Search Results (22)

This study systematically investigates the dynamic evolution of chemical regimes in pulsed coaxial dielectric barrier discharge (DBD) plasma under atmospheric pressure using mass spectrometry. An innovative real-time mass spectrometric monitoring methodology was established, enabling the dynamic tracking of the formation and consumption processes of key reactive species such as ozone (O₃) and nitrogen oxides (NO_x). Energy density was the critical parameter governing the evolution of gaseous chemical components, with a quantitative elucidation of the regulatory mechanisms of air flow rate and control voltage on plasma chemical regime transition kinetics. Experimental results revealed significant parametric correlations: Under a constant control voltage of 140 V, increasing the gas flow rate from 0.5 to 5.5 L/min prolonged the transition duration from O₃-NO_x coexistence regime to a NO_x-dominant regime from 408 s to 1210 s. Conversely, at a fixed flow rate of 3.5 L/min, elevating the control voltage from 120 V to 140 V accelerated this transition, reducing the required time from 2367 s to 718 s. Parametric sensitivity analysis demonstrated that control voltage exerts approximately 3.3 times greater influence on transition kinetics than flow rate variation. Through comprehensive analysis of the formation and consumption mechanisms of N, O, O₃, and NO_x species, we established a complete plasma chemical reaction network. This scheme provides fundamental insights into reaction pathways while offering practical optimization strategies for DBD systems. For aerospace applications, this work holds particular significance by demonstrating that the identified control parameters can be directly applied to plasma-assisted treatment of propellant wastewater at launch sites, where the efficient removal of nitrogen-containing pollutants is crucial. These findings advance both the fundamental understanding of atmospheric-pressure plasma chemistry and the engineering applications of plasma-based environmental remediation technologies in aerospace operations. Full article

This study investigates the aerodynamic and aeroacoustic performance of a novel two-stage two-bladed coaxial propeller that is axially and angularly spaced. Aerodynamic propulsive thrust and efficiency are validated and evaluated using a Reynolds-averaged Navier–Stokes computational fluid dynamics (CFD) model for the two-bladed APC27x13 propeller. Aeroacoustic assessment is conducted using a Ffowcs Williams–Hawkings integral model. A four-bladed coplanar APC27x13 propeller is simulated and considered as the baseline propeller. The CFD results suggest that changes in the rotor thrust for the coaxial blades are within $3\%$ for propellers with $0.25D$ axial spacing (where D is the propeller diameter) and ${30}^{\circ }$ angular spacing for the advance ratio of $J=0.3$–$0.5$. The aeroacoustic assessment for $J=0.3$ reveals that blades with ${30}^{\circ }$ and ${60}^{\circ }$ azimuthal spacing and $0.25D$ axial spacing significantly reduce noise compared to the baseline propeller. The reduction is attributed to the redistribution of tonal noise blade passing frequencies, resulting in a reduction in the A-weighted noise levels by up to 2 dBA. Additionally, the study accounts for the effect of the blade tip Mach number, concluding that a tip Mach number ranging between $0.7$ and $0.9$ is optimal for noise reduction in the ${30}^{\circ }$ configuration. The results highlight the potential noise reduction benefits of uneven axial and angular blade spacing while maintaining similar aerodynamic performance. Full article

This article presents an optimal tracking controller retrofitted with a nonlinear adaptive integral compensator, specifically designed to ensure robust and accurate positioning of Vertical Take-Off and Landing (VTOL) Unmanned Aerial Vehicles (UAVs) that utilize contra-rotating motorized propellers for differential thrust generation. The baseline position controller is synthesized by employing a fixed-gain Linear Quadratic Integral (LQI) tracking controller that stabilizes position by tracking both state variations and pitch-axis tracking error integral, which adjusts the voltage to control each coaxial propeller’s speed accurately. Additionally, the baseline tracking control law is supplemented with a rate-varying integral compensator. It operates as a nonlinear scaling function of the tracking-error velocity and the braking acceleration to enhance the accuracy of reference tracking without sacrificing its robustness against exogenous disruptions. The controller’s performance is analyzed by performing experiments on a tailored hardware-in-the-loop aero-pendulum testbed, which is representative of VTOL UAV dynamics. Experimental results demonstrate significant improvements over the nominal LQI tracking controller, achieving 17.9%, 61.6%, 83.4%, 43.7%, 35.8%, and 6.8% enhancement in root mean squared error, settling time, overshoot during start-up, overshoot under impulsive disturbance, disturbance recovery time, and control energy expenditure, respectively, underscoring the controller’s effectiveness for potential UAV and drone applications under exogenous disturbances. Full article

