designed, and its parameters were determined by theoretical analysis results. The arrangement mode of threshing elements adopted a combination of a T-type rasp bar, a separating straight rod, and a spiral extracting rod with a 6-head spiral pattern and an arrangement step of 250 mm. Secondly, the arrangement step of threshing elements was determined by discrete element method solution (DEM) simulation; the result showed that the average movement velocity was 55.04 m/s and the threshing time was 6–8 s. Finally, a multiple factors experiment of the threshing device was carried out, and the result showed that the order of the effect factors of the BGR and UGR was cylinder rotational speed > concave clearance > feed amount. When cylinder rotational speed was 309.17 r/min, concave clearance was 35.48 mm, and the feed amount was 6.13 kg/s. The verification experiment result showed that the BGR and UGR were 1.24% and 1.33%, respectively, which meet standard requirements. The research results could provide a reference for the design of a high moisture content grain threshing device and combine harvester. Full article
