Search Results (15)

To clarify the effect of surface characteristics on the interfacial properties of T1100-grade carbon fiber (CF)/bismaleimide (BMI) composites, three CFs (F1, F2, and F3) with different surface treatments and sizing agents were studied. Surface physicochemical properties and sizing–resin reaction behavior were characterized; nano-infrared spectroscopy was innovatively used to quantify interfacial structure. The correlation among surface features, interfacial structure, and mechanical properties was established. All dry-jet wet-spun T1100 CFs show smooth surfaces with similar roughness, and mechanical interlocking contributes little to interfacial adhesion. F3 possesses the highest active carbon, oxygen content, and epoxy value. Its sizing agent exhibits strong reactivity with BMI, forming a ~200 nm thick interface and the highest interfacial shear strength (IFSS) of 95.9 MPa. Constructing a “thick and strong” interface promotes shear failure from brittle to tough, significantly enhancing 90° tensile and interlaminar shear strength (ILSS). This work provides guidance for interface design and engineering applications of T1100/BMI composites in aerospace primary load-bearing structures. Full article

Hypersonic vehicles impose stringent requirements on lightweight structures to maintain mechanical integrity under extreme thermal environments. Bismaleimide (BMI)-based carbon fiber-reinforced polymer (CFRP) composites, featuring a high glass transition temperature and excellent thermal stability, are regarded as promising candidates for such applications. However, the high curing temperature and narrow processing window of BMI resins make it challenging to manufacture stiffened-shell structures with low defect levels and high fiber volume fractions. In this study, an integrated manufacturing route—hot-melt prepregging–filament winding–matched-metal mold forming—is proposed, and the key processing parameters are optimized via single-factor experiments and the Box–Behnken response surface methodology. The tensile strength of the laminate is selected as the response variable to evaluate the effects of the compression displacement (A), thermal consolidation/bonding temperature (B), heating rate (C), and cooling rate (D). The results reveal a unimodal dependence of the tensile strength on each parameter, with the significance ranking B > D > A > C; moreover, the A–B and A–D interactions are significant (p < 0.01). The established quadratic regression model exhibits good agreement with experimental data (R² = 0.974; R²_adj = 0.949). The predicted optimum conditions are A = 0.07 mm, B = 114.93 °C, C = 1.35 °C·min⁻¹, and D = 4.58 °C·min⁻¹, corresponding to a predicted tensile strength of approximately 2287 MPa. Validation experiments yielded 2291 MPa, in excellent agreement with the prediction. Microstructural observations indicate tight interlaminar bonding and a pronounced reduction in voids under the optimized conditions. Applying the optimized process to fabricate stiffened-shell demonstrators achieves a fiber volume fraction of >60% and a void content of <1%. This work provides a quantitatively defined processing window and parameter optimization basis for the high-quality manufacturing of BMI-CFRP stiffened-shell structures, with significant engineering relevance. Full article

The epoxy-bonded joint between carbon-fiber-reinforced bismaleimide (CF-BMI) and quartz-fiber-reinforced bismaleimide (QF-BMI) composites can meet the structure–function integration requirements of next-generation aviation equipment, and the structural design of their bonding zones directly affects their service performance. Hence, in this study, the carbon-fiber-reinforced bismaleimide composite ZT7H/5429, the woven quartz-fiber-reinforced bismaleimide composite QW280/5429, and epoxy adhesive film J-116 were used as research materials to investigate the influence of the bonding area size on the mechanical properties, and this study proposes a novel design methodology combining radial basis function (RBF) neuron machine learning with the NSGA-II algorithm to enhance the mechanical properties of the bonded components. First, a finite element simulation model considering 3D hashin criteria and cohesion was established, and its accuracy was verified with experiments. Second, the RBF neuron model was trained using the finite element tensile strength and shear strength data from various adhesive layer parameter combinations. Then, the multi-objective parameter optimization of the surrogate model was accomplished through the NSGA-II algorithm. The research results demonstrate a high consistency between the finite element simulation results and experimental outcomes for the epoxy-bonded CF/QF-BMI composite joint. The stress distribution of the adhesive layers is similar under the different structural parameters of adhesive films, though the varying structural dimensions of the adhesive layers lead to distinct failure modes. The trained RBF neuron model controls the prediction error within 2.21%, accurately reflecting the service performance under various adhesive layer parameters. The optimized epoxy-bonded CF/QF-BMI composite joint exhibits 16.1% and 11.2% increases in the tensile strength and shear strength, respectively. Full article