Many diseases produce pathological changes in the fundus; analyzing the retinopathy of the fundus could help diagnose diseases in time. A fundus camera is a medical imaging device that specializes in taking fundus images to diagnose hypertension, coronary heart disease, diabetes, and others. The fundus optical imaging system is the core part of it. Nevertheless, the conventional fundus optical imaging system is large and not suitable for mobile examination and follow-up use. So, it has not been widely used in medical institutions. In this paper, a miniaturized fundus optical imaging system based on aspheric technology and non-coaxial illumination is proposed. The length of the imaging system is only 34.6$\mathrm{mm}$, the field of view is 50°, and the MTF curve is greater than 0.2 at 100 $\mathrm{lp}/\mathrm{mm}$, which can resolve the structure of 5$\mathrm{um}$. The illumination system adopts a non-coaxial annular array illumination structure to avoid occlusion of the imaging system. Our study effectively tackles the pressing predicament of fundus optical system miniaturization. This innovative paradigm harbors the potential to revolutionize fundus image data acquisition, propelling the field of fundus diagnosis forward and efficiently catering to crucial applications, improving the versatility of fundus examination, and providing technical support for the intelligent diagnosis system. Full article

Electric vertical takeoff and landing (eVTOL) vehicles possess high payload transportation capabilities and compact design features. The traditional method of increasing propeller size to cope with high payload is no longer applicable. Therefore, this study proposes the use of coaxial counter-rotating propellers as the lift system for eVTOL vehicles, consisting of two coaxially mounted, counter-rotating bi-blade propellers. However, if the lift of a single rotating propeller is linearly increased without considering the lift loss caused by the downwash airflow generated by the upper propeller and the torque effect of the lift system, it will significantly impact performance optimization and safety in the eVTOL vehicles design process. To address this issue, this study employed the Moving Reference Frame (MRF) method within Computational Fluid Dynamics (CFD) technology to simulate the lift system, conducting a detailed analysis of the impact of the upper propeller’s downwash flow on the aerodynamic performance of the lower propeller. In addition, the aerodynamic performance indicators of coaxial counter-rotating propellers were quantitatively analyzed under different speed conditions. The results indicated significant lift losses within the coaxial contra-rotating propeller system, which were particularly notable in the lift loss of the lower propeller. Moreover, the total torque decreased by more than 93.8%, and the torque was not completely offset; there was still a small torsional effect in the coaxial counter-rotating propellers. The virtual testing method of this study not only saves a significant amount of time and money but also serves as a vital reference in the design process of eVTOL vehicles. Full article

The spray and combustion characteristics of a gas-centered swirl coaxial (GCSC) injector used in oxidizer-rich staged combustion cycle engines were analyzed. The study focused on varying the recess ratio, presence of gas swirl, and swirl direction to improve injector performance. The impact of the recess ratio was assessed by increasing it for gas jet-type injectors with varying momentum ratios. Gas-swirl effects were studied by comparing injectors with and without swirl against a baseline of a low recess ratio gas injection. In atmospheric pressure-spray experiments, injector performance was assessed using backlight photography, cross-sectional imaging with a structured laser illumination planar imaging technique (SLIPI), and droplet analysis using ParticleMaster. Increasing the recess ratio led to reduced spray angle and droplet size, and trends of gas swirl-type injectors were similar to those of high recess ratio gas jet-type injectors. Combustion tests involved fabricating combustion chamber heads equipped with identical injectors, varying only the injector type. Oxidizer-rich combustion gas, produced by a pre-burner, and kerosene served as propellants. Combustion characteristics, including characteristic velocity, combustion efficiency, and heat flux, were evaluated. Elevated recess ratios correlated with increased characteristic velocity and reduced differences in the momentum–flux ratios of injectors. However, increasing the recess ratio yielded diminishing returns on combustion efficiency enhancement beyond a certain threshold. Gas swirling did not augment characteristic velocity but notably influenced heat flux distribution. The trends observed in spray tests were related to combustion characteristics regarding heat flux and combustion efficiency. Additionally, it was possible to estimate changes in the location and shape of the flame according to the characteristics of the injector. Full article

