Search Results (47)

Due to the lack of rotational symmetry, off-axis two-mirror freeform optical systems usually exhibit coupled alignment degrees of freedom and poor sensitivity-matrix conditioning, which increase the difficulty of alignment. To address this issue, a geometrically constrained alignment method based on a multi-zone computer-generated hologram (CGH) is proposed. A multi-zone CGH integrating null compensation and mark projection on a single substrate was designed to provide both wavefront and spatial references. In combination with a staged alignment procedure, the projected optical marks were used to assist in establishing the relative positional relationship between the interferometer–CGH subsystem and the PM-SM system, while also providing geometric references for secondary-mirror pose adjustment during wavefront-guided iterative alignment. Results from multiple alignment experiments show that the mean wavefront RMS was $0.0577\mathrm{\lambda }$ at 632.8 nm, with a standard deviation of $0.004\mathrm{\lambda }$. These results suggest that, under the present experimental conditions, the proposed method exhibits good repeatability and convergence stability and can provide a reference for the alignment of freeform optical payloads. Full article

Mixed-scene holographic 3D display for film and television visual content presentation remains challenging because recorded digital holograms and computer-generated holograms (CGHs) are produced under different numerical and hardware constraints. Direct hologram superposition typically causes strong zero-order interference, diffraction efficiency degradation, and sampling pitch mismatch between the recording sensor and the replay panel, while conventional resizing reduces the effective replay aperture and narrows the available parallax. To address these issues, this paper proposes a zero-order-suppressed single-hologram fusion framework with parallax-preserving digital resizing. A recorded digital hologram is first processed by Gaussian high-pass filtering to suppress the dominant zero-order component, then resampled to match the LCOS replay pitch, and finally normalized and fused with a CGH generated through bipolar intensity encoding. On this basis, two resizing routes are developed: a spatial-domain method for aperture-preserving whole-scene scaling and a frequency-domain method for object-selective scaling and translation. Optical validation on a three-channel LCOS prototype shows that the quantitative diffraction efficiency analysis predicts an increase from approximately 10.1% to 20.05% per reconstructed object for the two-hologram fusion case, and the revised experimental results are consistent with this improvement trend. The experiments further verify replay scaling at multiple factors, the selective manipulation of physical and virtual objects, mixed-scene color replay, and occlusion-consistent depth ordering. Together with the distortion analysis, these results demonstrate improved replay visibility after fusion while maintaining geometric controllability and effective replay aperture. By relying on hologram-domain preprocessing and resizing rather than full mixed-scene recomputation, the proposed method also reduces computational burden. The study therefore provides an efficient and controllable mixed-scene holographic replay framework for visually enriched film and television content presentation, although its depth applicability remains bounded and dedicated real-time timing benchmarks are left for future work. Full article

High-precision centering alignment of the lens is crucial for ensuring the imaging quality of refractive optical systems. A multi-zone computer-generated hologram (MZ-CGH) was designed and utilized for centering a large-aperture refractive infrared lens. Different from traditional methods that use the line connecting the geometric centers of lens spheres as the optical axis for alignment, the minimization of transmitted wavefront aberrations detected via interferometry is employed as the target for lens centering. According to the structure design, the large-aperture lens is divided into a front barrel integrated with lenses 1–3, a back barrel integrated with lenses 4–5, and a separated lens 6. An MZ-CGH contains three main zones with compensation information for testing the transmitted wavefront of lenses 1–3, according to the alignment and centering sequence. The method is applied to align and analyze errors in an infrared optical system with a clear aperture of 400 mm, achieving lens decenter errors better than 5 μm. After alignment, the wavefront errors of the infrared optical system within ±7° of the field of view are better than RMS 0.07λ, with an average MTF higher than 0.5, demonstrating significant value for engineering applications. Full article

Traditional CGH algorithms often face a trade-off between computational efficiency and reconstruction fidelity. In this study, we propose a hybrid hologram synthesis framework that combines geometric and physical optics to generate phase-only holograms for SLM. A freeform surface obtained from geometric optics provides a smooth continuous phase initialization for the iterative CGH solver, which substantially reduces the number of required iterations. We further improve the SGD-based optimization by introducing an adaptive step size factor and explicit phase constraints during the update process. These modifications guide the solution toward a smooth phase profile, thereby suppressing high-frequency phase noise and mitigating speckle artifacts. Compared with a standard CGH algorithm, the proposed method achieves an approximately four times improvement in computational efficiency while maintaining reconstruction quality. Finally, we integrate the resulting holograms into an eye tracker–based autofocus system, enabling real-time adaptation to changes in the human eye’s focal state. Full article

High-speed realization of computer-generated holograms (CGHs) is a crucial problem in the field of modern 3D visualization and optical image processing system development. Binary CGHs can be realized using high-resolution, high-speed spatial light modulators such as ferroelectric liquid crystals on silicon devices or digital micro-mirror devices providing the high throughput of optoelectronic systems. However, the quality of holographic images restored by binary CGHs often suffers from distortions, background noise, and speckle noise caused by the limitations and imperfections of optical system components. The present manuscript introduces a method based on the optimization of CGH models directly in the optical system with a camera-in-the-loop configuration using effective direct search with a random trajectory algorithm. The method was experimentally verified. The results demonstrate a significant enhancement in the quality of the holographic images optically restored by binary-phase CGH models optimized through this method compared to purely digitally generated models. Full article