Carbon fiber/epoxy composites are widely used in aerospace due to their strength and ease of fab weatherrication, but they suffer from glass transition at high temperatures. In contrast, carbon fiber/bismaleimide composites exhibit superior thermal stability, irradiation resistance, and toughness. This study investigates the effects of thermal cycling and UV irradiation on carbon fiber/bismaleimide composite shells. Anti-symmetric shells with varying ply angles were tested under two-point tensile loading. Results show that these shells maintain stability between −70 °C and 180 °C, outperforming epoxy-based composites. This research offers valuable insights for aerospace applications of such bistable shells under thermal and UV aging conditions. Full article

In this study, a one-pot aryl diazonium reaction was used as a simple and mild method to graft graphene onto the smooth and inert surface of T1100-grade carbon fiber (CF) through covalent bonding without any damage on CF, to refine the interface performance of CF/bismaleimide (BMI) composites. XPS, SEM, AFM, and dynamic contact angle testing (DCAT) were used to characterize chemical activity, morphologies, and wettability on untreated and grafted CF surfaces. Meanwhile, the impact of the graft method on the tensile strength of CF was also examined using the monofilament tensile test. IFSS between CF grafted with graphene and BMI resin achieved 104.2 MPa after modification, increasing from 85.5 MPa by 21.8%, while the tensile strength did not decrease compared to the pristine CF. The mechanism of this interface enhancement might be better chemical bonding and mechanical interlock between CF grafted with graphene and BMI resin, which is generated from the high surface chemical activity and rough structure of graphene. This study may propose a simple and mild method to functionalize the CF surface and enhance the interface performance of composites without compromising the tensile properties of T1100-grade CF. Full article

Structural damping composites exhibit considerable potential in aerospace and other fields due to their excellent damping and vibration reduction performance, as well as their structural carrying capacity. However, conventional structural damping composite materials generally do not combine excellent mechanical and damping properties at the same time, which makes it difficult for them to meet the practical demand in engineering. In this paper, polyetherimide (PEI) non-woven fabric interlayer materials loaded with quantified polydopamine (PDA) and carboxylated multi-walled carbon nanotubes (MWCNTs-COOH) were used to prepare carbon fiber-reinforced bismaleimide composites through the co-curing process. The mechanical and damping properties of the composites were systematically studied. The results demonstrate that PEI non-woven fabric interlayers loaded with PDA and MWCNTs-COOH can synchronously improve the mechanical and damping properties of the co-cured composites. The incorporation of carbon nanotubes and polydopamine during the co-curing process synergistically improves the flexural strength, flexural modulus, interlaminar shear strength, and impact fracture toughness of the composites. Most importantly, damping properties show an increase of 45.0% in the loss factor of the co-cured composites. Moreover, the reinforcement mechanism was investigated using the optical microscopy and scanning electron microscopy, which indicated that the PEI interlayers loaded with carbon nanotubes and polydopamine form a rich resin area between the layers of the composites. Full article

The electrochemical impedance spectroscopy and weight gain tests were performed on carbon fiber/vinyl ester and carbon fiber/bismaleimide composites in 3.5% NaCl solution to study the electrochemical and water absorption behaviors. The microstructure morphology and the flexural property of the composites in the long-term exposure process were analyzed with the scanning electron microscope and four-point bending tests. The results revealed that after long-time immersion (>200 d), the water absorption of the two composites is less than 0.5%. This has little effect on the microstructural integrity, only with slight damage on the fiber/resin interfaces, but results in a significant decrease (about 84%) in the composite flexural property. The variation of the water absorption percentage shows good consistency with that of the resin capacitance (Q_c) and is negatively related to the variation of the resin resistance (R_po) and the low-frequency impedance (|Z|_0.01Hz) of the composites. A good linear relationship exists between the variations of phase angles in the middle-frequency range (0.1−10 Hz) and the |Z|_0.01Hz. The phase angle at 10 Hz (θ_10Hz) may be suggested as a suitable parameter to rapidly evaluate the performance of carbon fiber-reinforced polymer composites, just like for evaluating the protective performance of polymer-coated metals in the literature. Full article