Due to their contact-free and low-maintenance features, magnetic gears (MGs) have been increasingly investigated to amplify the torque of electric motors in electric vehicles (EVs). In order to meet the requirements of propelling EVs, it is essential to design an MG with a high torque density. In this paper, a novel flux-focusing Halbach coaxial MG (FFH-CMG) is proposed, which combines the advantages of flux focusing and Halbach permanent magnet (PM) arrays. The proposed structure has a higher torque performance and greater efficiency than conventional structures. A multi-objective design optimization based on a surrogate model is implemented to achieve the maximum volumetric torque density (VTD), torque-per-PM volume (TPMV), and efficiency, as well as the minimum torque ripple, in the proposed FFH-CMG. The employed optimization approach has a higher accuracy and is less time-consuming compared to the conventional optimization methods based on direct finite-element analysis (FEA). The performance of the proposed FFH-CMG is then investigated through 2D-FEA. According to the simulation results, the optimized FFH-CMG can achieve a VTD of 411 kNm/m³, and a TPMV of 830 kNm/m³, which are significantly larger than those of the existing MGs and make the proposed FFH-CMG very suitable for EV applications. Full article

Ducted UAVs have attracted much attention because the duct structure can reduce the propeller tip vortices and thus increase the effective lift area of the lower propeller. This paper investigates the effects of parameters on the aerodynamic characteristics of ducted UAVs, such as co-axial twin propeller configuration and duct structure. The aerodynamic characteristics of the UAV were analyzed using CFD methods, while the impact sensitivity analysis of the simulation data was sorted using the orthogonal test method. The results indicate that, while maintaining overall strength, increasing the propeller spacing by about 0.055 times the duct chord length can increase the lift of the upper propeller by approximately 1.3% faster. Reducing the distance between the propeller and the top surface of the duct by about 0.5 times the duct chord length can increase the lift of the lower propeller by approximately 7.7%. Increasing the chord length of the duct cross-section by about 35.3% can simultaneously make the structure of the duct and the total lift of the drone faster by approximately 150.6% and 15.7%, respectively. This research provides valuable guidance and reference for the subsequent overall design of ducted UAVs. Full article

This paper presents the development, analysis, and performance evaluation of a novel transversal-feed Electron Cyclotron Resonance Plasma Thruster (ECRPT). The ECRPT operates based on the transversal-feed principle and incorporates optimized structural design. Through extensive simulation of the S-parameters of the antenna, optimal antenna sizes are determined for both coaxial and transversal-feed configurations. Additionally, the electric field intensity of the antenna is simulated for both feed structures, revealing higher electric field intensity in the transversal structure, thereby promoting discharge. We employ the drift-diffusion model to calculate the number density of electrons in the discharge chamber and ascertain that the number density can reach an order of magnitude of 10¹⁸ m⁻³. Experimental discharge tests are conducted under various microwave power conditions, demonstrating that the thruster can initiate and cease operation with an incident power as low as 5 W, significantly lower than that of traditional coaxial feed structures. At a power level of 20 W, the ion current density can attain 3 A/m². Moreover, the transversal-feed thruster exhibits exceptional performance when the power exceeds 10 W, and the propellant flow rate ranges from 0.5 SCCM to 5 SCCM. The superior performance characteristics of the proposed thruster configuration make it a promising candidate for applications demanding efficient and low-power plasma propulsion systems. Full article

A numerical method is used to evaluate the influence of propeller parameters on the aerodynamic performance of shrouded coaxial dual rotors in hover. Compared with the open-rotor configuration, the shrouded rotors reduce the tip vortex, resulting in a higher thrust and figure of merit (FoM). The varying inflow distribution over the inlet lip of the shroud introduces a different working condition for the propellers, thereby providing an opportunity for propeller parameter optimization. The pitch length, chord length, and tip clearance are chosen as the design parameters to improve the aerodynamic performance of the rotors. When the pitch lengths of the upper and lower propellers increase, the shrouded rotors outperform the original ones in both the coefficient of thrust (C_t) and in terms of the (FoM). The results show that increasing the chord length improves the C_t but that the (FoM) is almost unaffected. Moreover, smaller tip clearance can significantly improve the aerodynamic performance of the shrouded rotors. Results presented in this work provide insights into the parametric design and optimization of shrouded rotors. Full article

Hot fire tests of a multi-injector research combustor were performed with liquid-oxygen and liquefied-natural-gas (LOX/LNG) propellants at chamber pressures from 30 up to 67 bar, hence at conditions similar to an upper stage rocket engine. Within these tests shear coaxial injectors were tested with and without a recessed LOX post. In both configurations, operating conditions with flames anchored at the LOX post tip and thus, if available, pre-combustion in the recess volume as well as lifted flames were observed. Flame anchoring was indirectly detected via acoustic measurements, using mean speed of sound to indicate the presence of flame in the head end of the combustion chamber. While the injector without recess showed only stable combustion irrespective of the flame anchoring behavior, the recessed injector featured short-lived bursts of oscillatory combustion and sustained combustion instabilities. Analysis of the test data showed that stable flame anchoring could not be ensured at momentum flux ratios below 20 for a non-recessed and below 45 for a recessed injector. Full article

