In extremely shallow water environments, the limited water depth is comparable to the maximum bubble radius. The pulsation of an underwater explosion bubble is strongly constrained by both the free surface and the rigid seabed, exhibiting complex nonlinear coupling effects, which are of great significance for the safety assessment and protection design of nearshore engineering. To address this issue, an axisymmetric two-dimensional numerical model based on the Eulerian finite element method (EFEM) with operator splitting technique and the volume of fluid (VOF) interface-capturing approach is established. Under the assumptions of inviscid and compressible flow, a systematic numerical investigation is carried out to examine the effects of the water depth parameter $\lambda$, position parameter $\gamma$, and buoyancy parameter $\delta$ on the bubble dynamics and the evolution of free surface structures. The results show that the maximum bubble radius, pulsation period, and jet characteristics are all significantly regulated by the above three parameters. Moreover, under multi-period bubble pulsation, different parameter conditions lead to diverse evolution characteristics of free surface structures, including the water spike, wrinkles, and water skirt. The findings reveal the governing mechanisms of key dimensionless parameters on the nonlinear bubble-multi-boundary coupling dynamics in extremely shallow water explosions, providing an important numerical basis and theoretical reference for the theoretical analysis and safety design of related shallow water explosion engineering problems. Full article

The study of bubble pulsation from underwater explosions is critical for applications in marine resource exploration, underwater demolition, and offshore engineering. However, the existing research methods have significant limitations: Laboratory experiments struggle to replicate the dynamic decompression during the process of bubble rising. Field experiments in seas or lakes find it difficult to systematically cover complex parameter ranges. Furthermore, theoretical calculations face the problems of accurately coupling the bubble pulsation with its buoyancy-driven ascent. Therefore, this paper proposes a novel method for calculating the bubble pulsation period of underwater explosions. This method accurately simulates the pulsation and buoyancy-driven ascent of an underwater explosion bubble. Based on the bubble’s energy attenuation characteristics, it establishes the relationship between the pulsation period, TNT equivalent, and ambient hydrostatic pressure. To verify the accuracy of the method, we conducted underwater explosion experiments in the South China Sea with varying TNT equivalents and detonation depths. Abundant bubble pulsation period data of underwater explosions were obtained spatially by deploying hydrophone arrays at various depths. The close agreement between the theoretical predictions and the experimental results confirms the accuracy of the proposed method. By matching the measured values of the first pulsation period and the ratio of the second pulsation period to the first against a database of theoretical curves, a combination of depth and charge equivalent that satisfies both values can be identified, thereby enabling the inversion of the explosion parameters. Full article

As a core component in renewable energy systems for grid regulation, hydropower units are increasingly exposed to flow conditions that elevate the risk of cavitation and erosion, posing significant challenges to the safe operation of flow-passage components. In this study, model testing and computational fluid dynamics (CFD) simulations are employed to investigate the hydraulic performance and cavitation behavior of a bulb turbine operating under rated head conditions and varying cavitation numbers. The analysis focuses on how changes in cavitation intensity affect flow characteristics and efficiency within the runner region. The results show that as the cavitation number approaches its critical value, the generation, growth, and collapse of vapor cavities increasingly disturb the main flow, causing a marked drop in blade hydraulic performance and overall turbine efficiency. Cavitation predominantly occurs on the blade’s suction side near the trailing edge rim and in the clearance zone near the hub, with bubble coverage expanding as the cavitation number decreases. A periodic inverse correlation between surface pressure and the cavitation area is observed, reflecting the strongly unsteady nature of cavitating flows. Furthermore, lower cavitation numbers lead to intensified pressure pulsations, aggravating flow unsteadiness and raising the risk of vibration. Full article

In numerical simulations of underwater explosions, inaccuracies in the parameters of the Jones–Wilkins–Lee (JWL) equation of state often result in significant deviations between predicted shock wave pressure peaks or bubble pulsation periods and experimental or empirical results. To achieve the precise forecasting of underwater explosion loads, a corrected method for adjusting the initial conditions of explosives is proposed. This method regulates explosion loads by correcting the initial density and initial internal energy per unit mass of the explosive, offering a straightforward implementation and easy extension to complex scenarios. In addition, the accuracy and feasibility of the proposed method were validated through comparisons with experimental data and empirical formulas from international studies. The numerical framework employs the Runge–Kutta Discontinuous Galerkin (RKDG) method to solve the one-dimensional Euler equations. The spatial discretization of the Euler domain is achieved using the discontinuous Galerkin (DG) method, while temporal discretization utilizes a third-order Runge–Kutta (RK) method. The results demonstrate that the proposed correction method effectively compensates for load discrepancies caused by inaccuracies in the JWL equation of state parameters. After correction, the maximum error in the shock wave pressure peak is reduced to less than 4.5%, and the maximum error in the bubble pulsation period remains below 1.9%. Full article

To investigate the feasibility and formation laws of fabricating micro-dimples induced by near-wall laser-induced cavitation bubble (LICB) on 7050 aluminum alloy. A high-speed camera and a fiber-optic hydrophone system were used to capture pulsation evolution images and acoustic signals of LICB. Meanwhile, a three-dimensional profilometer was employed to examine the contour morphology of the surface micro-dimple on the specimen. The results show that at an energy level of 500 mJ, the total pulsation period for the empty bubble is 795 μs, with individual pulsation periods of 412.5 μs, 217 μs, and 165 μs for the first, second, and third cycles, respectively, with most energy of the laser and bubble being consumed during the first evolution period. Under the synergy of the plasma shock wave and collapse shock wave, a spherical dimple with a diameter of 450 μm is formed on the sample surface with copper foil as the absorption layer. A model of micro-dimple formed by LICB impact is established. As the energy increases, the depth of the surface micro-dimple peaks at an energy of 400 mJ and then decreases. The depth of the surface micro-dimple increases with the increase in the number of impacts; the optimal technology parameters for the micro-dimple formation by LICB impact are as follows: the absorption layer is copper foil, the energy is 400 mJ, and the number of impacts is three. Full article