Due to the excellent mechanical properties and heat resistance, bismaleimide matrix composite materials have been widely used in aircraft. However, they are susceptible to low-energy impacts, such as bird hits, gravel, tools falling, etc., which can easily result in delamination. The delamination can significantly reduce the compression performance of composites and become a potential hazard for aircraft in service. In this paper, a stitching method developed from the Z-pin manufacturing process was proposed to repair delaminated laminates. Firstly, the delaminated area was stitched by fiber bundles that were pre-impregnated with glue. Then, the fiber bundles threading through the laminate become the pins after the curing process, thus producing the bridging effect between delaminated layers. As a result, the in-plane compressive properties of the laminate are enhanced. The parameters, including the size, number, and position of the stitching hole, for the stitching repair were optimized, and the factors affecting the repair effect were discussed through both finite element analysis and experiments. The results showed that for a carbon fiber/bismaleimide composite plate with a circular delamination roughly 30 mm in diameter, the in-plane compressive strength can be recovered from 54.45% to 84.23% of the pristine plate, and the modulus was fully recovered. Full article

The review article presents an analysis of the properties of epoxy and thermosetting resin composites containing eugenol derivatives. Moreover, eugenol properties were characterized using thermogravimeters (TGA) and Fourier-transform infrared spectroscopy (FTIR). The aim of this work was to determine the possibility of using eugenol derivatives in polymer composites based on thermoset resins, which can be used as eco-friendly high-performance materials. Eugenol has been successfully used in the production of epoxy composites as a component of coupling agents, epoxy monomers, flame retardants, curing agents, and modifiers. In addition, it reduced the negative impact of thermoset composites on the environment and, in some cases, enabled their biodegradation. Eugenol-based silane coupling agent improved the properties of natural filler epoxy composites. Moreover, eugenol flame retardant had a positive effect on the fire resistance of the epoxy resin. In turn, eugenol glycidyl ether (GE) was used as a diluent of epoxy ester resins during the vacuum infusion process of epoxy composites with the glass fiber. Eugenol-based epoxy resin was used to make composites with carbon fiber with enhanced thermomechanical properties. Likewise, resins such as bismaleimide resin, phthalonitrile resin, and palm oil-based resin have been used for the production of composites with eugenol derivatives. Full article

When thermoplastic resin-toughened carbon fiber (CF) composites are formed by liquid resin transfer molding (RTM), the conventional methods cannot be used to set the fabric preform, which affects the overall mechanical properties of the composites. To address this challenge, the benzoxazine-based tackifier BT5501A was designed, a preforming–toughening bifunctional CF fabric was fabricated by employing thermoplastic polyaryletherketone (PEK-C), and an aviation RTM-grade bismaleimide (BMI) resin was used as the matrix to study the effect of the benzoxazine-based tackifier on the thermal curing property and heat resistance of the resin matrix. Furthermore, the preforming and toughening effects on the bifunctional CF fabric reinforced the BMI resin composites. The tackifier BT5501A has good process operability. The application of this tackifier can advance the thermal curing temperature of the BMI resin matrix and decrease the glass transition temperature of the resin, compared to that of the pure BMI resin. Furthermore, when the tackifier was added into the CF/PEK-C/BMI composites, the obtained CF/BT5501A/PEK-C/BMI composites had comparable compression strength after impact, pit depth, and damage area, compared to the CF/PEK-C/BMI composites, while the tackifier endowed the fabric preform with an excellent preforming effect. Full article

The demands for carbon fiber reinforced composites (CFRCs) are growing in the aviation industry for fuel consumption savings, despite the increasing risk of electromagnetic interference (EMI). In this work, polyacrylonitrile (PAN) sheets were prepared by electrospinning. Carbon nanofiber (CNF) sheets were obtained by the carbonization of PAN sheets. The laminate structures of the CF reinforced bismaleimide (BMI)-based composites were specially designed by introducing two thin CNF sheets in the upper and bottom plies, according to EMI shielding theory. The results showed that the introduction of CNF sheets led to a substantial increase in the EMI shielding effectiveness (SE) by 35.0% compared with CFRCs free of CNF sheets. The dominant EMI shielding mechanism was reflection. Noticeably, the introduction of CNF sheets did not impact the interlaminar shear strength (ILSS) of CFRCs, indicating that the strategy provided in this work was feasible for fabricating CFRCs with a high EMI shielding performance without sacrificing their mechanical properties. Therefore, the satisfactory EMI shielding and ILSS properties, coupled with a high service temperature, made BMI-based composites a promising candidate in some specific fields, such as high-speed aircrafts and missiles. Full article

