Search Results (6)

Search Parameters:
Keywords = capacitively-coupled chopper instrumentation amplifier (CCIA)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 7725 KB
Article
A 35 nV/√Hz Analog Front-End Circuit with Adjustable Bandwidth and Gain in UMC 40 nm CMOS for Biopotential Signal Acquisition
by Lu Liu, Bin Wang, Yiren Xu, Xiaokun Lin, Weitao Yang and Yinglong Ding
Sensors 2024, 24(24), 7994; https://doi.org/10.3390/s24247994 - 14 Dec 2024
Cited by 5 | Viewed by 3599
Abstract
This paper presents a 35 nV/√Hz analog front-end (AFE) circuitdesigned in the UMC 40 nm CMOS technology for the acquisition of biopotential signal. The proposed AFE consists of a capacitive-coupled instrumentation amplifier (CCIA) and a combination of a programmable gain amplifier (PGA) and [...] Read more.
This paper presents a 35 nV/√Hz analog front-end (AFE) circuitdesigned in the UMC 40 nm CMOS technology for the acquisition of biopotential signal. The proposed AFE consists of a capacitive-coupled instrumentation amplifier (CCIA) and a combination of a programmable gain amplifier (PGA) and a low-pass filter (LPF). The CCIA includes a DC servo loop (DSL) to eliminate electrode DC offset (EDO) and a ripple rejection loop (RRL) with self-zeroing technology to suppress high-frequency ripples caused by the chopper. The PGA-LPF is realized using switched-capacitor circuits, enabling adjustable gain and bandwidth. Implemented in theUMC 40 nm CMOS process, the AFE achieves an input impedance of 368 MΩ at 50 Hz, a common-mode rejection ratio (CMRR) of 111 dB, an equivalent input noise of 1.04 μVrms over the 0.5–1 kHz range, and a maximum elimination of 50 mV electrode DC offset voltage. It occupies an area of only 0.39 × 0.47 mm2 on the chip, with a power consumption of 8.96 μW. Full article
(This article belongs to the Special Issue Advances in Brain–Computer Interfaces and Sensors)
Show Figures

Figure 1

14 pages, 7409 KB
Article
A 1.87 µW Capacitively Coupled Chopper Instrumentation Amplifier with a 0.36 mV Output Ripple and a 1.8 GΩ Input Impedance for Biomedical Recording
by Xuan Phuong Tran, Xuan Thuc Kieu, Xuan Thanh Pham, Duy Phong Pham and Manh Kha Hoang
J. Low Power Electron. Appl. 2024, 14(3), 37; https://doi.org/10.3390/jlpea14030037 - 10 Jul 2024
Cited by 3 | Viewed by 4837
Abstract
Chopper and capacitively coupled techniques are employed in instrumentation amplifiers to create capacitively coupled chopper instrumentation amplifiers (CCIAs) that obtain a high noise power efficiency. However, the CCIA has some disadvantages due to the chopper technique, namely chopper ripple and a low input [...] Read more.
Chopper and capacitively coupled techniques are employed in instrumentation amplifiers to create capacitively coupled chopper instrumentation amplifiers (CCIAs) that obtain a high noise power efficiency. However, the CCIA has some disadvantages due to the chopper technique, namely chopper ripple and a low input impedance. The amplifier can easily saturate due to the chopper ripple of the CCIA, especially in extremely low noise problems. Therefore, ripple attenuation is required when designing CCIAs. To record biomedical information, a CCIA with a low power consumption and a low noise, low output ripple, and high input impedance (Zin) is presented in this paper. By introducing a ripple attenuation loop (RAL) including the chopping offset amplifier and a low pass filter, the chopping ripple can be reduced to 0.36 mV. To increase the Zin of the CCIA up to 1.8 GΩ, an impedance boost loop (IBL) is added. By using 180 nm CMOS technology, the 0.123 mm2 CCIA consumes 1.87 µW at a supply voltage of 1 V. According to the simulation results using Cadance, the proposed CCIA architecture achieves a noise floor of 136 nV/√Hz, an input-referred noise (IRN) of 2.16 µVrms, a closed-loop gain of 40 dB, a power supply rejection ratio (PSRR) of 108.6 dB, and a common-mode rejection ratio (CMRR) of 118.7 dB. The proposed CCIA is a helpful method for monitoring neural potentials. Full article
(This article belongs to the Special Issue Ultra-Low-Power ICs for the Internet of Things (2nd Edition))
Show Figures