Multirotors are gaining great importance in the layout of innovative and more agile mobility. In this framework, a possible solution to developing an aircraft complying with the stringent size requirements characterizing this type of application may be a coaxial rotor configuration. To exploit several possibilities linked to coaxial rotors, a scaled experimental model is designed to evaluate the performances of the counter-rotating propeller system, specifically regarding the distance between the two propellers. Both thrust and noise are considered as parameters of interest. Two brushless motors are deployed, whereas the propellers’ angular velocity, in terms of rounds per minute (rpm), is controlled by an external control system. Tests are conducted on both single isolated propellers as well as on the counter-rotating system: the two propellers and their respective motors are characterized regarding the thrust. Furthermore, a comparison with a numerical model is performed. Noise evaluation on the single propeller shows a motor contribution prevalence at a low rpm range (1140–1500 rpm) and a propeller prevalence for angular velocities higher than 1860 rpm. By varying the distances between the propellers, a sensitivity analysis is performed with the aim of identifying the optimum configuration, taking into account both noise and thrust performances. Full article

The momentum flux ratio (MFR) significantly affects the mixing characteristics and combustion efficiency of propellants in rocket engine injectors. The spray characteristics of three gas-centered swirl-coaxial injectors used in a full-scale combustion test were investigated according to the change in the momentum flux ratio. The difference in combustion efficiency was analyzed through the comparison with combustion test results using spray visualization and quantification. The spray cross-sectional shape and droplet distribution were measured using a structured laser illumination planar imaging technique. As the swirl effect was more apparent at a low MFR, the flow rate of the liquid that was sprayed outside was high. The flow rate of the liquid sprayed around the gas injection increased with the MFR. The Sauter mean diameter (SMD) of each injector liquid spray was obtained using the laser shadow imaging method. The SMD decreased as the MFR of all injector types increased, and the injector with a high liquid flow rate and small SMD injected towards the gas center exhibited higher combustion efficiency than the injector with a dominant liquid spray and the large SMD at a large injection angle. The outcomes of the study could help contribute to the increase in the combustion efficiency of the full-scale staged combustion cycle engine combustor. Full article

To determine the dynamic characteristics of a gas-centered swirl coaxial injector under backpressure, an experimental system of dynamic injection in a backpressure chamber was constructed. Filtered water and nitrogen were used as simulant media for rocket propellants, which are typically used with this kind of injector. An inertial flow pulsator was manufactured to generate the pulsation of the flows that feed to the liquid injector. The electric conductance method was adopted to measure liquid film thickness. After the pulsation of incoming flow in the feedline was tested, and the operating conditions for the injector to start pulsating were validated, the effects of the chamber backpressure and the recess length of the injector on the dynamic characteristics of spray, such as liquid film thickness, breakup length, and amplitude of pulsation, have been investigated in detail. Experimental results demonstrated that the increase in chamber backpressure prompts the liquid sheet to rupture earlier with a shorter breakup length, which results from the increased density of the ambient gas. Chamber backpressure suppresses the pulsation of the outlet flow, especially for a longer recess length. Moreover, a decrease in the recess length results in a reduction in breakup length due to an intense gas–liquid shearing in a narrower recess section. For a lower backpressure, the amplitude of outlet flow generally increases when the recess length increases. However, this phenomenon is not obvious for the conditions of higher backpressure and lower pulsation frequency. Full article

The ducted coaxial propeller (DCP) has great application value in eVTOL aircraft because of its high safety, compactness, and low noise. A numerical simulation method for the DCP is established using the sliding mesh technique. A DCP was designed and manufactured for the lift and power test to verify the numerical method. The characteristics of airflow separation inside the DCP were studied, and the influence of the vortex restrain ring (VRR) on the suppression of airflow separation and on lift augmentation of the duct is analyzed. Results show that, when the tip clearance ratio increases from 0.336% to 1.342%, both the total lift and aerodynamic efficiency decrease by about 11.3%. The influence is mainly reflected in the formation of the tip vortex, airflow separation in the straight, and diffusion sections of the duct. Tip vortex and airflow separation increases DCP energy dissipation and clogs the inner wall of the duct, reducing the effective inner diameter and airflow through the duct. Moreover, the role of the duct is weakened, and the wake is contracted, which increases the induced power loss. By adding a VRR to the diffusion section, the tip vortex and airflow separation can be effectively suppressed, which can increase the aerodynamic efficiency by 5.1%. Full article