This work concentrated on the interlaminar mechanical properties and toughening mechanism of carbon fiber-reinforced bismaleimide resin (CF/BMI) composites modified by polyacrylonitrile (PAN) nanofiber films. The PAN nanofiber films were prepared by electrospinning. End-notched flexure (ENF) and short-beam strength tests were conducted to assess the mode II fracture toughness (G_IIc) and interlaminar shear strength (ILSS). The results showed that the G_IIc and ILSS of PAN-modified specimens are 1900.4 J/m² and 93.1 MPa, which was 21.4% and 5.4% higher than that of the virgin specimens (1565.5 J/m² and 88.3 MPa), respectively. The scanning electron microscopy (SEM) images of the fracture surface revealed that the PAN nanofiber films toughen the composite on two scales. On the mesoscopic scale, the composite laminates modified by PAN formed a resin-rich layer with high strength and toughness, which made the crack propagate across the layers. At the microscopic scale, the crack propagation between two-dimensional nanofiber films led to constant pull-out and breakage of the nanofibers. As a result, the interlaminar fracture toughness of the composite laminates improved. Full article

Surface treatment is typically required to improve the bonding performance of carbon-fiber-reinforced composites. Herein, a wet peel ply was prepared using bismaleimide (BMI) resins as a matrix resin. The temperature–heating rate extrapolation method and rheological method were employed to study the reaction characteristics and viscosity-temperature characteristics of the matrix in the BMI wet peel ply. The curing temperatures of the BMI wet peel ply and the BMI prepreg were the same (200 °C), making this wet peel ply suitable for co-curing with the BMI prepreg. After treatment with the wet peel ply, the bonding strength of the BMI composite joint showed a mean shear strength of 35.5 MPa, which was 1.72% higher than that of the sanded composite and 17.5% higher than that of the composite treated with the dry peel ply. In addition, the BMI composite treated with the BMI wet peel ply exhibited good bonding stability with a coefficient of variation of 3.9. After damp-heat aging for 1440 h, the retention rate of shear strength at room-temperature was 82.3%. The relatively loosely woven carrier in the BMI wet peel ply increased the surface roughness of the composite, thus improving the bonding strength. Full article

Three-dimensional woven composites have been reported to have superior fracture toughness, fatigue life and damage tolerance compared with laminated composites due to through-thickness reinforcement. These properties make them lighter replacements for traditional high-strength metals and laminated composites. This paper will present impact resistance research on three-dimensional orthogonal woven composites consisting of carbon fibers/bismaleimide resin (BMI). A series of impact tests were conducted using the gas gun technique with the impacted target of 150 mm × 150 mm × 8 mm (length × width × thickness) and the cylindrical titanium projectile. The projectile velocity ranged from 180 m/s to 280 m/s, generating different results from rebound to perforation. This paper also presents a multiscale modeling strategy to investigate the damage and failure behavior of three-dimensional woven composites. The microscale and mesoscale are identified to consider the fiber/matrix scale and the tow architecture scale respectively. The macroscale model was effective with homogenized feature. Then a combined meso-macroscale model was developed with the interface definitions for component analysis in the explicit dynamic software LS-DYNA. The presented results showed reliable interface connection and can be used to study localized composites damage at a relatively high efficiency. Full article

The effects of reinforcement structures and hybrid types on the inter-laminar shear strength (ILSS) of carbon-glass hybrid fibers/bismaleimide composites under thermo-oxidative aging conditions were investigated. The process resulted in progressive deterioration of the matrix and fiber/matrix interfaces, in the form of chain scissions, weight loss, and fiber/matrix debonding, which significantly led to the decrease of the ILSS of composites. Moreover, the three-dimensional orthogonal woven hybrid composites (3D composites) showed higher ILSS retention rate than those of the laminated orthogonal hybrid composites (laminated composites). No delamination occurred in the aged 3D composites like in the aged laminated composites. This was because the Z-binder yarns in the 3D composites resisted the inter-laminar shear load, although the resin was damaged and the adhesive force between fiber bundles and resin decreased seriously after thermo-oxidative aging. Meanwhile, the ILSS retention rate of the laminated composites with the carbon fiber as intermediate layers was higher than that of the laminated composites with the glass fiber as the intermediate layers. This was because the carbon fiber/bismaleimide interface bonding performance was stronger than that of the glass fiber/bismaleimide at the same thermo-oxidative aging condition. Full article