Figure 1

12 pages, 5396 KB
Article
Ultra-Low Power Programmable Bandwidth Capacitively-Coupled Chopper Instrumentation Amplifier Using 0.2 V Supply for Biomedical Applications
by Xuan Thanh Pham, Xuan Thuc Kieu and Manh Kha Hoang
J. Low Power Electron. Appl. 2023, 13(2), 37; https://doi.org/10.3390/jlpea13020037 - 24 May 2023
Cited by 8 | Viewed by 4570
Abstract
This paper presents a capacitively coupled chopper instrumentation amplifier (CCIA) with ultra-low power consumption and programmable bandwidth for biomedical applications. To achieve a flexible bandwidth from 0.2 to 10 kHz without additional power consumption, a programmable Miller compensation technique was proposed and used [...] Read more.
This paper presents a capacitively coupled chopper instrumentation amplifier (CCIA) with ultra-low power consumption and programmable bandwidth for biomedical applications. To achieve a flexible bandwidth from 0.2 to 10 kHz without additional power consumption, a programmable Miller compensation technique was proposed and used in the CCIA. By using a Squeezed inverter amplifier (SQI) that employs a 0.2-V supply, the proposed CCIA addresses the primary noise source in the first stage, resulting in high noise power efficiency. The proposed CCIA is designed using a 0.18 µm CMOS technology process and has a chip area of 0.083 mm2. With a power consumption of 0.47 µW at 0.2 and 0.8 V supply, the proposed amplifier architecture achieves a thermal noise of 28 nV/√Hz, an input-related noise (IRN) of 0.9 µVrms, a closed-loop gain (AV) of 40 dB, a power supply rejection ratio (PSRR) of 87.6 dB, and a common-mode rejection ratio (CMRR) of 117.7 dB according to post-simulation data. The proposed CCIA achieves a noise efficiency factor (NEF) of 1.47 and a power efficiency factor (PEF) of 0.56, which allows comparison with the latest research results. Full article
(This article belongs to the Special Issue Ultra-Low-Power ICs for the Internet of Things (2nd Edition))
Show Figures

Figure 1

12 pages, 5375 KB
Article
A 1.2-µW 41-dB Ripple Attenuation Chopper Amplifier Using Auto-Zero Offset Cancelation Loop for Area-Efficient Biopotential Sensing
by Xuan Thanh Pham, Trung Kien Vu, Tien Dzung Nguyen and Loan Pham-Nguyen
Electronics 2022, 11(7), 1149; https://doi.org/10.3390/electronics11071149 - 6 Apr 2022
Cited by 14 | Viewed by 5155
Abstract
In this paper, a low-power and low-noise capacitive-coupled chopper instrumentation amplifier (CCIA) is proposed for biopotential sensing applications. A chopping technique is applied to mitigate the domination of flicker noise at low frequency. A new offset cancellation loop is also used to deal [...] Read more.
In this paper, a low-power and low-noise capacitive-coupled chopper instrumentation amplifier (CCIA) is proposed for biopotential sensing applications. A chopping technique is applied to mitigate the domination of flicker noise at low frequency. A new offset cancellation loop is also used to deal with the intrinsic offset, originating from process variation, to reduce ripple noise at the output of CCIA. Moreover, the optimization of the chip area was resolved by adding a T-network capacitor in the negative feedback loop. The CCIA is designed on 0.18 µm process CMOS technology with a total chip area of 0.09 mm2. The post-simulation results show that the proposed architecture can attenuate the output ripple up to 41 dB with a closed-loop gain of 40 dB and up to 800 Hz of bandwidth. The integrated input referred noise (IRN) of the CCIA is 1.8 µVrms over a bandwidth of 200 Hz. A noise efficiency factor (NEF) of 5.4 is obtained with a total power dissipation of 1.2 µW and a supply voltage of 1 V, corresponding to a power efficiency factor of 9.7 that is comparable with that of state-of-the-art studies. Full article
(This article belongs to the Special Issue Ultra-Low Voltage CMOS Front-End Design)
Show Figures