The subject of a gas jet generated by underwater detonation is an important issue in the field of underwater propulsion. The experimental system of underwater detonation is established, which utilizes a high-speed camera to record the morphological changes in bubbles and various pressure sensors to measure the flow field pressure. The effect of nozzles and the pressure of the flow field are analyzed thoroughly. The comparison of the bubble and field pressure shows that the shrinking nozzle increases the peak pressure of the transmitted shock wave generated by underwater detonation compared with that of the straight nozzle. Simultaneously, the water–air mixing phenomenon caused by the gas jet is enhanced. Under the influence of the reflected shock wave and the converging angle of the nozzle, the pulsation process of the bubble is inhibited enormously, which results in the bubble energy being substantially below that of the straight nozzle. The bubble pulsation period is 24.2 ms when the shrinking nozzle is installed, and the pressure of the bubble pulsation is quite small, only 9.8 kPa. On the contrary, the expansion angle increases the velocity of the gas jet, suppressing the water–gas mixing phenomenon while enhancing the bubble pulsation process. The bubble pulsation period is 33.0 ms when the expanding nozzle is equipped, which is larger than the 31.2 ms of the straight nozzle and the bubble pulsation pressure is higher, at 26.1 kPa. Although the bubble energy is increased when the expanding nozzle is installed, thus generating a higher pulsation pressure, the peak pressure and direction of the shock wave are changed in the water. Full article

A direct drive servovalve has some inherent benefits over its conventional counterparts, but also has better reliability and output power. However, due to the rigid connection between the spool and the motor, which takes the place of interstage drive-by fluid, the spool oscillation is a long-standing unsolved problem. In order to study the oscillation mechanism and the influencing factors, a double-circuit direct drive servovalve was numerically simulated. An oil return valve cavity was concentrated on as the main flow domain and was used to analyze the fluid flow characteristics. Local cavitation fraction and surface average cavitation fraction were defined to evaluate the cavitation situation. The periodic growth process of bubbles in the valve cavity was obtained. The numerical results show that bubbles in the oil return valve cavity changes, although the occurrence, evolution, and collapse stages were certain. The intensity of pressure pulsation caused by bubble variation is highly related to the bubbles causing the cavitation, which suggests a workable way to inhibit the spool oscillation. Full article

High-speed underwater vehicles are subjected to complex multiphase turbulent processes, such as the growth, development, shedding, and collapse of cavitation bubbles. To study the cavity evolution and pressure pulsation characteristics, in this paper, cloud cavitation over a conical axisymmetric test body with four pressure sensors is investigated. A multi-field simultaneous measurement experiment method for the natural cavitation of underwater vehicles is proposed to understand the relationship between cavity evolution and instantaneous pressure. The results show that the evolution of cloud cavitation can be mainly divided into three stages: (I) the growth process of the attached cavity, (II) the shedding process of the attached cavity, and (III) the collapse of detached cavities. The evolution of the attached cavity and collapse of the large-scale shedding cavity will cause strong pressure pulsations. It is found that the cavitation number plays an important role in cavitation evolution and pressure pulsation. Interestingly, as the cavitation number decreases, the fluctuation intensity of cavitation increases significantly and gradually presents obvious periodicity. Moreover, the unstable cavitating flow patterns are highly correlated with the time domain and frequency domain characteristics of pressure. Especially, as the cavitation number decreases, the main frequency becomes lower and the pressure band becomes more concentrated. Full article

It is well known that the bubble dynamics and load characteristics of cavitation bubbles depend to a great extent on their proximity to the boundary. The purpose of this study is to explore the relationship between the boundary curvature and bubble dynamics, as well as the load characteristics, and summarize the relevant change laws. This study takes three hemispheres of different curvatures and one flat board as its main research boundaries. The hemisphere was chosen as the curved surface boundary because the hemisphere represents the simplest type of curved surface boundary. This method allowed us to easily observe the experimental results and summarize the change laws of bubble dynamics and load characteristics. A high voltage electricity of 400 V was used to produce stable and repeatable electric spark bubbles in this experiment. Since the pulsation time of the bubbles is very short, we used a high-speed camera to acquire the necessary photographs. We also used a Hopkinson bar (HPB) to measure the bubble collapse load. Suppose that the dimensionless parameter of curvature is ζ and the dimensionless parameter of the explosion distance is γ. By summarizing the 44 groups of the experimental results under different combinations of ζ and γ, we found that the cavitation bubble dynamics and loading characteristics are affected by ζ. With an increase of ζ, the shockwave load and bubble collapse load will decrease. In addition, in terms of load characteristics, this study further verified the change trend of the shockwave load and bubble collapse load with γ. For the bubble shrink shape, this paper illustrates the relationship between the bubble’s shrink shape and its shrinkage speed. Four typical bubble shrink shapes are summarized. The effects of different ζ and γ values on the jet are preliminarily explored using the experimental results, and, by considering the experimental results, the developmental trends of the time of the bubble’s first pulsation period are discussed. Full article