This paper presents a hybrid fabrication method for producing anti-counterfeit optical elements on plastic products and surfaces targeting multidiscipline applications such as food, pharmaceuticals, luxury goods, and electronics industry. Our proposition combines the design flexibility and rapid prototyping capabilities of stereolithography three-dimensional (SLA 3D) printing with nanoimprint lithography (NIL) to create unique optical security tags onto plastic surfaces. The proposed approach is cost-effective, scalable, and tailored for mass production, addressing the increasing demand for secure and reliable authentication solutions. NIL is substrate agnostic, offering material selection versatility and realization of security tags onto polymer surfaces, which are widely used across various sectors such as packaging industry, medical devices, and flexible electronics. This enables integration into a wide range of materials, further enhancing applicability on flat and 3D shape surfaces. An evaluation method based on digital reconstruction has been used to ensure robust performance and verification of the produced optical security features. The results demonstrate that this hybrid approach provides a reproducible and technically feasible path for the development of optical anti-counterfeiting tags suitable for large-scale implementation, particularly within fast-moving consumer goods (FMCG). Full article

We present a deep learning-based approach to optimize the central angle between adjacent camera viewpoints for the efficient generation of natural 360-degree holographic 3D content. High-quality 360-degree digital holograms require the acquisition of densely sampled RGB–depth map pairs, a process that traditionally requires significant computational costs. Our method introduces a novel pipeline that systematically evaluates the impact of varying central angles—defined as the angular separation between equidistant viewpoints in an object-centered coordinate system—on both depth map estimation and holographic 3D image reconstruction. By systematically applying this pipeline, we determine the optimal central angle that achieves an effective balance between image quality and computational efficiency. Experimental investigations demonstrate that our approach significantly reduces computational demands while maintaining superior fidelity of the reconstructed 3D holographic images. The relationship between central angle selection and the resulting quality of 360-degree digital holographic 3D content is thoroughly analyzed, providing practical guidelines for the creation of immersive holographic video experiences. This work establishes a quantitative standard for the geometric configuration of viewpoint sampling in object-centered environments and advances the practical realization of real-time, high-quality holographic 3D content. Full article

Against the backdrop of the rapid advancement of intelligent speech interaction and holographic display technologies, this paper introduces an interactive holographic display system. This paper applies 2D-to-3D technology to acquisition work and uses a Complex-valued Convolutional Neural Network Point Cloud Gridding (CCNN-PCG) algorithm to generate a computer-generated hologram (CGH) with depth information for application in point cloud data. During digital human hologram building, 2D-to-3D conversion yields high-precision point cloud data. The system uses ChatGLM for natural language processing and emotion-adaptive responses, enabling multi-turn voice dialogs and text-driven model generation. The CCNN-PCG algorithm reduces computational complexity and improves display quality. Simulations and experiments show that CCNN-PCG enhances reconstruction quality and speeds up computation by over 2.2 times. This research provides a theoretical framework and practical technology for holographic interactive systems, applicable in virtual assistants, educational displays, and other fields. Full article

We present a novel approach for securing valuable documents using a complementary approach based on the encryption of computer-generated holograms (CGHs). The proposed approach utilizes the well-known iterative Fourier transform algorithm (IFTA) to generate a phase-only CGH for valuable digital and/or physical documents. The generated CGH is then secured by binary phase randomization, which is implemented using the symmetric encryption technique, exclusive OR (XOR). The reconstruction process for the calculated secured CGHs varied slightly depending on whether the documents were digital or physical. For digital documents, reconstruction was performed using a symmetric decryption key followed by an inverse Fourier transform (IFFT). On the other hand, the reconstruction of the physical document involved two additional processes: printing and scanning. To evaluate the quality of the digital reconstruction, the speckle signal-to-noise ratio (SSNR) was estimated for both printed grayscale and binary CGHs. The security analysis of the XOR-encrypted CGH was quantitatively evaluated to ensure the level of protection against various cryptographic attacks such as plaintext and brute-force attacks. The results revealed that the combination of phase CGHs and the XOR encryption/decryption provides robust cryptographic protection for valuable documents, benefiting document security and anti-counterfeiting. Full article

This work presents an optical encryption process for various types of information related to 3D worlds (scenes) or 2D images, utilizing Computer-Generated Holograms (CGHs). It also introduces a modification to the Dual Random Phase Encoding (DRPE) encryption algorithm by incorporating pixel shuffling. This proposal enables the use of either a single key for both pixel shuffling and phase mask definition or two independent keys. The latter option is particularly advantageous in applications that require the involvement of two independent agents to retrieve the original plaintext. The dimension of the CGHs determines the size of the keys based on the random generation of values by cryptographically secure algorithms, so the use of arithmetic encryption is proposed for data compression. However, this proposal allows the use of other algorithms described in the literature to generate the shuffle and phase matrices. The complete workflow is described starting from the synthesis of a 3D scene, defined by a mesh of triangles with shape and appearance modeling, or 2D images of any level of geometric or visual complexity using computer graphics; its storage in a CGH, the encryption and decryption process, and finally, the results obtained in the laboratory and by simulation are shown. The similarity between different encryption levels is measured by the Pearson Coefficient to evaluate the results obtained. Full article