Figure 1

14 pages, 5827 KB
Article
A 0.6-µW Chopper Amplifier Using a Noise-Efficient DC Servo Loop and Squeezed-Inverter Stage for Power-Efficient Biopotential Sensing
by Xuan Thanh Pham, Ngoc Tan Nguyen, Van Truong Nguyen and Jong-Wook Lee
Sensors 2020, 20(7), 2059; https://doi.org/10.3390/s20072059 - 6 Apr 2020
Cited by 13 | Viewed by 7728
Abstract
To realize an ultra-low-power and low-noise instrumentation amplifier (IA) for neural and biopotential signal sensing, we investigate two design techniques. The first technique uses a noise-efficient DC servo loop (DSL), which has been shown to be a high noise contributor. The proposed approach [...] Read more.
To realize an ultra-low-power and low-noise instrumentation amplifier (IA) for neural and biopotential signal sensing, we investigate two design techniques. The first technique uses a noise-efficient DC servo loop (DSL), which has been shown to be a high noise contributor. The proposed approach offers several advantages: (i) both the electrode offset and the input offset are rejected, (ii) a large capacitor is not needed in the DSL, (iii) by removing the charge dividing effect, the input-referred noise (IRN) is reduced, (iv) the noise from the DSL is further reduced by the gain of the first stage and by the transconductance ratio, and (v) the proposed DSL allows interfacing with a squeezed-inverter (SQI) stage. The proposed technique reduces the noise from the DSL to 12.5% of the overall noise. The second technique is to optimize noise performance using an SQI stage. Because the SQI stage is biased at a saturation limit of 2VDSAT, the bias current can be increased to reduce noise while maintaining low power consumption. The challenge of handling the mismatch in the SQI stage is addressed using a shared common-mode feedback (CMFB) loop, which achieves a common-mode rejection ratio (CMRR) of 105 dB. Using the proposed technique, a capacitively-coupled chopper instrumentation amplifier (CCIA) was fabricated using a 0.18-µm CMOS process. The measured result of the CCIA shows a relatively low noise density of 88 nV/rtHz and an integrated noise of 1.5 µVrms. These results correspond to a favorable noise efficiency factor (NEF) of 5.9 and a power efficiency factor (PEF) of 11.4. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

18 pages, 2031 KB
Article
Fully Integrated Biopotential Acquisition Analog Front-End IC
by Haryong Song, Yunjong Park, Hyungseup Kim and Hyoungho Ko
Sensors 2015, 15(10), 25139-25156; https://doi.org/10.3390/s151025139 - 30 Sep 2015
Cited by 28 | Viewed by 11805
Abstract
A biopotential acquisition analog front-end (AFE) integrated circuit (IC) is presented. The biopotential AFE includes a capacitively coupled chopper instrumentation amplifier (CCIA) to achieve low input referred noise (IRN) and to block unwanted DC potential signals. A DC servo loop (DSL) is designed [...] Read more.
A biopotential acquisition analog front-end (AFE) integrated circuit (IC) is presented. The biopotential AFE includes a capacitively coupled chopper instrumentation amplifier (CCIA) to achieve low input referred noise (IRN) and to block unwanted DC potential signals. A DC servo loop (DSL) is designed to minimize the offset voltage in the chopper amplifier and low frequency respiration artifacts. An AC coupled ripple rejection loop (RRL) is employed to reduce ripple due to chopper stabilization. A capacitive impedance boosting loop (CIBL) is designed to enhance the input impedance and common mode rejection ratio (CMRR) without additional power consumption, even under an external electrode mismatch. The AFE IC consists of two-stage CCIA that include three compensation loops (DSL, RRL, and CIBL) at each CCIA stage. The biopotential AFE is fabricated using a 0.18 μm one polysilicon and six metal layers (1P6M) complementary metal oxide semiconductor (CMOS) process. The core chip size of the AFE without input/output (I/O) pads is 10.5 mm2. A fourth-order band-pass filter (BPF) with a pass-band in the band-width from 1 Hz to 100 Hz was integrated to attenuate unwanted signal and noise. The overall gain and band-width are reconfigurable by using programmable capacitors. The IRN is measured to be 0.94 μVRMS in the pass band. The maximum amplifying gain of the pass-band was measured as 71.9 dB. The CIBL enhances the CMRR from 57.9 dB to 67 dB at 60 Hz under electrode mismatch conditions. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1