A spatial light modulator (SLM) is a key element in several applications, but it is subject to surface deformation due to manufacturing imperfections or environmental factors. Therefore, the current study aims to analyze and compensate for such deformations in a phase-only SLM using a Michelson interferometer. The recorded interferogram represents the interference between the wavefront reflected from the SLM surface (object wave) and a reference wave. Noise in the recorded interferogram can degrade the accuracy of phase measurements. Various digital filtering techniques were applied to improve the signal-to-noise ratio (SNR) of the interferogram. The filtered interferogram enabled accurate phase extraction through Fourier transform processing and side peak selection using a spatial carrier frequency method. Additionally, phase errors caused by the tilt of the reference beam were corrected. Thereafter, the conjugate of the corrected phase distribution was used to calculate a phase-only computer-generated hologram (CGH), which was displayed on the SLM to compensate for surface deformations. The effectiveness of the proposed compensation procedure was confirmed by a second phase measurement, which demonstrated improved SLM performance. This study highlights the impact of combining the interferometric techniques with digital processing for precise surface deformation analysis. Full article

Traditional methods of hologram generation, such as point-, polygon-, and layer-based physical simulation approaches, suffer from substantial computational overhead and generate low-fidelity holograms. Deep learning-based computer-generated holography demonstrates effective performance in terms of speed and hologram fidelity. There is potential to enhance the network’s capacity for fitting and modeling in the context of computer-generated holography utilizing deep learning methods. Specifically, the ability of the proposed network to simulate Fresnel diffraction based on the provided hologram dataset requires further improvement to meet expectations for high-fidelity holograms. We propose a neural architecture called Holo-U²Net to address the challenge of generating a high-fidelity hologram within an acceptable time frame. Holo-U²Net shows notable performance in hologram evaluation metrics, including an average structural similarity of 0.9988, an average peak signal-to-noise ratio of 46.75 dB, an enhanced correlation coefficient of 0.9996, and a learned perceptual image patch similarity of 0.0008 on the MIT-CGH-4K large-scale hologram dataset. Full article

The optimization of imaging accuracy and speed is a crucial issue in the development of computer-generated holograms (CGH) for three-dimensional (3D) displays. This paper proposes an optimized iterative algorithm based on the angular spectrum method (ASM) to achieve high-quality holographic imaging across multiple planes. To effectively utilize spatial resources for multi-image reconstruction and mitigate the speckle noise caused by the overlapping of target images, constraint factors are introduced between different layers within the same region. The seeking rule of the constraint factor is also analyzed. By utilizing both constraint factors and variable factors, the presented method is able to calculate phase holograms for target figure imaging at four different planes. Simulation and experimental results demonstrate that the proposed method effectively improves the overall quality of the different planes, thus holding great potential for wide-ranging applications in the field of holography. Full article

A large-aperture silicon carbide (SiC) aspheric mirror has the advantages of being light weight and having a high specific stiffness, which is the key component of a space optical system. However, SiC has the characteristics of high hardness and multi-component, which makes it difficult to realize efficient, high-precision, and low-defect processing. To solve this problem, a novel process chain combining ultra-precision shaping based on parallel grinding, rapid polishing with central fluid supply, and magnetorheological finishing (MRF) is proposed in this paper. The key technologies include the passivation and life prediction of the wheel in SiC ultra-precision grinding (UPG), the generation and suppression mechanism of pit defects on the SiC surface, deterministic and ultra-smooth polishing by MRF, and compensation interference detection of the high-order aspheric surface by a computer-generated hologram (CGH). The verification experiment was conducted on a Ø460 mm SiC aspheric mirror, whose initial surface shape error was 4.15 μm in peak-to-valley (PV) and a root-mean-square roughness (Rq) of 44.56 nm. After conducting the proposed process chain, a surface error of RMS 7.42 nm and a Rq of 0.33 nm were successfully obtained. Moreover, the whole processing cycle is only about 216 h, which sheds light on the mass production of large-aperture silicon carbide aspheric mirrors. Full article

Metasurface regulates the polarization, phase, amplitude, frequency, and other characteristics of electromagnetic waves through the subwavelength microstructure. By using its polarization characteristics, it can realize the functions of optical rotation and vector beam generation. It is the most widely used method of regulation. However, parallel optical manipulation, imaging, and communication usually require polarization-insensitive focused (or vortex) arrays of beams, so polarization-independent wavelength multiplexing optical systems need to be considered. In this paper, the genetic algorithm combined with the computer-generated hologram (CGH) is used to control the transmission phase of the structure itself, and on the basis of wavelength multiplexing, the corresponding array of focused or vortex beams without the polarization selection property is realized. The simulation software results show that the method has a huge application prospect in optical communication and optical manipulation. Full article
